Bosch Oven Carriage User Manual

5 (1)
Bosch Oven Carriage User Manual

Built-in Appliances 2008

Comfort

Oven carriage

The oven carriage provides convenience of a special kind. Wire grills and baking sheets are simply hung onto the door and pulled out as it is opened, so there’s no need to reach into the hot oven and both hands are free for the work at hand. Available on HBN 334551.

Telescopic extension rails/shelves

Extendible telescopic shelves are available as an additional component for all ovens as fully extendable shelves or semi-extendable rails. They allow you to draw out wire shelves and baking trays on three levels. Allowing you to not have to reach into a hot oven when basting a roast. Integrated in HBN 23 T 551 J. For all other units, available as an accessory.

Let our passion become your inspiration

Oven lighting

Halogen lights provide excellent illumination. For some models the oven light can be switched on even when the door is closed, allowing you to see what is happening inside the oven anytime. The SoftLight function allows for a smooth dimming function.

Eco Clean

This world innovation ensures that hard to reach areas are cleaned effectively. The ceramic spherules in the surface allow for a profound

increase of grease. Oxygen, bound in the ceramic, breaks down the soiling from all sides when the oven is hot. The oxygen stores are regenerated during normal oven operation. This new system is able to extend the average service life of the appliance. Four times more soiling cycles can be run in comparison to other existing conventional catalytic systems. Selected models come equipped standard with rear wall EcoClean liners. Sidewall liners and ceilings are available as accessories.

Granite Enamel

A new attractive lighter grey enamel cavity provides easy cleaning with an extreme scratch and acid resistant surface.

Full glass inner door

The new full glass inner door not only looks elegant but is also easy to clean. When opened you can comfortably place trays or roasters on the door.

XXL oven cavity

The external dimensions of the new ovens are the same but the inner cavity has become XXL in size. There is no other 60 cm wide oven, which offers as much space, with a capacity of up to 65 litres. With 10 % larger baking trays offering space for loads of pastries as well as for a large turkey.

XXL oven window

The new oven windows, which have been enlarged from between 40% to 80%, allow for an overall view of cakes or roasts. This is particularly beneficial when baking on several levels.

Safety

Child lock

It’s an effective child protection system as it prevents unauthorised access to oven and hot plate functions.

Cool touch front

Quadruple glazing incorporated into the ventilated door design keeps the front door temperature between 40°C -60°C. This saves energy and ensures a safe environment for you and your children in the kitchen.

Automatic safety switch off

In the event that the appliance senses no further instructions after a specific time period, it will switch off automatically, this is dependent on the temperature after 30min-10hours.

Saves Time

Quick heat (automatic/manual)

The quick start oven heating system will ensure that oven reaches

the desired temperature up to 35% faster without consuming more energy, e.g. it takes only 5 minutes to reach 180°C. Once the temperature has been reached, the oven automatically switches to the pre-selected heating method. For manually operated models an acoustic signal resounds to select the heating method.

Multifunction 3-D premium/comfort

Multifunction 3-D comfort means easy operation, professional roasting and baking together with optimised safety. Large contrasting read-outs gives you the time of day, selected temperature and heating method. The 3-D PREMIUM ovens offer an additional automatic roasting facility with 24 programmes that allow you to prepare the most ambitious dishes. Available on HBN 560551 B or

HBN 334551.

Electronic clock/child lock

Large contrasting read-outs give you the time of day. An alarm clock and a Start/Stop function are included, which allows you to set up the on/off switch of the oven. All models with electronic clock have the child lock protection system.

Heating Methods

Defrost

The defrosting heating method is perfect for gentle defrosting of frozen food items.

Top/bottom heat

Top/ bottom heat is the classical heating method for all items you want to bake or roast.

Top/bottom heat special

The heating method top/ bottom heat special prevents cakes and pastries from drying out. So it’s ideal for moist cakes, yeast-risen pastries or frozen pastries.

Separate bottom heat

Separated bottom heat allows you to brown cakes and pastries or to heat dishes in a Bain Marie.

3-D hot air

By means of 3-D hot air, cooking cakes and biscuits can be prepared on up to three levels at the same time.

Pizza function

The pizza level combines hot air cooking and bottom heat. This is ideal when preparing frozen food like pizza or French fries without preheating.

Hot air grilling

The hot air grilling system prepares large roasts, such as duckling or goose, with a rotary spit quality. This is done by the grill and fan being switched on and off alternatively (patented interval control mode).

Large surface grill

The large surface grill is ideal when you would like to prepare fish, steaks or toast in the oven. It’s also suited for au gratin dishes.

Small surface grill

When you use the small surface grill only the middle part of the grill-heating element is heated. This is the ideal setting for small amounts, e.g. four slices of toast.

Intensive heat

Intensive heat is ideal for pizza, bread and frozen food because of the unsurpassed strong bottom heat.

Keep warm function

The keep warm function keeps the correct temperature for a longer period of time. Plates and cups are kept at the correct temperature by means of the preheat function.

Bosch Ovens

HBL 3552 – 90 cm Oven

multifunction

HEATING METHODS (8)

Defrosting, top/bottom heat, bottom heat, hot air, 3D hot air, hot air grilling, Large surface grill, Top heat

COMFORT AND SAFETY

Maximum oven temperature 250°C

Electronic clock

Cool front, oven door below 50°C

Cool air ventilation

66L oven cavity

CLEANING

• Easy cleaning enamel oven walls

DESIGN

• Interior lights

STANDARD ACCESSORIES

1 Enamel baking tray

1 Combination Grid

Overall (H x W x D): 47.4 x 89.4 x 54.5 cm

Aperture (H x W x D): 46.0 x 86.0 x 55.0 cm

Capacity: 66 litres

Rating: 2800 W

HBN 560551 B Eye-level Oven

multifunction 3-d premium

Heating methods (8)

Top/bottom heat, bottom heat, 3D hot air, hot air grilling, radiant small and large surface grill, pizza mode, top/bottom heat special

COMFORT AND SAFETY

Maximum oven temperature 300°C, exact electronic temperature control

Symbol display

24 automatic roasting programmes

XL – Oven cavity 58 litres with Granite Enamel

Quick heat (pre-heats 35% quicker)

Electronic clock

Safety switch off

Child lock to prevent unsupervised operation of the appliance

Cool front, oven front is below 50°C

Oven light, separate on/off button

CLEANING

EcoClean system, easy clean of coated surfaces

Grease and odour catalysator

Full glass inner door

design

• Bar handle, pop-up controls

STANDARD ACCESSORIES

1 wire rack

1 grill wire

1 universal pan

Handle for removing pan

Overall (H x W x D): 59.5 x 59.5 x 54.8 cm Aperture (H x W x D): 59.5 x 56.0 x 55.0 cm Capacity: 58 litres

HBN 36 L 651 (left-hinged) Eye-Level Oven HBN 36 R 651 (right-hinged) Eye-Level Oven

MULTIFUNCTION 3D PREMIUM

HEATING METHODS (10)

Top/bottom heat, bottom heat, 3Dhot air, hot air grilling, small and large area surface grill, Pizza mode, defrost, top/bottom heat special, keep warm

COMFORT AND SAFETY

Maximum oven temperature 300°C

Symbol display with automatic temperature display

24 Automatic Roasting Programmes

Sabbath function

XL – Oven cavity 58 litres with Granite Enamel

Quick heat (pre-heats 35% quicker)

Electronic clock

Safety switch off

Child lock to prevent unsupervised operation of the appliance

Cool Front, oven front is below 40°C

Oven light, separate on/off button

CLEANING

EcoClean system, easy clean of coated surfaces (back)

Grease and odour catalysator

Full glass inner door

DESIGN

Full glass or stainless steel front

Bar handle, Pop-up controls

STANDARD ACCESSORIES

1 enamel baking tray, 1 universal pan,

1 combo grid

Overall (H x W x D): 59.5 x 59.5 x 54.8 cm Aperture (H x W x D):

57.5 x 59.7 x 56.0 x 55.0 cm Capacity: 58 litres

HBN 334551 Eye-level Oven

multifunction 3-d comfort

Heating methods (8)

Defrosting, top/bottom heat, bottom heat, 3D hot air, hot air grilling, radiant small and large surface grill, pizza mode

COMFORT AND SAFETY

Oven carriage mechanical

Maximum oven temperature 270°C, electronic controlled

XXL – Oven cavity 65 litres with Granite Enamel

Quick heat (pre-heats 35% quicker)

Electronic clock

Child lock to prevent unsupervised operation of the appliance

Cool front, oven front is below 50°C

Oven light

CLEANING

EcoClean system, easy clean of coated surfaces

Grease and odour catalysator

Full glass inner door

DESIGN

• Bar handle, pop-up controls

STANDARD ACCESSORIES

1 enamel baking tray

1 universal pan

1 grid

Overall (H x W x D): 59.5 x 59.5 x 54.8 cm Aperture (H x W x D):

57.5-59.7 x 56.0 x 55.0 cm Capacity: 65 litres

HBN 23 T 551 J Eye-level Oven



HBN 230250 E Eye-level Oven

multifunction



multifunction

Heating methods (6)



Heating methods (7)

• Top/bottom heat, bottom heat, 3D hot air, hot air grilling, large grill

• Defrosting, top/bottom heat, bottom heat, hot air, hot air grilling,









variable small and large surface grill

COMFORT AND SAFETY



COMFORT AND SAFETY

• Maximum oven temperature 270°C, electronic controlled

• XL oven cavity, 58 litres with Granite Enamel



• Maximum oven temperature 250°C

Symbol display



• XL oven cavity, 58 litres with Granite Enamel

• Quick Heat (pre-heats oven 35% quicker)



Electronic clock

Electronic clock



• Child lock to unsupervised operation of the appliance

• Telescopic extension rails included



Cooling fan

• Child lock to prevent unsupervised operation of the appliance

Oven light

• Cool front, oven front is below 50°C



CLEANING







CLEANING



• EcoClean system, easy clean of coated surfaces

• EcoClean system, easy clean of coated surfaces



• Full glass inner door

• Grease and odour catalysator



design

• Full glass inner door









Bar handle

design

Includes 3 telescopic

standard accessories

Bar Handle, pop-up controls

extension rails







• 1 enamel baking tray

standard accessories



• 1 aluminium baking tray

• 1 enamel baking tray



1 grid

1 universal pan



Overall (H x W x D):

1 grid









59.5 x 59.5 x 54.8 cm

Overall (H x W x D):



Aperture (H x W x D):

59.5 x 59.5 x 54.8 cm



57.5-59.7 x 56.0 x 55.0 cm

Aperture (H x W x D):



Capacity: 58 litres

57.5 – 59.7 x 56.0 x55.0 cm







Capacity: 58 litres







HBN 210250 E Eye-level Oven

multifunction

Heating methods (7)

Defrosting, top/bottom heat, bottom heat, hot air, hot air grilling, radiant small and large surface grill

COMFORT AND SAFETY

Maximum oven temperature 250°C

XL oven cavity, 58 litres with Granite Enamel

Mechanical timer

Cooling fan

Oven light

CLEANING

EcoClean system, easy clean of coated surfaces

Smooth cavity

Full glass inner door

design

• Bar handle

STANDARD ACCESSORIES

1 enamel baking tray

1 aluminium baking tray

1 grid

Overall (H x W x D): 59.5 x 59.5 x 54.8 cm Aperture (H x W x D):

57.5-59.7 x 56.0 x 55.0 cm Capacity: 58 litres

HBN 110250 Eye-level Oven

conventional

Heating methods (4)

• Top/bottom heat, bottom heat, radiant small and large surface grill

COMFORT AND SAFETY

Maximum oven temperature 250°C

XL oven cavity, 58 litres with Granite Enamel

Mechanical timer

Cooling fan

Oven light

CLEANING

• Smooth oven cavity

design

• Bar handle

standard accessories

1 enamel baking tray

1 grid

Overall (H x W x D): 59.5 x 59.5 x 54.8 cm Aperture (H x W x D):

57.5-59.7 x 56.0 x 55.0 cm Capacity: 58 litres

HEN 100250 E Under-counter Oven

conventional

Heating methods (4)

• Top/bottom heat, bottom heat, radiant small and large surface grill

COMFORT AND SAFETY

Maximum oven temperature 250°C

XL oven cavity, 58 litres with Granite Enamel

Oven light

CLEANING

• Smooth oven cavity

design

• Bar handle

standard accessories

1 enamel baking tray

1 grid

Overall (H x W x D): 59.5 x 59.5 x 54.8 cm Aperture (H x W x D):

57.5-59.7 x 56.0 x 55.0 cm Capacity: 58 litres

HEN 100250 E – Stainless Steel

HEN 100220 E – White

HEN 100260 E – Black

DHU 635 GZA Extractor – 60 cm

EXHAUST OR RECIRCULATING OPERATION

COMFORT AND SAFETY

Grease filter, adjustable perspex cover

3 power levels

Includes metal and carbon filter

DESIGN

Seperate light switch

Worktop lighting – 1 x 40 Watt

Unit dimensions (H x W x D): 14.0 x 60.0 x 51.0 cm Rating: 130 W

Max. extraction: 300 m3/h

DHU 635 GZA – Stainless Steel

DHU 636 GZA – Black

DHU 632 GZA – White

NKE 625 A 01 Ceramic Hob – 60cm

CERAMIC HOB WITHOUT CONTROLS

COMFORT AND SAFETY

4 High Speed cooking zones

4 fold residual heat indicators

DESIGN

Brushed Stainless steel frame

To be combined with under-counter oven HEN…

Overall (H x W x D): 4.5 x 57.6 x 51.8 cm Aperture (H x W x D): 4.5 x 56.0 x 50.0 cm Rating: 6400W

NCM 615 A 01 Stainless Steel Hob – 60 cm

enamel hob without controls

COMFORT AND SAFETY

2 speed plates

2 normal plates

DESIGN

• Stainless steel

Overall (H x W x D): 5.6 x 58.0 x 51.0 cm Aperture (H x W x D): 3.9 x 56.0 x 49.0 cm Rating: 7000 W

NCM 615 A 01 – Stainless Steel

NCM 616 A 01 – Black

NCM 612 A 01 – White

Bosch Under-counter Set Options

Steam cooking is the ideal form of gentle cooking

For vegetables, fish, meat and casseroles. Cooking with steam makes the use of oil a thing of the past, as you are able to prepare a healthy meal while still enjoying all the added benefits of a dish bursting with

colour, nutrients and flavour. The stainless steel interior of the steamer can accommodate up to two cooking levels simultaneously enabling you to cook a meal with fish and vegetables at the same time, with both still retaining their own unique flavour.

HBC 26 D 550 B Steamer

BUILT-IN STEAM COOKER

HEATING METHODS

Pressureless Steam cooking between 40°C to 100°C

100% Steam

COMFORT AND SAFETY

Electronic control of water supply and temperature

37 automatic programmes

Automatic temperature proposal

Clear text display for cooking functions and automatic programmes

Timer and clock function

Cleaning Programme

Childproof lock

DESIGN

Retractable push buttons

Stainless Steel oven cavity

Removable Water reservoir, 1.3L

STANDARD ACCESSORIES

Grid

Perforated tray

Unperforated tray

Overall: (H x W x D): 45.4 x 59.4 x 52.0 cm Aperture (H x W x D): 45.0 x 56.0 x 55.0cm Interior Capacity: 35 litre

Bosch Steamer

HBC 86 K 751 Gourmet Built-in Microwave Oven

HBC 86 Q 651 Quantum Speed Oven









































































































































































































































































































































































































































































built in microwave oven

Microwave and heating methods (7)

Microwave 900 W with 5 power levels

Top/bottom heat, hot air, 3D hot air, variable grill, hot air grilling, bottom heat, intensive heat

Microwave can be used separately or in combination with all heating methods

COMFORT AND SAFETY

Weight automatic – 51 programmes

Exact temperature control 30°C-300°C

Quick heat (oven heats up 35% faster)

3 level programming microwave

Memory function (6)

Child lock to prevent unsupervised operation of the appliance

Electronic clock

CLEANING

• Back and top with EcoClean panels – easy clean of coated surfaces

design

Digital display with clear text

Pop-up controls

Enamelled interior

Standard accessories

Combi grid

Universal tray

Overall (H x W x D): 45.4 x 59.5 x 52.0 cm Aperture (H x W x D): 45.0 x 56.0 x 55.0 cm Capacity: 42 litres Rating: 3600 W

BUILT-IN HALOGEN LIGHT MICROWAVE OVEN

Perfected heating systems due to combination of halogen light, flat panel heaters, Quartz grill and microwave. Saves up to 70% time compared to multi-functions ovens

microwave and heating methods (4)

900 W microwave with 5 power levels

Top/bottom heat till 250°C, hot air, variable quartz grill (3 settings), halogen lights intensive setting, separate bottom heat

Microwave can be used separately or in combination with all other heating methods (except intensive setting)

Halogen light in pre-programmed settings

comfort and safety

Electronic clock

Memory function (6 memory options)

3-stage programming (microwave)

Weight automatic programmes

Child lock to prevent unsupervised operation of the appliance

design

Clear text display for heating methods and automatic programmes

Easy control electronics with popup controls

40 cm turntable

Stainless steel interior

Overall (H x W x D): 45.8 x 59.5 x 46.7 cm Aperture (H x W x D): 45.0 x 56.2 x 55.0 cm Capacity: 34 litres Rating: 3600 W

HMT 9856 Microwave

HSC 290651 Warmer Drawer – 290 mm high

BUILT-IN MICROWAVE WITH grill

Microwave and Heating Methods

1000W microwave with 5 power levels, 1000/600/360/180/90W

Variable grill 1300W (up to 3 levels)

COMFORT AND SAFETY

Inverter technology, time - / energy saving

Microwave and grill can be used separately or combined together (up to 600W microwave)

Up to 3 microwave and grill combinations can be programmed consecutively

Cook-by-weight facility, 10 programmes

Memory button

34 cm diameter glass turntable

Design

User friendly electronics with push-buttons and digital display

Stainless Steel interior

Built-in frame incl.

Overall (H x W x D): 31.0 x 51 x 39 cm Aperture (H x W x D): 38 x 56.2 x 55 cm Capacity: 27 litres Rating: 2620 W

WARMER DRAWER

Ideal for yeast dough, defrosting, keeping food warm, plate warmer

TECHNIQUE

Temperature regulation between 40°C – 80°C

Seperate dishwarmer function

Maximum capacity 25 kg

DESIGN

Stainless steel interior

Telescopic drawer

Overall (H x W x D): 29.0 x 59.5 x 53.5 cm

Aperture (H x W x D): 29.0 x 56.2 x 55.0 cm

Capacity: 25 KG

Bosch Microwave Oven, Quantum Speed

Oven and Warmer Drawer

Loading...
+ 19 hidden pages
