Fire Alarm Systems | RSS Multi‑candela Strobes
RSS Multi‑candela Strobes
www.boschsecurity.com
u UL Regulated voltage range of 16 V to 33 V using
filtered DC or unfiltered FWR voltage
u Strobes produce 1 flash per second over the
regulated voltage range
These Wheelock multi‑candela strobes provide
intensities of 15 cd, 30 cd, 75 cd, 95 cd
(ceiling‑mount), and 110 cd (wall‑mount).
They can be synchronized when used with the
DSM-12/24-R Synchronization Module or a compatible
control panel. Synchronized strobes can eliminate
possible restrictions on the number of strobes in the
field of view. When synchronized, these strobes
comply with ADA requirements concerning
photosensitive epilepsy and meet the requirements of
NFPA 72.
Certifications and approvals
Cooper Wheelock, Inc. holds these Listings and
Approvals:
Region
Certification
USA UL UUKC: Signaling Appliances and Equip-
ment for the Hearing Impaired (UL1971)
CSFM see our website
u ADA/NFPA/ANSI compliant
u Zero inrush above peak
u Fast installation with In and Out screw terminals
using 18 AWG to 12 AWG (ISO 0.75 mm2 to 4 mm2)
diameter wire
Installation/configuration notes
Compatible Products
The following products are compatible with the RSS
Strobes:
Category Product ID Product Description
Control
D7024
1
Addressable FACP
Panels
D7024 Conventional FACP
D8024
D9124
D10024A
FPD-7024
2
2
2
1
Analog FACP
Addressable FACP
Analog FACP
Addressable FACP
FPD-7024 Conventional FACP
FPA-1000 Analog Addressable FACPs
Modules SM‑12/24‑R Single synchronization module (red)
DSM‑12/24‑R Dual synchronization module (red)
1
When used with a D7039 Multiplex Expansion
Module, the FPD-7024 and D7024 become
addressable fire alarm control panels (FACPs).
2 | RSS Multi‑candela Strobes
2
For synchronization, use the DSM-12/24-R
Synchronization Module with these control panels.
Mounting Considerations
These strobe appliances use an integral strobe
mounting plate for mounting on the indicated back
boxes for the indicated applications:
Conduit
Applications
Single‑gang •
Double‑gang • •
Four‑inch square •
100‑mm European •
BB‑R • •
SHBB‑R •
Surface
Mounted
Flush
Mounted
All models have an attractive cover plate for a clean,
finished appearance.
Wiring
Notice
Do not use these strobe units in coded or pulsed
signaling circuits.
The input terminals accept wires with diameters
between 18 AWG and 12 AWG (ISO 0.75 mm2 and
4 mm2).
Parts included
75 cd: 253 mA RMS maximum
110 cd: 347 mA RMS maximum
Voltage (Input): 24 VDC nominal;
16 VDC or FWR to 33 VDC or FWR
Environmental
Relative Humidity: Up to 95%, non‑condensing
Temperature (Operating): +32°F to +120°F (0°C to +49°C)
Mechanical
Dimensions (H x W x D): 4.75 in. x 4.75 in. x 2.5 in.
(12.1 cm x 12.1 cm x 6.4 cm)
Material: Molded plastic enclosure incorporating a
Xenon flashtube and Lexan lens.
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and
must be treated accordingly.
Ordering information
RSS‑24MCC‑FR Ceiling‑mount Strobe (square, red)
Square red ceiling‑mount strobe providing intensities
of 15 cd, 30 cd, 75 cd, or 95 cd
Order number RSS-24MCC-FR
RSS‑24MCC‑FW Ceiling‑mount Strobe (square, white)
Square white ceiling‑mount strobe providing
intensities of 15 cd, 30 cd, 75 cd, or 95 cd
Order number RSS-24MCC-FW
Quant. Component
1 Strobe
1 Hardware pack
1 Literature pack
Technical specifications
Electrical
24MCC models
Current Draw at 16 VDC to
33 VDC:
Current Draw at 16 FWR to
33 FWR:
24MCW models
Current Draw at 16 VDC to
33 VDC:
Current Draw at 16 FWR to
33 FWR:
15 cd: 65 mA RMS maximum
30 cd: 105 mA RMS maximum
75 cd: 189 mA RMS maximum
95 cd: 249 mA RMS maximum
15 cd: 110 mA RMS maximum
30 cd: 170 mA RMS maximum
75 cd: 280 mA RMS maximum
95 cd: 375 mA RMS maximum
15 cd: 60 mA RMS maximum
30 cd: 92 mA RMS maximum
75 cd: 165 mA RMS maximum
110 cd: 220 mA RMS maximum
15 cd: 102 mA RMS maximum
30 cd: 155 mA RMS maximum
RSS‑24MCW‑FR Wall‑mount Strobe (square, red)
Square red wall‑mount strobe providing intensities of
15 cd, 30 cd, 75 cd, or 110 cd
Order number RSS-24MCW-FR
RSS‑24MCW‑FW Wall‑mount Strobe (square, white)
Square white wall‑mount strobe providing intensities
of 15 cd, 30 cd, 75 cd, or 110 cd
Order number RSS-24MCW-FW
Accessories
BB‑R Steel Back Box
Black, 10.2 cm (4 in.) square, 3.8 cm (1.5 in.) deep
Order number BB-R
DBB‑R Steel Back Box (red)
8.6 cm (3.375 in.) square, 5.6 cm (2.1875 in.) deep
Order number DBB-R
DSM‑12/24‑R Dual Synchronization Module (red)
A 12/24 VDC Cooper Wheelock module that
synchronizes notification appliances on a single Class
A or two Class B circuits.
Order number DSM‑12/24‑R
3 | RSS Multi‑candela Strobes
Represented by:
Americas: Europe, Middle East, Africa: Asia-Pacific: China: America Latina:
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: +1 800 289 0096
Fax: +1 585 223 9180
security.sales@us.bosch.com
www.boschsecurity.us
Bosch Security Systems B.V.
P.O. Box 80002
5617 BA Eindhoven, The Netherlands
Phone: + 31 40 2577 284
Fax: +31 40 2577 330
emea.securitysystems@bosch.com
www.boschsecurity.com
Robert Bosch (SEA) Pte Ltd, Security
Systems
11 Bishan Street 21
Singapore 573943
Phone: +65 6571 2808
Fax: +65 6571 2699
apr.securitysystems@bosch.com
www.boschsecurity.asia
Bosch (Shanghai) Security Systems Ltd.
201 Building, No. 333 Fuquan Road
North IBP
Changning District, Shanghai
200335 China
Phone +86 21 22181111
Fax: +86 21 22182398
www.boschsecurity.com.cn
Robert Bosch Ltda Security Systems Division
Via Anhanguera, Km 98
CEP 13065-900
Campinas, Sao Paulo, Brazil
Phone: +55 19 2103 2860
Fax: +55 19 2103 2862
latam.boschsecurity@bosch.com
www.boschsecurity.com
© Bosch Security Systems 2014 | Data subject to change without notice
2712732171 | en, V4, 19. Aug 2014
NATP‑R Trim Plate (red)
13.3 cm (5.25 in.) square, 2.1 cm (0.8125 in.) thick.
Not Available.
Order number NATP-R
NATP-W Trim Plate (white)
13.3 cm (5.25 in.) square, 2.1 cm (0.8125 in.) thick
Order number NATP-W
RP‑R Retrofit Plate (red)
20.3 cm (8 in.) high, 14.9 cm (5.875 in.) wide.
Not Available.
Order number RP-R
SBB‑R Surface‑mount Back Box (red)
14 cm (5.5 in.) x 14.2 cm (5.6 in.) x 9.1 cm (3.6 in.)
Order number SBB-R
SBB‑W Surface‑mount Back Box (white)
14 cm (5.5 in.) x 14.2 cm (5.6 in.) x 9.1 cm (3.6 in.)
Order number SBB-W
SFP‑R Semi‑flush Plate (red)
15.2 cm (6 in.) square by 0.8 cm (0.3125 in.) thick
Order number SFP-R
SHBB‑R Shallow Surface Back Box (red)
12.7 cm (5 in.) square by 4 cm (1.56 in.) deep
Order number SHBB-R
