Belshaw AutoFiller Donut Injector Operators Manual
1
Store this document safely and ensure it is available
at all times.
Enter Serial
No. here
In the event of an enquiry please quote this serial number.
Non-availability may affect the service / repair of your machine.
OPERATING AND MAINTENANCE MANUAL
ELECTRONIC DOUGHNUT JAMMER
ONLY FOR USE WITH SEEDLESS FILLINGS
MANUAL No.Y-DN-06E
FG053 -JAMMER 22-08-14 Rev A14
2
FG053 -JAMMER 22-08-14 Rev A14
3
Failure to adhere to the cleaning and maintenance
instructions detailed in this booklet could affect the
warranty of this machine
ONLY FOR USE WITH
SEEDLESS FILLINGS
FG053 -JAMMER 22-08-14 Rev A14
4
INDEX
1.0 INTRODUCTION
2.0 DIMENSIONS
3.0 SPECIFICATIONS
4.0 SAFETY
5.0 INSTALLATION
6.0 ISOLATION
7.0 CLEANING INSTRUCTIONS
8.0 OPERATING CONDITIONS
9.0 OPERATING INSTRUCTIONS
10.0 SETTING
11.0 MAINTENANCE
12.0 PROBLEM SOLVING
13.0 SPARES AND SERVICE
14.0 ELECTRICS
FG053 -JAMMER 22-08-14 Rev A14
5
1.0 INTRODUCTION
Mono’s electronic filler can fill doughnuts and past
waste. Fillings are precisely dispensed through dual nozzles in variable, preset
amounts.
To change fillings halfway through a run – just lift the filler unit from the console and
replace it with another unit containing the new filling.
Mono’s doughnut and pastry filler is simple to operate and programme – and really easy
to keep clean.
ries two at a time without mess or
2.0 DIMENSIONS
Height (
Height (without hopper) 205mm (8”)
with hopper) 460mm (18”)
Depth (including tray) 360mm (14”)
Width 390mm (15 ½”)
FG053 -JAMMER 22-08-14 Rev A14
6
3.0 SPECIFICATIONS
Weight (
without filling) 10.5kg (23lbs)
Hopper capacity 9.1kg (20lbs)
Single delivery capacity 9.5gms to 907gms
(1/3oz to 2lbs)
These figures can vary depending on the filling used.
WARNING.
Only to be used with seedless jams and fillings
ELECTRICAL REQUIREMENTS
See serial plate for machine version.
240volt 1 phase 50Hz total power 60Watts 0.3amps
or
120volt 1 phase 50Hz total power 60Watts 1.5amps
NOISE LEVEL
Less than 85dB
FG053 -JAMMER 22-08-14 Rev A14
