Bertazzoni REF24FCIPRR, REF24FCIPRL User Manual

0 (0)

Built-in Columns Freezer

User manual

Congélateur

Mode d’emploi

INDEX

EN

1

IMPORTANT SAFETY AND ENVIRONMENTAL HANDLING DIRECTIONS

4

1.1

For your safety.................................................................................................................................................................

4

1.2

Important information when using the appliance.................................................................................................

4

1.3

Caring for the environment..........................................................................................................................................

5

1.4

Cleaning, sanitization and maintenance of the ice and/or water dispenser (if present)...........................

5

2

INSTALLATION

6

2.1

Installation.........................................................................................................................................................................

6

2.2

Connection to the water system.................................................................................................................................

6

2.3

Connection to the electrical power supply...............................................................................................................

6

3

BEFORE STARTING

7

3.1

Know your appliance......................................................................................................................................................

7

3.2

Main components............................................................................................................................................................

8

3.3

Electric Control.................................................................................................................................................................

9

3.4

Main control panel..........................................................................................................................................................

9

4

BASIC OPERATIONAL OF THE APPLIANCE

10

4.1

Switching on and off.......................................................................................................................................................

10

4.2

How to adjust the temperature for different requirements................................................................................

11

4.3

Information signals of warning messages on the display..................................................................................

12

5

CUSTOMIZE FUNCTIONS AND SETTINGS

13

5.1

Functions...........................................................................................................................................................................

13

5.2

Settings..............................................................................................................................................................................

18

6

INTERNAL LAYOUT

24

6.1

Internal layout (positioning, adjustment, removal)...............................................................................................

24

7

ACTIVATION AND USE OF THE ICE MAKER

25

7.1

Activation and use of the Ice Maker...........................................................................................................................

25

7.2

Water filter for freezer column Ice Maker................................................................................................................

25

8

LIGHTING

27

8.1

Lighting...............................................................................................................................................................................

27

9

FOOD STORAGE

27

9.1

General directions...........................................................................................................................................................

27

9.2

How to best preserve food quality..............................................................................................................................

28

10

CARE AND CLEANING

28

10.1

Care and Cleaning...........................................................................................................................................................

28

10.2

Internal Cleaning.............................................................................................................................................................

29

10.3

Cleaning of the toe kick cover and condenser........................................................................................................

29

11

TROUBLESHOOTING GUIDE

30

11.1

Troubleshooting Guide...................................................................................................................................................

30

11.2

Malfunction messages appearing on the display..................................................................................................

32

12

WARRANTY

33

12.1

Warranty.............................................................................................................................................................................

33

3

1.IMPORTANTSAFETYANDENVIRONMENTALHANDLINGDIRECTIONS

1.1 For your safety

>If this appliance is replacing an existing appliance which must be removed or disposed of, make sure that it does not become a dangerous trap for children by cutting its power supply cable and rendering it impossible to close the door. Use the same caution at the end of the lifespan of the new appliance.

>This appliance is designed to refrigerate beverages and foods and is intended for domestic use.

>The appliance must be installed by following the instructions in the Installation Guide, particular care should be taken not to obstruct the vent openings of the appliance and of the built-in units.

>The appliance features a concentrated lighting system with LED lamps. Do not stare into these lamps when they are on to avoid possible eyesight damage.

This warning is also contained on the label attached to the inside of the freezer door.

>When the freezer is functioning do not touch the inner surfaces in stainless steel with wet or damp hands, since skin may stick to the very cold surfaces.

>Do not use any type of electrical equipment inside of the food conservation compartments.

>When positioning the shelves, do not place fingers in the shelf slide guides.

>Do not position containers of flammable liquids near the appliance.

>Completely switch off the appliance and unplug the power supply cable during cleaning operations. If the plug is not easily reached, it is a good idea to turn off the breaker or remove the fuse that controls the socket that the appliance is connected to.

>The packaging parts can be dangerous for children: do not allow children to play with the plastic bags, plastic film or Styrofoam.

>Any repairs must be performed by a qualified Bertazzoni Service technician.

>This appliance is not intended for use by persons (including children) with reduced physical, sensory or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

>Do not damage the appliance refrigerant circuit pipes.

>Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

>If the power cord of this appliance is damaged, it must be replaced by the manufacturer, customer service or a similarly qualified person. Improper in-

stallations and repairs may put the user at considerable risk.

>Repairs may be performed by the manufacturer, customer service or a similarly qualified person only.

>Plug into a grounded 3 prong outlet.

>Do not remove ground prong.

>Do not use an adapter.

>Do not use an extension cord.

>Disconnect power to all units before servicing.

>If the SUPPLY CORD is damaged, it must be replaced by the manufacturer, its service agent or similar qualified person in order to avoid a hazard.

>Children should be supervised to ensure that they do not play with the appliance.

1.2 Important information when using the appliance

>Never use electrical appliances inside the appliance (e.g. heater, electric ice maker, etc.). Explosion hazard!

>Never defrost or clean the appliance with a steam cleaner! The steam may penetrate electrical parts and cause a short-circuit. Risk of electric shock!

>Do not use pointed and sharp-edged implements to remove frost or layers of ice. You could damage the refrigerant tubes. Leaking refrigerant may cause eye injuries or ignite.

>Do not store products which contain flammable propellants (e.g. spray cans) or explosive substances in the appliance.

Explosion hazard!

>Do not stand on or lean heavily against base of appliance, drawers or doors, etc.

>Before cleaning the appliance, pull out the power cord plug or switch off the fuse. Do not pull out the power cord plug by tugging on the power cord.

>Store high-percentage alcohol tightly closed and standing up.

>Keep plastic parts and the door seal free of oil and grease. Otherwise, parts and door seal will become porous.

>Never cover or block the ventilation openings for the appliance.

4

Symbols used in the Guide:

Note

Recommendations for correct use of the appliance

Important

Directions for avoiding appliance damage

Warning

Indications for avoiding injury to people

1.3 Caring for the environment

>Pay special attention to correct disposal procedure for all the packaging materials.

>The appliance must not be disposed of with urban waste. Contact local waste disposal centres for on how to dispose of recyclable waste.

>Prior to disposal, cut the power supply cord and make it impossible to close the door.

>During disposal, avoid damage to the refrigeration circuit.

>The appliance does not contain hazardous substances for the atmospheric ozone layer, neither in

the refrigeration circuit nor in the insulation.

1.4 Cleaning, sanitization and maintenance of the ice and/or water dispenser (if present)

Failure to follow the instructions regarding sanitizing can compromise the hygienic safety of the water dispensed.

>When using the appliance for the first time and every time the filter is changed, it is recommended to let the water flow in the circuit using the “Manual Cleaning” and discard the ice produced in the first 24 hours.

>If the water dispenser has not been used for more than 4/5 days, it is advisable to clean the circuit and run off the first litre of water.

>Reposition the removable water dispenser (if present), ensuring your hands are hygienically clean.

EN

>Clean the ice bucket or drawer regularly but using only drinking water.

>The filter must be changed when indicated on the control panel or when the ice/water dispenser has not been used for more than 30 days.

>With each filter replacement, sanitise the ice and/ or water distribution system using a food grade disinfectant (with sodium hypochlorite), which does not alter the characteristics of the materials. Rinse with at least 1/2 gallon of water before use.

>Only original spare parts supplied by the manufacturer should be used when replacing components in the ice and water dispenser.

>Any work on the appliance must be carried out by a qualified technician or the After-sales Service.

Warning

To avoid contamination of food, please respect the following instructions:

>Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance.

>Clean regularly surfaces that can come in contact with food and accessible drainage systems.

>Clean water tanks if they have not been used for 48 h; flush the water system connected to a water supply if water has not been drawn for 5 days.

>Store raw meat and fish in suitable containers in the appliance, so that it is not in contact with or drip onto other food.

>If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance.

5

2. INSTALLATION

2.1 Installation

Make sure that installation is performed correctly, adhering to all directions in the specific installation manual provided with the appliance.

Warning

Always connect the water before the power.

2.2 Connection to the water system

The models provided with Ice Maker require a connection to the domestic water supply system. This can be executed through the 1/4” water line (copper or polyethylene)to the house water supply.

The system pressure must be between from 8 psi to 75 psi (between 0.5 bar and 5 bar).

Different pressures can cause malfunctions or leaks in the water system.

The appliance should be supplied only with drinkable water.

Warning

The appliance should be supplied only with drinkable water.

Warning

Make sure that installation is performed correctly, according to all of the directions in the specific installation manual provided with the appliance.

Warning

Do not attempt to use a locally sourced garden hose threaded adapter or braided supply line. It will strip the threads on the appliance water connection solenoid.

2.3 Connection to the electrical power supply

The appliance operates at 115 V AC, 60 Hz and is equipped with a power supply cord with a 3-prong grounded plug, which must be connected to a corresponding 3-prong (15 Amp) grounding-type wall

receptacle.

Important

Do not use extension cords and/or multiple adapters for the power supply connection.

6

3. BEFORE STARTING

EN

3.1 Know your appliance

Congratulations for having purchased your new appliance: from now on you can use our innovative conservation system, which will allow you to keep any kind of beverage in the best way possible.

This manual will answer most of your questions about the product’s features. Should you require further information, please check our website

>our website

in the US http://us.bertazzoni.com/care-service

in Canada https://ca.bertazzoni.com/more/support

Important

Before calling, write down the model type and serial number which are available on the warranty certificate and on the rating plate, and any messages which may have appeared on the display. Built In freezers come with 2 years parts & labor warranty, and 5 year parts & labor for sealed system only.

> or write us an e-mail at aftersaleservice@bertazzoni.com

Fridge Gas Fill Charge



oz

Quantité de Gaz Réfrigerateur





Freezer Gas Fill Charge

6.3

oz

Quantité de Gaz Congélateur





Total Absorbed Current

3.0

A

Courant Absorbée Totale





Voltage

115

V

Tension





Frequency

60

Hz

Frequence





Refrigerant Gas Type

R134a



Type de Gaz Rèfrigerant





Defrost Heater

344

W

Chau age de Dégivrage





Chemical name of blowing gas

HFO



Nom chimique du gaz sou•ant





IP number





Adresse IP





Made in Italy

Position of the serial number inside the compartment.

MODEL

ZKS5990FZ3IU

CODE

REF24FCIPIXL

SER.NO./N° SERIE

F20200101000006

ETL LISTED Conforms to UL 60335-1 and UL 60335-2-24 Certified to

CSA C22.2#60335-1 3186660 CSA C22.2#60335-2-24

Model .

Code .

Serial Number .

Features .

7

3. BEFORE STARTING

3.2 Main components

1

2

6

3 5

<![if ! IE]>

<![endif]>Freezer

4

7

8

Freezer

1)Stainless steel body.

2)Interactive control panel.

3)Patented shelf positioning system.

4)Ice maker container.

5)Door bins.

6)LED illuminations.

7)Stainless stell drawers.

8)Removable Grill.

8

EN

3.3 Eletronic Control

The innovative electronic control system designed by Bertazzoni maintains constant temperature in the entire compartment and visualizes it on the control panel display. It also allows user interaction making it possible to personalize settings of the various functions and to receive sound and/or visual messages should any malfunction occur in the appliance.

3.4 Main control panel

On/ Off:

Touch the icon to turn the unit on or off.

Home

Touch the Home icon for going back to the main display screen.

Alarm

Touch the icon to view the allarm tone functions and to deactivate them.

Back

Touch the arrow icon for going back to the previous display screen.

9

4. BASIC OPERATIONAL OF THE APPLIANCE

4.1 Switching on and off

First time starting the unit

Touch the button . The display shows the following launch screens:

1) Bertazzoni Logo.

Functions

Initial test…

2) Initial test

(lasts 3 minuts).

Settings

3) The display shows the main screen with the envirorment temperature measured from the fridge inside the compartments. Automatically the unit starts to cool down until reaching the set temperatures.



Functions

4) Home screen.





- Freezer compartment

- 18 °C



-18° (0°F)

Settings



When the appliance is first switched on it is reccomended to wait at least 12 hours without opening the doors and before placing any food inside the unit. During such period deactivated any error message by pressing the Alarm button.

Shutdown.

1) touch the bottomoff.

Are you sure you want to power off this unit?





2) Touch the icon

Yes

No

Yes to switch on.



Are you sure?

3) Confirm shutdown by

Yes No touching the Yes icon.

When the freezer is off there are no warning signs that prove that the freezer is plugged

to a socket.

Switching off for longer periods

During long absence periods it is recommended to switch off the freezer by pressing the Unit button for three seconds and disconnecting the electrical plug or the breaker controlling the socket.

Completely empty the freezer, clean and dry it and leave the doors and drawers partially open

to prevent unpleasant odors.

If at the first startup the Standby message does not appear, but another message appears, it means that the appliance has already started the cooling process.

During the first startup, it will not be possible to use the Menu to modify the factory settings until the preset temperature has been reached.

Each time the appliance is switched on it goes through a self-diagnosis procedure lasting three minutes before completely starting up.

10

4.2 How to adjust the temperature for different requirements.

Each model has been carefully tested before leaving the factory and is adjusted in such a way to ensure high performance and low consumption.

Usually, it is not necessary to modify the settings.

How it looks to the home screen:

Freezer

- 18 °C

Preset

compartment

temperature



EN

The temperature shown can vary slightly in respect to the set temperature following frequent openings of the doors or insertion of room temperature foods or large quantities of foods.

6 to 12 hours are necessary to reach the selected temperature.

Padlock icon.

The padlock icon shows up when the temperatures are set up.

The padlock open/close shows that is or isn't possible to modify the compartment's temperatures anymore.

Modify the temperatures compartment

How to modify the freezer compartment temperature.

Functions

- 18 °C

Settings

0 - 13

- 14 °C

- 15

OK

- 16

0 - 13

- 14 °C

- 15

OK

- 16

1) Home screen. Touch the icon of freezer compartement.

2) Scoll up/down to select the desided temperature

freezer from -13° C to -23° C (from 9° F to -11° F)

3) Touch the icon ok to confirm the desider temperature.

Usually an open yellow padlock can be seen open; in that case you can scroll up or down with a finger on the display, select the desired temperature and press OK for confirming.

0 - 13

- 14 °C

- 15

OK

- 16

Whereas a closed padlock can be seen if the user has activated some functions that modify the settings of Freezer Compartment therefore the user in that situation will not be able anymore to change the temperature of the compartments.

11

4. BASIC OPERATIONAL OF THE APPLIANCE

0 - 13

- 14 °C

- 15

OK

- 16

If the icon function is touched and a specific function is set (for example holiday, ect...), the yellow padlock will be seen closed and it won't be possible to change the temperature of the compartments as long as the function won't be completed or if it is manually deactivated.

4.3 Information signals of warning messages on the display.

An integrated control system will give information through bright text messages you can see on the display.

The audio signal that goes along with some of the anomalies signals and can be turned off by touching the button alarm on the main control panel.

You can find the list of the error messages at the end of this manual.

12

5. CUSTOMIZE FUNCTIONS AND SETTINGS

EN

INFORMATION FOR THE USE OF THE DISPLAY.

It is possible to personalize the operation of your Bertazzoni unit in order to adapt it to the different ways you might want to use it.

5.1 Functions.

After touching the icon Function on the home screen , the icons for the following functions will be shown.

Shopping Mode Freezer

1) Shopping Mode Freezer.

Vacation Mode

2) Vacation Mode.

Rapid Bottle Cooler

3) Rapid Bottle Cooler.

Ice Maker

4) Ice Maker.



Water Filter

5) Water filter.



Water System Purge

6) Circuit cleaning.

1) Shopping Mode Freezer

The function works at the maximum power level, without any break, from a minimum of 1 to a maximum of 12 hours, depending on time set, permitting more rapid freezing of food that has just been placed in the freezer. Once the time set is expired, the function deactivates automatically, returning to the previously set temperature. It

is possible to program a timed activation of the function.

After a prolonged interruption of electrical current, it is necessary to reactivate the function.

Functions

- 18 °C Settings

A) Home screen.

Touch the icon



functions.

Vacation Mode



B) Touch the icon



Shopping Mode



Shopping Mode Freezer Rapid Bottle Cooler

freezer.

Shopping Mode Freezer (up to 24 hours)















C) Touch the icon















On to activate the















function.



On





Off





































7













8





D) Scroll up /

Hour



9





down to setting













the desired time





















10



OK

and then press ok.







11

















It is possible to program this function 1 to 24 hours in advance.

13

5. CUSTOMIZE FUNCTIONS AND SETTINGS

2) Vacation Mode

This function (recommended in case of prolonged absences since it allows considerable energy savings) brings the freezer compartment temperature to -18° C (-0.4° F)

It is possible to program the duration, or it can be manually deactivated upon return after a period of absence. This function remains active even if during the period of absence there is a prolonged interruption of electrical power.

It is possible to program a period from 1 to 90 days.

3) Rapid Bottle Cooler

This function can be activated when it is necessary to cool off beverages quickly, by placing them inside the freezer compartment.

It is possible to select a duration of 1 to 45 minutes. A sound signal will indicated when the optimal temperature has been reached.

After removing the beverages, deactivate the sound signal by pressing the Alarm button .





Functions



-

18 °C



A) Home screen.



Touch the icon



Settings

functions.







Vacation Mode

B) Touch the icon

Vacation Mode.

Shopping Mode Freezer

Rapid Bottle Cooler

Vacation Mode

On Off

7

8 Day 9

OK

11

C)Touch the button On to activate the function.

D)Scroll up / down to set the desired time (in days) and then press ok.

It is possible to program a period from 1 to 90 days.

Functions

- 18 °C

Settings

Vacation Mode

Shopping Mode Freezer

Rapid Bottle Cooler

Rapid Bottle Cooler

On Off

35

36 Min 37

38

OK

39

A) Home screen. Touch the icon functions.

B) Touch the icon Rapid Bottle Cooler.

C) Touch the button On to activate the function.

D) Scroll up / down to set the desired time (in minutes) and then press ok.

14

4) Ice Maker activation

A pre-rinse of the water circuit should be performed before activating the Ice Maker for the first time. After a few minutes the Ice Maker can be activated.

Important

Do not activate the Ice Maker unless the appliance is connected to the water line.

Functions

- 18 °C

Settings

Ice Maker

Water Filter

Water System Purge

A) Home screen. Touch the icon functions.

B) Scroll twice right and then touch the icon ice maker.

Ice Maker

C) Touch the button







Yes to activate the







Yes



No

ice maker.













EN

4a) Set Ice cube Size - SuperIce

The IceMaker function permits selecting the size of the ice cubes, by choosing between Large (base setting) or Medium, and activation of the SuperIce function, which increases the quantity of produced ice.

The SuperIce function deactivates automatically after 24 hours.

Functions

- 18 °C

Settings

Ice Maker

Water Filter

Water System Purge

Set Cube Size

Superice









A) Home screen. Touch the icon functions.

B)Scroll twice right and then touch the icon ice maker.

C)Touch the icon Set Cube Size. The default cube size is "medium".

Set Cube Size

Medium Large

Ice Maker On/Off

Set Cube Size

Superice

Superice

D)Touch the icon medium/large to choose the desired Set Cube Size.

E)If you would like to increase the production of ice, touch the Superice icon, this will enable the freezer to produce more ice, up to 1,5kg a day.

F)Confirm the function or not by touching the On or Off button.

15

5. CUSTOMIZE FUNCTIONS AND SETTINGS

5) Water Filter Activation

5a) Water Filter Deactivation

The water filter is essential for the purification of

To deactivate an active filter reminder follow

the water used for making ice, for cleaning the

these steps:

circuit or for supplying water for the freezer com-



partment. The display permits visualizing the time



left before the filter needs to be replaced. The water



filter Remider has to be activated by the user.



Functions

- 18 °C

Settings

Ice Maker

Water Filter

Water System Purge

Water Filter

Are you sure?

On

Water Filter

Enable reminder countdown timer?

Yes

No

Water Filter Status

Next reminder…

Left 365 days



Functions

A) Home screen.

- 18 °C Settings

Touch the icon



functions.



Ice Maker

Water Filter

B) Scroll once



right and then



touch the icon

Water System Purge



water filter.



C)Confirm the function by touching the on button.

D)Confirm the function by touching the button Yes.

E) Indicates the remaining days before the replacement due date of the filter.

Touch the home button .

Water Filter

Next Reminder…

Left Xxx Days

Off Reset

Water Filter

Disable reminder?

Yes No

A) Home screen. Touch the icon functions.

B)Scroll once right and then touch the icon water filter.

C)Push off to activate Water Filter Reminder.

D)Confirm the function by touching the Yes button.

16

Bertazzoni REF24FCIPRR, REF24FCIPRL User Manual

5b) Reset Filter

The Reset Filter function sets to zero the time left before the filter needs to be replaced. It is necessary to set the reminder function to zero each time the cartridge is replaced.

Functions

- 18 °C

Settings

Ice Maker

Water Filter

Water System Purge

Water Filter

Next Reminder…

Left Xxx Days

Off

Reset

Water Filter

Reset reminder countdown?

Yes

No

Water Filter Status

Next reminder…

Left 365 days

A) Home screen. Touch the icon functions.

B)Scroll once right and then touch the icon Water filter.

C)Touch the button reset.

D)Touch the Yes button to proceed.

E)The countdown to the next water filter cartridge replacement will be indicated.

Push Home button to go back to the main screen or push "Yes" to deactivate filter

reminder.

EN

6) Manual Clean, Water Filter

If ice production has been disabled or unused for a long period it is recommended to perform a Manual Clean function.

Before proceeding it is important to turn off the ice maker.





Functions



-

18 °C



A) Home screen.



Touch the icon



Settings

functions.







Ice Maker

Water Filter



B) Touch the icon



Water System

Water System Purge

Purge.



Manual Clean

Yes No

Manual Clean

Please wait...

Manual Clean

Start Cleaning

Enter

Manual Clean

Cleaning running

C)Touch the icon yes to activate the manual cleaning.

D)Please wait...

E)Touch the icon enter to start the cleaning.

F)Cleaning running...

17

5. CUSTOMIZE FUNCTIONS AND SETTINGS

Cleaning completed

Empty water from ice bin. Replace ice bin and press OK.

OK

Cleaning completed

Please wait...

G) At the end of the cleaning, press ok and empty water from ice bin.

H) Wait a few seconds for the main menu screen to appear.

Repeat the cleaning steps until the water in the freezer tray is clean.

Place a water container or vessel under the ice tray to capture any water then close the drawer.

Bypass filter

The included filtration system can be bypassed when excellent water qualty is available from the home water system. You can simply remove the water filter from the adapter and the system will automatically bypass the cartridge.

5.2 Settings.

It is possible to personalize the settings of your Bertazzoni freezer for adapting it to the different ways you might want to use it.

Date

1) Date.



Time

2) Time.



°c / °f

3) Celsius or Fahrenheit.

Language

4) Language.

Sabbath

5) Sabbath.

Reset

6) Reset.

Demo

7) Demo Mode.

Maintenance

8) Maintenance.

Service

9) Service.

Info System

10) Info System.

18

EN

1) Date

2) Time

The display will show the date in the format

The display shows the hours and minutes in the

(day:month:year).

format hh:mm.

By touching the display you can modify the settings.

This function selects the display at 12 or 24 h.

Functions

- 18 °C

Settings

Date

Time

°c / °f

Language





2015

2016 Year 2017

2018

OK

2019

7

8

Month 9

10

OK

11

7

8 Day 9

10

OK

11

A) Home screen. Touch the icon settings.

B)Touch the icon date.

C)Scroll up or down until selecting the desired year and press ok.

D)Scroll up or down until selecting the desired month and press ok.

E)Scroll up or down until selecting the desired day and them press ok.

Functions

- 18 °C

Settings

Date

Time

°c / °f

Language

Hour?

12 24

7

8

Hour 9

10

OK

11

35

36 Min 37

38

OK

39

A) Home screen. Touch the icon settings.

B)Touch the icon time.

C)Touch in which way you want to see the time: 12 or 24 hours.

D)Scroll up / down to set the hours and then press ok.

E)Scroll up / down to set the minutes and then press ok.

19

5. CUSTOMIZE FUNCTIONS AND SETTINGS

3) SET °C/°F

This function permits visualizing the temperature in Centigrade or Fahrenheit degrees. Normally, the appliance is set for visualization in centigrade degrees.





Functions



-

18 °C



A) Home screen.



Touch the icon



Settings

settings.







Date

Time





B) Touch the icon

°c / °f

Language

°C/°F.

4) Language

To set the language of the freezer, simply touch the settings button on the display.





Functions



-

18 °C



A) Home screen.



Touch the icon



Settings

settings.







Date

Time





B) Touch the icon

°c / °f

Language

language.









C) Scroll up / down







to select either



°C



centigrade or





Fahrenheit degre-



°F





OK

es and press ok.















Italiano

English



C) Scroll up /



Français



down to select the



desired language

Deutsch



OK

and press ok.

Español







20

5) Sabbath Mode

The function makes it possible to comply to certain religious observances requiring that the operation of the appliance, is not affected by the opening or closing of the doors (the thermostatic control, the inner lighting and the ice maker are deactivated).

Functions

- 18 °C

Settings

Sabbath

Reset

Demo

A) Home screen. Touch the icon settings.

B) Scroll right twice and touch the icon sabbath.

EN

6) Reset

It gives the possibility to restore the base settings that were set in the factory, cancelling all the changes that has been made from there onward.





Functions



-

18 °C



A) Home screen.



Touch the icon



Settings

settings.









Sabbath







B) Scroll right





twice and touch





Reset

Demo

icon reset.









Confirm

Sabbath Mode

Yes No

Sabbath Mode

Yes No

Sabbath Mode

C) Touch the Yes button to activate the function.

D)Touch the yes button to activate the function.

E)The fridge will work accordingly to this configuration.

Confirm resetting to factory default settings?

Yes No

Reset

Yes No

Reset

Reset complete

C)Touch the yes button.

D)Touch the Yes button.

E)The reset has been performed. The freezer's factory settings have been restored.

21

Loading...
+ 47 hidden pages
