Desktop Assistant Pro

Overview

Desktop Assistant Pro is a LAN CTE based application that provides the enduser with the capabilities to manage the configuration of desktop telephones.

The functionality available includes:

 Button labelling including font, font size and background colour control.  Label printing.  Button programming of end-user accessible features (requires CTE

access to devices).

 Saving/Restoring a telephone configuration.  Telephone feature help.

Required Information

Before commencing configuration of Desktop Assistant Pro, it would be useful to obtain the following information/facilities:

 The extension number of the phone to be configured by Desktop

Assistant Pro.

 LAN CTE associated to the PC and DN in Element Manager.  LAN CTE loaded and configured on the PC that will be running

Desktop Assistant Pro.

Supported Operating Systems

Desktop Assistant Pro is supported on the following operating systems:

 Windows XP Professional SP3  Windows Vista Business, Ultimate, Enterprise SP2 32/64 bit  Windows 7 Professional, Ultimate, Enterprise 32/64 bit

NN40011-015 Issue 1.2 BCM Rls 6.0 5

Desktop Assistant Pro/Pro AE

Ensure LAN CTE is configured on the BCM to associate the required computers and telephones: Refer to the LAN CTE Guide.

Load LAN CTE onto the computer that will be using Desktop Assistant Pro: Refer to the LAN CTE Guide.

Load Desktop Assistant Pro onto the PC:

Refer to the Installing Desktop Assistant

Pro section of this guide.

Flowchart

This flowchart depicts the relevant steps required to install and configure the Desktop Assistant Pro application on a desk top PC.

6 NN40011-015 Issue 1.2 BCM Rls 6.0

Desktop Assistant Pro/Pro AE

Note: You can also use the Web Page button in Element Manager to launch a web broswer session. The BCM you wish to access must be selected in the Element Navigation Panel to do this.

Loading and Configuring LAN CTE

LAN CTE will have to be configured on the BCM via Element Manager to associate the phone device that you wish to use with Desktop Assistant Pro and your computer (refer to the LAN CTE Guide).

LAN CTE will have to be loaded onto the computer that will be using Desktop Assistant Pro (refer to the LAN CTE Guide).

Installing Desktop Assistant Pro

1. Open Internet Explorer.In the address field type (replacing the relevant part with your BCM IP address): http://<bcm ip address>/

2. Click on Go, or press Return on your keyboard.

3. If you are presented with the Certificate Error window, click on Continue to this website (not recommended).

NN40011-015 Issue 1.2 BCM Rls 6.0 7

Desktop Assistant Pro/Pro AE

4. Accept any further security messages that you may get presented with.

5. You will now see the login screen, enter your BCM User name and Password. By default these are set to User ID: nnadmin Password: PlsChgMe! Click on OK.

6. In the Welcome to BCM window, ensure the Main tab has been selected, and the BCM button clicked.

8 NN40011-015 Issue 1.2 BCM Rls 6.0

Desktop Assistant Pro/Pro AE

7. In the Applications area, select User Applications,and click on Run.

8. Again, accept any security messages that appear, and if prompted enter any login details.

9. From the User Applications screen, click on Desktop Assistant Pro.

NN40011-015 Issue 1.2 BCM Rls 6.0 9

Desktop Assistant Pro/Pro AE

10. Click on Download Desktop Assistant Pro Link.

11. Click the Run (or Open) button.

10 NN40011-015 Issue 1.2 BCM Rls 6.0

Desktop Assistant Pro/Pro AE

12. The files will be downloaded to your computer. If you see a Security Warning screen, click Run.

13. The Welcome screen will appear. Click the Next button.

NN40011-015 Issue 1.2 BCM Rls 6.0 11

Desktop Assistant Pro/Pro AE

14. The Licence screen will appear. Click Yes to accept the agreement.

15. The Choose Destination Location screen will appear. Select Next to accept the default destination.

12 NN40011-015 Issue 1.2 BCM Rls 6.0
