DEFINITY® Communications System
Generic 1, Generic 3, and System 75
Generic 2 and System 85
8101, 8102, and 8110 Telephones
User's Guide
NOTICE
While reasonable efforts were made to ensure that the information in this document
was complete and accurate at the time of printing, AT&T can assume no
responsibility for any errors. Changes or corrections to the information contained in
this document may be incorporated into future issues.
TO ORDER COPIES OF THIS DOCUMENT
Contact:
Order:
For more information about AT&T documents, see Business Communications
Systems Publications Catalog, 555-000-010.
HEARING AID COMPATIBILITY
This equipment is compatible with the inductively coupled hearing aids prescribed
by the Federal Communications Commission (FCC).
AT&T Customer Information Center
2855 North Franklin Road
P.O. Box 19901
Indianapolis, IN 46219
1-800 432-6600,
In Canada:
Document No. AT&T 555-230-746
Issue 2, December 1993
1 800 255-1242
YOUR RESPONSIBILITY FOR YOUR SYSTEM'S SECURITY
You are responsible for the security of your system. AT&T does not warrant that
this product is immune from or will prevent unauthorized use of common-carrier
telecommunication services or facilities accessed through or connected to it. AT&T
will not be responsible for any charges that result from such unauthorized use.
Product administration to prevent unauthorized use is your responsibility and your
system manager should read all documents provided with this product to fully
understand the features available that may reduce your risk of incurring charges.
Prepared by
AT&T GBCS Documentation Development
Middletown, New Jersey 07748-1998
©1993 AT&T
All Rights Reserved
Printed in USA
Contents
Your 8101, 8102, and 8110 Telephones
What the Features Do
Phone Features
System Features
How to Use the Features
Special Instructions for General Use
Conventions Used in Procedure Descriptions
Quick Reference Lists
Phone Features
Answering and Placing a Call
Auto Answer (for 8110 Users)
Hold
Message
Mute (for 8110 Users)
Personalized Ring (for 8102 and 8110 Users)
Programmable Dialing Buttons (8102 and 8110)
Redial
1
8
8
9
11
11
11
12
13
13
14
15
16
16
17
17
19
Redial (With Auto-Pause) (8102 and 8110 Users)
Speakerphone (for 8110 Users)
System Features
Special Instructions
Abbreviated Dialing
Automatic Callback
Call Forwarding All Calls
Call Park
Call Pickup
Call Waiting
Conference
Drop (for 8102 and 8110 Users)
Hold (with Second Dial Tone)
Leave Word Calling
Priority Calling
Send All Calls
Transfer
Voice Message Retrieval
20
21
23
23
23
25
25
26
27
27
28
28
29
31
31
32
32
33
i
Tones and Their Meanings
Ringing Tones
Handset Tones
34
34
34
Key Words to Know
Quick Reference Lists
35
ii
Your 8101, 8102, and 8110 Telephones
The 8101, 8102, and 8110 telephones are similar in appearance; however, the 8110
telephone has an added built-in speakerphone. (If you have an 8110 telephone, you
may also be able to use the Auto Answer feature; check with your system manager.)
These telephones are designed to help you use the many features of the AT&T
DEFINITY® Communications System Generic 1 and Generic 3 (System 75) and
Generic 2 (System 85).
Figures 1 and 2 show the 8101 telephone, Figures 3 and 4 show the 8102 telephone,
and Figures 5 and 6 show the 8110 telephone. The explanations that follow these
figures will help familiarize you with the many features available for each telephone.
1
Handset
Data jack
Labeling
designation
card
Flash button
Handset jack
Figure 1. 8101 Telephone, Top View
Redial button
Hold light
Hold button
Message light
Dial pad
TOP VIEW
Line jack
SIDE VIEW
Figure 2. 8101 Telephone, Side and Bottom Views
Positive disconnect
(Off/On)
Ringer
volume
control
(Lo/Med/Hi)
Mode
selector
(pulse/tone)
BOTTOM VIEW
2
Program Button
Handset
Data Jack
Adjunct (equipment)
Jack
Pause Button
Programmable
Dialing Buttons
Flash Button
Handset Jack
Redial Button
Hold Light
Hold Button
Message Light
Dial Pad
TOP VIEW
Figure 3. 8102 Telephone, Top View
Adjunct
Power Jack
Line Jack
Tone Selector
(Slow/Fast)
SIDE VIEW
Ringer
Volume
Control
Tone
Selector
(Lo/Hi)
BOTTOM VIEW
Figure 4. 8102 Telephone, Side and Bottom Views
3
Handset
Data Jack
Auxiliary
Power Jack
Program Button
Flash Button
Speaker Button
Handset Jack
Pause Button
Programmable
Dialing Buttons
Redial Button
Hold Light
Hold Button
Auto Answer Button
Mute Button
Message Light
Dial Pad
TOP VIEW
Figure 5. 8110 Telephone, Top View
Line Jack
Tone Selector
(Slow/Fast)
Speaker
Volume
Control
Ringer
Volume
Control
SIDE VIEW
Tone
Selector
(Lo/Hi)
BOTTOM VIEW
Figure 6. 8110 Telephone, Side and Bottom Views
4
Starting with the handset on the TOP VIEW and continuing clockwise:
Handset
Data jack
Adjunct (equipment) jack (on
the 8102 only)
Auxiliary power jack (on the
8110 only)
Pause button (on the 8102 and
8110 only)
For placing and receiving calls (also known as the
receiver).
For connecting a device such as a modem to your
telephone. This jack is labeled DATA.
For connecting adjunct equipment such as a
speakerphone or headset to your telephone. This jack is
labeled ADJUNCT.
For improving the performance of the built-in
speakerphone on long loops where there is limited power
available from the line. This jack is
labeled
For inserting a .5-second pause/delay into a telephone
number stored on a programmable dialing button or into
a dialing access code in the Auto-Pause feature of
Redial. See “Redial (With Auto-Pause)” in the section
titled How to Use the Features.
Programmable Dialing buttons
(on the 8102 and 8110 only)
Hold light
Hold button
Redial button
Auto Answer button (on the
8110 only)
Mute button (on the 8110 only)
Message light
The 12 buttons on which you can program frequently
dialed telephone numbers, emergency numbers, or
feature codes.
A red light that remains on to remind you that you have
a call on hold.
For putting a call on hold.
For redialing the last number you dialed from the dial
pad.
For automatically activating the built-in speakerphone
whenever a call comes in. Your system manager can tell
you whether you have this feature.
For turning off the microphone associated with the
handset or the built-in speakerphone.
A red light that flashes when a message has been left for
you.
5
Dial pad
The standard 12-button pad for dialing telephone
numbers. The dial pad is also used with the PROGRAM
button to store numbers on the programmable dialing
buttons or to store dialing access codes in the Redial
Auto-Pause feature.
Handset jack
Speaker button (on the 8110
only)
Flash button
Program button (on the 8102
and 8110 only)
For connecting the handset to your telephone.
For accessing the built-in speakerphone and microphone
combination.
For using features such as Conference with business
communications systems, and for custom calling
features if you are using your telephone at home.
For storing telephone numbers on the programmable
dialing buttons and dialing access codes in the AutoPause feature of Redial
The SIDE VIEW shows the following features:
Mode Selector (Tone or Pulse)
(on the 8101 only)
Positive Disconnect
(ON or OFF) (on the 8101 only)
Tone Selector (HI or LO) (on
the 8102 and 8110 only)
Tone Selector (FAST or SLOW)
(on the 8102 and 8110 only)
Ringer Volume
control
For selecting one of two dialing modes (tone or pulse).
For selecting positive disconnect or turning it off
(on or off).
For selecting one of two tone ringer frequencies
(high or low).
For selecting one of two tone ringer modulation rates
(fast or slow).
A 3-position switch to control the volume for the tone
ringer. Slide it up (away from you) for a louder ring,
down (toward you) for a quieter ring. The volume
control is labeled
Speaker volume control
(On the 8110 only)
For raising or lowering the volume of the built-in
speakerphone. The volume control is
labeled
6
The BOTTOM VIEW includes the following:
Adjunct power jack (for adjunct
equipment) (on the 8102 only)
Line jack
For connecting an adjunct power source for using
adjunct equipment. This jack is labeled ADJ PWR.
For connecting a line cord to your telephone. This jack
is labeled LINE.
7
What the Features Do
The following section lists several voice features and briefly explains what each one
does and how you might want to use it.
The features in this guide have been divided into two categories:
●
Phone Features Those telephone features that you can use immediately no
matter which communications system your telephone is behind.
Note: You can use the Speakerphone and Mute features only if you are using the
8110 telephone. You may also be able to use the Auto Answer feature if it is
assigned to your 8110 telephone.
●
System Features Those features that you can use only with a DEFINITY
Generic 1 or System 75 or Generic 2 or System 85 switching system. Most of
these features must be assigned by the system manager to your telephone. Check
with your system manager to see which of these features you can use.
Phone Features
Auto Answer (for 8110 Users) Automatically answers the call and turns on the
built-in speakerphone on the 8110 telephone. When this feature is activated, the
telephone rings once, and then an alerter tone sounds to notify you that the call has
been answered. Your telephone will automatically drop the call and be ready for the
next call when the calling party hangs up. Answer calls without lifting the handset.
Hold Puts a call on hold until you can return to it. While a call is on hold, you can
leave your telephone to perform another task or pick up a call on another extension.
Use when you have a call that you don’t wish to drop, but which you have to
interrupt briefly to do something else. Note: If you want to place or answer a call
while you have a call on hold, you can use the System Feature, “Hold (with Second
Dial Tone).”
Message Turns on your Message light to let you know that a caller has left a
message for you. You can then follow your system manager’s local message retrieval
procedures to get your message.
Mute (for 8110 Users) Turns off the microphone of the built-in speakerphone or the
handset. Use when you want to confer with someone in the room with you, but you
do not want the other party on the call to hear your conversation.
Personalized Ring (for 8102 and 8110 Users) The two tone controls on the side of
the telephone allow you to choose your own personalized ringing pattern for your
telephone. You can choose one of two ringing frequencies and also one of two ringer
modulation rates. Use to help distinguish your incoming calls from those of other
telephones in your work area.
Positive Disconnect (for 8101 users) In the ON position, hangs up the phone for
approximately two seconds, even if the switchhook depression is for a shorter
duration. This action prevents inadvertent switchhook flashes. To initiate a
switchhook flash in this mode, the [
FLASH
] button must be pressed. In the
OFF
position, switchhook functioning is normal.
8
Programmable Dialing Buttons (for 8102 and 8110 Users) The 12 programmable
dialing buttons are provided for one-touch dialing of frequently dialed telephone or
account numbers. You can also store emergency numbers, such as 911, or feature
codes on your programmable dialing buttons. Note: If you want to store more than
12 programmable dialing numbers, you can use the system feature, “Abbreviated
Dialing.”
Redial The Redial feature automatically redials the last extension or outside
number you dialed from the dial pad. Use this feature to save time in redialing a
busy or unanswered number. The number you redial can be up to 20 digits.
Redial (With Auto-Pause) (for 8102 and 8110 Users) The Auto-Pause feature can
automatically insert pauses after a dial access code (such as 9) in a redialed number.
If you usually wait a short period to obtain a second dial tone after dialing an access
code, you can set the waiting time needed by the Redial feature by programming the
Auto-Pause feature as described in the section, “Phone Features.”
Speakerphone (for 8110 Users) Allows you to place and answer calls without
lifting the handset. Use this feature any time you prefer hands-free communication
(either speaking or listening) or for group conference situations.
System Features
Abbreviated Dialing Allows you to store selected telephone numbers for quick and
easy dialing. Each number can be a complete or partial telephone number, an
extension number, or a trunk or feature code. There are four possible types of
lists—personal, group, system, and enhanced—and you can have a total of three out
of the four possible lists (see your system manager for details). Numbers on a
personal list are programmable by you; numbers on all other lists are programmable
only by the system manager. Use as a timesaver for dialing frequently called,
lengthy, or emergency numbers.
Automatic Callback Sends you a special 3-burst ringing tone indicating that a
previously busy or unanswered extension is now available. Use to avoid constant
redialing when you wish to speak to someone who is frequently busy on the telephone
or in and out of the office. Note: Can be used only for extensions, not outside
numbers.
Call Forwarding All Calls Temporarily forwards all your calls to another extension
or to an outside number, depending on your system. Use when you will be away
from your telephone and you want your calls to be forwarded to a telephone of your
choice.
Call Park Puts a call on hold at your telephone, for retrieval at any extension. Use
when you need to go elsewhere to get information during a call, or whenever you
wish to complete a call from a different location. Also, if the call received is for
someone else, use it to hold the call until the called party can answer it from the
nearest available telephone.
Call Pickup Lets you answer a call at your telephone for another extension in your
pickup group. Use when you wish to handle a call for a group member who is absent
or otherwise unable to answer. Note: You can only use this feature if you and the
called party have been assigned to the same pickup group by your system manager.
9
Call Waiting When you are busy on a call, sends a distinctive tone to notify you of
another incoming call waiting to be answered. This allows you to complete or hold
your present call and pick up the waiting call.
and your waiting caller from having to call back later.
Conference Allows you to add a third party to a call, so that you can conduct a
three-way conversation. (If you wish to conference more than three parties, call your
attendant for assistance. ) Use to set up time-saving conferences, or to spontaneously
include a third party important to a discussion. Note: If you have both an active
call and a call on hold, you must terminate one of them before you can use
Conference.
Drop Allows you to drop a line without hanging up the handset or turning the
telephone off.
Hold (with Second Dial Tone) Puts a call on hold until you can return to it. When
you hear a second dial tone, you can place or answer another call or activate another
feature. Use the Hold feature when you have a call you don’t wish to drop, but which
you have to interrupt briefly to do something else.
Leave Word Calling Leaves a message for another extension to call you back. The
called party will be able to dial message service (for example, attendant, AUDIX®,
covering user, etc.) to retrieve a short, standard message which gives your name and
extension, the date and time you called, and the number of times you called. Use
any time you wish to have someone call you back; it will help cut down on repeated
call attempts.
It will save you from missing calls,
Priority Calling Allows you to call another extension with a distinctive 3-burst ring
to indicate that your call requires immediate attention. Use when you have
important or timely information for someone.
Send All Calls Temporarily sends all your calls to the extension of a person
designated to answer them when you cannot (perhaps a secretary or receptionist).
Use when you will be away from your desk for awhile, or when you do not wish to be
interrupted by telephone calls.
Transfer Transfers a call from your telephone to another extension or outside
number. Use when your caller needs to speak further with someone else.
Note: Calls from an outside number to your telephone can be transferred only to an
extension, not to another outside number.
Voice Message Retrieval Gives you messages (via computerized voice) left for you
through Leave Word Calling or as typed by a covering user. If authorized by your
system manager, you may also retrieve messages for one or more of your coworkers.
Use to hear all messages received while you were away.
10
How to Use the Features
The following procedures give short, step-by-step instructions for using each feature.
For your convenience, features are listed alphabetically.
Special Instructions for General Use
As you operate the features assigned to your telephone, keep in mind the following
general rules.
●
Follow carefully all the steps listed in the procedure for the particular feature
you are using.
●
If you receive an intercept tone (high-pitched, alternating high and low tone)
while attempting to operate any feature, you have taken too much time to
complete a procedural step or have made a dialing error. Hang up, get dial
tone, and begin again at Step 1.
●
For directions on filling out the programmable dialing buttons designation
card, see the procedures for “Programmable Dialing Buttons” under Phone
Features in this section.
●
In many cases, before you begin a procedure, you must have the handset offhook (removed from the cradle of the telephone), or, if you are using an 8110
telephone, you can turn on the speakerphone.
●
To the right of each Phone Feature heading is a box. For each feature available
on your telephone, make a check in the blank box as a reminder. This check
indicates that you can use any of these features immediately, without any help
from your system manager.
Conventions Used in Procedure Descriptions
In this guide, the following conventions are used in the procedure descriptions:
[ Feature ]
[feedback tone]
For a list of tones and their meanings, see the section titled Tones and Their
Meanings.
Each of these boxes represents a button that has a
feature assigned to it. The button is labeled with the
feature name.
The tone that appears in brackets after a step indicates
what you should hear from your handset (or
speakerphone, if appropriate) after successfully
performing that step.
11
Quick Reference Lists
At the end of this booklet is a set of quick reference lists. Use them to record your
feature and trunk codes, Abbreviated Dialing personal list items, and message and
attendant extensions. Once you have completed the lists, remove the page from the
booklet (tear along the perforation), and keep the lists near your telephone.
12
Phone Features
The following features can be used no matter which communications system your
8101, 8102, or 8110 telephone is behind. Remember that you can use the
Speakerphone and Mute features only if you are using an 8110 telephone. Some
8110 users will also be able to use the Auto Answer feature; check with your system
manager.
Answering and Placing a Call
Note: If you are using the 8110 telephone, you can place and answer calls either by
going off-hook (by lifting the handset) or leaving the handset on-hook and by
pressing
that you can place and answer calls without lifting the handset.
If you are using the 8102 telephone, you can connect an external speakerphone to the
Speakerphone/headset jack on the bottom of your telephone. For procedures on
answering and placing calls with the adjunct speakerphone, refer to the instructions
that came with the equipment.
To answer a call
To answer a call using
the speakerphone (for
8110 users)
[ Spkr ] . Pressing [ Spkr ] simultaneously activates the built-in microphone so
1
Pick up handset
2
Speak to other party
1
When you hear the telephone ring,
[ Spkr ]
press
●
Red light next to [ Spkr ] goes on
■
To place a call
To place a call using the
speakerphone (for 8110
users)
Speak to other party
2
1
Pick up handset
2
Dial desired number
1 While on-hook, press [ Spkr ]
●
Red light next to [ Spkr ] goes on
Dial desired number
2
[dial tone]
[dial tone]
13
To end a call
1
Hang up handset
or
if you are using the speakerphone,
[ Spkr ]
press
●
Red light next to [ Spkr ] goes off
Auto Answer (for 8110 Users)
■
Note: If you are using the 8110 telephone with a DEFINITY Generic 1 system, the
line must be assigned as “Data Restricted” in order for the Auto Answer feature to
work properly on your telephone. Contact your system manager to have the “Data
Restricted” feature assigned to your line.
To use the Auto Answer
feature so your telephone
automatically answers
incoming calls
1 While handset is on-hook, press [ Auto ]
●
Button released to the “up” position
●
Colored area under button will remind you that
the Auto Answer feature is active
2
When a call comes in, the built-in speakerphone on
your telephone is automatically activated
●
Both you and the other party hear a full ring and
then a short burst of tone
●
Red light next to [ Spkr ] goes on
3 Speak to caller
4
When caller ends the call, 8110 telephone hangs up
automatically
or
You can press [ Spkr ] to end call
●
The 8110 telephone is now ready for next
Auto Answer call
14
To turn off the Auto
Answer feature
temporarily
1
Press [ Auto ]
●
Button reverts to “down” position
You may also choose to disable the Auto Answer button (
[ Auto ] ) so that it cannot be
activated accidentally. Follow the following procedure to remove the Auto Answer
button and cover the opening from which you removed the button.
Note: In order to complete this procedure, you must use the slot cover which is
shipped in the box with the telephone.
1
To disable the Auto
Answer button so that it
cannot be used
Press [ Auto ] so that the button is in the “up” position
2
Lift the button from its slot on the face of the
telephone
3
Take the slot cover (provided with the telephone) and
place it in a horizontal position in the empty slot. Be
sure that the cap is flush with the face of the
telephone.
Hold
Note: If you want to place or answer another call or activate another feature while
you have a call on hold, you can use the System Feature, Hold (with Second Dial
Tone). For directions on using this feature, see “Hold (with Second Dial Tone)”
under the section, System Features.
1
Press
[
Hold
To put a call on hold
To return to the held call
●
Red light next to button goes on; call is on hold
●
You may hang up handset; the call remains on
hold
1
Press [ Hold ]
or
if you have hung up the handset, pick up handset
again from the cradle
●
Red light next to button goes off; you are
reconnected to other party
or
]
■
15
2
If you are using an 8110 telephone, press [ Spkr ]
●
Red light next to [ Spkr ] goes on; red light next to
the PAUSE button goes off
●
You are reconnected to other party
Message
To retrieve a message
when your Message light local message retrieval procedures
is blinking
1 See your system manager for instructions about your
Note: The message light also flashes when a call is
coming in (that is, when the telephone is ringing).
Mute (for 8110 Users)
■
■
To prevent the other
party from hearing you
(To mute microphone)
To resume talking to the
other party (To turn on
microphone again)
1
Press [ Mute ]
●
Red light next to [ Mute ] goes on
●
Other party cannot hear you
1
Press [ Mute ]
●
Red light next to [ Mute ] goes off
2
Resume conversation with other party
16
Personalized Ring (for 8102 and 8110 Users)
The tone selector labeled HI--LO will help you select one of two tone-ringer
frequencies. Slide the tone selector to HI for a higher frequency; slide the tone
selector to LO for a lower frequency.
The tone selector labeled FAST--SLOW will help you select one of two tone-ringer
modulation rates. Slide the tone selector to FAST for a faster modulation rate; slide
the tone selector to SLOW for a slower modulation rate.
The 3-position switch on the side of your telephone allows you to control the volume
for the tone ringer.
●
Slide it up (away from you) for a louder ring.
●
Slide it down (toward you) for a quieter ring.
■
Programmable Dialing Buttons (8102 and 8110)
The 12 programmable dialing buttons are provided for one-touch dialing of
frequently dialed telephone numbers. You can also store emergency numbers, such
as 911, and feature codes on these buttons.
Shipped with each telephone is a button designation card on which you can write the
names or numbers or codes stored on each of the programmable dialing buttons. Use
the procedure directly below to remove the plastic cover on the front of your
telephone and place the designation card under it.
Note: You can program up to 20 elements (digits and characters such as a # or *) on
a programmable dialing button. If the number you want to store is longer than 20
elements, you can do one of the following:
●
Store up to 20 elements on one button; store the remainder of the elements on a
second button. To place a call using these buttons, press the first button; when
all of the elements have been dialed, press the second button in the sequence.
●
Store up to 20 elements on one button; dial the remainder of the digits and
characters manually.
■
Important: Some environments may want to disable the PROGRAM and PAUSE
buttons so that the programmable dialing buttons cannot be reassigned. To remove
and cover these two buttons and the two topmost programmable dialing buttons, you
will need to use the 8102 and 8110 Telephones D-Kit (D182363), COMCODE
106248370. This kit includes a plastic cover and a special button designation card to
fit over these buttons.
17
To insert the button
designation card on your
telephone
1
If you are using a new telephone, remove the button
designation card from the box in which the telephone
was shipped
2
In the blank space next to the appropriate
programmable dialing button, write or type the name
or telephone number you want to store
3
Fold along the perforated edge(s) and detach the
card(s) from the sheet
4 Remove the plastic cover by placing your finger in
the finger slot on the right side of the telephone and
lifting up
Place the designation card on the telephone. Replace
5
the plastic cover over the designation card by fitting
the cover’s bottom tabs into the slots on the
telephone and pressing down, allowing the tabs on
the top to snap into place
To program any of the 12
programmable dialing
buttons (while on-hook)
Press the PROGRAM button to enter programming
1
mode
●
You hear a low continuous tone while you are in
programming mode
Press programmable dialing button on which you
2
want to store the number
●
Tone is briefly interrupted twice
Dial number you want to program on the button.
3
You can use up to 20 elements (digits and characters,
including Pause and Flash)
●
The tone to remind you that you are in
programming mode is interrupted at each time
you press a dial pad key, the PAUSE button or
[ Flash ]
●
You hear a rapid error tone if you try to enter
more than 20 elements
●
You can use the PAUSE button to program a
.5-second pause between a dialing access number,
such as 9, and the telephone number, and for
certain banking and long-distance services.
18
For example, to put a pause between the dialing
access number, 9, and the telephone number,
press the PAUSE button, then 12125551234 .)
Several depressions of the PAUSE button will
produce a multiple of a .5-second pause. (Three
depressions of the PAUSE button would equal 1.5
seconds.)
●
Programmable dialing buttons can also be used to
program system features. See your system
manager for system feature codes.
4
To program another programmable dialing button,
repeat Steps 2 and 3
5
Press the PROGRAM button when you are ready to
exit programming mode
To dial a number with a
programmable dialing
button
To erase a number stored
on a programmable
dialing button
Redial
Pick up handset
1
or
if you are using an 8110 telephone,
you can press
2
When you hear a dial tone, press the appropriate
programmable dialing button
●
Number programmed on the button is
automatically dialed
1
Press the PROGRAM button
2
Press button to be cleared twice
3
Press the PROGRAM button
or
lift handset
[ Spkr ]
■
To automatically redial
the last number you
dialed (from the dial pad)
Pick up handset
1
or
if you are using an 8110 telephone, you can
[ Spkr ]
press
Press [ Redial ]
2
●
Number is automatically redialed
Note: You will hear a rapid error tone if the
dialed number is longer than 20 elements.
[dial tone]
19
Redial (With Auto-Pause) (8102 and 8110 Users)
■
To program an automatic
pause for redialed
numbers
While the telephone is on-hook,
1
press the PROGRAM button
2
Press [ Redial ]
3
Press the appropriate access code and number of
pauses in order to insert a long enough waiting time
to obtain a second dial tone.
For example, if you need two pauses inserted
between the access code, such as 9, and the
remainder of the telephone number you are dialing,
you would press the PAUSE button twice
Note: You may store up to three different access
code or pause combinations. Each code can have up
to three characters and up to four pauses.
4
Press the PROGRAM button again
[programming tone]
EXAMPLE: In the following example, there are three different access code or pause
combinations.
1
Press the PROGRAM button
Press [ Redial ]
2
Dial 9 and then press the PAUSE button three times
3
(PAUSE PAUSE PAUSE). Since each depression of
the PAUSE button adds .5 seconds of waiting time,
this initial access code (three depressions of the
PAUSE button) is 1.5 seconds.
Dial *9 (the second access code needed in the dialing
4
sequence in this example) and then press the PAUSE
button twice (PAUSE PAUSE)
Dial *8 (the third access code needed in this
5
sequence) and then press the PAUSE button four
times (PAUSE PAUSE PAUSE PAUSE)
[programming tone]
20
6
Press the PROGRAM button again
The access code sequence is stored for redialing
●
at a later time. Now, when you press
redial a call using one of the above access code or
pause combinations, the telephone will
automatically insert the correct number of pauses
(three in this example) to ensure waiting the
appropriate length of time to obtain a second dial
tone.
[ Redial ] to
To erase all stored access
1
Press the PROGRAM button
codes
2
Press [ Redial ] twice
3
Press the PROGRAM button again
Speakerphone (for 8110 Users)
To place or answer a call 1
without lifting the
handset
Press [ Spkr ]
●
Red light goes on next to button
Place or answer call
2
●
Adjust speakerphone volume with sliding arm on
right of set
[programming tone]
■
To prevent the other
party from hearing you
(To mute microphone)
Press [ Spkr ] again to hang up
3
●
Red light goes off
1
Press [ Mute ]
●
Red light next to [ Mute ] goes on
●
Other party cannot hear you
21
To resume talking to
other party (To turn on
speakerphone
microphone again)
To change from
speakerphone to handset
To change from handset
to speakerphone
1 Press [ Mute ]
●
Red light next to [ Mute ] goes off
2
Resume conversation with other party
1
Lift handset and talk
●
Red light goes off next to [ Spkr ]
1
During a call using handset, press [ Spkr ]
●
Red light goes on next to [ Spkr ]
2
Hang up handset
22
System Features
Since your 8101, 8102, or 8110 telephone is connected to a DEFINITY Generic 1 or
System 75 or Generic 2 or System 85 communications system, you may be able to use
some of the following features. Check with your system manager to see which of
these features have been assigned to your telephone, as well as what other features
may be available to you with additional systems.
Special Instructions
The first time you use these procedures, you will need to customize them for your use
by following these directions: (Your system manager can supply any information
required.)
To the right of each of the feature name is a box. For each feature available on
●
your telephone, make a check in the blank box as a reminder. There is already
a check in the box beside the Conference, Drop, Hold (With Second Dial Tone)
and Transfer features.
●
You can activate or cancel most of the features by dialing 2- or 3-digit codes. In
the blanks provided within the procedures, write in the assigned feature code
numbers.
Note: You can store these feature codes (including Flash) on programmable
dialing buttons.
●
Step 1 in most procedures gives you two options. Follow the first option if the
named feature is listed on your directory; follow the second option (in gray
type) if it is not.
●
System 75 is available in more than one version. In some cases, a feature
operates differently with Version 1, and sometimes Version 2, than it does with
later versions; where this occurs, the procedures include a Version Note with
directions for using Version 1 or Version 2, or for using Version 3 and
DEFINITY Generic 1. Be sure to follow the directions corresponding to the
version you are using.
Abbreviated Dialing
Note: Both the 8102 and the 8110 telephones have 12 programmable dialing buttons
on which you can store telephone numbers or access codes. In addition, DEFINITY
Generic 1 and System 75 allow you to store numbers in a maximum of three
Abbreviated Dialing lists.
1
To program or reprogram
an outside number,
extension, or feature code
into a personal list
On a separate sheet of paper, jot down the outside
numbers, extensions, and/or feature codes you want
to program as items on your personal list(s)
■
23
Note: Each telephone number or feature code is
stored as a separate list item.
2
Pick up handset
3
Dial Abbreviated Dialing Program code
4
Dial personal list number (1, 2, or 3)
Version Note: If you are using System 75,
Version 1, you may omit Step 4.
5
Dial list item
6
Dial number you want to program
(1, 2, 3...)
Version Note: If you are using System 75,
Version 1, you can use up to 16 digits;
for Version 2, you can use up to 24 digits.
Note: If you are programming an outside number,
be sure to include a trunk code, if applicable.
7
Press [ # ]
●
Number is stored
[confirmation tone]
[dial tone]
[dial tone]
[dial tone]
To place a call using a
personal, group, system,
or enhanced list
●
Repeat Steps 5 through 7 if you want to program
additional items on the same list; hang up and
begin again at Step 1 if you want to program
items on another personal list
Hang up to end programming
8
Note: Keep your own personal lists in the
Abbreviated Dialing table provided in the back of
this booklet; group, system, and enhanced lists are
available from your system manager.
1
Dial appropriate Abbreviated Dialing List code:
●
List 1
●
List 2
●
List 3
2 Dial desired list item (1, 2, 3...)
●
Stored number is automatically dialed
[dial tone]
24
Automatic Callback
■
To automatically place
another call to an
extension that was busy
or did not answer
1
Press [ Flash ] during call attempt
[recall dial tone]
2
Dial the Automatic Callback code
[confirmation tone]
3
Hang up
●
You will receive a 3-burst priority ring when the
extension you attempted to call is available
Note: After you activate Automatic Callback, the
system monitors the called extension. That
extension becomes available after the called party
completes a call.
4
Lift handset when you hear priority ring
[ringback tone]
●
A call is automatically placed to extension, which
receives regular ringing
Note: You can place only one Automatic Callback
call at a time, and Automatic Callback is canceled
after 30 minutes or if the callback call goes
unanswered.
To cancel an
Automatic Callback
request
Dial Automatic Callback Cancel code
1
Call Forwarding All Calls
1
To temporarily redirect
all calls to an extension
or outside number
of your choice
Dial Call Forward code
Version Note: If you are using System 75,
Version 3, or DEFINITY Generic 1, next dial the
extension number whose calls are to be forwarded,
although you must first have console permission.
2
Dial extension or number where calls will be sent
Version Note: If you are using System 75,
Version 1, calls can be forwarded only to another
extension, not to an outside number.
[confirmation tone]
■
[dial tone]
[confirmation tone]
25
Note: Some telephones may have restrictions on
where calls can be forwarded (see your system
manager).
3
Hang up
Note: You may hear a ring-ping tone as each call is
forwarded.
To cancel
Call Forwarding
Call Park
1
Dial Call Forward Cancel code
●
Your calls will ring at your own telephone again
[confirmation tone]
■
To park a call at your
extension (for retrieval at
any extension)
To retrieve parked call
from any extension
Press [ Flash ]
1
2
Dial Call Park code
[recall dial tone]
[confirmation tone]
●
Call is parked at your extension
Note: To return to the parked call before you hang
up, press
Hang up
3
1
Dial Answer Back code
2
Dial extension where call is parked
[ Flash ] again.
[confirmation tone]
●
If you are returning to a call parked at your
telephone, dial your own extension
●
You are connected to parked call
[dial tone]
26
Note: If you receive intercept tone, the parked call
has been disconnected or retrieved by someone else.
Call Pickup
To answer a call to a
member of your pickup
group when your
telephone is idle
To pick up a call while
you are active on
another call
1
Dial Call Pickup code
●
You are connected to ringing call
1
Press [ Flash ]
2
Dial Hold code
●
Present call is put on hold
3
Dial Call Pickup code
●
You are connected to call
■
[recall dial tone]
[dial tone]
To return to a held call 1
Call Waiting
To answer a call
waiting tone
To answer a call waiting
tone, putting your
present call on hold
Complete present call and hang up
●
Held call sends 3-burst priority ring
2
Lift handset
●
You are connected to held call
1 Complete present call and hang up
●
Receive ringing from waiting call
(1
-- internal, 2 -- outside, 3 -- priority)
2
Pick up and answer
1
Press [ Flash ]
●
Present call is put on hold
2
Dial Hold code
■
[recall dial tone]
27
●
You are connected to waiting call
To return to held call
Conference
To add a third party
to a call
1
Complete present call and hang up
●
Held call sends 3-burst priority ring
2
Lift handset
●
You are connected to held call
1
Press [ Flash ]
●
Present call is put on hold
2
Dial number of third party
[recall dial tone]
Note: You can privately discuss the call with the
third party at this time; if no answer or busy, press
[ Flash ] twice to return to original party.
3
Press
[
Flash
]
■
●
All parties are now connected
1
Press
[
Flash
To drop third party
●
You remain connected to original party
]
Drop (for 8102 and 8110 Users)
1
To disconnect from a
normal call, or to drop
the last party added to a
conference call
Press the button you have programmed as [ Drop ]
■
28
Hold (with Second Dial Tone)
Note: The following feature allows you to place or answer another call or activate
another feature while you have a call on hold. If you want merely to put a call on
hold while you are busy with another task (and do not need to answer or place
another call), press
call, press
[ Hold ] again. See “Hold” in the section titled Phone Features.
Version Note: If you are using System 75, Version 1, use these directions:
[ Hold ] on your telephone. When you want to return to the held
■
To put a call on hold
To return to held call
To put call 1 on hold
and place call 2
1
Press [ Flash ]
Note: Do not hang up or call will be dropped.
1
Press [ Flash ] twice
1
Press [ Flash ]
●
Call 1 is put on hold
Dial call 2 (or another feature)
2
[recall dial tone]
[recall dial tone]
To put call 2 on hold
and return to call 1
To complete call 2
and return to call 1
1 Press [ Flash ]
●
Call 2 is put on hold
[recall dial tone]
2 Press [ Flash ] twice
●
Call 1 is reconnected
After party on call 2 hangs up, press [ Flash ] twice
1
●
Call 1 is reconnected
29
Version Note: If you are using System 75, Version 2, Version 3, or DEFINITY
Generic 1, the following directions apply:
To put a call on hold
To return to held call
To put call 1 on hold and
place call 2
1
Press [ Flash ]
2
Dial Hold code
[recall dial tone]
Note: If you hang up, held call sends a 3-burst
priority ring.
Hang up, receive 3-burst priority ring, and lift
handset
1
Press [ Flash ]
2
Dial Hold code
●
Call 1 is put on hold
Dial call 2 (or another feature)
3
[recall dial tone]
[dial tone]
[dial tone]
To put call 2 on hold
and return to call 1
To complete call 2 and
return to call 1
Note: If you hang up, call 1 sends a 3-burst priority
ring.
1
Press [ Flash ]
2
Dial Hold code
●
Call 2 is put on hold, and call 1 is reconnected
[recall dial tone]
Note: If you hang up, call 2 sends a 3-burst priority
ring.
1 After party on call 2 hangs up, hang up, receive
3-burst priority ring, and lift handset
30
Leave Word Calling
■
To leave a message after
dialing an extension
(when your call is not
answered, you hear
coverage or busy tone, or
you have been put on
hold)
To leave a message
without ringing an
extension
1
Press [ Flash ]
2
Dial Leave Word Calling code
●
Message light goes on at called telephone
Note: If reorder tone is heard, the message is not
stored; try again.
1
Dial Leave Word Calling code
2
Dial the extension
Message light goes on at called telephone
[recall dial tone]
[confirmation tone]
[confirmation tone]
[dial tone]
To cancel a
Leave Word Calling
message
Note: You cannot cancel
a message left for an
AUDIX subscriber).
Priority Calling
To place a priority call
1 Dial Leave Word Calling Cancel code
2
Dial extension
Note: If reorder tone is heard, the message is not
deleted; try again.
1
Dial Priority Calling code
2
Dial extension
[confirmation tone]
[dial tone]
■
[dial tone]
31
Send All Calls
■
To send all incoming calls
(except priority calls)
immediately to coverage
To cancel
Send All Calls
1
Dial Send All Calls code
[confirmation tone]
2
Hang up
Note: You may hear a ring-ping tone from your
telephone as each call is sent to coverage.
1
Dial Send All Calls Cancel code
[confirmation tone]
●
Your calls will ring at your own telephone again
Transfer
To send present call to
another extension or
outside number
Press [ Flash ]
1
●
Present call is put on hold
Dial number that call is to be transferred to
2
[ringback tone]
●
Remain on line and announce call; if number
dialed is busy or not answered, press
twice to return to held call
Note: Only calls from another extension can be sent
to an outside number; you cannot transfer a call from
an outside number to another outside number.
Hang up
3
●
Transfer is completed
[recall dial tone]
[ Flash ]
■
32
Voice Message Retrieval
Version Note: If you are using System 75, Version 1, you cannot use this feature.
■
To retrieve your voice
messages when your
Message light is on
1 Dial Voice Message Retrieval code
[dial tone]
2 Press [ # ]
Note: Do not press [ # ] if calling from another
extension; instead, dial your own extension and your
security code, if required.
3
Move through messages with these dial pad buttons:
(Press
[ # ]
[ 3 ]
[ 4 ]
[ 5 ]
[ 8 ]
When you call back an extension with
to also delete the message by pressing
press
storage.
[ # ] to retrieve first message)
NEXT (read next message)
DELETE (erase from storage)
HELP (request assistance)
REPEAT (read message again)
CALL (call back named extension)
[ 8 ] ; otherwise the message will remain in
[voice prompting]
[ 8 ] , be sure
[ 3 ] before you
To retrieve voice
messages for a coworker
4
Hang up to end Voice Message Retrieval
1 Dial Voice Message Retrieval Coverage
code
2
Dial coworker’s extension
Note: If you receive an intercept tone, see your
system manager for further instructions.
3
Move through the messages with dial pad buttons
previously listed
4
Hang up to end Voice Message Retrieval
[voice prompting]
[dial tone]
33
Tones and Their Meanings
Ringing tones are produced by an incoming call. Handset tones are those which
you hear through the handset (receiver).
Ringing Tones
●
1 ring
●
2 rings
●
3 rings
call you placed.
●
ring-ping (half ring)
Send All Calls or Call Forwarding All Calls is active.
Handset Tones
●
auto answer tone
Auto Answer feature is active.
●
busy tone
number dialed is in use.
— A call from another extension.
— A call from outside or from the attendant.
— A priority call from another extension, or from an Automatic Callback
— A call redirected from your telephone to another because
— A short burst of tone immediately following a ring when the
— A low-pitched tone repeated 60 times a minute; indicates the
●
call waiting tone
— One, two, or three beeps of high-pitched tone, not repeated;
indicates an incoming call is waiting to be answered. Number of beeps designates
the source: one for an internal call, two for an outside or attendant call, three for
a priority call.
●
call waiting ringback tone
— A ringback tone with a lower-pitched signal at the
end; indicates that the extension called is busy, but the called party has been
given a call waiting tone.
●
confirmation tone — Three short bursts of tone; indicates a feature activation or
cancellation has been accepted.
●
coverage tone — One short burst of tone; indicates your call will be sent to
another extension to be answered by a covering user.
●
dial tone
●
intercept/time-out tone — An alternating high and low tone; indicates a dialing
— A continuous tone; indicates dialing can begin.
error, denial of the service requested, or a failure to dial within a preset interval
(usually 10 seconds) after lifting the handset or dialing the previous digit.
●
programming tone
— A low continuous tone when you are in programming mode
(programming a programmable dialing button).
●
recall dial tone
— Three short bursts of tone followed by a steady dial tone;
indicates the feature request has been accepted and dialing can begin.
●
reorder tone
— A fast busy tone repeated 120 times a minute; indicates all
trunks are busy.
●
ringback tone
— A low-pitched tone repeated 15 times a minute; indicates the
number dialed is being rung.
34
Key Words to Know
activate To begin or turn on the operation of a feature.
attendant The person who handles incoming and outgoing calls at the main
console.
AUDIX (Audio Information Exchange) An optional voice mail and message service
that provides coverage for calls to you by recording callers’ messages and reporting
Leave Word Calling messages.
coverage Automatic redirection of calls from an unanswered telephone to another
telephone. Redirection could be to the extension of a receptionist, secretary,
coworker, AUDIX, or message center. A person who provides coverage is a covering
user.
dial pad The 12 pushbuttons you use to dial a number and access features.
enhanced list One of the four types of Abbreviated Dialing lists; programmable
only by the system manager (and available only with System 75 Version 3). Contains
telephone numbers useful to all system members, and stores each of those numbers
as a 3-digit list item.
extension A dialing number of one to five digits assigned to each telephone
connected to your System 75.
feature A special telephone function or service, such as Conference, Hold, Send All
Calls, etc. A fixed feature already appears on your telephone and can be used
immediately. A system feature can be used only if the telephone is connected to a
DEFINITY Generic 1 or System 75 and if the feature has been assigned to your
telephone by your system manager.
feature code A dial code of one, two, or three digits you use to activate or cancel
the operation of a feature.
group list One of the four types of Abbreviated Dialing lists; programmable only by
the system manager. Contains telephone numbers useful to members of a specific
group, and stores each of those numbers as a 2-digit list item.
handset The handheld part of the telephone that you pick up, talk into, and listen
from. Also known as the receiver.
party A person who places or receives a call.
personal list One of the four types of Abbreviated Dialing lists; programmable by
the system manager or by you, the user. Contains telephone numbers of your choice,
and stores each of them as a single-digit list item.
personal list item One of the 10 available slots on an Abbreviated Dialing personal
list. The first nine personal list items are given digits 1 to 9, with 0 for the tenth
item.
phone features Those telephone features you can use immediately no matter which
communications system your telephone is behind.
35
pickup group A group of telephone users who can answer calls for each other
through the Call Pickup feature. Group members are determined by the system
manager and are usually located in the same work area or perform similar job
functions.
priority call An important or urgent call that sends a special 3-burst ring.
program/reprogram To use your dial pad to assign a telephone number to a
personal list item for Abbreviated Dialing.
retrieve To collect telephone messages with the Message or Voice Message
Retrieval features. (Also, with Call Park, to resume a call from an extension other
than the one where the call was first placed or received.)
ringer The device that produces the electronic ringing sound in your telephone.
stored number A telephone number that has been programmed and stored as a
1-, 2-, or 3-digit list item for use with Abbreviated Dialing. It can be a complete or
partial telephone number, an extension number, or a trunk or feature code. Once
programmed, a number can be accessed by first dialing the list, then the list item
digit(s) under which it is stored.
system The device that makes connections for all voice and data calls for a
network, and also contains software for features. Also known as a switch,
switching system, or PBX (private branch exchange). (Your switch is an AT&T
System 75 or 85.)
system features Those features you can use only if your telephone is connected to
a System 75 (or 85) or DEFINITY Generic 1 (or 2) switching system.
system list One of the four types of Abbreviated Dialing lists; programmable only
by the system manager. Contains telephone numbers helpful to all system users,
and stores each of those numbers as a 2-digit list item.
system manager The person responsible for specifying and managing the
operation of features for all the voice and data equipment in your network.
System 75 or 85 The AT&T system to which you are connected. It transmits and
receives voice and data signals for all communications equipment in your network.
trunk A telecommunications channel between your System 75 and the local or long
distance calling network. Trunks of the same kind connecting to the same end points
are assigned to the same trunk group.
trunk code A dial code of one, two, or three digits that you dial to access a trunk
group to place an outside call.
36
Quick Reference Lists
Feature Codes
Feature
ABBREVIATED DIALING
List 1
List 2
List 3
Program
AUTOMATIC CALLBACK
Cancel
CALL FORWARDING
ALL CALLS
Cancel
CALL PARK
Answer Back
Code
Feature
CALL PICK UP
HOLD
(System Feature)
LEAVE WORD CALLING
Cancel
PRIORITY CALLING
SEND ALL CALLS
Cancel
VOICE MESSAGE RETRIEVAL
Coverage
Code
Trunk Codes
Abbreviated Dialing*
Description
Code
Miscellaneous
Description Extension
Message
Attendant
Personal List 1
Item
No.
1
2
3
4
5
6
7
8
9
0
* You may have as many as 3 personal lists, and each list can
have either 5 or 10 items; see your system manager.
Name Name Name
Personal List 2
Personal List 3
AT&T 555-230-746
Issue 2
December 1993
Graphics © AT&T 1988
Loading...
