Bosch KDN 56VI30N, KDN 56AI30N, KDN 56AW30N User Manual
Fridge-freezer
Soğutucu/Dondurucu kombine cihazı
Холодильно-морозильная комбинация
KDN
en User manual
tr Kullanım kılavuzu
ru Инструкция по эксплуатации
en Table of Contents
Safety and warning information ............ 4
Information concerning disposal .......... 5
Scope of delivery .................................... 6
Ambient temperature and ventilation .. 6
Connecting the appliance ..................... 7
Getting to know your appliance ........... 8
Switching the appliance on ................... 9
Setting the temperature ......................... 9
Alarm function ...................................... 10
Usable capacity .................................... 10
Refrigerator compartment .................. 11
Super cooling ....................................... 11
Freezer compartment .......................... 11
Max. freezing capacity ........................ 12
tr İçindekiler
Güvenlik ve ikaz bilgileri ..................... 21
Giderme bilgileri ................................... 23
Teslimat kapsamı ................................. 23
Mekan sıcaklığına ve havalandırmaya
dikkat edilmelidir .................................. 24
Cihazın elektrik şebekesine
bağlanması ............................................ 24
Cihaz özelliklerinin öğrenilmesi ......... 25
Cihazın devreye sokulması ................ 26
Sıcaklık derecesinin ayarlanması ...... 26
Alarm fonksiyonu ................................. 27
Kullanılabilen hacim ............................. 27
Soğutucu bölmesi ................................ 28
Süper soğutma ..................................... 28
Dondurucu bölmesi ............................. 29
Azami dondurma kapasitesi .............. 29
Freezing and storing food .................. 12
Freezing fresh food ............................. 12
Super freezing ...................................... 13
Thawing frozen food ............................ 14
Interior fittings ....................................... 14
Switching off and disconnecting
the appliance ........................................ 15
Defrosting .............................................. 15
Cleaning the appliance ....................... 15
Light (LED) ............................................ 16
Tips for saving energy ........................ 16
Operating noises ................................. 17
Eliminating minor faults yourself ....... 17
Customer service ................................. 20
Besinlerin dondurulması ve
depolanması ......................................... 29
Taze besinlerin dondurulması ........... 30
Süper dondurma .................................. 31
Dondurulmuş besinlerin buzunun
çözülmesi .............................................. 31
Donanım ................................................ 32
Cihazın kapatılması, cihazın
tamamen kapatılması .......................... 33
Cihazın buzunun çözülmesi ............... 33
Cihazın temizlenmesi .......................... 34
Aydınlatma (LED) ................................. 35
Enerji tasarrufu ..................................... 35
Çalışma sesleri ..................................... 35
Basit hataları kendiniz
giderebilirsiniz ....................................... 36
Yetkili servis .......................................... 39
ru Coдepжaниe
Укaзaния пo бeзoпacнocти
ипpeдyпpeждeния .............................. 40
Укaзaния пo yтилизaции ................... 42
Oбъeм пocтaвки .................................. 43
Teмпepaтypa oкpyжaющeй
cpeды ивeнтиляция ........................... 43
Подключение бытового прибора ... 44
Знакомство с бытовым прибором .45
Включение бытового прибора ....... 46
Уcтaнoвкa тeмпepa
Предупредительная функция .......... 47
Пoлeзный oбъeм ................................. 48
Xoлoдильнoe oтдeлeниe ................... 48
Cyпepoxлaждeниe .............................. 49
Mopoзильнoe oтдeлeниe .................. 50
Maкc. пpoизвoдитeльнocть
зaмopaживaния ................................... 50
тypы .................... 46
Зaмopaживaниe и xpaнeниe
пpoдyктoв ............................................. 50
Зaмopaживaниe cвeжиx
пpoдyктoв питaния ............................. 51
Cyпepзaмopaживaниe ....................... 52
Paзмopaживaниe пpoдyктoв ............ 52
Cпeциaльнoe ocнaщeниe ................. 53
Bыключeниe прибора ивывoд
eгo из экcплyaтaции .......................... 54
Paзмopaживaниe ................................ 54
Чистка бытового прибора ................ 55
Ocвeщeниe (нa cвeтoдиoдax) .......... 56
Kaк cэкoнoмить элeктpoэнepгию .. 56
Paбoчиe шyмы ..................................... 57
Caмocтoятeльнoe ycтpaнeниe
мeлкиx нeиcпpaвнocтeй ................... 58
Cлyжбa cepвиca ................................. 62
en
enTable of Contents
enInstruction for Use
Safety and warning
information
Before you switch ON the
appliance
Please read the operating and
installation instructions carefully! They
contain important information on how to
install, use and maintain the appliance.
The manufacturer is not liable if you fail
to comply with the instructions and
warnings. Retain all documents for
subsequent use or for the next owner.
If the power cord of this appliance is
damaged, it must be replaced by the
manufacturer, customer service or a
similarly qualified person. Improper
installations and repairs may put the user
at considerable risk.
Repairs may be performed by the
manufacturer, customer service or a
similarly qualified person only.
Only original parts supplied by the
manufacturer may be used. The
manufacturer guarantees that only these
parts satisfy the safety requirements.
A extension cable may be purchased
from customer service only.
Technical safety
This appliance contains a small quantity
of environmentally-friendly but flammable
R600a refrigerant. Ensure that the tubing
of the refrigerant circuit is not damaged
during transportation and installation.
Leaking refrigerant may cause eye
injuries or ignite.
If damage has occurred
■ Keep naked flames and/or ignition
sources away from the appliance,
■ thoroughly ventilate the room for
several minutes,
■ switch off the appliance and pull out
the mains plug,
■ inform customer service.
The more refrigerant an appliance
contains, the larger the room must be in
which the appliance is situated. Leaking
refrigerant can form a flammable gas-air
mixture in rooms which are too small.
The room must be at least 1 m³ per 8 g
of refrigerant. The amount of refrigerant
in your appliance is indicated on the
rating plate inside the appliance.
Important information when
using the appliance
■ Never use electrical appliances inside
the appliance (e.g. heater, electric ice
maker, etc.). Risk of explosion!
■ Never use a steam cleaner to defrost
or clean the appliance! The steam
may penetrate electrical parts
and cause a short-circuit. Risk of
electric shock!
■ Do not use pointed or sharp-edged
implements to remove frost or layers
of ice. You could damage
the refrigerant tubing. Leaking
refrigerant may ignite or cause eye
injuries.
■ Do not store products which contain
flammable propellants (e.g. spray
cans) or explosive substances
in the appliance. Risk of explosion!
■ Do not stand or support
yourself on the base, drawers
or doors, etc.
4
en
■ Before defrosting and cleaning
the appliance, pull out the mains plug
or switch off the fuse.
Do not pull out the mains plug
by tugging the cable.
■ Bottles which contain a high
percentage of alcohol must be sealed
and stored in an upright position.
■ Keep plastic parts and the door seal
free of oil and grease. Otherwise,
parts and door seal will become
porous.
■ Never cover or block the ventilation
openings for the appliance.
■ People (childern incl.) who have
limited physical, sensory or mental
abilities or inadequate knowledge
must not use this appliance unless
they are supervised or given
meticulous instructions.
■ Do not store bottled or canned drinks
(especially carbonated drinks)
in the freezer compartment. Bottles
and cans may explode!
■ Never put frozen food straight
from the freezer compartment
into your mouth.
Risk of low-temperature burns!
■ Avoid prolonged touching of frozen
food, ice or the evaporator pipes, etc.
Risk of low-temperature burns!
General regulations
The appliance is suitable
■ for refrigerating and freezing food,
■ for making ice.
This appliance is intended for use in
the home and the home environment.
The appliance is suppressed according
to EU Directive 2004/108/EC.
The refrigeration circuit has been
checked for leaks.
This product complies with the relevant
safety regulations for electrical
appliances (EN 60335-2-24).
Information concerning
disposal
* Disposal of packaging
The packaging protects your appliance
from damage during transit. All utilised
materials are environmentally safe and
recyclable. Please help us by disposing
of the packaging in an environmentally
friendly manner.
Please ask your dealer or inquire at your
local authority about current means of
disposal.
Children in the household
■ Keep children away from packaging
and its parts.
Danger of suffocation from folding
cartons and plastic film!
■ Do not allow children to play with the
appliance!
■ If the appliance features a lock:
keep the key out of the reach of
children!
5
en
* Disposal of your old
appliance
Old appliances are not worthless
rubbish! Valuable raw materials can be
reclaimed by recycling old appliances.
This appliance is identified
according to the European
guideline 2002/96/EC on waste
electrical and electronic
equipment – WEEE. The directive
specifies the framework for an
EU-wide valid return and re-use
of old appliances.
ã=Warning
Redundant appliances
1. Pull out the mains plug.
2. Cut off the power cord and discard
with the mains plug.
3. Do not take out the trays
and receptacles: children are
therefore prevented from climbing in!
4. Do not allow children to play with
the appliance once it has spent its
useful life. Danger of suffocation!
Refrigerators contain refrigerant
and gases in the insulation. Refrigerant
and gases must be disposed
of professionally. Ensure that tubing
of the refrigerant circuit is not damaged
prior to proper disposal.
Scope of delivery
After unpacking all parts, check for any
damage in transit.
If you have any complaints, please
contact the dealer from whom you
purchased the appliance or our
customer service.
The delivery consists of the following
parts:
■ Free-standing appliance
■ Bag containing installation materials
■ Interior fittings (depending on model)
■ Operating instructions
■ Installation manual
■ Customer service booklet
■ Warranty enclosure
■ Information on the energy
consumption and noises
Ambient temperature
and ventilation
Ambient temperature
The appliance is designed for a specific
climate class. Depending on the climate
class, the appliance can be operated at
the following temperatures.
The climate class can be found on
the rating plate. Fig. -
Climate class Permitted ambient
temperature
SN +10 °C to 32 °C
N +16 °C to 32 °C
ST +16 °C to 38 °C
T +16 °C to 43 °C
6
en
Note
The appliance is fully functional within
the room temperature limits
of the indicated climatic class. If
an appliance of climatic class SN
is operated at colder room temperatures,
the appliance will not be damaged up to
a temperature of +5 °C.
Ventilation
Fig. 3
The air on the rear panel and on the side
panels of the appliance heats up.
Conduction of the heated air must
not be obstructed. Otherwise,
the refrigerating unit must work harder.
This increases power consumption.
Therefore: Never cover or block
the ventilation openings!
Connecting
the appliance
After installing the appliance, wait at least
1 hour until the appliance is switched on.
During transportation the oil in
the compressor may have flowed into
the refrigeration system.
Before switching on the appliance for
the first time, clean the interior of
the appliance (see chapter “Cleaning
the appliance”).
Electrical connection
The socket must be near the appliance
and also freely accessible following
installation of the appliance.
The appliance complies with the
protection class I. Connect the appliance
to 220–240 V/50 Hz alternating current
via a correctly installed socket with
protective conductor. The socket must
be fused with a 10 to 16 A fuse.
For appliances operated in nonEuropean countries, check whether the
stated voltage and current type match
the values of your mains supply match
the values of the mains supply. This
information can be found on the rating
plate. Fig. -
ã=Warning
Never connect the appliance
to electronic energy saver plugs.
Our appliances can be used with mains
and sine-controlled inverters. Mainscontrolled inverters are used
for photovoltaic systems which
are connected directly to the national
grid. Sine-controlled inverters must be
used for isolated applications (e.g. on
ships or in mountain lodges) which are
not connected directly to the national
grid.
7
en
Getting to know your
appliance
Please fold out the illustrated last page.
These operating instructions refer
to several models.
The features of the models may vary.
The diagrams may differ.
Fig. 1
1-7 Controls
8 Light switch for freezer
compartment
9 On/Off button
10 Fast freezer compartment
11 Light (LED)
12 Light switch for refrigerator
compartment
13 Extendable glass shelf
14 Air outlet opening
15 Shelf in the refrigerator
compartment
16 Cold storage compartment
17 Vegetable container
18 Ventilation opening
19 Height-adjustable feet
20 Door shelf
21 Ice maker
22 Ice cube container
23 Butter and cheese compartment
24 Egg rack
25 Door container
26 Door shelf
27 Bottle holder
28 Shelf for large bottles
A Freezer compartment
B Refrigerator compartment
Controls
Fig. 2
1 Alarm button
Used to switch off the warning
signal, see chapter “Alarm
function”.
2 “Super” button refrigerator
compartment
Switches super cooling on and
off.
3 Refrigerator compartment
temperature selection button
The button sets the temperature
in the refrigerator compartment.
4 Temperature display refrigerator
compartment
The numbers correspond
to the set refrigerator
compartment temperatures in °C.
5 “Super” button (freezer
compartment)
Switches super freezing
on and off.
6 Temperature selection button
freezer compartment
The button sets the temperature
in the freezer compartment.
7 Temperature display freezer
compartment
The numbers correspond
to the set freezer compartment
temperatures in °C.
8
Note
When the appliance is not used for some
time, the display on the fascia switches
to ECO mode.
en
Setting
the temperature
Fig. 2
Switching
the appliance on
1. Press the On/Off button 1/9. Warning
signal is emitted.
2. Press the alarm button 2/1. Warning
signal stops.
The alarm button 2/1 remains lit until
the set temperature has been reached.
The factory has recommended
the following temperatures:
■ Refrigerator compartment: +4 °C
■ Freezer compartment: –18 °C
Operating tips
■ When the appliance has been
switched on, it may take several hours
until the set temperatures have been
reached.
■ The fully automatic No Frost system
ensures that the freezer compartment
remains free of ice. Defrosting is no
longer required.
■ The sides of the housing are
sometimes heated slightly. This
prevents condensation in the area of
the door seal.
■ If the freezer compartment door
cannot be immediately re-opened after
it has been closed, wait until the
resulting low pressure has equalised.
Refrigerator compartment
The temperature can be set from +2 °C
to +8 °C.
Keep pressing temperature setting
button 3 until the required refrigerator
compartment temperature is set.
The value last selected is saved. The set
temperature is indicated on temperature
display 4.
We recommend a factory setting
of +4 °C in the refrigerator compartment.
Perishable food should not be stored
above +4 °C.
Freezer compartment
The temperature can be set from -16 °C
to -24 °C.
Keep pressing temperature setting
button 6 until the required freezer
compartment temperature is set.
The value last selected is saved.
The set temperature is indicated
on temperature display 7.
We recommend a factory setting of 18 °C in the freezer compartment.
9
en
Alarm function
The warning signal switches on if
the freezer compartment is too warm.
Switching off the warning signal
Fig. 2
Press the “alarm” button 1 to switch off
the warning signal.
Door alarm
The door alarm switches on if an
appliance door is left open for longer
than one minute. Close the door to
switch off the warning signal.
Temperature alarm
The temperature alam switches on if
the freezer compartment is too warm.
Alarm
button
illumina
tes
flashes flashes Thaw alarm:
flashes illuminates Thaw alarm:
Temperature
display
flashes Temperature alarm:
Explanation
Frozen food is
not at risk of
thawing.
Frozen food is
at risk of thawing.
At some time
the freezer
compartment was
too warm. Frozen
food is at risk
of thawing.
Temperature warning
The alarm may switch on without any
risk to the frozen food:
■ when the appliance is switched on,
■ when large quantities of fresh food
are placed in the appliance,
■ if the freezer compartment door
is open too long.
Thaw warning
If taste, odour and appearance remain
unchanged, the food can be boiled
or fried and then refrozen. No longer
store the frozen produce for the max.
storage period.
Note
Do not refreeze thawing or thawed food.
It can only be refrozen when it has been
used to prepare a ready meal (boiled
or fried).
No longer store the frozen produce for
the max. storage period.
Usable capacity
Information on the usable capacity can
be found inside your appliance on
the rating plate. Fig. -
Fully utilising the freezer
volume
The maximum amount of food can be
placed in the freezer by removing
the following fittings.
Removing the fittings
10
■ The door shelf can be taken out.
Fig. 4
■ If appliances feature an ice maker,
the latter can be taken out. Fig. 5
Refrigerator
compartment
The refrigerator compartment is the ideal
storage location for ready meals, cakes
and pastries, preserved food, condensed
milk, hard cheese, fruit and vegetables
sensitive to cold as well as tropical fruit.
en
■ Warmest zone
is at the very top of the door.
Note
Store e.g. cheese and butter in
the warmest zone. When served,
the cheese will not have lost its flavour
and the butter will be easy to spread.
Note when loading products
Wrap or cover food before placing
in the appliance. This will retain
the aroma, colour and freshness
of the food. In addition, flavours will not
be transferred between foods
and the plastic parts will not become
discoloured.
Note
Avoid contact between food and rear
panel. Otherwise the air circulation will
be impaired.
Food or packaging could freeze
to the rear panel.
Note the chill zones in
the refrigerator compartment!
The air circulation in the refrigerator
compartment creates different chill
zones:
■ Coldest zone
is on the rear panel inside
the appliance and on the cold storage
compartment. Fig. 1/16
Note
Store perishable food e.g. fish,
sausage, meat in the coldest zones.
Super cooling
Super cooling sets the refrigerator
temperature to the coldest temperature
setting for approx. 6 hours. Then
the appliance automatically switches
to the temperature set prior to super
cooling mode.
Switch on super cooling mode, e.g.
■ before placing large quantities of food
in the refrigerator compartment.
■ for the fast cooling of drinks.
Switching on and off
Fig. 2
Press “super” button 2.
The button is lit when super cooling is
switched on.
Freezer compartment
Use the freezer compartment
■ To store deep-frozen food.
■ To make ice cubes.
■ To freeze food.
11
en
Note
Ensure that the freezer compartment
door has been closed properly. If
the door is open, the frozen food will
thaw. The freezer compartment will
become covered in thick ice. Also: waste
of energy due to high power
consumption!
Max. freezing capacity
Information about the max. freezing
capacity within 24 hours can be found
on the rating plate. Fig. -
Freezing and storing
food
Purchasing frozen food
■ Packaging must not be damaged.
■ Use by the “use by” date.
■ Temperature in the supermarket
freezer must be -18 °C or lower.
■ If possible, transport deep-frozen food
in an insulated bag and place quickly
in the freezer compartment.
Note when loading products
Freeze large quantities of food in the fast
freezer compartment where food freezes
particularly quickly and therefore also
gently.
Food which is already frozen must not
come into contact with the food which is
to be frozen.
Freezing fresh food
Freeze fresh and undamaged food only.
To retain the best possible nutritional
value, flavour and colour, vegetables
should be blanched before freezing.
Aubergines, peppers, zucchini and
asparagus do not require blanching.
Literature on freezing and blanching
can be found in bookshops.
Note
Keep food which is to be frozen away
from food which is already frozen.
■ The following foods are suitable for
freezing:
Cakes and pastries, fish and seafood,
meat, game, poultry, vegetables, fruit,
herbs, eggs without shells, dairy
products such as cheese, butter and
quark, ready meals and leftovers such
as soups, stews, cooked meat and
fish, potato dishes, soufflés and
desserts.
■ The following foods are not suitable
for freezing:
Types of vegetables, which are usually
consumed raw, such as lettuce or
radishes, eggs in shells, grapes,
whole apples, pears and peaches,
hard-boiled eggs, yoghurt, soured
milk, sour cream, crème fraîche and
mayonnaise.
Packing frozen food
To prevent food from losing its flavour
or drying out, place in airtight containers.
1. Place food in packaging.
2. Remove air.
3. Seal the wrapping.
4. Label packaging with contents
and date of freezing.
12
Suitable packaging:
Plastic film, tubular film
made of polyethylene, aluminium foil,
freezer containers.
These products are available
from specialist outlets.
Unsuitable packaging:
Wrapping paper, greaseproof paper,
cellophane, bin liners and used
shopping bags.
Items suitable for sealing packaged
food:
Rubber bands, plastic clips, string, coldresistant adhesive tape, etc.
Bags and tubular film
made of polyethylene can be sealed
with a film heat sealer.
Shelf life of frozen food
Storage duration depends on the type
of food.
At a temperature of -18 °C:
■ Fish, sausage, ready meals and cakes
and pastries:
up to 6 months
■ Cheese, poultry and meat:
up to 8 months
■ Vegetables and fruit:
up to 12 months
en
Super freezing
Food should be frozen solid as quickly
as possible in order to retain vitamins,
nutritional value, appearance and flavour.
Several hours before placing fresh food
in the freezer compartment, switch on
super freezing to prevent an unwanted
temperature rise.
As a rule, 4-6 hours is adequate.
This appliance runs constantly
and the freezer compartment drops to
a very low temperature.
If the max. freezing capacity is to be
used, super freezing must be switched
on for 24 hours before the fresh produce
is placed in the freezer compartment.
Smaller quantities of food (up to 2 kg)
can be frozen without “super freezing”.
Note
When super freezing is switched on,
increased operating noises may occur.
Switching on and off
Fig. 2
Press “super” button 5.
If the super freezing has been switched
on the button is lit.
Super freezing automatically switches off
after approx. 2½ days.
13
en
Thawing frozen food
Depending on the type and application,
select one of the following options:
■ at room temperature
■ in the refrigerator
■ in an electric oven, with/without fan
assisted hot-air
■ in the microwave
ã=Caution
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Interior fittings
You can reposition the shelves inside
the appliance and the door shelves as
required:
■ Pull shelf forwards, lower and swing
out to the side.
■ Raise the door shelf and remove. Fig.
4
Special features
(not all models)
Taking out the extendable glass shelf
Fig. 1/13
The glass shelf can be removed for
cleaning. To do this, pull out shelf, lift at
the front and take out.
Bottle shelf
Fig. 6 A/B
Bottles can be stored securely on
the bottle shelf.
Cold storage compartment
Fig. 1/16
The cold storage compartment has lower
temperatures than the refrigerator
compartment. Even temperatures below
0°C may occur.
Ideal for storing fish, meat and sausage.
Not suitable for lettuce and vegetables
and produce sensitive to cold.
Vegetable container with humidity
controller
Fig. 7
To create the optimum storage climate
for vegetables, salad and fruit, the air
humidity in vegetable container can be
regulated according to the quantity
stored.
Smaller quantities of food –
slide the regulator to the left.
Larger quantities of food –
slide the regulator to the right.
Drawer insert
Fig. 9
The insert can be taken out.
Door container
Fig. 1/25
Ideal for the storage of sweets, spices
and dressings. Also suitable for cosmetic
products.
Bottle holder
Fig. 1/27
The bottle holder prevents bottles from
falling over when the door is opened
and closed.
14
Ice maker
Fig. 8
1. Take out water container and fill with
water up to the mark.
2. Carefully empty water into the storage
container via the filler opening. Ensure
that the water does not run into or
splash onto the storage container.
Otherwise, ice cubes could freeze to
each other or to the container.
3. When the ice cubes are frozen, press
lever down and release.
The ice cubes loosen and fall into
the storage container.
4. Remove ice cubes from the storage
container. The ice cubes should be
removed regularly from the storage
container to prevent them from
freezing to each other.
Switching off and
disconnecting the
appliance
Switching off the appliance
Fig. 1
Press the On/Off button 9.
Refrigerating unit and light switch off.
Disconnecting the appliance
If you do not use the appliance
for a prolonged period:
1. Switch off the appliance.
2. Pull out mains plug or switch off fuse.
3. Clean the appliance.
4. Leave the appliance door open.
en
Defrosting
Refrigerator compartment
Defrosting is actuated automatically.
The condensation runs through
the drainage hole into an evaporation
pan on the rear of the appliance.
Freezer compartment
The fully automatic No Frost system
ensures that the freezer compartment
remains free of ice. Defrosting is no
longer required.
Cleaning the appliance
ã=Caution
■ Do not use abrasive, chloride or acidic
cleaning agents or solvents.
■ Do not use scouring or abrasive
sponges.
The metallic surfaces could corrode.
■ Never clean shelves and containers in
the dishwasher.
The parts may warp!
Water used for cleaning must not drip
into the
■ slots in the front base area in
the freezer compartment,
■ controls,
■ and light.
15
en
Proceed as follows:
1. Before cleaning: Switch the appliance
off.
2. Pull out the mains plug or switch off
the fuse.
3. Take out the frozen food and store in
a cool location. Place the ice pack (if
enclosed) on the food.
4. Clean the appliance with a soft cloth,
lukewarm water and a little pH neutral
washing-up liquid. The rinsing water
must not run into the light.
5. Wipe the door seal with clear water
only and then wipe dry thoroughly.
6. After cleaning reconnect and switch
the appliance back on.
7. Put the frozen food back in the freezer
compartment.
Interior fittings
All variable parts of the appliance
can be taken out for cleaning.
Take out glass shelves
Pull the glass shelves forwards and take
out.
Take out shelves in the door
Fig. 4
Lift shelves upwards and take out.
Taking glass shelf out of chiller
compartment
Fig. *
Press the holder upwards and take out
the glass shelf.
Note
Do not clean glass shelf of the cold
storage compartment under running
water.
Taking out glass shelf above vegetable
drawer
Fig. +
Before the glass shelf can be taken out,
pull out the vegetable drawer.
The glass shelf can be taken apart for
cleaning.
Light (LED)
Your appliance features a maintenancefree LED light.
These lights may be repaired
by customer service or authorised
technicians only.
Tips for saving energy
■ Install the appliance in a dry, well
ventilated room! The appliance should
not be installed in direct sunlight
or near a heat source (e.g. radiator,
cooker).
If required, use an insulating plate.
■ Do not block the ventilation openings
in the appliance.
■ Allow warm food and drinks to cool
down before placing in the appliance.
■ Thaw frozen food in the refrigerator
compartment and use the low
temperature of the frozen food to cool
refrigerated food.
■ Open the appliance as briefly as
possible.
■ Ensure that the freezer compartment
door is always closed properly.
■ Occasionally clean the rear
of the appliance to prevent an
increased power consumption.
16
Preventing noises
Operating noises
Quite normal noises
Droning
Motors are running (e.g. refrigerating
units, fan).
Bubbling, humming or gurgling noises
Refrigerant is flowing through the tubing.
Clicking
Motor, switches or solenoid valves are
switching on/off.
Cracking
Automatic defrosting is running.
The appliance is not level
Please align the appliance with a spirit
level. Use the height-adjustable feet
or place packing underneath them.
The appliance is not free-standing
Please move the appliance away
from adjacent units or appliances.
Containers or storage areas wobble
or stick
Please check the removable parts
and re-insert them correctly if required.
Bottles or receptacles are touching
each other
Move the bottles or receptacles slightly
away from each other.
Eliminating minor faults yourself
Before you call customer service:
Please check whether you can eliminate the fault yourself based on the following
information.
Customer service will charge you for advice – even if the appliance is still under
guarantee!
en
Fault Possible cause Remedial action
Temperature differs
greatly from the set
value.
In some cases it is adequate
to switch off the appliance
for 5 minutes.
If the temperature is too high wait
a few hours and check whether
the temperature has approached
the set value.
If the temperature is too low check
the temperature again the next day.
17
en
Fault Possible cause Remedial action
The light
does not function.
Controls have reduced
luminosity.
Displays
do not illuminate.
Warning signal
sounds.
The alarm button is lit.
Fig. 2/1
The LED light
is defective.
Appliance was open
too long.
Light is switched off
after approx. 10 min.
When the appliance is
not used for some
time, the display on
the fascia switches
to energy saving
mode.
Power failure; the fuse
has been switched off;
the mains plug
has not been inserted
properly.
Fault – the freezer
compartment is too
warm!
Appliance is open. Close the appliance.
Ventilation openings
have been covered.
Too much food was
placed in the freezer
compartment at once.
See chapter “Light (LED)” section.
When the appliance is closed
and opened, the light is on again.
As soon as the appliance is again
used, e.g. the door is opened,
the display switches back to normal
illumination.
Connect mains plug. Check whether
the power is on, check the fuses.
To switch off the warning signal,
press the alarm button 1.
Ensure that there is adequate
ventilation.
Do not exceed max. freezing
capacity.
When the fault has been eliminated,
the alarm button goes out shortly
afterwards.
18
Fault Possible cause Remedial action
Warning signal
sounds.
Alarm button flashes.
Fig. 2/1
The temperature in
the freezer
compartment is too
warm.
Fault – the freezer
compartment is too
warm!
Frozen food is at risk! Note
Appliance is open. Close the appliance.
Ventilation openings
have been covered.
Too much food was
placed in the freezer
compartment at once.
Appliance opened
frequently.
The ventilation
openings have been
covered.
Large quantities of
fresh food are being
frozen.
To switch off the warning signal,
press the alarm button 1. Alarm
button stops flashing.
Frozen food which has started
thawing or which has thawed can be
refrozen if meat and fish were above
+3 °C for not more than one day
or other frozen food for not more
than three days.
If taste, odour and appearance have
not changed, the food can be boiled
or fried and then refrozen.
No longer store the frozen produce
for the max. storage period.
Ensure that there is adequate
ventilation.
Do not exceed max. freezing
capacity.
When the fault has been eliminated,
the alarm button goes out shortly
afterwards.
Do not open the appliance
unnecessarily.
Remove obstacles.
Do not exceed max. freezing
capacity.
en
19
en
Fault Possible cause Remedial action
Freezer compartment
door was open
for a long time;
temperature is no
longer reached.
The evaporator
(refrigeration
generator)
in the No Frost system
is covered in thick ice
and can no
longer be defrosted
fully automatically.
To defrost the evaporator, remove
the frozen food
with the compartments, insulate well
and store in a cool location.
Switch off the appliance and move
it away from the wall. Leave
the appliance door open.
After approx. 20 min.
the condensation begins to run
into the evaporation pan,
at the rear of the appliance. Fig. ,
To prevent the evaporation pan
from overflowing in this case,
mopupthecondensation
with a sponge.
The evaporator is defrosted when
the water stops running
into the evaporation pan. Clean
the interior. Switch the appliance
back on again.
Customer service
Your local customer service
canbefound inthetelephone directory
or in the customer-service index. Please
provide customer service
with the appliance product number
(E-Nr.) and production number (FD).
These specifications
can be found on the rating plate. Fig. -
To prevent unnecessary call-outs, please
assist customer service by quoting
the product and production numbers.
This will save you additional costs.
20
Repair order and advice
on faults
Contact information for all countries can
be found on the enclosed customer
service list.
GB 0844 8928979 Calls from a BT
landline will be
charged at up
to 3 pence per
minute. A call
set-up fee of up
to 6 pence may
apply.
IE 01450 2655
US 800 944 2904 toll-free
trİçindekiler
trKullanma kılavuzu
Güvenlik ve ikaz
bilgileri
Cihazı çalıştırmadan önce
Kullanma ve montaj kılavuzlarını
dikkatlice okuyunuz! Bu kılavuzlarda
cihazın kurulması, yerleştirilmesi,
kullanılması ve bakımı ile ilgili önemli
bilgiler bulunmaktadır.
Üretici, kullanma talimatlarındaki bilgi
ve uyarıları dikkate almazsanız, herhangi
bir sorumluluk üstlenmez. Tüm belge
ve dokümanları sonradan kullanma
ihtimalinden veya cihazı satacak
olursanız, yeni sahibi için saklayınız.
Teknik güvenlik
Bu cihaz az miktarda, çevreye zarar
vermeyen fakat yanıcı özelliği olan
R600a soğutma maddesini ihtiva
etmektedir. Cihaz taşınırken veya monte
edilirken cihazın soğutucu madde
sirkülasyon sistemindeki boruların zarar
görmemesine dikkat ediniz. Dışarı
fışkıran soğutucu madde tutuşup
yanabilir veya göz yaralanmasına sebep
olabilir.
Hasar durumunda
■ Açık ateş veya alev kaynakları
cihazdan uzak tutulmalıdır.
■ Cihazın kurulu olduğu yer birkaç
dakika havalandırılmalıdır.
■ Cihazı kapatınız ve elektrik fişini çekip
prizden çıkarınız.
■ Yetkili servise haber verilmelidir.
tr
Bir cihaz ne kadar fazla soğutucu madde
ihtiva ederse, kurulduğu yer de o derece
büyük olmalıdır. Çok küçük yerlerde,
soğutma maddesi devresinde bir kaçak
söz konusu olduğunda, yanıcı bir gaz
hava karışımı oluşabilir.
Her 8 gram soğutucu madde için gerekli
olan yerin hacmi en az 1 m³ kadardır.
Cihazınızın içinde bulunan soğutma
maddesinin miktarı, cihazın iç kısmındaki
tip levhasında yazılıdır.
Eğer bu cihazın elektrik şebekesi
kablosu zarar görürse, üretici, yetkili
servis veya benzeri ustalık özelliklerine
sahip başka bir kişi tarafından
değiştirilmesi gerekir. Hatalı veya
gerektiği şekilde yapılmayan kurma
çalışmalarından ve onar
ımlardan dolayı
cihazı kullanan kişi için oldukça önemli
tehlikeler ortaya çıkabilir.
Onarımlar sadece üretici, yetkili servis
veya benzeri eğitime sahip yetkili bir kişi
tarafından yapılmalıdır.
Sadece üreticinin orijinal parçaları
kullanılmalıdır. Üretici sadece bu
parçalarda güvenlik taleplerine
uyulduğunu garanti eder.
Elektrik şebekesi kablosu için bir uzatma
parçası sadece yetkili servis üzerinden
alınabilir.
Kullanım esnasında
■ Cihazın içinde kesinlikle elektrikli
cihazlar kullanmayınız (örn. ısıtma
cihazları, elektrikli buz yapma
makineleri vs.). Patlama tehlikesi!
■ Cihazı temizlemek veya buzunu
çözmek için asla buharlı temizleme
cihazları kullanmayınız. Buhar elektrikli
parçalara temas edebilir ve kısa devre
olmasına sebep olabilir! Elektrik
çarpma tehlikesi!
21
Loading...
