BLAUPUNKT
XSMART
EN USER MANUAL
FOREWORD
Congratulations! And thank you for buying a great new product from
Blaupunkt. With the Blaupunkt Bluebot XSMART robot vacuum cleaner,
you can clean most oor types with the greatest of ease.
This manual is specic to the Blaupunkt Bluebot XSMART robot vacuum
cleaner as specied in section 2.1 Intended use. Hereafter the Blaupunkt
Bluebot XSMART robot vacuum cleaner will be referred to as ‘the robot’.
This manual is intended to help the user to set up and operate the robot. It
also describes the operation of the robot with the BluebotXS Plus app and
the Alexa app. Download these apps on your smartphone for maximum
operating ease.
We kindly ask you to carefully read the information in this manual before
using the robot, to familiarise yourself with its intended use and potential
dangers and risks.
support.blaupunktrobotics.eu
+31 (0)20 894 33 15
support@blaupunktrobotics.eu
We also have a live chat feature on our website!
© 2018 Blaupunkt XSmart UM
All rights reserved. No parts of this work may be reproduced in any
form or by any means – (graphic, electronic, or mechanical, including
photocopying, recording, taping, or information storage and retrieval
systems) – without the written permission of the publisher.
Revision 03/2018
2
TABLE OF CONTENTS
EN
1. Reading guide ...........................................................................................4
2. Safety .........................................................................................................5
2.1 Intended use .......................................................................................................................5
2.2 General safety .....................................................................................................................5
2.3 Product safety .....................................................................................................................5
2.4 Electrical safety ...................................................................................................................6
2.5 Fire and explosion hazard...............................................................................................6
2.6 Maintenance ........................................................................................................................7
2.7 Transport and Storage .....................................................................................................7
2.8 Recycling and Disposal ....................................................................................................7
3. General product description ....................................................................8
3.1 Main parts.............................................................................................................................8
3.2 Dierent cleaning kits for dierent cleaning purposes .......................................9
3.3 Cleaning modes .................................................................................................................9
4. General description of the control types ............................................. 10
4.1 LED panel ........................................................................................................................... 10
4.2 Remote control ................................................................................................................11
4.3 BluebotXS Plus app ........................................................................................................ 12
4.4 Alexa App .......................................................................................................................... 13
4.5 Available functions per control type .......................................................................13
5. Getting started ....................................................................................... 14
5.1 Unpacking the box ......................................................................................................... 15
5.2 Mounting the brushes .................................................................................................. 16
5.3 Installing the suitable cleaning kit ........................................................................... 16
5.4 Installing the charging station ................................................................................... 18
5.5 Placing the magnetic strips.........................................................................................19
5.6 Charging the robot ........................................................................................................20
5.7 Placing the batteries in the remote control ..........................................................21
5.8 Setting the time .............................................................................................................. 21
5.9 Installing the BluebotXS Plus app on your mobile phone ............................... 22
5.10 Connecting the BluebotXS Plus app to your robot ............................................ 22
5.11 Installing Alexa ................................................................................................................ 23
6. Operation ............................................................................................... 24
6.1 Before running the robot .............................................................................................24
6.2 Running the robot in Auto Cleaning mode ..........................................................24
6.3 Running the robot in other cleaning modes ........................................................ 24
6.4 Sending robot to the charging station ...................................................................25
6.5 Using the Alexa voice control function ..................................................................26
7. Scheduling the robot ............................................................................. 27
7.1 Scheduling the robot with the LED panel ............................................................. 27
7.2 Scheduling the robot with the remote control ...................................................27
7.3 Scheduling the robot with the BluebotXS Plus app .......................................... 28
8. Maintenance ........................................................................................... 30
8.1 Maintenance schedule .................................................................................................30
8.2 Cleaning the side brushes ........................................................................................... 31
8.3 Cleaning the dust bin and the lters ....................................................................... 32
8.4 Cleaning the sensors and wheels ............................................................................. 33
8.5 Cleaning the charge poles...........................................................................................34
8.6 Cleaning the suction passage and the dust sensor .......................................... 34
8.7 Cleaning the normal suction nozzle ....................................................................... 35
8.8 Cleaning the brush suction nozzle ........................................................................... 35
8.9 Replacing the battery ....................................................................................................36
9. Troubleshooting .................................................................................... 37
9.1 LED panel codes .............................................................................................................. 37
9.2 BluebotXS Plus app error notication ..................................................................... 38
10. Disposal .................................................................................................. 38
11. Technical specications ......................................................................... 39
3
1. READING GUIDE
This manual includes notes and warnings on safe operation of the robot.
These notes and warnings are marked with the following signal words.
Read them carefully!
1
DANGER!
The signal word that indicates a hazard with a high level of risk which, if not
avoided, will result in death or serious injury.
1
WARNING!
The signal word that indicates a hazard with a medium level of risk which, if not
avoided, could result in death or serious injury and/or cause serious damage to the
robot.
1
CAUTION!
The signal word that indicates a hazard with a low level of risk which, if not avoided,
could result in minor or moderate injury and/or cause damage to the robot.
NOTICE
The signal word that indicates information that is considered important, although
not hazard-related (e.g. messages relating to property damage).
Table 1 - Symbols used in this manual
This manual includes instructions for all available control types. These
instructions are marked with the following symbols, each representing a
control type.
Instructions relating to operating the robot with the LED panel.
Instructions relating to operating the robot with the remote control.
Instructions relating to operating the robot with the BluebotXS Plus
app.
Instructions relating to operating the robot with the Alexa app.
Table 2 - Symbols representing the dierent control types
4
2. SAFETY
EN
This section contains safety instructions for protection from risk of personal
injury or property damage. Failure to follow these instructions shall void
any warranty.
2.1 Intended use
The Blaupunkt Bluebot XSMART robot vacuum cleaner is intended for
cleaning a wide range of ooring, such as carpet, laminate ooring, tiles
etc. The robot is not suitable for high pile carpets. On this material, the
robot can become stuck and unable to move around.
The robot can only be operated with the LED panel, the remote control, the
BluebotXS Plus app and/or via the Alexa voice control function. To use this
last function, you will need to purchase Alexa separately.
The robot is intended to be used with its original accessories only, and
is intended for domestic use only. The robot is not intended for use in
environments with high humidity, like bathroom areas.
2.2 General safety
This appliance can be used by children aged eight years and above and
•
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge, if they have been given supervision or
instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Young children and pets should be supervised to ensure that they do
•
not play with the appliance.
The robot must be used in an environment with a temperature between
•
0°C and 40°C.
Do not use the robot in a wet or moist environment (any environment
•
with liquid), e.g. bathroom area or laundry.
Do not use the product if it is defective.
•
Only use the original accessories.
•
Repairs must only be performed by Blaupunkt Robotics or its ocially
•
authorized partners.
2.3 Product safety
•
1
WARNING!
The rotating wheels and roller brush of the robot can clamp ngers. Do
•
not touch the wheels or roller brush while the robot is in operation.
A damaged or leaking battery can cause re, explosion or personal
•
injury. Never dismantle the battery case. Do not throw the battery into
re or heat the battery and do not crush or throw the battery. In the
event that battery leakage contacts your skin or clothes, immediately
wash o the leakage with clean water.
•
Before use, remove all fragile objects, cords, clothing, paper and loose
•
cables from the oor and lift curtains and drapes o the oor to avoid
any possible accidents.
Make sure the robot does not come into contact with cigarette ends,
•
lighters, matches or any ammable substance.
5
Do not place the robot on tables, chairs, etc, as damage may occur
•
should it fall o.
Do not let a curtain or any kind of wrapping material wind up in the
•
drive wheels.
Do not use the robot outdoors.
•
Do not expose the robot to sunlight.
•
Do not use a covered or wrapped robot.
•
Do not block or insert objects into the ventilation holes of the robot.
•
Do not put the robot near a heat source.
•
Do not sit on the robot and do not attach an object to the top of it.
•
2.4 Electrical safety
•
1
WARNING!
In the case of overheating during charging, stop using the robot
•
immediately. Turn OFF the power switch and remove the adapter from
the power socket.
A damaged power cord can cause electric shock, overheating or re. Do
•
not destroy or modify the power cord and do not bend it too tightly. Do
not heat the cord. Do not pull or press the inexible cord excessively
with heavy objects.
Dust on the metal terminals of the power plug can result in electric
•
shock, overheating or re. Regularly remove the dust from the power
plug and surroundings with a dry cloth.
Wet hands can conduct the electric current from the robot
•
unintentionally and cause electric shock. Do not touch the power cord,
plug or adapter with wet hands.
Charging and powering the robot with components that are not original
•
parts can cause electric shock, overheating or re. Only use the original
battery, charging base and power adapter (UK Type Adapter Model No.:
GQ12-240060-AB; EU Type Adapter Model No.: GQ15-240060-AG).
A short-circuit occurs when the positive (+) pole and the negative (-)
•
pole of the battery are connected. Short-circuits can cause heat
generation in metal objects, re or explosion. Prevent short-circuits by
keeping metal objects or conducting substances away from the battery
poles.
•
Before charging, check whether the adapter and outlet are properly
•
connected.
The adapter must use an alternating voltage of 100-240 VAC.
•
Do not use the power adapter with an AC converter.
•
2.5 Fire and explosion hazard
Do not switch the robot on within or let the robot enter a ammable
•
and/or combustible environment.
Do not use the robot to clean combustible or highly volatile substances,
•
such as gasoline.
6
EN
2.6 Maintenance
Never wash the main body or the charging device. Only the dustbin and
•
lters are washable (except HEPA lters). Do not wash other parts of this
robot. Return the dustbin and lters to the main body when dry.
Clean the outside of the robot with a soft cloth. When the robot is very
•
dirty, use a slightly damp cloth and a neutral solution.
When the dustbin is full, empty it before next use.
•
Cleaning and user maintenance should not be done by children without
•
supervision.
2.7 Transport and Storage
We recommend that you retain the original carton and packing
•
materials for transporting the robot for service. This is the only way to
safely protect the robot against damage in transit. If you do dispose of
the carton and the packing materials, please remember to recycle with
due care for the environment.
Turn o the power switch when the robot will not be used for an
•
extended period of time. Battery leakage may cause re, injury or
pollution to the environment. Cut the power source of the adapter and
disconnect the plug from the socket.
2.8 Recycling and Disposal
The battery must be insulated with tape when taken for recycling or
•
disposal. Contact with other metals could lead to heating, bursting or
re. Bring the insulated battery to a technical service centre with an
authorised reseller for disposal. Alternatively, dispose of the battery
according to local laws.
Turn o the power switch during transportation.
•
7
3. GENERAL PRODUCT DESCRIPTION
3.1 Main parts
An overview of the main parts can be found in Figure 1 and Table 3.
13
12
11
1 2 43
2×
9
4×
10
2×
No. Description
1 Blaupunkt Bluebot XSMART
robot vacuum cleaner
2 HEPA lter (is installed in part 1)
3 Dust bin with brush (is installed
in part 1)
4 Primary lter (is installed in
part 3)
5 Brush suction nozzle (is
installed in part 1)
5
6
7
8
6 Normal suction nozzle
7 Remote control + 2 batteries
8 Power adapter
9 4x Side brushes (indicated
L=left, R=right)
10 2x Magnetic strip (2 × 1 m)
11 Mopping pad
12 Water tank
13 Charging station
Figure 1 - Main parts
8
Table 3 - Main parts
EN
3.2 Dierent cleaning kits for dierent cleaning purposes
The robot comes with cleaning kits for dierent cleaning purposes.
See Table 4:
Cleaning purpose Floor type (examples) Cleaning kits
dry cleaning carpets (< 2cm) normal suction nozzle
dry cleaning laminate ooring brush suction nozzle
wet cleaning laminate ooring and tiles oors mopping kit
Table 4 - Selecting the suitable cleaning kit
See section 5.3 for instructions about installation of the correct cleaning kit.
3.3 Cleaning modes
The robot has ve Cleaning modes.
Auto Cleaning mode:
•
The robot will rst start mapping the area by cleaning the edges of the
area. When mapping is complete, the robot will start cleaning the area
by zigzag movements. When nished, the robot will return to the
charging station.
Edge Cleaning mode:
•
The robot will only clean the edges of the area. When nished, the robot
will return to the charging station.
Area Cleaning mode:
•
The robot will clean an area of 2 m² using maximum suction. Place the
robot on the desired area. When nished, the robot will stop automatically.
Random Cleaning mode:
•
The robot will clean the area by random movements. The robot is not
able to map the area. When the battery is almost empty, the robot will
return to the charging station.
Intensive Cleaning mode:
•
The robot will rst start mapping the area by cleaning the edges. When
mapping is complete, the robot will start cleaning the area by zigzag
movements. The robot will then clean the area a second time. When
nished, the robot will return to the charging station.
Sections 6.2 and 6.3 describe how to select and run the various Cleaning
modes.
9
4. GENERAL DESCRIPTION OF THE CONTROL TYPES
The robot has four control types. The robot can be operated using the:
LED panel
•
remote control
•
BluebotXS Plus app
•
Alexa app (voice control)
•
This section gives a general description of the four control types.
4.1 LED panel
Figure 2 and Table 5 describe the items on the LED panel.
1
3 4 5 6
Figure 2 - The LED panel
2
No. Description
1 Display: Shows time, date, modes and information.
2 Power:
• Press this button to switch the robot to Standby when switched o.
• Press this button to start in Auto Cleaning mode when in Standby.
• Press this button to switch the robot to Standby when cleaning.
• Press and hold this button to switch the robot o.
3 HOME:
• Press this button and the robot will start automatic charging.
• In Clock mode: Increase the time or scheduling of the clean.
4 Max Cleaning:
• Enhance the suction power.
• In Clock mode: Decrease the time or scheduling of the clean.
5 PLAN: Schedule a cleaning cycle.
6 Edge Cleaning mode: the robot will start cleaning along the walls and will
clean only edges and corners of the area.
Table 5 - Description of the LED panel
10
EN
ON/OFF
PLAN HOME
MODE CLK MAX
4.2 Remote control
Figure 3 and Table 6 describe the items on the remote control.
8
Figure 3 - The remote control
7
No. Description
1 Display: Shows time, date, modes and information.
2 HOME: Press this button and the robot will start automatic charging.
3 ON/OFF:
• Press this button to switch the robot to Standby when switched o.
• Press this button to start in Auto Cleaning mode when in Standby.
1
2
3
4
5
6
• Press this button to switch the robot to Standby when cleaning.
4 Direction buttons:
• In standby mode: move the robot forward, backward, turn left or turn
right.
• In Clock mode: increase or decrease the time and date while setting
time or scheduling.
5 Max: Enhance the suction power.
6 Clock Setting : Press this button to set the time.
7 Mode Cleaning: Switch between dierent cleaning modes
• MODE 1: Edge Cleaning mode: the robot will start cleaning along the
walls.
• MODE 2: Area Cleaning mode: the robot will start cleaning 2 m² in a
zigzag pattern. After cleaning that 2 m² area, it will stop.
• MODE 3: Random Cleaning mode: the robot will start to clean the area
randomly.
• MODE 4: Intensive Cleaning mode: the robot will clean the same area
twice (areas with less than 40 m²).
• MODE 5: the robot will stop the cleaning cycle and go to standby.
(There is no “MODE 5” displayed on the remote LCD panel).
8 PLAN: Schedule a cleaning cycle.
Table 6 - Description of the remote control items
11
4.3 BluebotXS Plus app
Figure 4 and Table 7 describe the items of the BluebotXS Plus app. For
information about how to install the BluebotXS Plus app, see section 5.9.
8
1
2
3
4
5 6 7 151413 16
Figure 4 - Home screen and Operation screen
9
10
11
12
Table 7 - Description of the BluebotXS Plus app items
17
No. Description
1 Battery level indicator.
2 Working/Standby/Charging/Charging Complete/Auto recharging/Error/
Oine: The status of the robot.
3 Start/Pause/Re-charge: Start, pause or re-charge the robot.
4 Current/Last: Cleaned area and duration of current or last cleaning activity.
Tap this area to jump to the Navigation screen directly.
5 Robot: Navigate to the Home screen of the robot.
6 Mall: Navigate to online shopping and service related to your robot.
7 Me: Displays your prole, see Figure 5. Tap the cogwheel to go to Settings.
8 Add Device/My Robot/Manual: Add a new device, open devices overview or
read the user manual.
9 Tap this area to jump to the Operation screen directly.
10 Up/Down and Turn Left/Turn Right: Control the movement of the robot
manually.
11 Start/Pause: Tap this button to start in Auto Cleaning mode when in Standby.
Press this button to switch the robot to Standby when cleaning.
12 Operation: Tap this button to change the cleaning mode.
13 Operation: Open the Operation screen of the robot, see Figure 4.
14 Schedule: Open the Schedule screen of the robot.
15 Navigation: Open the Navigation screen of the robot. The Navigation screen
displays a real-time map of the area the robot is cleaning.
16 Option: Open the Options screen of the robot. Here you can change the
name, update rmware, disable/enable voice tips, open the error list, delete
the robot and check the status and battery level.
17 Re-charge: Tap this button to send the robot back to the charging station for
re-charging.
12
Loading...
