Blaupunkt MP71 User Manual
Operating instructions
Radio / CD
Los Angeles MP71
Open here
2
ENGLISH
FRANÇAIS
ESPAÑOL
2
1
3
4
5
6
PORTUGUÊS
NEDERLANDS
14
13
12
11
10
9
8
7
SVENSKA
ESPAÑOL
PORTUGUÊS
3
OPERATING ELEMENTS
1 button for opening the control unit
2 Button for switching the device on and
off and for muting the device
3 Volume control
4 Softkeys. The function of the Softkeys
depends on the contents of the display at the time
5 OK button for confirming menu entries
and for leaving the menu
6 DEQ button for calling up the equaliz-
er menu
7 Multi-function rocker
8 MENU button, which calls up the bas-
ic settings menu
9 AUD button for adjusting bass, treble,
balance, fader and loudness
: DIS button, to change the contents of
the display
; Display
< CD button, to start playing the CD
= CDC button, to start play from the CD
changer (only if connected) or
play from an external audio source
(only if connected)
> TUNE button, to begin radio operation
Calling up the radio function menu
(only possible when the radio is
switched on)
4
CONTENTS
Notes ............................................... 6
Road safety ............................................. 6
Fitting ...................................................... 6
Accessories............................................. 6
KeyCard Theft Protection .............. 7
Switching on and off...................... 9
Adjusting the volume................... 10
Tone and volume .......................... 11
Adjusting the bass................................. 11
Adjusting the treble ............................... 11
Loudness............................................... 11
Adjusting the left/right volume balance . 11
Adjusting the front/rear volume ratio
(fader).................................................... 11
Adjusting the display................... 12
Radio Operation ........................... 13
Switching to Radio Mode ...................... 13
RDS Function........................................ 13
Tuner Alternative ................................... 13
Select Waveband/Memory Level .......... 13
Setting the station ................................. 14
Setting station search sensitivity ........... 14
Saving a station..................................... 14
Saving a station automatically
(Travelstore).......................................... 14
Going to a pre-set station...................... 14
Scanning through stations .................... 15
Setting sample duration (Scantime) ...... 15
Programme type (PTY) ......................... 15
Optimising radio reception .................... 16
Switching between stereo and mono .... 17
Changing information displayed............ 17
Setting the tuner.................................... 17
CD operation................................. 18
Starting CD operation and inserting
the CD ................................................... 18
Removing the CD.................................. 18
Selecting a track.................................... 18
Fast searching (audible)........................ 19
Random Track Replay (MIX)................. 19
Scanning tracks (SCAN) ....................... 19
Repeating tracks (REPEAT).................. 19
Changing the display contents .............. 19
MP3 mode ..................................... 20
Preparing the MP3 CD .......................... 20
Switching to MP3 mode ........................ 21
Selecting a directory.............................. 21
Selecting tracks..................................... 21
Fast searching (audible)........................ 21
Random track play (MIX) ...................... 21
Scanning tracks (SCAN) ....................... 22
Repeating individual tracks or
whole directories (REPEAT).................. 22
Setting the display................................. 22
Setting scrolling text .............................. 22
CD changer operation (optional) 23
Starting CD changer operation.............. 23
Selecting a CD ...................................... 23
Selecting a track.................................... 23
Fast searching (audible)........................ 23
Changing the display contents .............. 24
Repeat play of individual tracks
or whole CDs (REPEAT)....................... 24
Playing tracks in random sequence (MIX)
Sampling all tracks on all CDs (SCAN) . 24
24
CLOCK - Time ............................... 25
Equalizer ....................................... 26
External audio sources................ 29
Pre-amplifier / subout .................. 29
Technical data .............................. 30
Guarantee ..................................... 30
Installation instructions............. 112
ENGLISH
FRANÇAIS
ESPAÑOL
PORTUGUÊS
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
5
NOTES
Notes
Thank you for deciding to use a Blaupunkt
product. We hope you enjoy using this new
piece of equipment.
Before using the device for the first time,
please read these operating instructions. The
Blaupunkt editors are constantly working on
making the operating instructions clearer and
easier to understand. However, if you still
have any questions on how to operate the
unit please contact your dealer or the telephone hotline for your country. You will find
the hotline telephone numbers printed at the
back of this booklet.
Road safety
Road safety has the first priority. Only
make adjustments to your car radio when
the traffic conditions allow . Familiarise yourself with the device before you start driving.
You must be able to hear audible alarms
from police vehicles, fire engines or ambulances promptly when inside the vehicle. Y ou must therefore listen at an appropriate volume when travelling.
Fitting
If you want to fit your car radio yourself, read
the fitting and connecting notes at the end of
the guide.
Accessories
Only use accessories approved by Blaupunkt.
Remote control
The optional RC 10, RC 10 H, and RC 08
remote controls allow you to control your car
radio’s basic functions safely and conveniently.
Amplifier
Any Blaupunkt amplifier can be used.
CD changer
The following Blaupunkt CD changers can be
connected:
CDC A 06, CDC A 08, CDC A 072 and IDC
A 09.
If an adapter cable is used (Blaupunkt No.
7 607 889 093) the CDC A 05 or CDC A 071
CD changers can also be connected.
Microdrive™ player
As an alternative to a CD changer, you can
also connect a Compact Drive MP3 player in
order to access additional MP3 tracks. In the
case of the Compact Drive MP3, you first use
a computer to store the MP3 tracks on the
Microdrive™ hard disk of the Compact Drive
MP3, and then, when the Compact Drive MP3
is connected to the car radio, you can play
the tracks like normal CD tracks.
6
THEFT PROTECTION
KeyCard Theft Protection
Two KeyCards are included with your car radio.
If one KeyCard is lost or damaged you can
obtain a replacement through your Blaupunkt
dealer.
If you use two KeyCards, the settings of the
first KeyCard are adopted by the first KeyCard. You can, however, store the following
functions separately:
station button allocation, bass, treble, balance
and fader settings, loudness, beep volume
and equalizer settings.
In addition to this, the most recent settings
for waveband, station, RDS,scan time, search
sensitivity, initial volume and SHARX are
stored.
This means that the basic settings you have
selected are made as soon as the KeyCard
is inserted.
Inserting the KeyCard
➮ Press the button 1.
The control unit opens.
➮ Insert the KeyCard, as shown in the di-
agram (arrow 1), with the contact surfaces downwards.
2
3
➮ Gently push the KeyCard with the hold-
er in the direction of the arrow (2) until
you feel it stop.
➮ Close the control unit (arrow 3).
1
Note:
If the wrong kind of card, such as a credit card,
is inserted into the device, “Wrong KC” will
appear on the display.
Remove the incorrect card, and insert a KeyCard that is known to the device.
Removing the KeyCard
To unlock the control unit:
➮ Press the button 1.
The control unit opens.
➮ Push the card with the holder to the
right until you feel it stop.
➮ Remove the card from the control unit.
➮ Close the control unit.
Note:
In order to prevent theft, remove the KeyCard
whenever you leave the vehicle, and leave the
control unit opened.
For reasons of safety the control unit
must always be closed when the vehicle is
moving.
Replacing KeyCards / “Training”
a second KeyCard
Note:
A maximum of two KeyCards can be used
per device.
If you already have two KeyCards for the device and you “train” a third KeyCard, the device can no longer be operated with the KeyCard not involved in the training process.
To “train” a new KeyCard in case of loss or
damage:
➮ Insert the first KeyCard and switch the
device on.
➮ Press the MENU button 8.
➮ Press the or button 7 until
“LEARN KC” appears in the display .
ENGLISH
FRANÇAIS
ESPAÑOL
PORTUGUÊS
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
7
THEFT PROTECTION
➮ Press the button 7.
“CHANGE” appears in the display.
➮ Remove the first KeyCard.
➮ Insert the new KeyCard.
“LEARN OK” appears in the display .
To leave the menu:
➮ Press the MENU button 8.
The radio can now be operated with the new
KeyCard.
KeyCard lost or damaged
If all the KeyCards belonging to a device are
damaged or lost, a new KeyCard will have to
be “retrained” with the device’s master code.
You will find this code in the device’s Car Radio Passport.
Keep your Car Radio Passport in a
safe place, but never in the car itself.
The instructions for this are in the section on
“T raining a new KeyCard / Entering the master code”.
Using this KeyCard, you can then “train” a
second KeyCard. Please read the section on
“Replacing / T raining KeyCards”.
New KeyCards can be obtained from your
dealer.
Training a new KeyCard /
Entering the master code
If you no longer have a valid KeyCard for your
device, and would like to train a new KeyCard:
➮ Insert the new , unknown KeyCard into
the device.
➮ Close the control unit.
➮ If necessary, switch the device off.
➮ Hold down the TUNE and ST1 buttons
> and 4 at the same time.
➮ Switch the device on with the main but-
ton 2.
“0000” appears in the display .
Enter the four-figure master code from the Car
Radio Passport as follows:
➮ Enter each of the numbers for the mas-
ter code using the
pressing until the desired number ap-
pears in the display .
and buttons 7
➮ To enter the next/previous digit, use the
and buttons 7.
➮ When the master code is correctly dis-
played, press the OK button 5.
If the device switches to play, the new Key-
Card has been accepted.
Visual theft protection (LED)
When the device is switched off and the KeyCard has been removed, the power button
and the CD slot illumination can be set to flash.
This is done by setting “LED” to “ON” in the
menu.
➮ Press the MENU button, 8.
➮ Press the or button 7 until either
“LED ON” or “LED OFF” appears in the
display .
➮ Press the or button 7 to switch
between the settings ON and OFF.
➮ Press the OK button 5 or the MENU
button 8 to leave the menu. The set-
tings are then saved.
8
SWITCHING ON AND OFFTHEFT PROTECTION
Display Radio Passport Data
Using the KeyCard supplied, you can view
Radio Passport data such as device name,
type number (7 6 ...) and device number in
the display .
➮ Press the MENU button 8.
➮ Press the or button 7 until “READ
KC” appears in the display.
➮ Press the button 7.
The Radio Passport data is shown on the display as scrolling text.
➮ Press the OK button 5 or the MENU
button 8 to leave the menu. The settings are then saved.
Care of the KeyCard
The KeyCard can only function properly if the
contacts are free of particles. Avoid touching
the contacts with your skin.
If necessary, clean the KeyCard contacts using a lint-free cloth dipped in alcohol.
Switching on and off
There are a number of methods for switching
the device on or off.
Switching on and off with the
button 2
➮ Press the main button 2 to switch on.
The device switches on.
➮ To switch off, hold the main button 2,
pressed for longer than two seconds.
The device switches off.
Switching on and off with the
vehicle ignition
If the device is correctly connected to the vehicle ignition, and has not been switched off
with the main button 2, it is switched on and
off along with the ignition.
You can also switch the device on when the
ignition is off.
➮ Press the main button 2.
Note:
In order to protect the vehicle battery, the
device is automatically switched off after an
hour if the vehicle ignition is off.
ENGLISH
FRANÇAIS
ESPAÑOL
PORTUGUÊS
NEDERLANDS
SVENSKA
Switching on and off with the
KeyCard
You can also switch the device on and off by
inserting and removing the KeyCard, if the
device was not previously switched off with
the main button 2. Read the chapter on
“KeyCard theft protection” for information
about inserting and removing the KeyCard.
ESPAÑOL
PORTUGUÊS
9
VOLUME
Adjusting the volume
The volume can be adjusted in steps from 0
(off) to 66 (maximum).
➮ To increase the volume, turn the volume
control to the right.
➮ To reduce the volume, turn the volume
control to the left.
Adjusting the switch-on volume
The volume level of the device when it is
switched on can be adjusted.
➮ Press the MENU button 8.
➮ Press the button 7 as often as is
necessary for “ON VOL” to appear in
the display .
➮ Adjust the switch-on volume with the
buttons 7 or with the volume con-
trol.
If you set a volume level below “1”, “LAST
VOL” will appear in the display. This means
that whatever volume was in use before the
device was switched off will be activated again
when the device is switched on.
Risk of serious injury!
If the level of switch-on volume is set to
maximum, the volume when switching on
can be very high.
If the volume was set to maximum
before switching off, and the value for the
switch-on volume is set to “LAST VOL”, the
volume when switching on can be very
high.
Either case can result in serious injury to
hearing!
➮ Press the OK button 5 or the MENU
button 8 to leave the menu. The settings are then saved.
Muting
You can reduce the level of the volume (mute)
suddenly.
➮ Press the main button 2.
“MUTE” is shown on the display.
Cancelling the mute
➮ Press the main button 2.
or
➮ Turn the volume control 3.
Muting during telephone
operation
If your car radio is connected to a mobile telephone, the radio is muted when the telephone
is taken “off the hook”. This requires the mobile telephone to be connected to the car radio as described in the fitting instructions.
Adjusting the volume for the
confirmation tone (beep)
With certain functions, if you hold a button
pressed for longer than two seconds, for instance in order to save a station frequency to
a station button, a confirmation tone, or beep,
is generated. The volume level of the beep
can be adjusted.
➮ Press the MENU button 8.
➮ Press the button 7 as often as is
necessary for “BEEP” to appear in the
display .
➮ Adjust the volume with the buttons
7 or with the volume control. “0”
means that the beep is off, while “9” is
the maximum beep volume.
➮ Press the OK button 5 or the MENU
button 8 to leave the menu. The settings are then saved.
10
Loading...
