BORK CM DEP 1012 Explode view

SPARE PARTS LIST

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

1 31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

1 top cover PP 1
2 screw ST3X8 2
3 tank cover PP 1
4 hot water sprayer PP 1
5 joint pipe silicone 1
6 water tank PP 1
7 steam pipe PP 1
8 flat washer SUS 1
9 seal ring 2 silicone 1

seal ring 1 silicone 1
clean window PC 1
button PP 1
PCB (1) PP 1
control panel PP 1
screw ST3X8 6
water gauge PP 1
back valve PP 1
in tube silicone 1
out tube silicone 1
screw ST3X12 2
main housing PP 1
caliper ring SUS 3
Insulating Ring silicone 1
warmer plate secc 1
Shelve Block bakelite 5
nylon tie NYLON 3
shrinkage tube 6L=30 3
earth lead wire
ring terminal Brass 2
silicon tube

fibreglass tube
clip Brass 2
temperature fuse 1
leader wire L1=90 1
power cord 1
sleeve PVC 2
Strain Resift PP 1
leader wire L2=120 1
screw M3X8 2
lock washer
leader wire L4=120 1
leader wire L3=130 1
terminal 250 7
filter handle PP 1

Æ1.0×50

Æ4.5×Æ7×60
Æ7×60

Æ3.2

1

1

2
