Purpose of this Document

PURPOSE OF THIS DOCUMENT

The purpose of this document is to provide you with an overview of the installation and wiring of the VN2000 Hot Tap
Insertion Meter. For information on basic configuration, see the VN2000 Transmitter User Manual supplied with the meter or
download the manual at www.badgermeter.com.

MPORTANTI

Read this manual carefully before attempting any installation or operation.
Keep the manual in an accessible location for future reference.

UNPACKING AND INSPECTION

Upon opening the shipping container, visually inspect the product and applicable accessories for any physical damage such
as scratches, loose or broken parts, or any other sign of damage that may have occurred during shipment.

OTE:N If damage is found, request an inspection by the carrier’s agent within 48 hours of delivery and file a claim with the

carrier. A claim for equipment damage in transit is the sole responsibility of the purchaser.

Storage

If the meter is not scheduled for installation soon after delivery and must be stored:

• After inspection, re-pack the meter into its original packing.

• If the meter being stored has been previously installed, remove all process fluids and corrosives.

• Store in a clean, dry site free of mechanical vibration, shock and chemical corrosives.

SAFETY

Safety Symbol Explanations

DANGER

INDICATES A HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED IS ESTIMATED TO BE CAPABLE OF CAUSING DEATH OR
SERIOUS PERSONAL INJURY.

INDICATES A HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED COULD RESULT IN SEVERE PERSONAL INJURY
OR DEATH.

INDICATES A HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED IS ESTIMATED TO BE CAPABLE OF CAUSING MINOR OR
MODERATE PERSONAL INJURY OR DAMAGE TO PROPERTY.

Safety Precautions

IF THE EQUIPMENT IS USED IN A MANNER NOT SPECIFIED BY THE MANUFACTURER, THE PROTECTION PROVIDED BY
THE EQUIPMENT MAY BE IMPAIRED.

Page 5 June 2018 VRX-UM-02217-EN-04

Product Label

PRODUCT LABEL

Figure 1: VN2000 meter label

Page 6 June 2018VRX-UM-02217-EN-04
