Page 1
Performance.
Passion for
HP2 Enduro.
BMW Motorrad
High Performance
HP2 Enduro
The Ultimate
Riding Machine
Page 2
Page 3
The genius is in the detail:
a spirit level for calibrating
the damping.
03-05 | HP2 Enduro
For cruising the streets:
the HP2 Enduro with 17-inch
road wheels.
HP stands for high performance. And high performance is achieved by focusing only on the essentials,
and getting rid of anything that does not contribute to this objective. This ruthless elimination of excess
weight combined with a wealth of radical design details has resulted in a truly unique motorcycle.
BMW Motorrad’s design engineers have had this vision for many years. Now ´ nally the world is ready for it.”
„
Page 4
06-07| HP2 Enduro
“I earn a lot of
frequent µ yer miles.”
Page 5
08-09| HP2 Enduro
“Great roads around here.”
Page 6
A world ´ rst: the HP2 Enduro is the ´ rst production
motorcycle to feature the Air Damping System,
a spring damper mechanism that runs exclusively
on air.
High-tech made easy.
Technology doesn’t have to be complicated to be innova-
tive. With the Air Damping System, simply adjusting the
air pressure to the rider’s weight is enough to ensure the
optimum balance of compression and rebound damping.
And the adjustment process could hardly be easier. All the
rider has to do is sit on his bike on a µ at surface, and turn
the valve on the Air Damping System until the spirit level
built into the bike is correctly aligned.
The air pressure can also be adjusted manually, using a
hand pump stowed under the seat to increase it, and a
release valve to decrease it. Once the suspension has been
set up in this way, the damping can be ´ ne-tuned in both
Sport and Competition modes via a handwheel on the
suspension strut.
Advantage BMW.
BMW Motorrad’s new Air Damping System has a number
of advantages compared with oil-damped suspension
struts with coil springs. It manages to combine involving
feedback with outstanding stability, so you enjoy a smooth
ride even on rough terrain. This lightweight solution is also
completely maintenance-free.
Look, no spring!
10-11| HP2 Enduro
Elastomer end stop
Valve
Bypass hole
Bellows
Piston rod
Overµ ow to
upper chamber
Air valves for compression
and rebound phases
Dividing piston
Handwheel
Riding on air.
Page 7
“Someone asked me the other day if there was
any way the chassis could be improved.”
12-13| HP2 Enduro
“I’m still thinking about it.”
Page 8
14-15| HP2 Enduro
“It’s like a 1200-cc BMX.”
Page 9
Total freedom at your feet.
16-17| HP2 Enduro
The generously sized footrests and narrow seat of the HP2 Enduro
allow riders to really throw their weight around. Because freedom
of movement is vital to getting maximum performance from your
machine, especially in slow, twisting, technically demanding
ections. And the high-torque boxer engine with its low centre
of gravity and smooth power delivery is the perfect complement
to the HP2 Enduro’s rider-friendly handling, ensuring you can cross
even the most challenging of terrain with the minimum of fuss.
Page 10
“105-horsepower* power drifts.
Any questions?”
* 77 kW
18-19| HP2 Enduro
Page 11
For off-road riding without compromises:
the HP2 Enduro with enduro tyres.
Dimensions/weight
Seat height 920 mm
Unladen weight
(fully fuelled/road ready)* 195 kg
Dry weight** 175 kg
Max. permitted total weight 380 kg
Usable tank volume 13 l
Reserve 2 l
Length 2,350 mm
Width (across mirrors) 880 mm
*As de² ned in EU directive 93/93/EEC,
² lled with all operating ³ uids, fuelled to
at least 90% of usable tank capacity.
** Without ³ uids.
Frame Steel space frame
Suspension, front USD fork with WAD travel-related damping, 45 mm diameter,
compression continuously adjustable within two zones,
rebound continuously adjustable
Suspension, rear Die-cast aluminium single-sided swinging arm with BMW
Motorrad Paralever, innovative Air Damping System, spring
pre-load and damping in² nitely adjustable via a pneumatic
mechanism
Travel, front/rear 270 mm/250 mm
Rim size, front 1.85 x 21" cross-spoke wheel
Rim size, rear 2.50 x 17" cross-spoke wheel
Tyre, front 90/90 - 21
Tyre, rear 140/80 - 17
Brakes, front Single disc brake, diameter 305 mm, double-piston
³ oating caliper
Brakes, rear Single disc brake, diameter 265 mm, vibration-damped,
double-piston ³ oating caliper
Chassis/brakes
Type Air/oil-cooled 4-stroke, 2-cylinder boxer, twin camshafts,
four valves per cylinder
Bore x stroke 101 mm x 73 mm
Capacity 1,170 cc
Output 77 KW (105 bhp) at 7,000 rpm
Max. torque 115 Nm at 5,500 rpm
Compression ratio 11.0 : 1
Fuel/
engine management
Electronic intake pipe injection, BMS-K digital engine
management with overrun fuel cut-off, double ignition
Emission control Regulated 3-way catalytic converter, compliant with
EU3 emission standard
Engine
Maximum speed 200 km/h
Fuel consumption – 100 km
at a constant 90 km/h 4.1 litres
Fuel consumption – 100 km
at a constant 120 km/h 5.5 litres
Fuel type Super plus unleaded 98 octane (RON); can also be oper-
ated with minimum 95 octane (RON) due to automatic knock
control
Performance/fuel consumption
Clutch Single-disc dry clutch, hydraulically operated
Gears Synchromesh 6-speed helical gearbox
Drive Shaft drive
Transmission
Battery 12 V/12 Ah
Electrics
Technical data
Width: 880 mm
Overall length: 2,350 mm
Seat height: 920 mm*
Wheelbase: 1,610 mm Castor: 127 mm
Cylinder head angle: 60.5°
All ² gures relate to motorcycle with
normal load (= inc. 85 kg for rider).
* Figure relates to unladen motorcycle
as per DIN standard.
20-22 | HP2 Enduro
Page 12
The HP2 Enduro is ² tted as standard with an array
of special components.
• Grab bar
• USD fork with WAD travel-related damping
• Air Damping System
• Plastic cylinder guard
• Spare wheel mounting point on rear wheel
• Detachable number plate mounting
Ready to rumble. HP2 Enduro.
Useful accessories to suit every need.
• Enduro rear bag
• BMW Navigator with base unit
• Pillion passenger footrests
• Emergency valve cover repair kit
• Low seat
• Steering column guard
• White indicators
• LED white indicators*
The Enduro package, supplied as standard, gives your HP2 Enduro
the professional equipment it needs to meet any challenge.
• Hand protectors (not illustrated)
• Headlight guard
• Rear axle guard
• Cylinder guard
• Brake snake
The Enduro package (fitted as standard).
17-inch road tyres
This wheel set comprises rear and front
rims (including brake discs), pre-² tted with
tyres. It can easily be ² tted in place of the
enduro wheels.
Height-adjustable foot brake lever
The height of the foot brake lever can be
adjusted by about 20 millimetres without
the need for a tool, ensuring maximum
comfort in both the seated (on-road) and
standing (off-road) positions.
Sport silencer
The 100-per cent titanium sport silencer
from AkrapoviĖ
®
weighs just 2.2 kilograms
(approx.) and sounds every bit as good as
it looks.
Enduro tank rucksack
Specially designed for the HP2, this
tank rucksack is both stylish and totally
waterproof. The main compartment
includes a generously sized map pocket.
Capacity is expandable from 12 to 18 litres.
Headlight guard
A sheet of clear plastic mounted in front
of the headlight prevents damage from
³ ying stones. For off-road use only.
Brake snake
A metal cable between the foot brake
lever and the engine prevents objects
such as rocks and branches from jamming
the brake.
Cylinder guard
A slimline yet heavy-duty plastic protector
to prevent damage in the cylinder/throttle
valve area.
For those who want a little bit extra.
* Available from spring 2007.
Rear axle guard
Greatly reduces the risk of damage to the
rear axle transmission casing when riding
on hard surfaces.
Page 13
bmw-motorrad.com
The illustrations in this brochure show professional riders, following carefully selected routes on private property. BMW Motorrad does not recommend that any riders (particularly inexperienced ones) attempt to replicate what is illustrated here. The models illustrated in this brochure show
the specifications for Germany. In part, they include optional equipment and accessories not fitted as standard. According to the specific requirements of other markets, alterations in models, standard and optional equipment as described in the text and illustrations may occur. For detailed
information on the range of rider equipment and accessories available in your country, please contact your BMW Motorrad dealer. Subject to change in design and equipment. Subject to error.
© BMW Motorrad, UX-VM-2, Munich, Germany. Not to be reproduced, wholly or in part, without written permission of BMW AG, Munich. Printed in Germany 08/2006. 6 11 202 236 20
