Features

• High-performance, Low-power AVR 8/16-bit AVR XMEGA Microcontroller

• Non-volatile Program and Data Memories

– 16K - 128K Bytes of In-System Self-Programmable Flash – 4K Boot Code Section with Independent Lock Bits – 1K - 2K Bytes EEPROM – 2K - 8K Bytes Internal SRAM

• Peripheral Features

– Four-channel DMA Controller with support for external requests – Eight-channel Event System – Five 16-bit Timer/Counters

Three Timer/Counters with 4 Output Compare or Input Capture channels Two Timer/Counters with 2 Output Compare or Input Capture channels High-Resolution Extensions on all Timer/Counters Advanced Waveform Extension on one Timer/Counter

– Five USARTs

IrDA Extension on one USART

– Two Two-Wire Interfaces with dual address match (I – Two SPIs (Serial Peripheral Interfaces) peripherals – AES and DES Crypto Engine – 16-bit Real Time Counter with Separate Oscillator – One Twelve-channel, 12-bit, 2 Msps Analog to Digital Converter

– One Two-channel, 12-bit, 1 Msps Digital to Analog Converter – Two Analog Comparators with Window compare function – External Interrupts on all General Purpose I/O pins – Programmable Watchdog Timer with Separate On-chip Ultra Low Power Oscillator

• Special Microcontroller Features

– Power-on Reset and Programmable Brown-out Detection – Internal and External Clock Options with PLL – Programmable Multi-level Interrupt Controller – Sleep Modes: Idle, Power-down, Standby, Power-save, Extended Standby – Advanced Programming, Test and Debugging Interfaces

PDI (Program and Debug Interface) for programming, test and debugging

• I/O and Packages

– 36 Programmable I/O Lines – 44-lead TQFP – 44-pad MLF

• Operating Voltage

– 1.6 – 3.6V

• Speed performance

– 0 – 12 MHz @ 1.6 – 2.7V – 0 – 32 MHz @ 2.7 – 3.6V

C and SMBus compatible)

8/16-bit XMEGA A4

Microcontroller

ATxmega128A4 ATxmega64A4 ATxmega32A4 ATxmega16A4

Preliminary

Typical Applications

• Industrial control • Climate control • Hand-held battery applications

• Factory automation • ZigBee • Power tools

• Building control • Motor control • HVAC

• Board control • Networking • Metering

• White Goods • Optical • Medical Applications

8069C–AVR–06/08

1. Ordering Information

XMEGA A4

Ordering Code Flash (B) E2 (B) SRAM (B) Speed (MHz) Power Supply Package

(1)(2)(3)

Tem p

ATxmega128A4-AU 128K + 4K 2K 8K 32 1.6 - 3.6V

ATxmega64A4-AU 64K + 4K 2K 4K 32 1.6 - 3.6V

ATxmega32A4-AU 32K + 4K 2K 4K 32 1.6 - 3.6V

ATxmega16A4-AU 16K + 4K 1K 2K 32 1.6 - 3.6V

ATxmega128A4-MU 128K + 4K 2K 8K 32 1.6 - 3.6V

ATxmega64A4-MU 64K + 4K 2K 4K 32 1.6 - 3.6V

ATxmega32A4-MU 32K + 4K 2K 4K 32 1.6 - 3.6V

44A

-40° - 85°

44M1

ATxmega16A4-MU 16K + 4K 1K 2K 32 1.6 - 3.6V

Notes: 1. This device can also be supplied in wafer form. Please contact your local Atmel sales office for detailed ordering information.

2. Pb-free packaging, complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also Halide free and fully Green.

3. For packaging information see ”Packaging information” on page 56.

Package Type

44A

44M1

44-lead, 10 x 10 mm Body Size, 1.0 mm Body Thickness, 0.8 mm Lead Pitch, Thin Profile Plastic Quad Flat Package (TQFP)

44-pad, 7 x 7 x 1.0 mm Body, Lead Pitch 0.50 mm, 5.20 mm Exposed Pad, Micro Lead Frame Package (MLF)

2. Pinout/Block Diagram

Figure 2-1. Bock Diagram and TDFP-pinout.

INDEX CORNER

PA 5

PA 6

PA 7

PB0

PB1

PB2

PB3

GND

VCC

PC0

PC1

PA 4

PA 3

PA 2

PA 1

PA 0

AVCC

GND

PR1

PR0

RESET/PDI_CLK

PDI_DATA

ADC A

AC A0

Port

AC A1

DAC B

Port

PC2

PC3

PC4

T/C0:1

Port C

PC5

Port R

OSC/CLK

Control

Power

Control

Reset

Control

Watchdog

USART0:1

TWI

DATA BU S

BOD POR

TEMP

CPU

DMA

Interrupt Controller

Event System ctrl

DATA B U S

EVENT ROUTING NETWORK

T/C0:1

SPI

USART0:1

Port D

PC6

PC7

VREF

RTC

OCD

FLASH

RAM

E2PROM

T/C0

SPI

USART0

Port E

PD0

VCC

GND

TWI

PD1

PD2

Note: For full details on pinout and pin functions refer to ”Pinout and Pin Functions” on page 47.

PE3

PE2

VCC

GND

PE1

PE0

PD7

PD6

PD5

PD4

PD3

8069C–AVR–06/08

3. Overview

XMEGA A4

The XMEGA A4 is a family of low power, high performance and peripheral rich CMOS 8/16-bit microcontrollers based on the AVR instructions in a single clock cycle, the XMEGA A4 achieves throughputs approaching 1 Million Instructions Per Second (MIPS) per MHz allowing the system designer to optimize power consumption versus processing speed.

The AVR CPU combines a rich instruction set with 32 general purpose working registers. All the 32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing two independent registers to be accessed in one single instruction, executed in one clock cycle. The resulting architecture is more code efficient while achieving throughputs many times faster than conventional single-accumulator or CISC based microcontrollers.

The XMEGA A4 devices provides the following features: In-System Programmable Flash with Read-While-Write capabilities, Internal EEPROM and SRAM, four-channel DMA Controller, eight-channel Event System, Programmable Multi-level Interrupt Controller, 36 general purpose I/O lines, 16-bit Real Time Counter (RTC), five flexible 16-bit Timer/Counters with compare modes and PWM, five USARTs, two Two Wire Serial Interfaces (TWIs), two Serial Peripheral Interfaces (SPIs), AES and DES crypto engine, one Twelve-channel, 12-bit ADC with optional differential input with programmable gain, one Two-channel, 12-bit DAC, two analog comparators with window mode, programmable Watchdog Timer with separate Internal Oscillator, accurate internal oscillators with PLL and prescaler and programmable Brown-Out Detection.

The Program and Debug Interface (PDI), a fast 2-pin interface for programming and debugging, is available.

enhanced RISC architecture. By executing powerful

The XMEGA A4 devices have five software selectable power saving modes. The Idle mode stops the CPU while allowing the SRAM, DMA Controller, Event System, Interrupt Controller and all peripherals to continue functioning. The Power-down mode saves the SRAM and register contents but stops the oscillators, disabling all other functions until the next TWI or pin-change interrupt, or Reset. In Power-save mode, the asynchronous Real Time Counter continues to run, allowing the application to maintain a timer base while the rest of the device is sleeping. In Standby mode, the Crystal/Resonator Oscillator is kept running while the rest of the device is sleeping. This allows very fast start-up from external crystal combined with low power consumption. In Extended Standby mode, both the main Oscillator and the Asynchronous Timer continue to run. To further reduce power consumption, the peripheral clock to each individual peripheral can optionally be stopped in Active mode and in Idle sleep mode.

The device is manufactured using Atmel's high-density nonvolatile memory technology. The program Flash memory can be reprogrammed in-system through the PDI. A Bootloader running in the device can use any interface to download the application program to the Flash memory. The Bootloader software in the Boot Flash section will continue to run while the Application Flash section is updated, providing true Read-While-Write operation. By combining an 8/16-bit RISC CPU with In-System Self-Programmable Flash, the Atmel XMEGA A4 is a powerful microcontroller family that provides a highly flexible and cost effective solution for many embedded applications.

The XMEGA A4 devices is supported with a full suite of program and system development tools including: C compilers, macro assemblers, program debugger/simulators, programmers, and evaluation kits.

8069C–AVR–06/08

3.1 Block Diagram

Figure 3-1. XMEGA A4 Block Diagram

XMEGA A4

PR[0..1]

XTAL1/ TOSC1

XTAL2/ TOSC2

PA[0..7]

PB[0..3]

PORT A (8)

ACA

ADCA

AREFA

Internal

Reference

AREFB

PORT B (4)

DACB

Event System

Controller

DMA

Controller

BUS

Controller

DES

AES

Oscillator

Circuits/

Clock

PORT R (2)

DATA BUS

CPU

NVM Controlle r

Flash EEPROM

Generation

Oscillator

Control

SRAM

Controller

Prog/Debug

Controller

Interrupt

Controller

Sleep

OCD

Real Time

Counter

Watchdog

Oscillator

Watchdog

Timer

Power Supervision POR/BOD &

RESET

PDI

TWIE

USARTE0

TCE0

VCC

GND

RESET/ PDI_CLK

PDI_DATA

PE[0..3]

PORT E (4)

8069C–AVR–06/08

IRCOM

TCC0:1

USARTC0:1

PORT C (8)

PC[0..7]

EVENT ROUTING NETWORK

SPIC

TWIC

DATA BUS

TCD0:1

PORT D (8)

PD[0.. 7 ]

SPID

USARTD0:1

4. Resources

A comprehensive set of development tools, application notes and datasheets are available for download on http://www.atmel.com/avr.

4.1 Recommended reading

• XMEGA A Manual

• XMEGA A Application Notes

This device data sheet only contains part specific information and a short description of each peripheral and module. The XMEGA A Manual describes the modules and peripherals in depth. The XMEGA A application notes contain example code and show applied use of the modules and peripherals.

The XMEGA A Manual and Application Notes are available from http://www.atmel.com/avr.

5. Disclaimer

For devices that are not available yet, typical values contained in this datasheet are based on simulations and characterization of other AVR XMEGA microcontrollers manufactured on the same process technology. Min. and Max values will be available after the device is characterized.

XMEGA A4

8069C–AVR–06/08

6. AVR CPU

6.1 Features

6.2 Overview

XMEGA A4

• 8/16-bit high performance AVR RISC Architecture

– 138 instructions – Hardware multiplier

• 32x8-bit registers directly connected to the ALU

• Stack in RAM

• Stack Pointer accessible in I/O memory space

• Direct addressing of up to 16M Bytes of program and data memory

• True 16/24-bit access to 16/24-bit I/O registers

• Support for 8-, 16- and 32-bit Arithmetic

• Configuration Change Protection of system critical features

The XMEGA A4 uses the 8/16-bit AVR CPU. The main function of the CPU is program execution. The CPU must therefore be able to access memories, perform calculations and control peripherals. Interrupt handling is described in a separate section. Figure 6-1 on page 6 shows the CPU block diagram.

Figure 6-1. CPU block diagram

Program

Counter

OCD

STATUS/

CONTROL

Peripheral

Module 1

Peripheral

Module 2

DATA BUS

Flash

Program

Memory

Instruction

Decode

ALU

DATA BUS

32 x 8 General

Purpose

Registers

Multiplier/

DES

EEPROM PMICSRAM

8069C–AVR–06/08

The AVR uses a Harvard architecture - with separate memories and buses for program and data. Instructions in the program memory are executed with a single level pipeline. While one instruction is being executed, the next instruction is pre-fetched from the program memory. This

concept enables instructions to be executed in every clock cycle. The program memory is InSystem Re-programmable Flash memory.

6.3 Register File

The fast-access Register File contains 32 x 8-bit general purpose working registers with single clock cycle access time. This allows single-cycle Arithmetic Logic Unit (ALU) operation. In a typical ALU cycle, the operation is performed on two Register File operands, and the result is stored back in the Register File.

Six of the 32 registers can be used as three 16-bit address register pointers for data space addressing - enabling efficient address calculations. One of these address pointers can also be used as an address pointer for look up tables in Flash program memory.

6.4 ALU - Arithmetic Logic Unit

The high performance Arithmetic Logic Unit (ALU) supports arithmetic and logic operations between registers or between a constant and a register. Single register operations can also be executed. Within a single clock cycle, arithmetic operations between general purpose registers or between a register and an immediate are executed. After an arithmetic or logic operation, the Status Register is updated to reflect information about the result of the operation.

XMEGA A4

6.5 Program Flow

The ALU operations are divided into three main categories – arithmetic, logical, and bit-functions. Both 8- and 16-bit arithmetic is supported, and the instruction set allows for efficient implementation of 32-bit arithmetic. The ALU also provides a powerful multiplier supporting both signed and unsigned multiplication and fractional format.

When the device is powered on, the CPU starts to execute instructions from the lowest address in the Flash Program Memory ‘0’. The Program Counter (PC) addresses the next instruction to be fetched. After a reset, the PC is set to location ‘0’.

Program flow is provided by conditional and unconditional jump and call instructions, capable of addressing the whole address space directly. Most AVR instructions use a 16-bit word format, while a limited number uses a 32-bit format.

During interrupts and subroutine calls, the return address PC is stored on the Stack. The Stack is effectively allocated in the general data SRAM, and consequently the Stack size is only limited by the total SRAM size and the usage of the SRAM. After reset the Stack Pointer (SP) points to the highest address in the internal SRAM. The SP is read/write accessible in the I/O memory space, enabling easy implementation of multiple stacks or stack areas. The data SRAM can easily be accessed through the five different addressing modes supported in the AVR CPU.

8069C–AVR–06/08

7. Memories

7.1 Features

7.2 Overview

XMEGA A4

• Flash Program Memory

– One linear address space – In-System Programmable – Self-Programming and Bootloader support – Application Section for application code – Application Table Section for application code or data storage – Boot Section for application code or bootloader code – Separate lock bits and protection for all sections

• Data Memory

– One linear address space – Single cycle access from CPU – SRAM – EEPROM

Byte or page accessible Optional memory mapping for direct load and store

– I/O Memory

Configuration and Status registers for all peripherals and modules

16-bit accessible General Purpose Register for global variables or flags – External Memory support – Bus arbitration

Safe and deterministic handling of CPU and DMA Controller priority – Separate buses for SRAM, EEPROM, I/O Memory and External Memory access

Simultaneous bus access for CPU and DMA Controller

• Calibration Row Memory for factory programmed data

Oscillator calibration bytes

Serial number

Device ID for each device type

• User Signature Row

One flash page in size

Can be read and written from software

Data is kept after Chip Erase

The AVR architecture has two main memory spaces, the Program Memory and the Data Memory. In addition, the XMEGA A4 features an EEPROM Memory for non-volatile data storage. All three memory spaces are linear and require no paging. The available memory size configurations are shown in ”Ordering Information” on page 2. In addition each device has a Flash memory signature row for calibration data, device identification, serial number etc.

Non-volatile memory spaces can be locked for further write or read/write operations. This prevents unrestricted access to the application software.

7.3 In-System Programmable Flash Program Memory

The XMEGA A4 devices contains On-chip In-System Programmable Flash memory for program storage, see Figure 7-1 on page 9. Since all AVR instructions are 16- or 32-bits wide, each Flash address location is 16 bits.

8069C–AVR–06/08

XMEGA A4

The Program Flash memory space is divided into Application and Boot sections. Both sections have dedicated Lock Bits for setting restrictions on write or read/write operations. The Store Program Memory (SPM) instruction must reside in the Boot Section when used to write to the Flash memory.

A third section inside the Application section is referred to as the Application Table section which has separate Lock bits for storage of write or read/write protection. The Application Table section can be used for storing non-volatile data or application software.

Figure 7-1. Flash Program Memory (Hexadecimal address)

Word Address

EFFF / 77FF / 37FF / 17FF

F000 / 7800 / 3800 / 1800

FFFF / 7FFF / 3FFF / 1FFF

10000 / 8000 / 4000 / 2000

10FFF / 87FF / 47FF / 27FF

Application Section

(128K/64K/32K/16K)

...

Application Table Section

(4K/4K/4K/4K)

Boot Section

(4K/4K/4K/4K)

The Application Table Section and Boot Section can also be used for general application software.

8069C–AVR–06/08

XMEGA A4

7.4 Data Memory

The Data Memory consist of the I/O Memory, EEPROM and SRAM memories, all within one linear address space, see Figure 7-2 on page 10. To simplify development, the memory map for all devices in the family is identical and with empty, reserved memory space for smaller devices.

Figure 7-2. Data Memory Map (Hexadecimal address)

Byte Address ATxmega64A4 Byte Address ATxmega32A4 Byte Address ATxmega16A4

1000

I/O Registers

(4KB)

EEPROM

(2K)

FFF FFF FFF

1000

17FF 17FF 17FF

I/O Registers

(4KB)

EEPROM

(2K)

RESERVED RESERVED RESERVED

1000

I/O Registers

(4KB)

EEPROM

(1K)

2000

2FFF 2FFF 27FF

3000

FFFFFF FFFFFF FFFFFF

External Memory

7.4.1 I/O Memory

Internal SRAM

(4K)

(0 to 16 MB)

2000

3000

Internal SRAM

(4K)

External Memory

(0 to 16 MB)

2000

2800

Byte Address ATxmega128A4

FFF

1000

17FF

2000

3FFF

4000

FFFFFF

Internal SRAM

External Memory

(0 to 16 MB)

I/O Registers

RESERVED

Internal SRAM

External Memory

(0 to 16 MB)

(2K)

(4KB)

EEPROM

(2K)

(8K)

8069C–AVR–06/08

All peripherals and modules are addressable through I/O memory locations in the data memory space. All I/O memory locations can be accessed by the Load (LD/LDS/LDD) and Store (ST/STS/STD) instructions, transferring data between the 32 general purpose registers in the CPU and the I/O Memory.

The IN and OUT instructions can address I/O memory locations in the range 0x00 - 0x3F directly.

I/O registers within the address range 0x00 - 0x1F are directly bit-accessible using the SBI and CBI instructions. The value of single bits can be checked by using the SBIS and SBIC instructions on these registers.

The I/O memory address for all peripherals and modules in XMEGA A4 is shown in the ”Periph-

eral Module Address Map” on page 51.

7.4.2 SRAM Data Memory

The XMEGA A4 devices has internal SRAM memory for data storage.

7.4.3 EEPROM Data Memory

The XMEGA A4 devices has internal EEPROM memory for non-volatile data storage. It is addressable either in a separate data space or it can be memory mapped into the normal data memory space. The EEPROM memory supports both byte and page access.

7.5 Calibration Row

The Calibration Row is a separate memory section for factory programmed data. It contains calibration data for functions such as oscillators, device ID, and a factory programmed serial number that is unique for each device. The device ID for the available XMEGA A1 devices is shown in Table 7-1 on page 11. Some of the calibration values will be automatically loaded to the corresponding module or peripheral unit during reset. The Calibration Row can not be written or erased. It can be read from application software and external programming.

Table 7-1. Device ID bytes for XMEGA A4 devices.

XMEGA A4

Device Device ID bytes

Byte 2 Byte 1 Byte 0

ATxmega16A4 41 94 1E

7.6 User Signature Row

The User Signature Row is a separate memory section that is fully accessible (read and write) from application software and external programming. The User Signature Row is one flash page in size, and is meant for static user parameter storage, such as calibration data, custom serial numbers, random number seeds etc. This section is not erased by Chip Erase, and requires a dedicated erase command. This ensures parameter storage during multiple program/erase session and On-Chip Debug sessions.

ATxmega32A4 41 85 1E

ATxmega64A4 46 96 1E

ATxmega128A4 46 97 1E

8069C–AVR–06/08

XMEGA A4

7.7 Flash and EEPROM Page Size

The Flash Program Memory and EEPROM data memory is organized in pages. The pages are word accessible for the Flash and byte accessible for the EEPROM.

Table 7-2 on page 12 shows the Flash Program Memory organization. Flash write and erase

operations are performed on one page at the time, while reading the Flash is done one byte at the time. For Flash access the Z-pointer (Z[m:n]) is used for addressing. The most significant bits in the address (FPAGE) gives the page number and the least significant address bits (FWORD) gives the word in the page.

Table 7-2. Number of words and Pages in the Flash.

Devices Flash Page Size FWORD FPAGE Application Boot

Size (Bytes) (words) Size No of Pages Size No of Pages

ATxmega16A4 16K + 4K 128 Z[6:0] Z[13:7] 16K 64 4K 16

ATxmega32A4 32K + 4K 128 Z[6:0] Z[14:7] 32K 128 4K 16

ATxmega64A4 64K + 4K 128 Z[6:0] Z[15:7] 64K 128 4K 16

ATxmega128A4 128K + 4K 256 Z[7:0] Z[16:8] 128K 256 4K 16

Table 7-3 on page 12 shows EEPROM memory organization for the XMEGA A4 devices.

EEPROM write and erase operations can be performed one page or one byte at the time, while reading the EEPROM is done one byte at the time. For EEPROM access the NVM Address Register (ADDR[m:n]) is used for addressing. The most significant bits in the address (E2PAGE) gives the page number and the least significant address bits (E2BYTE) gives the byte in the page.

Table 7-3. Number of Bytes and Pages in the EEPROM.

Devices EEPROM Page Size E2BYTE E2PAGE No of Pages

Size (Bytes) (Bytes)

ATxmega16A4 1K 32 ADDR[4:0] ADDR[10:5] 32

ATxmega32A4 2K 32 ADDR[4:0] ADDR[10:5] 64

ATxmega64A4 2K 32 ADDR[4:0] ADDR[10:5] 64

ATxmega128A4 2K 32 ADDR[4:0] ADDR[10:5] 64

8069C–AVR–06/08

8. DMAC - Direct Memory Access Controller

8.1 Features

• Allows High-speed data transfer

– From memory to peripheral – From memory to memory – From peripheral to memory – From peripheral to peripheral

• 4 Channels

• From 1 byte and up to 16 M bytes transfers in a single transaction

• Multiple addressing modes for source and destination address

–Increment – Decrement – Static

• 1, 2, 4, or 8 bytes Burst Transfers

• Programmable priority between channels

8.2 Overview

The XMEGA A4 has a Direct Memory Access (DMA) Controller to move data between memories and peripherals in the data space. The DMA controller uses the same data bus as the CPU to transfer data.

XMEGA A4

It has 4 channels that can be configured independently. Each DMA channel can perform data transfers in blocks of configurable size from 1 to 64K bytes. A repeat counter can be used to repeat each block transfer for single transactions up to 16M bytes. Each DMA channel can be configured to access the source and destination memory address with incrementing, decrementing or static addressing. The addressing is independent for source and destination address. When the transaction is complete the original source and destination address can automatically be reloaded to be ready for the next transaction.

The DMAC can access all the peripherals through their I/O memory registers, and the DMA may be used for automatic transfer of data to/from communication modules, as well as automatic data retrieval from ADC conversions, data transfer to DAC conversions, or data transfer to or from port pins. A wide range of transfer triggers is available from the peripherals, Event System and software. Each DMA channel has different transfer triggers.

To allow for continuous transfer, two channels can be interlinked so that the second takes over the transfer when the first is finished and vice versa.

The DMA controller can read from memory mapped EEPROM, but it cannot write to the EEPROM or access the Flash.

8069C–AVR–06/08

9. Event System

9.1 Features

9.2 Overview

• Inter-peripheral communication and signalling with minimum latency

• CPU and DMA independent operation

• 8 Event Channels allow for up to 8 signals to be routed at the same time

• Events can be generated by

– TImer/Counters (TCxn) – Real Time Counter (RTC) – Analog to Digital Converters (ADCx) – Analog Comparators (ACx) – Ports (PORTx) – System Clock (Clk – Software (CPU)

SYS

)

• Events can be used by

– TImer/Counters (TCxn) – Analog to Digital Converters (ADCx) – Digital to Analog Converters (DACx) – Ports (PORTx) – DMA Controller (DMAC) – IR Communication Module (IRCOM)

• The same event can be used by multiple peripherals for synchronized timing

• Advanced Features

– Manual Event Generation from software (CPU) – Quadrature Decoding – Digital Filtering

• Functions in Active and Idle mode

XMEGA A4

8069C–AVR–06/08

The Event System is a set of features for inter-peripheral communication. It enables the possibility for a change of state in one peripheral to automatically trigger actions in one or more peripherals. What changes in a peripheral that will trigger actions in other peripherals are configurable by software. It is a simple, but powerful system as it allows for autonomous control of peripherals without any use of interrupts, CPU or DMA resources.

The indication of a change in a peripheral is referred to as an event, and is usually the same as the interrupt conditions for that peripheral. Events are passed between peripherals using a dedicated routing network called the Event Routing Network. Figure 9-1 on page 15 shows a basic block diagram of the Event System with the Event Routing Network and the peripherals to which it is connected. This highly flexible system can be used for simple routing of signals, pin functions or for sequencing of events.

The maximum latency is two CPU clock cycles from when an event is generated in one peripheral, until the actions are triggered in one or more other peripherals.

The Event System is functional in both Active and Idle modes.

Figure 9-1. Event System Block Diagram

XMEGA A4

PORTx

ADCx

ClkSYS

CPU

RTC

Event Routing

Network

DACx

ACx

DMACIRCOM

T/Cxn

The Event Routing Network can directly connect together ADCs, DACs, Analog Comparators (ACx), I/O ports (PORTx), the Real-time Counter (RTC), Timer/Counters (T/C) and the IR Communication Module (IRCOM). Events can also be generated from software (CPU).

All events from all peripherals are always routed into the Event Routing Network. This consist of eight multiplexers where each can be configured in software to select which event to be routed into that event channel. All eight event channels are connected to the peripherals that can use events, and each of these peripherals can be configured to use events from one or more event channels to automatically trigger a software selectable action.

8069C–AVR–06/08

10. System Clock and Clock options

10.1 Features

• Fast start-up time

• Safe run-time clock switching

• Internal Oscillators:

– 32 MHz run-time calibrated RC oscillator – 2 MHz run-time calibrated RC oscillator – 32 kHz calibrated RC oscillator – 32 kHz Ultra Low Power (ULP) oscillator

• External clock options

– 0.4 - 16 MHz Crystal Oscillator – 32 kHz Crystal Oscillator – External clock

• PLL with internal and external clock options with 2 to 31x multiplication

• Clock Prescalers with 2 to 2048x division

• Fast peripheral clock running at 2 and 4 times the CPU clock speed

• Automatic Run-Time Calibration of internal oscillators

• Crystal Oscillator failure detection

10.2 Overview

XMEGA A4

XMEGA A4 has an advanced clock system, supporting a large number of clock sources. It incorporates both integrated oscillators, external crystal oscillators and resonators. A high frequency Phase Locked Loop (PLL) and clock prescalers can be controlled from software to generate a wide range of clock frequencies from the clock source input.

It is possible to switch between clock sources from software during run-time. After reset the device will always start up running from the 2 Mhz internal oscillator.

A calibration feature is available, and can be used for automatic run-time calibration of the internal 2 MHz and 32 MHz oscillators. This reduce frequency drift over voltage and temperature.

A Crystal Oscillator Failure Monitor can be enabled to issue a Non-Maskable Interrupt and switch to internal oscillator if the external oscillator fails. Figure 10-1 on page 17 shows the principal clock system in XMEGA A4.

8069C–AVR–06/08

Figure 10-1. Clock system overview

32 kHz ULP

Interna l Oscillator

32.768 kHz

Calibrated Internal

Oscilla to r

clk

XMEGA A4

ULP

WDT/BOD

RTC

2 MHz

Run-Time Calibrated

Interna l Oscillator

32 MHz

Run-time Calibr a ted

Interna l Oscillator

32.768 KHz

Crystal Oscillator

0.4 - 16 MHz

Crystal Oscillator

External

Clock Input

CLOCK CONTROL

UNIT

with PLL and

Prescaler

clk

PERIPHERALS

PER

INTERRUPT

NVM MEMORY

CPU

ADC DAC

PORTS

...

DMA

EVSYS

RAM

CPU

FLASH

EEPROM

Each clock source is briefly described in the following sub-sections.

10.3 Clock Options

10.3.1 32 kHz Ultra Low Power Internal Oscillator

The 32 kHz Ultra Low Power (ULP) Internal Oscillator is a very low power consumption clock source. It is used for the Watchdog Timer, Brown-Out Detection and as an asynchronous clock source for the Real Time Counter. This oscillator cannot be used as the system clock source, and it cannot be directly controlled from software.

10.3.2 32.768 kHz Calibrated Internal Oscillator

The 32.768 kHz Calibrated Internal Oscillator is a high accuracy clock source that can be used as the system clock source or as an asynchronous clock source for the Real Time Counter. It is calibrated during protection to provide a default frequency which is close to its nominal frequency.

8069C–AVR–06/08

10.3.3 32.768 kHz Crystal Oscillator

The 32.768 kHz Crystal Oscillator is a low power driver for an external watch crystal. It can be used as system clock source or as asynchronous clock source for the Real Time Counter.

10.3.4 0.4 - 16 MHz Crystal Oscillator

The 0.4 - 16 MHz Crystal Oscillator is a driver intended for driving both external resonators and crystals ranging from 400 kHz to 16 MHz.

10.3.5 2 MHz Run-time Calibrated Internal Oscillator

The 2 MHz Run-time Calibrated Internal Oscillator is a high frequency oscillator. It is calibrated during protection to provide a default frequency which is close to its nominal frequency. The oscillator can use the 32 kHz Calibrated Internal Oscillator or the 32 kHz Crystal Oscillator as a source for calibrating the frequency run-time to compensate for temperature and voltage drift hereby optimizing the accuracy of the oscillator.

10.3.6 32 MHz Run-time Calibrated Internal Oscillator

The 32 MHz Run-time Calibrated Internal Oscillator is a high frequency oscillator. It is calibrated during protection to provide a default frequency which is close to its nominal frequency. The oscillator can use the 32 kHz Calibrated Internal Oscillator or the 32 kHz Crystal Oscillator as a source for calibrating the frequency run-time to compensate for temperature and voltage drift hereby optimizing the accuracy of the oscillator.

XMEGA A4

10.3.7 External Clock input

The external clock input gives the possibility to connect a clock from an external source.

10.3.8 PLL with Multiplication factor 2 - 31x

The PLL provides the possibility of multiplying a frequency by any number from 2 to 31. In combination with the prescalers, this gives a wide range of output frequencies from all clock sources.

8069C–AVR–06/08

11. Power Management and Sleep Modes

11.1 Features

• 5 sleep modes

–Idle – Power-down –Power-save –Standby – Extended standby

• Power Reduction registers to disable clocks to unused peripherals

11.2 Overview

The XMEGA A4 provides various sleep modes tailored to reduce power consumption to a minimum. All sleep modes are available and can be entered from Active mode. In Active mode the CPU is executing application code. The application code decides when and what sleep mode to enter. Interrupts from enabled peripherals and all enabled reset sources can restore the microcontroller from sleep to Active mode.

In addition, Power Reduction registers provide a method to stop the clock to individual peripherals from software. When this is done, the current state of the peripheral is frozen and there is no power consumption from that peripheral. This reduces the power consumption in Active mode and Idle sleep mode.

XMEGA A4

11.3 Sleep Modes

11.3.1 Idle Mode

In Idle mode the CPU and Non-Volatile Memory are stopped, but all peripherals including the Interrupt Controller, Event System and DMA Controller are kept running. Interrupt requests from all enabled interrupts will wake the device.

11.3.2 Power-down Mode

In Power-down mode all system clock sources, and the asynchronous Real Time Counter (RTC) clock source, are stopped. This allows operation of asynchronous modules only. The only interrupts that can wake up the MCU are the Two Wire Interface address match interrupts, and asynchronous port interrupts, e.g pin change.

11.3.3 Power-save Mode

Power-save mode is identical to Power-down, with one exception: If the RTC is enabled, it will keep running during sleep and the device can also wake up from RTC interrupts.

11.3.4 Standby Mode

Standby mode is identical to Power-down with the exception that all enabled system clock sources are kept running, while the CPU, Peripheral and RTC clocks are stopped. This reduces the wake-up time when external crystals or resonators are used.

8069C–AVR–06/08

11.3.5 Extended Standby Mode

Extended Standby mode is identical to Power-save mode with the exception that all enabled system clock sources are kept running while the CPU and Peripheral clocks are stopped. This reduces the wake-up time when external crystals or resonators are used.

XMEGA A4

8069C–AVR–06/08

12. System Control and Reset

12.1 Features

• Multiple reset sources for safe operation and device reset

– Power-On Reset – External Reset – Watchdog Reset

The Watchdog Timer runs from separate, dedicated oscillator – Brown-Out Reset

Accurate, programmable Brown-Out levels – PDI reset – Software reset

• Asynchronous reset

– No running clock in the device is required for reset

• Reset status register

12.2 Resetting the AVR

During reset, all I/O registers are set to their initial values. The SRAM content is not reset. Application execution starts from the Reset Vector. The instruction placed at the Reset Vector should be an Absolute Jump (JMP) instruction to the reset handling routine. By default the Reset Vector address is the lowest Flash program memory address, ‘0’, but it is possible to move the Reset Vector to the first address in the Boot Section.

XMEGA A4

The I/O ports of the AVR are immediately tri-stated when a reset source goes active.

The reset functionality is asynchronous, so no running clock is required to reset the device.

After the device is reset, the reset source can be determined by the application by reading the Reset Status Register.

12.3 Reset Sources

12.3.1 Power-On Reset

The MCU is reset when the supply voltage VCC is below the Power-on Reset threshold voltage.

12.3.2 External Reset

The MCU is reset when a low level is present on the RESET pin.

12.3.3 Watchdog Reset

The MCU is reset when the Watchdog Timer period expires and the Watchdog Reset is enabled. The Watchdog Timer runs from a dedicated oscillator independent of the System Clock. For more details see ”WDT - Watchdog Timer” on page 22.

12.3.4 Brown-Out Reset

The MCU is reset when the supply voltage VCC is below the Brown-Out Reset threshold voltage and the Brown-out Detector is enabled. The Brown-out threshold voltage is programmable.

8069C–AVR–06/08

+ 48 hidden pages
