Blaupunkt RCR 168 User Manual

Cobur g RCR 168 Colorado RCR 168 Portofino RCR 168
Operating instructions
DEUTSCH
ITALIANO
NEDERLANDS
PORTUGUÊS
1
8
1
2
3
4
5 9
6
7
10
15
16
17
3
2
2
14
10
A készülék a 70 MHz.-es sávban mæködœ URH adók vételére nem alkalmas. Az OIRT sáv vételét (Kossuth, Petœfi, Bartók) le-
9
hetœvé tevœ keverœ, külön tartozékként megvásárolható, az egy éves jótállási idœn belül. A vásárlás lehetœségét a jótállást vállaló biztositja.
11
1213
Display
The display consists of three fields and varies according to the operating mode and function.
Display field 1:
Radio mode Memory banks and wavebands Brief indication of preset station (e.g. P1)
Display field 2:
Radio mode Radio frequency or station name PTY programme type Clock display
Cassette mode CAS - cassette inserted MTL - tape type
Cassette mode TAPE1/TAPE2 - side of tape playing Active functions (e.g. CPS)
Audio
Clock display Numeric and graphic representation of vo­lume and audio settings
DSC Permanent display for DSC programming. Graphic representation of the adjusted vo­lume level.
DSC
Serves as display and input field during
DSC programming
Clock display
Miscellaneous
Indicates new source (e.g. when changing
from radio to cassette) and active functions
(e.g. BASS, SCAN)
Display field 3:
Active functions
- Stereo
- Cassette inserted
LD - Loudness Radio mode
AF - Alternative Frequency for RDS PTY - RDS programme type TA - Priority for traffic information TP - Traffic programme station lo - Seek tuning sensitivity
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
21
ESPAÑOL
PORTUGUÊS
Contents
Display .........................................21
Quick reference ........................... 23
Remote control operation .................... 26
Important notes ........................... 26
What you need to know....................... 26
Traffic safety ........................................ 26
Installation............................................ 26
Telephone mute................................... 26
Warning note .................................. 27
Accessories ......................................... 27
Release panel .............................. 27
Theft protection.................................... 27
Detaching the release panel................ 27
Attaching the release panel................. 27
Fixing the release panel ...................... 28
Selecting the operating mode.... 28
Radio operation with RDS .......... 28
AF - Alternative frequency................... 28
REG - regional programme ................. 28
Selecting a waveband ......................... 29
Station tuning....................................... 29
Automatic seek tuning / ............. 29
Scrolling through the broadcast
networks (FM only) .............................. 29
Switching between the memory
banks (FM)........................................... 29
Storing stations....................................29
Automatically storing the strongest
stations with Travelstore...................... 30
Recalling stored stations ..................... 30
Scanning stored stations with
Preset Scan ......................................... 30
Scanning stations with Radio Scan..... 30
Changing the scan time....................... 30
Selecting the automatic tuning
sensitivity ............................................. 30
PTY - Programme Type....................... 31
Programme types .............................31
Switching PTY ON/OFF ................... 31
Checking the programme type of
the station.........................................31
Displaying the selected programme
type...................................................31
Selecting a programme type ............ 31
Storing programme types................. 32
Scanning stations with PTY SCAN .. 32
PTY priority.......................................32
Traffic programme station
reception with RDS-EON ............ 33
Traffic announcement priority on/off ... 33
Warning beep ...................................... 33
Switching the warning beep off........34
Automatic seek tuning start
(Cassette mode) .................................. 34
Adjusting the volume for traffic an­nouncements and the warning beep ... 34
Cassette deck operation ............34
Cassette playback ............................... 34
Reversing the tape .............................. 34
Skipping cassette titles........................ 34
Scan.....................................................34
Fast winding......................................... 34
Tape type selection ............................. 35
Cassette eject ...................................... 35
Traffic information during cassette
playback............................................... 35
Clock ............................................ 35
Setting the clock .................................. 35
Setting the TIMER ............................... 35
Naming an external audio
source .......................................... 36
DSC programming ...................... 36
Overview of the DSC factory settings . 37
Specifications.............................. 38
Amplifier ............................................... 38
Tuner.................................................... 38
Cassette............................................... 38
22
Quick reference
1 REL
To release the detachable panel (theft protection). Press this knob and remove the re­lease panel.
2 ON - Power on/off
Press this button to turn the unit on. It will play at the preset volume. If you press this button briefly while listening to the radio, the volume will mute instantly (MUTE). Cancel this function by pressing the ON button again. You can adjust the mute volume (refer to the section on DSC programming). Press the button for about 2 seconds to turn the unit off.
Switching on/off with the ignition:
If the unit has been connected as des­cribed in the instructions, it can also be turned on and off with the vehicle ignition. Press the ON button to keep on ope­rating the unit when the ignition is switched off. To prevent the battery from running down, the system will turn off automa­tically after one hour of playback.
3 Volume knob
Turn the knob to adjust the volume.
4 DSC Direct Software Control
This feature allows you to adjust the basic programmable settings. For further information, refer to the section on DSC programming.
5 Cassette slot
Insert the tape into the slot with the open side showing to the right. The tape will be played in direction "TAPE 1".
6 Display
The display indicates all settings, ope­rating modes and functions.
7
This button switches tape playback between Tape 1 and Tape 2 (different sides of the tape).
88
8
Eject
88
Press this button to eject the cassette.
9 Rocker switch
Radio mode
/ Seek tuning
Up Down
<< / >> Up/down in short intervals
(for FM only if "AF" is off)
For FM only: << / >> Scrolls through the broad
cast networks, if AF is on. Example: NDR 1, 2, 4,
Cassette mode
/ CPS function
Up
Down Press repeatedly to skip over the cor­responding number of songs. Press the button indicating the opposite di­rection or << >> to stop the function.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
23
>> Fast forward << Fast rewind
Press the button indicating the opposi­te direction or ding.
Additional rocker switch functions:
For additional settings use
AUD ; DSC-MODE 4 PTY @
Important: The corresponding function must be active.
: SRC (Source)
Press button briefly to select the ope­rating mode (tuner, cassette or AUX IN). The active mode will appear in the display.
; AUD
Treble and bass adjustment
You can store different settings for the FM, MW, LW, cassette mode and AUX IN.
Setting the tone:
Select the operating mode. Press AUD once and use the rocker
switch to set the tone.
/ to stop tape win-
Treble +
Treble ­<< Bass ­>> Bass
For Fader and balance adjustment: press AUD twice.
Fader front
Fader rear << Balance left >> Balance right
The selected values will appear in the display. The last setting is stored au­tomatically.
Switching AUD off: Press the button again briefly. If you do not make any adjustments to the tone within 8 seconds, the AUD mode will quit automatically.
Extra function: LD
Loudness boosts the bass frequency at low volume. Loudness on/off: Press AUD for ap­prox. 1 second. "LD" will appear when this setting is active. Refer to the section on DSC pro­gramming to adjust Loudness to diffe­rent levels.
< SCA Scan
Scans radio stations or song titles/ tracks. You can set the scan time in DSC pro­gramming.
Radio mode Press SCA briefly.
All of the FM stations within reception range will be scanned. "SCAN" will appear in the display, alternating with the radio station currently being scan­ned (flashing).
Preset Scan
Press SCA for approx. 2 seconds until you hear a beep. "PS Scan" will ap­pear in the display, followed by the station symbol (flashing). The stations stored on the station pre­set buttons and within reception range will be scanned. To stop Scan / Preset Scan: Press SCA again.
PTY Scan
PTY Scan cannot be started unless PTY is switched on ("PTY" will light up in the display.) The radio stations for the program type selected will be scanned. "PTY SCAN" will appear in the dis-
24
play, alternating with radio station currently being scanned (flashing). To stop Scan / PTY Scan: Press SCA again.
Cassette mode Press SCA briefly.
All of the titles on the cassette will be scanned. To stop Scan: Press SCA again
= DIS - Clock display
Radio mode Press this button briefly and the time
will appear in the display for a short while.
Cassette mode Press this button to switch the display
between the time and the cassette track (TAPE 1/TAPE 2).
> Preset buttons 1 to 6
Radio mode You can store six stations in each FM
memory bank (1, 2, and "T"). On MW and LW you can also store six stations each
hout MW, LW)
(Coburg RCR 168 wit-
.
Store station - Hold down a preset button in radio mode until you hear a beep. Recall station - Select a waveband and the memory bank on FM as well; press the corresponding preset button briefly.
Cassette mode
1/MTL -
Selects between chrome or iron oxide tape types. Press 1/MTL.
- Pause
3/
Interrupts tape playback. "PAUSE" will appear in the display. Press this button once again to resu­me playback.
? BA/TS
Switches between the wavebands/ memory banks FM1, FM2, FMT (Tra­velstore), MW and LW
168 without MW, LW)
(Coburg RCR
.
Extra function: Travelstore
To store the six most powerful radio stations in the Travelstore bank: Press BA/TS until a beep sounds and "T-STORE" appears.
@ PTY (Programme Type)
You can select among various pro­gramme types. Using the rocker switch <<>> it is possible to recall all PTY programme types, if PTY is acti­vated ("PTY" lights up in the display).
A AF·TA
Alternative Frequency in RDS mode: If "AF" appears in the display, the ra­dio will automatically search for the best radio frequency offering the same programme. AF on/off: Press AF·TA until a beep is emitted.
TA (Traffic Announcement = priority for traffic programmes) TA on/off: Press AF·TA briefly: "TA" will appear in the display, priority for traffic pro­grammes activated. “TP” (Traffic Programme) will be dis­played when the radio is tuned into a station which broadcasts traffic infor­mation.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
25
Important notes
Remote control operation
General SRC Press briefly: change the audio
source Press briefly: muting
V+ Higher volume V- Lower volume
Radio mode
Seek tuning upwards
Seek tuning downwards >> Next FM preset upwards << Press briefly: select the wave-
band
Hold down: Travelstore Cassette mode
Select track (CPS) upwards
Select track (CPS) downwards >> Fast forward << Fast rewind
Hold down: reversing the tape
What you need to know
Before using your new car audio system, please read through the following informa­tion carefully.
Traffic safety
As the driver of a motor vehicle, it is your responsibility to pay attention to the traffic situation at all times. Never use your car audio system in a way that could distract you.
Please keep in mind that you travel a di­stance of 14 m per second at a speed of only 50 km/h.
Should the traffic situation become parti­cularly demanding, we advise you not to use the audio system.
Always make sure that you are still able to hear any warning signals coming from out­side the vehicle, such as police or fire en­gine sirens, so that you can react accor­dingly.
Consequently, you should always select a moderate volume for playing your car au­dio system while you are driving.
Installation
If you would like to install your new car ste­reo yourself or add other audio compon­ents to existing ones, then please read the enclosed instructions on installation and connection carefully.
In order to ensure that the unit operates properly the positive power supply line must be connected via the ignition and the per­manent +12 V lead.
Do not ground the loudspeaker outputs!
Telephone mute
If you have installed a car telephone in your vehicle, it is possible to automatically mute the radio and cassette playback when you use the telephone (telephone mute). "PHONE" will then appear in the display. Traffic announcements continue to have priority if you have activated TA. You can interrupt traffic messages by pressing AF·TA.
26
Release panel
Warning note
Danger of damage to the automatic power antenna in a car wash. Before you drive into a car wash
• switch the radio off by pressing the ON button.
The power antenna will retract, if it doesn’t, press ON again. Do not drive into the car wash unless the power antenna has retracted!
Accessories
Use only Blaupunkt-approved accessories and spare parts.
Remote control unit (not included with the unit, sold seperately) The RC 08 infrared remote control unit al­lows you to conveniently operate the most important functions from the steering wheel.
Theft protection
This unit is equipped with a detachable con­trol panel. A car radio without a control pa­nel is worthless to thieves.
Protect your car audio system and detach the control panel when you leave your ve­hicle. Thanks to the release panel’s well­planned design, it is very easy to attach and detach.
Note:
Do not pull the release panel straight out from the chassis, but rather slide it to the left to detach it as illustrated below. Be sure not to drop the panel. Do not expose the release panel to direct sunlight or other heat sources. Do not expose it to moisture.
Detaching the release panel
Press the REL button to release the con­trol panel. Then remove the panel and in­sert it into the carrying case provided.
If the unit was still in operation, it will turn off now. All current settings will remain stored. If a cassette is inserted, it will remain in the unit.
The unit will turn on again automatically when you re-attach the release panel.
Attaching the release panel
Slide the panel (B) from the left along the guide of the chassis (A). Gently push the left side of the panel against the front of the chassis until it snaps into place.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
27
ESPAÑOL
PORTUGUÊS
Radio operation with RDS (Radio Data System)
Fixing the release panel
If you wish to fix the release panel to the chassis permanently, screw down the enclosed bolt into the hole (C) on the left hand side of the chassis, see Fig.
C
Selecting the operating mode
Use the SRC (source) button to select bet­ween radio and cassette mode.
To select the operating mode:
Press SRC.
28
The Radio Data System enhances your enjoyment when you listen to FM radio sta­tions. More and more radio stations now broad­cast RDS information along with their re­gular programming. As soon as a programme has been identi­fied, the station name including a regional identifier, if applicable, will appear in the display, for example, NDR1 NDS (regional programme in Lower Saxony, Germany). When RDS is activated, the preset buttons become programme buttons. You now know exactly which programme you have tuned into, making it easy to find the desi­red station quickly.
But RDS also offers you further advantages:
AF - Alternative frequency
The AF (Alternative Frequency) function makes sure that the radio always tunes into the strongest frequency for the currently sel­ected programme automatically. If this function is activated, "AF" will appear in the display.
To switch AF on/off,
press the AF·TA button for a longer time.
While searching for the strongest recepti­on signal, the radio may switch to mute briefly.
If "SEARCH" appears in the display when the radio is switched on or one of the stored frequencies recalled, the unit is already automatically searching for an alternative frequency. "SEARCH" will disappear from the display when the alternative frequency has been found or after the frequency band has run through completely. If the reception quality of the programme selected deteriorates beyond a certain point:
Tune into another station.
REG - regional programme
Certain radio programmes are split up at times into regional programmes offering local information. The 1st programme broadcast by NDR, for example, offers pro­grammes with different contents in the nor­thern German states of Schleswig-Holstein, Hamburg and Lower Saxony at certain times of the day. If you are listening to a particular regional programme and wish to continue doing so, select "REG ON" in the DSC mode. If you leave the service area of the regio­nal programme you are tuned into, or if you would like to take full advantage of RDS service, switch to "REG OFF" in the DSC mode.
Selecting a waveband
The following wavebands are available: UKW (FM) 87,5 – 108 MHz,
MW (AM) 531 – 1602 kHz und LW 153 – 279 kHz
(Coburg RCR 168 without MW, LW)
.
Press the BA/TS button to select the desired waveband.
Station tuning
Automatic seek tuning /
• Press / , the car radio will automati-
cally search for the next station.
If you hold / pressed up or down on the rocker switch, seek tuning will speed up in the corresponding direction.
Automatic seek tuning
<< / >> Up/down in short intervals (on FM
Up Down
only if "AF" is switched off)
Manual tuning with <<>> You can also tune into a station manually.
Important: AF and PTY must be switched off (i.e. the symbols do not light up in the display).
If necessary, deactivate these functions:
• Press AF·TA or PTY. Manual tuning:
• Press << >>; the frequency will change in short intervals in the corresponding direction.
If you hold << >> pressed to the left or the right on the rocker switch, the frequency scan will speed up.
Scrolling through the broadcast networks (FM only)
You can use the <<>> buttons to tune into stations in your reception area.
If it is possible to receive several program­mes in the same broadcast network, you can scroll through them in the forwards di­rection by pressing >>, or backwards using the << button, e.g. NDR 1, 2, 3, 4.
For this to work properly you must have al­ready tuned into the stations at least once and "AF" must be active (lights up in the display).
To do this, you can start the Travelstore seek operation:
• Press BA/TS for 2 seconds; the system will start to run through the frequency band.
If "AF" is not lit up,
Press AF·TA until a beep is emitted.
It is now possible to select stations using <<>>.
Switching between the memory banks (FM)
You can switch between the memory banks 1, 2 and T in order to store stations and recall them later.
The currently selected memory bank will appear in the display.
• Press the BA/TS button as many times as necessary until the desired memory bank lights up in the display.
Storing stations
On FM, you can store six stations on the preset buttons 1, 2, 3, 4, 5, 6 for each of the memory banks (1, 2, T).
On MW/LW, you can also store six stations each
(Coburg RCR 168 without MW, LW)
• Select the appropriate waveband by pressing BA/TS.
29
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
.
PORTUGUÊS
• Tune into a station with the rocker switch (either automatically / or manually <</>>).
• Press the desired preset button until the radio resumes play after the muting (takes approx. 2 seconds) or until you hear a beep.
Now the station has been stored. The display will indicate which preset but-
ton is currently activated.
Automatically storing the stron­gest stations with Travelstore
You can automatically store the six FM sta­tions with the most powerful signals in your current reception area sorted according to their signal strength. This function is parti­cularly convenient on longer trips.
• Press the BA/TS button for 2 seconds.
"T-STORE" will appear in the display. The six strongest FM stations will be auto­matically stored on the memory bank "T" (Travelstore). When this process has been completed, the radio will play the strongest station. If desired, stations can also be stored ma­nually in the Travelstore bank (see "Storing stations").
Recalling stored stations
You can recall any stored station at the touch of a button.
• Select the waveband by pressing BA/ TS. For FM, also choose the correspon­ding memory bank by pressing the BA/ TS button as many times as necessary until the desired bank appears in the dis­play.
• Press the corresponding preset button briefly to recall the station.
Scanning stored stations with Preset Scan
You can scan all of the stored stations on any of the wavebands.
To start Preset Scan:
• Press SCA for approx. 2 seconds.
All of the stations stored on the waveband will be scanned one after the other. "PS­SCAN" will appear in the display, alterna­ting with the station name or frequency. The abbreviation for the station currently play­ing (e.g. P1) will flash in display field 1.
Continue listening to a scanned station/ end Preset Scan:
• Press SCA briefly.
Scanning stations with Radio Scan
You can scan through all of the stations in your reception area.
To start the Scan function:
• Press SCA briefly. The scanned frequency or the station name will start flashing in the display.
During the scanning process "SCAN" will appear in the display.
To select a scanned station/switch off the Scan function:
• Press SCA briefly.
Changing the scan time
The scan time can be selected from bet­ween 5 to a maximum of 20 seconds. If you would like to alter the scan time, plea­se refer to the section on "DSC pro­gramming - SCANTIME".
Selecting the automatic tuning sensitivity
You can alter the automatic tuning sensiti­vity.
If "lo" is displayed, the radio will only pick up strong, local stations (low sensitivity).
30
If "lo" does not light up, the radio will also pick up weaker, more distant stations.
If you would like to alter the sensitivity level please refer to the section on "DSC pro­gramming - SENS".
PTY - Programme Type
PTY is an RDS service offered by an incre­asing number of broadcasting stations. This feature allows you to select FM stations according to their programme type. After you have chosen the PTY of your prefe­rence, the corresponding stations can be selected either by seek tuning or using the scan function.
Programme types
Switch PTY on. Use <<>> to have the last selected pro-
gramme type displayed and to choose a new one.
You can select any one of the stored types with the preset buttons 1-6.
The following list indicates some of the pro­gramme types which are currently availa­ble.
WEATHER FINANCE
TRAVEL HOBBIES JAZZ COUNTRY NEWS INFO SPORT CULTURE SCIENCE VARIED POP MUSIC ROCK MUSIC CLASSICS
Switching PTY ON/OFF
• Press PTY.
When the function is active, the program­me type selected last will briefly appear in the display. "PTY" will appear permanent­ly.
Checking the programme type of the station
• Press PTY for approx. 2 seconds.
After the beep tone the display will show the programme type offered by the station currently playing.
If "NONE" appears in the display, the cur­rent station has no PTY code.
Displaying the selected programme type
• Press << or >>. The programme type selected last will be
displayed briefly.
Selecting a programme type
a) Using the preset buttons
When PTY is switched on, you can use the preset buttons 1-6 to select the pro­gramme types stored at the factory.
• Press one of the presets 1-6. The selected programme type will be dis­played for 2 seconds.
If you would like to listen to a station with this PTY,
• press
/ to start the seek tuning
function. If the radio is unable to find a station offe­ring the selected programme type, the dis­play will show "NO PTY" and a beep tone will be emitted. The radio will select the sta­tion which was tuned into before seek tu­ning was activated. You can assign different programme types to each preset position.
31
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
Please refer to the next section on "Storing programme types".
b) Using the <<>> buttons on the rocker
switch When PTY is switched on, you can select a programme type using buttons <<>>.
• Press << or >>; the programme type selected last will be displayed for 3 se­conds.
• During this period press >> (forwards) or << (backwards) to select the desired type.
• Press << or >> as many times as requi­red.
If you would like to listen to a station with the selected PTY,
• press function.
If the radio is unable to find a station offe­ring the selected programme type, the dis­play will show "NO PTY" and a beep tone will be emitted. The radio will select the sta­tion which was tuned into before seek tu­ning was activated.
/ to start the seek tuning
Storing programme types
Each of the preset buttons 1-6 has been assigned one programme type at the fac­tory.
If desired, you can also replace these with other available programme types.
To do so, make sure that "PTY" lights up in the display.
• If necessary, press the PTY button to switch on the function.
• Select a programme type using buttons <<>> and
• hold down the desired preset button (1-
6) until you hear a beep.
Now the selected programme type can be recalled by pressing this preset as long as "PTY" lights up in the display.
Scanning stations with PTY SCAN
Important: "PTY" must appear in the dis­play.
• Press SCA.
All of the stations in your current reception area offering the selected programme type will be scanned.
To switch off PTY-SCAN:
Press SCA again.
PTY priority
Situation: PTY is switched on and lights up in the dis-
play. No station offering the selected program-
me type can be found currently in your re­ception range (with seek tuning or scan).
The set will switch back to the station pre­viously tuned into.
As soon as it is possible to receive a pro­gramme in the broadcast network with the PTY selected, the radio will switch over to the corresponding station for the duration of the programme.
Example:
- Station playing: NDR3.
- "PTY" lights up in the display.
- Programme type "POP" selected.
- Seek tuning is started.
- No station with "PTY-POP" can be found.
- The display shows "NO PTY" and
- automatically switches back to NDR3.
- NDR2 airs a "PTY-POP" programme.
- The radio will switch to the linked stati­on NDR2 for the duration of the "POP" programme.
32
Traffic programme station reception with RDS-EON
During cassette operation, the set will also switch to the radio programme if the selec­ted PTY becomes available within the broadcast network.
Note:
As already mentioned, these functions are only supported by a limited number of RDS stations at the present time.
The abbreviation "EON" stands for Enhan­ced Other Networks, which means that in­formation is exchanged within a radio net­work.
Many FM radio stations provide their ser­vice area with traffic messages at regular intervals.
Along with their programmes, all traffic pro­gramme stations transmit a special carrier signal, which is decoded by your car radio. If this signal is identified, "TP" will appear in the display (Traffic Programme).
In addition to these, there are also stations which do not actually transmit traffic infor­mation themselves, but by using RDS-EON it is possible for them to forward the traffic messages broadcast by another traffic pro­gramme station in the same radio network.
If you want to have the priority for traffic announcements activated while listening to one of these stations (e.g. NDR3), "TA" must appear on the display panel.
If a traffic announcement is broadcast, the radio will automatically switch to the linked traffic programme station (in this case, NDR2) for the duration of the message and return to the original programme (NDR3) afterwards.
Traffic announcement priority on/off
If the priority for traffic announcement pro­grammes is activated, "TA" will light up in the display.
To switch the priority on or off:
• Press the AF·TA button.
If you press AF·TA while a message is being broadcast, this message will be in­terrupted. The unit will then switch back to the pre­vious mode. The priority for other traffic messages remains active. Please note that several buttons have no function while a traffic announcement is broadcast.
Warning beep
If you leave the reception area of the traffic programme station currently tuned into, you will hear a warning beep after approx. 30 seconds. This warning will also be emitted if you press a preset button for a station which does not send the traffic programme signal (TP).
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
33
PORTUGUÊS
Cassette deck operation
Switching the warning beep off
a) Tune into another station offering traffic
information:
• Press the rocker switch or
• press a preset button which has a traffic programme station allocated to it.
Alternatively: b) Switch off the priority for traffic an-
nouncements:
• Press TA. "TA" will disappear from the display.
Automatic seek tuning start
(Cassette mode)
If you leave the reception area for the traf­fic programme station you have tuned into while you are listening to a cassette, the system will automatically start searching for a new traffic programme. If no such station is found within approx. 30 seconds, a warning beep will sound eve­ry 30 seconds. To switch the warning beep off, press TA button.
Adjusting the volume for traffic announcements and the warning beep
Although this volume was preset at the fac­tory, you can use the DSC function to alter the setting (see "DSC programming - TA VOL").
34
Cassette playback
Insert the tape into the slot with the open side showing to the right. "CASSETTE" will appear in the display. The tape will play in the direction "TAPE 1". If a tape is already inside, press SRC to select "CASSETTE" mode. The tape will play in the direction last selected.
Reversing the tape
Press to change the tape direction du­ring cassette playback from TAPE1 to TAPE2 or vice versa: At the end of the tape, the unit will automa­tically switch to the opposite side.
Skipping cassette titles
CPS stands for Cassette Program Search and allows you to skip over songs on the tape. The titles must, however, be separately by at least 3 seconds of blank tape. During tape playback press either on the rocker switch to activate the CPS mode. "CPS FF" or "CPS FR" will appear in the display. Press the button / repea­tedly to skip the corresponding number of titles in either direction.
or
The number of titles to be skipped will ap­pear in the display and count down until the title selected has been reached. Press
or << >> to stop the function.
Scan
To scan all of the songs on a tape, press SCA. "SCAN" will appear in the display. All of the titles on the tape in the tape deck will be scanned briefly one after the other. Press SCA again to switch the SCAN function off. The title currently playing will continue to play.
Fast winding
Use the rocker switch to fast forward or rewind the tape during cassette operation: >> forward << rewind. "FORWARD" or "REWIND" will light up in the display. Press the button indicating the opposite di­rection or If you have activated "Radio Monitor ON", the unit will play the radio station last sel­ected while the tape is winding. You can alter the Radio Monitor setting in DSC mode.
/ to stop the function.
Clock
Tape type selection
If you are playing METAL or CrO2 casset­tes, press MTL. "MTL" will then light up in display field 1.
Cassette eject
Press to eject the cassette.
Traffic information during cas­sette playback
The Traffic Announcement function (priori- ty for traffic programmes) makes it possi­ble to listen to traffic information during cas­sette playback. If a traffic message is broad­cast, cassette playback will be interrupted and you will hear the message. This function is active, if "TA" lights up in the display. Press AF·TA briefly to activate TA.
This unit is equipped with an internal clock. Display priority:
To alter the display priority, press
until you hear a beep. Press this button repea­tedly until the desired display appears (does not apply for radio mode).
Radio mode Press this button to display the clock briefly.
Cassette mode Press this button to switch between the track played and the clock.
Setting the clock
Set the clock in the DSC mode.
• Press DSC briefly.
• Press / to select the function
"CLOCKSET".
• Press << >> to activate the hours or the
minutes. The option you can set will flash.
• Press
• When you have completed the setting,
press DSC briefly to store it.
/ to alter the flashing display.
Setting the TIMER
Using this unit it is possible to conveniently switch on a radio station you have selec­ted at any time before. The radio station can be selected regardless of the currently active operating mode.
Proceed as follows:
• Select the radio station of your choice.
• Press DSC.
• Press
• If you want to turn off the Timer, press the << button and "OFF" will appear in display field 2.
• If you want to set the timer press the >> button. The timer time previously set will be shown first. Press >> button again to enter edit mode. The minutes will flash.
• Press
• Press << to activate the hour.
• Press / to set the hour.
• Press DSC to store your entry. You have now set the TIMER.
/ to select TIMER.
/ to set the minutes.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
35
ESPAÑOL
PORTUGUÊS
Naming an external audio source
AUX NAME makes it possible to enter a name of up to 8 characters for an external audio source (AUX ON, see DSC Menu). For this, press SRC to select the AUX mode (only possible if AUX ON is set in the DSC menu).
• Press SRC as often as required until AUX appears in the display.
Enter the AUX NAME in the DSC menu.
• Press DSC briefly.
• Press function
• Press << >> to enter into editing mode.
The adjustable position will flash.
• Press / to select a character you want to enter. Select a dash “_” to leave a blank space.
• Press << >> to select the next position.
• When you have entered the name com­pletely, press DSC briefly to store the name.
• Press DSC again to quit the DSC menu.
/ to select the AUX NAME
DSC programming
The car radio has been equipped with DSC (Direct Software Control) to allow you to cu­stomise certain programmable, basic set­tings to suit your personal needs and pre­ferences and then store them. The basic settings for this audio equipment were made at the factory. In the following you can find an overview of these settings, so that you can always re­set to them if desired. If you wish to alter any of the programming,
• press DSC. MENU
Use the to select the functions you wish to change. The display will show you the setting you have selected. Press << >> on the rocker switch to change the values. Confirm the setting you have selected by pressing the DSC button.
<< >> Adjust/recall value
/ will light up in the display.
/ buttons on the rocker switch
/ Select function
LOUDNESS Loudness boosts the bass
frequencies at low volume. LOUD 1 - Low boost LOUD 6 - Max. boost
BAS CENT Bass Center Frequency Ad-
justment. Adjusts the mid-range fre­quency to the specific equipment in the vehicle (50 or 100 Hz)
TA VOL The traffic announcement
and warning beep volume can be set between 0 to 63. The message will then come through at this volu­me, if the standard volume is lower.If the standard vo­lume is set higher than the TA VOL level, then the traf­fic report will be played at the standard volume.
REG OFF To listen to a regional radio
programme outside of its RDS transmission range, switch on "REG ON". For full RDS service, switch to "REG OFF".
36
SENS LO Adjusts seek tuning
sensitivity."LO" stands for local reception."DX" stands for distant reception. Select "LO 3" if you want to receive strong stations in the local area, select "DX 1" if you want to tune into weaker stations which are further away.
CLOCK 24 Switches between 12-h and
24-h clock display.
CLOCKSET Sets the clock manually.
Press << >> to select hours/minutes. Press
/
to adjust the flashing value.
TIMER Switches on a selected ra-
dio station at a selected time.
ON VOL Sets the turn-on volume.
Press << >> to adjust the turn-on volume as desired.
MUTE Changes the mute volume. BEEP Changes the volume of the
acknowledgement tone (beep) between 0 and 9. (0 = off)
RM ON Radio Monitor
If the Radio Monitor function is active during fast winding of the tape, the unit will switch to the radio and play the station listened to last.
SCANTIME Use this function to set the
scan time for the radio or cassette player from 5 to 20 seconds.
BL SKIP Switches the Blank Skip
function off and on; there must be at least 10 secon­ds of blank tape between songs.
AUX Select AUX ON if you wish
to connect a Discman or Walkman.
AUX NAME Allows you to name an ex-
ternal audio source (e.g. a discman).
DISPLAY Switches the display on or
off while the car radio is tur­ned off.
Overview of the DSC factory settings
LOUDNESS 3 BAS CENT 50 Hz TA VOL 40 REG OFF SENS DX1 CLOCK CLOCK 24 CLOCKSET TIMER OFF ON VOL 20 MUTE 10 BEEP 3 RM ON SCANTIME 10 seconds BL SKIP ON AUX OFF DISP OFF
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
37
PORTUGUÊS
Specifications
Amplifier
Output power: 4 x 25 W RMS power
acc. to DIN 45324 at
14.4 V 4 x 40 W max. power
Tuner
Wavebands: FM : 87.5 - 108 MHz MW : 531 - 1602 kHz LW : 153 - 279 kHz
(Coburg RCR 168 without MW, LW)
FM frequency response: 35 - 16000 Hz
Cassette
Frequency response: 30 - 18000 Hz
.
Subject to modification!
38
Blaupunkt-Werke GmbH
Bosch Gruppe
3/98 Mg/MS K7/VKD 8 622 401 762(H)
Loading...
