AT&T 210 BLK, ATCL2940, 210WH User Manual

User’s manual

CL2940 Big button/big display telephone

with speakerphone/caller ID/ call waiting

Congratulations

Compatible with

Hearing Aid T-Coil

TIA-1083

on your purchase of this AT&T product. Before using this AT&T product, please read Important safety information on page 43 of this user’s manual. Please thoroughly read the user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Model number: CL2940 Type: Big button/big display telephone with speakerphone/caller ID/

call waiting Serial number: ___________________________________________________________ Purchase date: ___________________________________________________________ Place of purchase: _______________________________________________________ Both the model and serial numbers of your AT&T product can be found on the

bottom of the telephone base. Save your sales receipt and original packaging in case it is necessary to return

your telephone for warranty service.

Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

Audio Assist® is a registered trademark of Advanced American Telephones.

Parts checklist

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

Handset

Mounting bracket

Quick start guide

CL2940

Big button/big display telephone with speakerphone/caller ID/ call waiting

Telephone base

Coiled handset cord

Telephone line cord

Quick start guide

User’s manual

CL2940 Big button/ big display

telephone with speakerphone/ caller ID/call waiting

Table of contents

Getting started

Quick reference guide ..............................1

Installation ......................................................3

Battery installation .....................................4

Telephone installation ..............................6

Installation options .....................................7

Tabletop to wall mount

installation ...........................................7

Wall mount to tabletop

installation ...........................................9

Telephone settings

Telephone settings ..................................11

Set date and time ............................... 11

Contrast ...................................................12

Dial mode ............................................... 12

Language ................................................ 13

Home area code .................................. 13

Local area code ................................... 14

Telephone operation

Telephone operation...............................15

Making a call .........................................15

On hook dialing (predialing)..........15

Answering a call .................................. 15

Ending a call ..........................................15

Speakerphone ....................................... 15

Last number redial ............................. 16

Ringer volume ......................................16

Options while on call ............................. 17

Volume control .....................................17

Call waiting ............................................ 17

Mute ...........................................................17

Chain dialing ......................................... 18

Audio Assist® ......................................... 19

Temporary tone dialing ....................19

Getting started

Quick reference guide

MENU/SELECT

Press to enter the main menu (page 11).

While using the menu, press to accept the current setting, and move to the next menu option (page 11).

While reviewing the call history, press to store the displayed name and number in the directory (page 33).

While reviewing the directory, press to edit the displayed entry (page 23).

CID

Press to review the call log (page 31).

While using the menu, press to scroll through the settings page 11).

While reviewing the directory, speed dial memory or caller ID history, press to scroll down (pages 22, 26 and 31 respectively).

While entering names or numbers, press to move the cursor to the left.

DELETE X

When the telephone is idle, press and hold to clear the caller ID history (page 32).

While reviewing the directory, speed dial memory or caller ID history, press to delete an individual entry (pages 24, 27 and 32 respectively).

# (pound key)

Press repeatedly to show other dialing options while reviewing a caller ID entry (page 31).

DIR

Press to enter the directory (page 22).

While using the menu, press to scroll through the settings (page 11).

While reviewing directory, speed dial memory or caller ID history, press to scroll up (pages 22, 26 and 31 respectively).

While entering names or numbers, press to move the cursor to the right.

Extra large tilt display

Adjust the viewing angle to reach maximum visibility.

CANCEL

Press to cancel an operation.

Press to return to the previous menu.

Press and hold to return to idle mode.

When the telephone is idle, press and hold to clear the missed call indicator (page 29).

SPEED DIAL

Press to access the speed dial memory (page 26).

Press to store a caller ID entry in a speed dial memory location (page 34).

FLASH

During a call, press to answer an incoming call if you subscribe to a call waiting service provided by your telephone service provider (page 17).

MUTE

During a call, press to mute the handset or speakerphone. Press again to resume your conversation (page 17).

Getting started

Quick reference guide

REDIAL/PAUSE

While using the handset or speakerphone, press to dial the last number dialed (page 16).

While the telephone is idle, press to display the last number dialed (page 16).

While entering numbers, press to insert a three-second dialing pause.

AUDIO ASSIST

Voices will sound louder and clearer if you press AUDIO ASSIST while you are on a call using the handset (page 19).

VOLUME

While on a call, press to adjust the listening volume (page 17).

RINGER VOL -/+

Slide to decrease or increase the ringer volume (page 16).

SPEAKER

Press to turn the speakerphone on or off (page 15).

INCOMING CALL light

Flashes quickly when there is an incoming call.

MUTE light

On when the microphone is muted (page 17).

SPEAKER light

On when the speakerphone is in use.

Audio Assist® is a registered trademark of Advanced American Telephones.

Getting started

Installation

Make sure to install four AA alkaline batteries (not included).

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (page 6). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the telephone base display - remove it before use.

CAUTION: To reduce the risk of fire or injury to persons or damage to the telephone, read and follow these instructions carefully:

Use only alkaline AA batteries (not included).

• Dispose of these batteries in a safe manner. Do not burn or puncture. Like

• other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

Do not open or mutilate the battery. Released electrolyte is corrosive and

• may cause damage to the eyes or skin. It may be toxic if swallowed.

Exercise care in handling batteries in order not to create a short circuit. Do

• not allow conductive materials such as rings, bracelets or keys to touch the battery. The battery or conductor may overheat and cause harm.

Use the battery identified for use with this product only in accordance with

• the instructions and limitations specified in this manual.

Observe proper polarity orientation between the battery and metallic contacts.

• Do not disassemble your telephone. There are no serviceable parts inside.

• Refer to qualified service personnel for servicing.

STOP!

See page 4 for easy instructions.

Getting started

Battery installation

Before using the telephone, you should install four new AA alkaline batteries (not included) to provide memory backup and enable the use of some features. The four AA batteries are required for the following features to work: speakerphone, mute, flash, caller ID, display, menu, directory, redial, speed dial, clock, Audio Assist® and the INCOMING CALL light.

If you unplug the telephone line cord from the telephone wall jack when there are no working batteries installed, the following information will be lost: caller ID history, directory entries, speed dial entries, and all settings in the feature menu. We recommend you install new batteries before initial use and change the batteries soon after the low battery icon appears.

CAUTION: Always unplug the telephone line cord before installing new batteries.

Press the large tabs on the battery compartment cover as the arrows

1. indicated below to open the battery compartment cover.

Detach the battery compartment cover from the telephone base.2.

Getting started

Battery installation

Insert four new AA alkaline batteries (not provided) into the battery

3. compartment, following the polarity markings.

Insert the small tabs on the battery compartment cover into the slots on the

4. battery compartment at the telephone base. Then press down on the battery compartment cover as the arrows indicated until it clicks into place.

If no batteries are installed or the batteries are depleted, you can make or answer calls using only the handset.

NOTES:

Use disposable AA alkaline batteries only. Do not use rechargeable batteries.

•

If you do not use the telephone for a long time, remove the batteries from the telephone to

• prevent possible leakage.

After replacing the batteries, you need to reset the date and time. For instructions, see Set

• date and time on page 11.

If no batteries are installed, you can only make or answer calls using the handset, however,

• you can switch to the speakerphone mode during the call by pressing SPEAKER.

Getting started

Telephone installation

Install the telephone base as shown below. If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack. The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Plug one end of the coiled handset cord into the handset jack on the left

1. side of the telephone base. Plug the other end into the jack at the bottom of the handset.

Handset

Coiled handset cord

Plug one end of the telephone line cord into the TEL LINE jack on the back

2. of the telephone base. Plug the other end of the telephone line cord into a telephone wall jack or a DSL filter.

Telephone wall jack

A DSL filter (not included) is required if you have DSL high-speed Internet service.

The DSL filter must be plugged into the telephone wall jack.

Lift the handset or press SPEAKER to check for a dial tone.

3. Adjust the angle of the tilt display to reach maximum visibility.

Getting started

Installation options

If you want to mount your telephone on a wall, use the mounting bracket provided with the package to connect with a standard dual-stud telephone wall mounting plate. If you do not have this mounting plate, you can purchase one from many hardware or consumer electronic retailers. Professional assistance may be required to install the mounting plate.

Tabletop to wall mount installation

To install the telephone base in the wall mount position, make sure you first unplug the telephone line cord from the telephone wall jack.

Put the handset aside. Hold down the switch hook on the telephone base,

1. then slide the handset tab upwards to remove it from the slot. Rotate the handset tab by 180 degrees. Then replace the handset tab into the slot until it locks into position.

Switch hook

Handset tab

Insert the protruding tab of the mounting bracket into the groove at

2. the center of the telephone base. Press down on the small tabs of the mounting bracket and snap them into the slots at the telephone base.

Getting started

Installation options

Remove the telephone line cord from the slot on the bottom of the

3. telephone base. Bundle the telephone line cord securely with a twist tie.

Plug the other end of the telephone line cord into a telephone wall jack or

4. a DSL filter.

A DSL filter (not included) is required if you have DSL highspeed Internet service.

The DSL filter must be plugged into the telephone wall jack.

Align the holes on the bottom of the telephone base with the wall

5. mounting plate. Then slide the telephone base down until it locks securely. Replace the handset in the telephone base.

Adjust the viewing angle of the tilt display for maximum visibility.6.

Getting started

Installation options

Wall mount to tabletop installation

To change the telephone base from the wall mount position to tabletop position, follow the steps below.

Slide the telephone base upwards, then remove it from the wall mounting

1. plate.

Unplug the telephone line cord from the telephone wall jack. Untie the

2. bundled telephone line cord, if necessary. Route the telephone line cord through the slot on the bottom of the telephone base.

Put the handset aside. Hold down the switch hook on the telephone base,

3. then slide the handset tab upwards to remove it from the slot. Rotate the handset tab by 180 degrees. Then replace the handset tab into the slot until it locks into position.

Switch hook

Handset tab

Getting started

Installation options

Press on the small tabs of the mounting bracket and then pull the mounting

4. bracket up to detach it from the telephone base.

Plug the other end of the telephone line cord into a telephone wall jack or

5. a DSL filter. Replace the handset in the telephone base.

Telephone wall jack

A DSL filter (not included) is required if you have DSL high-speed Internet service.

The DSL filter must be plugged into the telephone wall jack.

Adjust the viewing angle of the tilt display for maximum visibility.6.

Telephone settings

Use the menu to change the telephone settings.

Press MENU/SELECT repeatedly until the screen displays the desired feature.

1. Press CID or DIR until the screen displays the desired setting.

2. Press MENU/SELECT to save your selection and move to the next feature.

NOTE: Press CANCEL to cancel an operation or exit the menu.

Set date and time

When the telephone is idle, the screen shows the date and time. If you subscribe to caller ID service, the day, month and the time are set automatically with each incoming call. You may also set the date and time manually by following the steps below.

Press MENU/SELECT, the screen displays

1. DATE/TIME and USE # FOR AM/PM alternatively.

Use the dial pad keys (0-9) to set the month, or

2. press DIR to skip to set the day.

Use the dial pad keys (0-9) to set the day, or press

3. DIR to skip to set the hour.

Use the dial pad keys (0-9) to set the hour, or press

4. DIR to skip to set the minute.

Use the dial pad keys (0-9) to set the minute.

5. Press # (pound key) to select between AM or PM.

6. Press MENU/SELECT to save your setting and move

7. to the next menu setup.

DATE/TIME

1/01

USE # FOR AM/PM

1/01

12:00

Telephone settings

Contrast

You can set the contrast of the screen to one of four levels.

Press MENU/SELECT repeatedly until the screen

displays CONTRAST. Press CID or DIR to choose from 1, 2 (default

2. setting), 3 or 4.

Press MENU/SELECT to save your setting and move to the next menu setup.

Dial mode

The dial mode is preset to touch-tone dialing. If you have pulse (rotary) service, you must change the dial mode to pulse dialing before using the telephone.

Press MENU/SELECT repeatedly until the screen

1. displays DIAL MODE.

Press CID or DIR to choose TOUCH TONE (default

2. setting) or PULSE.

Press MENU/SELECT to save your setting and move to

3. the next menu setup.

CONTRAST 2

DIAL MODE

TOUCH TONE

PULSE

+ 38 hidden pages
