User’s Manual
SRP-350/352plusIII
Thermal Printer
Rev. 1.03
http://www.bixolon.com
SRP-350/352plusIII
■ Safety Precautions
In using the present appliance, please keep the following safety regulations in order to prevent any hazard or material damage.
WARNING
Violating following instructions can cause serious injury or death.
Do not plug several products in one multi-outlet.
•This can provoke over-heating and a fire.
•If the plug is wet or dirty, dry or wipe it before usage.
•If the plug does not fit perfectly with the outlet, do not plug in.
•Be sure to use only standardized multi-outlets.
PROHIBITED
You must use only the supplied adapter.
• It is dangerous to use other adapters.
ONLY SUPPLIED ADAPTER
PROHIBITED
Do not pull the cable to unplug.
•This can damage the cable, which is the origin of a fire or a breakdown of the printer.
Keep the plastic bag out of children’s reach.
• If not, a child may put the bag on his head.
PROHIBITED |
PROHIBITED |
Do not plug in or unplug with your hands wet.
• You can be electrocuted.
Do not bend the cable by force or leave it under any heavy object.
• A damaged cable can cause a fire.
PROHIBITED |
PROHIBITED |
Rev. 1.03 |
- 2 - |
SRP-350/352plusIII
CAUTION
Violating following instructions can cause slight wound or damage the appliance.
If you observe a strange smoke, odor or noise from the printer, unplug it before taking following measures.
•Switch off the printer and unplug the set from the mains.
•After the disappearance of the smoke, call your dealer to repair it.
TO UNPLUG
PRINTER
Install the printer on the stable surface.
•If the printer falls down, it can be broken and you can hurt yourself.
Keep the desiccant out of children’s reach.
• If not, they may eat it.
PROHIBITED
Use only approved accessories and do not try to disassemble, repair or remodel it for yourself.
•Call your dealer when you need these services.
•Do not touch the blade of auto cutter.
PRINTER |
DISASSEMBLING |
|
PROHIBITED |
PROHIBITED |
PRINTER |
|
Do not let water or other foreign objects in the printer.
•If this happened, switch off and unplug the printer before calling your dealer.
PROHIBITED
PRINTER
Do not use the printer when it is out of order. This can cause a fire or an electrocution.
• Switch off and unplug the printer before calling your dealer.
TO UNPLUG
PRINTER
DEALER
Rev. 1.03 |
- 3 - |
SRP-350/352plusIII
■ Warning - U.S.A
i) Class A Digital Device : Wired Device
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
ii) Class B Digital Device : Wireless Device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
iii)Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment.
iv)Caution: Exposure to Radio Frequency Radiation.
To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons.
■ Notice - Canada
i) Class A Digital Device : Wired Device
This Apparatus complies with class “A” limits for radio interference as specified in the
Canadian department of communications radio interference regulations.
Get appareil est conforme aux normes class “A” d’interference radio tel que specifier par ministre canadien des communications dans les reglements d’interference radio .
ii) Class B Digital Device : Wireless Device
This Apparatus complies with class “B” limits for radio interference as specified in the Canadian department of communications radio interference regulations.
Get appareil est conforme aux normes class “B” d’interference radio tel que specifier par ministre canadien des communications dans les reglements d’interference radio .
Rev. 1.03 |
- 4 - |
SRP-350/352plusIII
■ Caution
Some semiconductor devices are easily damaged by static electricity. You should turn the printer “OFF”, before you connect or remove the cables on the rear side, in order to guard the printer against the static electricity. If the printer is damaged by the static electricity, you should turn the printer “OFF”.
■ Waste Electrical and Electric Equipment (WEEE)
This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
■ Rating Label Symbol Information
DC (Direct current)
■ Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may cause undesired operation.
■Label Material
*Control Label: PC
*Other Labels: PET
Rev. 1.03 |
- 5 - |
SRP-350/352plusIII
■ Introduction to Product
SRP-350/352plusIII series printers have been designed to be connected to various types of electronic devices such as ECR (Electronic Cash Register), POS (Point Of Sales), and computer peripheral devices.
Major features of the printer are as follows.
1.Print at a max. speed of 300mm/s(180 dpi)
2.Low noise thermal printing
3.Support of USB & Ethernet (built-in type), serial, parallel, POWERED USB, Wireless LAN, and Bluetooth interfaces
4.Built-in data buffer (data can be received and buffered while printing)
5.Control of external devices like cash registers through peripheral device drive circuit
6.Barcode
7.Support of various print density settings (by changing DIP switch settings)
It is advisable to read the contents of this manual carefully before using the printer for the first time.
Use only authorized supplies that can be trusted!
-We are not responsible for quality and service for damage caused by the use of unauthorized products (or recycled ones).
-The following Bluetooth mark and QD ID B021701 is only applicable to models with the Bluetooth SIG qualification.
We at Bixolon Co., Ltd. constantly strive to improve product functions and quality. To do this, the specifications of our product and the contents of the manual may change without prior notice.
Rev. 1.03 |
- 6 - |
SRP-350/352plusIII
■ Table of Contents
1. Installing Printer and Getting Started ........................................................................ |
8 |
|
1-1 Unpacking................................................................................................................. |
8 |
|
1-2 Interface.................................................................................................................... |
9 |
|
1-2-1 |
USB Interface ............................................................................................... |
9 |
1-2-2 |
Ethernet Interface ......................................................................................... |
9 |
1-2-3 |
Serial Interface(RS-232C) .......................................................................... |
10 |
1-2-4 |
Parallel Interface(IEEE1284) ...................................................................... |
12 |
1-2-5 Wireless LAN Interface ............................................................................... |
13 |
|
1-2-6 |
Bluetooth Interface ..................................................................................... |
13 |
1-2-7 |
Powered USB Interface .............................................................................. |
13 |
1-3 Drawer Cable.......................................................................................................... |
14 |
|
1-4 Setting Dip Switches............................................................................................... |
15 |
|
1-4-1 |
Serial Interface ........................................................................................... |
15 |
1-4-2 |
Parallel / USB / Ethernet / Wireless LAN / Powered USB Interface ............ |
15 |
1-4-3 |
Bluetooth Interface ..................................................................................... |
16 |
1-5 Installing & Replacing Paper................................................................................... |
17 |
|
1-6 Recommended Papers ........................................................................................... |
19 |
|
1-7 Structure of 2 inches specification. ......................................................................... |
19 |
|
1-8 Removing Paper Jam ............................................................................................. |
20 |
|
1-9 Adjusting Paper Near-end Sensor Setting .............................................................. |
21 |
|
1-10 Using Printer Functions ........................................................................................ |
21 |
|
1-11 Connecting a Computer........................................................................................ |
22 |
|
1-12 Connecting Power Supply .................................................................................... |
22 |
|
2. Self-Test...................................................................................................................... |
|
23 |
3. Hexadecimal Dumping .............................................................................................. |
24 |
|
4. Specifications ............................................................................................................ |
25 |
|
5. Appendix .................................................................................................................... |
|
26 |
5-1 Cleaning Printer ...................................................................................................... |
26 |
|
Rev. 1.03 |
- 7 - |
SRP-350/352plusIII
1. Installing Printer and Getting Started
1-1 Unpacking
Check the following contents list, and contact your dealer for assistance if any item is missing or incorrect.
SRP-350/352plusIII |
Cable Cover |
CD |
Paper |
Installation Guide |
AC/DC Adapter |
Power Cord |
Rev. 1.03 |
- 8 - |
