Features

• High-performance, Low-power AVR 8/16-bit XMEGA Microcontroller

• Non-volatile Program and Data Memories

– 64K/128K/192K/256K Bytes of In-System Self-Programmable Flash – 4K/8K/8K/8K Boot Code Section with Independent Lock Bits – 2K/2K/4K/4K Bytes EEPROM – 4K/8K/16K/16K Bytes Internal SRAM

• Peripheral Features

– Four-channel DMA Controller with support for external requests – Seven 16-bit Timer/Counters

4 Timer/Counters with 4 Output Compare or Input Capture channels 3 Timer/Counters with 2 Output Compare or Input Capture channels High Resolution Extensions on all Timer/Counters Advanced Waveform Extension on 1 Timer/Counters

– Seven USARTs

IrDA Extension on 1 USART – AES Crypto Engine – DES Crypto Engine – Two 2-wire Interfaces (I – Four SPIs (Serial Peripheral Interfaces) – 16-bit Real Time Counter with Separate Oscillator – Two Eight-channel, 12-bit, 2 Msps ADCs – One Two-channel, 12-bit, 1 Msps DAC – Four Analog Comparators – External Interrupts on all General Purpose I/O pins – Programmable Watchdog Timer with Separate On-chip Oscillator

• Special Microcontroller Features

– Power -on Reset and Programmable Brown-out Detection – Internal and External Clock Options with PLL – Programmable Multi-level Interrupt Controller – Sleep Modes: Idle, Power-down, Standby, Power-save, Extended Standby – Advanced Programming, Test and Debugging Interfaces

JTAG (IEEE 1149.1 Compliant) Interface f or test, debug and programming

PDI (Program and Debug Interface) for programming, test and debugging

• I/O and Pac kages

– 50 Programmable I/O Lines – 64-lead TQFP – 64-pad MLF

• Operating Voltage

– 1.8 – 3.6V

• Speed performance

– 0 – 12 MHz @ 1.8 – 2.7V – 0 – 32 MHz @ 2.7 – 3.6V

C and SMBus compliant)

8/16-bit XMEGA

Microcontroller

ATxmega256A3 ATxmega192A3 ATxmega128A3 ATxmega64A3

Advance Information

Typical Applications

• Industrial control • Climate control • Hand-held battery applications

• Factory automation • ZigBee • Power tools

• Building control • Motor control • HVAC

• Board control • Networking • Metering

• White Goods • Optical • Medical Application

8068A–AVR–02/08

1. Block Diagram/Pinout

ATxmega A3

BAT

INDEX CORNER

AC3/ACD3/PA3

AC4/ADC4/PA4

AC5/ADC5/PA5

AC6/ADC6/PA6

AC7/ADC7/PA7

AREF/AC0/ADC0/ADC8/PB0

AC1/ADC1/ADC9/PB1

DAC0/AC2/ADC2/ADC10/PB2

DAC1/AC3/ADC3/ADC11/PB3

TMS/AC4/ADC4/ADC12/PB4

TDI/AC5/ADC5/ADC13/PB5

TCK/AC6/ADC6/ADC14/PB6

TDO/AC7/ADC7/ADC15/PB7

GND

VCC

SDA/OC0A/_OC0A/PC0

PA2/ADC2/AC2

PA1/ADC1/AC1

PA0/ADC0/AC0/AREF

AVCC

GND

PR1/XTAL1

PR0/XTAL2

PDI_CLK/RESET

PDI_DATA/TEST

PF7

PF6

VCC

646362616059585756555453525150

ADC A

DAC A

Por t

AC A0

AC A1

ADC B

DAC B

Por t

AC B0

AC B1

Por t R

OSC/CLK

Control

Powe r

Control

Reset

Control

Watchdog

EVENT ROUTING NETWORK

DATA BU S

VREF

BOD POR

TEMP

RTC

FLASH

CPU

DMA

Interrupt Controller

Event System ctrl

DATA BU S

RAM

E2PROM

T/C0:1

USART0:1

SPI

TWI

Port C Port D Port E Port F

T/C0:1

USART0:1

SPI

T/C0:1

USART0:1

TWI

SPI

171819202122232425262728293031

GND

PF5/VCC

OCD

T/C0:1

PF4

PF3/OC0D/TXD0

SPI

USART0:1

PF2OC0C/RXD0

PF1/OC0B/XCK0

PF0/OC0A

GND

VCC

PE7/SCK/TXD1/TOSC1

PE6/MISO/RXD1/TOSC2

PE5OC1B/MOSI/XCK1

PE4OC1A/_SS

PE3/OC0D/TXD0

PE2OC0C/RXD0

PE1/OC0B/XCK0/SCL

PE0/OC0A/SDA

GND

VCC

PD7/SCK/TXD1

8068A–AVR–02/08

VCC

GND

_SS/OC1A/OC0C/PC4

RXD0/OC0C/_OC0B/PC2

TXD0/OC0D/D/OC0B/PC3

TXD1/SCK/OC0D/PC7

RXD1/MISO/_OC0D/PC6

SCL/XCK0/OC0B/OC0A/PC1

XCK1/MOSI/OC1BB/OC0C/PC5

OC0A/PD0

XCK0/OCB0PD1

TXD0/OCD0/PD3

RXD0/OC0C/PD2

_SS/OC1A/PD4

RXD1/MISO/PD6

XCk1/MOSI/OC1B/PD5

ATxmega A3

2. Ordering Information

For packaging information, see ”Packaging information” on page 53.

64A

64M1

(1)(2)

Temp

-40° - 85°C

Ordering Code Flash (B) E2 (B) SRAM (B) Speed (MHz) Power Supply Package

ATxmega256A3-AU 256K + 8K 4K 16K 32 1.8 - 3.6V ATxmega192A3-AU 192K + 8K 4K 16K 32 1.8 - 3.6V ATxmega128A3-AU 128K + 8K 2K 8K 32 1.8 - 3.6V ATxmega64A3-AU 64K + 4K 2K 4K 32 1.8 - 3.6V ATxmega256A3-MU 256K + 8K 4K 16K 32 1.8 - 3.6V ATxmega192A3-MU 192K + 8K 4K 16K 32 1.8 - 3.6V ATxmega128A3-MU 128K + 8K 2K 8K 32 1.8 - 3.6V ATxmega64A3-MU 64K + 4K 2K 4K 32 1.8 - 3.6V

Notes: 1. This device can also be supplied in wafer f orm. Please contact your local Atmel sales office for detailed ordering information.

2. Pb-free packaging, complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also Halide free and fully Green.

64A 64M1

8068A–AVR–02/08

Package Type

64-lead, 14 x 14 mm Body Size, 1.0 mm Body Thickness, 0.8 mm Lead Pitch, Thin Profile Plastic Quad Flat Package (TQFP) 64-pad, 9 x 9 x 1.0 mm Body, Lead Pitch 0.50 mm, 5.40 mm Exposed Pad, Micro Lead Frame Package (MLF)

3. Disclaimer

4. Overview

ATxmega A3

Typical values contained in this datasheet are based on simulations and characterization of other AVR microcontrollers manufactured o n th e same proce ss te ch nolo gy. Min a nd Ma x valu es will be available after the device is characterized.

The XMEGA A3 is a family of low power, high performance and peripheral rich CMOS 8/16-bit microcontrollers based on the AVR instructions in a single clock cycle, the XMEGA A3 achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power co nsumption versus pr ocessing speed.

5. Resources

A comprehensive set of development tools, application notes, and datasheets are available for download on http://www.atmel.com.

5.1 Recommended reading

• XMEGA A Manual

• Application Notes This document contains part specific information only. The XMEGA A Manual describes the

peripherals in-depth. The application notes contain example code and show applied use of the peripherals.

enhanced RISC architecture. By executing powerful

8068A–AVR–02/08

6. AVR CPU

6.1 Features

6.2 Overview

ATxmega A3

• 8/16-bit high performance AVR RISC Architecture

– 139 instructions – Hardware multiplier

• 32x8-bit registers directly connected to the ALU

• Stack in RAM

• Stack Pointer accessible in I/O memory space

• Direct addressing of up to 16M bytes of program and data memory.

• True 16/24-bit access to 16/24-bit I/O registers

• Support for 8-, 16- and 32-bit Aritmetic’s

• Configuration Change Protection of system critical features.

The XMEGA A3 uses an 8/16-bit AVR CPU. The main function of the CPU core is to ensure correct program execution. The CPU must therefore be able to access memories, perform calculations and control peripherals. Interrupt handling is described in a separate section. Figure

6-1 on page 5 shows the CPU block diagram.

Figure 6-1. CPU block diagram

DATA BUS

Program

Counter

Indirect Addressing

32 x 8 General

Purpose

Registers

FLASH

Program

Memory

SRAM

Data

ALU

Dir ec t Addr essing

Instruction

PERIPHERAL

MODULE 1

PERIPHERAL

MODULE n

The AVR uses a Harvard architecture - with separate memories and buses for program and data. Instructions in the program memory are executed with a single level pipeline. While one instruction is being executed, the next instruction is pre-fetched from the program memory. This concept enables instructions to be executed in every clock cycle. The pr ogram memory is InSystem Re-programmable Flash mem o ry.

Instruction

Decoder

DATA BUS

STATUS/

CONTROL

EEPROMI/O LINES

PMIC

8068A–AVR–02/08

6.3 Register File

The fast-access Register File contains 32 x 8-bit general purpose working registers with a single clock cycle access time. This allows single-cycle Arithmetic Logic Unit (ALU) operation. In a typical ALU operation, two operands are output from the Register File, the operation is executed, and the result is stored back in the Register File - in one clock cycle.

Six of the 32 registers can be used as three 16-bit indirect address register pointers for Data Space addressing - enabling efficient address calculations. One of these add ress pointers can also be used as an address pointer for look up tables in Flash program memory.

6.4 ALU - Arithmetic Logic Unit

The high performance Arithmetic Logic Unit (ALU) supports arithmetic and logic operations between registers or between a constant and a register. Single register operations can also be executed in the ALU. Within a single clock cycle, arithmetic operations between genera l purpose registers or between a register and an immediate are executed. Aft er an arithmetic or logic operation, the Status Register is updated to reflect information about the result of the operation.

The ALU operations are divided into three main categories – arithmetic, logical, and bit-functions. Both 8-, 16 and 32-bit arithmet ic is supp orted. Th e ALU als o provide a powerfu l multiplier supporting both signed/unsigned multiplication and fractional format.

ATxmega A3

6.5 Program Flow

Program flow is provided by conditional and unconditional jump and call instructions, able to address the whole address space directly. Most AVR instructions use a 16-bit word format. Some instructions also use a 32-bit format.

The Program Flash memory space is divided in two sections, the Boot section and the Application section. Both sections have dedicated Lock bits for write and read/write protection. The Store Program Memory (SPM) instruction used to access the Application section must reside in the Boot section.

A third section exists inside the Application section. This section, the Application Table section, has separate Lock bits for write and read/write protection. The Application Table section can be used for storing non-volatile data or application software.

The Program Counter (PC) addresses t he locat ion fr om wh ere t he instru ction s are f etched . Af ter a reset, the PC is set to location ‘0’.

During interrupts and subroutine calls, the return address PC is stored on the Stack. The Stack is effectively allocated in the general data SRAM, and consequent ly the Stack size is o nly limited by the total SRAM size and the usage of the SRAM. The Stack Pointer (SP) is default reset to the highest address of the internal SRAM. The SP is read/write accessible in the I/O space. The data SRAM can easily be accessed through the five dif ferent addr essing modes support ed in the AVR architecture.

8068A–AVR–02/08

7. Memories

7.1 Features

7.2 Overview

ATxmega A3

• Flash Program Memory

– One linear address space – In-System Reprogrammable – Self-Programming and Bootloader support – Application Section fo r application code – Application Table Section for application code or data storage – Bootloader Section for application code or bootloader code – Separate lock bits and protection for all sections

• Data Memory

– One linear address space – Single cycle access from CPU – SRAM – EEPROM

Byte or page accessible Optional memory mapping for direct Load/Store

– I/O Memory

Configuration and Status register for all peripherals and modules

16 bit accessible General Purpose Register for global variable or flags – External Memory – Bus arbitration

Safe and deterministic handling of CPU and DMA Controller priority – Separate buses for SRAM, EEPROM, IO Memory and External Memory access

• Enables simulatiouns bus access for CPU and DMA Controller

The AVR architecture has two main memory spaces, the Program Memory and the Data Memory. In addition, the XMEGA A3 features an EEPROM Memory for non-volatile data storage. All three memory spaces are linear and require no pagi ng. The memory conf igurations are shown in

”Ordering Information” on page 3.

Non-volatile memory spaces can be locked for further write and read/write operations. This prevents unrestricted access to the application software.

7.3 In-system Programmable Flash Program Memory

The XMEGA A3 contains On-chip In-System Re-programmable Flash memory for program storage, see Table 7-1 on page 8. Since all AVR instructions are 16- or 32-bits wide, each Flash address location is 16 bits.

The XMEGA A3 has additional Boot section for bootloader applications. The Store Program Memory (SPM) instruction used to write to the Flash will only operate from this section. Operation of the SPM is also associated with Boot Lock bits for software protection.

The XMEGA A3 has an Application Table section inside the Application section for storage of Non-volatile data.

8068A–AVR–02/08

Figure 7-1. Flash Program Memory (Hexadecimal address)

Word Address

ATxmega A3

The Application Table- and Boot sections can also be used for general application software.

7.4 SRAM Data Memory

The XMEGA A3 has internal SRAM memory for data storage. The Memory Map for the devices in the family resemble each other, see Table 7-2 on page 8.

7.5 EEPROM Data Memory

The XMEGA A3 has internal EEPROM memory for non-volatile data storage. It is addressable either in a separate data space or it can be memory mapped the normal data space. The EEPROM memory supports both byte and page access.

The Internal SRAM and EEPROM memory spaces start at the same address in all devices, see

Table 7-2 on page 8. The Reserved memory space is empty.

1EFFF / 16FFF / EFFF / 77FF

1F000 / 17000 / F000 / 7800

1FFFF / 17FFF / FFFF / 7FFF

20000 / 18000 / 10000 / 8000

20FFF / 18FFF / 10FFF / 87FF

Application Section

(256K/192K/128K/64K)

...

Application Table Section

(8K/8K/8K/4K)

Boot Section

(8K/8K/8K/4K)

Figure 7-2. Data Memory Map (Hexadecimal address)

Byte Address ATxmega192A3 Byte Address ATxmega128A3 Byte Address ATxmega64A3

1000

1FFF

2000

5FFF 3FFF 2FFF

6000

FFFFFF FFFFFF FFFFFF

8068A–AVR–02/08

FFF FFF FFF

I/O Registers

(4KB)

EEPROM

(4K)

Internal SRAM

(16K)

External Mempry

(0 - 16 MB)

1000

17FF 17FF

2000

4000

I/O Registers

(4KB)

EEPROM

(2K)

RESERVED RESERVED

Internal SRAM

(8K)

External Mempry

(0 - 16 MB)

1000

2000

3000

I/O Registers

EEPROM

Internal SRAM

External Mempry

(0 - 16 MB)

(4KB)

(2K)

(4K)

ATxmega A3

Byte Address ATxmega256A3

FFF

1000

1FFF

2000

5FFF

I/O Registers

(4KB)

EEPROM

(4K)

Internal SRAM

(16K)

6000

FFFFFF

External Mempry

(0 - 16 MB)

8068A–AVR–02/08

7.6 I/O Memory

ATxmega A3

All XMEGA A3 I/Os and peripherals are addressable through I/O memory locations in the data memory space. All I/O locations may be accessed by the LD/L DS/LDD and ST/STS/STD instructions, transferring data between the 32 general purpose registers and the I/O memory.

IN and OUT instructions can address I/O memory locations in the range 0x00 - 0x3F directly. I/O registers within the address range 0x00 - 0x1F are directly bit-accessible using the SBI and

CBI instructions. The value of single bits can be checked by using th e SBIS and SBIC instructions in these registers.

The I/O space definition of the XMEGA A3 is shown in ”Peripheral Module Address Map” on

page 51.

8068A–AVR–02/08

8. DMA - Direct Memory Access Controller

8.1 Features

• Allows High-speed data transfer

– From memory to peripheral – From memory to memory – From peripheral to memory – From peripheral to peripheral

• 4 Channels

• From 1 byte and up to 16 M bytes transfers in a single transaction

• Multiple addressing modes for source and destination address

–Incremental – Decremental – Static

• 1, 2, 4, or 8 bytes Burst Tra nsfers

• Programmable priority between channels

8.2 Overview

The XMEGA A3 has a Direct Memory Access (DMA) controller to move data between memories and peripherals in the data space. The DMA controller uses the same data bus as the CPU to transfer data.

ATxmega A3

The XMEGA A3 has 4 DMA channels that may be configured independently. The DMA controller supports transfer of up to 64K data blocks and can be configured to access memory with incrementing, decrementing or static addressing.

Since the DMA can access all the peripherals through the I/O memory, the DMA may be used for automatic transfer of data to/from communication modules, as well as automatic da ta retrieval from ADC conversions or data transfer to DAC conversions.

The DMA controller can read from memory mapped EEPROM, but it cannot write to the EEPROM or access the Flash.

8068A–AVR–02/08

9. Event System

9.1 Features

9.2 Overview

• Inter peripheral communication and signalling

• CPU and DMA independent operation

• 8 Event Channels allows for up to 8 signals to be routed at the same time

• Events can be generated by

– Timer/Counters (TCxn) – Real Time Counter (RTC) – Analog to Digital Converters (ADCx) – Analog Comparators (ACx) – Ports (PORTx) – System Clock (Clk – Software (CPU)

SYS

)

• Events can be used by

– TImer/Counters (TCxn) – Analog to Digital Converters (ADCx) – Digital to Analog Converters (DACx) – Ports (PORTx) – DMA Controller (DMAC)

• Advanced Features

– Manual Event Generation from software (CPU) – Quadrature Decoding – Digital Filtering

• Operative in Active and Idle mode

ATxmega A3

The Event System is a set of features for inter pe ripheral comm unication. It enable s the possibility for a change of state in one peripheral to automatically trigger actions in other pe ripherals. What change of state in a peripheral that will trigger actions in other peripherals is configurable in software. It is a simple, but powerful system as it allows for autonomous cont rol of per iph erals without any use of interrupt, CPU or DMA resources

The indication of a change of state in a peripheral is referred to as an event. The events are passed between peripherals using a dedicated ro uting network called the Event Routing Net work. Figure 9-1 on page 13 shows a basic block diagram of the Event System with the Event Routing Network and the peripherals that are connected. The event system is no t a single enti ty, but a set of features for inter peripheral communication. This highly flexible system can be used for simple rerouting of signals, pin functions or for sequencing of events.

The event system is functional in both Active- and Idle mode.

8068A–AVR–02/08

Figure 9-1. Event system block diagram.

ATxmega A3

CPU

ADCx

DACx

PORTxn

The the event routing network can directly connect together ADCs, DACs, Analog Comparators (AC), I/O ports (PORT), the Real-time Counter (RTC), and Timer/Counters (T/C). Events can also be generated from software (CPU).

DMA IRCOM

RTC

Event

Routing Network

ACxn

T/Cxn

8068A–AVR–02/08

10. System Clock and Clock options

10.1 Features

• Fast start-up time

• Safe run time clock switching

• 4 Internal Oscillators; 32 MHz, 2 MHz, 32 kHz, 32 kHz Ultra Low Power (ULP)

• 0.4 - 16 MHz Crystal Oscillator, 32 kHz Crystal Oscillator, external clock

• PLL with internal and external clock options and 1 to 31x multiplication

• Clock Prescalers with 1 to 2048x division

• Fast peripheral clock.

• Automatic Run-Time Calibration of internal oscillators

• Crystal Oscillator failure detection

10.2 Overview

XMEGA A3 has an advanced clock system, supporting a lar ge numbe r of clo ck sources. It in corporates both integrated oscillators, and external crystal oscillators and resonators. A high frequency Phase Locked Loop (PLL) and clock pr escalers can be controlled from software to generate a wide range of clock frequencies. The clock distribution also enables the possibility to switch between clock sources from software during run-time. A calibration feature (DFLL) is available, and can be used for automatic run-time calibration of the internal oscillators. A Crystal Oscillator Failure Monitor can be enabled to issue a Non-Maskable Interrupt and switch to internal oscillator if the external oscillator fails. Figure 10-1 on page 15 shows the principal clock system in XMEGA A3.

ATxmega A3

8068A–AVR–02/08

Figure 10-1. Clock system overview

ATxmega A3

32 KHz ULP

Intern al Oscillator

32 KHz Calibrated

Intern al Oscillator

32 KHz

Crystal Oscillator

0.4 - 16 MHz

Crystal Oscillator

2 MHz

Run-time C a libra te d

Intern al Oscillator

CLOCK

CONTROL

UNIT

with PLL

WDT/BOD

RTC

PERIPHERALS

ADC DAC

... ...

SYSTEM

CPU DMA

INTERRUPT

...

32 MHz

Run-time C a libra te d

Intern al Oscillator

External

Clock Input

Each clock source is briefly described in the following sub-sections.

MEMORY

RAM

FLASH

EEPROM

...

8068A–AVR–02/08

10.3 Clock Options

10.3.1 32 kHz Ultra Low Power Internal Oscillator

The 32 kHz Ultra Low Power (ULP) Internal Oscillator is a very low power consumptio n clock source based on internal components only. As it is intended mainly for system functions, it should not be used when an accurate clock is required.

10.3.2 32 kHz Calibrated Internal Oscillator

Compared to the internal ULP oscillator, the 32 kHz Calibrated Internal Oscillator is a high accuracy clock source based on internal components only.

10.3.3 32 kHz Crystal Oscillator

The 32 kHz Crystal Oscillator is a low power driver for an external watch crystal.

10.3.4 0.4 - 16 MHz Crystal Oscillator

The 0.4 - 16 MHz Crystal Oscillator is a driver intended both for driving resonators and crystals from 400 kHz to 16 MHz.

10.3.5 2 MHz Run-ti me Ca librat ed Interna l Os ci lla tor

ATxmega A3

The 2 MHz Run-time Calibrated Internal Oscillator is a high frequency oscillator based on internal components only. The oscillator can use the 32 kHz Calibrated Internal Oscillator or the 32 kHz Crystal Oscillator to calibrate the frequency run-time to compensate for temperature and voltage drift, optimizing the accuracy of the oscillator.

10.3.6 32 MHz Run-time Calibrated Internal Oscillator

The 32 MHz Run-time Calibrated Internal Oscillator is a high frequency oscillator based on internal components only. The oscillator can use the 32 kHz Calibrated Internal Oscillator or the 32 kHz Crystal Oscillator to calibrate the frequency run-time to compensate for temperature and voltage drift, optimizing the accuracy of the oscillator.

10.3.7 External Clock input

The external clock input gives the possibility to connect to a clock from an external source.

10.3.8 PLL with Multiplication factor 2 - 31x

The PLL provides the possibility of multiplying a frequency with any real number from 2 to 31. In combination with some prescalers, this gives a numerous number of clock frequency options to use.

8068A–AVR–02/08

11. Power Management and Sleep Modes

11.1 Features

• 5 sleep modes

–IDLE – Power-down –Power-save –Standby – Extended standby

• Power Reduction register to disable clock to un u sed peripheral

11.2 Overview

The XMEGA A3 provides various sleep modes tailored to reduce power consumption to a minimum. All sleep modes are accessible from Active mode. In Active mode the CPU is executing application code. The application code decides when and what sleep mode to enter.

Various sources can restore the microcontroller from sleep to Active mode. This is called a wake-up.

ATxmega A3

In addition Power Reduction Registers (PRR) provides a method to stop the clock to individual peripherals from software. When this is done the current state of the peripheral is frozen and there is no power consuption from the peripheral.

11.3 Sleep Modes

11.3.1 Idle Mode

In Idle mode the CPU and Non-Volatile Memory are stopped, but all peripherals including the Interrupt Controller, Event System and DMA Controller are kept running.

Interrupt request from all enabled interrupts will wake the device.

11.3.2 Power-down Mode

In Power-down mode all system clock sources, including the Real Time Counter clock source are stopped. This allows operation of asynchronous modules only. The only interrupts that can wake up the MCU are the Two Wire Interface address match interrupts, and asynchronous port interrupts.

11.3.3 Power-save Mode

Power-save mode is identical to Power-down, with one exception: If the Real Time Counter (RTC) is enabled, it will keep running during sleep and the device can

also wake up from either RTC Overflow or Compare Match interrupt.

11.3.4 Standby Mode

8068A–AVR–02/08

Standby mode is identical to Power-down with the exception that the system clock sources are kept running, while the CPU, Peripheral and RTC clocks are stopped. This r edu ces t he wake-up time when external crystals or resonators are used.

11.3.5 Extended Standby Mode

Extended Standby mode is identical to Power-save mode with the exception that the system clock sources are kept running while the CPU and Peripheral clocks are stopped. This reduces the wake-up time when external crystals or resonators are used.

ATxmega A3

8068A–AVR–02/08

12. System Control and Reset

12.1 Resetting the AVR

During reset, all I/O Registers are set to their initial values. Application execution starts from the Reset Vector. The instruction placed at t he Reset Vector should be a JMP - Absolute Jump instruction to the reset handling r outine. If the applic ation neve r enab les an int errupt sour ce, th e Interrupt Vectors are not used. The regular application code can then be placed at these locations. This is also the case if the Reset Vector is in the Application section while the Interrupt Vectors are in the Boot section or vice versa.

The I/O ports of the AVR are immediately tri-stated when a reset source goes active. The reset functionality is asynchronous, hence no running clock is required to reset the device.

12.2 Reset Sources

The reset source can be determined by the application by readig a reset status register. The XMEGA A3 has the following sources of reset:

•

Power-on Reset

• External Reset

• Watchdog Reset

• Brown-out Reset

• JTAG AVR Reset

• PDI reset

• Software reset

ATxmega A3

12.2.1 Power-on Reset

The MCU is reset when the supply voltage VCC is below the Power-on Reset threshold voltage.

12.2.2 External Reset

The MCU is reset when a low level is present on the RESET pin.

12.2.3 Watchdog Reset

The MCU is reset when the Watchdog Timer period exp ires and the Wat chdog Reset is enable d.

12.2.4 Brown-out Reset

The MCU is reset when the supply voltage VCC is below the Brown-out Reset threshold voltage and the Brown-out Detector is enabled.

12.2.5 JTAG AVR Reset

The MCU is reset as long as there is a logic one in the Reset Register, one of the scan chains of the JTAG system. Refer to IEEE 1149.1 (JTAG) Boundary-scan for details.

12.2.6 PDI reset

The MCU may be reset through the Program and Debug Interface (PDI).

12.2.7 Software res et

8068A–AVR–02/08

The MCU may be reset by the CPU writing to a special I/O register.

12.3 WDT - Watchdog Timer

12.3.1 Features

11 selectable timeout period, from 8 ms to 8s.

•

• Two operation modes

– Standard mode – Window mode

• Runs from 1 kHz Ultra Low Power clock reference

• Configuration lock

12.3.2 Overview

The XMEGA A3 has a Watchdog Timer (WDT) that will run continuously when turned on. If the Watchdog Timer is not reset within a software configurable time-out period, the microcontroller will reset. To prevent this reset, a Watchdog Reset (WDR) instruction must be run by software to reset the WDT.

The WDT has a Window mode. In this mode the WDR instruction must be run within a specified period called a window. Application software can set the minimum and maximum limits for this window. If the WDR instruction is not run inside the window limits, the microcontroller will be reset.

ATxmega A3

For maximum safety, the WDT also has an Always-on mode. This mode is enabled by programming a fuse. In Always-on mode, application software can not disable t he WDT.

A protection mechanism is used to prevent unwante d enabling, disabling or change of WDT settings.

8068A–AVR–02/08

13. PMIC - Programmable Multi-level Interrupt Controller

13.1 Features

• Separate interrupt vector for each interrupt

• Short, predictable interrupt response time

• Programmable Multi-level Interrupt Controller

– 3 programmable interrupt levels – Selectable priority scheme within low level interrupts (round-robin or fixed) – Non-Maskable Interrupts (NMI)

• Interrupt vectors can be moved to the start of the Boot Section

13.2 Overview

XMEGA A3 has a Programmable Multi-level Interrupt Controller (PMIC). All peripherals can define three different priority levels for interrupts; high, medium or low. Medium level interrupts may interrupt low level interrupt service routines. High level interrupts may interrupt both lowand medium level interrupt service routines. Low level interrupts have an optional round robin scheme to make sure all interrupts are serviced within a certain amount of time.

A Non-Maskable Interrupt (NMI) can detect oscillator failure.

ATxmega A3

13.3 Interrupt vectors

When an interrupt is serviced, the program counter will jump to the interrupt vector address. The interrupt vector is the sum of the module or peripherals base address and the specific interrupt's offset address. The base addresses for the XMEGA A3 device is shown in Table 13-1. Offset addresses for each interrupt available in the peripheral are described in the manual. For peripherals or modules that have only one interrupt, the interrupt vector is shown in Table 13-1.

Table 13-1. Reset and Interrupt Vectors

Program Address

(Base Address) Source Interrupt Description

0x000 RESET 0x002 IVEC_XOSCF_INT_vect Crystal Oscillator Failure Interrupt vector (NMI) 0x004 IVEC_PORTC_INT_base Port C Interrupt base 0x008 IVEC_PORTR_INT_base Port R Interruptbase

0x00C IVEC_DMAC_INT_base DMA Controller Interrupt base

0x014 IVEC_RTC_INT_base Real Time Counter Interrupt base 0x018 IVEC_TWIC_INT_base Two-Wire Interface on Port C Interrupt base

0x01C IVEC_TIMERC0_INT_base Timer/Counter 0 on port C Interrupt base

0x028 IVEC_TIMERC1_INT_base Timer/Counter 1 on port C Interrupt base 0x030 IVEC_SPIC_INT_vect SPI C Interrupt vector

0x032 IVEC_USARTC0_INT_base USART 0 on port C Interrupt base 0x03D IVEC_USARTC1_INT_base USART 1 on port C Interrupt base 0x03E IVEC_AES_INT_vect AES Interrupt vector

0x040 IVEC_NVM_INT_base Non-Volatile Memory INT base

0x044 IVEC_POR TB_INT_base Port B INT base

8068A–AVR–02/08

Table 13-1. Reset and Interrupt Vectors (Continued)

Program Address

(Base Address) Source Interrupt Description

0x048 IVEC_ACB_INT_base Analog Comparator Port B INT base 0x04E IVEC_ADCB_INT_base Analog to Digital Converter Port B INT base

0x056 IVEC_POR TE_INT_base Port E INT base 0x05A IVEC_TWIE_INT_base Two-Wire Interface on Port E INT base 0x05E IVEC_TIMERE0_INT_base Timer/Counter 0 on port E Interrupt base 0x06A IVEC_TIMERE1_INT_base Timer/Counter 1 on port E Interrupt base

0x072 IVEC_SPIE_INT_vect SPI E Interrupt vector

0x074 IVEC_USARTE0_INT_base USART 0 on port E Interrupt base 0x07A IVEC_USARTE1_INT_base USART 1 on port E Interrupt base

0x080 IVEC_PORTD_INT_base Port D INT base

0x084 IVEC_POR TA_INT_base Port A INT base

0x088 IVEC_ACA_INT_base Analog Comparator Port A INT base 0x08E IVEC_ADCA_INT_base Analog to Digital Converter Port A INT base

0x096 IVEC_TWID_INT_base Two-Wire Interface on Port D INT base 0x09A IVEC_TIMERD0_INT_base Timer/Counter 0 on po rt D Interrupt base

ATxmega A3

0x0A6 IVEC_TIMERD1_INT_base Timer/Counter 1 on po rt D Interrupt base 0x0AE IVEC_SPID_INT_vector SPI D Interrupt vector 0x0B0 IVEC_USARTD0_INT_base USART 0 on port D Interrupt base 0x0B6 IVEC_USARTD1_INT_base USART 1 on port D Interrupt base 0x0D0 IVEC_PORTF_INT_base Port F INT base 0x0D4 IVEC_TWIF_INT_base Two-Wire Interface on Port F INT base 0x0D8 IVEC_TIMERF0_INT_base Timer/Counter 0 on port F Interrupt base 0x0E4 IVEC_TIMERF1_INT_base Timer/Counter 1 on port F Interrupt base 0x0EC IVEC_SPIF_INT_vector SPI F Interrupt base 0x0EE IVEC_USARTF0_INT_base USART 0 on port F Interrupt base 0x0F4 IVEC_USARTF1_INT_base USART 1 on port F Interrupt base

8068A–AVR–02/08

14. I/O Ports

14.1 Features

14.2 Overview

ATxmega A3

• Selectable input and output configuration for each pin indi vidually

• Flexible pin configuration through dedicated Pin Configuration Register

• Synchronous and/or asynchronous input sensing with port interrupts and events

– Sense both edges – Sense rising edges – Sense falling edges – Sense low level

• Asynchronous wake-up signalling

• Highly configurable output driver and pull settings:

– Totem-pole – Pull-up/-down – Wired-AND – Wired-OR – Bus keeper – Inverted I/O

• Slew rate control

• Flexible pin masking

• Configuration of multiple pins in a single operation

• Read-Modify-Write (RMW) support

• Toggle/clear/set registers for OUT and DIR registers

• Clock output on port pin

• Event Channel 7 output on port pin

• Mapping of port registers (virtual ports) into bit accessible I/O memory space

The XMEGA A3 has flexible General Purpose I/O (GPIO) Ports. A port consists of up to 8 pins, ranging from pin 0 to pin 7. The ports implement severa l funct io ns, including inte rrup ts, synchronous/asynchronous input sensing and configurable output settings. All functions are individual per pin, but several pins may be configured in a single operation.

14.3 I/O configuration

All port pins have programmable output configuration. In addition, all GPIO pins have inverted I/O. For an input, this means inverting the signal between the port pin and the pin register. For an output, this means inverting the output signal between the port register and the port pin. Some port pins also have configurable slew rate limitation to reduce electromagnetic emission.

The configuration options include:

•

• Pull-down resistor

• Pull-up resistor

• Bus keeper

• Inverted I/O

• Slew rate limitation

Push-pull

8068A–AVR–02/08

14.4 Push-pull

ATxmega A3

Figure 14-1. I/O configuration - Totem-pole

DIRn

14.5 Pull-down

14.6 Pull-up

OUTn

INn

Figure 14-2. I/O configuration - Totem-pole with pull-down (on input)

DIRn

OUTn

INn

14.7 Bus-keeper

8068A–AVR–02/08

Figure 14-3. I/O configuration - Totem-pole with pull-up (on input)

DIRn

OUTn

INn

The bus-keeper’s weak output produces the same logical level as the last output level. It acts as a pull-up if the last level was ‘1’, and pull-down if the last level was ‘0’.

Figure 14-4. I/O configuration - Totem-pole with bus-keeper

DIRn

ATxmega A3

14.8 Others

OUTn

INn

Figure 14-5. Output configuration - Wired-OR with optional pull-down

OUTn

INn

Figure 14-6. I/O configuration - Wired-AND with optional pull-up

14.9 Port Interrupt

8068A–AVR–02/08

INn

OUTn

Ports can have pin-change interrupts an d external interrupts. Each po rt supports being the source of two interrupts, and each pin may be configured individually or grouped. Each of the interrupts may be given a specific priority and given specific sense configuration.

14.10 Input sensing

ATxmega A3

• Sense both edges

• Sense rising edges

• Sense falling edges

• Sense low level The basic input sensing may be synchronous or asynchronous and is built on the configuration

shown in Figure 14-7 on page 26.

Figure 14-7. Input sensing system overview

Asynchronous sensing

IN V ERT ED I/O

Synchronizer

INn

EDGE

DETECT

Synchronous sensing

EDGE

DETECT

Interrupt

Control

IR E Q

Event

In addition, all GPIO pins may be configured as inverted I/O, meaning that the pin value is inverted before sensing.

8068A–AVR–02/08

15. T/C - 16-bits Timer/Counter with PWM

15.1 Features

• 4 Timer/Counter 0 (Timer0)

• 4 Timer/Counter 1 (Timer1)

• Double Buffered Timer Period Setting

• Compare or Capture Channels are Double Buffered

• 4 Combined Compare or Capture (CC) Channels in Timer0

• 2 Combined Compare or Capture (CC) Channels in Timer1

• Waveform Generation:

– Single Slope Pulse Width Modulation – Dual Slope Pulse Width Modulation – Frequency Generation

• Input Capture:

– Input Capture with Noise Cancelling – Frequency capture – Pulse width capture – 32-bit input capture

• Event Counter with Direction Control

• Timer Overflow and Timer Error Interrupts and Events

• One Compare Match or Capture Interrupt and Event per CC Channel

• Supports DMA Operation

• Hi-Resolution Extension (Hi-Res)

• Advanced Waveform Extension (A WEX)

ATxmega A3

15.2 Overview

XMEGA A3 has 8 Timer/Counters. 4 are of type Timer0 and 4 of type Timer1. The difference between Timer0 and Timer1 type is that Timer0 has 4 Compare/Capture channels, and Timer1 only has 2. In addition, Timer0 may have an Advanced Waveform Extension (AWEX), that is not available in Timer1.

The Timer/Counters (T/C) are 16-bit wide and can count any clock, event or input signal in the microcontroller. A programmable prescaler is available to get a useful T/C reso lution. Upd ates of Timer and Compare registers are double buffered to ensure glitch free operation. Using Compare channels many different waveforms can be genera ted, single slope PWM, du al slope PWM and frequency generation.

The High-Resolution Extension can be enabled to increase the waveform generation resolution by 2 bits (4x). This is available for all Timer/Counters.

The Input Capture has a noise canceller to avoid incorrect ca pture of the T/C. Any input pin or event in the microcontroller can be used to trigger the capture.

A wide range of interrupt or event sources are availa ble, including T/C overflow, Compa re match and Capture for each timer and CC channel.

PORTC, PORTD, PORTE and PORTF each has one Timer/Counter 0 and one Timer/ Counter 1. Notation of these timers are TCC0, TimerC1, TCD0, TCD1, TCE0, TCE1, TCF0, and TCF1.

8068A–AVR–02/08

16. AWEX - Advanced Waveform Extension

16.1 Features

• 4-DTI Units (8-pin)

• 8-bit Resolution

• Separate High and Low Side Dead-Time Setting

• Double Buffered Dead-Time

• Fault Protection (Event Controlled)

• Single Channel Multiple Output Operation (for BLDC control)

• Double Buffered Pattern Generation

16.2 Overview

The Advanced Waveform Extention (AWEX) provides extra features to the Time/Counter in Waveform Generation (WG) modes. AWEX enables easy and robust implementation of for example advanced motor control (AC, BLDC, SR, and Stepper) and power control applications.

Any WG output from the Timer/Counte r 0 are split into a complimentary pair of ou tputs when a ny AWEX feature is enabled. These output pairs go through a Dead-Time Inse rtion (DTI) unit that enables generation of the non-inverted Low Side (LS) and inverted High Side (HS) of the WG output with dead time insertion between LS and HS switching. The DTI outp ut will override the normal port value according to the port override setting. Optionally the final output can be inverted by using inverted I/O (INVEN) bit setting for port pin (Pxn).

ATxmega A3

The Pattern Generation unit can be used to generate a synchronized bit pattern on the port it is connected to. In addition, the waveform generator output from the Compare Channel A can be distributed to and override all the port pins. When the Pattern generator unit is enabled the DTI unit i bypassed.

The Fault Protection unit is connected to the Event System, enabling any event to trigger a fault condition that will disable the AWEX output.

The AWEX is only available on TCC0 and TCE0. The notation of these are AWEXC and AWEXE.

8068A–AVR–02/08

17. RTC - Real-Time Counter

17.1 Features

• 16-bit Timer

• Flexible Tick resolution ranging from 1 Hz to 32 kHz

• 1 Compare register

• 1 T op Value register

• Clear timer on Overflow or Compare Match

• Overflow or Compare Match event and interrupt generation

17.2 Overview

The XMEGA A3 includes a 16-bit Real-time Counter (RTC). The RTC can be clocked from a accurate 32.768 kHz Crystal Oscillator, the 32 kHz Calibrated Internal Oscillator, or from the 32 kHz Ultra Low Power Internal Oscillator. The RTC include both a Period and Compare register, for details, see Figure 17-1.

A wide range of Resolution and Time-out periods can be conf igure d usin g the RTC. With a maximum resolution of 30.5 µs, time-out periods range up to 2000 seconds. With a resolution of 1 second, maximum time-out period is over 18 hours (65536 se conds).

ATxmega A3

Figure 17-1. Real-time Counter overview

32 kHz

10-bit

prescaler

1 kHz

16-bit Period

Overflow

16-bit Timer

Compare Match

16-bit Compare

8068A–AVR–02/08

18. TWI - Two Wire Interface

18.1 Features

• Two Identical TWI peripherals

• Simple yet Powerfu l an d Flexible Communication Interface

• Both Master and Slave Operation Supported

• Device can Operate as Transmitter or Receiver

• 7-bit Address Space Allows up to 128 Different Slave Addresses

• Multi-master Arbitration Support

• Up to 400 kHz Data Transfer Speed

• Slew-rate Limited Output Drivers

• Noise Suppression Circuitry Rejects Spikes on Bus Lines

• Fully Programmable Slave Address with General Call Support

• Address Recognition Causes Wake-up when in Sleep Mode

• I

C and System Management Bus (SMBus) compliant

18.2 Overview

The 2-wire Serial Interface (TWI) is a bi-directional bus with only two lines, the clock (SCL) and the data (SDA). The protocol makes it possible to interconnect up to 128 individually addressable devices. Since it is a multi-master bus, one or more devices capable of taking control of the bus, can be connected.

ATxmega A3

The only external hardware needed to implement the bus is a single pull-up resistor for each of the TWI bus lines. Mechanisms for resolving bus contention are inherent in the TWI protocol.

PORTC and PORTE each have one TWI. Notation of these perip he ra ls ar e TWIC and TWIE.

8068A–AVR–02/08

19. SPI - Serial Peripheral Interface

19.1 Features

• 4 Identical SPI peripherals

• Full-duplex, Three-wire Synchronous Data Transfer

• Master or Slave Operation

• LSB First or MSB First Data Transfer

• Seven Programmable Bit Rates

• End of Transmission Interrupt Flag

• Write Collision Flag Protection

• Wake-up from Idle Mode

• Double Speed (CK/2) Master SPI Mode

19.2 Overview

The Serial Peripheral Interface (SPI) allows high-speed synchronous data transfer between different devices. Devices can communicate using a master-slave scheme, and data a re transferred both to and from the devices simultaneously.

PORTC, PORTD, PORTE, and PORTF each have one SPI. Notation of these peripherals are SPIC, SPID, SPIE, and SPIF.

ATxmega A3

8068A–AVR–02/08

20. USART

20.1 Features

20.2 Overview

ATxmega A3

• 8 Identical USART peripherals

• Full Duplex Operation (Independent Serial Receive and Transmit Registers)

• Asynchronous or Synchronous Operation

• Master or Slave Clocked Synchronous Operation

• High-resolution Arithmetic Baud Rate Generator

• Supports Serial Frames with 5, 6, 7, 8, or 9 Data Bits and 1 or 2 Stop Bits

• Odd or Even Parity Generation and Parity Check Supported by Hardware

• Data OverRun Detection

• Framing Error Detection

• Noise Filtering Includes False Start Bit Detection and Digital Low Pass Filter

• Three Separate Interrupts on TX Complete, TX Data Register Empty and RX Complete

• Multi-processor Communicat ion Mode

• Double Speed Asynchronous Communication Mode

• IrDA

The Universal Synchronous and Asynchronous serial Receiver and Transmitter (USART) provides highly flexible serial communication device. The frame format can be customized to support a wide range of standards, and the USART implements different error detection.

PORTC, PORTD, PORTE, and PORTF each have two USARTs. Notation of these peripherals are USARTC0, USARTC1, USARTD0, USARTD1, USARTE0, USARTE1, USARTF0, USARTF1.

8068A–AVR–02/08

21. IRCOM - IR Communication Module

21.1 Features

• Pulse modulation/demodulation for infrared communication

• IrDA 1.4 Compatible for baud rates up to 115.2 kbps

• Selectable pulse modulation scheme

– 3/16 of baud rate period – Fixed pulse period, 8-bit programmable – Pulse modulation disabled

• Built in filtering

• Can be connected to and used by any USART and one USART at the time

21.2 Overview

XMEGA contains an Infrared Communication Module (IRCOM) IrDA 1.4 compatible module for baud rates up to 115.2 kbps. This supports three modulat ion sch emes: 3/ 16 of baud rate pe rio d, fixed programmable pulse time based on the Peripheral Clock speed , or pulse modulation disabled. There is one IRCOM available, and this can be connected to any USART to enable infrared pulse coding/decoding for that USART.

ATxmega A3

8068A–AVR–02/08

22. Crypto Engine

22.1 Features

22.2 Overview

ATxmega A3

• Data Encryption Standard (DES) core instruction

• Advanced Encryption Standard (AES) crypto module

• DES Instruction

– Encryption and Decryption – DES and triple-DES supported – Single-cycle DES instruction – Encryption/Decryption in 16 clock cycles per 8-byte block

• AES Crypto Module

– Encryption and Decryption – Support 128-bit keys – Support XOR data load mode to the State memory – Encryption/Decryption in 375 clock cycles per 16-byte block

The Advanced Encryption Standard (AES) and Data Encryption Standard (DES) are two commonly used standards for encryption. These are supported through an AES peripheral module and a DES core instruction.

DES is supported by a DES instruction in the AVR XMEGA CPU. The 8-byte key and 8-byte data blocks must be loaded into the Register file, and then DES must be executed 16 times to encrypt/decrypt the data block.

The AES Crypto Module encrypts and decrypts 128-bit dat a blocks with the use of a 12 8-bit key. The key and data must be loaded into the module before encryption/decryption is started. It takes 375 peripheral clock cycles before encrypted/decrypted data can be read ou t.

8068A–AVR–02/08

23. ADC - 12-bit Analog to Digital Converter

23.1 Features

• Two ADCs with 12-bit resolution

• 2 Msps conversion rate

• Signed- and Unsigned conversions

• 4 result registers with individual channel control for each ADC

• 16 single ended inputs

• 16x8 differential inputs

• Gain of 1, 2, 4, 8, 16, 32 or 64

• Selectable accuracy of 8-, 10- or 12-bit.

• Built-in Auto Calibration

• Internal- or External Reference

• Event triggered conversion for accurate timing

• DMA transfer of conversion results

• Interrupt/Event on compare result

23.2 Overview

The XMEGA A3 devices has two Analog to Digital Converters (ADC), see Figure 23-1 on page

36. The two ADCs modules can be operated simultaneously, individually or synchronized.

ATxmega A3

The ADC converts analog voltages to digital values.The ADC has 12-bit resolution and is capable of converting up to 2 million samples per second. The input selection is flexible, and both single-ended and differential measurements can be done. The ADC provides both signed and unsigned results, and an optional gain stage is available to increase the dynamic range of the ADC.

The ADC uses Successive Approximation Result (SAR) ADC . A SAR ADC meas ures one bi t of the conversion result a time. The ADC has a pipe line architectu re. This means that a new analog voltage can be sampled and a new ADC measurement started while other ADC measurements are ongoing.

ADC measurements can either be started by the application software or an incoming event from another peripheral in the device. Four different result registers with individual channel selection (MUX registers) are provided to make it easier for the application to keep track of the data. It is also possible to use DMA to move ADC results directly to memory or peripherals.

Both internal and external analog reference voltages can be used. A very accurate internal 1.0V reference is available, providing a conversion range from 0 - 1.0 V in unsigne d mode and -1.0 to

1.0V in signed mode.

8068A–AVR–02/08

Figure 23-1. ADC overview

Channel A MUX selection Channel B MUX selection

ATxmega A3

Configuration

Reference selection

ADC

Event

Pin inputs Internal inputs

Each ADC has 4 registers defining a MUX selection with a corresponding result register. This means that 4 channels may be sampled within 1.5 µs without any intervention by the ap plication other than starting the conversion, and the result will be available in 4 data registers.

The ADC may be configured to make 8-, or 12-bit results, reducing the conversion time (propagation delay) from 4µs for 12-bit to 3µs for 8-bit resolution.

ADC conversion results are provided left- or right adjusted with optional ‘1’ or ‘0’ padding. This eases calculation when the result is represented as a signed integer (signed 16-bit number).

Trigger

Channel A

Channel B

8068A–AVR–02/08

PORTA and PORTB each have one ADC. Notation of these peripherals are ADCA and ADCB.

24. DAC - 12-bit Digital to Analog Converter

24.1 Features

• One DAC with 12-bit resolution

• Up to 1 Msps conversion rate

• Flexible conversion range

• Multiple trigger sources

• 1 continuous time or 2 Sample and Hold (S/H) outputs for each DA C

• Built-in offset and gain calibration

• High drive capabilities

• DAC Power reduction mode

24.2 Overview

The XMEGA A3 features one 12-bit, 1 Msps DAC with built-in calibration of offset and gain, see

Figure 24-1 on page 37.

A DAC converts a digital value into an analog signal. The DAC ma y use the bandg ap referenc e voltage as upper limit for conversion, but it is also possible to use the supply voltage or any applied voltage in-between. An external reference input is shared with the ADC reference input.

ATxmega A3

Figure 24-1. DAC overview

Configuration

Reference selection

Channel A

DAC

Channel B

Event

Trigger

Channel A

Channel B

Each DAC has one continuous output with high drive capabilities for both resistive and capacitive loads. It is also possible to split the continuous ti me chan nel into t wo Sample and Hold (S/H) channels; each with separate data conversion registers.

A DAC conversion may be started from the application software by writing the data conversion registers. The DAC may also be configured to do conversions triggered by the Event System to have regular timing independent of the application. DMA may be used for transferring data from memory location to DAC data registers.

A DAC power reduction mode can be enabled to reduce power consumption.

8068A–AVR–02/08

The DAC has a built-in calibration system that removes offset and gain error. PORTB have one DAC and the notation of this is DACB.

25. AC - Analog Comparator

25.1 Features

• Four Analog Comparators

• Selectable Power vs. Speed

– 20 µA/500 ns active current consumption/propagation delay, or – 130 µA/30 ns active current consumption/propagation delay

• Selectable hysteresis

– 0, 20 mV, 50 mV

• Analog Comparator output available on pin

• Flexible Input Selection

• Basic interrupt and event generation on

– Rising edge – Falling edge –Toggle

• Window function interrupt and event generation on

– Signal above window – Signal inside window – Signal below window

25.2 Overview

ATxmega A3

The XMEGA A3 features four An alog Com parators (AC). An An alog Comp arator com pares tw o voltages, and the output indicates which input is largest. T he Analog Comparat or may be co nfigured to give interrupt requests and/or events upon several different combinations of input change.

Both hysteresis and propagation delays may be adjusted in order to find the optimal operation for each application.

The Analog Comparators are always grouped in pairs (AC0 and AC1) on each analog port. They have identical behavior but separate control regi sters

PORTA and PORTB each have one AC. Notations are ACA0, ACA1, ACB0, and ACB1.

8068A–AVR–02/08

Figure 25-1. Analog comparator overview

ATxmega A3

0x000000

0x001000

0x002000

0x006000/

0x00A000

I/O Registers

(4KB)

EEPROM

(2KB/4KB)

In te rn a l S R A M

(16/32KB)

External M em ory

(0 - 16 M B )

0x000FFF

0x001FFF

0x005FFF/ 0x009FFF

0xFFFFFF

8068A–AVR–02/08

25.3 Input Selection

The Analog comparators have a very flexible input selection and the two comparators grouped in a pair may be used to realize a window function. One pair of analog comparators is shown in

Figure 25-1 on page 39.

•

Input selection from pin

• Internal signals available on both analog comparator inputs

• 6-bit scale down of VCC, available on both analog comparator inputs

25.4 Window Function

The window function is realized by connecting the inputs of th e two analog comp arat ors in a pair as shown in Figure 25-2.

Figure 25-2. Analog comparator window function

ATxmega A3

– Pin 0, 1, 2, 4, 6 selectable to positive input of analog comparator – Pin 0, 1, 3, 5, 7 selectable to negative input of analog comparator

– Bandgap Reference voltage – Output from 12-bit DAC

Upper limit of window

Input signal

Lower limit of window

AC0

AC1

Interrupt

sensitivity

control

Interrupts

Events

8068A–AVR–02/08

26. OCD - On-chip Debug

26.1 Features

• Complete Program Flow Control

– Symbolic Debugging Support in Hardware – Go, Stop, Reset, Step into, Step over, Step out, Run-to-Cursor

• 1 dedicated program address breakpoint or symbolic breakpoi nt for AVR studio/emulator

• 4 Hardware Breakpoints

• Unlimited Number of User Program Breakpoints

• Uses CPU for Accessing I/O, Data, and Program

• Non-Intrusive Operation

– Uses no hardware or software resources

• High Speed Operation

– No limitation on frequency of TCK versus system clock frequency

26.2 Overview

The XMEGA A3 has an On-chip debug (OCD) system that - in combination with Atmel’s development tools - provides all the necessary functions to debug an application.

ATxmega A3

8068A–AVR–02/08

27. Program, Debug and Test Interfaces

27.1 Features

• JTAG Interface (IEEE std. 1149.1 compliant)

• PDI - Program and Debug Interface (Atmel proprietary 2-pin interface)

• Boundary-scan capabilities according to the IEEE Std. 1149.1 (JTAG)

• Access to the OCD system

• Programming of Flash, EEPROM, Fuses and Lock Bits

27.2 Overview

The JTAG and PDI are the physical interface to access the programming and debug facilities. The PDI uses one dedicated pin together with the Reset pin, no general purpose pins are used. When JTAG is used it makes use of four general purpose pins.

27.3 JTAG interface

The JTAG physical layer handles the basic low-level serial communication over four I/O lines named TMS, TCK, TDI, and TDO. It complies to the IEEE Std. 1149.1 for test a ccess port and boundary scan.

ATxmega A3

27.4 PDI - Program and Debug Interface

The PDI is an Atmel proprietary protocol for communication between the microcontroller and Atmel’s development tools.

8068A–AVR–02/08

28. Pinout

The pinout of XMEGA A3 is shown in ”Block Diagram/Pinout” on page 2. In addition to general I/O functionality, each pin may have several function. This will depend on which peripheral is enabled and connected to the actual pin. Only one of the alternate pin functions can be used at the time.

28.1 Alternate Pin Function Description

The tables below shows the notation for all pin functions available and describe its function.

28.1.1 Operation/Power Supply

VCC Digital supply voltage AVCC Analog supply voltage GND Ground

28.1.2 Analog functions

ACxn Analog Comparator input port x pin y ADCn Analog to Digital Converter input port x pin y

ATxmega A3

DACn Digital to Analog Converter output port x pin y AREFx Analog Reference input port x pin

28.1.3 Timer functions

OCnx Output Compare Channel x for Timer n _OCnx Inverted Output Compare Channel x for Timer n

28.1.4 Communication functions

SCL Serial Clock for TWI SDA Serial Data for TWI XCK0 Tr ansfer Clock for USART n RxD0 Receiver Data for USART n TxD0 Tr ansmitter Data for USART n _SS Slav e Select for SPI MOSI Master Out Slave In for SPI MISO Master In Slave Out f o r SPI SCK Serial Clock for SPI

8068A–AVR–02/08

28.1.5 Oscillators

TOSCn Timer Oscillator pin x XTALn Input/Ouptut to inverting Oscillator

28.1.6 DEBUG/SYSTEM functions

TEST Test pin PROG Programming pin RESET Reset pin PDI_CLK Program and Debug Interface Clock PDI_DATA Program and Debug Interface Data TCK JTAG Test Clock TDI JTAG Test Data In TDO JTAG Test Data Out TMS JTAG Test Mode Select

ATxmega A3

28.2 Alternate Pin Functions

The tables below shows the main and alternate pin functions for all pins on each port. It also shows which peripheral which make use of or enable the alte rnate pin function.

Table 28-1. Port A - Alternate functions

PORT A PIN # INTERRUPT ADCA POS ADCA NEG GND 60 AVCC 61 PA0 62 SYNC ADC0 ADC0 ADC0 AC0 AC0 AREFA PA1 63 SYNC ADC1 ADC1 ADC1 AC1 AC1 PA2 64 SYNC/ASYNC ADC2 ADC2 ADC2 AC2 DAC0 PA3 1 SYNC ADC3 ADC3 ADC3 AC3 AC3 DAC1 PA4 2 SYNC ADC4 ADC4 ADC4 AC4 PA5 3 SYNC ADC5 ADC5 ADC5 AC5 AC5 PA6 4 SYNC ADC6 ADC6 ADC6 AC6 PA7 5 SYNC ADC7 ADC7 ADC7 AC7 AC0 OUT

ADAA

GAINPOS

Table 28-2. Port B - Alternate functions

PORT B PIN # INTERRUPT PB0 6 SYNC ADC0 ADC0 ADC0 AC0 AC0 AREFB PB1 6 SYNC ADC1 ADC1 ADC1 AC1 AC1 PB2 8 SYNC/ASYNC ADC2 ADC2 ADC2 AC2 DAC0 PB3 9 SYNC ADC3 ADC3 ADC3 AC3 AC3 DAC1 PB4 10 SYNC ADC4 ADC4 ADC4 AC4 TMS

ADCB

POS

ADCB

NEG

ADCB

GAINPOS

GAINNEG ACB POS ACB NEG ACB OUT DACB REFB JTAG

ADCA

GAINNEG ACA POS ACA NEG ACA OUT DACA REFA

ADCB

8068A–AVR–02/08

ATxmega A3

Table 28-2. Port B - Alternate functions

PORT B PIN # INTERRUPT PB5 11 SYNC ADC5 ADC5 ADC5 AC5 AC5 TDI PB6 12 SYNC ADC6 ADC6 ADC6 AC6 TCK PB7 13 SYNC ADC7 ADC7 ADC7 AC7 AC0 OUT TDO GND 14 VCC 15

ADCB

POS

Table 28-3. Port C - Alternate functions

PORT C PIN # INTERRUPT TCC0 AWEXC TCC1 USARTC0 USARTC1 SPIC TWIC CLOCKOUT EVENTOUT PC0 16 SYNC OC0A OC0A SDA PC1 17 SYNC OC0B OC0A XCK0 SCL PC2 18 SYNC/ASYNC OC0C OC0B RXD0 PC3 19 SYNC OC0D OC0B TXD0 PC4 20 SYNC OC0C OC1A SS PC5 21 SYNC OC0C OC1B XCK1 MOSI PC6 22 SYNC OC0D RXD1 MISO PC7 23 SYNC OC0D TXD1 SCK CLKOUT EVOUT GND 24 VCC 25

ADCB

NEG

ADCB

GAINPOS

ADCB

GAINNEG ACB POS ACB NEG ACB OUT DACB REFB JTAG

Table 28-4. Port D - Alternate functions

PORT D PIN # INTERRUPT TCD0 TCD1 USARTD0 USARTD1 SPDI TWID CLOCKOUT EVENTOUT PD0 26 SYNC OC0A SDA PD1 27 SYNC OC0B XCK0 SCL PD2 28 SYNC/ASYNC OC0C RXD0 PD3 29 SYNC OC0D TXD0 PD4 30 SYNC OC1A SS PD5 31 SYNC OC1B XCK1 MOSI PD6 32 SYNC RXD1 MISO PD7 33 SYNC TXD1 SCK CLKOUT EVOUT GND 34 VCC 35

Table 28-5. Port E - Alternate functions

PORT E PIN # INTERRUPT TCE0 AWEXEI TCE1 USARTE0 USARTE1 SPIE TWIE CLOCKOUT EVENTOUT PE0 36 SYNC OC0A OC0A PE1 37 SYNC OC0B OC0A XCK0 SCL PE2 38 SYNC/ASYNC OC0C OC0B RXD0 PE3 39 SYNC OC0D OC0B TXD0 PE4 40 SYNC OC0C PE5 41 SYNC OC0C OC1B XCK1 MOSI

OC1A SS

SDA

8068A–AVR–02/08

ATxmega A3

Table 28-5. Port E - Alternate functions

PORT E PIN # INTERRUPT TCE0 AWEXEI TCE1 USARTE0 USARTE1 SPIE TWIE CLOCKOUT EVENTOUT PE6 42 SYNC OC0D RXD1 MISO PE7 43 SYNC OC0D TXD1 SCK CLKOUT EVOUT GND 44 VCC 45

Table 28-6. Port F - Alternate functions

PORT F PIN # INTERRUPT TCF0 TCF1 USARTF0 USARTF1 SPIF TWIF PF0 46 SYNC OC0A SDA PF1 47 SYNC OC0B XCK0 SCL PF2 48 SYNC/ASYNC OC0C RXD0 PF3 49 SYNC OC0D TXD0 PF4 50 SYNC OC1A SS PF5 51 SYNC OC1B XCK1 MOSI PF6 54 SYNC RXD1 MISO PF7 55 SYNC TXD1 SCK GND 52 VCC 53

8068A–AVR–02/08

29. Electrical Characteristics - TBD

29.1 Absolute Maximum Ratings*

ATxmega A3

Operating Temperature.................................. -55°C to +125°C

*NOTICE: Stresses beyond those listed under “Absolute

Maximum Ratings” may cause permanent dam-

Storage Temperature..................................... -65°C to +150°C

age to the device. This is a stress rating only and functional operation of the device at these or

Voltage on any Pin with respect to Ground..-0.5V to V

+0.5V

other conditions beyond those indicated in the operational sections of this specification is not

Maximum Operating Voltage ............................................ 3.6V

implied. Exposure to absolute maximum rating conditions for extended periods may affect

DC Current per I/O Pin............................................... 20.0 mA

DC Current

and GND Pins................................ 200.0 mA

device reliability.

29.2 DC Characteristics

TA = -40°C to 85°C, VCC = 1.8V to 3.6V (unless otherwise noted)

Symbol Parameter Condition Min. Typ. Max. Units

IL1

IH1

RST

Input Low Voltage, except XTAL1 pin V Input Low Voltage, XTAL1 pins V Input High Voltage, except XTAL1 pin V Input High Voltage, XTAL1 pin V Output Low Voltage Output High Voltage Input Leakage

Current I/O Pin Input Leakage

Current I/O Pin Reset Pull-up Resistor kΩ I/O Pin Pull-up Resistor kΩ

Active 32 MHz mA Active 20 MHz mA

Power Supply Current

Active 8MHz mA

µA

Idle 20 MHz mA WDT disabled µA

Idle 32 MHz mA

Power-down mode

WDT slow sampling µA WDT fast sampling

Note: 1. “Max” means the highest value where the pin is guaranteed to be read as low

2. “Min” means the lowest value where the pin is guaranteed to be read as high

8068A–AVR–02/08

ATxmega A3

29.3 ADC Characteristics – TBD

Table 29-1. ADC Characteristics

Symbol Parameter Condition Min Typ Max Units

Resolution LSB Integral Non-Linearity (INL) LSB Differential Non-Linearity (DNL) LSB Gain Error LSB Offset Error LSB Conversion Time µs ADC Clock Frequency MHz DC Supply Voltage mA Source Impedance Ω Start-up time µs

AVCC Analog Supply Voltage VCC - 0.3 VCC + 0.3 V

Table 29-2. ADC Gain Stage Characteristics

Symbol Parameter Condition Min Typ Max Units

Gain Input Capacitance pF Offset Error mV Gain Error % Signal Range V DC Supply Current mA

Start-up time

# clk

cycles

8068A–AVR–02/08

ATxmega A3

29.4 DAC Characteristics – TBD

Table 29-3. DAC Characteristics

Symbol Parameter Condition Min Typ Max Units

Resolution LSB Integral Non-Linearity (INL) LSB Differential Non-Linearity (DNL) LSB Gain Error LSB Offset Error LSB Calibrated Gain/Offset Error LSB Output Range V Output Settling Time µs Output Capacitance nF Output Resistance kΩ Reference Input Voltage V Reference Input Capacitance pF Reference Input Resistance kΩ Current Consumption mA Start-up time µs

29.5 Analog Comparator Characteristics – TBD

Table 29-4. Analog Comparator Characteristics

Symbol Parameter Condition Min Typ Max Units

Offset mV

Hysteresis

High High Speed mode

Propagation Delay

Low power mode High Speed mode

Current Consumption

Low power mode

Start-up time µs

mVLow

µA

8068A–AVR–02/08

30. Typical Characteristics - TBD

ATxmega A3

8068A–AVR–02/08

31. Peripheral Module Address Map

The address maps shows the base address for each peripheral and module in XMEGA A3. For complete register description and summa ry for each peripheral modu le, refer to the XMEGA A Manual.

Base Address Name Description

0x0000 GPIO General Purpose IO Registers 0x0010 VPORT0 Virtual Port 0 0x0014 VPORT1 Virtual Port 1 0x0018 VPORT2 Virtual Port 2 0x001C VPORT3 Virtual Port 2 0x0030 CPU CPU 0x0040 CLK Clock Control 0x0048 SLEEP Sleep Controller 0x0050 OSC Oscillator Control 0x0060 DFLLRC32M DFLL for the 32 MHz Internal RC Oscillator 0x0068 DFLLRC2M DFLL for the 2 MHz RC Oscillator 0x0070 PR Power Reduction 0x0078 RST Reset Controller 0x0080 WDT Watch-Dog Timer 0x0090 MCU MCU Control 0x00A0 PMIC Programmable MUltilevel Interrupt Controller 0x00B0 PORTCFG Port Configuration 0x00C0 AES AES Module 0x0100 DMA DMA Controller 0x0180 EVSYS Event System 0x01C0 NVM Non Volatile Memory (NVM) Controller 0x0200 ADCA Analog to Digital Converter on port A 0x0240 ADCB Analog to Digital Converter on port B 0x0320 DACB Digital to Analog Converter on port B 0x0380 ACA Analog Comparator pair on port A 0x0390 ACB Analog Comparator pair on port B 0x0400 RTC Real Time Counter 0x0480 TWIC Two Wire Interface on port C 0x0490 TWID Two Wire Interface on port D 0x04A0 TWIE Two Wire Interfaceon port E 0x04B0 TWIF Two Wire Interface on port F 0x0600 PORTA Port A 0x0620 PORTB Port B 0x0640 PORTC Port C 0x0660 PORTD Port D 0x0680 PORTE Port E 0x06A0 PORTF Port F 0x07E0 PORTR Port R 0x0800 TCC0 Timer/Counter 0 on port C 0x0840 TCC1 Timer/Counter 1 on port C 0x0880 AWEXC Advanced Waveform Extension on port C 0x0890 HIRESC High Resolution Extension on port C 0x08A0 USARTC0 USART 0 on port C 0x08B0 USARTC1 USART 1 on port C 0x08C0 SPIC Serial Peripheral Interface on port C 0x08F8 IRCOM Infrared Communication Module 0x0900 TCD0 Timer/Counter 0 on port D 0x0940 TCD1 Timer/Counter 1 on port D 0x0990 HIRESD High Resolution Extension on port D 0x09A0 USARTD0 USART 0 on port D 0x09B0 USARTD1 USART 1 on port D 0x09C0 SPID Serial Peripheral Interface on port D 0x0A00 TCE0 Timer/Counter 0 on port E 0x0A40 TCE1 Timer/Counter 1 on port E 0x0A80 AWEXE Advanced Waveform Extensionon port E 0x0A90 HIRESE High Resolution Extension on port E 0x0AA0 USARTE0 USART 0 on port E 0x0AB0 USARTE1 USART 1 on oirt E

ATxmega A3

8068A–AVR–02/08

Base Address Name Description

0x0AC0 SPIE Serial Peripheral Interface on port E 0x0B00 TCF0 Timer/Counter 0 on port F 0x0B40 TCF1 Timer/Counter 1 on port F 0x0B90 HIRESF High Resolution Extension on port F 0x0BA0 USARTF0 USART 0 on port F 0x0BB0 USARTF1 USART 1 on port F 0x0BC0 SPIF Serial Peripheral Interface on port F

ATxmega A3

8068A–AVR–02/08

32. Packaging information

32.1 64A

PIN 1

PIN 1 IDENTIFIER

ATxmega A3

E1 E

0°~7°

Notes:

1.This package conforms to JEDEC reference MS-026, Variation AEB.

2. Dimensions D1 and E1 do not include mold protrusion. Allowable protrusion is 0.25 mm per side. Dimensions D1 and E1 are maximum plastic body size dimensions including mold mismatch.

3. Lead coplanarity is 0.10 mm maximum.

A2 A

SYMBOL

COMMON DIMENSIONS

(Unit of Measure = mm)

MIN

A – – 1.20

A1 0.05 – 0.15

A2 0.95 1.00 1.05

D 15.75 16.00 16.25

D1 13.90 14.00 14.10 Note 2

E 15.75 16.00 16.25

E1 13.90 14.00 14.10 Note 2

B 0.30 – 0.45

C 0.09 – 0.20

L 0.45 – 0.75

e 0.80 TYP

NOM

MAX

NOTE

2325 Orchard Parkway

San Jose, CA 95131

8068A–AVR–02/08

TITLE

64A, 64-lead, 14 x 14 mm Body Size, 1.0 mm Body Thickness,

0.8 mm Lead Pitch, Thin Profile Plastic Quad Flat Package (TQFP)

10/5/2001

DRAWING NO.

64A

REV.

32.2 64M1

Marked Pin# 1 ID

ATxmega A3

SEATING PLANE

TOP VIEW

BOTTOM VIEW

1. JEDEC Standard MO-220, (SAW Singulation) Fig. 1, VMMD.

Note:

2. Dimension and tolerance conform to ASMEY14.5M-1994.

Pin #1 Corner

1 2 3

Option A

Option B

Option C

Pin #1 Triangle

Pin #1 Chamfer (C 0.30)

Pin #1 Notch (0.20 R)

SIDE VIEW

SYMBOL

A 0.80 0.90 1.00

A1 – 0.02 0.05

b 0.18 0.25 0.30

D2 5.20 5.40 5.60

E2 5.20 5.40 5.60

e 0.50 BSC

L 0.35 0.40 0.45

K 1.25 1.40 1.55

0.08

COMMON DIMENSIONS

(Unit of Measure = mm)

MIN

8.90 9.00 9.10

NOM

MAX

NOTE

2325 Orchard Parkway

San Jose, CA 95131

8068A–AVR–02/08

TITLE

64M1, 64-pad, 9 x 9 x 1.0 mm Body, Lead Pitch 0.50 mm,

5.40 mm Exposed Pad, Micro Lead Frame Package (MLF)

DRAWING NO.

64M1

5/25/06

REV.

33. Errata

33.1 All rev.

ATxmega A3

No known errata.

8068A–AVR–02/08

34. Datasheet Revision History

34.1 8068A – 02/08

1. Initial revision.

ATxmega A3

8068A–AVR–02/08

Features.....................................................................................................1

Typical Applications ................................................................................ 1

1 Block Diagram/Pinout ..............................................................................2

2 Ordering Information ............................................................................... 3

3 Disclaimer .................................................................................................4

4 Overview ...................................................................................................4

5 Resources .................................................................................................4

5.1Recommended reading .............................................................................................4

6 AVR CPU ................................................................................................... 5

6.1Features ....................................................................................................................5

6.2Overview ................. .......... ...... .......... .......... ......... .......... .......... .......... ...... .......... ........5

ATxmega A3

6.3Register File ..............................................................................................................6

6.4ALU - Arithmetic Logic Unit .............................................. .... ... ..................................6

6.5Program Flow ............................................................................................................6

7 Memories ..................................................................................................7

7.1Features ....................................................................................................................7

7.2Overview ................. .......... ...... .......... .......... ......... .......... .......... .......... ...... .......... ........7

7.3In-system Programmable Flash Program Memory ....................................................7

7.4SRAM Data Memory ..................................................................................................8

7.5EEPROM Data Memory ............................................. ... ... .... .....................................8

7.6I/O Memory ..............................................................................................................10

8 DMA - Direct Memory Access Controller ............................................. 11

8.1Features ..................................................................................................................11

8.2Overview ................. .......... ...... .......... .......... ......... .......... .......... .......... ...... .......... ......11

9 Event System ..........................................................................................12

9.1Features ..................................................................................................................12

9.2Overview ................. .......... ...... .......... .......... ......... .......... .......... .......... ...... .......... ......12

10 System Clock and Clock options .........................................................14

10.1Features ................................................................................................................14

10.2Overview ...................... ................ ................ ................ ................ ............. .............14

10.3Clock Options ........................................................................................................16

8068A–AVR–02/08

11 Power Management and Sleep Modes ................................................. 17

11.1Features ................................................................................................................17

11.2Overview ...................... ................ ................ ................ ................ ............. .............17

11.3Sleep Modes ..........................................................................................................17

12 System Control and Reset .................................................................... 19

12.1Resetting the AVR .................................................................................................19

12.2Reset Sources ....................................... ... ... ... ... ....................................................19

12.3WDT - Watchdog Timer .................. ... .... ... ... .................................................... ... ...20

13 PMIC - Programmable Multi-level Interrupt Controller ....................... 21

13.1Features ................................................................................................................21

13.2Overview ...................... ................ ................ ................ ................ ............. .............21

13.3Interrupt vectors . ... ... .... ................................................... .... ...................................21

14 I/O Ports ..................................................................................................23

ATxmega A3

14.1Features ................................................................................................................23

14.2Overview ...................... ................ ................ ................ ................ ............. .............23

14.3I/O configuration ... ... .... ... ... .................................................... ... ... ..........................23

14.4Push-pull ......................... ................ ................ ................ ................. ................ ......24

14.5Pull-down ..................... ................................................ .......................................... 24

14.6Pull-up ...................................................................................................................24

14.7Bus-keeper ............................................................................................................24

14.8Others ...................... .............................................. ............................................. ...25

14.9Port Interrupt ..........................................................................................................25

14.10Input sensing ...... ... .... ... ... .................................................... ... ... ..........................26

15 T/C - 16-bits Timer/Counter with PWM .................................................27

15.1Features ................................................................................................................27

15.2Overview ...................... ................ ................ ................ ................ ............. .............27

16 AWEX - Advanced Waveform Extension .............................................28

16.1Features ................................................................................................................28

16.2Overview ...................... ................ ................ ................ ................ ............. .............28

17 RTC - Real-Time Counter .......................................................................29

17.1Features ................................................................................................................29

17.2Overview ...................... ................ ................ ................ ................ ............. .............29

18 TWI - Two Wire Interface .......................................................................30

18.1Features ................................................................................................................30

8068A–AVR–02/08

18.2Overview ...................... ................ ................ ................ ................ ............. .............30

19 SPI - Serial Peripheral Interface ............................................................31

19.1Features ................................................................................................................31

19.2Overview ...................... ................ ................ ................ ................ ............. .............31

20 USART ..................................................................................................... 32

20.1Features ................................................................................................................32

20.2Overview ...................... ................ ................ ................ ................ ............. .............32

21 IRCOM - IR Communication Module .....................................................33

21.1Features ................................................................................................................33

21.2Overview ...................... ................ ................ ................ ................ ............. .............33

22 Crypto Engine .........................................................................................34

22.1Features ................................................................................................................34

22.2Overview ...................... ................ ................ ................ ................ ............. .............34

ATxmega A3

23 ADC - 12-bit Analog to Digital Converter ............................................. 35

23.1Features ................................................................................................................35

23.2Overview ...................... ................ ................ ................ ................ ............. .............35

24 DAC - 12-bit Digital to Analog Converter ............................................. 37

24.1Features ................................................................................................................37

24.2Overview ...................... ................ ................ ................ ................ ............. .............37

25 AC - Analog Comparator .......................................................................38

25.1Features ................................................................................................................38

25.2Overview ...................... ................ ................ ................ ................ ............. .............38

25.3Input Selection .......................................................................................................40

25.4Window Function ......................................................................................... .... ... ...40

26 OCD - On-chip Debug ............................................................................41

26.1Features ................................................................................................................41

26.2Overview ...................... ................ ................ ................ ................ ............. .............41

27 Program, Debug and Test Interfaces ...................................................42

27.1Features ................................................................................................................42

27.2Overview ...................... ................ ................ ................ ................ ............. .............42

27.3JTAG interface .......................................................................................................42

27.4PDI - Program and Debug Interface ......................................................................42

28 Pinout ...................................................................................................... 43

8068A–AVR–02/08

iii

28.1Alternate Pin Function Description ........................................................................43

28.2Alternate Pin Functions .........................................................................................44

29 Electrical Characteristics - TBD ............................................................47

29.1Absolute Maximum Ratings* ....................................... ... .......................................47

29.2DC Characteristics .................................................................................................47

29.3ADC Characteristics – TBD ...................................................................................48

29.4DAC Characteristics – TBD ...................................................................................49

29.5Analog Comparator Characteristics – TBD ...........................................................49

30 Typical Characteristics - TBD ...............................................................50

31 Peripheral Module Address Map .......................................................... 51

32 Packaging information .......................................................................... 53

32.164A ........................................................................................................................53

32.264M1 ........................ ............. .......... ............. ............. ............. ............. ............. ......54

ATxmega A3

33 Errata ....................................................................................................... 55

33.1All rev. ....................................................................................................................55

34 Datasheet Revision History ...................................................................56

34.18068A – 02/08 .......................................................................................................56

Table of Contents.......................................................................................i

8068A–AVR–02/08

ATxmega A3

8068A–AVR–02/08

Headquarters International

Atmel Corporation

2325 Orchard Parkway San Jose, CA 95131 USA Tel: 1(408) 441-0311 Fax: 1(408) 487-2600

Atmel Asia

Room 1219 Chinachem Golden Plaza 77 Mody Road Tsimshatsui East Kowloon Hong Kong Tel: (852) 2721-9778 Fax: (852) 2722-1369

Product Contact

Web Site

www.atmel.com

Literature Requests

www.atmel.com/literature

Atmel Europe

Le Krebs 8, Rue Jean-Pierre Timbaud BP 309 78054 Saint-Quentin-enYvelines Cedex France Tel: (33) 1-30-60-70-00 Fax: (33) 1-30-60-71-11

Technical Support

avr@atmel.com

Atmel Japan

9F, Tonetsu Shinkawa Bldg. 1-24-8 Shinkawa Chuo-ku, Tokyo 104-0033 Japan Tel: (81) 3-3523-3551 Fax: (81) 3-3523-7581

Sales Contact

www.atmel.com/contacts

Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual pro perty right is granted by this document or in connection w ith the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDI-

TIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL ATMEL BE LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENT AL DAMAGES (INCL UDING, WIT HOUT LI MITATION, DAMAGES FOR LOSS OF PR OFIT S, BU SINESS I NTERR UPTI ON, OR L OSS OF INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF ATMEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Atmel makes no

representations or warranties with respect to the accuracy or complete ness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Atmel does not make any commitment to update the information contained here in. Unless specifically provided otherwise, Atmel products are not suitable for, and shall not be used in, automotive applications. Atmel’s products are not intended, authorized, or warranted for use as components in applications intended to suppor t or sustain life.

© 2008 Atmel Corporation. All rights reserved. Atmel®, logo and combinations thereof, AVR® and others are registered trademarks or trade- marks of Atmel Corporation or its subsidiaries. Other term s and product names may be trademarks of others.

8068A–AVR–02/08

ATMEL ATxmega64A3, ATxmega256A3, ATA5746-PXQW, ATA5745 Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual

Features

Typical Applications

1. Block Diagram/Pinout

2. Ordering Information

3. Disclaimer

4. Overview

5. Resources

5.1 Recommended reading

6. AVR CPU

6.1 Features

6.2 Overview

6.3 Register File

6.4 ALU - Arithmetic Logic Unit

6.5 Program Flow

7. Memories

7.1 Features

7.2 Overview

7.3 In-system Programmable Flash Program Memory

7.4 SRAM Data Memory

7.5 EEPROM Data Memory

7.6 I/O Memory

8. DMA - Direct Memory Access Controller

8.1 Features

8.2 Overview

9. Event System

9.1 Features

9.2 Overview

10. System Clock and Clock options

10.1 Features

10.2 Overview

10.3 Clock Options

10.3.1 32 kHz Ultra Low Power Internal Oscillator

10.3.2 32 kHz Calibrated Internal Oscillator

10.3.3 32 kHz Crystal Oscillator

10.3.4 0.4 - 16 MHz Crystal Oscillator

10.3.5 2 MHz Run-ti me Ca librat ed Interna l Os ci lla tor

10.3.6 32 MHz Run-time Calibrated Internal Oscillator

10.3.7 External Clock input

10.3.8 PLL with Multiplication factor 2 - 31x

11. Power Management and Sleep Modes

11.1 Features

11.2 Overview

11.3 Sleep Modes

11.3.1 Idle Mode

11.3.2 Power-down Mode

11.3.3 Power-save Mode

11.3.4 Standby Mode

11.3.5 Extended Standby Mode

12. System Control and Reset

12.1 Resetting the AVR

12.2 Reset Sources

12.2.1 Power-on Reset

12.2.2 External Reset

12.2.3 Watchdog Reset

12.2.4 Brown-out Reset

12.2.5 JTAG AVR Reset

12.2.6 PDI reset

12.2.7 Software res et

12.3 WDT - Watchdog Timer

12.3.1 Features

12.3.2 Overview

13. PMIC - Programmable Multi-level Interrupt Controller

13.1 Features

13.2 Overview

13.3 Interrupt vectors

14. I/O Ports

14.1 Features

14.2 Overview

14.3 I/O configuration

14.4 Push-pull

14.5 Pull-down

14.6 Pull-up

14.7 Bus-keeper

14.8 Others

14.9 Port Interrupt

14.10 Input sensing
