Blaupunkt COBURG DJ I, RCM 127, COBURG DJ A User Manual
Radio / Cassette / Changer
Coburg RCM 127
Casablanca RCM 127
Cannes RCM 127
Woodstock DJ I
Woodstock DJ A
Operating instructions
18
17
16
15
14
13
12
11
Coburg
Woodstock
1
8
2
3
4
2
3
6
5
11
4
7
Fernbedienung RC 06 (Option)
Remote control RC 06 (optional)
Télécommande RC 06 (en option)
Telecomando RC 06 (optional)
Afstandsbediening RC 06 (Optie)
Fjärrkontroll RC 06 (Tillval)
Mando a distancia RC 06 (opcional)
Telecomando RC 06 (opção)
9
10
Casablanca
Cannes
Woodstock
RCM 127
DJ I
RCM 127
RCM 127
DJ A
2
Contents
Quick reference ............................ 28
Important notes ............................ 33
Precautions........................................... 33
Traffic safety ......................................... 3 3
Installation.............................................33
Sound source mute .............................. 33
Accessories .......................................... 33
KeyCard theft protection system 34
Putting the unit into operation .............. 34
Removing the KeyCard ........................ 34
“Training” a second KeyCard/
Replacing a KeyCard............................ 34
Displaying the radio pass data ............. 34
Short Additional Memory (S.A.M.)........ 35
Turn On Message (T.O.M.) .................. 35
Optical indication of anti-theft
protection .............................................. 35
Care of your KeyCard........................... 35
Switching the audio source ........ 35
Radio operation with RDS ........... 36
AF - Alternative frequency.................... 36
REG - regional programme .................. 36
Selecting a waveband
(only Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A)...
Station tuning........................................ 37
Automatic tuning / ....................... 37
Manual tuning with << >>.................. 37
36
Scrolling through the broadcasting
networks................................................ 37
Changing the memory bank ................. 37
Storing stations..................................... 37
Automatically storing the strongest
stations with Travelstore....................... 38
Recalling stored stations ...................... 38
Scanning stored stations with
Preset Scan .......................................... 38
Scanning stations with Radio-Scan...... 38
Selecting the seek tuning sensitivity .... 39
Switching from stereo to mono............. 39
Loudness .............................................. 39
PTY – Programme-Type....................... 39
Switching PTY on/off......................... 39
Programme type ................................... 39
Checking the programme type of the
station ................................................ 40
Displaying the selected programme
type.................................................... 40
Selecting a programme type ............. 40
Storing programme types.................. 41
Scanning stations with PTY-SCAN... 41
PTY priority........................................ 41
Receiving traffic programme
stations with RDS-EON................ 42
Traffic announcement priority on/off .... 42
Beep tone ............................................. 4 2
Switching off the beep tone............... 42
Automatic seek tuning start .................. 42
Adjusting the volume for traffic
announcements and the beep tone...... 43
Tape operation ............................. 43
Inserting a tape..................................... 43
Removing a tape................................... 43
Fast Forward/Rewind ........................... 43
Selecting titles with CPS ...................... 43
Switching the tape side (autoreverse).. 44
Tape equalisation ................................. 44
Scanning cassette titles with SCAN ..... 44
Listening to the radio during
fast tape winding with RM .................... 44
Care notes ............................................ 44
CD changer operation.................. 45
Switching to the CD changer mode...... 45
Selecting CDs and titles ....................... 45
MIX playback ........................................ 45
Selecting the display mode .................. 46
SCAN .................................................... 46
DSC programming ....................... 47
Overview of DSC factory settings ........ 49
Appendix....................................... 49
Specifications........................................ 49
Blaupunkt telephone hotline ................. 49
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
27
Quick reference
1 Switching on/off with the ON button:
Press ON.
When switching the set on with the ON
button, the KeyCard has to be inserted. The unit will play with the pre-adjusted volume.
Switching on/off with the KeyCard:
The set has to be turned on with the
ON button.
Note:
Read the information in chapter
“KeyCard theft protection system”.
Switching on/off via the ignition:
When connected correspondingly, the
set can also be turned on and off with
the vehicle ignition.
After the ignition has been switched
off, a double beep tone will remind you
that you should remove the KeyCard
before leaving your vehicle.
Switching on with the ignition being
switched off:
To keep on operating the set when the
ignition is switched off (KeyCard is inserted), proceed as follows:
Press ON. The unit will be turned on.
To avoid that the battery goes flat, the
system will be turned off automatically
after one hour of playback.
2 VOL+ / VOL-
To alter the volume.
Each time the set is switched on, it will
play with the pre-adjusted volume
(VOL FIX).
You may also change the VOL FIX setting (see chapter “DSC programming”).
3
For instantly muting the volume.
By pressing the
can be muted immediately. “MUTE”
will appear in the display.
The function is cancelled by pressing
button or VOL+.
When pressing VOL-, the
volume will be adopted.
To programme the mute volume level,
proceed as follows:
• Adjust the desired volume.
• Press
hear a beep.
Now this volume level is stored as your
mute volume.
button the volume
(mute)
for 1 second until you
28
4 Rocker switch
Radio operation
/ Station search
Up
Down
<</>> Up/Down in short intervals
(on FM only if AF is off)
On FM only:
<</>> To scroll through the station net-
works when AF is on, e.g.NDR 1, 2,
3, 4, N-JOY, FFN, ANTENNE ...
Tape operation
/ Title selection (S-CPS)
Up
Down
Fast forward
Fast rewind
Stop function by pressing the opposite key.
Changer operation
Optional:
Coburg RCM 127, Casablanca
RCM 127, Cannes RCM 127
Included in scope of delivery:
Woodstock DJ I, Woodstock DJ A
CD selection
Up
Down
Title selection
Upwards: Press briefly.
CUE - fast advance (audible):
Keep depressed.
Downwards: Press as many times
as required.
To re-start a title: Press briefly.
REVIEW - fast reverse (audible):
Keep depressed.
Extra rocker switch functions:
Further setting functions with
AUD B
DSC Mode A
PTY @
Condition: The corresponding function
is activated.
5 Display
a
e
d
f
b
c
a) NDR1 NDS - Station name
b) TR 1 - Track (side) 1 of the cas-
c) 1 : 52 - Playback TIME or disc
d) FM - Waveband
e) 5 - Preset button (1-6)
f) I, II, T - Memory bank I, II or
g) lo - Seek tuning sensitivity
h) AF - Alternative frequency for
i) TP - A traffic station is being
j) TA - Priority for traffic stations
k) LD - Loudness
l) PTY - Programme type function
j
gi h
k
l
sette
NUMBER during CD
changer operation
Travelstore
RDS operation
received
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
29
PORTUGUÊS
6 KeyCard theft protection system
To operate the set it is necessary that
the KeyCard is inserted.
KeyCard
Inserting the KeyCard
With the KeyCard tongue sticking out
of the unit, introduce the KeyCard into
the slot with the contact area show-
ing up.
To remove the card, press first to unlock.
Read also the information in chapter
“KeyCard theft protection system”.
Flashing KeyCard tongue
When the radio is turned off and the
KeyCard removed, the KeyCard
tongue can be programmed to flash
for optical theft protection.
For more information see chapter
“DSC programming”.
This flashlight can be switched off by
pushing in the tongue and lock.
“WRONG KC” will briefly appear
on the display and the set will switch
off automatically.
7 FMT
(Coburg RCM 127,
Woodstock DJ I)
BND
(Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A)
For selection of the FM memory banks
I, II and T (Travelstore).
To switch over:
Press button repeatedly.
The selected memory bank will appear
in the display.
Travelstore
To store and recall the six most powerful stations with Travelstore.
To store: Press button for approximately 1 sec. until you hear a beep
and “T-STORE” appears in the display.
To recall: Select the memory bank “T”
and press the corresponding preset
button (1-6) briefly.
Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A:
Additional selection of medium- and
long-wave stations, provided that “AM
ON” has been adjusted in the DSC
menu.
8 AF
Alternative frequency during RDS op-
eration:
When “AF” lights up in the display, the
system will automatically seek a frequency offering better reception of the
same RDS programme.
AF on/off: Press AF briefly.
Regional function on/off:
Press the AF button for approximately
1 sec. until you hear a beep. “REGON” or “REG-OFF” will appear in the
display (see chapter REG - regional
programme).
9 TA (priority for traffic announcements)
When “TA” lights up in the display, the
system will play traffic stations only.
Priority on/off: Press TA.
: 1, 2, 3, 4, 5, 6 - preset buttons
You can store six stations for each of
the memory banks I, II and T.
To store a station: Press a preset
button during radio operation and hold
down until the set resumes play after
the muting and you hear a beep.
To recall a station: Select the desired
memory bank and press the relevant
preset button briefly.
30
Extra function of preset buttons
To store and recall a PTY programme
type.
When PTY is active (“PTY” lights up in
the display), you can store and recall
one programme type on/from each
preset button on FM.
; SRC (Source)
You can switch between the radio,
tape and CD changer operating
modes, provided that a cassette/CD is
inserted.
< lo
To switch the seek tuning sensitivity
level:
Press button briefly.
If “lo” is displayed, the radio will only
pick up strong, local stations (normal
sensitivity).
If “lo” does not light up, the radio will
also pick up weaker, distant stations
(high sensitivity).
Extra function of lo button:
To switch between mono and stereo
reception:
Press button for approximately 1 sec.
(beep).
The selected condition will be briefly
displayed.
/
=
To switch the tape side: Press briefly.
To eject the tape: Press for approximately 1 sec.
Extra function /
Frequency display during radio operation:
Press button briefly.
The frequency will be briefly displayed.
> Cassette loading slot
Insert the tape with side A or 1 facing
up, the open side showing to the right.
? SC
Radio operation
Scan
Press SC briefly.
The scanned frequency or the station
name will start flashing in the display.
During the actual scanning process
“FM-SCAN” or “AM-SCAN” will be displayed. The unit will scan all FM stations which can be received.
Preset Scan
Press SC for approximately 1 sec. until
you hear a beep.
“SCAN” and the name or frequency of
the scanned station will alternately appear in the display.
The unit will scan all stations stored on
the preset buttons.
To stop Scan / Preset Scan:
Press SC once again.
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
31
ESPAÑOL
PORTUGUÊS
Tape operation
Cassetten-Scan
Press SC.
“CC-SCAN” will appear in the display.
All cassette titles will be scanned briefly.
To stop cassette scan:
Press SC once again.
Changer operation
CD-Scan
Press SC briefly.
“CDC-SCAN” will appear in the display.
All CD titles will be scanned briefly.
To stop CD-Scan:
Press SC once again.
@ PTY (Programme Type)
In the PTY mode, the preset buttons
become programme type buttons. With
every preset you can select one programme type, such as for example
NEWS, SPORT, POP MUSIC, EDUCATE, etc.
A DSC (Direct Software Control)
Use the DSC function to customise
certain programmable, basic settings
to suit your personal needs and preferences. See chapter “DSC programming” for more information.
B AUD
To adjust the treble, bass, balance and
fader.
If the display shows “TRE” or “BAS”,
you can adjust the reproduction of the
treble and bass frequencies with the
rocker switch. If “BAL” or “FAD” is displayed, you can set the balance (left/
right) and fader (front/rear).
Press AUD as many times as required
and make the setting using the rocker
switch.
Treble + / Fader front
Treble – / Fader rear
The last setting will be stored automatically.
To switch off AUD: Press button once
again.
If the setting remains unchanged within 8 seconds, the display will switch
back to the previous condition.
Extra function AUD
Loudness - When listening at a low
level, the Loudness function creates a
more natural sound by boosting
the low frequency range.
Loudness on/off: Press AUD for approximately 1 sec.
“LD” lights up in the display if the
Loudness function is switched on.
Please refer to chapter “DSC programming” for more information on how to
program the Loudness boost.
32
Bass – / Balance left
Bass + / Balance right
Loading...
