Beckhoff CU8210-D004-0102 User manual

Manual | EN

CU8210-D004-0102

LTE USB Stick for Europe, Middle East, Africa

3/9/2021 | Version: 1.1

Table of contents

Table of contents

1 Notes on the documentation ....................................................................................................................5

1.1 Representation and structure of warnings.........................................................................................6

1.2 Documentation issue status ..............................................................................................................7

2 For your safety...........................................................................................................................................8

2.1 Intended use......................................................................................................................................8

2.2 Staff qualification ...............................................................................................................................8

2.3 Safety instructions .............................................................................................................................9

3 Product overview.....................................................................................................................................10

3.1 Structure ..........................................................................................................................................10

3.2 Name plate ......................................................................................................................................11

3.3 System requirements.......................................................................................................................11

4 Installing a SIM card................................................................................................................................12

5 Configuration ...........................................................................................................................................13

5.1 Installing the driver ..........................................................................................................................13

5.2 Establishing a mobile communication connection ...........................................................................14

6 Diagnostic LED ........................................................................................................................................15

7 Technical data..........................................................................................................................................16

7.1 Dimensions......................................................................................................................................17

8 Support and Service................................................................................................................................18

CU8210-D004-0102 3Version: 1.1

Table of contents

CU8210-D004-01024 Version: 1.1

Notes on the documentation

1 Notes on the documentation

This description is only intended for the use of trained specialists in control and automation engineering who
are familiar with applicable national standards.
It is essential that the documentation and the following notes and explanations are followed when installing
and commissioning the components.
It is the duty of the technical personnel to use the documentation published at the respective time of each
installation and commissioning.

The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.

Disclaimer

The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without prior announcement.
No claims for the modification of products that have already been supplied may be made on the basis of the
data, diagrams and descriptions in this documentation.

Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, EtherCAT G®, EtherCAT G10®, EtherCAT P®, Safety over EtherCAT®,
TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by Beckhoff Automation
GmbH.
Other designations used in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owners.

Patent Pending

The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents:
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702
with corresponding applications or registrations in various other countries.

EtherCAT® is a registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
Germany

Copyright

© Beckhoff Automation GmbH & Co. KG, Germany.
The reproduction, distribution and utilization of this document as well as the communication of its contents to
others without express authorization are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a
patent, utility model or design.

CU8210-D004-0102 5Version: 1.1

Notes on the documentation

1.1 Representation and structure of warnings

The following warnings are used in the documentation. Read and follow the warnings.

Warnings relating to personal injury:

DANGER

Hazard with high risk of death or serious injury.

WARNING

Hazard with medium risk of death or serious injury.

CAUTION

There is a low-risk hazard that can result in minor injury.

Warnings relating to damage to property or the environment:

NOTE

There is a potential hazard to the environment and equipment.

Notes showing further information or tips:

This notice provides important information that will be of assistance in dealing with the product or
software. There is no immediate danger to product, people or environment.

CU8210-D004-01026 Version: 1.1

Notes on the documentation

1.2 Documentation issue status

Version Modifications

1.0 First version

1.1 Chapter "Technical data" revised

CU8210-D004-0102 7Version: 1.1

For your safety

2 For your safety

Read the chapter on safety and follow the instructions in order to protect from personal injury and damage to
equipment.

Limitation of liability

All the components are supplied in particular hardware and software configurations appropriate for the
application. Unauthorized modifications and changes to the hardware or software configuration, which go
beyond the documented options, are prohibited and nullify the liability of Beckhoff Automation GmbH & Co.
KG.
In addition, the following actions are excluded from the liability of Beckhoff Automation GmbH & Co. KG:

• Failure to comply with this documentation.

• Improper use.

• Use of untrained personnel.

• Use of unauthorized replacement parts.

2.1 Intended use

With the CU8210-D004-0102 4G USB stick, Beckhoff Industrial PCs can be equipped with a GSM/UMTS/
LTE modem and subsequently connect to a mobile communication network. The USB stick can also receive
and send text messages using the Short Message Service (SMS).

The 4G USB stick was developed for a work environment that conforms to protection class IP20. This
involves finger protection and protection against solid foreign objects up to 12.5 mm, but not protection
against water. Operation of the devices in wet and dusty environments is not permitted, unless specified
otherwise. The specified limits for electrical and technical data must be adhered to.

The 4G USB stick is used to:

• equip Industrial PCs with an internet connection in rural areas without a comprehensive wired
infrastructure;

• establish a mobile communication connection between devices over long distances,

• or to reach difficult to access machine or plants such as wind turbines more easily. In addition, service
technicians can check the status of a plant with the help of a direct connection to the Device Manager
or a remote connection.

Improper use

The 4G USB stick is not suitable for operation in the following areas:

• areas in which the use of radio devices is prohibited.

• Potentially explosive atmospheres.

• Areas with an aggressive environment, e.g. aggressive gases or chemicals.

• applications that require real-time communication via radio.

2.2 Staff qualification

All operations involving Beckhoff software and hardware may only be carried out by qualified personnel with
knowledge of control and automation engineering. The qualified personnel must have knowledge of the
administration of the Industrial PC and the associated network.

All interventions must be carried out with knowledge of control programming, and the qualified personnel
must be familiar with the current standards and guidelines for the automation environment.

CU8210-D004-01028 Version: 1.1

For your safety

2.3 Safety instructions

The following safety instructions must be followed during installation and working with networks and the
software.

Mobile communication

• Make sure that a minimum distance of 20 cm is maintained to people during operation.

• The USB stick can be impaired in the vicinity of metal constructions or plants that emit electromagnetic
waves. Plan the distances and use the USB stick in such a way that the connection between the USB
stick and the mobile communication network is as unobstructed as possible.

• Do not allow any dust, liquids or vapors that could damage the USB stick to get inside it. Use the USB
stick together with the CU8210-M001-01x0 cabinet dome in order to protect it against environmental
influences.

Working with networks

• Restrict access to all devices to an authorized circle of persons.

• Change the default passwords to reduce the risk of unauthorized access. Regularly change the
passwords.

• Protect the devices with a firewall.

• Apply the IT security precautions according to IEC 62443, in order to limit access to and control of
devices and networks.

Working with the software

• Use up-to-date security software. The safe function of the PC can be compromised by malicious
software such as viruses or Trojans.

• The sensitivity of a PC against malicious software increases with the number of installed and active
software.

• Uninstall or disable unnecessary software.

Further information about the safe handling of networks and software can be found in the Beckhoff
Information System:

http://infosys.beckhoff.com

Document name

IPC Security Guideline

CU8210-D004-0102 9Version: 1.1

Product overview

3 Product overview

The 4G USB stick is equipped with a GSM/UMTS/LTE modem, which makes a wireless connection to a
mobile communication infrastructure possible. Industrial PCs that require a mobile communication
connection can be retrofitted with the 4G USB stick.

The USB stick is available in three different country versions and enables global use for industrial
applications. The USB stick is downwardly compatible and supports the 2G and 3G band.

The USB stick enables the exchange of data at a transfer rate of up to 150 Mbit/s (DL) and 50 Mbit/s (UL)
and can also be controlled with the help of AT commands.

The equipment of the USB stick includes:

• a USB interface for the supply of power and data transmission,

• a slot for a Mini-SIM (2FF)

• a built-in main and diversity antenna

• two CRC9 (TS-5) interfaces for external antennas.

3.1 Structure

Fig.1: Structure of a CU8210-D004-0102 4G USB stick.

Table1: Legend for the configuration.

No. Component Description

1

2 cover The SIM card slot is located under the cover.

3 External antenna Interface for the connection of an external antenna. A total of 2

4

5 Name plate The name plate can be used for the identification of the model and

Diagnostic LED [}15]

Installing a SIM card [}12]

The diagnostic LED indicates the status of the USB stick and, for
example, whether the USB stick is switched on, whether a network
is within range or whether the USB stick has already established a
connection.

CRC9 (TS-5) interfaces are available.

Slot for the SIM card.

is located under the cover.

CU8210-D004-010210 Version: 1.1

Product overview

3.2 Name plate

The 4G USB sticks are available in three versions, which differ only in the type of approval. Depending on
the approval, the sticks can be used in certain regions or countries.

The name plate makes it easier to find a stick with the appropriate approval for a region or country.

Fig.2: Name plate of a CU8210-D004-0102 4G USB stick.

The name plate is located under the cover:

• The model MS2372h-517 corresponds to the CU8210-D004-0101 4G USB stick, which is suitable for
operation in North and South America.

• The model MS2372h-153 corresponds to the CU8210-D004-0102 4G USB stick, which is suitable for
operation in EMEA (Europe, Middle East, Africa).

• The model MS2372h-607 corresponds to the CU8210-D004-0103 4G USB stick, which is suitable for
operation in Asia and Australia.

3.3 System requirements

Table2: System requirements - CU8210-D004-0102.

Operating system Version

Windows Windows 7 (32 and 64-bit)

Windows 10 (32 and 64-bit)

TwinCAT/BSD TwinCAT/BSD v.12.1

CU8210-D004-0102 11Version: 1.1

Installing a SIM card

4 Installing a SIM card

NOTE

Short circuit

The SIM card or the USB stick can be damaged. Do not remove the SIM card during operation and switch
the Industrial PC off.

In this work step we show you how to install a SIM card in the USB stick. Use the Mini-SIM card format. You
can also use a Micro or Nano-card with an appropriate adapter.

Proceed as follows:

1. Push the cover of the USB stick back and remove it.

2. Push the SIM card into the SIM card slot with the chip facing downwards. The diagonal edge points
towards the USB plug.

3. Place the cover on the USB stick and push it forwards until it engages again.

ð In the next step you can establish a connection to the mobile communication network.

CU8210-D004-010212 Version: 1.1

Configuration

5 Configuration

5.1 Installing the driver

In this work step we show you how to install the driver for the 4G USB stick. Following the installation, a new
network interface is created in Windows.

Requirements:

• Driver: Provided by Beckhoff Service.

Proceed as follows:

1. Make sure that the USB stick is not yet connected to the Industrial PC.

2. Run the DriverSetup.exe file to start the installation.

3. Following successful installation, an entry is made in the log file Install.log. The installation routine does
not give any feedback about the success of the installation.
The following message may appear after the installation: "This program might not have installed
correctly". You can ignore this message.

4. Connect the USB stick. The USB stick is ready for operation in the background following a short
installation.

ð The driver has been successfully installed if a new interface for mobile connections appears.

In the next step you can start a mobile communication connection.

CU8210-D004-0102 13Version: 1.1

Configuration

5.2 Establishing a mobile communication connection

In this step we show you how to establish a mobile communication connection. You need a connection with
a mobile communication provider, which will provide you with further access data.

Requirements:

• Connection with a mobile communication provider.

• Industrial PC with already installed drivers (see: Installing the driver [}13])

Proceed as follows:

1. Click the network symbol at the bottom right in the taskbar to display the available connections.

2. Choose the appropriate connection and click Connect.

3. You have to enter a PIN if the SIM card is protected by one.

ð Depending on the mobile communication provider, you must configure the connection in a browser and

enter additional access data. The access data will be provided to you by the mobile communication
provider.

CU8210-D004-010214 Version: 1.1

6 Diagnostic LED

Display Flashing code Description

red No signal

yellow Weak signal

green Strong signal

white The software of the 4G USB stick is

being updated

Diagnostic LED

CU8210-D004-0102 15Version: 1.1

Technical data

7 Technical data

Table3: Technical data, dimensions and weights.

CU8210-D004-0102

Dimensions (W x H x D) 88 mm x 28 mm x 11.5 mm

Weight approx. 30 g

Table4: Technical data, general data.

CU8210-D004-0102

Type 4G USB-2.0 stick, MS2372h-153

LTE R9

HSPA+/HSDPA/HSUPA/
WCDMA

4G band B1/B3/B7/B8/B20

3G band B1/B8

2G band 850/900/1800/1900

Output power LTE +23 dBm (Power Class 3)

Sensitivity LTE according to 3GPP TS 36.101 (R9)

Data transfer rate LTE DL 150 Mbit/s, UL 50 Mbit/s

Power supply 5V

Operating systems Windows 7/10, TwinCAT/BSD

SIM card USIM card, format: Mini-SIM (2FF)

Internal antenna supports antenna diversity for 3G/4G

External antenna
(optional)

Telecommunication
services

Diagnostic LED 1 network status

R8

HSPA+/HSUPA/HSDPA/WCDMA +24 dBm (Power Class 3)

WCDMA/HSPA/HSPA+ according to 3GPP TS 25.101(R8)

DC-PA+ DL 42 Mbit/s, UL 5.76 Mbit/s
HSPA+ DL 21 Mbit/s, UL 5.76 Mbit/s

2 CRC9 (TS-5) interfaces

Short Message Service (SMS)

Table5: Technical data, approvals.

CU8210-D004-0102

Approvals EMEA (Europe, Middle East, Africa)

Table6: Technical data, environmental conditions.

CU8210-D004-0102

Ambient temperature
during operation

Ambient temperature
during storage

Protection class IP 20

-20…+55 °C

-40…+70 °C

CU8210-D004-010216 Version: 1.1

7.1 Dimensions

Fig.3: CU8210-D004-0102 dimensions.

Technical data

CU8210-D004-0102 17Version: 1.1

Support and Service

8 Support and Service

Beckhoff and their partners around the world offer comprehensive support and service, making available fast
and competent assistance with all questions related to Beckhoff products and system solutions.

Beckhoff's branch offices and representatives

Please contact your Beckhoff branch office or representative for local support and service on Beckhoff
products!

The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet
pages: https://www.beckhoff.com

You will also find further documentation for Beckhoff components there.

Beckhoff Support

Support offers you comprehensive technical assistance, helping you not only with the application of
individual Beckhoff products, but also with other, wide-ranging services:

• support

• design, programming and commissioning of complex automation systems

• and extensive training program for Beckhoff system components

Hotline: [phone]
Fax: [phone]
e-mail: [e-mail]

Beckhoff Service

The Beckhoff Service Center supports you in all matters of after-sales service:

• on-site service

• repair service

• spare parts service

• hotline service

Hotline: [phone]
Fax: [phone]
e-mail: [e-mail]

Beckhoff Headquarters

Beckhoff Automation GmbH & Co. KG

Huelshorstweg 20
33415 Verl
Germany

Phone: [phone]
Fax: [phone]
e-mail: [e-mail]
web:

https://www.beckhoff.com

CU8210-D004-010218 Version: 1.1

List of tables

List of tables

Table 1 Legend for the configuration. ....................................................................................................... 10

Table 2 System requirements - CU8210-D004-0102. .............................................................................. 11

Table 3 Technical data, dimensions and weights. .................................................................................... 16

Table 4 Technical data, general data. ...................................................................................................... 16

Table 5 Technical data, approvals............................................................................................................ 16

Table 6 Technical data, environmental conditions.................................................................................... 16

CU8210-D004-0102 19Version: 1.1

List of figures

List of figures

Fig. 1 Structure of a CU8210-D004-0102 4G USB stick........................................................................ 10

Fig. 2 Name plate of a CU8210-D004-0102 4G USB stick.................................................................... 11

Fig. 3 CU8210-D004-0102 dimensions. ................................................................................................ 17

CU8210-D004-010220 Version: 1.1

More Information:

www.beckhoff.com/CU8210-D004-0102

Beckhoff Automation GmbH & Co. KG
Hülshorstweg 20
33415 Verl
Germany
Phone: [phone]
[e-mail]
www.beckhoff.com
