FSE 21906
Freezer
морозильник
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service.
For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future references.
This manual
•Will help you use your appliance in a fast and safe way.
•Read the manual before installing and operating your product.
•Follow the instructions, especially those for safety.
•Keep the manual in an easily accessible place as you may need it later.
•Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
C Important information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical Recycling and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive 2002/96/EC in order to be recycled or dismantled to minimise its impact on the environment. For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially dangerous for the environment and human health due to the presence of hazardous substances.
|
|
|
|
|
|
|
|
1 Your Freezer |
3 |
|
4 Preparation |
12 |
|
|
2 Important Safety |
|
|
5 Using your freezer |
13 |
|
|
Warnings |
4 |
|
|
|
|
|
|
Setting the operating temperature.... |
13 |
|||
|
Intended use |
4 |
||||
|
Making ice........................................ |
16 |
||||
|
For products with a water dispenser;. 6 |
|
|
|
||
|
Child safety........................................ |
6 |
6 Maintenance and |
17 |
|
|
|
HCA Warning..................................... |
6 |
cleaning |
|
||
|
...Things to be done for energy saving |
7 |
Protection of plastic surfaces .......... |
17 |
||
|
Technical specifications of your |
|
|
7 Recommended solutions |
||
|
freezer................................................ |
7 |
||||
|
|
|
|
for the problems |
18 |
|
|
3 Installation |
8 |
|
|
|
|
|
Points to be considered when re- |
|
|
|
|
|
|
transporting your freezer.................... |
8 |
|
|
|
|
|
Before operating your freezer............. |
8 |
|
|
|
|
|
Disposing of the packaging................ |
9 |
|
|
|
|
|
Disposing of your old freezer.............. |
9 |
|
|
|
|
|
Placing and Installation....................... |
9 |
|
|
|
|
|
Adjusting the legs............................. |
10 |
|
|
|
|
|
Reversing the doors......................... |
11 |
|
|
|
|
2EN
1 Your Freezer
1
2
4
3
4
4
4
5
1.Control Panel
2.Flap (Fast-Freeze compartment)
3.Ice cube tray & Ice bank
4.Drawers
5.Adjustable front feet
CFigures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.
3EN
2 Important Safety Warnings
Please review the following information. Failure to observe this information may cause injuries or material damage. Otherwise, all warranty and reliability commitments will become invalid.
The usage life of the unit you purchased is 10 years. This is the period for keeping the spare parts required for the unit to operate as described.
Intended use
This product is intended to be used
–indoors and in closed areas such as homes;
–in closed working environments such as stores and offices;
–in closed accommodation areas such as farm houses, hotels, pensions.
• This product should not be used outdoors.
General safety
•When you want to dispose/scrap the product, we recommend you to consult the authorized service in
order to learn the required information and authorized bodies.
•Consult your authorized service for all your questions and problems related to the freezer. Do not intervene or
let someone intervene to the freezer without notifying the authorised services.
•For products with a freezer compartment; Do not eat cone ice cream and ice cubes immediately after you take them out of the freezer compartment! (This may cause frostbite in your mouth.)
•For products with a freezer compartment; Do not put bottled and canned liquid beverages in the freezer compartment. Otherwise, these may burst.
•Do not touch frozen food by hand; they may stick to your hand.
•Unplug your freezer before cleaning or defrosting.
•Vapor and vaporized cleaning materials should never be used in cleaning and defrosting processes of your freezer. In such cases, the vapor may get in contact with the electrical parts and cause short circuit or electric shock.
•Never use the parts on your freezer such as the door as a means of support or step.
•Do not use electrical devices inside the freezer.
•Do not damage the parts, where the refrigerant is circulating, with drilling or cutting tools. The refrigerant that might blow out when the gas channels of the evaporator, pipe extensions or surface coatings are punctured causes skin irritations and eye injuries.
•Do not cover or block the ventilation holes on your freezer with any material.
•Electrical devices must be repaired by only authorised persons. Repairs performed by incompetent persons create a risk for the user.
•In case of any failure or during a maintenance or repair work, disconnect your freezer’s mains supply by either turning off the relevant fuse or unplugging your appliance.
4EN
•Do not pull by the cable when pulling off the plug.
•Place the beverage with higher proofs tightly closed and vertically.
•Never store spray cans containing flammable and explosive substances in the freezer.
•Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
•This product is not intended to be used by persons with physical, sensory or mental disorders or unlearned or inexperienced people (including children) unless they are attended by a person who will be responsible for their safety or who will instruct them accordingly for use of the product
•Do not operate a damaged freezer.
Consult with the service agent if you have any concerns.
•Electrical safety of your freezer shall be guaranteed only if the earth system in your house complies with standards.
•Exposing the product to rain, snow, sun and wind is dangerous with respect to electrical safety.
•Contact authorized service when there is a power cable damage to avoid danger.
•Never plug the freezer into the wall outlet during installation. Otherwise, risk of death or serious injury may arise.
•This freezer is intended for only storing food items. It must not be used for any other purpose.
•Label of technical specifications is located on the left wall inside the freezer.
•Never connect your freezer to electricity-saving systems; they may damage the freezer.
•If there is a blue light on the freezer, do not look at the blue light with optical tools.
•For manually controlled freezers, wait for at least 5 minutes to start the freezer after power failure.
•This operation manual should be handed in to the new owner of the product when it is given to others.
•Avoid causing damage on power cable when transporting the freezer.
Bending cable may cause fire. Never place heavy objects on power cable. Do not touch the plug with wet hands when plugging the product.
•Do not plug the freezer if the wall outlet is loose.
•Water should not be sprayed directly on inner or outer parts of the product for safety purposes.
•Do not spray substances containing inflammable gases such as propane gas near the freezer to avoid fire and explosion risk.
•Never place containers filled with water on top of the freezer, otherwise this may cause electric shock or fire.
•Do not overload your freezer with excessive amounts of food. If overloaded, the food items may fall down and hurt you and damage freezer when you open the door.
5EN
Never place objects on top of the freezer; otherwise, these objects may fall down when you open or close the freezer's door.
•As they require a precise temperature, vaccines, heat-sensitive medicine and scientific materials and etc. should not be kept in the freezer.
•If not to be used for a long time, freezer should be unplugged. A possible problem in power cable may cause fire.
•The plug's tip should be regularly cleaned; otherwise, it may cause fire.
•The plug’s tip should be cleaned regularly with a dry cloth; otherwise, it may cause fire.
•Freezer may move if adjustable legs are not properly secured on the floor. Properly securing adjustable legs on the floor can prevent the freezer to move.
•When carrying the freezer, do not hold it from door handle. Otherwise, it may be snapped.
•When you have to place your product next to another freezer or freezer, the distance between devices should be at least 8cm. Otherwise, adjacent side walls may be humidified.
For products with a water dispenser;
Pressure of water mains should be minimum 1 bar. Pressure of water mains should be maximum 8 bars.
• Use only potable water.
Child safety
•If the door has a lock, the key should be kept away from reach of children.
•Children must be supervised to prevent them from tampering with the product.
HCA Warning
If your product's cooling system contains R600a:
This gas is flammable. Therefore, pay attention to not damaging the cooling system and piping during usage and transportation. In the event of damage, keep your product away from potential fire sources that can cause the product catch a fire and ventilate the room in which the unit is placed.
Ignore this warning if your product's cooling system contains R134a.
Type of gas used in the product is stated in the type plate which is on the left wall inside the freezer.
Never throw the product in fire for disposal.
6EN
2010-11-xx
Y Y Y Y - M M - D D
Things to be done for energy saving
•Do not leave the doors of your freezer open for a long time.
•Do not put hot food or drinks in your freezer.
•Do not overload your freezer so that the air circulation inside of it is not prevented.
•Do not install your freezer under direct sunlight or near heat emitting appliances such as ovens, dishwashers or radiators.
•Pay attention to keep your food in closed containers.
•For products with a freezer compartment; You can store maximum amount of food items in the freezer when you remove the shelf or drawer of the freezer.
Energy consumption value stated for your freezer has been determined by removing freezer shelf or drawer and under maximum load. There is no harm to use a shelf or drawer according to the shapes and size of food to be frozen.
•Thawing frozen food in fridge compartment will both provide energy saving and preserve the food quality.
Technical specifications of your freezer
Energy efficiency class |
А |
|
|
Protection class |
1 |
|
|
7EN
3 Installation
B Please remember that the manufacturer shall not be held liable if the information given in the instruction
manual is not observed.
Points to be considered when re-transporting your freezer
1.Your freezer must be emptied and cleaned prior to any transportation.
2.Shelves, accessories, crisper and etc. in your freezer must be fastened securely by adhesive tape against any jolt before repackaging.
3.Packaging must be tied with thick tapes and strong ropes and the rules of transportation printed on the package must be followed.
Please do not forget…
Every recycled material is an indispensable source for the nature and for our national resources.
If you wish to contribute to recycling the packaging materials, you can get further information from the environmental bodies or local authorities.
Before operating your freezer
Before starting to use your freezer check the following:
1.Is the interior of the freezer dry and can the air circulate freely in the rear of it?
2.You can install the 2 plastic wedges as illustrated in the figure. Plastic wedges will provide the required distance between your freezer and the wall in order to allow the air circulation. (The illustrated figure is only an example and does not match exactly with your product.)
3.Clean the interior of the freezer as recommended in the “Maintenance and cleaning” section.
4.Plug the freezer into the wall outlet. When the fridge door is open the fridge compartment interior light will come on.
5.You will hear a noise as the compressor starts up. The liquid and gases sealed within the refrigeration system may also give rise to noise, even if the compressor is not running and this is quite normal.
6.Front edges of the freezer may feel warm. This is normal. These areas are designed to be warm to avoid condensation.
Electric connection
Connect your product to a grounded socket which is being protected by a fuse with the appropriate capacity.
Important:
•The connection must be in compliance with national regulations.
•The power cable plug must be easily accessible after installation.
•The specified voltage must be equal to your mains voltage.
•Extension cables and multiway plugs must not be used for connection.
8EN
B A damaged power cable must be replaced by a qualified electrician.
B Product must not be operated before it is repaired! There is danger of
electric shock!
Disposing of the packaging
The packing materials may be dangerous for children. Keep the packing materials out of the reach of children or dispose them of by classifying them in accordance with the waste instructions. Do not
dispose them of along with the normal household waste.
The packing of your freezer is produced from recyclable materials.
Disposing of your old freezer
Dispose of your old machine without giving any harm to the environment.
•You may consult your authorized dealer or waste collection center of your municipality about the disposal of your freezer.
Before disposing of your freezer, cut out the electric plug and, if there are any locks on the door, make them inoperable in order to protect children against any danger.
Placing and Installation
1.Install your freezer to a place that allows ease of use.
2.Keep your freezer away from heat sources, humid places and direct sunlight.
3.There must be appropriate air ventilation around your freezer in order to achieve an efficient operation.
If the freezer is to be placed in a recess
in the wall, there must be at least 5 cm distance with the ceiling and at least 5 cm with the wall.
If the floor is covered with a carpet, your product must be elevated 2.5 cm from the floor.
4.Place your freezer on an even floor surface to prevent jolts.
5.Do not keep your freezer in ambient temperatures under 10°C.
9EN
C This appliance is designed to operate at temperatures specified in the table below is equipped with
Advanced Electronic Temperature Control System [AETCS] which ensures that at the advised setting [4
- four on the knob] the frozen food in the freezer will not defrost even if the ambient temperature falls as low as -15 °C.
When first installed the product
MUST NOT be placed in low ambient temperatures because the freezer will not reduce to it’s standard operating temperature. Once it has reached its steady operating state it can be relocated.
So you may then install your appliance in a garage or an unheated room without having to worry about frozen food in the freezer being spoilt. However at low ambient temperatures mentioned above, fridge contents are likely to freeze, so check and consume food in the fridge accordingly. When the ambient temperature returns to normal, you may change the knob setting to suit your needs.
C If the ambient temperature is below 0°C, the food in the fridge compartment will freeze.So, we recommend you don’t use the fridge compartment in such low ambient conditions. You can continue using the freezer compartment as usual.
Adjusting the legs
If your freezer is unbalanced;
You can balance your freezer by turning the front legs of it as illustrated in the figure. The corner where the leg exists is lowered when you turn
in the direction of black arrow and raised when you turn in the opposite direction. Taking help from someone to slightly lift the freezer will facilitate this process.
10 EN
Reversing the doors
Proceed in numerical order .
(12)
5
1 2 3
6
4
45°
|
8 |
7 |
|
|
9 |
|
16 |
12 |
13 |
180° |
|
15 |
16 |
|
|
|
14 |
11 |
10 |
11 EN
4 Preparation
CYour freezer should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight.
CThe ambient temperature of the room where you install your freezer should at least be 10°C. Operating your freezer under cooler conditions than this is not recommended with regard to its efficiency.
CPlease make sure that the interior of your freezer is cleaned thoroughly.
CIf two freezers are to be installed side by side, there should be at least 2 cm distance between them.
CWhen you operate your freezer for the first time, please observe the following instructions during the initial six hours.
-The door should not be opened frequently.
-It must be operated empty without any food in it.
-Do not unplug your freezer. If a power failure occurs out of your control, please see the warnings in the “Recommended solutions for the problems” section.
COriginal packaging and foam materials should be kept for future transportations or moving.
12 EN
5 Using your freezer
Setting the operating temperature
Warm
Cold
The operating temperature is regulated by the temperature control.
1 = Lowest cooling setting (Warmest setting)
MAX. = Highest cooling setting (Coldest setting)
Please choose the setting according to the desired temperature.
The interior temperature also depends on ambient temperature, the frequency with which the door is opened and the amount of foods kept inside.
Frequently opening the door causes the interior temperature to rise.
For this reason, it is recommended to close the door again as soon as possible after use.
The normal storage temperature of your appliance should be -18 °C (0 °F).
Lower temperatures can be obtained by adjusting the thermostat knob towards Position MAX.
We recommend checking the temperature with a thermometer to ensure that the storage compartments are kept to the desired temperature.
Remember to take the reading immediately since the thermometer temperature will rise very rapidly after you remove it from the freezer.
13 EN
Loading...
