BECKHOFF CU8880-0000 User Manual

Installation- and Operating instructions for

CU8880-0000

Ethernet Controller with USB Input

Version: 1.3
Date: 2009-07-16

Table of contents

Table of contents

1. General instructions 2

Notes on the Documentation 2
Liability Conditions 2
State at Delivery 2
Description of safety symbols 2

2. Product Description 3

Product Overview 3
Power Supply 4
Data connectors 4

USB type B Port (X20) (standard-cable) 4
RJ 45-Port (X10) (standard CAT5-cable) 4

LED Diagnostics 5

3. Installation Instructions 6

Transport and Unpacking 6

Transport 6
Unpacking 6

Mounting / Unmounting 7
Connecting devices 8

Connecting cables 8

4. Operating Instructions 9

Configuration 9

5. Appendix 10

Assembly dimensions 10
Beckhoff Support & Service 11

Beckhoff branches and partner companies 11
Beckhoff Headquarters 11
Beckhoff Support 11
Beckhoff Service 11

Technical data 12
Approvals for USA and Canada 12

FCC: Federal Communications Commission Radio Frequency Interference
Statement 12
FCC: Canadian Notice 12

CU8880-0000 1

General instructions

General instructions

Notes on the Documentation

This description is only intended for the use of trained specialists in control

and automation engineering who are familiar with the applicable national
standards. It is essential that the following notes and explanations are
followed when installing and commissioning these components.

Liability Conditions

The responsible staff must ensure that the application or use of the
products described satisfy all the requirements for safety, including all the
relevant laws, regulations, guidelines and standards.

The documentation has been prepared with care. The products described
are, however, constantly under development. For that reason the
documentation is not in every case checked for consistency with
performance data, standards or other characteristics. None of the
statements of this manual represents a guarantee (Garantie) in the
meaning of § 443 BGB of the German Civil Code or a statement about the
contractually expected fitness for a particular purpose in the meaning of

§ 434 par. 1 sentence 1 BGB. In the event that it contains technical or
editorial errors, we retain the right to make alterations at any time and
without warning. No claims for the modification of products that have
already been supplied may be made on the basis of the data, diagrams
and descriptions in this documentation.

© This documentation is copyrighted. Any reproduction or third party use of
this publication, whether in whole or in part, without the written permission
of Beckhoff Automation GmbH, is forbidden.

State at Delivery

All the components are supplied in particular hardware and software

configurations appropriate for the application. Modifications to hardware or
software configurations other than those described in the documentation
are not permitted, and nullify the liability of Beckhoff Automation GmbH.

Description of safety symbols

The following safety symbols are used in this operating manual. They are

intended to alert the reader to the associated safety instructions.

Danger

Warning

i

Note

2 CU8880-0000

This symbol is intended to highlight risks for the life or health of personnel.

This symbol is intended to highlight risks for equipment, materials or the
environment.

This symbol indicates information that contributes to better understanding.

Product Description

Product Description

Product Overview

View of the CU8880-0000

The CU8880 USB-to-LAN adapter places an additional industrially-suited

and independent Ethernet interface at the user’s disposal. In this way, four
or more Ethernet interfaces can be implemented, depending on the system
configuration. The CU8880 is used for necessary IT communication, so
that the respective on-board Ethernet interfaces are available for EtherCAT
or real-time Ethernet communication. Drivers for the USB-to-LAN adapter
are available for Windows XP Professional, and Windows XP Embedded.

• user-friendly installation via integrated top hat rail adapter

power supply via USB - no supply voltage necessary

•

• compact industrial design

• clear quick diagnosis by separate LEDs.

CU8880-0000 3

Product Description

Power Supply

Power supply via USB-port The Ethernet controller does not need any

additional power supply. The power supply
(5 V DC) is realized by the USB connector.
The LED P20 lights green when power supply
is connected.

Data connectors

The connector are 1 USB port Type B and a RJ45-connector. The pins

are described below:

USB type B Port (X20) (standard-cable)

USB type B Port

RJ 45-Port (X10) (standard CAT5-cable)

RJ 45 Port

Pin Signal

1 VCC
2 Data ­3 Data +
4 GND
shield shield

Pin Signal

1 TX+
2 TX­3 RX+
4 n.c.
5 n.c.
6 RX­7 n.c.
8 n.c.

4 CU8880-0000

Product Description

LED Diagnostics

LED Diagnostics

The following table shows the possible states for the LEDs:

LED Assignment Status Meaning

off no power supply connected P20 power supply
lights green 5 V
off P10 Ethernet port

lights green Ethernet Collision
off P11 Ethernet port

lights yellow Ethernet full duplex
off P12 Ethernet port

lights Ethernet Link
off Ethernet Speed 10MBit P13 Ethernet port

lights Ethernet Speed 100MBit

via USB-Port

DC

CU8880-0000 5

Installation Instructions

Installation Instructions

Please also refer to chapter General instructions.

Transport and Unpacking

The specified storage conditions must be observed (see chapter Technical

data).

Transport

Despite the robust design of the unit, the components are sensitive to

strong vibrations and impacts. During transport, the unit should therefore
be protected from excessive mechanical stress. Therefore, please u se the
original packaging.

Danger of damage to the unit!

Warning

If the device is transported in cold weather or is exposed to extreme
variations in temperature, make sure that moisture (condensation) does not
form on or inside the device.

Prior to operation, the unit must be allowed to slowly adjust to room
temperature. Should condensation occur, a delay time of approximately 12
hours must be allowed before the unit is switched on.

Unpacking

Proceed as follows to unpack the unit:

1. Remove packaging.

2. Do not discard the original packaging. Keep it for future relocation.

3. Check the delivery for completeness by comparing it with your order.

4. Please keep the associated paperwork. It contains important
information for handling the unit.

5. Check the contents for visible shipping damage.

6. If you notice any shipping damage or inconsistencies between the
contents and your order, you should notify Beckhoff Service.

6 CU8880-0000

Installation Instructions

Mounting / Unmounting

The CU8880 can be snapped onto a 35 mm mounting rail conforms to

EN 50022.

Mounting the Ethernet
Controller

Just push the unit on the upper side under the rail (figure 1) and snap in
the lower side as shown below (figure 2):

Unmounting the Ethernet
Controller

To release the CU8880 from the mounting rail pull down the locking clip
with a screwdriver (figure 1) and pull off the device from the rail (figure 2):

CU8880-0000 7

Installation Instructions

Connecting devices

The power supply plug must be withdrawn!

Warning

The connections are documented in the section Product Description.

Please read the documentation for the external devices prior to connecting
them.

During thunderstorms, plug connector must neither be inserted nor
removed.

When disconnecting a plug connector, always handle it at the plug. Do not
pull the cable!

Connecting cables

When connecting the cables to the CU8880, proceed according to the
following sequence:

• Switch off all the devices that are to be connected.

• Disconnect all the devices that are to be connected from the power

supply.

• Connect all the cables between the CU8880 and to the devices

that are to be connected.

• Reconnect all devices to the power supply.

8 CU8880-0000

Operating Instructions

Operating Instructions

Configuration

Software driver Drivers for the USB-to-LAN adapter are available for Windows XP

Professional, and Windows XP Embedded.

The provided CD contains the according configuration software.

i

Note

CU8880-0000 9

Appendix

Appendix

Assembly dimensions

The product is characterized by small overall installed size. With a height of

approx. 100 mm, the module dimensions exactly match those of the
Beckhoff Bus Terminals. Together with the lowered connector surfaces,
this means that it can be used in a standard terminal box with a height of
120 mm.

10 CU8880-0000

Appendix

Beckhoff Support & Service

Beckhoff and their partners around the world offer comprehensive support

and service, guaranteeing fast and competent assistance with all questions
related to Beckhoff products and system solutions.

Beckhoff branches and partner companies

Please contact your Beckhoff branch office or partner company for local

support and service on Beckhoff products!

The contact addresses for your country can be found in the list of Beckhoff
branches and partner companies: www.beckhoff.com

You will also find further documentation

for Beckhoff components there.

Beckhoff Headquarters

Beckhoff Automation GmbH
Eiserstraße 5
33415 Verl
Germany

Phone:
Fax: [phone]
e-mail: [e-mail]

+49(0)5246/963-0

Beckhoff Support

Beckhoff offers you comprehensive technical assistance, helping you not
only with the application of individual Beckhoff products, but also with wide­ranging services:

• worldwide support

• design, programming and commissioning of complex automation

systems

• training program for Beckhoff system components

Hotline:
Fax: [phone]
e-mail: [e-mail]

+49(0)5246/963-157

Beckhoff Service

The Beckhoff service center supports you in all matters of after-sales
service:

• on-site service

• repair service

• spare parts service

• hotline service

Hotline:
Fax: [phone]
e-mail: [e-mail]

Quote the project number If servicing is required, please quote the project number of your product.

+49(0)5246/963-460

CU8880-0000 11

Appendix

Technical data

Number of ports 1 USB-input type B
1 Ethernet interface with 10/100BASE-T-connector RJ45
Supported USB standard USB 2.0
Status display 5 LEDs
USB wiring length maximum 1 meter
Power supply power supply via USB input connector
Max. current input from 5 V

maximum 500 mA at 5V DC

USB

The following conditions must be observed during operation:

Environmental conditions Ambient temperature: 0 to 55°C (operation)

-25°C to +70°C (transport/ storage)

Atmospheric humidity: Maximum 95%, non-condensing
Vibration/ Shock resistance EN 60068-2-6 / EN 60068-2-27, EN 60068-2-29
EMC resistance burst/ ESD EN 60000-6-2 / EN 60000 -6-4
Protection class IP20

Do not use the CU8880 in

The Ethernet Controller may not be used in areas of explosive hazard.

areas of explosive hazard
Dimensions (W x H x D) app. 35 mm x 98,5 mm x 76,6 mm (with mounting for DIN rail)

Weight app. 95 g
Assembly on 35 mm mounting rail conforms to EN 50022
Installation position any
Approvals CE

Approvals for USA and Canada

FCC Approval for USA

FCC Approval for Canada

FCC: Federal Communications Commission

Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his

own expense.

FCC: Canadian Notice

This equipment does not exceed the Class A limits for radiated emissions as

described in the Radio Interference Regulations of the Canadian Department of

Communications.

12 CU8880-0000
