Radio / CD
Acapulco MP52 7 642 265 310
Daytona MP53 7 643 290 310
Operating instructions
http://www.blaupunkt.com
Open here
2
DEUTSCH
ENGLISH
2
4
1
3
5
6
798
10
11
1213141516
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
3
CONTROLS
1 button - unlatches the flip/
release panel
2 Volume control
3 Button - switches the radio and
mute function on/off
4 RDS button - switches RDS con-
venience function on/off (radio
data system).
Selects variable radio texts.
5 BND button (band), source se-
lection for radio mode,
selection of FM memory levels
and the wavebands MW and L W
TS, starts the Travelstore function.
6 Display (display field)
7 DIS, change display contents
button - indicates the time on
the display
8 MENU button - selects the menu
for basic settings
9 button - opens the flip/release
panel
: Arrow-key block
; OK button - confirms menu en-
tries and starts the scan function
< DEQ+ button (digital equalizer) -
switches the equalizer on/off
= AUDIO button - adjusts bass,
treble, X-BASS, balance and
fader
> Key block 1 - 6
? TRAF button - activates the traf-
fic-information standby mode
@ SRC button - selects between
CD, MP3, CD changer/Compact
Drive MP3 (if connected) and
AUX sources
38
TABLE OF CONTENTS
Notes and accessories .......... 40
Flip/release panel .................. 41
Switching on/off .................... 42
Volume adjustment ................ 43
Radio mode ............................ 44
Setting the tuner ............................ 44
Switching to radio mode ................ 44
RDS function (AF, REG) ................ 45
Selecting the waveband/memory ... 45
Tuning into a station ....................... 45
Setting the sensitivity of the station
search mode ................................. 46
Storing stations ............................. 46
Storing stations automatically
(Travelstore) .................................. 46
Listening to preset stations ............ 46
Scanning receivable stations
(SCAN) ......................................... 47
Setting the scanning time .............. 47
Programm-Typ (PTY) ..................... 47
Optimising radio reception............. 48
Selecting radio text display ............ 49
Setting the display ......................... 49
Traffic information.................. 50
CD Mode ................................ 51
Starting CD mode ......................... 51
Selecting a track ........................... 51
Quick track selection ..................... 51
Fast search (audible) ..................... 51
Random play (MIX) ........................ 52
Scanning tracks (SCAN) ............... 52
Repeating a track (REPEAT) .......... 52
Interrupting play (PAUSE).............. 52
Changing the display ..................... 52
Traffic announcements in CD mode. 52
Naming CDs ................................. 53
Displaying CD text ......................... 53
Removing a CD ............................. 54
MP3 mode .............................. 54
Preparing the MP3-CD .................. 54
Switching to MP3 mode ................ 55
Selecting a directory...................... 55
Selecting tracks ............................ 56
Fast searching (audible) ................ 56
Random track play (MIX) ............... 56
Scanning tracks (SCAN) ............... 56
Repeating individual tracks or
whole directories (REPEAT)........... 57
Pausing playback (PAUSE)............ 57
Setting the display ......................... 57
CD changer mode .................. 58
Starting CD changer mode ............ 58
Selecting a CD.............................. 58
Selecting a track ........................... 58
Fast search (audible) ..................... 58
Changing the display ..................... 58
Repeating individual tracks or
whole CDs (REPEAT).................... 58
Random play (MIX) ........................ 58
Scanning all tracks on all CDs
(SCAN) ......................................... 59
Interrupting Play (PAUSE) ............. 59
Naming CDs ................................. 59
CLOCK - Time ........................ 60
Tone and volume balance ...... 61
Equalizer for Acapulco MP52 . 63
Equalizer for Daytona MP53 .. 66
External audio sources .......... 69
TMC for dynamic navigation
systems .................................. 69
Technical data ........................ 70
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
39
NOTES AND ACCESSORIES
Notes and accessories
Thank you for deciding to use a Blaupunkt product. We hope you enjoy using this new piece of equipment.
Please read these operating instructions before using the equipment for
the first time.
The Blaupunkt editors are constantly
working on making the operating instructions clearer and easier to understand. However, if you still have any
questions on how to operate the equipment, please contact your dealer or the
telephone hotline for your country. You
will find the telephone numbers printed
at the back of this booklet.
We provide a manufacturer guarantee
for our products bought within the European Union. You can view the guarantee conditions at www.blaupunkt.com
or ask for them directly at:
Blaupunkt GmbH
Hotline
Robert Bosch Str. 200
D-31 139 Hildesheim
Road safety
Road safety has priority . Only operate your car radio if road and traffic conditions allow. Familiarise yourself with the unit before setting off on
your journey.
You should always be able to hear
police, fire and ambulance sirens in
good time. For this reason, set the
volume of your car radio at a suitable level.
Installation
If you would like to install your car radio
yourself, please read the installation and
connection instructions at the end of the
manual.
Accessories
Please use only Blaupunkt-approved
accessories.
Remote controls
The most important functions of your car
radio can be selected safely and conveniently from the steering wheel using
the remote controls RC 08, RC 10 or
RC 10H (available as an optional extra).
The radio cannot be switched on/off via
remote control.
Amplifiers
All Blaupunkt amplifiers are suitable for
use with the radio.
Calibration microphone
You can use the calibration microphone
(available as an accessory) for the
equalizer’s automatic sound calibration
feature.
CD changer
The following Blaupunkt CD changers
can be connected to the radio:
CDC A 02, CDC A 08 and IDC A 09.
Compact Drive MP3
As an alternative to a CD changer, you
can connect a Compact Drive MP3 to
access MP3 music tracks. If you connect a Compact Drive MP3, you will first
need to use a computer to store the MP3
40
NOTES AND ACCESSORIES FLIP/RELEASE PANEL
music tracks on the Microdrive™ hard
disk inside the Compact Drive MP3.
Then, when the Compact Drive MP3 is
connected to the car radio, you can play
the tracks like normal CD music tracks.
The Compact Drive MP3 is operated in
the same way as a CD changer. Most
of the CD changer functions can also
be used with the Compact Drive MP3.
Amplifier / sub-out
The car radio provides connections for
connecting external amplifiers and a
subwoofer.
We recommend you use well-matched
products from the Blaupunkt or Velocity
product ranges.
Interface for vehicle-specific display
and steering-wheel remote control
Some vehicles are already fitted at the
factory with a display in the dashboard
and a steering-wheel remote control.
There are specific interfaces available
for various vehicle types so that you can
use the remote control and the display
for the car radio.
You can find out for which vehicles such
an interface is available from your Blaupunkt dealer or from the Blaupunkt telephone hotline.
Flip/release panel
Theft protection
Your car radio is fitted with a flip/release
panel to guard against theft. Without this
panel, the unit is worthless to the thief.
Protect your unit from theft by taking the
flip/release panel with you every time
you leave the car. Do not leave the panel
behind in the car, even if it is out of sight.
The constructive design of the panel
makes for simple handling.
Note:
● Do not drop the flip/release panel.
● Do not expose the flip/release pan-
el to direct sunshine or other sources of heat.
● Keep the flip/release panel in the
case provided.
● Avoid touching the contacts of the
flip/release panel. Please clean it
when necessary with some white
spirit on a lint-free cloth.
Removing the flip/release panel
1
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
41
PORTUGUÊS
DANSK
FLIP/RELEASE PANEL SWITCHING ON/OFF
➮ Press the button 1.
This unlatches the flip/release panel.
➮ First pull the flip/release panel
straight and then to the left out of
the unit.
● After removing the flip/release pan-
el, the unit switches itself off.
● All the current settings are saved.
● If there is a CD in the unit, it re-
mains there.
Attaching the flip/release panel
➮ Slide the flip/release panel from left
to right into the unit guide.
➮ Press the left side of the panel into
the unit until it slots into place.
Note:
● Do not press against the display
while attaching the flip/release panel.
If the device was still switched on when
you removed the control panel, it will
automatically switch on again with the
last settings activated (i.e. radio, CD, CD
changer/Compact Drive MP3 or AUX)
when the panel is replaced.
Switching on/off
There are various ways of switching the
car radio on and off, as described below.
Switching on/off using the ignition
If the car radio is correctly connected to
the ignition and has not been switched
off using the button 3, it is switched
on/off simultaneously with the ignition.
You can also switch on your car radio
when the vehicle ignition is off.
➮ To do so, press the button 3.
Note:
To protect the vehicle battery, the unit
switches off automatically after one
hour.
Switching on/off using the flip/
release panel
➮ Remove the flip/release panel.
The unit switches itself off.
➮ Replace the flip/release panel once
more.
The car radio is switched on. The last
settings (radio, CD, CD changer/Compact Drive MP3 or AUX) are activated.
Switching on/off using the button
3
➮ To switch the unit on, press the but-
ton 3.
➮ To switch the unit off, hold the but-
ton 3 down for more than two
seconds.
The car radio is now switched off.
42
VOLUME ADJUSTMENT
Volume adjustment
The system volume can be adjusted in
steps from 0 (off) to 66 (maximum).
➮ To raise the system volume, turn
the volume control 2 to the right.
➮ To lower the system volume, turn
the volume control 2 to the left.
Setting the switch-on volume
You can set the volume at which you
wish the car radio to play when switched
on.
➮ Press the MENU button 8.
➮ Press the or button : repeat-
edly until “ON VOLUME” appears
on the display.
➮ Use the buttons : to set the
switch-on volume.
If you select “LAST VOL”, the volume
played before the unit was last switched
off will be reactivated.
Note:
● To protect your hearing, the maxi-
mum switch-on volume under the
“LAST VOL” setting is “38”. If the
volume was higher before the unit
was switched off and “LAST VOL”
has been selected, the volume will
be set at “38” the next time the radio is switched on.
When you have completed setting the
volume,
➮ press the MENU button 8 or OK
;.
Mute setting
This feature enables you to lower the
system volume instantaneously (mute).
➮ Briefly press button 3.
“MUTE” appears on the display.
Telephone Audio/Navigation
Audio
If your car radio is connected to a mobile telephone or a navigation system,
the volume will be muted as soon as
you “pick up” the telephone or the radio
relays voice output from the navigation
system and the conversation or voice
output is heard through the radio's loudspeakers. In order for this to work, the
mobile telephone or navigation system
has to be connected to the car radio as
described in the instructions. For this,
you need adapter cable Blaupunkt no.
7 607 001 503.
To find out which navigation systems are
compatible with your car radio, please
consult your Blaupunkt dealer.
If a traffic announcement is received
during a telephone call or navigationsystem voice output, the traffic announcement will not be heard until the
conversation/voice output is over.
The volume at which telephone conversations and voice output from the navigation system are switched on is adjustable.
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “TEL/NA VI VOL” appears on
the display .
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
43
VOLUME ADJUSTMENT RADIO MODE
➮ Use the buttons : to set the
desired volume.
➮ When you have completed the set-
tings, press either the MENU button 8 or OK ;.
Note:
You can adjust the volume for telephone
conversations and voice output while
they are being heard by using the volume control 2.
Automatic Sound
This function adjusts the volume of your
car radio automatically to your driving
speed. This requires your device to be
connected as described in the installation guide.
The automatic volume booster can be
set in six stages (0-5).
➮ Press the MENU button 8.
➮ Press the button : until “AUTO
SOUND” appears in the display .
➮ Set the volume adjustment with the
buttons :.
➮ When the setting process is com-
plete, press the MENU button 8
or OK ;.
Note:
The right speed-adjusted volume setting depends on noise levels inside your
car. Try various values (0-5) until you
find the best setting.
Radio mode
This unit is equipped with an RDS radio
receiver. Many of the receivable FM stations transmit a signal that not only carries the programme but also additional
information such as the station name
and programme type (PTY).
The station name appears on the display as soon as it is received.
Setting the tuner
In order to guarantee the perfect functioning of the radio element, the unit
must be set for the region in which you
are located. You can choose between
Europe (EUROPE) and America (N
AMERICA). The tuner comes from the
factory set for the region in which the
unit was sold. Should you encounter
problems with radio reception, please
check this setting.
This set of instructions refers to the “EUROPE” setting.
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “TUNER AREA” appears on
the display .
➮ Press the or
longer than two seconds to switch
between “EUROPE” and “N
AMERICA”.
➮ Press the MENU button 8 or OK
;.
button : for
44
Switching to radio mode
If you are in CD, CD changer/Compact
Drive MP3 or AUX mode:
➮ press the BND/TS button 5.
RADIO MODE
RDS function (AF, REG)
The RDS functions AF (Alternative Frequency) and REG (Regional) extend
your radio's range of functions.
● AF: If this RDS function is activat-
ed, the unit automatically tunes into
the best receivable frequency for
the station that is currently set.
● REG: Some radio stations set
aside some of their broadcasting
time for regional programmes that
provide different regional content.
With the REG function, your car radio is prevented from switching to
alternative frequencies with a different regional content.
Note:
REG has to be specially activated/deactivated in the unit's menu.
Switching REG function on/off
To use the RDS functions AF and REG,
➮ press the MENU button 8.
➮ Press the button : repeatedly
until “REG” appears on the display .
“OFF” or “ON” will be displayed
alongside “REG”.
➮ To switch REG on or off, press the
or button :.
➮ Press the MENU button 8 or OK
;.
Switching the RDS convenience
function on/off
➮ To use the RDS functions AF and
REG, press the RDS button 4.
The RDS convenience functions are
active when RDS lights up on the display with a symbol. When the RDS convenience functions are activated, “REG
ON” or “REG OFF” appears briefly on
the display.
Selecting the waveband/
memory
This unit can receive programmes
broadcast over the FM as well as MW
and LW (AM) waveband. There are
three preset memory levels for the FM
range and one each for the MW and
LW ranges. Six stations can be stored
on each memory level.
➮ In order to switch between memory
levels or wavebands, briefly press
the BND/TS button 5.
Tuning into a station
There are various methods available for
tuning into a station.
Automatic station search mode
➮ Press the or button :.
The unit tunes into the next receivable
station.
Tuning into stations manually
You can also tune into stations manually .
➮ Press either the or
Note:
You can only tune into stations manually if the RDS function has first been deactivated.
buttons :.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
45
RADIO MODE
Browsing through broadcasting
networks (only FM)
If a radio station provides several programmes, you have the option of browsing through its so-called “broadcasting
network”.
➮ Press the or
move to the next station on the
broadcasting network.
Note:
If you want to use this feature, the RDS
function must first be activated.
You will then only be able to switch to
stations that you have received once
already . T o do so, use the Scan or T ravelstore function.
button : to
Setting the sensitivity of the
station search mode
You can choose whether you wish to
preset only strong or also poor-reception stations.
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “SENS” appears on the display.
“SENS 6” denotes maximum sensitivity. “SENS 1” is the minimum.
➮ Use the buttons : to set the
desired degree of sensitivity .
➮ When you have completed the set-
tings, press the MENU button 8
or the OK buttons ;.
Storing stations
Storing stations manually
➮ Select the required FM memory
level, FM1, FM2, FMT or either
waveband MW or L W.
➮ Tune into the desired station.
➮ Hold down one of the preset sta-
tion buttons 1 - 6 > on which you
wish to store the station for more
than two seconds.
Storing stations automatically
(Travelstore)
You can store the six stations with the
strongest reception in the region automatically (only FM). The stations are
stored in the FMT memory.
Note:
Stations that were previously stored in
this memory are deleted in the process.
➮ Hold down the BND / TS button 5
for more than two seconds.
The automatic station-storing procedure
begins. “TRA VEL-STORE” appears on
the display. Once the process is completed, the station stored in FMT memory location 1 is played.
Listening to preset stations
➮ Select the memory or frequency
range.
➮ Hold down the preset station but-
ton 1 - 6 > of the desired station.
46
RADIO MODE
Scanning receivable stations
(SCAN)
You can briefly listen in to all receivable
stations. The scanning time can be set
in the menu at between 5 and 30 seconds.
Starting SCAN
➮ Hold down the OK button ; for
more than two seconds.
The scanning process begins. “SCAN”
appears briefly on the display, followed
by the current station name or frequency, which flashes.
Ending SCAN, continuing to listen
to a station
➮ Press the OK button ;.
The scanning process is completed, the
station last scanned remains active.
Setting the scanning time
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “SCANTIME” appears on the
display.
➮ Use the buttons : to set the
desired scanning time.
➮ Once the setting has been com-
pleted, press the MENU button 8
or OK ;.
Note:
The set scantime also applies to scanning in CD mode but not to scanning in
CD changer mode.
Programm-Typ (PTY)
Besides transmitting the station name,
some FM stations also provide information on the type of programme they are
currently broadcasting. This information
can be received and displayed by your
car radio.
For example, the programme types can
be:
CUL TURE TRAVEL JAZZ
SPORT NEWS POP
ROCK CLASSICS
You can use the PTY function to select
stations of a particular programme type.
PTY-EON
Once the programme type has been
selected and the search started, the unit
switches from the current station to one
of the selected programme type.
Note:
● If no station corresponding to the
selected programme type is found,
a beep sounds and “NO PTY” appears briefly on the display . The
unit then tunes in automatically to
the station last received.
● If the set station or a different sta-
tion in the broadcasting network
should broadcast the desired programme type at a later time, the
unit will automatically switch from
the current station, or from CD or
CD changer mode, to the station
broadcasting the desired programme type.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
47
DANSK
RADIO MODE
Switching PTY on/off
➮ Press the MENU button 8.
➮ Press the or button : repeat-
edly until “PTY ON” or “PTY OFF”
appears on the display .
➮ Press the or
switch PTY on (ON) or off (OFF).
When PTY is activated, PTY lights up
on the display.
button : to
➮ Press the MENU button 8 or OK
;.
Selecting programme type and
starting a search
➮ Press the or
The current programme type appears
on the display.
button :.
➮ If you would like to select a differ-
ent programme type, you can
switch to a different programme
type by pressing the
: within the time the programme
is displayed.
Or
or button
➮ Press one of the buttons 1 - 6 >
to select the programme type
stored on that particular button.
The selected programme appears briefly on the display .
➮ Press the or button : to start
the search.
The next station corresponding to your
selected programme type will then be
set.
Storing the programme type on the
preset station buttons
➮ Use the or
a programme type.
button : to select
➮ Hold down the desired preset sta-
tion button 1 - 6 > for more than
two seconds.
The programme type is now stored on
the selected preset station button 1 - 6
>.
Optimising radio reception
High-frequency cut-off feature
(HICUT)
The HiCut function improves the sound
during poor radio reception (only FM).
If interference occurs, the treble is automatically reduced and thus also the
interference level.
Switching HiCut on/off
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “HICUT” appears on the display.
➮ Use the or
HICUT.
“HICUT 0” denotes no treble reduction,
“HICUT 3” the greatest automatic reduction of the treble and the interference
level.
button : to select
➮ Press the MENU button 8 or OK
;.
48
RADIO MODE
Interference-related waveband
change (SHARX)
With the SHARX function you can eliminate interference from neighbouring
stations almost completely (FM). Activate the SHARX function in an area of
high transmitter density.
Switching SHARX on/off
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “SHARX” appears on the display.
➮ Use the or
button : to switch
SHARX on or off.
“SHARX OFF” denotes no automatic
waveband change, “SHARX ON” that
the SHARX feature is activated.
➮ Press the MENU button 8 or OK
;.
Selecting radio text display
Some radio stations use the RDS signal to broadcast advertising or other information instead of their station name.
Such “radio texts” appear on the display.
You can deactivate the “radio texts” display for stations that you have stored
on the station buttons.
➮ Press the RDS button 4 until
“NAME FIX” appears on the display.
➮ In order to reactivate the display of
“radio texts”, hold down the RDS
button 4 until “NAME VAR” appears on the display.
Note:
If you tune into an already stored station using a different means (e.g. using
SCAN or by searching), the “radio texts”
will be displayed.
Setting the display
In radio mode you can choose between
the continuous display of the time or the
continuous display of the station name/
frequency .
➮ Hold down the DIS button 7
until the desired feature appears on
the display .
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
49
DANSK
TRAFFIC INFORMATION
Traffic information
Your car radio is equipped with an RDSEON reception system. EON stands for
Enhanced Other Network.
When a traffic announcement (TA) is
broadcast, your unit will automatically
switch, within a broadcasting network,
from a station which does not transmit
traffic information to one that does.
The unit reverts to the programme previously listened to when the traffic announcement is over.
Switching traffic information
priority on/off
➮ Press the TRAF button ?.
Priority for traffic announcements is activated when the traffic-jam symbol lights
up on the display .
Note:
You will hear a warning tone,
● if you leave the reception area of a
traffic information station to which
you are currently tuned in;
● if you leave the reception area of a
traffic information station when you
are listening to a CD and the subsequent automatic search cannot
locate a new traffic information station;
● if you retune the radio from a traffic
information station to one that does
not broadcast traffic information.
Either deactivate the priority for traffic
information or switch to a station which
broadcasts traffic information.
Setting the traffic
announcement volume
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “TA VOLUME” appears on the
display.
➮ Use the or
desired volume.
button : to set the
➮ Once the setting is completed,
press the MENU button 8 or OK
;.
Note:
You can also adjust the volume during
a traffic announcement for its duration
by using the volume control 2.
Note:
You can also adjust the tone and volume balance for traffic announcements.
Please see the “Tone and V olume Balance” section.
50
CD MODE
CD Mode
You can use this device for playing
standard CDs, CD-Rs and CD-RWs
with a diameter of 12 cm. Besides playing CDs containing audio data on this
device, you can also play CDs containing MP3 files. For further details, please
read the chapter entitled “MP3 mode”
that follows this chapter.
To ensure the system functions properly , only use CDs labelled with the compact disc logo. Problems might be experienced when trying to play copy-protected CDs. Blaupunkt cannot guarantee the proper functioning of copy-protected CDs!
Risk of damage to CD drive!
Single CDs with a diameter of 8 cm
and CDs which are not circular
(“shape CDs”) should not be used.
We accept no liability for any damage to the CD drive that may occur
as a result of the use of unsuitable
CDs.
Starting CD mode
● If there is no CD in the drive,
➮ Press the button 9.
The flip/release panel opens.
➮ Gently insert the CD into the CD
compartment with the printed side
uppermost until you feel some resistance.
The CD will be drawn into the drive.
Do not hinder or assist the drive as it
draws the CD in.
➮ Close the panel using light pres-
sure until you feel it latch into place.
CD playback begins.
● If there is already a CD in the drive,
➮ press the SRC button @ repeated-
ly until “CD” appears on the display.
Playback begins from the point at which
it was last interrupted.
Selecting a track
➮ Press one of the buttons on the ar-
row block : to select the next or
previous track.
or button : is pressed once,
If the
the current track is played again from
the beginning.
Quick track selection
To quickly select tracks backwards or
forwards,
➮ keep one of the buttons :
pressed until fast reverse / forward
track selection begins.
Fast search (audible)
For a fast search backwards or forwards
➮ keep the buttons : pressed
until the fast search backwards or
forwards begins.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
51
CD MODE
Random play (MIX)
➮ Press the button 5 MIX >.
“MIX CD” appears briefly on the display ,
the MIX symbol lights up. The next track
played will be randomly selected.
Stopping MIX
➮ Press the button 5 MIX > once
again.
“MIX OFF” appears briefly on the display , the MIX symbol goes out.
Scanning tracks (SCAN)
You can briefly listen in to all the tracks
on a CD.
➮ Hold down the OK button ; for
more than two seconds. The next
track starts to play.
Note:
The scanning time is adjustable. Read
about setting the scanning time in the
section “Setting the scanning time” in
the chapter “Radio mode”.
Stopping SCAN and continuing
playback
➮ Press the OK button ; to end
scanning.
The current track will then continue to
play .
Repeating a track (REPEAT)
➮ If you would like to repeat a track,
press button 4 RPT >.
“REPEA T TRCK” appears briefly on the
display , the RPT symbol lights up. The
track is then repeated until RPT is deactivated.
Stopping REPEAT
➮ If you would like to end repeat,
press the button 4 RPT > once
again.
“REPEAT OFF” appears briefly on the
display , the RPT symbol goes out. Normal playback is resumed.
Interrupting play (PAUSE)
➮ Press the button 1 >.
“PAUSE” appears on the display.
Ending Pause
➮ Press the button 1 > during the
pause.
Play then resumes.
Changing the display
➮ To alter the display between track
number and time or track number
and playing time or track number
and CD name, press the DIS
button once or several times for
more than two seconds until the
desired elements appear on the
display.
7
Traffic announcements in CD
mode
➮ If you want to receive traffic an-
nouncements whilst listening to a
CD, press the TRAF ? button.
Traffic announcement priority is active
when the traffic-jam symbol lights up on
the display. Please see the chapter
“Traffic information”.
52
CD MODE
Naming CDs
To make it easier for you to recognise
your CDs, the car radio offers an individual name option for 30 CDs. The
names should have a maximum of eight
digits. If you attempt to allocate more
than 30 names, “FULL” will appear on
the display .
Entering/altering CD names
➮ Listen to the desired CD.
➮ Press the MENU button 8.
➮ Use the buttons : to select
“CD NAME”.
➮ Press the or
You are now in the edit mode. If the CD
you have selected is still unnamed, eight
underlines appear on the display .
The current input position flashes.
button : twice.
➮ Use the buttons : to select
your characters. If a position is left
blank, you have selected the underline.
➮ Use the or
ceed to your next input position.
button : to pro-
➮ Press the MENU button 8 or OK
; to save the name entered.
Clearing a CD name
➮ Listen to the CD whose name you
wish to clear.
➮ Press the MENU button 8.
➮ Use the buttons : to select
“CD NAME”.
➮ Press the or
button :.
➮ Hold down the MENU button 8. A
beep sounds at the end of four
seconds and “DELETE NAME” appears on the display .
➮ Release the MENU button 8.
The CD name is now deleted.
➮ Press the OK button ; to return to
the menu.
Displaying CD text
Some CDs feature so-called CD text.
The CD text may include the name of
the performer, the album and the track
name.
You can have the CD text displayed as
running text at every change of track.
After the CD text has been displayed
once, the standard display is used.
Please see the section “Changing the
display”. If the CD in the player contains
no CD text, “NO TEXT” will appear on
the display when the CD text function is
activated.
Switching CD text on/off
➮ Press the MENU button 8.
➮ Press the button : repeatedly
until “CD TEXT” appears on the
display.
➮ Switch on the CD text function by
pressing the buttons :
(“CD TEXT ON”) or off (“CD TEXT
OFF”).
➮ When you have completed the set-
ting procedure, press the MENU
button 8 or OK ;.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
53
CD MODE MP3 MODE
Note:
CD texts are displayed with a maximum
length of 20 characters.
Removing a CD
➮ Press the button 9.
The flip/release panel opens to the front
and the CD is ejected.
➮ Carefully remove the CD and close
the flip/release panel.
MP3 mode
You can also use this car radio for playing CD-Rs and CD-RWs containing
MP3 music files.
MP3 is a process developed by the
Fraunhofer Institute for compressing CD
audio data. Compression allows data to
be reduced to around 10% of their original size without a noticeable loss in
quality (at a bit rate of 128 Kbit/s). If a
lower bit rate is used to convert CD audio data to MP3, you can create smaller files but there will be a loss in quality .
Preparing the MP3-CD
The various combinations of CD burners, CD burning software and CD blanks
may lead to problems arising with the
ability to play certain CDs. If problems
occur with your own burned CDs, you
should try another brand of CD blank or
choose another blank colour. Best results are achieved with CD blanks that
provide 74 minutes of playing time.
The format of the CD must be ISO 9660
Level 1 / Level 2 or Joliet. Other formats
cannot be played reliably .
Avoid multi-sessions. If you write more
than one session to the CD, only the
first session will be detected.
You can create a maximum of 255 directories on a CD. Each of these directories can be accessed using this device.
Each directory can in turn contain up to
255 tracks and subdirectories that can
also be accessed. A maximum of 8 levels of directories are allowed.
54
D01
D02
D03
T001
T002
T003
T004
T005
T001
T002
T003
T004
T005
T006
D04
T001
T002
T003
T004
T005
T006
T007
T008
T009
T010
T011
Each directory can be named using a
PC. The directory name can be displayed in the device’s display . Name the
directories and tracks using your CD
burner software. The software’s operating instructions will provide details on
how to do this.
Note:
● When naming directories and
tracks you should avoid using special characters. Use a maximum of
32 characters for track names and
directory names.
If you like your files to be in the correct
order, you should use burner software
that places files in alphanumerical order. If your software does not provide
this feature, you can also sort the files
MP3 MODE
manually . To do so, you should place a
number (e.g. “001”, “002”, etc.) in front
of each file name - the leading zeros
must also be included.
MP3 tracks can contain addition information such as the artist, track and album names (ID3 tags). This device can
display ID3 tags if they are version 1.
When creating (encoding) MP3 files
from audio files, you should use bit rates
up to a maximum of 256 kB/sec.
Only MP3 files with the “.MP3” file extension can be played on this device.
Note:
To ensure uninterrupted playback,
● do not attempt to change the file
extension to “.MP3” of any files other than MP3 files and then attempt
to play them!
● Do not use “mixed” CDs containing
both non-MP3 data and MP3
tracks.
● Do not use mix-mode CDs contain-
ing both audio tracks and MP3
tracks.
Switching to MP3 mode
MP3 mode is activated in the same way
as normal CD mode. For further details,
please read the section entitled “Switching to CD mode / Inserting a CD” in the
“CD mode” chapter.
Selecting a directory
To move up or down to another directory ,
➮ press the or button : once or
several times.
55
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
MP3 MODE
Note:
● Any directories not containing MP3
files will be skipped automatically .
If, for instance, you are listening to
tracks in directory D01 and you select the next directory by pressing
or button :, directory
the
D02 (which does not contain any
MP3 tracks) will be skipped and
D03 will be played. The display will
then automatically switch from
“D02” to “D03”.
Selecting tracks
To move up or down to another track in
the current directory,
➮ press the or button : once or
several times.
If you press the
current track will be played again from
the beginning.
button : once, the
Fast searching (audible)
To fast search backwards or forwards,
➮ keep one of the or button :
pressed until fast searching backwards / forwards begins.
Random track play (MIX)
To play the tracks in the current directory in random order,
➮ briefly press button 5 MIX >.
“MIX DIR” appears in the display and
the MIX symbol lights up.
To play all the tracks on the inserted
MP3-CD in random order,
➮ briefly press button 5 MIX >
again.
“MIX CD” appears in the display and the
MIX symbol lights up. All the tracks in
the current directory are played randomly. After that, all the tracks in the next
directory are played randomly .
Cancelling MIX
To cancel MIX,
➮ keep pressing button 5 MIX > un-
til “MIX OFF” appears in the display
and the MIX symbol disappears.
Scanning tracks (SCAN)
You can briefly play all the tracks on the
CD.
➮ Press the OK button ; for longer
than two seconds. The next track
will then be played briefly .
“SCAN” appears in the display. The
tracks on the CD are briefly played in
ascending order.
Note:
● You can set the scanning time
(scantime). For further details on
setting the scantime, please read
the section entitled “Setting the
scantime” in the “Radio mode”
chapter.
Stopping SCAN and continuing
playback
➮ Briefly press the OK button ;.
The currently scanned track will then
continue to be played normally .
56
MP3 MODE
Repeating individual tracks or
whole directories (REPEAT)
To play the current track repeatedly,
➮ briefly press button 4 RPT >.
“REPEAT TRCK” appears briefly in the
display and RPT lights up.
To repeat the whole directory,
➮ keep pressing button 4 RPT > un-
til “REPEAT DIR” appears briefly in
the display .
Cancelling REPEAT
To stop the current track or current directory from being repeated,
➮ keep pressing button 4 RPT > un-
til “REPEAT OFF” appears briefly
in the display and RPT disappears.
Pausing playback (PAUSE)
➮ Press button 1 >.
“PAUSE” appears in the display.
Cancelling pause
➮ Press button 1 > while in
pause mode.
Playback is resumed.
Setting the display
You can display various information on
the current track:
● File name
● Directory name
● Track name (only if the ID3 tag is
present)
● Album name (only if the ID3 tag is
present)
● Artist name (only if the ID3 tag is
present)
● Clock time
The above information (except for clock
time) is displayed once as scrolling text
in the display when the track is changed.
To switch between the different displays,
➮ repeatedly press the DIS button
> for longer than two seconds until the required information appears
in the display.
Briefly displaying the directory and
clock time
You can briefly display the directory
number and the clock time.
➮ Briefly press the DIS button >.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
57
ESPAÑOL
PORTUGUÊS
DANSK
CD CHANGER MODE
CD changer mode
Note:
Information on handling CDs, inserting
CDs and operating the CD changer can
be found in the operating instructions
accompanying your CD changer.
Starting CD changer mode
➮ Press the SRC button @ repeat-
edly until “CHANGER” appears on
the display .
Playback begins with the first CD the
CD changer recognises.
Selecting a CD
➮ To change up or down to a different
CD, press the or button :
once or several times.
Selecting a track
➮ To move up/down from one track to
another on the current CD,
press the
several times.
Fast search (audible)
For a fast search backwards or forwards
➮ keep the buttons : pressed
until the fast search backwards or
forwards begins.
or button : once or
Changing the display
➮ To alter the display between track
number and playing time or track
number and time or track number
and CD number or track number
and CD name, press the DIS
button once or several times for
more than two seconds until the
desired elements appear on the
display.
7
Repeating individual tracks or
whole CDs (REPEAT)
➮ To repeat the current track, press
the button 4 RPT > briefly.
“REPEA T TRCK” appears briefly on the
display and RPT lights up.
➮ To repeat play of the entire CD,
press the button 4 RPT > once
again.
“REPEAT DISC” appears briefly on the
display and RPT lights up.
Stopping REPEAT
➮ To stop the repeat function for the
current track or CD,
press the button 4 RPT > repeatedly until “REPEAT OFF” appears
briefly on the display and RPT
goes out.
58
Random play (MIX)
➮ To play the tracks on the current
CD in random order, press the button 5 MIX >.
“MIX CD” appears briefly on the display
and MIX lights up.
CD CHANGER MODE
➮ To play the tracks of all the inserted
CDs in random order, press the
button 5 MIX > once again.
“MIX ALL” appears briefly on the display and MIX lights up.
Stopping MIX
➮ Press the button 5 MIX > until
“MIX OFF” appears briefly on the
display and MIX goes out.
Scanning all tracks on all CDs
(SCAN)
➮ To listen in briefly to all the tracks
on all inserted CDs in ascending
order, hold down the OK button ;
for more than two seconds.
“SCAN” appears on the display .
Stopping SCAN
➮ To stop scanning, press the OK
button ; briefly.
The track currently being scanned then
continues play.
Interrupting Play (PAUSE)
➮ Press the button 1 >.
“PAUSE” appears on the display .
Ending Pause
➮ Press the button 1 > during the
pause.
Play then resumes.
Naming CDs
To make it easier for you to recognise
your CDs, the car radio offers an individual name option for 99 CDs. The
names should have a maximum of seven digits.
If you attempt to allocate more than 99
names, “FULL” will appear on the display.
Entering/altering CD names
➮ Press the MENU button 8.
➮ Use the buttons : to select
“CDC NAME”.
➮ Press the or
button :.
The name of the CD appears on the
display.
➮ Press the or
button :.
You are now in the edit mode. If the CD
you have selected is still unnamed, seven underlines appear on the display .
The current input position flashes.
➮ Use the buttons : to select
your characters. If a position is left
blank, you have selected the underline.
➮ Use the or
button : to pro-
ceed to your next input position.
➮ Press the MENU button 8 or OK
; to save the name entered.
Clearing a CD name
➮ Listen to the CD whose name you
wish to clear.
➮ Press the MENU button 8.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
59
CD CHANGER MODE
CLOCK - TIME
➮ Use the buttons : to select
“CDC NAME”.
➮ Press the or
button :.
➮ Hold down the MENU button 8. A
beep sounds at the end of four
seconds and “DELETE NAME” appears on the display.
➮ Release the MENU button 8.
The CD name is now deleted.
➮ Press the OK button ; to return to
the menu.
Clearing all CD names
All CD names saved are deleted.
➮ Listen to a CD.
➮ Press the MENU button 8.
➮ Use the buttons : to select
“CDC NAME”.
➮ Press the or
button :.
➮ Hold down the MENU button 8.
A beep sounds at the end of four
seconds and “DELETE NAME” appears on the display.
Continue to hold down the MENU
button 8 until a second beep
sounds and “DELETE ALL” appears on the display.
➮ Release the MENU button 8.
All CD names in the CD changer are
now deleted.
➮ Press the OK button ; to return to
the menu.
CLOCK - Time
Briefly displaying the time
➮ Press the DIS 7 button briefly
to display the time.
Setting the time
The time can be set automatically using the RDS signal. If you are unable to
receive an RDS station or the station
you are listening to does not support this
function, it is also possible for you to set
the clock manually .
Setting the time automatically
➮ To set the time automatically , press
the MENU button 8.
➮ Press the button : repeatedly
until “CLK MANUAL” (manual) or
“CLK AUTO” (automatic) appears
on the display.
➮ Press the button : until “CLK
AUTO” appears on the display.
➮ Press the MENU button 8 or OK
; once you have completed the
setting.
As soon as a station with the RDS time
function (RDS-CT) is received, the clock
is set automatically .
Setting the time manually
➮ To set the time manually , press the
MENU button 8.
➮ Press the button : repeatedly
until “CLOCKSET” appears on the
display .
➮ Press the button :.
60
CLOCK - TIME TONE AND
VOLUME BALANCE
The time appears on the display. The
minutes flash and can now be set.
➮ Set the minutes using the but-
tons :.
➮ Once the minutes have been set,
press the button :. The hours
now flash.
➮ Set the hours using the but-
tons :.
➮ Press the MENU button 8 or OK
; once you have completed the
setting.
Selecting the 12/24-hour clock
mode
➮ Press the MENU button 8.
“MENU” appears on the display .
➮ Press the button : repeatedly
until “24 H MODE” or “12 H MODE”
appears on the display.
➮ Press the buttons : to switch
between the 12 and 24-hour mode.
➮ Press the MENU button 8 or OK
; once you have completed the
setting.
Tone and volume balance
You can alter the tone setting individually for each source (radio, CD, CD
changer/Compact Drive MP3, AUX and
traffic announcements).
Note:
Adjustments to the sound setting for traffic announcements can only be performed during a traffic announcement.
Adjusting the bass
➮ Press the AUDIO = button.
“BASS” appears on the display .
➮ Press the or button : to set
the bass.
➮ Press the AUDIO button = or OK
; once you have completed the
setting.
Adjusting the treble
➮ Press the AUDIO = button.
“BASS” appears on the display.
➮ Press the button : repeatedly
until “TREBLE” appears on the display.
➮ Press the or button : to set
the treble.
➮ Press the AUDIO button = or OK
; once you have completed the
setting.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
61
DANSK
TONE AND VOLUME BALANCE
Setting the X-BASS
X-BASS means that the bass is raised
to a comfortable level at lower volume
levels. Y ou can adjust the X-BASS function individually for all audio sources.
When X-BASS is activated, the X-BASS
symbol lights up on the display .
➮ Press the AUDIO button =.
“BASS” appears on the display .
➮ Press the button : repeatedly
until “X-BASS” appears on the display.
➮ Press the or button : to se-
lect X-BASS.
“XBASS 0” means that X-BASS is
switched off.
➮ After completing the setting, press
the AUDIO button = or OK ;.
Setting the volume distribution
left/right (balance)
➮ To set the volume distribution left/
right (balance), press the AUDIO
= button.
“BASS” appears on the display .
➮ Press the button : repeatedly
until “BALANCE” appears on the
display .
➮ Press the or button : to set
the volume distribution left/right.
➮ Press the AUDIO button = or OK
; once you have completed the
setting.
Setting the volume distribution
front/rear (fader)
➮ To set the volume distribution front/
rear (fader), press the AUDIO =
button.
“BASS” appears on the display .
➮ Press the button : repeatedly
until “FADER” appears on the display.
➮ Press the or button : to set
the volume distribution front/rear.
➮ Press the AUDIO button = or OK
; once you have completed the
setting.
62
EQUALIZER (ACAPULCO MP52)
Equalizer for Acapulco MP52
This unit is equipped with an automatic
digital sound calibration feature. It provides you with three self-calibrating 5band equalizers.
The USER1 - USER3 equalizers can
be calibrated automatically with the help
of a special calibration microphone. Y ou
can obtain this microphone from your
Blaupunkt dealer.
The automatically ascertained values
can also be adjusted manually. If you
want to adjust the equalizer manually,
please read the section entitled “Adjusting the digital equalizer”.
In addition, the unit is equipped with
sound presets.
Switching the equalizer on/off
To activate the equalizer,
➮ keep the DEQ+ button < pressed
until DEQ lights up in the display
and “EQ ON” is displayed briefly.
To deactivate the equalizer,
➮ keep the DEQ+ button < pressed
until DEQ disappears from the display and “EQ OFF” is displayed
briefly .
Automatic sound calibration
You can electronically calibrate and
store values for three different situations
or users, e.g.:
USER 1 for the driver only
USER 2 for the driver and front
passenger
USER 3 for the front and rear
occupants
Hold the microphone in the appropriate
position whilst calibration is taking place.
The microphone position for situation 1
(e.g. for the driver alone) is at the height
of the driver’s head.
For situation 2, the microphone is between the driver and passenger.
For Situation 3, it is in the middle of the
vehicle interior (left/right, front/back).
Really quiet surroundings are required
for the calibration. Any extraneous noise
will distort the measured values.
Note:
The sound radiating from the loudspeakers must not be obstructed by any
objects. All the loudspeakers must be
connected. The microphone must be
connected to the unit.
To calibrate an equalizer,
➮ place the microphone in the re-
quired position in the vehicle.
➮ Press the DEQ+ button <.
➮ Select “AUTO” using the or
button :.
➮ Use the or button : to select
“USER 1”, “USER 2” or “USER 3”.
➮ Start the calibration process using
the or button :.
“ADJUSTING” appears in the display
during the calibration process. Calibration takes around one minute.
If an error occurs during calibration or
the microphone is not connected properly, “NO MICRO” appears in the display and the process is cancelled.
63
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
EQUALIZER (ACAPULCO MP52)
Cancelling automatic calibration
If you want to cancel automatic calibration,
➮ briefly press the DEQ+ < or OK
; button.
Adjusting the digital equalizer
Besides the automatic sound calibration, you can also manually adjust a
parametric 5-band equalizer.
In this case, parametric means that one
frequency can be boosted or reduced
(GAIN +8 to -8) individually for each of
the five bands.
The following bands are available:
● SUB LOW EQ 32 - 50 Hz
● LOW EQ 63 - 250 Hz
● MID EQ 315 - 1,250 Hz
● MID/HIGH EQ 1,600 - 6,300 Hz
● HIGH EQ 8,000 - 12,500 Hz
These bands can be set without the
need for measuring equipment. They
will allow you to significantly influence
the sound characteristics in your vehicle.
Notes on adjusting the settings
We recommend you use a CD that you
are familiar with for making changes to
the settings.
Before adjusting the equalizer, set the
sound and volume distribution settings
to zero and deactivate loudness. For
further details, refer to the chapter entitled “Tone and volume balance”.
➮ Listen to the CD.
➮ What kind of impression does the
sound make?
➮ Now read the “Sound impression”
column in the table entitled “Help
adjusting the equalizer”.
➮ Adjust the equalizer values as de-
scribed in the “Measures” column.
Adjusting the equalizer
➮ Press the DEQ+ button <.
➮ Press the or button : to se-
lect “DIGITAL EQ”.
➮ Use the or button : to select
“USER EQ1”, “USER EQ2” or
“USER EQ3” equalizer that you
want to adjust.
➮ Press the or button : to se-
lect the filter.
➮ Press the or button :.
➮ Press the or button : to se-
lect the frequency.
➮ Adjust the level using the or
button :.
➮ To select the next filter, first press
the OK button ; and then the
or button :.
➮ When you have finished making all
your adjustments, press the DEQ+
button <.
64
EQUALIZER (ACAPULCO MP52)
Selecting sound presets
You can also select sound presets for
the following styles of music.
● CLASSIC
● POP
● JAZZ
● ROCK
● TECHNO
● SPEECH
The settings for these music styles have
already been programmed.
➮ Press the DEQ+ button <.
➮ Keep pressing the or button
: until “SND PRESETS” appears
in the display.
➮ Press the or button : to se-
lect the required sound preset.
➮ Press the DEQ+ < or OK ; but-
ton.
Setting the level indicator
The level indicator (spectrometer) on
your display briefly indicates the volume,
tone and equalizer settings with symbols on your display as you make the
corresponding settings.
When settings are not being made, the
spectrometer indicates the original level of the car radio.
You can also set the type of spectrometer on your menu.
There are two types available.
Selecting a spectrometer type
➮ Press the MENU button 8.
“MENU” appears on the display .
➮ Press the button : repeatedly
until “EQ DISPLA Y” appears on the
display.
➮ Press the or
button :, to select between displaying “SPECTRUM 1” and “SPECTRUM 2” or
“EQ DISP OFF”.
➮ Press the MENU button 8 or OK
; once you have completed the
setting.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
65
ESPAÑOL
PORTUGUÊS
DANSK
EQUALIZER (DAYTONA MP53)
Equalizer for Daytona MP53
This car radio is fitted with three parametric digital equalizers, which can be
set individually. This means you have
the means to save and request different equalizer settings for different situations (eg only driver, driver and front
passenger or vehicle occupants in front
and back).
“Parametric” means that for each of the
five filters, one frequency can be individually raised or lowered (GAIN +8 to
-8). The following filters are available:
● SUB LOW EQ 32 - 50 Hz
● LOW EQ 63 - 250 Hz
● MID EQ 315 - 1250 Hz
● MID/HIGH EQ 1600 - 6300 Hz
● HIGH EQ 8000 - 12500 Hz
These filters can be set without measuring equipment. This means that the
sound quality inside the vehicle can be
greatly influenced.
Presets for different musical styles (SND
PRESETS) can also be selected.
Notes on adjusting the equalizer
We recommend you use a CD you are
familiar with when adjusting the equalizer.
Before adjusting the equalizer, set the
tone and volume balance to zero. T o do
this, please see the chapter “Tone and
volume balance”.
➮ Listen to the CD.
➮ Evaluate the tone impression ac-
cording to your taste.
➮ Now consult the chart “An aid to
adjusting the equalizer” in the
“Sound impression” section.
➮ Set the equalizer values as de-
scribed under “What to do”.
Switching the equalizer on/off
➮ To switch on the equalizer, hold
down the DEQ button < until EQ
lights up on the display “EQ ON” is
briefly displayed.
➮ To switch on the equalizer, hold
down the DEQ button < until EQ
disappears from the display “EQ
OFF” is briefly displayed.
66
EQUALIZER (DAYTONA MP53)
Setting the equalizer
➮ Press the DEQ button <.
➮ Select “DIGIT AL EQ” using the
or button :.
➮ Select the equalizer “USER EQ1”,
“USER EQ2” or “USER EQ3”,
which you would like to set by
pressing the
or the button :.
➮ Select the filter using the or
button :.
➮ Press the or
button :.
➮ To select the frequency , press the
or button :.
➮ Set the level using the or
but-
ton :.
➮ To select the next filter, first press
the OK button ;, then the or
button :.
➮ When all the settings have been
selected, press the DEQ button
<.
Selecting sound presets
Sound presets can also be selected for
the following music styles
● CLASSIC
● POP
● JAZZ
● ROCK
● TECHNO
● SPEECH
Settings for these musical styles have
already been programmed.
➮ Press the DEQ button <.
➮ Press the or button : repeat-
edly until “SND PRESETS” appears on the display.
➮ Select the desired musical style by
pressing the or button :.
➮ Press the DEQ button < or OK
;.
Setting the level indicator
The level indicator (spectrometer) on
your display briefly indicates the volume,
tone and equalizer settings with symbols on your display as you make the
corresponding settings.
When settings are not being made, the
spectrometer indicates the original level of the car radio.
You can also set the type of spectrometer on your menu.
There are two types available.
Selecting a spectrometer type
➮ Press the MENU button 8.
“MENU” appears on the display .
➮ Press the button : repeatedly
until “EQ DISPLA Y” appears on the
display.
➮ Press the or
button :, to select between displaying “SPECTRUM 1” and “SPECTRUM 2” or
“EQ DISP OFF”.
➮ Press the MENU button 8 or OK
; once you have completed the
setting.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
67
EQUALIZER (ACAPULCO MP52 / DAYTONA MP53)
Setting aid for the equalizer
Commence settings at mid and treble section and complete them in the bass
section.
Sound impression/problem
What to do
Bass reproduction too weak
Impure bass
Booming
Disagreeable pressure
Sound very dominant,
aggressive, no stereo effect
Muffled reproduction
Low transparency
No instrumental brilliance
Raise bass with
frequency: 50 to 100 Hz,
level: +4 to +6
Reduce lower mid-section with
frequency: 125 to 400 Hz,
level: approx. -4
Reduce mid-section with
frequency: 1,000 to 2,500 Hz,
level: -4 to -6
Raise tweeter range with
frequency: approx. 12,600 Hz,
level: +2 up to +4
68
TMCEXTERNAL AUDIO SOURCES
External audio sources
In addition to the CD changer, you can
also connect up a different external audio source with a line output. Such
sources can be, for example, portable
CD players, minidisc players or MP3
players.
If there is no CD changer connected to
your unit, two external audio sources
can be hooked up.
The AUX output has to be switched on
in the install menu.
To connect up an external audio source,
you will need an adapter cable, obtainable from any authorised Blaupunkt
dealer.
Switching the AUX input on/off
➮ Press the MENU button 8.
“MENU” appears on the display .
➮ Press the button : repeatedly
until “AUX-IN-1 OFF” or “AUX-IN-1
ON” appears on the display.
For the second AUX input, a “2” will be
displayed instead of a “1”. If a CD changer is connected, only input “2” will be
available.
➮ Press the or
switch AUX on or off.
➮ Press the MENU button 8 or OK
; once you have completed the
setting.
Note:
When the AUX input is switched on, it
can be selected using the SRC button
@.
button : to
TMC for dynamic navigation
systems
TMC denotes “Traffic Message Channel”. Traffic announcements are transmitted digitally via TMC and can therefore be used by suitable navigation systems for route planning. Your car radio
has one TMC output for connection to
Blaupunkt navigation systems. Your
Blaupunkt dealer will tell you which navigation systems can be used with your
car radio.
When a navigation system is connected and a TMC station received, “TMC”
lights up on the display.
When the dynamic navigation system
is activated, the radio automatically
tunes into a TMC station.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
69
TECHNICAL DATA
Technical data
Amplifier
Output power: 4 x 26 watts sine
in accordance
with DIN 45 324 at
14.4V,
4 x 50 watts max.
power
Tuner
Frequency ranges:
FM : 87.5 - 108 MHz
MW : 531 - 1 602 kHz
LW : 153 - 279 kHz
FM transmission range:
20 - 16 000 Hz
CD
Transmission range:
15 - 20 000 Hz
Pre-amp output
4 channels: 4 V
Input sensitivity:
AUX 1 input : 2 V / 6 kΩ
AUX 2 input : 775 mV / 10 kΩ
Tel/Navi reception : 10 V / 560 Ω
Subject to changes!
70
Service-Nummern / Service numbers / Numéros du service aprèsvente / Numeri del servizio di assistenza / Servicenummers /
Telefonnummer för service / Números de servicio / Número de
serviço / Servicenumre
Country: Phone: Fax: WWW:
Germany (D) 0180-5000225 05121-49 4002 http://www.blaupunkt.com
Austria (A) 01-610 390 01-610 393 91
Belgium (B) 02-525 5454 02-525 5263
Denmark (DK) 44 898 360 44-898 644
Finland (FIN) 09-435 991 09-435 99236
France (F) 01-4010 7007 01-4010 7320
Great Britain (GB) 01-89583 8880 01-89583 8394
Greece (GR) 0030 210 57 85 350 0030 210 57 69 473
Ireland (IRL) 01-4149400 01-4598830
Italy (I) 02-369 6331 02-369 6464
Luxembourg (L) 40 4078 40 2085
Netherlands (NL) 023-565 6348 023-565 6331
Norway (N) 66-817 000 66-817 157
Portugal (P) 01-2185 00144 01-2185 11111
Spain (E) 902-120234 916-467952
Sweden (S) 08-7501500 08-7501810
Switzerland (CH) 01-8471644 01-8471650
Czech. Rep. (CZ) 02-6130 0441 02-6130 0514
Hungary (H) 01-333 9575 01-324 8756
Poland (PL) 0800-118922 022-8771260
Turkey (TR) 0212-3350677 0212-3460040
USA (USA) 800-2662528 708-6817188
Brasil
(Mercosur) (BR) +55-19 3745 2769 +55-19 3745 2773
Malaysia
(Asia Pacific) (MAL) +604-6382 474 +604-6413 640
Blaupunkt GmbH
10/03 CM/PSS 8 622 403 560
Loading...
