Biostar A880G PLUS, A785G3 PLUS, TA880G BIOS MANUAL

Download

A880G+/TA880G/A785G3+ BIOS Manu al

B IOS Set up.... ............ ............ ............ ............ ............ ............ ............ .........1

1 Main Menu...............................................................................................3

2 Adv anc ed Menu...... ............ ............ ............ ........................ ............ .........6

3 PCIPnP Menu........................................................................................17

4 Boot Men u..............................................................................................21

5 Chipse t Menu.........................................................................................24

6 Performance Menu...............................................................................30

7 Exit Menu...............................................................................................38

A880G+/TA880G/A785G3+ BIOS Manual

BIOS Setup

Introduction

The purpose of this manual is to describe the settings in the AMI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic

system configuration and save these settings to CMOS RAM. The power of CMOS RAM is supplied by a battery so that it retains the Setup information when the power is turned off.

Basic Input-Output System (BIOS) determines what a computer can do without accessing programs from a disk. T his system controls most of the input and output

devices such as keyboard, mouse, serial ports and disk drives. BIOS activates at the first stag e o f the booting proc ess, l oading and executing the operating syst em. S om e additional features, such as virus and password protection or chipset fine-tuning options are also included in BIOS . T he rest of this manual will to guide you through the options and settings in BIOS Setup.

Plug and Play Support

T his AMI BIOS supports the Plug and Play Version 1.0A specific ati on.

EPA Green PC Support

T his AMI BIOS supports Versi on 1. 03 of the EPA Green PC specification.

APM Support

This AMI BIOS supports Version 1.1&1.2 of the Advanced Power Management (AP M) speci fic ati on. Power m anagement fe atures are im pl ement ed via t he S yst em

Management Interrupt (SMI). Sleep and Suspend power management modes are supported. Power to the hard disk drives and video monitors can also be m anaged by

this AMI B IOS.

ACPI Support

AMI ACPI BIOS support Version 1.0/2.0 of Advanced Configuration and Power interfa ce specifi cation (ACPI). It provides ASL code for pow er management and

device configuration capabilities as defined in the ACPI specific ation, developed by Microso ft, Intel and Toshiba.

A880G+/TA880G/A785G3+ BIOS Manual

PCI Bus Support

T his AMI BIOS also supports Version 2.3 of the Intel PCI (Peripheral Component Int erconn ect ) local b u s s p eci fic atio n .

DRAM Sup port

DDR3 SDRAM (Do uble Dat a Rat e III Synch ro nous DR A M) is suppo rt ed.

Su ppor t e d CP Us

T his AMI BIOS supports the AMD C PU.

Using Setu p

When starting up the computer, press

<Del> during the Power-On Self-Test (POST) to enter the BIOS setup utility.

In the BIOS setup utility, you will see General Help description at the top right

corner, and this is providing a brief description of the selected item. Navigation Keys for that particular menu

are at the bottom right corner, and you can us e these keys to sel ect it em and ch ange the settings.

Notice

z T he default BIOS settings apply for most conditions to ensure optimum performan ce

of the motherboard. If the system becomes unstable after changing any settings, please load the default settings to ensure system’s compatibility and stability. Use

Load Setup Default under the Exi t Menu.

z For better system per form ance, the BIOS firmware is being continuously updated.

T he BIOS information described in this manual is for your re ference only. The actual BIOS i nformation and settings on board may be slightly different from this manual.

z T he content of this manual is subject to be changed without notice. We will not be

responsible for any mistakes found in this user’s manual and any system damage that may be caused by wrong-settings.

General Help

Navigati on Keys

A880G+/TA880G/A785G3+ BIOS Manual

1 Main Men u

Once you enter AMI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic sys tem information.

Main Advanced PCIPnP Boot Chipset Performance

System Overview AMI BIOS

Version :01.01.01 Build Date:01/01/10

System Memory

Size :

System Time [ :00:00]00

System Date [Fri 01/01/2010]

Floppy A > IDE/SATA Configuration

AM I BIO S

Shows s ystem information i ncluding BIOS version and built date.

BIOS SETUP UTILITY

Exit

Use [ENTER], [TAB] or [SHIFT-TAB] to

select a field. Use [+] or [-] to

configure system Time.

Select Screen Select Item Change Field

Select Field

Tab

General Help

Save and Exit

F10

Exit

ESC

System Memory

Shows s ystem m emory size, VGA shard m emory will be excluded. .

System Time

Set the system internal clock.

System Date

Set the system date. Note that the ‘Day’ automatically changes when you set the date.

Floppy A

Select the type of fl oppy disk drive installed in your system. Options: 360K, 5. 25 i n / 1.2M, 5.25 in / 720K, 3. 5 in / 1.44M, 3. 5 in /

2.88M, 3.5 in / None

A880G+/TA880G/A785G3+ BIOS Manual

IDE /SAT A C onfig uration

Th e BIOS w i ll au t o m atical ly detect t h e presen c e o f ID E / SATA d evices . Th ere i s a su b-menu fo r each IDE/ SAT A device. Select a d evice and p ress <Enter> to enter

the sub-menu of detailed options.

Main

IDE/SATA Configuration

> Primary IDE Master

> Primary IDE Slave > SATA 1 Device

> SATA 2 Device > SATA 3 Device

> SATA 4 Device

Hard Disk Write Protect [Disabled] IDE Detect Time Out (Sec) [35]

BIOS SETUP UTILITY

While entering setup, BIOS auto detects the

presence of IDE devices. This displays the status of auto

detection of IDE devices.

Select Screen Select Item Go to Sub Screen

Enter

General Help

Save and Exit

F10

Exit

ESC

Primary IDE Master/Slav e ; SATA 1/2/3/4 Device

Main

Primary IDE Master

Device :

Type [Auto]

LBA/Large Mode [Auto] Block (Multi-Sector Transfer)[Auto] PIO Mode [Auto]

DMA Mode [Auto] S.M.A.R.T [Auto]

32Bit Data Transfer [Enabled]

BIOS SETUP UTILITY

Select the type of device connected to the system.

Select Screen Select Item

Change Option

General Help

Save and Exit

F10

Exit

ESC

The BIOS detects the information and values of respective devices, and these information and values are shown below to the name of the sub-menu.

A880G+/TA880G/A785G3+ BIOS Manual

Type

Select the type of the IDE/SAT A drive. Options: Auto (De fault) / CDROM / ARMD / Not Installed

LBA/Large Mode

Enable or disable the LBA mode. Options: Auto (De fault) / Disabled

Block (Multi-Sector Transfer)

En able o r d i s ab l e m u l ti -s ect or t ran s fer. Options: Auto (De fault) / Disabled

PIO Mode

Select the P IO m ode. Options: Auto (De fault) / 0 / 1 / 2 / 3 / 4

DMA Mode

Select the DMA mode. Opti ons: Aut o (De faul t) / S WDM A0 ~ 2 / MWDM A0 ~ 2 / UDMA0 ~ 5

S.M.A.R.T

Set the Smart Monitoring, Analysi s, and Reporting Technology. Options: Auto (De fault) / Disabled / Enabled

32Bit Data Trans fer

Enable or disable 32-bit data transfer. Options: Enabled (Default) / Disabled

Har d Disk Wri te Protec t

Disable or enable device write protection. This will be effective only if the device is accessed through B IOS.

Options: Disabled (De fault) / Enabled

IDE Detect Time Out (Sec)

Select the time out value for detecting IDE/SAT A devices. Options: 35 (Default) / 30 / 25 / 20 / 15 / 10 / 5 / 0

A880G+/TA880G/A785G3+ BIOS Manual

2 Advanced Menu

T he Advanced Menu allows you t o configu re the settings of CP U, Super I/O, Power Management, and other system devices.

Notice

z Beware of that setting inappropriate values in items of this menu may cause

system to malfunction.

Main Advanced PCIPnP Boot Chipset Performance

WARNING: Setting wrong values in below sections may cause system to malfunction.

> CPU Configuration

> SuperIO Configuration > Smart Fan Configuration

> Hardware Health Configuration > Power Configuration

> USB Configuration > AUDIO Configuration > Onboard LAN Configuration

BIOS SETUP UTILITY

Configure CPU.Advanced Settings

Exit

Select Screen Select Item

Enter

Go to Sub Screen

General Help

F10

Save and Exit Exit

ESC

CPU Configuration

T his item shows the CPU information that the BIOS automatically detects.

Advanced

CPU Configuration

Module Version: AGESA Version: Physical Count: Logical Count:

AMD CPU Revision:

Cache L1: Cache L2: Cache L3: Speed : NB Clk: ncHT Speed : WidthI/O : Able to Change Freq :

uCode Patch Level :

Secure Virtual Machine Mode [Enabled]

PowerNow [Enabled] ACPI SRAT Table [Enabled] Probe Filter [Enabled]

BIOS SETUP UTILITY

Enable/Disable Secure Virtual Machine Mode (SVM)

Select Screen Select Item Change Option

General Help

Save and Exit

F10

Exit

ESC

A880G+/TA880G/A785G3+ BIOS Manual

Secur e Virt ual Ma chine Mod e

Virtualization Technology can virtually separ ate your system resource into several parts, thus enhance the performance when running virtual machines or multi interface systems.

Options: Enabled (Default) / Disabled

PowerNow

T his item allows you to enable or disable the P owerNow power saving technology. Options: Enabled (Default) / Disabled

ACPI SRAT Tabl e

Th e operat i n g sys tem scans t h e A C PI SRAT at b oot t im e an d u s es the i n fo rmat i o n t o better allocate memory and schedule software threads for maximum performance.

This item controls whether the SRAT is made available to the operating system at boot up, or not.

Options: Enabled (Default) / Disabled

Probe Filter

T his item allows you to set ini tialization mode for Probe Filter. Options: Auto (De fault) / Disabled / MP Mode

Core Per formanc e Boos t

If this item is enabled, Revision E CP U automatically transition to pop-down p-state Options: Enabled (Default) / Disabled

Advanced Clock Calibration

Advanced Clock Calibration (ACC) is an enhanced technology for overclocking, needing support from both chipset and CPU. When enabled, it will improve the stability of advanced ove rclocki ng greatly.

Options: Disabled (De fault) / Auto / All Cores / Per C ore

Core Leve ling

T his item allows you to activate Core Leveling function. Options: Auto(Default) / Force Single Core / Force Dual Core / Force Tri Core /

Enable all Cores

A880G+/TA880G/A785G3+ BIOS Manual

S uperI O Co nf i g urat io n

Advanced

Configure ITE8721 Super IO Chipset

Onboard Floppy Controller [Enabled]

Serial Port1 Address [3F8/IRQ4] Parallel Port Address [Disabled]

OnBoard CIR Port [Disabled] Keyboard PowerOn [Disabled]

Mouse PowerOn [Disabled] Restore on AC Power Loss [Power Off]

BIOS SETUP UTILITY

Allows BIOS to Enable or Disable Floppy

Controller

Select Screen Select Item

Change Option

General Help

Save and Exit

F10

Exit

ESC

Onboard Floppy Controller

Select enabled if your system has a floppy disk controller (FDC) installed on the system board and you wis h to use it. If you installed another FDC or the system uses

no floppy drive, select disabl ed in this field. Options: Enabled (Default) / Disabled

Serial Port1 Address

Select an address and corresponding i nterrupt for the first and second seri al ports. Options: 3F8/IR Q4 (Default) / 2F8/ IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Disabled

Parallel Port Address

Th i s i t em al l ows yo u to det ermine acces s onboard parall el port controller with whi ch I/O Address.

Options: Disabled (De fault) / 378 / 278 / 3BC

Parallel Port Mode

T his item allows you to determine how the parallel port should function. Options: Normal (Default) Using Parallel port as Standard Printer Port.

EPP Using Parallel Port as Enhanced Parallel Port. ECP Using Parallel port as Extended Capabilities Port.

ECP + EPP Usi ng Parallel port as ECP & EPP mode.

A880G+/TA880G/A785G3+ BIOS Manual

ECP Mode DMA Channel

T his item allows you to sel ect parallel port ECP DM A. Opti ons: DMA3 (Default ) / DM A0 / DMA1

Parallel P ort IRQ

T his item allows you to sel ect t he IRQ for the onboard parallel port. Options: IRQ7 (De fault) / IRQ5 / Disabled

OnBoard CIR Por t

T his item allows you to sel ect consum er IR port. Options: Disabled (De fault) / Enabled

CIR Port IRQ

T his item allows you to sel ect consum er IR port IRQ. Options: IRQ10 (Default) /IRQ3 / IRQ4 / IRQ11

Keyboa rd PowerOn

T his item allows you to control the keyboard power on function. Options: Disabled (De fault) / Specifi c Key / Stroke Key / Any Key

Specific Key Enter

T his item will show only when Keyboard PowerOn is set “S pecific Key.”

Stroke Keys Selected

T his item will show only when Keyboard PowerOn is set “Stroke Key.” Options: C trl+F1 (Default) / Wake Key / Power Key / Ctrl+F2 / Ctrl+F3 /

Mouse PowerOn

T his item allows you to control the mouse power on function. Options: Disabled (De fault) / Enabled

C t rl +F 4 / Ctrl + F 5 / Ct rl +F 6

A880G+/TA880G/A785G3+ BIOS Manual

Restore on AC Power Loss

T his setting specifies how your system should behave a fte r a power fail or interrupts occurs. By choosing Disabled will leave the computer in the power off state. Choosing Enabled will restore the system to the status before power failure or

interrupt occurs. Options: P ower O ff (Default) / Last State

Smart Fan Confi guration

Advanc ed

Smart Fan Confi guration

CPU Smart Fan [Disabled]

Smart Fan Calib ration Control Mode Fan Ctrl OFF( C ) Fan Ctrl On(C) Fan Ctrl Start value Fan Ctrl Sensit ive

BIOS SETUP UTILITY

When you choice [Auto] ,[3Pin] or [4Pin],

please run the calibration to define the Fan parameters for Smart Fan control

Select Screen Select Item Change Option

General Help

Save and Exit

F10

Exit

ESC

CPU Sma r t Fa n

This item a llo w s you to control the CPU Sma rt Fan func tio n. Options: Disabled (De fault) / Auto / 4Pin / 3Pin

Sm art Fan Calibr a tion

Choose this item and then the BIOS will auto test and detect the CPU/System fan fun ctions and show CPU/S ystem fan speed.

Control Mode

T his item provides several oper ation modes of the fan. Options: Quiet / Performan ce / Manual

A880G+/TA880G/A785G3+ BIOS Manual

Fan Ctrl OFF (℃)

If the C PU/System T emperature is lower than the set value, FAN will turn off. Options: 0~127 (℃) (W ith the interval of 1℃)

Fan Ctrl On(℃ )

CPU/S ystem fan starts to work under smart fan function when arrive this set value. Options: 0~127 (℃) (W ith the interval of 1℃)

Fan Ctrl S tart Va l ue

When CPU/System temperature arrives to the set value, the CPU/System fan will work under Smart F an Function mode.

Options: 0~127 (With the int erval of 1)

Fan Ctrl Sensitive

Increasi ng t h e valu e w ill rai s e t he sp eed of C P U / Sy s t em fan. Options: 1~127 (With the int erval of 1)

Hardware Health Configuration

T his item shows the system temperature, fan speed, and voltage i nformation.

Advanced

Hardware Health Configuration

H/W Health Function [Enabled]

Shutdown Temperature [Disabled]

CPU Temperature NB Temperature

SYS Temperature CPU Fan

Sytem1 Fan +12.0V

Chip Voltage +5.00V

CPU Vcore DDR Voltage HT Voltage

BIOS SETUP UTILITY

Enables Hardware Health Monitoring

Device.

Select Screen Select Item

Change Option

General Help

F10

Save and Exit

ESC

Exit

H/W Health Functio n

If with a monitoring system, the system will show PC health stat us during POST stage. Options: Enabled (Default) / Disabled

A880G+/TA880G/A785G3+ BIOS Manual

Shutdown Te m perature

T his item allows you to set up the CPU shutdown Temperature. This item is only effecti ve under W indows 98 ACPI mode. Options: Disabled (Default) / 60℃/140℉ / 6 5 ℃/149℉ / 7 0℃/158℉ / 75℃/167℉

/ 80℃/176℉ / 85℃/185℉ / 90 ℃/194℉

Power Con figuration

Advanced

ACPI Settings

Suspend mode [S1 (POS)]

ACPI Version Features [ACPI v1.0] ACPI APIC support [Enabled]

AMI OEMB table [Enabled] Headless mode [Disabled]

RTC Resume [Disabled] RTC Alarm Date(Days)

RTC Alarm USB Wakeup From S3/S4 [Disabled] Power ON by PCIE/Onboard LAN [Disabled] Wake Up by PCI [Disabled] Wakeup on Ring [Disabled]

Time

BIOS SETUP UTILITY

Select the ACPI state used for System Suspend.

Select Screen Select Item

Change Option

General Help

Save and Exit

F10

Exit

ESC

Suspe nd m ode

T he item allows you to select the suspend type under the AC P I operating system . Opt i ons : S 1 (PO S ) (Defaul t ) P ower on Suspen d

S3 (ST R) Suspend to RAM S1 & S3 POS+STR

ACPI Version Features

Th e item al l o ws yo u to sel ect t he vers i o n of ACPI. Options: ACP I v1.0 (De fault) / ACPI v2.0 / ACPI v3.0

ACPI AP I C support

This item is used to enable or disable the motherboard's APIC (Advan ced Programmable Interrupt Controller). The APIC provides multiprocessor support,

more IRQs and faster interrupt handling. Options: Enabled (Default) / Disabled

A880G+/TA880G/A785G3+ BIOS Manual

AMI OEMB tabl e

Set this value to allow the AC PI BIOS to add a pointer to an OEMB table in the Root Syst em Descripti on Table (RSDT) table. Options: Enabled (Default) / Disabled

Headless mode

This is a server-specific feature. A headless server is one that operates without a keyboard, monitor or mouse. To run in headless mode, both BIOS and operating

system (e.g. Windows Server 2003) must support headless operation. Options: Disabled (De fault) / Enabled

RTC Re sume

When “ Enabled”, you can set the date and time at which the RTC (real-time clock) alar m awaken s th e s y s tem fro m Su s p en d mo d e.

Options: Disabled (De fault) / Enabled

RTC Alar m Date (Days )

You can choose which date the system will boot up.

RTC Alarm Time

You can choose the system boot up time, input hour, mi nute and second to specify.

USB Wakeup from S3/S4

T his item allows you to enable or disabled the USB resume from S 3/S4 function. Options: Disabled (De fault) / Enabled

Power O n by PCIE/ Onboard LAN

T his item allows you control the wake on LAN (WOL) function. Options: Disabled (De fault) / Enabled

Wake Up by PCI

En able / D i s able P CI to generat e a wake ev en t . Options: Disabled (De fault) / Enabled

Wakeup on Ri ng

T his item allows you control the wake on ring function. Options: Disabled (De fault) / Enabled

A880G+/TA880G/A785G3+ BIOS Manual

USB Configuration

T his item shows the USB controller and using USB device i nformation.

Advanced

USB Configuration

Module Version - 2.24.5-13.4

USB Devices Enabled:

Legacy USB Support [Enabled]

USB 2.0 Controller Mode [HiSpeed] BIOS EHCI Hand-Off [Enabled]

Legacy USB1.1 HC Support [Enabled] > USB Mass Storage Device Configuration

BIOS SETUP UTILITY

Enables support for legacy USB. AUTO option disables

legacy support if no USB devices are connected.

Select Screen Select Item Change Option

+F1

General Help

F10

Save and Exit Exit

ESC

Legacy USB Support

T his item determines if the BIOS should provide legacy support fo r USB devices li ke the key board, mo use, and US B d rive. This is a useful fe atu re when using such USB devices with operating systems that do not natively support USB (e.g. Microso ft DOS or Windows NT). Options: Enabled (Default) / Disabled

USB 2.0 Controller Mode

T his item allows you to sel ect t he operation m ode of the USB 2.0 controller. Options: HiSpeed (De fault) USB 2.0-480M bps

FullSpeed USB 1.1-12Mbps

BIO S EHCI Hand-Off

This item allows you to enable support for operating systems without an EHCI hand-o ff feature.

Options: Enabled (Default) / Disabled

Legacy USB1.1 HC Support

T his item allows you to enable to support US B1.1 HC. Options: Enabled (Default) / Disabled

A880G+/TA880G/A785G3+ BIOS Manual

US B Ma ss St o rag e De vi ce C o n f ig urat io n

Advanced

USB Mass Storage Device Configuration

USB Mass Storage Reset Delay [20 Sec]

Device #

Emulation Type [Auto]

BIOS SETUP UTILITY

Number of seconds POST waits for the

USB mass storage device after start

unit command.

Select Screen Select Item

Change Option

General Help

Save and Exit

F10

Exit

ESC

USB Mass Storage Reset Delay

T his item allows you to set the reset delay for US B mass storage device. Op t i ons : 20 Sec (D efau l t ) / 1 0 Sec / 3 0 S ec / 40 S ec

E m ula ti o n Type

T his item allows you to sel ect t he emulation type of the USB m ass storage device. Options: Auto (De fault) / Floppy / Forced FDD / Hard Disk / CDROM

AUDI O Configur atio n

BIOS SETUP UTILITY

AUDIO Configuration

AMD 880 HD Audio [Enabled]

HD Audio Azalia Device [Enabled]

Chipset

Options

Dis

abled

Enabled

Select Screen Select Item

Update

Enter

General Help

Save and Exit

F10

Exit

ESC

A880G+/TA880G/A785G3+ BIOS Manual

AM D 880 HD Audio

T his item allows you to control AM D 880 HD audio function. Options: Enabled (Default) / Disabled

HD Audi o Azali a Dev i ce

T his item allows you to control the HD audio device. Options: Enabled (Default) / Auto / Disabled

Onboa r d LA N Configura tion

Advanced

Onboard LAN Configuration

MAC ID Information :

Realtek PCIE NIC [Enabled]

Realtek Option ROM [Disabled]

BIOS SETUP UTILITY

Enable/Disable Onboard Realtek

PCIE Network Controller

+F1 F10 ESC

Select Screen Select Item

Change Option General Help Save and Exit Exit

MAC ID Information

Th i s area s ho ws t h e M AC ID .

Realtek PCIE NI C

T his option allows you to control the onboard LAN controller. Options: Enable (Default) / Disable

Realtek Option ROM

T his item allows you to enable or disable the Onboard LAN B oot ROM. Options: Disabled (De fault) / Enabled

A880G+/TA880G/A785G3+ BIOS Manual

3 PCIPnP Menu

T his section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the

speed o f the CPU itself uses when communicating with its own special components.

Notice

z Beware of that setting inappropriate values in items of this menu may cause

system to malfunction.

Main Advan c ed PCIPnP Boot Chipset Performance

Advanced PCI/Pn P Settings WARNING: Settin g wrong values in below sections

may ca use system to malfunction.

Clear NVRAM [No]

Plug & Play O/S [No] PCI Latency Tim er [64] Allocate IRQ to PCI VGA [Yes]

Palette Snoopin g [Disabled] PCI IDE BusMast er [Enabled]

> PCI Resource > PCI Express C onfiguration

BIOS SETUP UTILITY

Clear NVRAM during System Boot.

Select Screen Select Item

Change Option

General Help

Save and Exit

F10

Exit

ESC

Exit

Clear NVRAM

T his item allows you to clear t he data in the NVRAM (CMOS) by selecting “ Yes”. Options: No (Default) / Yes

Plug & Play OS

When set to YES, BIOS will only initialize the PnP cards used for the boot sequence (VGA, IDE, SCSI). The rest of the cards will be initialized by the PnP operating

system like Window™ 95. When set to NO, BIOS will initialize all the PnP cards. For non-PnP operating systems (DOS , Netware™), this option must set to NO.

Options: No (Default) / Yes

A880G+/TA880G/A785G3+ BIOS Manual

PCI Latency Timer

T his item controls how long a PCI device can hold the PCI bus be for e another takes over. T he longer the latency, the longer the PCI device can retain control of the bus

before handing it over to another PC I device. Options: 64 (Default) / 0-255

Allocate I RQ to P CI VGA

T his item allows BIOS to choose a IRQ to assign for the PCI VGA card. Opti ons: Yes (De fault) / No

Palette Snooping

Som e old graphic controllers need to “snoop” on the VGA palette and then map it t o their display as a way to provide boot i nformation and VGA compatibility. This item

allows such snooping to take place. Options: Disabled (De fault) / Enabled

PCI IDE BusMaster

T his item is a toggle for the built-in driver that allows the onbo ard IDE controller to perform D M A (Di r ect Mem o ry Acces s ) tran s fers .

Options: Enabled (Default) / Disabled

PCI Reso urce

PCIPnP

PCI Resource

IRQ3 [Avail able]

IRQ4 [Avail able] IRQ5 [Avail able]

IRQ7 [Avail able] IRQ9 [Avail able] IRQ10 [Avail able]

IRQ11 [Avail able] IRQ14 [Avail able] IRQ15 [Avail able]

DMA Channel 0 [Avail able] DMA Channel 1 [Avail able] DMA Channel 3 [Avail able]

DMA Channel 5 [Avail able] DMA Channel 6 [Avail able] DMA Channel 7 [Avail able]

Reserved Memory Size [Disab led]

vxx.xx (C)Copyright 19 85-200x, American Megatrends, Inc.

BIOS SETUP UTILITY

Available: Specified IRQ is available to be

used by PCI/PnP devices.

Reserved: Specified IRQ is reserved for use by Legacy ISA

devices.

Select Screen Select Item

Change Option

General Help

F10

Save and Exit

ESC

Exit

A880G+/TA880G/A785G3+ BIOS Manual

IRQ3/4/5/7/9/10/11/14/15

T hese items will allow you to assign each system interrupt a type, depending on the type of device using the interrupt. The option “Available” means the IRQ is going to assign autom atically.

Options: Available (Default) / Reserved

DMA Channel 0/1/3/5/6/7

T hese items will allow you to assign each DMA channel a type, depending on the type of device using the channel. T he option “ Available” means the channel is

going to assign automatically. Options: Available (Default) / Reserved

Reser ved M em or y Size

T his item allows BIOS to reserve certain memory size for spe cific PCI device. Options: Disabled (De fault) / 16K / 32K / 64K

PCI Express Configuration

PCIPnP

PCI Express Configuration

Relaxed Ordering [Auto]

Maximum Payload Size [Auto] Extended Tag Field [Auto]

No Snoop [Auto] Maximum Read Request Size [Auto]

Active State Power-Management[Disabled] Extended Synch [Auto]

BIOS SETUP UTILITY

Enable/Disable Pci Express Device

Relaxed Ordering.

Rel axed Orderi ng

T his item enabl es/disables PC I Express Device Rel axed Orde ring. Options: Auto (De fault) / Disabled / Enabled

Select Screen Select Item

Change Option

General Help

F10

Save and Exit

ESC

Exit

A880G+/TA880G/A785G3+ BIOS Manual

Maxim u m Payload Si ze

T his item sets Maximum Payload of Pci Express Device or allows System BIOS to sel ect t h e val ue. Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048

Extended Tag Fiel d

If this item is enabled, it will allow the system to use 8-bit TAG filed as a requester. Options: Auto (De fault) / Disabled / Enabled

No Snoop

T his item enabl es/disables Pci Express Device No Snoop opt ion. Options: Auto (De fault) / Disabled / Enabled

Maxim u m Rea d Request Size

T his item sets Maximum Read Request Size of P ci Express Device or allows System BIOS to select the value. Options: Auto (Default) / 128 Bytes / 256 Bytes / 512 Bytes / 1024 Bytes / 2048

Active State Po wer- Management

Bytes / 4096 B ytes

This item sets the ASPM configuration for the PCI Express devices before the operating sys tem boots. This function is for OS which does not support ASPM. Options: Disabled (De fault) / Enabled

Exte nded Synch

If this item is enabled, it will allow generation o f Extended Synchronization patterns. Options: Auto (De fault) / Disabled / Enabled

A880G+/TA880G/A785G3+ BIOS Manual

4 Boot Menu

T his menu allows you to setup the system boot opti ons.

Main Advanced PCIPnP Boot Chipset Performance

Boot Settings Configuration

> Boot Device Priority

> Hard Disk Drives > Removable Drives

> CD/DVD Drives Quick Boot [Enabled]

Full Screen LOGO Show [Enabled] AddOn ROM Display Mode [Force BIOS]

Bootup Num-Lock [ON] Interrupt 19 Capture [Disabled] Ignore Memory Error Messages [Disabled]

Smart Multi-Core [Auto] BOOT SUCCESS BEEP [Enabled]

BIOS SETUP UTILITY

Exit

Specifies the Boot Device

Priority sequence.

Select Screen Select Item

Enter

Go to Sub Screen

General Help

F10

Save and Exit

ESC

Exit

Boot Device Priority

Items in this sub-menu specify the boot device priority sequence from the available devices. The number of device items that appears on the screen depends on the

number of devices installed in the system. Options: R emovable / Hard Disk / CDROM / Legacy LAN / Disabled

Hard Disk Drives

T he BIOS w ill attem pt to arrange t he hard di sk boot sequence aut omati cally. You can also ch an ge the b o oti n g s equence. Th e n umb er o f d evice i t ems t h at ap pears o n the screen depends on the number of devices i nstalled in the system. Op t i ons : P ri. M as t er / P ri. Sl ave / Sec. Mas t er / Sec. Sl ave / US B HD D0 /

USB HDD1 / USB HDD2 / Bootabl e Add-in C ards

Re mo va ble Dr ives

T he BIOS w ill attem pt to arran ge the remov able drive bo ot sequence automati cally. You can also change the booting sequence. The number of device items that

appears on the screen depends on the number of devic es installed in the system. Options: Floppy Disks / Zip100 / USB-FDD0 / USB-FDD1 / USB-ZIP0 /

USB -ZIP1 / LS 120

A880G+/TA880G/A785G3+ BIOS Manual

CD/DVD Drives

T he B IOS will attempt to arrange the CD/DVD drive boot sequence automatically. You can also change the booting sequence. The number of device items that

appears on the screen depends on the number of devic es installed in the system. Op t i ons : P ri. M as t er / P ri. Sl ave / Sec. Mas t er / Sec. Sl ave / US B C D R O M0 /

USB CDROM 1

Quick Boot

Enabling this option will cause an abridged version of the Power On Self-Test (POST) to execute a fter you power up the com puter. Options: Enabled (Default) / Disabled

Full Screen LOGO Show

T his item allows you to enable/disable Full Screen LOGO Show function. Options: Enabled (Default) / Disabled

AddOn ROM Dis play Mode

T his item sets the display mode for option ROM. Op t i ons : F orce B IO S (Default) / Keep Cu rren t

Boot u p Num- Lo ck

Selects the NumLock State after the system switched on. Options: ON (De fault) / OFF

Interrupt 19 Capture

When set to Enabled, this item allows the option ROMs to trap interrupt 19. Options: Disabled (De fault) / Enabled

I gnore Memory Error Messages

When set to Enabled, the POST will ignore memory error messages. Options: Disabled (De fault) / Enabled

Smart Multi-Core

Options: Auto (De fault) / Disabled

A880G+/TA880G/A785G3+ BIOS Manual

BOOT S UCCESS BEEP

W hen this i tem is set to Enabled, BIOS will let user know boot success with beep. Options: Enabled (Default) / Disabled

A880G+/TA880G/A785G3+ BIOS Manual

5 Chipset Menu

Th i s su b m en u all o w s you to co nfi g ur e t he speci fic feat u res of th e chips et in stal l ed o n your system. This chipset manage bus speeds and access to system memory

resourc es, such as DRAM. It also coordinates communications with the P CI bus.

Main Advanced PCIPnP Boot Chips et Performance

WARNING: Setting wrong values in below sections

> NorthBridge Configuration

> SouthBridge Configuration

may cause system to malfunction.

BIOS SETUP UTILITY

Options for NBAdvanced Chipset Settings

Select Screen Select Item

Go to Sub Screen

Enter

General Help

Save and Exit

F10

Exit

ESC

Exit

Nort h Br i dge Configu r ati on

BIOS SETUP UTILITY

NorthBridge Chipset Configuration

RS880 CIMx Version : 5.9.1

> Internal Graphics Configuration

> PCI Express Configuration Primary Video Controller [PCI-GFX0-GPP-IGFX]

NB Power Management Features [Auto]

Chipset

Select Screen Select Item

Enter

Go to Sub Screen

General Help

F10

Save and Exit

ESC

Exit

A880G+/TA880G/A785G3+ BIOS Manual

Internal G raphics Configuration

BIOS SETUP UTILITY

Internal Graphics Configuration

Internal Graphics Mode [UMA]

UMA Frame Buffer Size [Auto] GFX Engine Clock Override [Disable]

Surround View [Disabled]

FB Location [Above 4G]

Chipset

Options

Disable UMA

Select Screen Select Item

Change Option

General Help

Save and Exit

F10

Exit

ESC

Int ernal Graphics Mode

T his item allows you to sel ect t he memory mode used for internal graphi cs devi ce. Options: UMA (Default) / Disable

UMA Frame Buffer Size

T his item allows you to choose the UMA fram e buffer size for internal gr aphics. Options: Auto (Default) / 32MB / 64MB / 128MB / 256MB / 512MB

GFX En gin e Clock Overri de

T his item allows you to control the int ernal GF X engine clock override function. Options: Disabled (De fault) / Enabled

GFX En gin e Clock

T his item allows you to set the internal GF X engine clock. Options: 500 (Default) / Min: 150, Max: 1200

Surro und Vi ew

T his item allows you to control the S urround View Function. Options: Disabled / Enabled / Auto (Default)

FB Location

T his item allows you to set the FB-DIMM locati on. Options: Above 4G (De fault) / Under 4G

A880G+/TA880G/A785G3+ BIOS Manual

PCI Express Config uration

BIOS SETUP UTILITY

PCI Express Configuration

> Port #02 Features

> Port #07 Features > NB-SB Port Features

Port #02/07 Fe atures

BIOS SETUP UTILITY

Gen2 High Speed Mode [Disabled]

Link ASPM [Disabled] Link Width [Auto] Slot Power Limi t,W [75 ]

Chipset

Select Screen Select Item

Enter

Update

General Help

F10

Save and Exit

ESC

Exit

Auto - RC only advertize Gen2

capability.

Select Screen Select Item Change Option

General Help

Save and Exit

F10

Exit

ESC

Gen 2 H igh Speed Mode

Options: Disabled (Default) / Auto

Link AS PM

Options: Disabled (De fault) / L0s / L1 / L0x & L1

A880G+/TA880G/A785G3+ BIOS Manual

Li nk W i dth (Onl y for Po r t #02)

Options: Auto (Default) / x1 / x2 / x4 / x8 / x16

Sl ot Pow er Lim it, W (Only for Port #02)

Options: 75 (Default) / 0-255

NB-SB Po rt Features

NB-SB Link ASPM [L1] Options

NP NB-SB VC1 Traffic Support [Disabled] Link Width [Auto]

BIOS SETUP UTILITY

Chipset

Disabled L1

+F1

F10 ESC

Select Screen Select Item

Change Option General Help Save and Exit Exit

NB-S B Link ASPM

Options: L1(Default) / Disabled

NP NB-SB V C1 T r affic Su ppor t

Options: Disabled (Default) / Enabled

Li nk Wi dt h

Options: Auto (Default) / x1 / x2 / x4

Pri mary Video Control l e r

T his option allows you to select the video controller in charge. Opt i ons : P CI-GF X 0 -GPP -IG FX (Default ) / G F X0-GP P-IG F X -P CI /

GPP-GFX0-IGFX-PCI / IGFX-GFX0-GPP-PCI

NB Pow er Ma nage ment Feature s

T his option controls the NB power management function. Options: Auto (De fault) / Disabled

A880G+/TA880G/A785G3+ BIOS Manual

S outhB ri dg e C o nf i gura tion

BIOS SETUP UTILITY

SouthBridge Chipset Configuration

SB710 CIMx Verison: 4.7.0

OHCI HC(Bus 0 Dev 18 Fn o) [Enabled]

OHCI HC(Bus 0 Dev 18 Fn 1) [Enabled] EHCI HC(Bus 0 Dev 18 Fn 2) [Enabled] OHCI HC(Bus 0 Dev 19 Fn 0) [Enabled] OHCI HC(Bus 0 Dev 19 Fn 1) [Enabled]

EHCI HC(Bus 0 Dev 19 Fn 2) [Enabled] OHCI HC(Bus 0 Dev 20 Fn 5) [Enabled]

OnChip SATA Channel [Enabled] OnChip SATA Type [Native IDE] Option ROM POST Delay [Disabled]

Power Saving Features [Disabled]

Chipset

Options

Disabled Enabled

Select Screen Select Item

Go to Sub Screen

Enter

General Help

Save and Exit

F10

Exit

ESC

OHCI HC(Bus 0 Dev 18/19/20 Fn 0/1/5)

T his item allows you to control OHC I host controller. (USB 1.1 Device) Options: Enabled (Default) / Disabled

EHCI HC(Bus 0 Dev 18/19 Fn 2)

T his item allows you to control EHC I host controller. (USB 2. 0 Device) Options: Enabled (Default) / Disabled

OnChip SATA Channel

T his option allows you to enable the on-chip Serial AT A. Options: Enabled (Default) / Disabled

OnChi p S ATA Type

T his option allows you to select the on-chip Serial ATA operation mode. Options: Native IDE (Default) / RAID / AHCI / Legacy IDE / IDEÆAHCI

Option ROM POST Delay

Options: Disabled (De fault) / 1 Second / 2 ~ 7 Seconds

A880G+/TA880G/A785G3+ BIOS Manual

SATA IDE Combined Mode

T his option controls the S AT A/PAT A combined mode. Options: Enabled (Default) / Disabled

Power Sa ving Feat ures

T his item allows you to enable or disable power saving fe atures in SB. As general rule, this feature should be disabled for desktop and enabled fo r mobile. See AMD

SB 710 Power S aving document for more details. Options: Disabled (De fault) / Enabled

A880G+/TA880G/A785G3+ BIOS Manual

6 Performance Menu

T his submenu allows you to change voltage and clock of various devi ces. (Howev er, we suggest you use the default setting. Changing the voltage and clock

improperly may dam age the device.)

Notice

z Beware of that setting inappropriate values in items of this menu may cause

system to malfunction.

Main Advanced PCIPnP Boot Chipset Performance

Notice: Please Clear CMOS if system no display after overclocking

CPU Vcore [StartUp]

CPU NB Over Voltage [StartUp]

Over Voltage [1.23V]

Chipset HT Over Voltage [1.22V]

Memory Over Voltage [1.60V] CPU Frequency [200]

> CPU FID/VID Control > DRAM Timing Configuration

> Hyper Transport Configuration > Memory Configuration

BIOS SETUP UTILITY

CPU Vcore ControlPerformance Settings

+F1

F10 ESC

Exit

Select Screen Select Item

Change Option General Help

Save and Exit Exit

CPU Vcore

T his item allows you to sel ect CP U Voltage Control.

CPU NB Over Voltage

T his item allows you to sel ect CP U NB Voltage Cont rol.

Chipset Over Voltag e

T his item allows you to sel ect Chipset Voltage Control.

HT Over Vo ltage

T his item allows you to sel ect HT Volt age Control.

A880G+/TA880G/A785G3+ BIOS Manual

Memory Over Voltage

T his item allows you to sel ect DDR Voltage Control.

CPU Fr e que nc y

T his item allows you to sel ect t he CPU Frequency. Options: 200 (MHz) (Default) / 200-600

CPU FI D/V ID Co ntr ol

BIOS SETUP UTILITY

CPU FID/VID Control

Custom P-States [Disabled]

Core VID [1.2250 V] Core FID [x14.0 2800MHz]

Core DID [Divided by 1] NB VID [1.1500 V]

NB FID [2000 MHZ]

Performance

Tells BIOS whether to use the setup options

below this to configure the

P-States, or whether to configure the

P-States automatically

Custom P-States

T his item allows you to sel ect t he P -States controlling. Options: Disabled (De fault) / Enabled

Core VI D

T his function allows you to adjust the voltage of CP U.

Core FID

T his item allows you to sel ect t he Ratio/Frequency of CPU. Options: x8.0 1600MHz ~ x16. 5 3300MHz

Select Screen Select Item

Change Option

General Help

F10

Save and Exit

ESC

Exit

A880G+/TA880G/A785G3+ BIOS Manual

Core DID

T his is the Core Divider. Options: Divided by 1 (Default) / Divided by 2 / Divided by 4 / Divided by 8 /

Divided by 16

NB VID

T his function allows you to adjust the voltage of NB chip.

NB FID

T his item allows you to sel ect t he F requency o f NB chip. Options: 800MHz ~ 2000MHz (Di ffered by CP U)

DRA M Timi ng Co nfiguration

BIOS SETUP UTILITY

DRAM Timing Config uration

Memory Clock Mode [Auto]

Memclock Value [DDR3-800] DRAM Timing Mode [Auto]

Memory CLK : CAS Latency(Tcl) : RAS/CAS Delay(Trcd) : Row Precharge Time(Trp): Min Active RAS(Tras) : RAS/RAS Delay(Trrd) : Row Cycle (Trc) :

Command Rate(CR) :

Performance

Select the DRAM Frequency programming

method. If Auto, the DRAM speed will be based on SPDs.

If Limit, the DRAM spe will not exceed the

specified value. If Manual, the DRAM speed specified will be programmed regardless.

Select Screen Select Item

Change Option

General Help

Save and Exit

F10

Exit

ESC

Memory Clock Mode

T his item allows you to control the Memory Cl ock. Options: Auto (De fault) / Limit / Manual

Me mclock Value

T his item allows you to set the Memory Clock. Options: DDR3-800 (Default) / DDR3-1066 / DDR3-1333 / DDR3-1600

A880G+/TA880G/A785G3+ BIOS Manual

D RAM Timing Mode

T his item allows you to choose to manually or automatically regul ate the DRAM Timing.

Options: Auto (Default) / DCT0 / DCT1 / Both

CAS Latency (CL)

Options: Auto (Default) / 4~12 CLK

2T Command

Options: Auto (De fault) / 1T / 2T

TRCD

Options: Auto (De fault) / 5~12 C LK

TRP

Options: Auto (De fault) / 5~12 C LK

tRTP

Options: Auto (De fault) / 4~7 CLK

TRAS

Options: Auto (De fault) / 15~30 CLK

TRC

Options: Auto (De fault) / 11~42 CLK

tWR

Options: Auto (De fault) / 5~8 / 10 / 12 CLK

TRRD

Options: Auto (De fault) / 4~7 CLK

tWTR

Options: Auto (De fault) / 4~7 CLK

tRFC0 / tRFC1 / tR FC2 / tRFC3

Options: Auto (Default) / 90ns / 110ns / 160ns / 300ns / 350ns

A880G+/TA880G/A785G3+ BIOS Manual

Hyper Transport Configuration

BIOS SETUP UTILITY

Hyper Transport Configuration

NODE0:PCI-X2 HT Link

HT Link Speed [Auto]

HT Link Width [Auto]

Performance

The Hypertransport link will run at this

speed if it is slower than or equal to the system clock and the board is capable.

+F1

F10 ESC

Select Screen Select Item Change Option

General Help Save and Exit Exit

HT Link Spee d

Options: Auto (Default) / 200MHz / 400MHz / 600MHz / 800MHz / 1GHz /

1. 2GHz / 1 .4GHz / 1.6GHz / 1.8GHz / 2.0GHz

H T Link W idt h

Options: Auto (De fault) / 4 Bit / 8 Bit / 16 Bit

A880G+/TA880G/A785G3+ BIOS Manual

Memory Configuration

BIOS SETUP UTILITY

Memory Configuration

Bank Interleaving [Auto]

Channel Interleaving [XOR of Address bit] Enable Clock to All DIMMs [Disabled]

MemClk Tristate C3/ATLVID [Disabled] Memory Hole Remapping [Enabled] DCT Unganged Mode [Always] Power Down Enable [Disabled]

Page Smashing [Disabled] > ECC Configuration

Performance

Enable Bank Memory Interleaving

+F1

F10 ESC

Select Screen Select Item

Change Option General Help Save and Exit Exit

Bank Interleav ing

Bank Interleaving is an advanced chipset technique used to improve memory performance. Memory interleaving increases bandwidth by allowing simultaneous

acc ess t o m o re than o ne pi ece o f mem o ry. Options: Auto (Default)

Channel Interleaving

T his item allows you to control the DDR2 dual-channel function. Options: XOR of Address bits [20:16, 6] (Default) / XOR of Address bits

[20:16, 9] / Address bits 6 / Address bits 12 / Disabled

Enabl e Clock to All DIMMs

This item determines whether the BIOS should actively reduce EMI (Electromagnetic Interference) and reduce power consumption by turning off unoccupied or inacti ve DIMM slots.

Options: Disabled (De fault) / Enabled

Me mClk Trista te C3/ATLVID

T his item enables or disables the MemClk Tristate function in C3 Mode. Options: Disabled (De fault) / Enabled

A880G+/TA880G/A785G3+ BIOS Manual

M emory Hole Re m apping

This item allows you to enable or disable the remapping of the overlapped PCI memory above the total physical memory. Only 64-bit OS supports this function. Options: Enabled (Default) / Disabled

DC T Unganged M ode

This item controls the DRAM controller ganged (128bit*1) / unganged (64bit*2) dual-channel operation mode. If two DRAM modules with different size are

installed, usi ng unganged mode can still make it run in dual-channel operation. Options: Always (Default) / Auto

Power Dow n Enable

T his item controls the DRAM power down function. Options: Disabled (De fault) / Enabled

Page Smashing

T his item is S/W Control of P age Sm ashing Mechanism. Options: Disabled (De fault) / IC / DC / Both

ECC Configuration

ECC Configurati on

ECC Mode [Disabled]

DRAM ECC Enab le [Disabled] DRAM SCRUB RE DIRECT [Disabled] 4-Bit ECC Mod e [Disabled]

DRAM BG Scrub [Disabled] Data Cache BG Scrub [Disabled] L2 Cache BG S crub [Disabled] L3 Cache BG S crub [Disabled]

BIOS SETUP UTILITY

Performance

Set the level of ECC protection. Note: The

Super ECC mode dynamically sets the DRAM scrub rate so all of memory is

scrubbed in 8 hours.

+F1

F10 ESC

Select Screen Select Item Change Option

General Help Save and Exit Exit

A880G+/TA880G/A785G3+ BIOS Manual

ECC M o de

T his item allows you to sel ect t he DRAM EC C Mode. Options: Disabled (De fault) / Basic / Good / Super / Max / User

DRAM ECC Ena bl ed

Options: Disabled (De fault) / Enabled

DR AM Scru b Red i r ect

Options: Disabled (De fault) / Enabled

4-bit ECC Mode

Options: Disabled (De fault) / Enabled

DR AM BG Scru b / Da ta Ca ch e BG Scr ub/L 2 C a che BG Scru b / L3 Ca che B G S cr ub

Options: Disabled (De fault) / 40ns / 80ns / 160ns / 320ns / 640ns / 1. 28us / 2.56us /

5.12us / 10.2us / 20.5us / 41.0us / 81.9us / 163.8us / 327.7us / 655.4us /

1.31ms / 2. 62m s / 5.24m s / 10.49ms / 20.97ms / 42.00m s / 84.00ms

A880G+/TA880G/A785G3+ BIOS Manual

7 Exit Menu

This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items.

Main Advan c ed PCIPnP Boot Chipset Performance

Exit Options

Save Changes an d Exit

Discard Changes and Exit Discard Changes

Load Optimal De faults

Security Settin gs

> Security

BIOS SETUP UTILITY

Exit

Exit system setup after saving the

changes. F10 key can be used

for this operation.

Select Screen Select Item Go to Sub Screen

Enter

General Help

Save and Exit

F10

Exit

ESC

Save Changes and E xit

Save al l configur ation changes to CMOS RAM and exi t setup.

Discard Chang es and Exit

Abandon all changes made during the current session and exit setup.

Discard Chang es

Abandon all changes made during the current session and restore the previously saved values.

Load Optimal Defaults

This selection allows you to reload the BIOS when problem occurs during system booting sequence. These configurations are factory settings optimized for this

system.

A880G+/TA880G/A785G3+ BIOS Manual

Secur ity

T his sub-menu allows you to provide/revise supervis or and user password.

BIOS SETUP UTILITY

Exit

Security Settin gs

Supervisor Pass word :Not Installed User Password :Not Installed

Change Supervis or Password

User Access Lev el [Full Access] Change User Pas sword Clear User Pass word Password Check [Setup]

Boot Sector Vir us Protection [Disabled]

Install or Change the password.

Select Screen Select Item Change

Enter

General Help

Save and Exit

F10

Exit

ESC

Change Superv i sor P as swor d

Setting the supervisor password will prohibit everyone except the supervisor from making changes using the CMOS Setup Utility. You will be prompted with to enter a

password.

User Access Level

T his item allows supervisor to set the user level. Op t i ons : F ull A cces s (Defau l t) / No A cces s / View O n l y / Lim i t ed

Cha nge Us er Password

If the S upervisor Password is not set, then the User Password will function in the same way as the Supervisor Password. If the S upervisor Password is set and the User

Password is set, the “User” will only be able to view configurations but will not be abl e to ch an g e t h em .

Cle ar Use r Passw ord

T his item is for clearing user password.

A880G+/TA880G/A785G3+ BIOS Manual

P asswo rd Check

T his item is for setting the timing that checking password. Options: S etup (Default) / Always

Boot Se ctor Vi r us Protection

T his option allows you to choose the VIRUS W arning featur e that is used to protect the IDE Hard Disk boot sector. If this fun ction is enabled and an attempt is made to

write to the boot sector, BIOS will display a warning message on the screen and sound an alarm beep. Options: Disabled (De fault) / Enabled

Biostar A880G PLUS, A785G3 PLUS, TA880G BIOS MANUAL

Specifications and Main Features

Frequently Asked Questions

User Manual
