Blaupunkt BPV650, BVP655 User Manual
BPV 655/BPV 650
CD MAN
FMlll
AMll
X-BASS
TRETRE
lo
LOUDLOUD
Issue date 06-02
288F0462
High-Power FM/AM/CD Receiver with Detachable Face
ENGLISH
Autoradio FM/AM à Lecteur CD de Forte Puissance et à Face Amovible
Receptor FM/AM/Reproductor de CD de Alta Potencia y con Panel Extraíble
Rádio FM/AM/CD de Alta Potência
com Face Removível
FRANÇAIS
ESPAÑOL
Robert Bosch Corporation
Sales Group —
Blaupunkt Division
2800 South 25th Avenue,
Broadview, Illinois 60155
http://www.blaupunktUSA.com/
PORTUGUÊS
BPV655_Cover 2002.06.17, 14:321
FCC WARNING
Precautions
Handling the Front Panel
This equipment has been tested and found to comply with the
limits for a Class B device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and, if not installed and used in accordance with instructions, may cause harmful interference with
radio communications. However, there is no guarantee that
radio interference will not occur in particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to consult the
dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to
operate this equipment.
Features
• Detachable front panel
• Built-in power amplifier
BPV 655
(max. output : 55W × 4ch)
BPV 650
(max. output : 50W × 4ch)
• FM/AM PLL Synthesizer tuner
• 30 Station preset memory
• Travel Store / Scan tuning
• Avoid installing the unit where it would be subject to high
temperatures, such as in direct sunlight or a hot air stream
from the heater, or where it would be subject to dust, dirt, or
excessive vibration.
• Do not turn on the unit if the temperature inside the car is
very high. Always cool down the unit before usage. Parking
your car in direct sunlight will result in a temperature rise.
• If the unit does not turn on, check the connections first. Then
check whether the fuse at the back of the unit is blown.
• Carefully read this manual before using the unit. If you encounter any problems that are not covered in this manual,
please consult the dealer where you purchased the unit or
the dealer nearest to you.
• This unit has been designed specifically for playback of
compact discs bearing the following mark. Other discs can-
not be played.
Handling Compact Discs
• Be careful when removing a compact disk after the playback is completed because the disk may be extremely hot.
• Do not use non-conventional discs such as heart-shaped,
octangonal discs, etc. The player could be damaged.
• Do not expose compact discs to direct sunlight or any heat
source.
• Check all compact discs before playing, and discard
cracked, scratched or warped discs.
• Wipe dirty or damp discs outward from the centre with a
soft cloth.
• Do not use any solvents such as commercially available
cleaners, antistatic spray, or thinner to clean the compact
discs.
Attaching the Front Panel
Place the right hand side of the front panel so that the parts
A of the front panel are engaged with the parts B of the unit
as shown below. Then push the left hand side of the front
panel until it is securely locked.
Detaching the Front Panel
Remove the CD from the unit, if any, and turn off the power of
the unit.
Press the
the front panel as shown below and remove it from the unit.
REL
to unlock the front panel from the unit. Grasp
Security
To avoid theft or loss of the front panel, you can inactivate
the release button
1. Unscrew the bolt marked
unit. (See diagram above)
REL
by installing the screw provided.
at the left front side of the
*
2. Attach the front panel.
3. Select a locking screw from the mounting hardware (See
page 7) and screw it into the same hole to fasten the front
panel.
Notes
• Do not press hard on the front panel when affixing it to the
unit. No more than light to moderate pressure should be
needed.
• Make sure there is no dust or dirt on the electrical terminals
on the back of the front panel as this could cause intermitent
operation or other malfunctions.
ENGLISH
BPV655(EN)_body 2002.06.17, 14:331
E-1
