Bosch FPA-1000-LC, FPA-1000-UL Specsheet

Fire Alarm Systems | FPA‑1000‑UL Analog Addressable Fire Panel

FPA‑1000‑UL Analog Addressable Fire
Panel

www.boschsecurity.com

u Support for up to 508 points on two analog

addressable loops

u Built‑in Ethernet connector for web‑browser based

programming and ConettixIP Alarm-over-IP
communication

u Carbon Monoxide Detector (gas) support meets

NFPA 720 (2009) requirements for visual and
audible annunciation

u Auto‑Learn mode for easy provisioning

u On‑line help and off‑line programming capability

provide simple configuration and service

The FPA‑1000‑UL Analog Addressable Fire Panel is an
advanced analog control panel for small to medium
facilities in commercial or public building applications.
The FPA‑1000‑UL combines complete built-in Fire
Alarm Control Panel (FACP) equipment such as
Notification Appliance Circuits (NACs), Signaling Line
Circuits (SLCs), relays, power supply, Digital Alarm
Communicator Transmitter (DACT), and Ethernet
connection with expandability using the option bus or
plug‑in boards. The two integrated NACs can be
expanded with remote addressable NAC power boosters

programmed with specific activation patterns.

and
The standard control panel includes one SLC that
supports 254 addressable points (254 analog detectors

modules, or 127 analog sounder bases in combination

or
with a suitable detector). The control panel is easily
expandable with the FPE‑1000‑SLC Signaling Line
Circuit Plug-in Module, doubling the address points to

508.
The panel has a compact and solid metal housing with
a keyed lock and a removable dead front door to
access electronics. It features surface and semi-flush
mounting options. On the front of the panel, six light­emitting diodes (LEDs) show Fire, Carbon Monoxide
(Gas) Alarm, Power, Supervisory, Silenced, and

Trouble conditions. The built‑in keypad can be used for
total system control and programming even when
wearing fireman gloves. In addition, a large 4‑line by
20‑character alphanumeric LCD display shows
programmed device point information. Four keys enable
Drill, Reset, Silence, and Acknowledge functions.
The FPA‑1000‑UL enables various programming
approaches:

• Front panel programming

• On-site programming, using a laptop with the
possibility of pre-programming at the office

• Off-site programming, with remote access via
Ethernet (browser-based).

Front panel programming provides an auto‑learn
function, allowing the installer to configure the system
quickly and easily in default mode. Using a local laptop
or remote access communication, the programming is
carried out by means of a browser‑based user
interface. Therefore, no software installation is required.
The panel can receive diagnostics from a Web browser
running on a networked PC.

2 | FPA‑1000‑UL Analog Addressable Fire Panel

System Overview

Functions

Communications

The FPA‑1000‑UL has a dual phone line PSTN/DACT
circuit and an Ethernet connection featuring Conettix
IP reporting. The panel communicates in Contact ID,
SIA, and Modem IIIa2. The panel provides miscellane­ous reporting functions such as dialing control and
transmission supervision, priorities of report groups,
routing to destinations, manual and auto test reports,
and Anti-Replay feature.
For the primary and secondary account, the following
features are programmable:

Two different phone or IP numbers

•
Different dialing types for PSTN (pulse only, tone and

•
pulse, or tone only)

• Individual PSTN line supervision (audible and visual
trouble signal in the case of a transmission path
failure)

• Selectable options for Report Steering Groups

• Programmable acknowledge wait time for each IP
reporting Conettix account (15 sec up to 255 sec)

• Test call frequency individually programmable for
each account (4, 12, 24 hour, 7 and 28 day intervals,
standard frequency 24 hour)

With modem function, it is possible to program the
control panel remotely (upload a new parameter file to
the panel from a remote station).

Notification Appliance Circuits (NACs)

Two Class A Style Z or Class B Style Y NACs provide up
to 4 A of 24 V power (non-synchronized: 2.5 A per
NAC; synchronized: 2.75 A NAC 1 + NAC 2 in total) to
operate horns, strobes, bells, and other notification

appliances. Each NAC can be programmed to provide
Temporal Code 4, Temporal Code 3, and steady, puls­ing, and synchronized protocol output for Wheelock,
Gentex, and System Sensor notification appliances.

Option Bus

On the Option Bus, the FPA-1000-UL supports:

• up to eight FMR-1000-RCMD Remote Command
Centers and FMR-1000-RA Remote Annunciators in
any

combination

• up to eight D7030X Series LED Annunciators with
eight LED zones each,

• up to eight D7030X Series/D7032 combinations

• up to two Octal Relay Modules or Octal Driver
Modules.

The outputs of the Octal Relay Modules or Octal Driver
Modules are fully programmable, and can be activated
by system events. These outputs have the same
programming options as the local relays. Each output
operates independently of the other seven to provide
complete flexibility. Communication with the D7035/B
or D7048/B is supervised.

Power

A transformer working with 120 VAC or 240 VAC is
supplied standard with the control panel. Two backup
batteries with 7 Ah to 18 Ah each fit inside the fire
panel cabinet. A separate battery box can provide
higher capacity.
The FPA-1000-UL provides two auxiliary power sup­plies (one FWR and one DC) with 0.5 A at 24 V each,
with switchable AUX/RST. This auxiliary power can run
expansion boards or other low current auxiliary
devices.
For installations requiring battery capacity higher than
40 Ah, a regulated and UL1481 Listed external power
supply can be used. The external power supplies
connect through the panel's battery terminals and are
supervised for AC and battery fault by an input module
on the SLC.
The FPP-RNAC-8A-4C Remote NAC Booster adds four
additional Notification Appliance Circuits (NFPA 72,
Class A Style Z or Class B Style Y) to the fire panel or
serves as a power supply for fire protective signaling
systems. This regulated power supply provides up to
6 A of power that is used to recharge batteries and
operate continuous and intermittent alarm loads. This
6 A of power can be distributed through the four NAC
Power Supply circuits that are part of the
FPP-RNAC-8A-4C. The FPP-RNAC-8A-4C is UL Listed for

in commercial fire alarm applications.

use

Signaling Line Circuits (SLCs)

The FPA‑1000‑UL Fire Panel uses the patented DCP
Digital Communication Protocol to communicate with
each of the analog addressable devices located on the
SLCs. This fast and reliable protocol allows the use of
standard non‑twisted, non‑shielded wiring for the
SLCs. The FPA‑1000‑UL supports two Class B, Style 4
or one Class A, Style 6 or 7 per SLC.

3 | FPA‑1000‑UL Analog Addressable Fire Panel

Certifications and Approvals

Region Certification

USA UL FSZI: Emergency Alarm System Control

Canada IC 1249A-FPA1000

USA FCC ESVAL00BFPA1000

CSFM 7165-1615:0229

FDNY­CoA

FM Signaling Systems - Central Station,

Units (ANSI/UL 2017) and
UOJZ: Control Units, System
(ANSI/UL 864, 9th

6034

Local Protective, Proprietary, and Remote
Station [FPA-1000-UL]

edition)

Installation/Configuration Notes

Mounting Considerations

The cabinet can be either semi-flush (requires optional
FPM‑1000‑SFMK Semi-flush Mounting Kit) or surface
mounted.
Depending on the configuration and the battery
selection, the FPA‑1000‑UL can be quite heavy. When
attaching the enclosure to a surface, use mounting
hardware (not supplied) capable of supporting this
weight,

and reinforce the wall as necessary.

Wiring Considerations

The length of wire allowed between the control panel
and the last device on a wiring run depends on the
current drawn on that wiring run. Reducing the
number of devices on a wiring run allows the individual
runs to be longer.
If not specified, use wire gauge 12 AWG to 18 AWG
(3.3 mm2 to 0.8 mm2).

Notice

Shared cable is not recommended for the Option
Bus, addressable‑points bus, telephone, or NAC
wiring. Do not run wiring for NAC, Option Bus,
and SLC in the same conduit. Avoid shielded or
twisted-pair wire except for special applications
where a reduced length of wiring (roughly 50%) is
acceptable for tolerating a harsh electrical
environment.

Point Capacity/Configuration

The FPA-1000-UL supports up to 508 addresses, 254
per loop. For addresses above 127 on each loop, only
the FAA‑325‑B6S Sounder base, FAP‑325‑V2F Smoke
Detector, FLM‑325-I4‑A and FLM‑325‑I4‑AI Contact
Monitors, FLM‑325‑NA4 and FLM‑325‑NAI4 Supervised
Output Modules, FLM‑325‑2R4‑2AI 2 A Dual Relay
Module, and FLM‑325‑2R4‑8A and FLM‑325‑2R4‑8AI 8 A
Dual Relay Modules can be used. For systems requiring
more than 127 points per loop, use these devices on
addresses above 127 and other devices below address

127.

Parts Included

Quant. Component

1 FPA‑1000‑UL main board

1 Enclosure with transformer

1 Enclosure lock and two keys1 (replacement key: D102)

1 FPE-1000-SLC signaling line circuit module

1 Hardware pack

3 Wiring labels (one each in English, Spanish, and

2 2.21 kΩ EOL resistors

Tabs with different language versions for LED and key text

Literature (one of each document type in English, Spanish,

1

Key code stamped on both lock and key

Portuguese)

(replacement resistors: EOL‑2.2K, 8 per package)

and Portuguese)

• Installation and Operation Guide

• Operating Instruction Sheet

• Program Record Sheet

• Release Note

Technical Specifications

Electrical

Power supply (primary)

Current: 120 VAC: 2 A maximum

Voltage: 120 VAC, 60 Hz or 240 VAC, 50 Hz

Power supply (secondary)

Current (Alarm)

Current (load):

Voltage:

Batteries

Voltage:

Capacities: maximum 40 Ah

Fuses

Auxiliary power supply (AUX)

240 VAC: 1 A maximum

• Panel < 0.240 A

• SLC = 0.63 A maximum

Standby: < 1.25 A

Alarm: 4 A Shared maximum

•

NAC 1 = 2.5 A maximum
NAC 2 = 2.5 A maximum

•

• AUX/FWR = 0.5 A maximum

• AUX/RST = 0.5 A maximum

• Option bus = 0.5 A maximum

24 VDC

2 x 12 VDC in series

• in cabinet: 7 Ah to 18 Ah

• in additional battery box: 24 Ah
to 40 Ah

15 A blade type

4 | FPA‑1000‑UL Analog Addressable Fire Panel

AUX/FWR: 0.5 A at 24 V FWR

AUX/RST: 0.5 A at 24 VDC

Non‑switched, power‑limited, unfiltered,
unsupervised

Switched, power‑limited, filtered,
unsupervised

Environmental

Environment:

Protection Class:

Relative Humidity: Up to 95%, non-condensing

Temperature (operating): +32°F to +120°F (0°C to +49°C)

Temperature (storage):

Indoor, dry

IP 30

+14°F to +131°F (-10°C to +55°C)

Mechanical

Operating Elements

LCD:

LEDs: Six total: Fire, Gas Alarm, Power,

Operation Keys: Drill, Reset, Silence, and Acknowledge

Alphanumeric Keypad:

Interfaces

PSTN/DACT:

Ethernet 1 x RJ45

Wiring

4‑line x 20‑character display, backlit

Supervisory, Silenced, and Trouble

12 alphanumeric keys, escape, enter,
and navigation buttons (left, right, up,
down)

2 lines, RJ45

Ordering Information

FPA‑1000‑UL Analog/Addressable Fire Panel UL

FPA‑1000‑UL Analog/Addressable Fire Panel with
enclosure and transformer

Order number FPA-1000-UL

FPA-1000-LC Analog Addressable Fire Panel Less
Enclosure

FPA‑1000‑UL Analog Addressable Fire Panel without
enclosure

Order number FPA-1000-LC

D7030X‑S2 LED Annunciator

Two LEDs indicate supervisory conditions; six indicate
alarm conditions.

Order number D7030X-S2

D7030X‑S8 LED Annunciator

All eight zone LEDs indicate supervisory conditions.

Order number D7030X-S8

D7035 Octal Relay Module

Provide eight Form C relay outputs (w/o enclosure) for
the D7024, FPD-7024, or FPA‑1000 Fire Alarm Control
Panels (FACP)

Order number D7035

D7035B Octal Relay Module with Enclosure

Provide eight Form C relay outputs (w/ enclosure) for
the D7024, FPD-7024, or FPA‑1000 Fire Alarm Control
Panels (FACP)

Order number D7035B

D7048 Octal Driver Module

Module and hardware

Order number D7048

Cable Entries:

Connections: Pluggable terminal blocks for AUX, Op-

Wire Gauge: 12 AWG to 18 AWG (0.75 mm2 to

Enclosure

Material: Cold rolled steel, 19 gauge (1.2 mm)

Color:

Dimensions (W x H x D): 14.5 in. x 4.3 in. x 22.7 in.

Dimensions with trim ring
(W x D):
Semi-flush mounted
(H recessed / H flush):

Weight: 18.1 lb (8.32 kg)

Double knock-outs (3/4, 1/2 in)

tion Bus, SLC, NAC, Main Board Relays

3.25 mm2)

Red

(36.8 cm x 10.9 cm x 57.7 cm)

17.5 in. x 25.6 in.(44.5 cm x 65.0 cm)

3.25 in. / 1.05 in. (8.25 cm / 2.7 cm)

D7048B Octal Driver Module with Fire Enclosure

Module, mounting plate, metal enclosure, and
hardware

Order number D7048B

FAA‑325‑B4 4‑inch Analog Sensor Base

Is combined with analog addressable detectors that
use the advanced digital communication protocol to
provide early fire warning for life safety and property
protection

Order number FAA-325-B4

FAA‑325‑B6S Analog Sounder Base

Contains an addressable sounder which provides an
audible alarm in the immediate vicinity and only works
in combination with one of the FAH‑325, FAI-325, or
FAP‑325 series analog sensors

Order number FAA-325-B6S

FAD‑325 Analog Duct Detector

Housing for use in heating, ventilation and air
conditioning systems (HVAC) that comes with an
FAD‑325‑DH Analog Duct Smoke Detector
Replacement

Order number FAD-325

5 | FPA‑1000‑UL Analog Addressable Fire Panel

FAD‑325‑R Analog Duct Detector with Relay

Housing with two Form C alarm contacts for use in
heating, ventilation and air conditioning systems
(HVAC) that comes with an FAD‑325‑DH Analog Duct
Smoke Detector Replacement. US sales only!

Order number FAD-325-R

FAH‑325 Analog Heat Detector

Used in indoor environments with high ambient tem­peratures such as kitchens, boiler rooms, or drying
rooms; compatible with 127 addresses

Order number FAH-325

FAI‑325 Analog Ionization Smoke Detector

For early warning of trouble from superheated or flam­ing combustibles where outside RFI and other electri­cal interference is expected. US sales only!

Order number FAI-325

FMM‑325A Single‑action Manual Station

Communicates with the FPA‑1000 Analog Addressable
Fire Panels, D9024, D8024, and D10024A FACPs (both
power and data) over a two‑wire polling circuit

Order number FMM-325A

FMM‑325A‑D Double‑action Manual Station

Communicates with the FPA‑1000 Analog Addressable
Fire Panels, D9024, D8024, and D10024A FACPs (both
power and data) over a two‑wire polling circuit

Order number FMM-325A-D

Accessories

FMR‑1000‑RA Remote Annunciator

LCD annunciator without system control capability for
use with the FPA‑1000 Analog Addressable Fire Panels

Order number FMR-1000-RA

FMR‑1000‑RCMD Remote Command Center

LCD annunciator with system control capability for use
with FPA‑1000 Analog Addressable fire Panels

Order number FMR-1000-RCMD

FPE‑1000‑CITY City Tie Plug‑in Module

Provides the FPA‑1000 Analog Addressable Fire Panels
with two supervised City Tie Local Energy circuits or
Reverse Polarity circuits

Order number FPE-1000-CITY

FPE‑1000‑SLC Signaling Line Circuit Plug‑in Module

Provides a Signaling Line Circuit (SLC) for connection
of analog devices to the FPA‑1000 Analog Addressable
Fire Panels

Order number FPE-1000-SLC

FPM‑1000‑ENC Enclosure with Dead Front Door

Enclosure with dead front door

Order number FPM-1000-ENC

D5070 Analog Device Programmer

Programs address settings on EEPROM‑programmable
analog devices

Order number D5070

D7030X LED Annunciator

Eight zone LEDs indicate alarm conditions.

Order number D7030X

D7032 Eight‑zone LED Annunciator Expander

Use with D7030X Series LED Annunciators

Order number D7032

FAA‑325‑2.5 Sampling Tube (2.5 ft)

2.5 ft (762 mm) long sample tube for use with the
FAD‑325 and FAD‑325‑R Analog Duct Detectors

Order number FAA-325-2.5

FAA‑325‑5 Sampling Tube (5 ft)

5 ft (1.52 m) long sample tube for use with the
FAD‑325 and FAD‑325‑R Analog Duct Detectors

Order number FAA-325-5

FAA‑325‑10 Sampling Tube (10 ft)

10 ft (3.05 m) long sample tube for use with the
FAD‑325 and FAD‑325‑R Analog Duct Detectors

Order number FAA-325-10

FAA‑325‑B6 6‑inch Analog Sensor Base

6‑inch (152.4 mm) base for FAH‑325, FAI‑325, and
FAP‑325 sensors. US sales only!

Order number FAA-325-B6

FAD-325-DH Analog Duct Smoke Detector Replacement
Head

Replacement detector for the FAD-325 and the
FAD‑325‑DH Analog Duct Smoke Detectors for use in
heating, ventilation, and air conditioning systems

Order number FAD-325-DH

FLM‑325‑2I4 Dual Input Monitor

Provides two independent contact monitoring circuits
to monitor Normally Open (NO) or Normally Closed
(NC) dry contact types of fire alarm devices

Order number FLM-325-2I4

FLM‑325‑2R4 Dual Relay Module

Provides two independently‑controlled Form C
contacts for a variety of Normally Open and
Normally Closed applications

Order number FLM-325-2R4

FLM‑325‑CZM4 Conventional Zone Module

Enables the FACP to interface and monitor up to 25
conventional devices depending on the device type
such as two‑wire smoke detectors or pull stations

Order number FLM-325-CZM4

FLM‑325‑I4 Contact Monitor 4‑inch

Mounted to a cover plate for a 4‑inch square or double
gang electrical back box; a bi‑colored LED provides
module status; compatible with 127 addresses

Order number FLM-325-I4

6 | FPA‑1000‑UL Analog Addressable Fire Panel

Represented by:

© Bosch Security Systems 2012 | Data subject to change without notice
2689769995 | en, V2, 08. Feb 2012

FLM‑325‑ISO Short Circuit Isolator

Isolates a shorted section on a specific polling circuit
from the rest of the system to minimize the loss of
communication

Order number FLM-325-ISO
