Features

• Incorporates the ARM926EJ-S

– DSP Instruction Extensions, ARM Jazelle – 32-KByte Data Cache, 32-KByte Instruction Cache, Write Buffer – CPU Frequency 400 MHz – Memory Management Unit – EmbeddedICE

™

, Debug Communication Channel Support

• Additional Embedded Memories

– One 64-KByte Internal ROM, Single-cycle Access at Maximum Matrix Speed – Two 16-KByte Internal SRAM, Single-cycle Access at Maximum Matrix Speed

• External Bus Interface (EBI)

– Supports SDRAM, Static Memory, ECC-enabled NAND Flash and CompactFlash

• USB 2.0 Full Speed (12 Mbits per second) Device Port

– On-chip Transceiver, 2,432-byte Configurable Integrated DPRAM

• USB 2.0 Full Speed (12 Mbits per second) Host and Double Port

– Single or Dual On-chip Transceivers – Integrated FIFOs and Dedicated DMA Channels

• Ethernet MAC 10/100 Base T

– Media Independent Interface or Reduced Media Independent Interface – 128-byte FIFOs and Dedicated DMA Channels for Receive and Transmit

• Image Sensor Interface

– ITU-R BT. 601/656 External Interface, Programmable Frame Capture Rate – 12-bit Data Interface for Support of High Sensibility Sensors – SAV and EAV Synchronization, Preview Path with Scaler, YCbCr Format

• Bus Matrix

– Six 32-bit-layer Matrix – Boot Mode Select Option, Remap Command

• Fully-featured System Controller, including

– Reset Controller, Shutdown Controller – Four 32-bit Battery Backup Registers for a Total of 16 Bytes – Clock Generator and Power Management Controller – Advanced Interrupt Controller and Debug Unit – Periodic Interval Timer, Watchdog Timer and Real-time Timer

• Reset Controller (RSTC)

– Based on a Power-on Reset Cell, Reset Source Identification and Reset Output

Control

• Clock Generator (CKGR)

– Selectable 32,768 Hz Low-power Oscillator or Internal Low Power RC Oscillator on

Battery Backup Power Supply, Providing a Permanent Slow Clock

– 3 to 20 MHz On-chip Oscillator, One up to 800 MHz PLL and One up to 100 MHz PLL

• Power Management Controller (PMC)

– Very Slow Clock Operating Mode, Software Programmable Power Optimization

Capabilities

– Two Programmable External Clock Signals

• Advanced Interrupt Controller (AIC)

– Individually Maskable, Eight-level Priority, Vectored Interrupt Sources – Three External Interrupt Sources and One Fast Interrupt Source, Spurious

Interrupt Protected

• Debug Unit (DBGU)

– 2-wire UART and Support for Debug Communication Channel, Programmable ICE

Access Prevention

– Mode for General Purpose 2-wire UART Serial Communication

™

ARM® Thumb® Processor

Technology for Java® Acceleration

AT91 ARM

Thumb Microcontrollers

AT91SAM9G20 Summary

NOTE: This is a summary document.

The complete document is available on the Atmel website at www.atmel.com.

6384CS–ATARM–11-Mar-09

• Periodic Interval Timer (PIT)

– 20-bit Interval Timer plus 12-bit Interval Counter

• Watchdog Timer (WDT)

– Key-protected, Programmable Only Once, Windowed 16-bit Counter Running at Slow Clock

• Real-time Timer (RTT)

– 32-bit Free-running Backup Counter Running at Slow Clock with 16-bit Prescaler

• One 4-channel 10-bit Analog-to-Digital Converter

• Three 32-bit Parallel Input/Output Controllers (PIOA, PIOB, PIOC)

– 96 Programmable I/O Lines Multiplexed with up to Two Peripheral I/Os – Input Change Interrupt Capability on Each I/O Line – Individually Programmable Open-drain, Pull-up Resistor and Synchronous Output – All I/O Lines are Schmitt Trigger Inputs

• Peripheral DMA Controller Channels (PDC)

• One Two-slot MultiMedia Card Interface (MCI)

™

– SDCard/SDIO and MultiMediaCard – Automatic Protocol Control and Fast Automatic Data Transfers with PDC

Compliant

• One Synchronous Serial Controller (SSC)

– Independent Clock and Frame Sync Signals for Each Receiver and Transmitter – I²S Analog Interface Support, Time Division Multiplex Support – High-speed Continuous Data Stream Capabilities with 32-bit Data Transfer

• Four Universal Synchronous/Asynchronous Receiver Transmitters (USART)

– Individual Baud Rate Generator, IrDA – Support for ISO7816 T0/T1 Smart Card, Hardware Handshaking, RS485 Support – Full Modem Signal Control on USART0

Infrared Modulation/Demodulation, Manchester Encoding/Decoding

• Two 2-wire UARTs

• Two Master/Slave Serial Peripheral Interfaces (SPI)

– 8- to 16-bit Programmable Data Length, Four External Peripheral Chip Selects – Synchronous Communications

• Two Three-channel 16-bit Timer/Counters (TC)

– Three External Clock Inputs, Two Multi-purpose I/O Pins per Channel – Double PWM Generation, Capture/Waveform Mode, Up/Down Capability – High-Drive Capability on Outputs TIOA0, TIOA1, TIOA2

• One Two-wire Interface (TWI)

– Compatible with Standard Two-wire Serial Memories – One, Two or Three Bytes for Slave Address – Sequential Read/Write Operations – Master, Multi-master and Slave Mode Operation – Bit Rate: Up to 400 Kbits – General Call Supported in Slave Mode – Connection to Peripheral DMA Controller (PDC) Channel Capabilities Optimizes Data Transfers in Master Mode

• IEEE

1149.1 JTAG Boundary Scan on All Digital Pins

• Required Power Supplies

– 0.9V to 1.1V for VDDBU, VDDCORE, VDDPLL – 1.65 to 3.6V for VDDOSC – 1.65V to 3.6V for VDDIOP (Peripheral I/Os) – 3.0V to 3.6V for VDDUSB – 3.0V to 3.6V VDDANA (Analog-to-digital Converter) – Programmable 1.65V to 1.95V or 3.0V to 3.6V for VDDIOM (Memory I/Os)

• Available in a 217-ball LFBGA and 247-ball TFBGA RoHS-compliant Package

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

1. Description

AT91SAM9G20 Summary

The AT91SAM9G20 is based on the integration of an ARM926EJ-S processor with fast ROM and RAM memories and a wide range of peripherals.

The AT91SAM9G20 embeds an Ethernet MAC, one USB Device Port, and a USB Host controller. It also integrates several standard peripherals, such as the USART, SPI, TWI, Timer Counters, Synchronous Serial Controller, ADC and MultiMedia Card Interface.

The AT91SAM9G20 is architectured on a 6-layer matrix, allowing a maximum internal bandwidth of six 32-bit buses. It also features an External Bus Interface capable of interfacing with a wide range of memory devices.

The AT91SAM9G20 is an enhancement of the AT91SAM9260 with the same peripheral features. It is pin-to-pin compatible with the exception of power supply pins. Speed is increased to reach 400 MHz on the ARM core and 133 MHz on the system bus and EBI.

6384CS–ATARM–11-Mar-09

2. AT91SAM9G20 Block Diagram

ARM926EJ-S Processor

JTAG Selection and Boundary Scan

In-Circuit Emulator

AIC

Fast SRAM

16 Kbytes

D0-D15

A0/NBS0

A2-A15, A18-A20

A16/BA0

A17/BA1

NCS0

NCS1/SDCS

NRD/CFOE

NWR0/NWE/CFWE

NWR1/NBS1/CFIOR

NWR3/NBS3/CFIOW

SDCK, SDCKE

RAS, CAS

SDWE, SDA10

FIQ

IRQ0-IRQ2

DRXD

DTXD

MMU

APB

ROM

64 Kbytes

Peripheral

Bridge

24-channel

Peripheral

DMA

Bus Interface

A1/NBS2/NWR2

TST

System

Controller

XIN

TDI

TDO

TMS

TCK

JTAGSEL

NANDOE, NANDWE

PMC

OSC

XOUT

PITWDT

DBGU

SLAVEMASTER

PDC

BMS

A23-A24

NCS5/CFCS1

A25/CFRNW

NCS4/CFCS0

NWAIT

CFCE1-CFCE2

EBI

Static

Memory

Controller

CompactFlash

NAND Flash

SDRAM

Controller

NCS2, NCS6, NCS7

NCS3/NANDCS

RTCK

ECC

Controller

ETXCK-ERXCK

ETXEN-ETXER

ECRS-ECOL

ERXER-ERXDV

ERX0-ERX3

ETX0-ETX3

MDC

MDIO

F100

10/100 Ethernet

MAC

FIFO

DMA

FIFO

SSC

PDC

USB

Device

DDM

DDP

TC0

TC1

TC2

TCLK0-TCLK2

TIOA0-TIOA2

TIOB0-TIOB2

SPI0

SPI1

PDC

USART0

USART1

USART2

USART3

USART4

USART5

RTS0-RTS3

SCK0-SCK2

TXD0-TXD5

RXD0-RXD5

CTS0-CTS3

PDC

TWI

TWCK

TWD

MCI

PDC

Transceiver

DPRAM

ICache

32K bytes

DCache

32K bytes

6-layer Matrix

NPCS2

NPCS1

SPCK

MOSI

MISO

NPCS0

NPCS3

SPI0_, SPI1_

MCCK

MCDA0-MCDA3

MCCDA

NRST

XIN32

XOUT32

VDDCORE

PIOA

PIOB

PIOC

DSR0

DCD0

DTR0

RI0

USB

OHCI

DMA

Transc.

HDPA

HDMA

HDPB

HDMB


Sensor

Interface

DMA

ISI_PCK

ISI_DO-ISI_D7

ISI_HSYNC

ISI_VSYNC

ISI_MCK

4-channel

10-bit

ADC

AD0-AD3

ADTRIG

ADVREF

VDDANA

GNDANA

PDC

D16-D31

RTT

OSC

RSTC

POR

4GPREG

SHDN

WKUP

SHDC

POR

OSCSEL

VDDBU

MCDB0-MCDB3

MCCDB

TC3

TC4

TC5

TCLK3-TCLK5

TIOA3-TIOA5

TIOB3-TIOB5

Fast SRAM

16 Kbytes

PDC

A21/NANDALE, A22/NANDCLE

PLLA

Filter

PLLB

Figure 2-1. AT91SAM9G20 Block Diagram

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

AT91SAM9G20 Summary

3. Signal Description

Table 3-1. Signal Description List (Continued)

Active

Signal Name Function Type

Power Supplies

VDDIOM EBI I/O Lines Power Supply Power 1.65V to 1.95V or 3.0V to 3.6V

VDDIOP Peripherals I/O Lines Power Supply Power 1.65V to 3.6V

VDDBU Backup I/O Lines Power Supply Power 0.9V to 1.1V

VDDANA Analog Power Supply Power 3.0V to 3.6V

VDDPLL PLL Power Supply Power 0.9V to 1.1V

VDDOSC Oscillator Power Supply Power 1.65V to 3.6V

VDDCORE Core Chip Power Supply Power 0.9V to 1.1V

VDDUSB USB Power Supply Power 1.65V to 3.6V

GND Ground Ground

GNDANA Analog Ground Ground

GNDBU Backup Ground Ground

GNDUSB USB Ground Ground

GNDPLL PLL Ground Ground

Clocks, Oscillators and PLLs

XIN Main Oscillator Input Input

XOUT Main Oscillator Output Output

XIN32 Slow Clock Oscillator Input Input

XOUT32 Slow Clock Oscillator Output Output

OSCSEL Slow Clock Oscillator Selection Input

PCK0 - PCK1 Programmable Clock Output Output

Shutdown, Wakeup Logic

SHDN Shutdown Control Output

WKUP Wake-up Input Input

ICE and JTAG

NTRST Test Reset Signal Input Low Pull-up resistor

TCK Test Clock Input No pull-up resistor

TDI Test Data In Input No pull-up resistor

TDO Test Data Out Output

TMS Test Mode Select Input No pull-up resistor

JTAGSEL JTAG Selection Input

RTCK Return Test Clock Output

Level Comments

Accepts between 0V and VDDBU.

Pull-down resistor. Accepts between 0V and VDDBU.

6384CS–ATARM–11-Mar-09

Table 3-1. Signal Description List (Continued)

Active

Signal Name Function Type

Reset/Test

NRST Microcontroller Reset I/O Low Pull-up resistor

TST Test Mode Select Input

BMS Boot Mode Select Input

Debug Unit - DBGU

DRXD Debug Receive Data Input

DTXD Debug Transmit Data Output

Advanced Interrupt Controller - AIC

IRQ0 - IRQ2 External Interrupt Inputs Input

FIQ Fast Interrupt Input Input

PIO Controller - PIOA - PIOB - PIOC

PA0 - PA31 Parallel IO Controller A I/O Pulled-up input at reset

PB0 - PB31 Parallel IO Controller B I/O Pulled-up input at reset

PC0 - PC31 Parallel IO Controller C I/O Pulled-up input at reset

External Bus Interface - EBI

D0 - D31 Data Bus I/O Pulled-up input at reset

A0 - A25 Address Bus Output 0 at reset

NWAIT External Wait Signal Input Low

Static Memory Controller - SMC

NCS0 - NCS7 Chip Select Lines Output Low

NWR0 - NWR3 Write Signal Output Low

NRD Read Signal Output Low

NWE Write Enable Output Low

NBS0 - NBS3 Byte Mask Signal Output Low

CompactFlash Support

CFCE1 - CFCE2 CompactFlash Chip Enable Output Low

CFOE CompactFlash Output Enable Output Low

CFWE CompactFlash Write Enable Output Low

CFIOR CompactFlash IO Read Output Low

CFIOW CompactFlash IO Write Output Low

CFRNW CompactFlash Read Not Write Output

CFCS0 - CFCS1 CompactFlash Chip Select Lines Output Low

Level Comments

Pull-down resistor. Accepts between 0V and VDDBU.

No pull-up resistor BMS = 0 when tied to GND. BMS = 1 when tied to VDDIOP.

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

AT91SAM9G20 Summary

Table 3-1. Signal Description List (Continued)

Active

Signal Name Function Type

NAND Flash Support

NANDCS NAND Flash Chip Select Output Low

NANDOE NAND Flash Output Enable Output Low

NANDWE NAND Flash Write Enable Output Low

NANDALE NAND Flash Address Latch Enable Output Low

NANDCLE NAND Flash Command Latch Enable Output Low

SDRAM Controller

SDCK SDRAM Clock Output

SDCKE SDRAM Clock Enable Output High

SDCS SDRAM Controller Chip Select Output Low

BA0 - BA1 Bank Select Output

SDWE SDRAM Write Enable Output Low

RAS - CAS Row and Column Signal Output Low

SDA10 SDRAM Address 10 Line Output

Multimedia Card Interface MCI

MCCK Multimedia Card Clock Output

MCCDA Multimedia Card Slot A Command I/O

MCDA0 - MCDA3 Multimedia Card Slot A Data I/O

MCCDB Multimedia Card Slot B Command I/O

MCDB0 - MCDB3 Multimedia Card Slot B Data I/O

Universal Synchronous Asynchronous Receiver Transmitter USARTx

SCKx USARTx Serial Clock I/O

TXDx USARTx Transmit Data I/O

RXDx USARTx Receive Data Input

RTSx USARTx Request To Send Output

CTSx USARTx Clear To Send Input

DTR0 USART0 Data Terminal Ready Output

DSR0 USART0 Data Set Ready Input

DCD0 USART0 Data Carrier Detect Input

RI0 USART0 Ring Indicator Input

Synchronous Serial Controller - SSC

TD SSC Transmit Data Output

RD SSC Receive Data Input

TK SSC Transmit Clock I/O

RK SSC Receive Clock I/O

TF SSC Transmit Frame Sync I/O

RF SSC Receive Frame Sync I/O

Level Comments

6384CS–ATARM–11-Mar-09

Table 3-1. Signal Description List (Continued)

Active

Signal Name Function Type

Timer/Counter - TCx

TCLKx TC Channel x External Clock Input Input

TIOAx TC Channel x I/O Line A I/O

TIOBx TC Channel x I/O Line B I/O

Serial Peripheral Interface - SPIx_

SPIx_MISO Master In Slave Out I/O

SPIx_MOSI Master Out Slave In I/O

SPIx_SPCK SPI Serial Clock I/O

SPIx_NPCS0 SPI Peripheral Chip Select 0 I/O Low

SPIx_NPCS1-SPIx_NPCS3 SPI Peripheral Chip Select Output Low

Two-Wire Interface

TWD Two-wire Serial Data I/O

TWCK Two-wire Serial Clock I/O

USB Host Port

HDPA USB Host Port A Data + Analog

HDMA USB Host Port A Data - Analog

HDPB USB Host Port B Data + Analog

HDMB USB Host Port B Data - Analog

USB Device Port

DDM USB Device Port Data - Analog

DDP USB Device Port Data + Analog

Ethernet 10/100

ETXCK Transmit Clock or Reference Clock Input MII only, REFCK in RMII

ERXCK Receive Clock Input MII only

ETXEN Transmit Enable Output

ETX0-ETX3 Transmit Data Output ETX0-ETX1 only in RMII

ETXER Transmit Coding Error Output MII only

ERXDV Receive Data Valid Input RXDV in MII, CRSDV in RMII

ERX0-ERX3 Receive Data Input ERX0-ERX1 only in RMII

ERXER Receive Error Input

ECRS Carrier Sense and Data Valid Input MII only

ECOL Collision Detect Input MII only

EMDC Management Data Clock Output

EMDIO Management Data Input/Output I/O

Level Comments

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

AT91SAM9G20 Summary

Table 3-1. Signal Description List (Continued)

Active

Signal Name Function Type

Image Sensor Interface

ISI_D0-ISI_D11 Image Sensor Data Input

ISI_MCK Image Sensor Reference Clock Output

ISI_HSYNC Image Sensor Horizontal Synchro Input

ISI_VSYNC Image Sensor Vertical Synchro Input

ISI_PCK Image Sensor Data clock Input

Analog to Digital Converter

AD0-AD3 Analog Inputs Analog Digital pulled-up inputs at reset

ADVREF Analog Positive Reference Analog

ADTRG ADC Trigger Input

Note: No PLLRCA line present on the AT91SAM9G20.

4. Package and Pinout

Level Comments

• The AT91SAM9G20 is available in a 217-ball, 15 x 15 mm, LFBGA package (0.8 mm pitch) (Figure 4-1).

• The AT91SAM9G20 is available in a 247-ball, 10 x 10 x 1.1 mm, TFBGA Green package, , (0.5 mm pitch) (Figure 4-2).

4.1 217-ball LFBGA Package Outline

Figure 4-1 shows the orientation of the 217-ball LFBGA package.

A detailed mechanical description is given in the section “AT91SAM9G20 Mechanical Characteristics” of the product datasheet.

Figure 4-1.

217-ball LFBGA Package (Top View)

17 16 15 14 13 12 11 10

7 6 5 4

2 1

6384CS–ATARM–11-Mar-09

Ball A1

ABCDEFGHJKLMNPRTU

4.2 217-ball LFBGA Pinout

Table 4-1. Pinout for 217-ball LFBGA Package

Pin Signal Name Pin Signal Name Pin Signal Name Pin Signal Name

A1 CFIOW/NBS3/NWR3 D5 A5 J14 TDO P17 PB5 A2 NBS0/A0 D6 GND J15 PB19 R1 NC A3 NWR2/NBS2/A1 D7 A10 J16 TDI R2 GNDANA A4 A6 D8 GND J17 PB16 R3 PC29 A5 A8 D9 VDDCORE K1 PC24 R4 VDDANA A6 A11 D10 GNDUSB K2 PC20 R5 PB12 A7 A13 D11 VDDIOM K3 D15 R6 PB23 A8 BA0/A16 D12 GNDUSB K4 PC21 R7 GND A9 A18 D13 DDM K8 GND R8 PB26 A10 A21 D14 HDPB K9 GND R9 PB28 A11 A22 D15 NC K10 GND R10 PA0 A12 CFWE/NWE/NWR0 D16 VDDBU K14 PB4 R11 PA4 A13 CFOE/NRD D17 XIN32 K15 PB17 R12 PA5 A14 NCS0 E1 D10 K16 GND R13 PA10 A15 PC5 E2 D5 K17 PB15 R14 PA21 A16 PC6 E3 D3 L1 GND R15 PA23 A17 PC4 E4 D4 L2 PC26 R16 PA24 B1 SDCK E14 HDPA L3 PC25 R17 PA29 B2 CFIOR/NBS1/NWR1 E15 HDMA L4 VDDOSC T1 NC B3 SDCS/NCS1 E16 GNDBU L14 PA28 T2 GNDPLL B4 SDA10 E17 XOUT32 L15 PB9 T3 PC0 B5 A3 F1 D13 L16 PB8 T4 PC1 B6 A7 F2 SDWE L17 PB14 T5 PB10 B7 A12 F3 D6 M1 VDDCORE T6 PB22 B8 A15 F4 GND M2 PC31 T7 GND B9 A20 F14 OSCSEL M3 GND T8 PB29 B10 NANDWE F15 BMS M4 PC22 T9 PA2 B11 PC7 F16 JTAGSEL M14 PB1 T10 PA6 B12 PC10 F17 TST M15 PB2 T11 PA8 B13 PC13 G1 PC15 M16 PB3 T12 PA11 B14 PC11 G2 D7 M17 PB7 T13 VDDCORE B15 PC14 G3 SDCKE N1 XIN T14 PA20 B16 PC8 G4 VDDIOM N2 VDDPLL T15 GND B17 WKUP G14 GND N3 PC23 T16 PA22 C1 D8 G15 NRST N4 PC27 T17 PA27 C2 D1 G16 RTCK N14 PA31 U1 GNDPLL C3 CAS G17 TMS N15 PA30 U2 ADVREF C4 A2 H1 PC18 N16 PB0 U3 PC2 C5 A4 H2 D14 N17 PB6 U4 PC3 C6 A9 H3 D12 P1 XOUT U5 PB20 C7 A14 H4 D11 P2 VDDPLL U6 PB21 C8 BA1/A17 H8 GND P3 PC30 U7 PB25 C9 A19 H9 GND P4 PC28 U8 PB27 C10 NANDOE H10 GND P5 PB11 U9 PA12 C11 PC9 H14 VDDCORE P6 PB13 U10 PA13 C12 PC12 H15 TCK P7 PB24 U11 PA14 C13 DDP H16 NTRST P8 VDDIOP U12 PA15 C14 HDMB H17 PB18 P9 PB30 U13 PA19 C15 NC J1 PC19 P10 PB31 U14 PA17 C16 VDDUSB J2 PC17 P11 PA1 U15 PA16 C17 SHDN J3 VDDIOM P12 PA3 U16 PA18 D1 D9 J4 PC16 P13 PA7 U17 VDDIOP D2 D2 J8 GND P14 PA9 D3 RAS J9 GND P15 PA26 D4 D0 J10 GND P16 PA25

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

4.3 247-ball TFBGA Package Outline

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19

Ball A1

Figure 4-2 shows the orientation of the 247-ball TFBGA package.

A detailed mechanical description is given in the section “AT91SAM9G20 Mechanical Characteristics” of the product datasheet.

AT91SAM9G20 Summary

Figure 4-2.

247-ball TFBGA Package (Bottom View)

6384CS–ATARM–11-Mar-09

4.4 247-ball TFBGA Package Pinout

Table 4-2. Pinout for 247-ball TFBGA Package

Pin Signal Name Pin Signal Name Pin Signal Name Pin Signal Name

A1 D13 F7 CFIOR/NBS1/NWR1 K10 GND P17 RTCK A2 D12 F8 SDA10 K11 VDDIOM P18 PB16 A12 A9 F9 NBS0/A0 K12 GND R2 GND A14 A13 F10 A6 K13 GND R3 PB29 A16 A20 F11 A12 K14 XOUT32 R5 PB26 A18 A22 F12 A15 K15 XIN32 R6 PB27 A19 NANDOE F13 BA1/A17 K17 HDPA R7 PA5 B1 D15 F14 PC10 K18 HDMA R8 GND B2 D14 F15 PC14 L2 NC R9 PA12 B3 D10 F16 VDDUSB L3 NC R10 GND B4 D9 F17 PC9 L5 ADVREF R11 PA19 B5 D7 F18 PC12 L6 PC2 R12 PA26 B6 D3 G2 PC26 L7 GND R13 PB1 B7 D2 G3 PC25 L8 GND R14 GND B8 RAS G5 PC24 L9 GND R15 PB7 B9 CAS G6 PC21 L10 GND R17 PB14 B10 NWR2/NBS2/A1 G8 VDDCORE L11 VDDCORE R18 PB9 B11 A3 G9 A5 L12 GND T2 PA1 B13 A10 G10 VDDCORE L13 OSCSEL T3 PB10 B15 A18 G11 VDDCORE L14 GNDBU T17 PB19 B17 A21 G12 VDDCORE L15 GND T18 PB17 B19 VDDUSB G14 PC13 L17 NRST U2 GNDANA C2 PC15 G15 GND L18 TCK U3 PB21 C3 D11 G17 GNDUSB M2 PC0 U4 PB28 C4 D8 G18 PC11 M3 PC1 U5 PB31 C5 SDCKE H2 PC31 M5 PC3 U6 PA4 C6 SDWE H3 PC30 M6 NTRST U7 PA3 C7 SDCK H5 PC28 M7 GND U8 PA9 C8 D1 H6 PC27 M8 GND U9 GND C9 SDCS/NCS1 H7 PC29 M9 GND U10 PA15 C10A2 H8 GND M10PA16 U11 PA21 C11 A7 H9 GND M11 VDDCORE U12 PA25 C12 A11 H10 VDDIOM M12 GND U13 PA29 C14 A19 H11 VDDIOM M13 VDDIOP U14 PA27 C16 GNDUSB H12 GND M14 TST U15 PA31 C18 CFWE/NWE/NWR0 H13 VDDCORE M15 JTAGSEL U16 GND D2 PC17 H14 SHDW M17 PB18 U17 PB2 D3 PC16 H15 VDDBU M18 TMS U18 GND D13 A14 H17 HDPB N2 PB20 V1 PB12 D15 NANDWE H18 HDMB N3 PB13 V2 PB23 D17 CFOE/NRD J2 VDDOSC N5 PB11 V3 PB30 D19 NCS0 J3 VDDPLL N6 BMS V4 PA2 E2 PC18 J5 XOUT N8 GND V5 PA8 E3 PC19 J6 XIN N11 PA17 V6 PA10 E5 D6 J7 VDDPLL N12 PA23 V7 PA13 E6 D5 J8 GND N14 GND V8 VDDIOP E7 D0 J9 VDDIOM N15 VDDIOP V9 PA14 E8 CFIOW/NBS3/NWR3 J10 VDDIOM N17 TDO V10 VDDIOP E9 GND J11 VDDIOM N18 TDI V11 PA20 E10 A4 J12 GND P2 PB24 V12 PA22 E11 A8 J13 GND P3 PB22 V13 VDDIOP E12 VDDIOM J14 WKUP P5 GND V14 PA30 E13 BA0/A16 J15 DDP P6 GND V15 PB0 E14 PC8 J17 DDM P7 PA6 V16 GND E15 PC4 J18 VDDIOP P8 PA7 V17 PB4 E16 PC5 K2 GNDPLL P9 PA11 V18 GND E18 PC7 K3 GND P10 GND V19 PB6 E19 PC6 K5 NC P11 PA18 W1 PB25 F2 PC22 K6 GNDPLL P12 PA24 W2 PA0 F3 PC23 K7 VDDANA P13 PA28 W18 PB8 F5 PC20 K8 GND P14 PB3 W19 PB15 F6 D4 K9 GND P15 PB5

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

5. Power Considerations

5.1 Power Supplies

The AT91SAM9G20 has several types of power supply pins:

• VDDCORE pins: Power the core, including the processor, the embedded memories and the peripherals; voltage ranges from 0.9V to 1.1V, 1.0V nominal.

• VDDIOM pins: Power the External Bus Interface I/O lines; voltage ranges between 1.65V and

1.95V (1.8V typical) or between 3.0V and 3.6V (3.3V nominal). The voltage range is selectable by software.

• VDDIOP pins: Power the Peripherals I/O lines; voltage ranges from 1.65V to 3.6V.

• VDDBU pin: Powers the Slow Clock oscillator, the internal RC oscillator and a part of the System Controller; voltage ranges from 0.9V to 1.1V, 1.0V nominal.

• VDDPLL pin: Powers the PLL cells; voltage ranges from 0.9V to 1.1V.

• VDDOSC pin: Powers the Main Oscillator cells; voltage ranges from 1.65V to 3.6V

• VDDANA pin: Powers the Analog to Digital Converter; voltage ranges from 3.0V to 3.6V, 3.3V nominal.

• VDDUSB pin: Powers USB transceiver; voltage ranges from 3.0V to 3.6V.

Ground pins GND are common to VDDCORE, VDDIOM, VDDOSC and VDDIOP pins power supplies. Separated ground pins are provided for VDDBU, VDDPLL, VDDUSB and VDDANA. These ground pins are respectively GNDBU, GNDPLL, GNDUSB and GNDANA.

AT91SAM9G20 Summary

5.2 Power Consumption

The AT91SAM9G20 consumes about 4 mA of static current on VDDCORE at 25°C. This static current rises at up to 18 mA if the temperature increases to 85°C.

On VDDBU, the current does not exceed 9 µA at 25°C. This static current rises at up to 18 µA if the temperature increases to 85°C.

For dynamic power consumption, the AT91SAM9G20 consumes a maximum of 50 mA on VDDCORE at maximum conditions (1.0V, 25°C, rises to 80mA at 85°C, processor running fullperformance algorithm out of high-speed memories).

5.3 Programmable I/O Lines

The power supplies pins VDDIOM accept two voltage ranges. This allows the device to reach its maximum speed either out of 1.8V or 3.3V external memories.

The maximum speed is 133 MHz on the pin SDCK (SDRAM Clock) loaded with 10 pF. The other signals (control, address and data signals) do not go over 66 MHz, loaded with 30 pF for power supply at 1.8V and 50 pF for power supply at 3.3V.

The EBI I/Os accept two slew rate modes, Fast and Slow. This allows to adapt the rising and falling time on SDRAM clock, control and data to the bus load.

The voltage ranges and the slew rates are determined by programming VDDIOMSEL and IOSR bits in the Chip Configuration registers located in the Matrix User Interface.

At reset, the selected voltage defaults to 3.3V nominal and power supply pins can accept either

1.8V or 3.3V. The user must make sure to program the EBI voltage range before getting the device out of its Slow Clock Mode.

At reset, the selected slew rates defaults are Fast.

6384CS–ATARM–11-Mar-09

6. I/O Line Considerations

6.1 JTAG Port Pins

TMS, TDI and TCK are schmitt trigger inputs and have no pull-up resistors.

TDO and RTCK are outputs, driven at up to VDDIOP, and have no pull-up resistor.

The JTAGSEL pin is used to select the JTAG boundary scan when asserted at a high level. It integrates a permanent pull-down resistor of about 15 kΩ to GND, so that it can be left uncon- nected for normal operations.

The NTRST signal is described in the Reset Pins paragraph.

All the JTAG signals are supplied with VDDIOP.

6.2 Test Pin

The TST pin is used for manufacturing test purposes when asserted high. It integrates a permanent pull-down resistor of about 15 kΩ to GNDBU, so that it can be left unconnected for normal operations. Driving this line at a high level leads to unpredictable results.

This pin is supplied with VDDBU.

6.3 Reset Pins

NRST is an open-drain output integrating a non-programmable pull-up resistor. It can be driven with voltage at up to VDDIOP.

NTRST is an input which allows reset of the JTAG Test Access port. It has no action on the processor.

As the product integrates power-on reset cells, which manages the processor and the JTAG reset, the NRST and NTRST pins can be left unconnected.

The NRST and NTRST pins both integrate a permanent pull-up resistor of 100 kΩ minimum to VDDIOP.

The NRST signal is inserted in the Boundary Scan.

6.4 PIO Controllers

All the I/O lines are Schmitt trigger inputs and all the lines managed by the PIO Controllers integrate a programmable pull-up resistor of 75 kΩ typical with the exception of P4 - P31. For details, refer to the section “AT91SAM9G20 Electrical Characteristics”. Programming of this pull-up resistor is performed independently for each I/O line through the PIO Controllers.

6.5 I/O Line Drive Levels

The PIO lines drive current capability is described in the DC Characteristics section of the product datasheet.

6.6 Shutdown Logic Pins

The SHDN pin is a tri-state output only pin, which is driven by the Shutdown Controller. There is no internal pull-up. An external pull-up to VDDBU is needed and its value must be higher than 1 MΩ. The resisitor value is calculated according to the regulator enable implementation and the SHDN level.

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

The pin WKUP is an input-only. It can accept voltages only between 0V and VDDBU.

6.7 Slow Clock Selection

The AT91SAM9G20 slow clock can be generated either by an external 32768Hz crystal or the on-chip RC oscillator.

7. Processor and Architecture

7.1 ARM926EJ-S Processor

• RISC Processor Based on ARM v5TEJ Architecture with Jazelle technology for Java acceleration

• Two Instruction Sets

– ARM High-performance 32-bit Instruction Set

– Thumb High Code Density 16-bit Instruction Set

• DSP Instruction Extensions

• 5-Stage Pipeline Architecture:

– Instruction Fetch (F)

– Instruction

– Execute (E)

– Data Memory (M)

– Register Write (W)

• 32-Kbyte Data Cache, 32-Kbyte Instruction Cache

– Virtually-addressed 4-way Associative Cache

– Eight words per line

– Write-through and Write-back Operation

– Pseudo-random or Round-robin Replacement

• Write Buffer

– Main Write Buffer with 16-word Data Buffer and 4-address Buffer

– DCache Write-back Buffer with 8-word Entries and a Single Address Entry

– Software Control Drain

• Standard ARM v4 and v5 Memory Management Unit (MMU)

– Access Permission for Sections

– Access Permission for large pages and small pages can be specified separately for

each quarter of the page

– 16 embedded domains

• Bus Interface Unit (BIU)

– Arbitrates and Schedules AHB Requests

– Separate Masters for both instruction and data access providing complete Matrix

system flexibility

– Separate Address and Data Buses for both the 32-bit instruction interface and the

32-bit data interface

Decode (D)

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

7.2 Bus Matrix

– On Address and Data Buses, data can be 8-bit (Bytes), 16-bit (Half-words) or 32-bit

(Words)

• 6-layer Matrix, handling requests from 6 masters

• Programmable Arbitration strategy

– Fixed-priority Arbitration

– Round-Robin Arbitration, either with no default master, last accessed default master

or fixed default master

• Burst Management

– Breaking with Slot Cycle Limit Support

– Undefined Burst Length Support

• One Address Decoder provided per Master

– Three different slaves may be assigned to each decoded memory area: one for

internal boot, one for external boot, one after remap

• Boot Mode Select

– Non-volatile Boot Memory can be internal or external

– Selection is made by BMS pin sampled at reset

• Remap Command

– Allows Remapping of an Internal SRAM in Place of the Boot Non-Volatile Memory

• Allows Handling of Dynamic Exception Vectors

7.2.1 Matrix Masters

7.2.2 Matrix Slaves

The Bus Matrix of the AT91SAM9G20 manages six Masters, which means that each master can perform an access concurrently with others, according the slave it accesses is available.

Each Master has its own decoder that can be defined specifically for each master. In order to simplify the addressing, all the masters have the same decodings.

Table 7-1. List of Bus Matrix Masters

Master 0 ARM926™ Instruction

Master 1 ARM926 Data

Master 2 PDC

Master 3 ISI Controller

Master 4 Ethernet MAC

Master 5 USB Host DMA

Each Slave has its own arbiter, thus allowing to program a different arbitration per Slave.

Table 7-2. List of Bus Matrix Slaves

Slave 0 Internal SRAM0 16 KBytes

Slave 1 Internal SRAM1 16 KBytes

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

Table 7-2. List of Bus Matrix Slaves (Continued)

Slave 2

Slave 3 External Bus Interface

Slave 4 Internal Peripherals

7.2.3 Masters to Slaves Access

All the Masters can normally access all the Slaves. However, some paths do not make sense, like as example allowing access from the Ethernet MAC to the Internal Peripherals. Thus, these paths are forbidden or simply not wired, and shown “-” in Table 7-3.

Table 7-3. AT91SAM9G20 Masters to Slaves Access

AT91SAM9G20 Summary

Internal ROM

USB Host User Interface

Master 0 & 1234 5

Slave

3 External Bus Interface X X X X X

4 Internal Peripherals X X - - -

Internal SRAM

16 Kbytes

Internal SRAM

16 Kbytes

Internal ROM X X - - -

UHP User Interface X X - - -

7.3 Peripheral DMA Controller

• Acting as one Matrix Master

• Allows data transfers from/to peripheral to/from any memory space without any intervention of the processor.

• Next Pointer Support, forbids strong real-time constraints on buffer management.

• Twenty-four channels

– Two for each USART

– Two for the Debug Unit

– Two for the Serial Synchronous Controller

– Two for each Serial Peripheral Interface

– One for Multimedia Card Interface

– One for Analog-to-Digital Converter

– Two for the Two-wire Interface

The Peripheral DMA Controller handles transfer requests from the channel according to the following priorities (Low to High priorities):

ARM926

Instruction &

Data

XXXXX

Peripheral

DMA

Controller

ISI

Controller

Ethernet

MAC

USB Host Controller

6384CS–ATARM–11-Mar-09

– TWI Transmit Channel

– DBGU Transmit Channel

– USART5 Transmit Channel

– USART4 Transmit Channel

– USART3 Transmit Channel

– USART2 Transmit Channel

– USART1 Transmit Channel

– USART0 Transmit Channel

– SPI1 Transmit Channel

– SPI0 Transmit Channel

– SSC Transmit Channel

– TWI Receive Channel

– DBGU Receive Channel

– USART5 Receive Channel

– USART4 Receive Channel

– USART3 Receive Channel

– USART2 Receive Channel

– USART1 Receive Channel

– USART0 Receive Channel

– ADC Receive Channel

– SPI1 Receive Channel

– SPI0 Receive Channel

– SSC Receive Channel

– MCI Transmit/Receive Channel

7.4 Debug and Test Features

• ARM926 Real-time In-circuit Emulator

– Two real-time Watchpoint Units

– Two Independent Registers: Debug Control Register and Debug Status Register

– Test Access Port Accessible through JTAG Protocol

– Debug Communications Channel

• Debug Unit

–Two-pin UART

– Debug Communication Channel Interrupt Handling

– Chip ID Register

• IEEE1149.1 JTAG Boundary-scan on All Digital Pins

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

8. Memories

16K Bytes

0xFFFC 0000

16K Bytes

0xFFFC 4000

SPI1

0xFFFC C000

SPI0

16K Bytes

0xFFFC 8000

16K Bytes

0xFFFA 4000

TCO, TC1, TC2

0xFFFA 8000

MCI

0xFFFB 0000

0xFFFB 4000

USART0

0xFFFB C000

USART1

0xFFFA 0000

0xFFFA C000

USART2

16K Bytes

TWI

16K Bytes

0xFFFB 8000

16K Bytes

UDP

SSC

256M Bytes

0x1000 0000

0x0000 0000

0x0FFF FFFF

0xFFFF FFFF

0xF000 0000

0xEFFF FFFF

Address Memory Space

Internal Peripherals

Internal Memories

EBI

Chip Select 0

EBI

Chip Select 1/

SDRAMC

EBI

Chip Select 2

EBI

Chip Select 3/

NANDFlash

EBI

Chip Select 4/

Compact Flash

Slot 0

EBI

Chip Select 5/

Compact Flash

Slot 1

EBI

Chip Select 6

EBI

Chip Select 7

Undefined

(Abort)

256M Bytes

1,518M Bytes

0x2000 0000

0x1FFF FFFF

0x3000 0000

0x2FFF FFFF

0x4000 0000

0x3FFF FFFF

0x6FFF FFFF

0x6000 0000

0x5FFF FFFF

0x5000 0000

0x4FFF FFFF

0x7000 0000

0x7FFF FFFF

0x8000 0000

0x8FFF FFFF

0x9000 0000

256M Bytes

0xFFFF FD00

0xFFFF FC00

0xFFFF FA00

0xFFFF F800

0xFFFF F600

0xFFFF F400

0xFFFF F200

16 Bytes

256 Bytes

512 bytes

512 Bytes

PMC

PIOC

PIOB

PIOA

DBGU

RSTC

0xFFFF F000

512 Bytes

AIC

0xFFFF EE00

512 Bytes

MATRIX

0xFFFF EC00

512 BytesSMC

0xFFFF FD10

16 Bytes

SHDC

0xFFFF EA00

512 BytesSDRAMC

0xFFFF FD20

16 Bytes

RTTC

0xFFFF FD30

16 Bytes

PITC

0xFFFF FD40

16 Bytes

WDTC

0xFFFF FD50

16 Bytes

GPBR

0xFFFF FD60

Reserved

256M Bytes

Peripheral Mapping

Internal Memory Mapping

(1) Can be ROM, EBI_NCS0 or SRAM

depending on BMS and REMAP

Notes :

ISI

EMAC

0xFFFF C000

SYSC

Reserved

0xFFFF FFFF

System Controller Mapping

16K Bytes

0xFFFF FFFF

Reserved

0xFFFF C000

ADC

USART3

USART4

USART5

TC3, TC4, TC5

16K Bytes

0xFFFD 4000

0xFFFD 8000

0xFFFD 0000

0xFFFE 0000

0xFFFD C000

0xFFFE 4000

0xFFFF E800

ECC 512 Bytes

CCFG

0xFFFF EF10

32K Bytes

16K Bytes

0x10 8000

ROM

0x20 0000

SRAM0

0x30 0000

0x30 4000

SRAM1

0x50 4000

0x10 0000

0x20 4000

UHP

16K Bytes

0x50 0000

Reserved

0x0FFF FFFF

Boot Memory (1)

0x0000 0000

Reserved

0xF000 0000

Figure 8-1. AT91SAM9G20 Memory Mapping

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

A first level of address decoding is performed by the Bus Matrix, i.e., the implementation of the Advanced High Performance Bus (AHB) for its Master and Slave interfaces with additional features.

Decoding breaks up the 4G bytes of address space into 16 banks of 256 Mbytes. The banks 1 to 7 are directed to the EBI that associates these banks to the external chip selects EBI_NCS0 to EBI_NCS7. Bank 0 is reserved for the addressing of the internal memories, and a second level of decoding provides 1 Mbyte of internal memory area. Bank 15 is reserved for the peripherals and provides access to the Advanced Peripheral Bus (APB).

Other areas are unused and performing an access within them provides an abort to the master requesting such an access.

Each Master has its own bus and its own decoder, thus allowing a different memory mapping per Master. However, in order to simplify the mappings, all the masters have a similar address decoding.

Regarding Master 0 and Master 1 (ARM926 Instruction and Data), three different Slaves are assigned to the memory space decoded at address 0x0: one for internal boot, one for external boot, one after remap. Refer to Table 8-1, “Internal Memory Mapping,” on page 20 for details.

A complete memory map is presented in Figure 8-1 on page 19.

8.1 Embedded Memories

• 64-KByte ROM

– Single Cycle Access at full matrix speed

• Two 16-Kbyte Fast SRAM

– Single Cycle Access at full matrix speed

8.1.1 Boot Strategies

Table 8-1 summarizes the Internal Memory Mapping for each Master, depending on the Remap

status and the BMS state at reset.

Table 8-1. Internal Memory Mapping

REMAP = 0 REMAP = 1

Address

BMS = 1 BMS = 0

0x0000 0000 ROM EBI_NCS0 SRAM0 16K

0x0010 0000 ROM

0x0020 0000 SRAM0 16K

0x0030 0000 SRAM1 16K

0x0050 0000 USB Host User Interface

The system always boots at address 0x0. To ensure a maximum number of possibilities for boot, the memory layout can be configured with two parameters.

REMAP allows the user to lay out the first internal SRAM bank to 0x0 to ease development. This is done by software once the system has booted. When REMAP = 1, BMS is ignored. Refer to the Bus Matrix Section for more details.

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

When REMAP = 0, BMS allows the user to lay out to 0x0, at his convenience, the ROM or an external memory. This is done via hardware at reset.

Note: Memory blocks not affected by these parameters can always be seen at their specified base

addresses. See the complete memory map presented in Figure 8-1 on page 19.

The AT91SAM9G20 matrix manages a boot memory that depends on the level on the BMS pin at reset. The internal memory area mapped between address 0x0 and 0x000F FFFF is reserved for this purpose.

If BMS is detected at 1, the boot memory is the embedded ROM.

If BMS is detected at 0, the boot memory is the memory connected on the Chip Select 0 of the External Bus Interface.

8.1.1.1 BMS = 1, Boot on Embedded ROM

The system boots using the Boot Program.

• Boot on slow clock (On-chip RC or 32,768 Hz)

• Auto baudrate detection

• Downloads and runs an application from external storage media into internal SRAM

• Downloaded code size depends on embedded SRAM size

• Automatic detection of valid application

• Bootloader on a non-volatile memory

– SDCard (boot ROM does not support high capacity SDCards.)

–NAND Flash

– SPI DataFlash

– EEPROM on TWI

• SAM-BA

Boot in case no valid program is detected in external NVM, supporting

– Serial communication on a DBGU

– USB Device HS Port

AT91SAM9G20 Summary

and Serial Flash connected on NPCS0 and NPCS1 of the SPI0

8.1.1.2 BMS = 0, Boot on External Memory

• Boot on slow clock (On-chip RC or 32,768 Hz)

• Boot with the default configuration for the Static Memory Controller, byte select mode, 16-bit data bus, Read/Write controlled by Chip Select, allows boot on 16-bit non-volatile memory.

The customer-programmed software must perform a complete configuration.

To speed up the boot sequence when booting at 32 kHz EBI CS0 (BMS=0), the user must take the following steps:

1. Program the PMC (main oscillator enable or bypass mode).

2. Program and start the PLL.

3. Reprogram the SMC setup, cycle, hold, mode timings registers for CS0 to adapt them

to the new clock.

4. Switch the main clock to the new value.

8.2 External Memories

The external memories are accessed through the External Bus Interface. Each Chip Select line has a 256-Mbyte memory area assigned.

6384CS–ATARM–11-Mar-09

Refer to the memory map in Figure 8-1 on page 19.

8.2.1 External Bus Interface

• Integrates three External Memory Controllers

– Static Memory Controller

– SDRAM Controller

– ECC Controller

• Additional logic for NAND Flash

• Full 32-bit External Data Bus

• Up to 26-bit Address Bus (up to 64MBytes linear)

• Up to 8 chip selects, Configurable Assignment:

– Static Memory Controller on NCS0

– SDRAM Controller or Static Memory Controller on NCS1

– Static Memory Controller on NCS2

– Static Memory Controller on NCS3, Optional NAND Flash support

– Static Memory Controller on NCS4 - NCS5, Optional CompactFlash support

– Static Memory Controller on NCS6-NCS7

8.2.2 Static Memory Controller

• 8-, 16- or 32-bit Data Bus

• Multiple Access Modes supported

– Byte Write or Byte Select Lines

– Asynchronous read in Page Mode supported (4- up to 32-byte page size)

• Multiple device adaptability

– Compliant with LCD Module

– Control signals programmable setup, pulse and hold time for each Memory Bank

• Multiple Wait State Management

– Programmable Wait State Generation

– External Wait Request

– Programmable Data Float Time

• Slow Clock mode supported

8.2.3 SDRAM Controller

• Supported devices

• Numerous configurations supported

• Programming facilities

AT91SAM9G20 Summary

– Standard and Low-power SDRAM (Mobile SDRAM)

– 2K, 4K, 8K Row Address Memory Parts

– SDRAM with two or four Internal Banks

– SDRAM with 16- or 32-bit Datapath

– Word, half-word, byte access

– Automatic page break when Memory Boundary has been reached

6384CS–ATARM–11-Mar-09

– Multibank Ping-pong Access

– Timing parameters specified by software

– Automatic refresh operation, refresh rate is programmable

• Energy-saving capabilities

– Self-refresh, power down and deep power down modes supported

• Error detection

– Refresh Error Interrupt

• SDRAM Power-up Initialization by software

• CAS Latency of 1, 2 and 3 supported

• Auto Precharge Command not used

8.2.4 Error Corrected Code Controller

• Hardware Error Corrected Code (ECC) Generation

– Detection and Correction by Software

• Supports NAND Flash and SmartMedia™ Devices with 8- or 16-bit Data Path.

• Supports NAND Flash/SmartMedia with Page Sizes of 528, 1056, 2112 and 4224 Bytes, Specified by Software

• Supports 1 bit correction for a page of 512,1024,2048 and 4096 Bytes with 8- or 16-bit Data Path

• Supports 1 bit correction per 512 bytes of data for a page size of 512, 2048 and 4096 Bytes with 8-bit Data Path

• Supports 1 bit correction per 256 bytes of data for a page size of 512, 2048 and 4096 Bytes with 8-bit Data Path

AT91SAM9G20 Summary

9. System Controller

The System Controller is a set of peripherals, which allow handling of key elements of the system, such as power, resets, clocks, time, interrupts, watchdog, etc.

The System Controller User Interface embeds also the registers allowing to configure the Matrix and a set of registers for the chip configuration. The chip configuration registers allows configuring:

The System Controller’s peripherals are all mapped within the highest 16 Kbytes of address space, between addresses 0xFFFF E800 and 0xFFFF FFFF.

However, all the registers of System Controller are mapped on the top of the address space. All the registers of the System Controller can be addressed from a single pointer by using the standard ARM instruction set, as the Load/Store instruction has an indexing mode of ±4 Kbytes.

Figure 9-1 on page 24 shows the System Controller block diagram.

Figure 8-1 on page 19 shows the mapping of the User Interfaces of the System Controller

peripherals.

– EBI chip select assignment and Voltage range for external memories

6384CS–ATARM–11-Mar-09

9.1 System Controller Block Diagram

NRST

SLCK

Advanced

Interrupt

Controller

Real-Time

Timer

Periodic

Interval

Timer

Reset

Controller

PA0-PA31

periph_nreset

System Controller

Watchdog

Timer

wdt_fault WDRPROC

PIO

Controllers

Power

Management

Controller

XIN

XOUT

MAINCK

PLLACK

pit_irq

MCK

proc_nreset

wdt_irq

periph_irq[2..4]

periph_nreset

periph_clk[2..27]

PCK

MCK

pmc_irq

nirq nfiq

rtt_irq

Embedded Peripherals

periph_clk[2..4]

pck[0-1]

in out enable

ARM926EJ-S

SLCK

irq0-irq2 fiq

irq0-irq2

fiq

periph_irq[6..24]

periph_irq[2..24]

int

periph_nreset

periph_clk[6..24]

jtag_nreset

por_ntrst

proc_nreset

periph_nreset

dbgu_txd

dbgu_rxd

pit_irq

dbgu_irq

pmc_irq

rstc_irq

wdt_irq

rstc_irq

SLCK

Boundary Scan

TAP Controller

jtag_nreset

debug

PCK

debug

idle

debug

Bus Matrix

MCK

periph_nreset

proc_nreset

backup_nreset

periph_nreset

idle

Debug

Unit

dbgu_irq

MCK

dbgu_rxd

periph_nreset

dbgu_txd

rtt_alarm

Shut-Down

Controller

SLCK

rtt0_alarm

backup_nreset

SHDN

WKUP

4 General-Purpose

Backup Registers

backup_nreset

XIN32

XOUT32

PLLBCK

PB0-PB31

PC0-PC31

VDDBU Powered

VDDCORE Powered

ntrst

VDDCORE

POR

MAIN

OSC

PLLA

VDDBU

POR

SLOW

CLOCK

OSC

PLLB

por_ntrst

VDDBU

rtt_irq

UDPCK

USB

Device

Por t

UDPCK

periph_nreset

periph_clk[10]

periph_irq[10]

USB Host

Por t

periph_nreset

periph_clk[20]

periph_irq[20]

UHPCK

OSC

OSCSEL

Figure 9-1. AT91SAM9G20 System Controller Block Diagram

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

9.2 Reset Controller

• Based on two Power-on-Reset cell

– one on VDDBU and one on VDDCORE

• Status of the last reset

– Either general reset (VDDBU rising), wake-up reset (VDDCORE rising), software

• Controls the internal resets and the NRST pin output

– Allows shaping a reset signal for the external devices

9.3 Shutdown Controller

• Shutdown and Wake-Up logic

– Software programmable assertion of the SHDWN pin

– Deassertion Programmable on a WKUP pin level change or on alarm

9.4 Clock Generator

• Embeds a Low Power 32768 Hz Slow Clock Oscillator and a Low power RC oscillator selectable with OSCSEL signal

– Provides the permanent Slow Clock SLCK to the system

• Embeds the Main Oscillator

– Oscillator bypass feature

– Supports 3 to 20 MHz crystals

• Embeds 2 PLLs

– The PLL A outputs 400-800 MHz clock

– The PLL B outputs 100 MHz clock

– Both integrate an input divider to increase output accuracy

– PLL A and PLL B embed their own filters

AT91SAM9G20 Summary

reset, user reset or watchdog reset

6384CS–ATARM–11-Mar-09

Figure 9-2. Clock Generator Block Diagram

On Chip RC OSC

Power

Management

Controller

XIN

XOUT

Slow Clock SLCK

Main Clock MAINCK

PLLA Clock PLLACK

ControlStatus

PLL and

Divider B

PLLB Clock PLLBCK

XIN32

XOUT32

Slow Clock

Oscillator

Main

Oscillator

PLL and

Divider A

Clock Generator

OSCSEL

9.5 Power Management Controller

•Provides:

– the Processor Clock PCK

– the Master Clock MCK, in particular to the Matrix and the memory interfaces.The

MCK divider can be 1,2,4,6

– the USB Device Clock UDPCK

– independent peripheral clocks, typically at the frequency of MCK

– 2 programmable clock outputs: PCK0, PCK1

• Five flexible operating modes:

– Normal Mode, processor and peripherals running at a programmable frequency

– Idle Mode, processor stopped waiting for an interrupt

– Slow Clock Mode, processor and peripherals running at low frequency

– Standby Mode, mix of Idle and Backup Mode, peripheral running at low frequency,

processor stopped waiting for an interrupt

– Backup Mode, Main Power Supplies off, VDDBU powered by a battery

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

AT91SAM9G20 Summary

MCK

periph_clk[..]

int

SLCK

MAINCK

PLLACK

Prescaler

/1,/2,/4,.../64

PCK

Processor

Clock

Controller

Idle Mode

Master Clock Controller

Peripherals

Clock Controller

ON/OFF

PLLBCK

Divider

/1,/2,/4,/6

USB Clock Controller

SLCK MAINCK PLLACK

Prescaler

/1,/2,/4,...,/64

Programmable Clock Controller

PLLBCK

Divider

/1,/2,/4

pck[..]

PLLBCK

UDPCK

ON/OFF

/1,/2

Divider

Figure 9-3. AT91SAM9G20 Power Management Controller Block Diagram

9.6 Periodic Interval Timer

• Includes a 20-bit Periodic Counter, with less than 1 µs accuracy

• Includes a 12-bit Interval Overlay Counter

• Real Time OS or Linux

9.7 Watchdog Timer

9.8 Real-time Timer

• 16-bit key-protected only-once-Programmable Counter

• Windowed, prevents the processor being in a dead-lock on the watchdog access

• Real-time Timer 32-bit free-running back-up Counter

• Integrates a 16-bit programmable prescaler running on slow clock

• Alarm Register capable of generating a wake-up of the system through the Shutdown Controller

9.9 General-purpose Back-up Registers

• Four 32-bit backup general-purpose registers

9.10 Advanced Interrupt Controller

• Controls the interrupt lines (nIRQ and nFIQ) of the ARM Processor

• Thirty-two individually maskable and vectored interrupt sources

/Windows CE® compliant tick generator

6384CS–ATARM–11-Mar-09

– Source 0 is reserved for the Fast Interrupt Input (FIQ)

– Source 1 is reserved for system peripherals

– Programmable Edge-triggered or Level-sensitive Internal Sources

– Programmable Positive/Negative Edge-triggered or High/Low Level-sensitive

• Three External Sources plus the Fast Interrupt signal

• 8-level Priority Controller

– Drives the Normal Interrupt of the processor

– Handles priority of the interrupt sources 1 to 31

– Higher priority interrupts can be served during service of lower priority interrupt

• Vectoring

– Optimizes Interrupt Service Routine Branch and Execution

– One 32-bit Vector Register per interrupt source

– Interrupt Vector Register reads the corresponding current Interrupt Vector

•Protect Mode

– Easy debugging by preventing automatic operations when protect models are

enabled

•Fast Forcing

– Permits redirecting any normal interrupt source on the Fast Interrupt of the

processor

9.11 Debug Unit

• Composed of two functions:

•Two-pin UART

• Debug Communication Channel Support

9.12 Chip Identification

• Chip ID:0x019905A1

• JTAG ID: 0x05B2403F

• ARM926 TAP ID:0x0792603F

–Two-pin UART

– Debug Communication Channel (DCC) support

– Implemented features are 100% compatible with the standard Atmel

– Independent receiver and transmitter with a common programmable Baud Rate

Generator

– Even, Odd, Mark or Space Parity Generation

– Parity, Framing and Overrun Error Detection

– Automatic Echo, Local Loopback and Remote Loopback Channel Modes

– Support for two PDC channels with connection to receiver and transmitter

– Offers visibility of and interrupt trigger from COMMRX and COMMTX signals from

the ARM Processor’s ICE Interface

USART

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

10. Peripherals

10.1 User Interface

10.2 Identifiers

AT91SAM9G20 Summary

The peripherals are mapped in the upper 256 Mbytes of the address space between the addresses 0xFFFA 0000 and 0xFFFC FFFF. Each User Peripheral is allocated 16 Kbytes of address space. A complete memory map is presented in Figure 8-1 on page 19.

Table 10-1 defines the Peripheral Identifiers of the AT91SAM9G20. A peripheral identifier is

required for the control of the peripheral interrupt with the Advanced Interrupt Controller and for the control of the peripheral clock with the Power Management Controller.

Table 10-1. AT91SAM9G20 Peripheral Identifiers (Continued)

Peripheral ID Peripheral Mnemonic Peripheral Name External Interrupt

0 AIC Advanced Interrupt Controller FIQ

1 SYSC System Controller Interrupt

2 PIOA Parallel I/O Controller A

3 PIOB Parallel I/O Controller B

4 PIOC Parallel I/O Controller C

5 ADC Analog to Digital Converter

6 US0 USART 0

7 US1 USART 1

8 US2 USART 2

9 MCI Multimedia Card Interface

10 UDP USB Device Port

11 TWI Two-wire Interface

12 SPI0 Serial Peripheral Interface 0

13 SPI1 Serial Peripheral Interface 1

14 SSC Synchronous Serial Controller

15 - Reserved

16 - Reserved

17 TC0 Timer/Counter 0

18 TC1 Timer/Counter 1

19 TC2 Timer/Counter 2

20 UHP USB Host Port

21 EMAC Ethernet MAC

22 ISI Image Sensor Interface

23 US3 USART 3

24 US4 USART 4

25 US5 USART 5

26 TC3 Timer/Counter 3

27 TC4 Timer/Counter 4

28 TC5 Timer/Counter 5

6384CS–ATARM–11-Mar-09

Table 10-1. AT91SAM9G20 Peripheral Identifiers (Continued)

Peripheral ID Peripheral Mnemonic Peripheral Name External Interrupt

29 AIC Advanced Interrupt Controller IRQ0

30 AIC Advanced Interrupt Controller IRQ1

31 AIC Advanced Interrupt Controller IRQ2

Note: Setting AIC, SYSC, UHP, ADC and IRQ0-2 bits in the clock set/clear registers of the PMC has no effect. The ADC clock is auto-

matically started for the first conversion. In Sleep Mode the ADC clock is automatically stopped after each conversion.

10.2.1 Peripheral Interrupts and Clock Control

10.2.1.1 System Interrupt

The System Interrupt in Source 1 is the wired-OR of the interrupt signals coming from:

• the SDRAM Controller

• the Debug Unit

• the Periodic Interval Timer

• the Real-time Timer

• the Watchdog Timer

• the Reset Controller

• the Power Management Controller

The clock of these peripherals cannot be deactivated and Peripheral ID 1 can only be used within the Advanced Interrupt Controller.

10.2.1.2 External Interrupts

All external interrupt signals, i.e., the Fast Interrupt signal FIQ or the Interrupt signals IRQ0 to IRQ2, use a dedicated Peripheral ID. However, there is no clock control associated with these peripheral IDs.

10.3 Peripheral Signal Multiplexing on I/O Lines

The AT91SAM9G20 features 3 PIO controllers (PIOA, PIOB, PIOC) that multiplex the I/O lines of the peripheral set.

Each PIO Controller controls up to 32 lines. Each line can be assigned to one of two peripheral functions, A or B. Table 10-2 on page 31, Table 10-3 on page 32 and Table 10-4 on page 33 define how the I/O lines of the peripherals A and B are multiplexed on the PIO Controllers. The two columns “Function” and “Comments” have been inserted in this table for the user’s own comments; they may be used to track how pins are defined in an application.

Note that some peripheral functions which are output only might be duplicated within both tables.

The column “Reset State” indicates whether the PIO Line resets in I/O mode or in peripheral mode. If I/O appears, the PIO Line resets in input with the pull-up enabled, so that the device is maintained in a static state as soon as the reset is released. As a result, the bit corresponding to the PIO Line in the register PIO_PSR (Peripheral Status Register) resets low.

If a signal name appears in the “Reset State” column, the PIO Line is assigned to this function and the corresponding bit in PIO_PSR resets high. This is the case of pins controlling memories, in particular the address lines, which require the pin to be driven as soon as the reset is released. Note that the pull-up resistor is also enabled in this case.

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

AT91SAM9G20 Summary

10.3.1 PIO Controller A Multiplexing

Table 10-2. Multiplexing on PIO Controller A

PIO Controller A Application Usage

I/O Line Peripheral A Peripheral B Comments Reset State Power Supply Function Comments

PA0 SPI0_MISO MCDB0 I/O VDDIOP

PA1 SPI0_MOSI MCCDB I/O VDDIOP

PA2 SPI0_SPCK I/O VDDIOP

PA3 SPI0_NPCS0 MCDB3 I/O VDDIOP

PA4 RTS2 MCDB2 I/O VDDIOP

PA5 CTS2 MCDB1 I/O VDDIOP

PA6 MCDA0 I/O VDDIOP

PA7 MCCDA I/O VDDIOP

PA8 MCCK I/O VDDIOP

PA9 MCDA1 I/O VDDIOP

PA10 MCDA2 ETX2 I/O VDDIOP

PA11 MCDA3 ETX3 I/O VDDIOP

PA12 ETX0 I/O VDDIOP

PA13 ETX1 I/O VDDIOP

PA14 ERX0 I/O VDDIOP

PA15 ERX1 I/O VDDIOP

PA16 ETXEN I/O VDDIOP

PA17 ERXDV I/O VDDIOP

PA18 ERXER I/O VDDIOP

PA19 ETXCK I/O VDDIOP

PA20 EMDC I/O VDDIOP

PA21 EMDIO I/O VDDIOP

PA22 ADTRG ETXER I/O VDDIOP

PA23 TWD ETX2 I/O VDDIOP

PA24 TWCK ETX3 I/O VDDIOP

PA25 TCLK0 ERX2 I/O VDDIOP

PA26 TIOA0 ERX3 I/O VDDIOP

PA27 TIOA1 ERXCK I/O VDDIOP

PA28 TIOA2 ECRS I/O VDDIOP

PA29 SCK1 ECOL I/O VDDIOP

PA30 SCK2 RXD4 I/O VDDIOP

PA31 SCK0 TXD4 I/O VDDIOP

6384CS–ATARM–11-Mar-09

10.3.2 PIO Controller B Multiplexing

Table 10-3. Multiplexing on PIO Controller B

PIO Controller B Application Usage

I/O Line Peripheral A Peripheral B Comments Reset State Power Supply Function Comments

PB0 SPI1_MISO TIOA3 I/O VDDIOP

PB1 SPI1_MOSI TIOB3 I/O VDDIOP

PB2 SPI1_SPCK TIOA4 I/O VDDIOP

PB3 SPI1_NPCS0 TIOA5 I/O VDDIOP

PB4 TXD0 I/O VDDIOP

PB5 RXD0 I/O VDDIOP

PB6 TXD1 TCLK1 I/O VDDIOP

PB7 RXD1 TCLK2 I/O VDDIOP

PB8 TXD2 I/O VDDIOP

PB9 RXD2 I/O VDDIOP

PB10 TXD3 ISI_D8 I/O VDDIOP

PB11 RXD3 ISI_D9 I/O VDDIOP

PB12 TXD5 ISI_D10 I/O VDDIOP

PB13 RXD5 ISI_D11 I/O VDDIOP

PB14 DRXD I/O VDDIOP

PB15 DTXD I/O VDDIOP

PB16 TK0 TCLK3 I/O VDDIOP

PB17 TF0 TCLK4 I/O VDDIOP

PB18 TD0 TIOB4 I/O VDDIOP

PB19 RD0 TIOB5 I/O VDDIOP

PB20 RK0 ISI_D0 I/O VDDIOP

PB21 RF0 ISI_D1 I/O VDDIOP

PB22 DSR0 ISI_D2 I/O VDDIOP

PB23 DCD0 ISI_D3 I/O VDDIOP

PB24 DTR0 ISI_D4 I/O VDDIOP

PB25 RI0 ISI_D5 I/O VDDIOP

PB26 RTS0 ISI_D6 I/O VDDIOP

PB27 CTS0 ISI_D7 I/O VDDIOP

PB28 RTS1 ISI_PCK I/O VDDIOP

PB29 CTS1 ISI_VSYNC I/O VDDIOP

PB30 PCK0 ISI_HSYNC I/O VDDIOP

PB31 PCK1 ISI_MCK I/O VDDIOP

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

AT91SAM9G20 Summary

10.3.3 PIO Controller C Multiplexing

Table 10-4. Multiplexing on PIO Controller C

PIO Controller C Application Usage

I/O Line Peripheral A Peripheral B Comments Reset State Power Supply Function Comments

PC0 SCK3 AD0 I/O VDDANA

PC1 PCK0 AD1 I/O VDDANA

PC2 PCK1 AD2 I/O VDDANA

PC3 SPI1_NPCS3 AD3 I/O VDDANA

PC4 A23 SPI1_NPCS2 A23 VDDIOM

PC5 A24 SPI1_NPCS1 A24 VDDIOM

PC6 TIOB2 CFCE1 I/O VDDIOM

PC7 TIOB1 CFCE2 I/O VDDIOM

PC8 NCS4/CFCS0 RTS3 I/O VDDIOM

PC9 NCS5/CFCS1 TIOB0 I/O VDDIOM

PC10 A25/CFRNW CTS3 A25 VDDIOM

PC11 NCS2 SPI0_NPCS1 I/O VDDIOM

PC12 IRQ0 NCS7 I/O VDDIOM

PC13 FIQ NCS6 I/O VDDIOM

PC14 NCS3/NANDCS IRQ2 I/O VDDIOM

PC15 NWAIT IRQ1 I/O VDDIOM

PC16 D16 SPI0_NPCS2 I/O VDDIOM

PC17 D17 SPI0_NPCS3 I/O VDDIOM

PC18 D18 SPI1_NPCS1 I/O VDDIOM

PC19 D19 SPI1_NPCS2 I/O VDDIOM

PC20 D20 SPI1_NPCS3 I/O VDDIOM

PC21 D21 I/O VDDIOM

PC22 D22 TCLK5 I/O VDDIOM

PC23 D23 I/O VDDIOM

PC24 D24 I/O VDDIOM

PC25 D25 I/O VDDIOM

PC26 D26 I/O VDDIOM

PC27 D27 I/O VDDIOM

PC28 D28 I/O VDDIOM

PC29 D29 I/O VDDIOM

PC30 D30 I/O VDDIOM

PC31 D31 I/O VDDIOM

6384CS–ATARM–11-Mar-09

10.4 Embedded Peripherals

10.4.1 Serial Peripheral Interface

• Supports communication with serial external devices

– Four chip selects with external decoder support allow communication with up to 15

peripherals

– Serial memories, such as DataFlash and 3-wire EEPROMs

– Serial peripherals, such as ADCs, DACs, LCD Controllers, CAN Controllers and

Sensors

– External co-processors

• Master or slave serial peripheral bus interface

– 8- to 16-bit programmable data length per chip select

– Programmable phase and polarity per chip select

– Programmable transfer delays between consecutive transfers and between clock

and data per chip select

– Programmable delay between consecutive transfers

– Selectable mode fault detection

• Very fast transfers supported

– Transfers with baud rates up to MCK

– The chip select line may be left active to speed up transfers on the same device

10.4.2 Two-wire Interface

• Compatibility with standard two-wire serial memory

• One, two or three bytes for slave address

• Sequential read/write operations

• Supports either master or slave modes

• Compatible with standard two-wire serial memories

• Master, multi-master and slave mode operation

• Bit rate: up to 400 Kbits

• General Call supported in slave mode

• Connection to Peripheral DMA Controller (PDC) capabilities optimizes data transfers in

10.4.3 USART

• Programmable Baud Rate Generator

• 5- to 9-bit full-duplex synchronous or asynchronous serial communications

master mode only

– One channel for the receiver, one channel for the transmitter

– Next buffer support

– 1, 1.5 or 2 stop bits in Asynchronous Mode or 1 or 2 stop bits in Synchronous Mode

– Parity generation and error detection

– Framing error detection, overrun error detection

– MSB- or LSB-first

– Optional break generation and detection

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

AT91SAM9G20 Summary

– By 8 or by-16 over-sampling receiver frequency

– Hardware handshaking RTS-CTS

– Optional modem signal management DTR-DSR-DCD-RI

– Receiver time-out and transmitter timeguard

– Optional Multi-drop Mode with address generation and detection

– Optional Manchester Encoding

• RS485 with driver control signal

• ISO7816, T = 0 or T = 1 Protocols for interfacing with smart cards

– NACK handling, error counter with repetition and iteration limit

• IrDA modulation and demodulation

– Communication at up to 115.2 Kbps

• Test Modes

– Remote Loopback, Local Loopback, Automatic Echo

The USART contains features allowing management of the Modem Signals DTR, DSR, DCD and RI. In the AT91SAM9G20, only the USART0 implements these signals, named DTR0, DSR0, DCD0 and RI0.

The USART1 and USART2 do not implement all the modem signals. Only RTS and CTS (RTS1 and CTS1, RTS2 and CTS2, respectively) are implemented in these USARTs for other features.

Thus, programming the USART1, USART2 or the USART3 in Modem Mode may lead to unpredictable results. In these USARTs, the commands relating to the Modem Mode have no effect and the status bits relating the status of the modem signals are never activated.

10.4.4 Serial Synchronous Controller

• Provides serial synchronous communication links used in audio and telecom applications (with CODECs in Master or Slave Modes, I

• Contains an independent receiver and transmitter and a common clock divider

• Offers a configurable frame sync and data length

• Receiver and transmitter can be programmed to start automatically or on detection of different event on the frame sync signal

• Receiver and transmitter include a data signal, a clock signal and a frame synchronization signal

10.4.5 Timer Counter

• Two blocks of three 16-bit Timer Counter channels

• Each channel can be individually programmed to perform a wide range of functions including:

– Frequency Measurement

– Event Counting

– Interval Measurement

– Pulse Generation

–Delay Timing

– Pulse Width Modulation

– Up/down Capabilities

• Each channel is user-configurable and contains:

S, TDM Buses, Magnetic Card Reader, etc.)

6384CS–ATARM–11-Mar-09

– Three external clock inputs

– Five internal clock inputs

– Two multi-purpose input/output signals

• Each block contains two global registers that act on all three TC Channels

Note: TC Block 0 (TC0, TC1, TC2) and TC Block 1 (TC3, TC4, TC5) have identical user interfaces. See

Figure 8-1, “AT91SAM9G20 Memory Mapping,” on page 19 for TC Block 0 and TC Block 1 base

addresses.

10.4.6 Multimedia Card Interface

• One double-channel MultiMedia Card Interface

• Compatibility with MultiMedia Card Specification Version 3.11

• Compatibility with SD Memory Card Specification Version 1.1

• Compatibility with SDIO Specification Version V1.0.

• Card clock rate up to Master Clock divided by 2

• Embedded power management to slow down clock rate when not used

• MCI has two slots, each supporting

– One slot for one MultiMediaCard bus (up to 30 cards) or

– One SD Memory Card

• Support for stream, block and multi-block data read and write

10.4.7 USB Host Port

10.4.8 USB Device Port

• Compliance with Open HCI Rev 1.0 Specification

• Compliance with USB V2.0 Full-speed and Low-speed Specification

• Supports both Low-Speed 1.5 Mbps and Full-speed 12 Mbps devices

• Root hub integrated with two downstream USB ports in the 217-LFBGA package

• Two embedded USB transceivers

• Supports power management

• Operates as a master on the Matrix

• USB V2.0 full-speed compliant, 12 MBits per second

• Embedded USB V2.0 full-speed transceiver

• Embedded 2,432-byte dual-port RAM for endpoints

• Suspend/Resume logic

• Ping-pong mode (two memory banks) for isochronous and bulk endpoints

• Six general-purpose endpoints

– Endpoint 0 and 3: 64 bytes, no ping-pong mode

– Endpoint 1 and 2: 64 bytes, ping-pong mode

– Endpoint 4 and 5: 512 bytes, ping-pong mode

• Embedded pad pull-up

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

10.4.9 Ethernet 10/100 MAC

• Compatibility with IEEE Standard 802.3

• 10 and 100 MBits per second data throughput capability

• Full- and half-duplex operations

• MII or RMII interface to the physical layer

• Register Interface to address, data, status and control registers

• DMA Interface, operating as a master on the Memory Controller

• Interrupt generation to signal receive and transmit completion

• 28-byte transmit and 28-byte receive FIFOs

• Automatic pad and CRC generation on transmitted frames

• Address checking logic to recognize four 48-bit addresses

• Support promiscuous mode where all valid frames are copied to memory

• Support physical layer management through MDIO interface

10.4.10 Image Sensor Interface

• ITU-R BT. 601/656 8-bit mode external interface support

• Support for ITU-R BT.656-4 SAV and EAV synchronization

• Vertical and horizontal resolutions up to 2048 x 2048

• Preview Path up to 640 x 480 in RGMB mode, 2048 x2048 in grayscale mode

• Support for packed data formatting for YCbCr 4:2:2 formats

• Preview scaler to generate smaller size image

• Programmable frame capture rate

AT91SAM9G20 Summary

10.4.11 Analog-to-Digital Converter

• 4-channel ADC

• 10-bit 312K samples/sec. Successive Approximation Register ADC

• -2/+2 LSB Integral Non Linearity, -1/+1 LSB Differential Non Linearity

• Individual enable and disable of each channel

• External voltage reference for better accuracy on low voltage inputs

• Multiple trigger source – Hardware or software trigger – External trigger pin – Timer Counter 0 to 2 outputs TIOA0 to TIOA2 trigger

• Sleep Mode and conversion sequencer – Automatic wakeup on trigger and back to sleep mode after conversions of all enabled channels

• Four analog inputs shared with digital signals

6384CS–ATARM–11-Mar-09

11. Pacakge Drawing

11.1 217-ball LFBA Package

Figure 11-1. 217-ball LFBGA Package Drawing

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

11.2 247-ball TFBGA Package

Figure 11-2. 247-ball TFBGA Package Drawing

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

12. AT91SAM9G20 Ordering Information

Table 12-1. AT91SAM9G20 Ordering Information

MRL A Ordering Code MRL B Ordering Code Package Package Type Temperature Operating Range

AT91SAM9G20-CU AT91SAM9G20B-CU BGA217 Green Industrial -40°C to 85°C

– AT91SAM9G20B-CFU BGA247 Green Industrial -40°C to 85°C

AT91SAM9G20 Summary

6384CS–ATARM–11-Mar-09

Revision History

Doc. Rev Comments

AT91SAM9G20 Summary

Change Request Ref.

6348CS “Features” , Section 4.3 “247-ball TFBGA Package Outline”, Section 4.4 “247-ball TFBGA Package

Pinout”, added 247-ball TFBGA package information.

Section 10.4.6 “Multimedia Card Interface”, compatibility with MultiMedia Card spec v3.11, SD

Memory Card spec v1.1.

Signal Description, Table 3-1, added GNDPLL to table 6022

Table 3-1, Signal Description and Section 10-4 “Multiplexing on PIO Controller C”, EF100 removed. 6148

Section 11. “Pacakge Drawing”:

Section 11.2 “247-ball TFBGA Package”, added to summary. 6079

Section 12. “AT91SAM9G20 Ordering Information”

Table 12-1, “AT91SAM9G20 Ordering Information,” MLR B ordering information added to summary. 6079

6384BS Overview

“Features” on page 1, Debug Unit (DBGU) updated. Section 10.4.3 “USART”, “Optional Manchester Encoding” added to list of USART features. Section 8.1.1.1 “BMS = 1, Boot on Embedded ROM”,

– SDCard,

Section 6.6 “Shutdown Logic Pins”, updated with external pull-up requirement. rfo

6384AS First issue

(boot ROM does not support high capacity SDCards) clarification added.

6079

6080

5846 5931 5935

6384CS–ATARM–11-Mar-09

ATMEL AT91SAM9G20 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Features

1. Description

2. AT91SAM9G20 Block Diagram

3. Signal Description

4. Package and Pinout

4.1 217-ball LFBGA Package Outline

4.2 217-ball LFBGA Pinout

4.3 247-ball TFBGA Package Outline

4.4 247-ball TFBGA Package Pinout

5. Power Considerations

5.1 Power Supplies

5.2 Power Consumption

5.3 Programmable I/O Lines

6. I/O Line Considerations

6.1 JTAG Port Pins

6.2 Test Pin

6.3 Reset Pins

6.4 PIO Controllers

6.5 I/O Line Drive Levels

6.6 Shutdown Logic Pins

6.7 Slow Clock Selection

7. Processor and Architecture

7.1 ARM926EJ-S Processor

7.2 Bus Matrix

7.2.1 Matrix Masters

7.2.2 Matrix Slaves

7.2.3 Masters to Slaves Access

7.3 Peripheral DMA Controller

7.4 Debug and Test Features

8. Memories

8.1 Embedded Memories

8.1.1 Boot Strategies

8.1.1.1 BMS = 1, Boot on Embedded ROM

8.1.1.2 BMS = 0, Boot on External Memory

8.2 External Memories

8.2.1 External Bus Interface

8.2.2 Static Memory Controller

8.2.3 SDRAM Controller

8.2.4 Error Corrected Code Controller

9. System Controller

9.1 System Controller Block Diagram

9.2 Reset Controller

9.3 Shutdown Controller

9.4 Clock Generator

9.5 Power Management Controller

9.6 Periodic Interval Timer

9.7 Watchdog Timer

9.8 Real-time Timer

9.9 General-purpose Back-up Registers

9.10 Advanced Interrupt Controller

9.11 Debug Unit

9.12 Chip Identification

10. Peripherals

10.1 User Interface

10.2 Identifiers

10.2.1 Peripheral Interrupts and Clock Control

10.2.1.1 System Interrupt

10.2.1.2 External Interrupts

10.3 Peripheral Signal Multiplexing on I/O Lines

10.3.1 PIO Controller A Multiplexing

10.3.2 PIO Controller B Multiplexing

10.3.3 PIO Controller C Multiplexing

10.4 Embedded Peripherals

10.4.1 Serial Peripheral Interface

10.4.2 Two-wire Interface

10.4.3 USART

10.4.4 Serial Synchronous Controller

10.4.5 Timer Counter

10.4.6 Multimedia Card Interface

10.4.7 USB Host Port

10.4.8 USB Device Port

10.4.9 Ethernet 10/100 MAC

10.4.10 Image Sensor Interface

10.4.11 Analog-to-Digital Converter

11. Pacakge Drawing

11.1 217-ball LFBA Package
