Avaya 15-601075 User Manual

IP Office

2402/5402 Phone User Guide

15-601075 Issue 05a - (16 July 2009)

© 2009 AVAYA All Rights Reserved.
Notice

While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of
printing, Avaya Inc. can assume no liability for any errors. Changes and corrections to the information in this document may be
incorporated in future releases.

Documentation Disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to the original published version of this
documentation unless such modifications, additions, or deletions were performed by Avaya.

Link Disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked Web sites referenced elsewhere within this
Documentation, and Avaya does not necessarily endorse the products, services, or information described or offered within
them. We cannot guarantee that these links will work all of the time and we have no control over the availability of the linked
pages.

License
USE OR INSTALLATION OF THE PRODUCT INDICATES THE END USER’S ACCEPTANCE OF THE TERMS SET FORTH
HEREIN AND THE GENERAL LICENSE TERMS AVAILABLE ON THE AVAYA WEBSITE AT
http://support.avaya.com/LicenseInfo/ (“GENERAL LICENSE TERMS”). IF YOU DO NOT WISH TO BE BOUND BY THESE
TERMS, YOU MUST RETURN THE PRODUCT(S) TO THE POINT OF PURCHASE WITHIN TEN (10) DAYS OF DELIVERY
FOR A REFUND OR CREDIT.
Avaya grants End User a license within the scope of the license types described below. The applicable number of licenses and
units of capacity for which the license is granted will be one (1), unless a different number of licenses or units of capacity is
specified in the Documentation or other materials available to End User. “Designated Processor” means a single stand-alone
computing device. “Server” means a Designated Processor that hosts a software application to be accessed by multiple users.
“Software” means the computer programs in object code, originally licensed by Avaya and ultimately utilized by End User,
whether as stand-alone Products or pre-installed on Hardware. “Hardware” means the standard hardware Products, originally
sold by Avaya and ultimately utilized by End User.
License Type(s): Designated System(s) License (DS).
End User may install and use each copy of the Software on only one Designated Processor, unless a different number of
Designated Processors is indicated in the Documentation or other materials available to End User. Avaya may require the
Designated Processor(s) to be identified by type, serial number, feature key, location or other specific designation, or to be
provided by End User to Avaya through electronic means established by Avaya specifically for this purpose.
Copyright
Except where expressly stated otherwise, the Product is protected by copyright and other laws respecting proprietary rights.
Unauthorized reproduction, transfer, and or use can be a criminal, as well as a civil, offense under the applicable law.

Third-Party Components
Certain software programs or portions thereof included in the Product may contain software distributed under third party
agreements (“Third Party Components”), which may contain terms that expand or limit rights to use certain portions of the
Product (“Third Party Terms”). Information identifying Third Party Components and the Third Party Terms that apply to them is
available on Avaya’s web site at: http://support.avaya.com/ThirdPartyLicense/

Avaya Fraud Intervention
If you suspect that you are being victimized by toll fraud and you need technical assistance or support, call Technical Service
Center Toll Fraud Intervention Hotline at [phone] for the United States and Canada. Suspected security
vulnerabilities with Avaya Products should be reported to Avaya by sending mail to: [e-mail].
For additional support telephone numbers, see the Avaya Support web site (http://www.avaya.com/support).

Trademarks
Avaya and the Avaya logo are registered trademarks of Avaya Inc. in the United States of America and other jurisdictions.
Unless otherwise provided in this document, marks identified by “®,” “™” and “SM” are registered marks, trademarks and
service marks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners.

Documentation information
For the most current versions of documentation, go to the Avaya Support web site (http://www.avaya.com/support) or the IP
Office Knowledge Base (http://marketingtools.avaya.com/knowledgebase/).

Avaya Support
Avaya provides a telephone number for you to use to report problems or to ask questions about your contact center. The
support telephone number is 1 800 628 2888 in the United States. For additional support telephone numbers, see the Avaya
Web site: http://www.avaya.com/support.

2402/5402 Phone Page 2

15-601075 Issue 05a (16 July 2009)IP Office

Contents

The Telephone1.

..................................................................... 81.1 Call Appearance Keys

..................................................................... 91.2 Logging On

..................................................................... 91.3 Logging Off

..................................................................... 101.4 No User

..................................................................... 101.5 The Display

..................................................................... 101.6 Personalized Ring

Call Handling2.

..................................................................... 122.1 Answering a Call

..................................................................... 132.2 Making a Call

..................................................................... 132.3 Clearing a Call

..................................................................... 142.4 Conference

..................................................................... 142.5 Transfer

..................................................................... 152.6 Speaker

..................................................................... 152.7 Redial

..................................................................... 152.8 Mute

..................................................................... 162.9 Hold

..................................................................... 162.10 Messages

Contents

System Features3.

..................................................................... 183.1 Call Forwarding

..................................................................... 193.2 Diverting Calls

..................................................................... 203.3 Do Not Disturb

..................................................................... 203.4 Voicemail

..................................................................... 213.5 Private Call

..................................................................... 213.6 Parking Calls

..................................................................... 223.7 Default Feature Codes

...............................................................................23Index

2402/5402 Phone Page 3

15-601075 Issue 05a (16 July 2009)IP Office

Chapter 1.

The Telephone

2402/5402 Phone Page 5

15-601075 Issue 05a (16 July 2009)IP Office

The Telephone:

1. The Telephone

This guide covers the use of the 2402 and 5402 phones on IP Office. Both phones are similar, however the 5402 is only
supported on the IP Office whereas the 2402 is supported on a range of Avaya phone systems.

1.Display, Call Appearance: Two Call Appearance Keys allow you to handle multiple calls. The display shows call
information.

2.Message Lamp: This lamp is used as follows;

· On (Continuous): There are new messages in your voicemail mailbox, or in another mailbox for which you have
been configured to receive "Message Waiting Indication".

· Flashing: The lamp also flashes when the phone receives a call.

3. MESSAGES: Access your voicemail mailbox.

4.Call Handling Buttons:

· HOLD:
Red button used to place a call on hold.

· TRANSFER:
Transfers a call to another phone.

· CONFERENCE:
Sets up conference calls with more than one other person.

· DROP:
Drops the current call or, if on a conference call, drops the last person to join the conference.

· REDIAL:
Redials the last number dialed or displays the last 6 numbers dialed from the phone, depending on configuration via
the Options menu.

5.Dial Pad: Standard 12-button pad for dialling phone numbers.

6. Volume Controls: Adjusts the speaker ringer volume depending on which is currently in use.

7.Handset Socket: The socket for the handset cable can be found on the side of the phone.

8. MUTE: Turns the handset microphone on/off. When muted, the associated light is on and the caller cannot hear you.

9. Feature: The system administrator can configure a number of special features which are then accessed by
pressing this key followed by any of the keys; 0 to 9, * or #.

10. SPEAKER: Pressing this key transfers the current call to the phone’s speaker. The adjacent lamp is lit when the
speaker is in use. Note however that the phone has no microphone and the handset is muted when the speaker is
being used, ie. This is a listen only mode. This button can be used to answer calls and to end calls being listened to on
the speaker.

· IP Office 4.1 and higher systems support a function called Group Listen. This function allows a call to be heard
through the speaker while talking through the handset. Consult with your system administrator for more details.

2402/5402 Phone Page 7

15-601075 Issue 05a (16 July 2009)IP Office

1.1 Call Appearance Keys

The main call handling screen contains two buttons set as 'Call Appearance' keys.

Having two Call Appearance keys is very useful. When holding a call, you can answer/make another call and then switch
between calls, transfer or conference. If you are set to receive a call waiting indication, the waiting call is shown against
the next call appearance key.

CAUTION

· Although your system administrator can replace the Call Appearance Keys with other functions, this would severely
restrict the use of features such as conference and transfer. It is for these reasons, that it is strongly recommended
that all Call Appearance keys remain at their default settings.

Call Appearance Key Icons

The icons displayed against the Call Appearance Keys allow you to determine the status (for example, on HOLD) of each
call.

Incoming Call:

A symbol next to a call appearance key indicates an incoming call. To answer the call and put any other current call on

hold, press / .

Connected:
A symbol next to a call appearance key indicates that it is the currently connected call. The caller's phone number (if

available) is also shown.

On HOLD:
A symbol next to a call appearance key indicates a call on hold. To take the call off hold and put any other current call
on hold, press the adjacent .

System Features

System Features can be set against dial pad digits by your system administrator and are accessed by pressing
Feature.

For Key and Lamp mode of operation these System Features must not be set against the Call Appearance keys. See the
CAUTION above.

Refer to overview of the feature key for details of System Features that can only be allocated to you by your system
administrator and to System Features for details of System Features that you can always access yourself by
dialling short codes. For example; to listen to your voicemail messages, dial *17.

18
