BERTAZZONI MASTER SERIES
36” DROP-IN LOW PROFILE COOKTOPS
QB36M 6 00 X
HIGHLIGHTS
• Bertazzoni’s exclusive dual control power burner in
cast brass delivers high-efficiency performance from
delicate low simmer to full power (750 – 18,000
BTUs) with best-in-class heat-up time.
• Cast iron pan supports of exclusive design allow
sliding of cookware across the entire cooking surface.
The stainless steel worktop is also seamless for easy
cleaning and the sharpest look.
• Bertazzoni low profile drop-in cooktops sit almost flush
over the countertop and present a seamless edge all
around. The design integrates beautifully with the
Bertazzoni line of convection ovens, specialty ovens
and warming drawers.
• The one-touch, child safety ignition system lets you
light and adjust burners with one hand.
FEATURES
Brass burners 6
Dual wok (1x) 750-18000 Btu/h
Rapid (1x) 11000 Btu/h
Semi-rapid (3x) 6500 Btu/h
Auxiliary (1x) 3400 Btu/h
Simmer rate 750 Btu/h
Maintop stainless steel
Controls soft touch round knobs
Grates cast iron
Wok adapter yes
Simmer ring yes
TECHNICAL SPECIFICATIONS
Electrical Requirements 120 V 60 Hz
Max Amp usage, power rating 0,1 A - 10 W
Certification CSA
Warranty 2 years parts and labor
ACCESSORIES
Stainless steel griddle for gas burners code SG36X
A LP conversion kit for all burners is included
• The thermocouple safety system automatically stops
the gas flow if the flame goes out, even when electrical
power is cut.
TO COOK BEAUTIFULLY
WWW.BERTAZZONI.COM
X
36" 13⁄16
2" 3⁄16 min
20"
1
⁄2
35"
5
⁄8
36" 13⁄16
2" 3⁄16 min
20"
1
⁄2
5
⁄8
5"
2"
35" 31⁄32
2" 11⁄16
11
⁄16
19"
INSTALLATION INSTRUCTIONS
QB36M 6 00 X
2" 11⁄16
2" 11⁄16
2"
2" 11⁄16
6" 3⁄8 min
21" 1⁄
19"
4
5
⁄8
35"
36" 13⁄16
20"
1
⁄2
2" 3⁄16 min
20" 15⁄32
5"
Bertazzoni recommends to operate the appliance after it has been
installed in a cabinet.
The kitchen cabinets shall be made of materials capable of
withstanding temperatures at least 117°F (65°C) above room
temperature in order to avoid possible damage to the cabinets
during appliance usage.
4" 3⁄4
Disclaimer: while every effort has been made to insure the accuracy of the information contained in
this brochure, Fratelli Bertazzoni reserves the right to change any part of the information at any time
without notice.
Fratelli Bertazzoni, Bertazzoni and the winged wheel brand icon are registered trademarks of
Bertazzoni Spa.
