User’s manual
EP562
Expansion 5.8 GHz digital
cordless handset
For use with the AT&T EP5632/
EP5632-2 telephone system with
BLUETOOTH® wireless technology
Congratulations
on purchasing your new AT&T product.
Please read this user’s manual for the information
necessary to install your new AT&T product. For
complete instructions, please refer to the manual
provided with your EP5632/EP5632-2 telephone,
which can be downloaded from our website at
www.telephones.att.com or call
1 (800) 222-3111.
In Canada dial 1 (866) 288-4268.
Model #: EP562
Product name: 5.8GHz expansion digital cordless handset
Serial #:
(found on the bottom of the charger)
Purchase date:
Place of purchase:
The ENERGY STARR program (www.energystar.gov)
recognizes and encourages the use of products that
save energy and help protect our environment. We
are proud to mark this product with the ENERGY
STARR label indicating it meets the latest energy
efficiency guidelines.
© 2007 Advanced American Telephones. All rights reserved.
AT&T and the AT&T logo are trademarks of AT&T Intellectual Property II, L.P. d/b/a
AT&T Intellectual Property licensed to Advanced American Telephones.
The BLUETOOTH® word mark and logos are owned by Bluetooth SIG, Inc. and
any use of such marks by Advanced American Telephones and its parent,
VTech Holdings Limited, is under license. VTech Holdings Limited is a member
of Bluetooth SIG, Inc. Other trademarks and trade names are those of their
respective owners.
Before you begin
you must install and charge the battery,
see page 2 for Battery installation instructions.
Please read and follow these instructions carefully:
• Use only the supplied rechargeable battery or
replacement battery.
• Observe the proper polarity orientation between the
battery and handset during the battery installation.
• Do not dispose the battery in a fire. Check with
local codes for special disposal instructions.
• Do not open or mutilate the battery. Released
electrolyte is corrosive and may cause damage to
the eyes or skin. It may be toxic if swallowed.
• Exercise care in handling batteries in order not to
create a short circuit with conductive materials such
as rings, bracelets, and keys. The battery or
conductor may overheat and cause harm.
• Charge the supplied battery or replacement battery
with this product only in accordance with the
instructions and limitations specified in this manual.
• Do not disassemble your telephone. There are no userserviceable parts inside. Refer to qualified service
personnel for servicing.
Getting started
BA
TTER
Y
PA
CK
80-5808-00-00
Parts checklist
Save your sales receipt and original packaging in case it is
necessary to return your telephone for warranty service.
Your new AT&T EP562 expansion handset includes:
Cordless
Handset battery
telephone
handset
User’s manual
EP562
Expansion 5.8 GHz digital
cordless handset
For use with the AT&T EP5632/
EP5632-2 telephone system with
BLUETOOTH® wireless technology
User's manual
Table of contents
Getting started
Battery installation.......................2
Battery charging............................3
Adding your new
handset..............................................4
Replacing a handset....................5
Quick reference
guide...................................................6
Handset main menu....................7
Belt clip & optional headset...8
compartment
Charger
Appendix
1
Belt clipHandset battery
cover
Power adapter for
charger
Troubleshooting.......................9
Technical
specifications.........................14
Important safety
information..............................15
FCC..............................................19
Limited warranty...................22
Getting started
BA
TTER
Y
PA
CK
80-5808-00-00
Battery installation
Install the battery as shown below. After installing the battery, you
need to register the handset with the telephone base (page 4).
Once registered, you can make and receive short calls. For optimal
performance, charge the handset battery for at least 16 hours
before use (page 3).
1. Press the tab and
slide the battery
compartment
cover downwards
(if necessary).
2. Insert the supplied
battery as
indicated. Insert
the top edge
(contacts and tab)
in first, then push
downwards on the
3. Align the cover
flat against
the battery
compartment
cover, then slide
it upwards until it
clicks into place.
lower portion of
the battery.
IMPORTANT INFORMATION
•
Use only the battery supplied with this product. To order a
replacement battery (AT&T model 103, part number 89-042900-00) or equivalent, visit our website at
www.telephones.att.com, or call 1 (800) 222-3111.
In Canada, dial 1 (866) 288-4268.
2
Getting started
Battery charging
For optimal performance, charge the handset battery for at least
16 hours before use. When fully charged, the handset battery
provides approximately five hours of talk time and three days of
standby time.
Electrical outlet
not controlled
by a wall switch
Power adapter
Charger
1. Plug the small
end of the power
adapter into
the jack on the
underside of the
2. Plug the large
end of the power
adapter into an
electrical outlet.
3. Place the handset
in the charger.
The CHARGE
light will be on
when charging.
charger, then
route the cord
through the shot
as shown.
IMPORTANT INFORMATION
• Use only the power adapter supplied with this product. To
order a replacement power adapter, visit our website at
www.telephones.att.com, or call 1 (800) 222-3111. In
Canada, dial 1 (866) 288-4268.
• The power adapter is intended to be correctly oriented in a
vertical or floor mount position. The prongs are not designed to
hold the plug in place if it is plugged into a ceiling, under-thetable or cabinet outlet.
3
Getting started
Adding your new handset
Before using a newly purchased handset (EP562), it must be
registered with the telephone base. If you already have 12
handsets registered to the same telephone base and you wish to
replace your newly purchased handset with another, see page 5.
Register Handset
12:00AM
Place in
Charger
12:00AM
Register handset:
Press MENU in the
base. Find 'Register
Handset' in the main
menu. Press SELECT.
12:00AM
Registration
in progress...
Before registering an additional handset
(EP562), make sure that the handset
battery is installed and charged.
To register a new handset:
1. Place the unregistered handset in the
telephone base or charger.
2. Press the MENU softkey on the
telephone base while in idle mode.
3. Press the UP and DOWN NavKeys to toto
highlight Register Handset, then press
the SELECT softkey.
•
Registering Handset will appear
on the telephone base display.
•
Registration in progress... will
appear on the handset display.
•
The registration process may take
up to 90 seconds to complete.
When the registration is complete, the
newly registered handset will be assigned
the next available handset registration
number. For instance, if you already have
HANDSET 1 and HANDSET 2, the next
registered handset will be HANDSET 3.
If you experience difficulty registering
a handset, see the Troubleshooting
section on page 9.
4
Getting started
NOTE: If you replace
a registered handset,
the new handset will
be assigned the next
available registration
number, rather than the
handset number of the
handset you will replace.
Replacing a handset
When you are replacing rather than
adding a handset, for your handsets to
be numbered sequentially, you need to
delete all the handset registrations on
the telephone base.
To delete all the handset registrations:
Settings
Clear Voice Mail
Default Settings
Delete Handsets
SEL ECT
Delete Handsets
Delete Registration
of all handsets?
YES
NOTE: After deletingAfter deleting
the handset registrations,
each handset will reset and
Place in Charger will appear
on the handset display.
NO
1. Press the MENU softkey on the
telephone base in idle mode to enter
to the main menu.
2. Press the UP and DOWN NavKeys to
select Settings, then press the SELECT
softkey to enter the Settings menu.
3. Press the UP and DOWN NavKeys
to highlight Delete Handsets, then
press the SELECT softkey. The screen
will show Delete Registration of all
handsets?
4. Press the YES softkey.
After deleting the registrations of all
handsets, you will need to individually
register each handset with the telephone
base (see page 4 for registration
instructions).
5
Getting started
Quick reference guide
Handset
Status light
Flashes rapidly during an
incoming call, and when
there is a new voice mail
message or new message
in the answering system.
Softkeys (2)
Press to select a menu
item displayed just above
the key.
HOME/FLASH
Press to make or answer a
HOME call.
Flashes rapidly when there rapidly when there
is an incoming HOME call.
and when a HOME call is
on hold.
SPEAKER
Press to activate the
handset speakerphone.
The SPEAKER key is lit
when the speakerphone
is on
12:00AM
REDIAL
HANDSET 1
CALLER ID
VOLUME
Press to adjust handset
listening volume while on
a call.
OFF/CANCEL
During a HOME or
CELLULAR line call, press
to end the call.
While in a menu, press to
cancel an operation, back
up to the previous menu,
or exit the menu display.
MENU/SELECT
Press to enter the main
menu (page 7).
Press to select, save, or set a
desired setting.
CELLULAR
Press to make or answer a
CELLULAR call.
Flashes when there is an
incoming CELLULAR call or
when a CELLULAR call is
on hold.
NavKeys
(in brackets)
Press the UP, DOWN,
LEFT or RIGHT
NavKeys to navigate
through the menus,
highlight items, and
change settings.
Int'com
(LEFT)
Settings
(UP)
Directory
(DOWN)
6
Msgs.
(RIGHT)
Quick launch keys
When in idle mode, press
one of the NavKeys
to launch a handset feature:
• Settings (UP)
• Directory (DOWN)
• Intercom (LEFT)
• Messages (RIGHT)
