FTB-8120NGE/8130NGE
Power Blazer

NEXT-GENERATION MULTISERVICE TEST MODULES

2011

GLOBAL GIGABIT ETHERNET TEST EQUIPMENT

GROWTH EXCELLENCE AWARD

Feature(s) of this product is/are protected by one or more of patent appl. US 2012/0307666 A1 and equivalents in other countries.

Fully integrated multiservice test solution supporting next-generation SONET/SDH, OTN, Ethernet
and Fibre Channel test functions

KEY FEATURES

The industry’s smallest and most effi cient module, ideal for
mobile backhaul and packet transport network deployments

Comprehensive Fibre Channel test capabilities
(1x, 2x, 4x, 10x)

OTN forward error correction (FEC) and optical channel data
unit multiplex testing capabilities as per ITU-T G.709

Complete bidirectional EtherSAM (ITU-T Y.1564) test suite

COMPLEMENTARY PRODUCTS

ODU0 and ODUfl ex for optical transport network (OTN), the
technology of choice for transporting Ethernet traffi c over the
core network; OAM&P for troubleshooting and maintenance

Ability to test all channels simultaneously and real-time
error/alarm monitoring to accelerate testing time and
improve the effi ciency of development environments

Complete Carrier Ethernet services portfolio: PBB-TE,
MPLS, IPv4/IPv6 and one-way delay

True wire-speed, stateful TCP throughput based on
RFC 6349 test for undisputable SLA reinforcement for
Ethernet services

SPEC SHEET

Platform

FTB-500

EXFO Connect-compatible: automated asset management;
data goes through the cloud and into a dynamic database

Compact Platform

FTB-200

FTB-8120NGE/8130NGE Power Blazer

SONET/SDH

SONET/SDH

NE

SONET/SDH

NE

SONET/SDH

THE CHOICE FOR INTEGRATED MULTISERVICE TRANSPORT TESTING

The responsibilities of traditional SONET/SDH telecom field installation personnel have evolved over the last few years. With the advent
of packet-aware SONET/SDH add-drop multiplexers—including multiservice transport platforms (MSTPs) and new reconfigurable
add-drop multiplexers (ROADMs)—technicians must not only perform traditional SONET/SDH tests, but are now also responsible
for verifying packet-based services such as Ethernet, 10 Gigabit Ethernet and Fibre Channel running over the same network
elements.

This has resulted in a growing need for multitechnology test solutions to support the deployment, operation and maintenance of
these multiservice platforms and the corresponding data-aware SONET/SDH networks.

EXFO’s FTB-8120NGE (2.5/2.7 Gbit/s) and FTB-8130NGE (10/11.3 Gbit/s) Power Blazer test modules have been designed
to specifically address such field commissioning and maintenance requirements, providing SONET/SDH, Ethernet and Fibre
Channel test functions in the industry’s smallest and most efficient module and setting a new standard for multiservice field testing.

SCALABLE, HIGH-PERFORMANCE SONET/SDH TESTING

SONET/SDH Service Turn-Up and Troubleshooting

The FTB-8120NGE/8130NGE Power Blazer modules offer a wide range of SONET/SDH test functions ranging from simple
bit-error-rate (BER) testing to advanced characterization and troubleshooting procedures. These functions include:

Mixed and bulk payload generation

›

and analysis from 64 kbit/s to
10 Gbit/s

High-order mappings:

›

STS-1/3c/12c/48c/192c and
AU-3/AU-4/AU-4-4c/16c/64c

Low-order mappings:

›

VT1.5/2/6, TU-11/12/2/3

Unframed optical signal testing at

›

10 Gbit/s rate

Section/RS, Line/MS, high-order (HO)

›

and low-order (LO) path overhead
manipulation and monitoring

Section/RS, Line/MS, high-order and

›

low-order path alarm/error generation
and monitoring

High-order and low-order pointer

›

generation and monitoring

K1/K2 OH byte capture

›

Tandem connection monitoring

›

Performance monitoring: G.821, G.826,

›

G.828, G.829, M.2100, M.2101

Frequency analysis and power

›

measurement

Payload block and replace

›

Frequency offset generation

›

DS1 loopcodes and NI/CSU loopback

›

emulation

Automatic protection switching (APS)

›

and service disruption time (SDT)
measurements

Multichannel SDT measurements and

›

real-time error/alarm monitoring for all
STS-1/AU-4 channels

Round-trip delay measurements

›

DS1/DS3 auto detection of line-code

›

framing and test pattern

Dual DS1/DS3 receiver testing

›

Independent transmitter and

›

receiver testing

Through mode analysis

›

Intrusive Through mode

›

Programmable error/alarm injection

›

DS1 FDL

›

Fractional T1/E1 testing

›

DS3 FEAC

›

Housed in either the FTB- 500 or FTB-200 platform,
the FTB- 8120NGE/8130NGE modules offer the
solution for fi eld circuit turn-up and troubleshooting.

FTB-8120NGE/8130NGE Power Blazer

Optical Transport Network Testing

OTN as per ITU-T G.709 has recently introduced two new concepts: ODU0 and ODUflex. ODU0 is a new virtual container
of 1.25 Gbit/s bandwidth specifically defined for efficiently mapping Gigabit Ethernet services over OTN. As for ODUflex,
it is the most efficient sub-wavelength bandwidth management capability for transport line rates of 10 Gbit/s, 40 Gbit/s and
upcoming 100 Gbit/s. ODUflex allows providers to interconnect routers in ways that enable efficient bandwidth growth in steps
of 1.25 Gbit/s, eliminating the need to allocate a full fixed-rate ODU container to each connection, and allowing service providers
to transport efficiently and seamlessly across lower-cost optical infrastructures.

With OTN deployments rapidly increasing, so is the need for smaller, field-oriented OTN test equipment. The FTB-8120NGE/8130NGE
Power Blazer modules offer OTN test capabilities for verifying compliancy with ITU-T G.709 standards. The tests include:

OTU1 (2.7 Gbit/s) and OTU2

›

(10.7 Gbit/s) bit rates

ODU0 (1.25 Gbit/s) container with

›

Gigabit Ethernet and SONET/SDH
client signals mapping

ODUflex with Ethernet client signal

›

mapping

Overclocked OTU2 rates: OTU1e

›

(11.0491 Gbit/s), OTU2e (11.0957
Gbit/s), OTU1f (11.2701 Gbit/s) and
OTU2f (11.3176 Gbit/s)

Unframed optical signal testing at

›

10.7 Gbit/s, 11.0491 Gbit/s,

11.0957 Gbit/s, 11.2701 Gbit/s and

11.3176 Gbit/s rates

Synchronous mapping of SONET/SDH

›

signals within OTN as well as
synchronous and asynchronous
demapping

Forward error correction (FEC) testing

›

Service disruption time (SDT)

›

measurements

Multichannel SDT measurements and

›

real-time error/alarm monitoring for all
ODU0 channels

Round-trip delay (RTD) measurements

›

OTU, ODU, OPU overhead

›

manipulation and monitoring

OTU, ODU (including ODU TCM),

›

OPU layer alarms/errors generation
and analysis

OTU, ODU (including ODU TCM)

›

trace messages

Mux/demux of ODU1/ODU2 testing;

›

generation of four ODU1 into a single
ODU2 structure and transporting it
over a single wavelength

ODU multiplexing alarm-generation and

›

analysis

Through mode analysis

›

Intrusive Through mode

›

EoOTN testing using internally

›

generated 10 GigE LAN and mapping
onto OTU1e and OTU2e rates

10 GigE LAN mapping into OTU2

›

using GFP-F

OTUk Signal

G.709 DUT

Power Blazer modules suppor t G.709
testing in either the FTB -200 or FTB-500.

FTB-8120NGE/8130NGE Power Blazer

ELECTRICAL OPTICAL

10 Mbit/s 100 Mbit/s

100 Mbit/s

1000 Mbit/s (GigE)

1000 Mbit/s

10 Gbit/s (10 GigE)—FTB-8130NGE only

Next-Generation SONET/SDH Testing

Available next-generation SONET/SDH test functionalities include generic framing procedure (GFP), virtual concatenation (VCAT)
and link-capacity adjustment scheme (LCAS). These options are available when the FTB-8120NGE/8130NGE are housed in the
FTB-500 platform.

GFP VCAT LCAS

Generation and analysis of frame types

›

(client management/client data)

Alarm/error generation and monitoring

›

Overhead manipulation and monitoring

›

Transmission and reception statistics monitoring

›

Supported over contiguous or VCAT containers

›

High-order and low-order VCAT support

›

Simultaneous manipulation and monitoring

›

of each member

Alarm/error generation and monitoring

›

Sequence-indicator manipulation

›

and processing

Group-summary monitoring

›

Differential delay analysis and insertion

›

SmartMode: Real-Time Signal Structure Discovery and Monitoring

EXFO’s FTB-8120NGE/8130NGE Power Blazer modules support a unique
feature called SmartMode. This provides users with full visibility of all high­order (STS/AU) and low-order (VT/TU) mixed mappings within the incoming
SONET/SDH and OTN test signal.

SmartMode automatically discovers the signal structure of the OC-n/STM-n
line including mixed mappings and virtual concatenation (VCAT) members.
In addition to this in-depth multichannel visibility, SmartMode performs real­time monitoring of all discovered high-order paths and user-selected low­order paths simultaneously, providing users with the industry’s most powerful
SONET/SDH multichannel monitoring and troubleshooting solution. Real­time monitoring allows users to easily isolate network faults, saving valuable
time and minimizing service disruption. SmartMode also provides one-touch
test case start, allowing users to quickly configure a desired test path and
SmartMode specific reporting.

Emulation and analysis of LCAS protocol

›

(Automatic and Manual modes)

Source and sink state machine

›

control and monitoring

Real-time generation and monitoring

›

of LCAS control fields

Real-time insertion and monitoring

›

of LCAS alarms/errors

FTB-8120NGE/8130NGE SmartMode: multichannel signal
discovery with real-time alarm sc an (shown in the FTB-50 0
user interface).

ETHERNET PERFORMANCE VALIDATION AND RELIABILITY

EXFO’s FTB-8120NGE/8130NGE offer a wide range of Ethernet test
functions designed for performance validation and reliability testing.

Interfaces

These modules support multiple Ethernet interfaces, both electrical and optical.

Applications

The FTB-8120NGE/8130NGE deliver the features required to perform
Ethernet service acceptance testing, namely RFC 2544 and BER testing.

FTB-8120NGE/8130NGE Power Blazer

ETHERSAM: THE NEW STANDARD IN ETHERNET TESTING

ITU-T Y.1564 is the new standard for turning up and troubleshooting Carrier Ethernet services. This methodology is completely
adapted to today’s Ethernet services, especially mobile backhaul and commercial services. Up to now, RFC 2544 has been the
most widely used methodology. However, it was designed for network device testing in the lab, not for services testing in the field.
ITU-T Y.1564 is the first testing standard developed for the field. It has a number of advantages over the RFC 2544 including
validation of critical SLA criteria such as packet jitter and QoS measurements. This methodology is also significantly faster, thereby
saving time and resources while optimizing QoS.

Contrary to other methodologies, EtherSAM supports new multiservice offerings. EtherSAM can simulate all types of services
that will run on the network and simultaneously qualify all key SLA parameters for each of these services. Moreover, it validates
the QoS mechanisms provisioned in the network to prioritize the different service types, resulting in more accurate validation
and much faster deployment and troubleshooting. EtherSAM is comprised of two phases, the service configuration test and the
service performance test.

Service Configuration Test

The service configuration test consists of sequentially testing each service to validate that the service is properly provisioned and
that all specific KPIs or SLA parameters are met. A ramp test and a burst test are performed to verify the committed information
rate (CIR), excess information rate (EIR), committed burst size (CBS) and excess burst size (EBS).

Ramp Test Burst Test

Service Performance Test

Once the configuration of each individual
service is validated, the service performance
test simultaneously validates the quality of all the
services over time.

FTB-8120NGE/8130NGE Power Blazer

EtherSAM Bidirectional Results

EXFO’s EtherSAM approach proves even more powerful as it executes the complete ITU-T Y.1564 test with bidirectional
measurements. Key SLA parameters are measured independently in each test direction, thus providing 100 % first-time-right service
activation—that is the highest level of confidence in service testing.

RFC 2544 TESTING

In cases where the Ethernet service is delivered via switched transport, the RFC 2544 measurements provide a baseline for service
providers to define SLAs with their customers. They enable service providers to validate the quality of service (QoS) delivered and
can provide them with a tool to create value-added services that can be measured and demonstrated to customers. For example,
these tests provide performance statistics and commissioning verification for virtual LANs (VLANs), virtual private networks (VPNs)
and transparent LAN services (TLS), all of which use Ethernet as an access technology.

The FTB-8120NGE/8130NGE Power Blazer modules come with a complete set of RFC 2544 test capabilities, including:

Throughput testing

›

Burst (back-to-back) testing

›

Frame loss analysis

›

Latency measurement

›

BER TESTING

Since the transparent transport of Ethernet services over physical media is becoming more widespread, Ethernet is increasingly
carried across a variety of layer 1 media over longer distances. This creates a growing need for the certification of Ethernet transport
on a bit-per-bit basis, which can be done using bit-error-rate testing (BERT).

BERT uses a pseudo-random binary sequence (PRBS) encapsulated into an Ethernet frame, making it possible to go from a
frame-based error measurement to a bit-error-rate measurement. This provides the bit-per-bit error count accuracy required for
the acceptance testing of physical-medium transport systems.

In addition to BER testing, the FTB-8120NGE/8130NGE Power Blazer modules also provide service disruption time (SDT)
measurements.

FTB-8120NGE/8130NGE Power Blazer

ETHERNET QUALITY OF SERVICE MEASUREMENTS

Data services are making a significant shift toward supporting a variety of applications on the same network. Multiservice offerings
such as triple-play services have fuelled the need for QoS testing to ensure the condition and reliability of each service and fully
qualify SLA parameters. The FTB-8120NGE/8130NGE allow service providers to simultaneously simulate and qualify different
applications through their multiple stream application. The user has the capability to configure up to 10 streams with different
Ethernet and IP QoS parameters such as VLAN ID (802.1Q), VLAN Priority (802.1p), VLAN stacking (802.1ad Q-in-Q), ToS
and DSCP. Specific stream profiles to transmit Voice-over-IP (VoIP), video and data can be selected for each stream. For each
stream, measurements for throughput, latency, frame loss and packet jitter (RFC 3393) are available simultaneously, allowing fast
and in-depth qualification of all SLA criteria.

PBB-TE AND MPLS: CARRIER ETHERNET TRANSPORT SOLUTION TESTING

As technologically-sophisticated commercial and residential consumers continue to drive demand for premium, high-bandwidth
data services such as voice and video, service providers worldwide are evolving their transport infrastructures to support these
bandwidth and quality intensive services. No longer is an all-IP core sufficient; providers must now expand their IP convergence
to the edge/metro network, in a cost-effective, quality-assured manner.

Two Ethernet tunneling technologies address these requirements: Provider Backbone Bridge-Traffic Engineering or PBB-TE (also
referred to as PBT) and transport MPLS. These two technologies enable connection-oriented Ethernet, providing carriers with a
means of offering scalable, reliable and resilient Ethernet services. The PBB-TE and MPLS options on the FTB-8120NGE/8130NGE
offer service providers a comprehensive field tool to efficiently qualify Ethernet services from end to end, validating metro and core
tunneling technologies.

TCP THROUGHPUT

The Internet protocol (IP) and transmission control protocol (TCP) together form the essence of TCP/IP networking. While IP deals
with the delivery of packets, TCP provides the integrity and assurance that the data packets transmitted by one host are reliably
received at the destination. Applications such as hypertext transfer protocol (HTTP), e-mail or file transfer protocol (FTP) depend
on TCP as their delivery assurance mechanism within networks. Customers deploying such applications expect not only physical
and link level SLAs from their service providers, but assurance that their TCP traffic requirements will be supported across the
network. The TCP throughput feature offers Ethernet service providers the capability of measuring and validating that the services
offered to their customers support the TCP traffic performance they expect.

ETHERNET ADVANCED TROUBLESHOOTING

The FTB-8120NGE/8130NGE provide a number of advanced features essential for in-depth troubleshooting in the event of
network failures or impairments. The advanced filtering option allows the user to configure up to ten filters each with up to four
operands, which will be applied to the received Ethernet traffic. Detailed statistics are available for each configured filter providing
the user with critical information required to pinpoint specific problems. Other advanced troubleshooting tools include advanced
auto-negation and flow-control capabilities.

The FTB-8120NGE/8130NGE also support full-line-rate data capture and decode. This key troubleshooting tool enables field
technicians to easily identify complex network issues. The comprehensive capture feature includes the capability to configure
capture filters and triggers to quickly zero in on network events.

FTB-8120NGE/8130NGE Power Blazer

INTERFACE RATE (GBIT/S)

1x 1.0625

2x

2.125

4x

4.25

10x 10.51875

FIBRE CHANNEL NETWORK INTEGRITY TESTING

EXFO’s FTB-8120NGE/8130NGE Power Blazer modules allow comprehensive testing capabilities for Fibre Channel network
deployment.

Interfaces

These modules support multiple Fibre Channel interfaces:

Applications

Since most SANs cover large distances and Fibre Channel has stringent performance attributes that must be respected, it is
imperative to test at each phase of network deployment to ensure appropriate service levels. EXFO’s FTB-8120NGE/8130NGE
Fibre Channel option provides full wire-speed traffic generation at FC-0, FC-1 and FC-2 logical layers, allowing BER testing for
link integrity measurements. Latency, buffer-to-buffer credit measurements for optimization, and login capabilities that enable end­to-end Fibre Channel network testing features are also supported.

Latency

Transmission of frames in a network is not instantaneous and is subject to multiple delays caused by the propagation delay in the
fiber and by processing time inside each piece of network equipment. Latency is the total accumulation of delays between two
end points. Some applications such as VoIP, video and storage area networks are very sensitive to excess latency.

It is therefore critical for service providers to properly characterize network latency when offering Fibre Channel services. From the
latency measurement that they perform, the FTB-8120NGE/8130NGE modules estimate buffer-to-buffer credit value requirements.

Buffer-to-Buffer Credit Estimation

The buffer credit mechanism is the flow-control engine for Fibre Channel. This is a crucial configuration parameter for optimal
network performance. Usually, network administrators calculate the value by taking the distance traveled and the data rate into
consideration; however, since latency issues are not considered, poor accuracy is to be expected. The FTB-8120NGE/8130NGE
modules are capable of estimating buffer credit values with respect to latency by calculating the distance according to the round­trip latency time.

Login Testing

Most new-generation transport devices (xWDM or SONET/SDH MUX) supporting Fibre Channel are no longer fully transparent;
they also have increased built-in intelligence, acting more as Fibre-Channel switches. With switch fabric login ability, the FTB­8120NGE/8130NGE modules support connections to a remote location through a fabric or semi-transparent networks.

The login process not only permits the unit to connect through a fabric, but it also exchanges some of the basic port characteristics
(such as buffer-to-buffer credit and class of service) in order to efficiently transport the traffic through the network.

The login feature allows automatic detection of port/fabric login, login status (successful login, in progress, failure and logout) and
response to remote buffer-to-buffer advertised credit.

FTB-8120NGE/8130NGE Power Blazer

UNSURPASSED CONFIGURATION AND OPERATIONAL FLEXIBILITY

Multiplatform Support and Versatility

The FTB-8120NGE/8130NGE modules share a unique architecture that allows them to be supported and interchangeable on
the FTB-500 and FTB-200 platforms. This cross-platform support provides users with added flexibility to select the platform that
best suits their testing needs. EXFO is the first and only test solution provider to offer this versatility, delivering single to multi­application test solutions with the same hardware module, which in turn dramatically reduces capital expenditures.

Once inserted into the FTB-200 Compact Platform, the FTB-8120NGE/8130NGE modules deliver the industry’s most compact
integrated SONET/SDH, Ethernet and Fibre Channel solution focused on field testing applications. Available with powerful
options—high-precision power meter, visual fault locator and fiber inspection probe—the FTB-200 provides all the critical test tools
required for day-to-day activities, eliminating the need to carry and manage multiple test sets.

Using the FTB-500 platform provides users with an all-in-one solution supporting a mix of SONET/SDH, OTN, Ethernet, Fibre
Channel and optical-layer test modules, making it the industry’s first truly integrated network testing platform. The resulting
modularity enables users to upgrade their systems in the field according to their testing needs. This multitechnology test platform
is the ideal solution for field, central office and lab applications.

Product Option Flexibility

With the FTB-8120NGE/8130NGE Power Blazer modules, users can
purchase one or more next-generation options (e.g., GFP, VCAT, LCAS)
and/or OTN options (OTU1, OTU2) via field upgrades to customize their
configuration as new needs arise. This eliminates the need to perform
complete hardware and/or platform retrofits, therefore significantly
decreasing capital and training expenses.

Also, EXFO’s FTB-8120NGE supports 1x/2x/4x Fibre Channel testing
options, while the FTB-8130NGE supports 1x/2x/4x/10x Fibre Channel
testing options.

FTB-8120NGE/8130NGE Power Blazer

PERT

EXFO Connect

AUTOMATED ASSET MANAGEMENT. PUSH TEST DATA IN THE CLOUD. GET CONNECTED.

EXFO Connect pushes and stores test equipment and test data content automatically in the cloud, allowing you to streamline
test operation from build-out to maintenance.

EX

TEST TOOLS ON THE FTB-200 PLATFORM

EXpert Test Tools is a series of platform-based software testing tools that enhance the value of the FTB-200 platform,
providing additional testing capabilities without the need for additional modules or units.

EXpert TEST TOOLS

EXpert VoIP generates a voice-over-IP call directly from the test platform to validate performance during service turn-up and troubleshooting.

Supports a wide range of signaling protocols, including SIP, SCCP, H.248/Megaco and H.323

›

Supports MOS and R-factor quality metrics

›

Simplifies testing with configurable pass/fail thresholds and RTP metrics

›

EXpert IP integrates six commonly used datacom test tools into one platform-based application to ensure that field technicians are
prepared for a wide range of testing needs.

Rapidly performs debugging sequences with VLAN scan and LAN discovery

›

Validates end-to-end ping and traceroute

›

Verifies FTP performance and HTTP availability

›

This powerful IPTV quality assessment solution enables set-top-box emulation and passive monitoring of IPTV streams, allowing quick
and easy pass/fail verification of IPTV installations.

Real-time video preview

›

Analyzes up to 10 video streams

›

Comprehensive QoS and QoE metrics including MOS score

›

FTB-8120NGE/8130NGE Power Blazer

ELECTRICAL INTERFACES

DS1 E1/2M E2/8M E3/34M DS3/45M STS-1e/

STM-0e/52M

E4/140M STS-3e/

STM-1e/155M

Tx pulse amplitude 2.4 to 3.6 V 3.0 V 2.37 V 2.37 V 1.0 ± 0.1 V 0.36 to 0.85 V 1.0 ± 0.1 Vpp 0.5 V

Tx pulse mask GR-499

Figure 9.5

G.703
Figure 15

G.703
Figure 15

G.703
Figure 16

G.703
Figure 17

DS-3
GR-499
Figure 9-8

45-M
G.703
Figure 14

G.253
Figure 4-10/4-11

GR-703
Figure 18/19

STM-3e
GR-253
Figure 4-12/
4-13/4-14

STM­1e/155M
G.703
Figure 22-23

Tx LBO
preamplification

Power dBdsx
+0.6 dBdsx (0-133 ft)
+1.2 dBdsx (133-266 ft)
+1.8 dBdsx (266-399 ft)
+2.4 dBdsx (399-533 ft)
+3.0 dBdsx (533-655 ft)

0 to 225 ft
255 to 450 ft

0 to 225 ft
255 to 450 ft

0 to 225 ft

Cable simulation Power dBdsx

–22.5 dBdsx
–15.0 dBdsx
–7.5 dBdsx
0 dBdsx

450 to 900 (927) ft 450 to 900 (927) ft

Rx level sensitivity
(dynamic range)

For 772 kHz:
TERM: ≤26 dB (cable
loss only) at 0 dBdsx Tx
DSX-MON: ≤26 dB
(20 dB resistive loss +
cable loss ≤ 6 dB)
Bridge: ≤6 dB
(cable loss only)

Note: measurement units =
dBdsx (Vref = 6 Vpp)

For 1024 kHz:
TERM: ≤6 dB
(cable loss only)
MON: ≤26 dB (20 dB
resistive loss +
cable loss ≤ 6 dB)
Bridge: ≤6 dB
(cable loss only)

Note: measurement
units = dBm

For 1024 kHz:
TERM: ≤6 dB
(cable loss only)
MON: ≤26 dB
(20 dB resistive loss
+ cable loss ≤ 6 dB)
Bridge: ≤6 dB
(cable loss only)

Note: measurement
units = dBm

For 4224 kHz:
TERM: ≤6 dB
(cable loss only)
MON: ≤26 dB
(20 dB resistive
loss + cable loss
≤ 6 dB)

Note: measurement
units = dBm

For 17.184 MHz:
TERM: ≤12 dB
(coaxial cable
loss only)
MON: ≤26 dB
(20 dB resistive
loss + cable loss
≤ 6 dB)

Note: measurement
units = dBm

For 22.368 MHz:
TERM: ≤10 dB
(cable loss only)
DSX-MON: ≤26.5 dB
(21.5 dB resistive loss +
cable loss ≤ 5 dB)

Note: measurement units =
dBm (Vref = 1.21 Vpp)

For 25.92 MHz:
TERM: ≤10 dB
(cable loss only)
MON: ≤25 dB
(20 dB resistive loss +
cable loss ≤ 5 dB)

Note: measurement
units = dBm

For 70 MHz:
TERM: ≤12 dB
(coaxial cable
loss only)
MON: ≤26 dB
(20 dB resistive loss
+ cable loss ≤ 6 dB)

Note: measurement
units = dBm

For 78 MHz:
TERM: ≤12.7 dB
(coaxial cable loss only)
MON: ≤26 dB
(20 dB resistive loss +
cable loss ≤ 6 dB)

Note: measurement
units = dBm

Transmit bit rate 1.544 Mbit/s

± 4.6 ppm

2.048 Mbit/s
± 4.6 ppm

2.048 Mbit/s
± 4.6 ppm

8.448 Mbit/s
± 4.6 ppm

34.368 Mbit/s
± 4.6 ppm

44.736 Mbit/s
± 4.6 ppm

51.84 Mbit/s
± 4.6 ppm

139.264 Mbit/s
±4.6 ppm

155.52 Mbit/s
± 4.6 ppm

Receive bit rate 1.544 Mbit/s

± 140 ppm

2.048 Mbit/s
± 100 ppm

2.048 Mbit/s
± 100 ppm

8.448 Mbit/s
± 100 ppm

34.368 Mbit/s
± 100 ppm

44.736 Mbit/s
± 100 ppm

51.84 Mbit/s
± 100 ppm

139.264 Mbit/s
± 100 ppm

155.52 Mbit/s
± 100 ppm

Measurement
uncertainty
(accuracy)

Frequency ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm

Electrical
power

Normal: ±1.0 dB
Monitor: ±2.0 dB

N

ormal

: ±1.0 dB

M

onitor

: ±2.0 dB

N

ormal

: ±1.0 dB

M

onitor

: ±2.0 dB

N

ormal

: ±1.0 dB

M

onitor

: ±2.0 dB

N

ormal

: ±1.0 dB

M

onitor

: ±2.0 dB

DSX range: ±1.0 dB
DSX-MON range: ±2.0 dB

DSX range: ±1.0 dB
DSX-MON range: ±2.0 dB

Normal: ±1.0 dB
Monitor: ±2.0 dB

Normal: ±1.0 dB
Monitor: ±2.0 dB

Peak-to-peak
voltage

±10 % down
to 500 mVpp

±10 % down
to 500 mVpp

±10 % down
to 500 mVpp

±10 % down
to 400 mVpp

±10 % down
to 200 mVpp

±10 % down
to 200 mVpp

±10 % down
to 200 mVpp

±10 % down
to 200 mVpp

±10 % down
to 200 mVpp

Frequency offset
generation

1.544 Mbit/s
± 140 ppm

2.048 Mbit/s
± 70 ppm

2.048 Mbit/s
± 70 ppm

8.448 Mbit/s
± 50 ppm

34.368 Mbit/s
± 50 ppm

44.736 Mbit/s
± 50 ppm

51.84 Mbit/s
± 50 ppm

139.264 Mbit/s
± 50 ppm

155.52 Mbit/s
± 50 ppm

Intrinsic jitter (Tx)

ANSI T1.403 section 6.3
GR-499 section 7.3

G.823 section 5.1 G.823 section 5.1 G.823 section

5.1

G.823 section 5.1
G.751 section 2.3

GR-449 section 7.3
(categories I and II)

GR-253 section

5.6.2.2 (category II)

G.823 section 5.1

G.825 section 5.1
GR-253 section 5.6.2.2

Input jitter
tolerance

AT&T PUB 62411
GR-499 section 7.3

G.823 section 7.1 G.823 section 7.1 G.823 section

7.1

G.823 section

7.1

GR-449 section 7.3
(categories I and II)

GR-253 section 5.6.2.2
(category II)

G.823 section 7.1
G.751 section 3.3

G.825 section 5.2
GR-253 section 5.6.2.3

Line coding AMI and B8ZS AMI and HDB3 AMI and HDB3 HDB3 HDB3 B3ZS B3ZS CMI CMI

Input impedance
(resistive termination)

100 ohms ± 5 %,
balanced

120 ohms ± 5 %,
balanced

75 ohms ± 5 %,
unbalanced

75 ohms ± 5 %,
unbalanced

75 ohms ± 5 %,
unbalanced

75 ohms ± 5 %,
unbalanced

75 ohms ± 5 %,
unbalanced

75 ohms ± 10 %,
unbalanced

75 ohms ± 5 %,
unbalanced

Connector type BANTAM

and RJ-48C

BANTAM
and RJ-48C

BNC BNC BNC BNC BNC BNC BNC

SYNCHRONISATION INTERFACES

External Clock DS1/1.5M External Clock E1/2M External Clock E1/2M Trigger 2 MHz

Tx pulse amplitude 2.4 to 3.6 V 3.0 V 2.37 V 0.75 to 1.5 V

Tx pulse mask GR-499 figure 9.5 G.703 figure 15 G.703 figure 15 G.703 figure 20

Tx LBO preamplification Typical power dBdsx

+0.6 dBdsx (0-133 ft)
+1.2 dBdsx (133-266 ft)
+1.8 dBdsx (266-399 ft)
+2.4 dBdsx (399-533 ft)
+3.0 dBdsx (533-655 ft)

Rx level sensivity (dynamic range) TERM: ≤6 dB (cable loss only)

(at 772 kHz for T1)
DSX-MON: ≤26 dB (20 dB resistive loss
+ cable loss ≤ 6 dB)
Bridge: ≤6 dB (cable loss only)

TERM: ≤6 dB (cable loss only)
MON: ≤26 dB (20 dB resistive loss
+ cable loss ≤ 6 dB)

Bridge: ≤6 dB (cable loss only)

TERM: ≤6 dB (cable loss only)
MON: ≤26 dB (resistive loss
+ cable loss ≤ 6 dB)

Bridge: ≤6 dB (cable loss only)

≤6 dB (cable loss only)

Transmission bit rate 1.544 Mbit/s ± 4.6 ppm 2.048 Mbit/s ± 4.6 ppm 2.048 Mbit/s ± 4.6 ppm

Reception bit rate 1.544 Mbit/s ± 50 ppm 2.048 Mbit/s ± 50 ppm 2.048 Mbit/s ± 50 ppm

Intrinsic jitter (Tx) ANSI T1.403 section 6.3

GR-499 section 7.3

G.823 section 6.1 G.823 section 6.1 G.703 table 11

Input jitter tolerance AT&T PUB 62411

GR-499 SECTION 7.3

G.823 section 7.2
G.813

G.823 section 7.2
G.813

Line coding AMI and B8ZS AMI and HDB3 AMI and HDB3

Input impedance (resistive termination) 75 ohms ± 5 %, unbalanced 75 ohms ± 5 %, unbalanced 75 ohms ± 5 %, unbalanced 75 ohms ± 5 %, unbalanced

Connector type BNC

a

BNC

a

BNC BNC

ELECTRICAL INTERFACES

The following section provides detailed information on all supported electrical interfaces.

Note

a. Adaptation cable required for BANTAM.

ETHERNET ADD/DROP INTERFACE

10/100/1000 Base-T (Add/Drop)

Compliance 10 Mbit/s: IEEE 802.3 section 14

100 Mbit/s: IEEE 802.3 section 25
1000 Mbit/s: IEEE 802.3 section 40

Connector RJ-45 Ethernet

Gigabit Ethernet (Add/Drop)

Interface/connector SFP/Dual LC

Compliance 1000 Mbit/s: IEEE 802.3 Section 40

a

Wavelength/Max Tx level 850, 1310 nm/—3 dBm

1550 nm/+5 dBm

REF-OUT INTERFACE

Parameter Value

Tx pulse amplitude 600 ± 150 mVpp
Transmission frequency

Clock divider = 16
Clock divider = 32
Clock divider = 64

SONET/SDH/10 GigE WAN

622.08 MHz

311.04 MHz

155.52 MHz

10 GigE LAN

644.53 MHz

322.266 MHz

161.133 MHz

OTU2

669.33 MHz

334.66 MHz

167.33 MHz

OTU1e

690.57 MHz

345.29 MHz

172.64 MHz

OTU2e

693.48 MHz

346.74 MHz

173.37 MHz

OTU1f

704.38 MHz

352.19 MHz

176.10 MHz

OTU2f

707.35 MHz

353.68 MHz

176.84 MHz

Output configuration AC coupled

Load impedance 50 ohms

Maximum cable length 3 meters

Connector Type SMA

SONET/SDH AND OTN OPTICAL INTERFACES

OC-3/STM-1 OC-12/STM-4 E2/8M OC-192/STM-64/OTU2

15 km;
1310 nm

40 km;
1310 nm

40 km;
1550 nm

80 km;
1550 nm

15 km;
1310 nm

40 km;
1310 nm

40 km;
1550 nm

80 km;
1550 nm

15 km;
1310 nm

40 km;
1310 nm

40 km;
1550 nm

80 km;
1550 nm

10 km;
1310 nm

40 km;
1550 nm

80 km;
1550 nm

Tx level

–5 to
0 dBm

–2 to
3 dBm

–5 to 0
dBm

–2 to
3 dBm

–5 to
0 dBm

–2 to
3 dBm

–5 to
0 dBm

–2 to
3 dBm

–5 to
0 dBm

–2 to
3 dBm

–5 to
0 dBm

–2 to
3 dBm

–6 to
–1 dBm

–1 to
2 dBm

0 to
4 dBm

Rx operating range

–23 to
–10 dBm

–30 to
–15 dBm

–23 to
–10 dBm

–30 to
–15 dBm

–22 to
0 dBm

–27 to
–9 dBm

–22 to
0 dBm

–29 to
–9 dBm

–18 to
0 dBm

–27 to
–9 dBm

–18 to
0 dBm

–28 to
–9 dBm

–11 to
–1 dBm

–14 to
–1 dBm

–24 to
–9 dBm

Transmit bit rate 155.52 Mbit/s ± 4.6 ppm 622.08 Mbit/s ± 4.6 ppm 2.48832 Gbit/s ± 4.6 ppm

2.66606 Gbit/s ± 4.6 ppm (OTU1)

9.95328 Gbit/s ± 4.6 ppm
(OC-192/STM-64)

10.70922 Gbit/s ± 4.6 ppm (OTU2)

11.0491 Gbit/s ± 4.6 ppm (OTU1e)

11.0957 Gbit/s ± 4.6 ppm (OTU2e)

11.2701 Gbit/s ± 4.6 ppm (OTU1f)

11.3176 Gbit/s ± 4.6 ppm (OTU2f)

9.95328 Gbit/s ± 4.6 ppm

10.70922 Gbit/s ± 4.6 ppm
(OTU2)

Receive bit rate 155.52 Mbit/s ± 100 ppm 622.08 Mbit/s ± 100 ppm 2.48832 Gbit/s ± 100 ppm

2.66606 Gbit/s ± 100 ppm (OTU1)

9.95328 Gbit/s ± 100 ppm
(OC-192/STM-64)

10.70922 Gbit/s ± 100 ppm (OTU2)

11.0491 Gbit/s ± 120 ppm (OTU1e)

11.0957 Gbit/s ± 120 ppm (OTU2e)

11.2701 Gbit/s ± 120 ppm (OTU1f)

11.3176 Gbit/s ± 120 ppm (OTU2f)

9.95328 Gbit/s ± 100 ppm

10.70922 Gbit/s
± 100 ppm (OTU2)

Operational
wavelength range

1261 to
1360 nm

1263 to
1360 nm

1430 to
1580 nm

1480 to
1580 nm

1270 to
1360 nm

1280 to
1335 nm

1430 to
1580 nm

1480 to
1580 nm

1260 to
1360 nm

1280 to
1335 nm

1430 to
1580 nm

1500 to
1580 nm

1290 to 1330 nm

1530 to
1565 nm

1530 to
1565 nm

Spectral width 1 nm (–20 dB) 1 nm (–20 dB) 1 nm (–20 dB) 1 nm (–20 dB)

Frequency offset generation ±50 ppm ±50 ppm ±50 ppm ±50 ppm

b

Measurement
uncertainty (accuracy)

Frequency ±4.6 ppm ±4.6 ppm ±4.6 ppm ±4.6 ppm

Optical power ±2 dB ±2 dB ±2 dB ±2 dB

Maximum Rx before damage

c

3 dBm 3 dBm 3 dBm 3 dBm

Jitter compliance GR-253 (SONET)

G.958 (SDH)

GR-253 (SONET)
G.958 (SDH)

GR-253 (SONET)
G.958 (SDH)
G.8251 (OTN)

GR-253 (SONET)
G.825 (SDH)
G.8251 (OTN)

Line coding NRZ NRZ NRZ NRZ

Eye safety SFP/XFP transceivers comply with IEC 60825 and 21 CFR 1040.10 (except for deviations pursuant to Laser Notice No. 50, dated July 2001), for Class 1 or 1M lasers.

Connector

d

Dual LC Dual LC Dual LC Dual LC

Transceiver type

e

SFP SFP SFP SFP

ELECTRICAL INTERFACES (CONT’D)

FTB-8120NGE/8130NGE Power Blazer

SONET/SDH AND OTN OPTICAL INTERFACES

The following section provides detailed information on all supported SONET/SDH/OTN optical interfaces.

Notes

a. SFP/XFP transceivers comply with IEC 60825 and 21 CFR 1040.10 (except for deviations pursuant to Laser Notice 50, dated July, 2001), for Class 1 or 1M lasers.

b. For OTU1e, OTU2e, OTU1f and OTU2f rates, the frequency offset generation is ±115 ppm.

c. In order not to exceed the maximum receiver power level before damage, an attenuator must be used.

d. External adaptors can be used for other types of connectors. For example FC/PC.

e. SFP/XFP compliance: The FTB-8120NGE/8130NGE selected SFP/XFP shall meet the requirements stated in the “Small

Form-Factor Pluggable (SFP) Transceiver Multisource Agreement (MSA)”. The FTB-8120NGE/8130NGE selected SFP/XFP
shall meet the requirements stated in the “Specification for Diagnostic Monitoring Interface for Optical Xcvrs”.

FTB-8120NGE/8130NGE Power Blazer

SONET AND DSN SDH AND PDH

Optical interfaces

OC-3, OC-12, OC-48, OC-192

Optical interfaces

STM-1, STM-4, STM-16, STM-64

Available wavelengths (nm) 1310, 1550 Available wavelengths (nm) 1310, 1550

Electrical interfaces

DS1, DS3, STS-1e, STS-3e

Electrical interfaces

a

1.5M (DS1), 2M (E1), 8M (E2), 34M (E3), 45M (DS3),

140M (E4), STM-0e, STM-1e
DS1 framing Unframed, SF, ESF 2M framing Unframed, PCM30, PCM31, PCM30 CRC-4, PCM31 CRC-4
DS3 framing Unframed, M13, C-bit parity 8M, 34M, 140M framing Unframed, framed
Clocking Internal, loop-timed, external (BITS), intermodule Clocking Internal, loop-timed, external (MTS/SETS), 2 MHz, intermodule

Mappings

b

Mappings

b

VT1.5 Bulk, DS1, GFP

c

TU-11-AU-3, TU-11-AU-4 Bulk, 1.5M, GFP

c

VT2 Bulk, E1, GFP

c

TU-12-AU-3, TU-12-AU-4 Bulk, 1.5M, 2M, GFP

c

VT6 Bulk, GFP

c

TU-3-AU-4 Bulk, 34M, 45M, GFP

c

STS-1 SPE Bulk, DS3, GFP

c

TU-2-AU-3, TU-2-AU-4 Bulk, GFP

c

STS-3c Bulk, E4, GFP

c

AU-4 Bulk, 140M, GFP

c

STS-12c/48c/192c, SPE Bulk, GFP

c

AU-4-4c/16c/64c Bulk, GFP

c

SONET overhead analysis
and manipulation

A1, A2, J0, E1, F1, D1-D12, K1, K2, S1, M0, E2, J1,
C2, G1, F2, H4, Z3, Z4, Z5, N1, N2, Z6, Z7

SDH overhead analysis
and manipulation

A1, A2, J0, E1, F1, D1-D12, K1, K2, S1, M0,

G1, F2, F3, K3, N1, N2, K4, E2, J1, C2, H4

Error insertion Error insertion

DS1 Framing bit, BPV, CRC-6, bit error E1 (2M) Bit error, FAS, CV, CRC-4, E-bit
DS3 BPV, C-bit, F-bit, P-bit, FEBE, bit error E2 (8M), E3 (34M), E4 (140M) Bit error, FAS, CV
STS-1e, STS-3e Section BIP (B1), line BIP (B2), path BIP (B3), BIP-2,

REI-L, REI-P, REI-V, BPV, FAS, bit error

STM-0e, STM-1e RS-BIP (B1), MS-BIP (B2), HP-BIP (B3), MS-REI,

HP-REI, LP-BIP-2, LP-REI, CV, FAS, bit error
OC-3, OC-12,

OC-48, OC-192

Section BIP (B1), line BIP (B2), path BIP (B3),
BIP-2, REI-L, REI-P, REI-V, FAS, bit error

STM-1, STM-4,
STM-16, STM-64

RS-BIP (B1), MS-BIP (B2), HP-BIP (B3), MS-REI,

HP-REI, LP-BIP-2, LP-REI, CV, FAS, bit error

Error measurement Error measurement

DS1 Framing bit, BPV, CRC-6, excess zeros, bit error E1 (2M) Bit error, FAS, CV, CRC-4, E-bit
DS3 BPV, C-bit, F-bit, P-bit, FEBE, bit error E2 (8M), E3 (34M), E4 (140M) Bit error, FAS, CV
STS-1e, STS-3e Section BIP (B1), line BIP (B2), path BIP (B3), BIP-2,

REI-L, REI-P, REI-V, BPV, FAS, bit error

STM-0e, STM-1e RS-BIP (B1), MS-BIP (B2), HP-BIP (B3), MS-REI,

HP-REI, LP-BIP-2, LP-REI, CV, FAS, bit error
OC-3, OC-12,

OC-48, OC-192

Section BIP (B1), line BIP (B2), path BIP (B3), BIP-2,
REI-L, REI-P, REI-V, FAS, bit error

STM-1, STM-4,
STM-16, STM-64

RS-BIP (B1), MS-BIP (B2), HP-BIP (B3), MS-REI,

HP-REI, LP-BIP-2, LP-REI, FAS, bit error

Alarm insertion Alarm insertion

DS1 LOS, RAI, AIS, OOF, pattern loss E1 (2M) LOS, LOS Mframe, LOS CRC Mframe, LOF, AIS,

TS16 AIS, RAI, RAI Mframe, pattern loss
DS3 LOS, RDI, AIS, OOF, DS3 idle, pattern loss E2 (8M), E3 (34M), E4 (140M) LOS, LOF, RAI, AIS, pattern loss

STS-1e, STS-3e, OC-3,
OC-12, OC-48, OC-192

LOS, LOF, SEF, AIS-L, RDI-L, AIS-P, LOP-P, LOM,
PDI-P, RDI-P, ERDI-PCD, ERDI-PPD, ERDI-PSD, UNEQ-P,
AIS-V, LOP-V, RDI-V, ERDI-VCD, ERDI-VPD, ERDI-VSD,
RFI-V, UNEQ-V, pattern loss

STM-0e, STM-1e, STM-1,
STM-4, STM-16, STM-64

LOS, LOF, OOF, MS-AIS, MS-RDI, AU-AIS, AU-LOP,

H4-LOM, HP-PDI, ERDI-PSD, ERDI-PCD, ERDI-PPD,

HP-UNEQ, TU-AIS, LP-RFI, LP-RDI, ERDI-VCD,

ERDI-VPD, ERDI-VSD, LP-RFI, LP-UNEQ, pattern loss

Alarm detection Alarm detection

DS1 LOS, loss of clock (LOC), RAI, AIS, OOF, pattern loss E1 (2M) LOS, LOS Mframe, LOS CRC Mframe, LOC, LOF, AIS,

TS16 AIS, RAI, RAI Mframe, pattern loss
DS3 LOS, LOC, RDI, AIS, OOF, DS3 idle, pattern loss E2 (8M), E3 (34M), E4 (140M) LOS, LOC, LOF, RAI, AIS, pattern loss
STS-1e, STS-3e, OC-3,

OC-12, OC-48, OC-192

LOS, LOC, LOF, SEF, TIM-S, AIS-L, RDI-L, AIS-P,
LOP-P, LOM, PDI-P, RDI-P, ERDI-PCD, ERDI-PPD, ERDI­PSD, PLM/SLM-P, UNEQ-P, TIM-P, AIS-V, LOP-V, RDI-V,
ERDI-VCD, ERDI-VCD, ERDI-VPD, ERDI-VSD, RFI-V,
UNEQ-V, TIM-V, PLM/SLM-V, pattern loss

STM-0e, STM-1e, STM-1,
STM-4, STM-16, STM-64

LOS, LOF, LOC, OOF, RS-TIM, MS-AIS, MS-RDI, AU-AIS,

AU-LOP, H4-LOM, HP-RDI, ERDI-PSD, ERDI-PCD,

ERDI-PPD, HP-PLM/SLM, HP-UNEQ, HP-TIM, TU-AIS,

LP-RFI, LP-RDI, ERDI-VPD, ERDI-VSD, LP-RFI, LP-UNEQ,

LP-TIM, LP-PLM/SLM, pattern loss

Frequency alarm on all supported interfaces.

Patterns Patterns

DS0 2E9-1, 2E11-1, 2E20-1, 1100, 1010, 1111, 0000,

1-in-8, 1-in-16, 3-in-24, 32 bit programmable
(inverted or non-inverted), bit errors

E0 (64K) 2E9-1, 2E11-1, 2E20-1, 1100, 1010, 1111, 0000,

1-in-8, 1-in-16, 3-in-24, 32 bit programmable

(inverted or non-inverted), bit errors
DS1

2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1, 1100, 1010,
1111, 0000, QRSS, 1-in-8, 1-in-16, 3-in-24, 32 bit programmable
(inverted or non-inverted), T1-DALY, 55-Octet, bit errors

E1 (2M) 2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1,

1100, 1010, 1111, 0000, 1-in-8, 1-in-16, 3-in-24,

32 bit programmable (inverted or non-inverted), bit errors
DS3 2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1, 1100,

1010, 1111, 0000, 1-in-8, 1-in-16, 3-in-24

d

, 32 bit

programmable (inverted or non-inverted), bit errors

E2 (8M), E3 (34M), E4 (140M) 2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1,

1100, 1010, 1111, 0000, 1-in-8, 1-in-16, 3-in-24 d,

32 bit programmable (inverted or non-inverted), bit errors
VT1.5/2/6 2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1,

1100, 1010, 1111, 0000, QRSS, 1-in-8, 1-in-16,
32 bit programmable (inverted or non-inverted), bit errors

TU-11/12/2/3 2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1, 1100,

1010, 1111, 0000, 1-in-8, 1-in-16, 32 bit programmable

(inverted or non-inverted), bit errors
STS-1, STS-3c/12c/48c/192c 2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1,

1100, 1010, 1111, 0000, 1-in-8, 1-in-16,
32 bit programmable (inverted or non-inverted), bit errors

AU-3/AU-4/AU-4-4c/16c/64c 2E9-1, 2E11-1, 2E15-1, 2E20-1, 2E23-1, 2E31-1,

1100, 1010, 1111, 0000, 1-in-8, 1-in-16,

32 bit programmable (inverted or non-inverted), bit errors

Pattern loss and bit-error generation and analysis supported on all patterns.

SONET/SDH FUNCTIONAL SPECIFICATIONS

Notes

a. 1.5M (DS1) and 45M (DS3) interfaces described under SONET and DSn column.
b. VCAT mappings are also available. Please refer to the VCAT section of this document for details.
c. GFP supported only with purchase of GFP-F option.
d. Not supported for E4 (140M).

FTB-8120NGE/8130NGE Power Blazer

NEXT-GENERATION SONET NEXT-GENERATION SDH

Generic framing procedure (GFP) Generic framing procedure (GFP)

Standards compliance As per ITU-T G.7041, and ANSI T1.105.02 Standards compliance As per ITU-T G.7041, G.707, and ANSI T1.105.02

Payload PRBS pattern; Ethernet Payload PRBS pattern; Ethernet

Ethernet add/drop Ability to add/drop Ethernet payload to/from GFP mapped

OC-n/OTU signal

Ethernet add/drop Ability to add/drop Ethernet payload to/from GFP mapped

STM-n/OTU signal

Error insertion Correctable core HEC, uncorrectable core HEC, correctable

type HEC, uncorrectable type HEC, correctable extension HEC,
uncorrectable extension HEC, payload FCS

Error insertion Correctable core HEC, uncorrectable core HEC, correctable

type HEC, uncorrectable type HEC, correctable extension HEC,
uncorrectable extension HEC, payload FCS

Error monitoring Correctable core HEC, uncorrectable core HEC, correctable

type HEC, uncorrectable type HEC, correctable extension HEC,
uncorrectable extension HEC, payload FCS

Error monitoring Correctable core HEC, uncorrectable core HEC, correctable

type HEC, uncorrectable type HEC, correctable extension HEC,
uncorrectable extension HEC, payload FCS

Alarm insertion

Loss of client signal (LOCS) and loss of client character
synchronization (LOCCS) with configurable time interval between
10 and 1200 ms, and loss of frame delineation (LFD)

Alarm insertion

Loss of client signal (LOCS) and loss of client character
synchronization (LOCCS) with configurable time interval
between 10 and 1200 ms, and loss of frame delineation (LFD),
client forward defect indication (FDI), client reverse defect
indication (RDI) and client defect clear indication (DCI)

Alarm monitoring

Loss of client signal (LOCS), loss of client character
synchronization (LOCCS) and loss of frame delineation (LFD)

Alarm monitoring

Loss of client signal (LOCS), loss of client character
synchronization (LOCCS) and loss of frame delineation (LFD),
client forward defect indication (FDI), client reverse defect
indication (RDI) and client defect clear indication (DCI)

Statistics Transmit: client data frames (including payload bytes),

client management frames, total frames, idle frames,
GFP bandwidth usage (%), GFP mapping efficiency (%)
Receive: client data frames (including payload bytes),
client management frames, total frames, idle (control) frames,
reserved (control) frames, invalid frames, discarded frames,
EXI mismatches, UPI mismatches, CID mismatches,
GFP bandwidth usage (%), GFP mapping efficiency (%)

Statistics Transmit: client data frames (including payload bytes),

client management frames, total frames, idle frames,
GFP bandwidth usage (%), GFP mapping efficiency (%)
Receive: client data frames (including payload bytes),
client management frames, total frames, idle (control) frames,
reserved (control) frames, invalid frames, discarded frames,
EXI mismatches, UPI mismatches, CID mismatches,
GFP bandwidth usage (%), GFP mapping efficiency (%)

Header manipulation PTI, PFI, EXI, UPI, CID and spare (extension header) fields Header manipulation PTI, PFI, EXI, UPI, CID and spare (extension header) fields

Header monitoring PLI, PTI, PFI, EXI, UPI, CID, spare (extension header) fields,

cHEC, tHEC, eHEC

Header monitoring PLI, PTI, PFI, EXI, UPI, CID, spare (extension header) fields,

cHEC, tHEC, eHEC

Virtual concatenation (VCAT) Virtual concatenation (VCAT)

Standards compliance Supports high-order and low-order virtual concatenation

as per ANSI T1.105

Standards compliance Supports high-order and low-order virtual concatenation

as per ITU G.707

Mappings High-order

STS-1-Xv (X = 1 to 21)
STS-3-Xv (X = 1 to 7)

Low-order
VT1.5-Xv (X = 1 to 64)
VT-2-Xv (X = 1 to 64)

Mappings High-order

VC-3-Xv (X = 1 to 21)
VC-4-Xv (X = 1 to 7)

Low-order
VC-11-Xv (X = 1 to 64)
VC-12-Xv (X = 1 to 64)
VC-3-Xv in AU-4 (X = 1 to 21)

Alarm insertion LOM, OOM1, OOM2, SQM

VCAT and Path alarms can be generated independently
on any member of a VCG

Alarm insertion LOM, OOM1, OOM2, SQM

VCAT and Path alarms can be generated independently
on any member of a VCG

Alarm monitoring LOM, OOM1, OOM2, SQM, LOA Alarm monitoring LOM, OOM1, OOM2, SQM, LOA

Differential delay Analysis

Range: 0 to 256 ms
Display: numerical and graphical

Insertion
Range: 0 to 256 ms

Differential delay Analysis

Range: 0 to 256 ms
Display: numerical and graphical

Insertion
Range: 0 to 256 ms

Sequence number
manipulation and
processing

Sequence range: 0 to 63
Sequence number monitoring: current AcSQ
(accepted SQ) monitored against the ExSQ (expected SQ);
SQM alarm raised on mismatch

Sequence number
manipulation and
processing

Sequence range: 0 to 63
Sequence number monitoring: current AcSQ
(accepted SQ) monitored against the ExSQ (expected SQ);
SQM alarm raised on mismatch

SONET/SDH FUNCTIONAL SPECIFICATIONS (CONT’D)

NEXT-GENERATION SONET/SDH (CONT’D)

Link capacity adjustment scheme (LCAS)

Standards compliance As per ITU G.7042; supported for both low-order and high-order VCAT groups
Test functions

› Emulation of source and sink state machines
› Automatic and manual control of source and sink state machines
› Independent overwrite capability at the source and sink for each member
› Automatic SQ management

Source state machine control

› Add/remove member(s)
› Configure: RS-ACK timeout, remote DUT, PLCT threshold
› Statistics count: received RS-ACK, unexpected RS-ACK
› Error/alarm generation: CRC errors, group ID (GID) mismatch
›

Error/alarm monitoring: loss of partial transport capacity, loss of total transport capacity, failure of protocol transmission, CRC errors, unexpected member status

Sink state machine control

› Add/remove member(s)
› Configure Hold-Off and Wait-to-Restore timers, PLCR threshold
› Toggle RS-ACK
› Statistics count: transmitted RS-ACK
› Error/alarm generation: CRC errors, group ID (GID) mismatch
›

Error/alarm monitoring: loss of partial transport capacity, loss of total transport capacity, failure of protocol reception, CRC errors, unexpected member status

ADDITIONAL TEST AND MEASUREMENT FUNCTIONS

Power measurements Supports power measurements, displayed in dBm (dBdsx for DS1), for optical and electrical interfaces.

Frequency measurements Supports clock frequency measurements (i.e., received frequency and deviation of the input signal clock from nominal frequency),

displayed in ppm and Gbit/s, for optical and electrical interfaces.

Frequency offset generation Supports offsetting the clock of the transmitted signal on a selected interface to exercise clock recovery circuitry on network elements.

Dual DSn receivers Supports two DS1 or DS3 receivers, allowing users to simultaneously monitor two directions of a circuit under test in parallel, resulting in quick isolation of

the source of errors.

Performance monitoring The following ITU-T recommendations, and corresponding performance monitoring parameters, are supported on the FTB-8120NGE/8130NGE.

ITU-T recommendation

G.821
G.826
G.828
G.829
M.2100
M.2101

Performance monitoring statistics

ES, EFS, EC, SES, UAS, ESR, SESR, DM
ES, EFS, EB, SES, BBE, UAS, ERS, SESR, BBER
ES, EFS, EB, SES, BBE, SEP, UAS, ESR, SESR, BBER, SEPI
ES, EFS, EB, SES, BBE, UAS, ESR, SESR, BBER
ES, SES, UAS, ESR, SESR
ES, SES, BBE, UAS, ESR, SESR, BBER

Pointer adjustment and analysis Generation and analysis of HO/AU and LO/TU pointer adjustments as per GR-253, and ITU-T G.707

Generation

› Pointer increment and decrement
› Pointer jump with or without NDF
› Pointer value

Analysis

› Pointer increments
› Pointer decrements
› Pointer jumps (NDF, no NDF)

› Pointer value and cumulative offset
Programmable error/alarm injection Ability to inject errors/alarms in the following modes: Manual, Constant Rate, Burst, Periodic Burst and Continuous.

Service disruption time
(SDT) measurements

The service disruption time test tool measures the time during which there is a
disruption of service due to the network switching from the active channels to the backup channels.
User-selectable triggers: all supported alarms and errors.
Measurements: last disruption, shortest disruption, longest disruption, average disruption, total disruption, and service disruption count.

Round-trip delay (RTD)
measurements

The round-trip delay test tool measures the time required for a bit to travel from the FTB-8120NGE/8130NGE transmitter back to its receiver after crossing
a far-end loopback. Measurements are supported on all supported FTB-8120NGE/8130NGE interfaces and mappings.
Measurements: last RTD time, minimum, maximum, average, measurement count (no. of successful RTD tests), failed measurement count.

APS message control and monitoring

Ability to monitor and set up automatic protection switching messages (K1/K2 byte of SONET/SDH overhead).

Synchronization status Ability to monitor and set up synchronization status messages (S1 byte of SONET/SDH overhead).

Signal label control and monitoring Ability to monitor and set up payload signal labels (C2, V5 byte of SONET overhead).

Through mode Ability to perform Through mode analysis of any incoming electrical (DSn, PDH) and optical line (OC-3/STM-1, OC-12/STM-4, OC-48/STM-16,

OC-192/STM-64, OTU1, OTU2, OTU1e and OTU2e) either transparently or intrusively.

M13 mux/demux Ability to multiplex/demultiplex a DS1 signal into/from a DS3 signal. (Note: E1 to DS3 mux/demux available with G.747 software option.)

DS1 FDL Support for DS1 Facility Data Link testing.

DS1 loopcodes Support for generation of DS1 in-band loopcodes with the availability of up to 10 pairs of user-defined loopcodes.

NI/CSU loopback emulation Ability to respond to DS1 in-band/out-of-band loopcodes.

DS3 FEAC Support for DS3 for-end alarms and loopback codewords.

DS1/DS3 auto detection Ability to automatically detect DS1/DS3 line coding, framing and test pattern.

Tandem connection
monitoring (TCM)

a

Tandem connection monitoring (TCM), Option 2 b, is used to monitor the performance of a subsection of a SONET/SDH path routed via different network providers.
The FTB-8120NGE/8130NGE supports transmitting and receiving alarms and errors on a TCM link; also, transmission and monitoring of the tandem
connection (TC) trace can be generated to verify the connection between TCM equipment.
Error generation: TC-IEC, TC-BIP, TC-REI, OEI
Error analysis: TC-IEC, TC-REI, OEI, TC-VIOL
Alarm generation: TC-RDI, TC-UNEQ, ODI, TC-LTC, TC-IAIS
Alarm analysis: TC-TIM, TC-RDI, TC-UNEQ, ODI, TC-LTC, TC-IAIS

Payload block and replace Ability to terminate and analyze a specific high-order path element and replace it with a PRBS pattern on the TX side.

K1/K2 OH byte capture Ability to capture K1/K2 OH byte value transitions.

SONET/SDH FUNCTIONAL SPECIFICATIONS (CONT’D)

FTB-8120NGE/8130NGE Power Blazer

Notes

a. HOP and LOP supported.

b. G.707 option 2.

ADDITIONAL FEATURES

Scripting

The built-in scripting engine and embedded macro-recorder provide a simple means of automating test cases and routines.
Embedded scripting routines provide a powerful means of creating advanced test scripts. Available only on the FTB-500 platform.

Reports Supports generation of test reports in .html, .csv, .txt, .pdf formats. Contents of reports are customizable by the user.

Power-up and restore In the event of a power failure to the unit, the active test configuration and test logger are saved and restored upon bootup.

Store and load configurations Ability to store and load test configurations to/from non-volatile memory.

Alarm hierarchy

Alarms are displayed according to a hierarchy based on root cause. Secondary effects are not displayed.
This hierarchy serves to facilitate alarm analysis.

Configurable test views

This allows users to customize their test views; i.e., to dynamically insert or remove test tabs/windows, in addition to creating new test
windows, so as to accurately match their testing needs. Available only on the FTB-500 user interface.

Configurable test timer Provides the ability for a user to set predefined test start and stop times.

Remote control

Available with Windows-based remote management software known as Visual Guardian Lite (optional software package).
This allows users to remotely monitor and control the FTB-8120NGE/8130NGE modules via standard Ethernet connection.

OTN FUNCTIONAL SPECIFICATIONS

OTN

Standards compliance ITU-T G.709, ITU G.798, ITU G.872
Interfaces OTU1 (2.7 Gbit/s), OTU2 (10.7 Gbit/s), OTU1e (11.0491 Gbit/s), OTU2e (11.0957 Gbit/s),

OTU1f (11.2701 Gbit/s), OTU2f (11.3176 Gbit/s)

Client types

a

All supported SONET/SDH mappings (including next-generation GFP, VCAT, LCAS), NULL, PRBS (2E31-1),
ODU1 into OTU2 multiplexing.

OTU Layer

Errors OTU-FAS, OTU-MFAS, OTU-BEI, OTU-BIP-8
Alarms LOF, OOF, LOM, OOM, OTU-AIS, OTU-TIM, OTU-BDI, OTU-IAE, OTU-BIAE
Traces 64-bytes Trail Trace Identifier (TTI) as defined in ITU-T G.709

ODU TCM Layer

Errors TCMi-BIP-8, TCMi-BEI (i = 1 to 6)
Alarms TCMi-LTC, TCMi-TIM, TCMi-BDI, TCMi-IAE, TCMi-BIAE
Traces 64-bytes Trail Trace Identifier (TTI) as defined in ITU-T G.709

ODU Layer

Errors ODU-BIP-8, ODU-BEI
Alarms ODU-AIS, ODU-OCI, ODU-LCK, ODU-TIM, ODU-BDI, ODU-FSF, ODU-BSF, ODU-FSD, ODU-BSD
Traces Generates 64-bytes Trail Trace Identifier (TTI) as defined in ITU-T G.709
FTFL

b

As defined in ITU-T G.709

ODU0

Muxing ODU0 into ODU1, ODU0 into ODU2
Client types Pattern, OC-3/STM-1, OC-12/STM-4, GigE using GFP-T
GFP-T errors SB Correctable, SB Uncorrectable, 10B_ERR

ODU Multiplexing

c

Alarms OPU-MSIM, ODU-LOFLOM

ODUflex

Muxing ODUflex into ODU2
Client types Ethernet using GFP-F or pattern for constant bit rate (CBR)

OPU Layer

Alarm OPU-PLM
Payload type (PT) label Generates and displays received PT value

Forward Error Correction (FEC)

Errors FEC-Correctable (Codeword), FEC-Uncorrectable (Codeword), FEC-Correctable (Symbol),

FEC-Correctable (Bit), and FEC-Stress (Codeword)

Ethernet over OTN (EoOTN)

c

Mapping Direct mapping into OTU1e or OTU2e or using GFP-F into OTU2
BERT Framed layer 2 supported with or without VLAN
Pattern PRBS 2E9-1, PRBS 2E11-1, PRBS 2E15-1, PRBS 2E20-1, PRBS 2E23-1, PRBS 2E31-1

and up to 10 user patterns. Capability to invert patterns
Error insertion FCS, 64B/66B block, bit
Error measurement Jabber/giant, runt, undersize, oversize, FCS, 64B/66B block
Error measurement (BERT) Bit error, bit mismatch 0, bit mismatch 1
Alarm insertion Link down, local fault, remote fault, pattern loss
Alarm detection Link down, local fault, remote fault, pattern loss
VLAN Capability to generate one stream with one layer of VLAN
Ethernet statistics Multicast, broadcast, unicast, N-unicast, frame size distribution, bandwidth, utilization, frame rate

ADDITIONAL FUNCTION

Service disruption time (SDT)
measurements

The service disruption time test tool measures the time during which there is a disruption of service due to the network switching
from the active channels to the backup channels. User-selectable triggers: all supported alarms and errors.
Measurements: last disruption, shortest disruption, longest disruption, average disruption, total disruption, and service disruption count.

Round-trip delay (RTD)
measurements

The round-trip delay test tool measures the time required for a bit to travel from the FTB-8120NGE/8130NGE transmitter back to its
receiver after crossing a far-end loopback. Measurements are supported on all supported FTB-8120NGE/8130NGE interfaces and
mappings.

Measurements: last RTD time, minimum, maximum, average, measurement count (no. of successful RTD tests), failed measurement count.

Multichannel testing Ability to monitor in real-time errors and alarms, and to perform simultaneous SDT measurements for all ODU0 channels;

a user-defined threshold can also be applied to the SDT measurements for simple pass/fail results for each channel.

SONET/SDH FUNCTIONAL SPECIFICATIONS (CONT’D)

OTN FUNCTIONAL SPECIFICATIONS

FTB-8120NGE/8130NGE Power Blazer

Notes

a. Available with ODUMUX option.
b. Fault type and fault location.
c. Available on the FTB-8130NGE only.

ELECTRICAL INTERFACES

10Base-T 100Base-T 1000Base-T

Tx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s

Tx uncertainty (accuracy) (ppm) ±100 ±100 ±100

Rx bit rate 10 Mbit/s 125 Mbit/s 1 Gbit/s

Rx measurement uncertainty (accuracy)
(ppm)

±4.6 ±4.6 ±4.6

Duplex mode Half and full duplex Half and full duplex Full duplex

Jitter compliance IEEE 802.3 IEEE 802.3 IEEE 802.3

Connector RJ-45 RJ-45 RJ-45

Maximum reach (m) 100 100 100

100 MBIT/S AND GIGE OPTICAL INTERFACES

100Base-FX 100Base-LX 1000Base-SX 1000Base-LX 1000Base-ZX

Wavelength (nm) 1310 1310 850 1310 1550

Tx level (dBm) —20 to —15 —15 to —8 —9 to —3 —9.5 to —3 0 to 5

Rx level sensitivity (dBm) —31 —28 —20 —22 —22

Maximum reach 2 km 15 km 550 m 10 km 80 km

Transmission bit rate (Gbit/s) 0.125 0.125 1.25 1.25 1.25

Reception bit rate (Gbit/s) 0.125 0.125 1.25 1.25 1.25

Tx operational wavelength range (nm) 1280 to 1380 1261 to 1360 830 to 860 1270 to 1360 1540 to 1570

Measurement uncertainty (accuracy)
Frequency (ppm)
Optical power (dB)

±4.6
±2

±4.6
±2

±4.6
±2

±4.6
±2

±4.6
±2

Maximum Rx before damage (dBm) 3 3 6 6 6

Jitter compliance ANSI X3.166 IEEE 802.3 IEEE 802.3 IEEE 802.3 IEEE 802.3

Ethernet classification ANSI X3.166 IEEE 802.3 IEEE 802.3 IEEE 802.3 IEEE 802.3

Laser type LED FP VCSEL FP DFB

Eye safety Class 1 Class 1 Class 1 Class 1 Class 1

Connector LC LC LC LC LC

Transceiver type SFP SFP SFP SFP SFP

ETHERNET INTERFACES

10 GIGE OPTICAL INTERFACES

10GBASE-SW 10GBASE-SR 10GBASE-LW 10GBASE-LR 10GBASE-EW 10GBASE-ER

Wavelength (nm) 850 Multimode 850 Multimode 1310 Singlemode 1310 Singlemode 1550 Singlemode 1550 Singlemode

Tx level (802.3ae-compliant) (dBm) –7.3 to –1 –7.3 to –1 –8.2 to 0.5 –8.2 to 0.5 –4.7 to 4.0 –4.7 to 4.0

Rx operating range (dBm) –9.9 to –1.0 –9.9 to –1.0 –14.4 to 0.5 –14.4 to 0.5 –15.8 to –1.0 –15.8 to –1.0

Transmission bit rate 9.95328 Gbit/s

± 4.6 ppm

a

10.3125 Gbit/s
± 4.6 ppm

a

9.95328 Gbit/s
± 4.6 ppm

a

10.3125 Gbit/s
± 4.6 ppm

a

9.95328 Gbit/s
± 4.6 ppm

a

10.3125 Gbit/s
± 4.6 ppm

a

Reception bit rate 9.95328 Gbit/s

± 135 ppm

10.3125 Gbit/s
± 135 ppm

9.95328 Gbit/s
± 135 ppm

10.3125 Gbit/s
± 135 ppm

9.95328 Gbit/s
± 135 ppm

10.3125 Gbit/s
± 135 ppm

Tx operational wavelength range
(802.3ae-compliant) (nm)

840 to 860 840 to 860 1260 to 1355 1260 to 1355 1530 to 1565 1530 to 1565

Measurement uncertainty (accuracy)
Frequency (ppm)
Optical power (dB)

±4.6
±2

±4.6
±2

±4.6
±2

±4.6
±2

±4.6
±2

±4.6
±2

Maximum Rx before damage (dBm) 0 0 1.5 1.5 4.0 4.0

Jitter compliance IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae

Ethernet classification IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae

Laser type VCSEL VCSEL DFB DFB EML EML

Eye safety Class 1 laser; complies

with 21 CFR 1040.10
and IEC 60825-1

Class 1 laser; complies
with 21 CFR 1040.10
and IEC 60825-1

Class 1 laser; complies
with 21 CFR 1040.10
and IEC 60825-1

Class 1 laser; complies
with 21 CFR 1040.10
and IEC 60825-1

Class 1 laser; complies
with 21 CFR 1040.10
and IEC 60825-1

Class 1 laser; complies
with 21 CFR 1040.10
and IEC 60825-1

Connector Duplex LC Duplex LC Duplex LC Duplex LC Duplex LC Duplex LC

Transceiver type
(compliant with XFP MSA)

XFP XFP XFP XFP XFP XFP

FTB-8120NGE/8130NGE Power Blazer

Note

a. When clocking is in internal mode.

TESTING (10 MBIT/S TO GIGE)

EtherSAM (Y.1564) Capability to perform the service configuration test, including the ramp and burst tests and service performance test as per ITU-T Y.1564.

Tests can be performed to a loopback or dual test set mode for bidirectional results.

RFC 2544 Throughput, back-to-back, frame loss and latency measurements according to RFC 2544. Frame size: RFC-defined sizes, user-configurable.

BERT Unframed, framed layer 1, framed layer 2 supported with or without VLAN Q-in-Q.

Patterns (BERT) PRBS 2E9-1, PRBS 2E11-1, PRBS 2E15-1, PRBS 2E20-1, PRBS 2E23-1, PRBS 2E31-1, CRPAT, CSPAT, CJTPAT, Short CRTPAT, Long CRTPAT and up to

10 user patterns. Capability to invert patterns.

Error insertion (BERT) FCS, bit and symbol.

Error measurement Jabber/giant, runt, undersize, oversize, FCS, symbol, idle, carrier sense, alignment, collision, late collision, excessive collision, UDP and IP header checksum.

Error measurement (BERT) Bit error, symbol error, idle error, bit mismatch 0, bit mismatch 1, performance monitoring (G.821 and G.826).

Alarm insertion (BERT) LOS, pattern loss.

Alarm detection LOS, link down, pattern loss, no traffic.

Service disruption time (SDT)
measurement (BERT)

Defect or No Traffic mode. Disruption time statistics include shortest, longest, last, average, total and count.

VLAN stacking Capability to generate one stream with up to three layers of VLAN (including IEEE 802.1ad Q-in-Q tagged VLAN).

Flow-control statistics Pause time, last pause time, max. pause time, min. pause time, paused frames, abort frames, frames Tx, frames Rx.

Advanced autonegotiation Capability to autonegotiate the rate, duplex and flow-control capabilities with another Ethernet port.

Configurable autonegotiate parameters.
Display of link partner capabilities.
Fault injection: offline, link failure, autonegotiation error.

Multistream generation Capability to transmit up to 10 streams. Configuration parameters are packet size, transmission mode (N-Frames, Burst, N-Burst, Ramp, N-Ramp and Continuous),

MAC source/destination address, VLAN ID, VLAN priority, IP source/destination address, ToS field, DSCP field, TTL, UDP source/destination port and payload.
(Available with Frame-Analyzer software option.) Selectable predefined stream profiles are also available for VoIP, video and data streams. VoIP codecs
(G.711, G.723.1, G.729), video (MPEG-2 SDTV, MPEG-2 HDTV, MPEG-4 HDTV).

Traffic filtering Capability to analyze the incoming traffic and provide statistics according to a set of up to 10 configurable filters. Filters can be configured for MAC source/

destination address, VLAN ID, VLAN priority, IP source/destination address, ToS field, DSCP field, TCP source/destination port and UDP source/destination port.
VLAN filtering can be applied to any of the stacked VLAN layers. (Available with Frame-Analyzer software option.)

Multistream analysis Capability to analyze per stream statistics: packet jitter, latency, throughput, frame loss and out-of-sequence (available with Frame-Analyzer software option).

Ethernet statistics Multicast, broadcast, unicast, N-unicast, pause frame, frame size distribution, bandwidth, utilization, frame rate, frame loss, out-of-sequence frames and

in-sequence frames. (Available with Frame-Analyzer software option.)

Packet jitter statistics Delay variation statistics (ms)—min., max., last, average and jitter measurement estimate (RFC 3393) (available with Frame Analyzer option).

PBB-TE

a

Capability to generate and analyze streams with PBB-TE data traffic including configuration of B-MAC (source and destination), B-VLAN and I-tag (as per 802.1ah)
and to filter received traffic by any of these fields.

MPLS

a

Capability to generate and analyze streams with up to two layers of MPLS labels and to filter received traffic by MPLS label or COS.

IPv6

a

Capability to perform BERT, RFC 2544, traffic generation and analysis and Smart Loopback tests over IPv6; ping, traceroute, neighbor discovery and
stateless auto-configuration.

Advanced filtering

a

Capability to enhance the filters with up to four (4) fields each, which can be combined with AND/OR/NOT operations.
A mask is also provided for each field value to allow for wildcards. Complete statistics are gathered for each defined filter.

Data capture

a

Capability to perform 10/100/1000M full-line-rate data capture and decode. Capability to configure detailed capture filters and triggers as well as capture slicing parameters.

Traffic scan

a

Capability to scan incoming live traffic and auto-discover all VLAN/VLAN Priority and MPLS ID/COS flows; capability to provide statistics for each flow including
frame count and bandwidth.

ETHERNET FUNCTIONAL SPECIFICATIONS

ADDITIONAL TEST AND MEASUREMENT FUNCTIONS (10 MBIT/S TO GIGE)

Power measurement Supports optical power measurement, displayed in dBm.

Frequency measurement Supports clock frequency measurements (i.e., received frequency and deviation of the input signal clock from nominal frequency).

Frequency offset
measurement

Range: ±120 ppm
Resolution: 1 ppm
Uncertainty (accuracy): ±4.6 ppm

Dual test set Performs end-to-end, bidirectional performance testing (as required by leading standards bodies)—remote FTB-8120NGE/8130NGE controlled via the LAN

connection under test.
DHCP client Capability to connect to a DHCP server to obtain its IP address and subnet mask for connecting on to the network.

Smart Loopback Capability to return traffic to the local unit by swapping packet overhead up to layer 4 of the OSI stack.

IP tools Capability to perform ping and traceroute functions.

TCP throughput
measurements

a

Capability to evaluate TCP throughput and provide performance results and statistics: window size with corresponding throughput, number of transmitted and

retransmitted segments, round-trip time.

FTB-8120NGE/8130NGE Power Blazer

Note

a. Available as a software option.

TESTING (10 GIGE)

EtherSAM (Y.1564) Capability to perform the service configuration test, including the ramp and burst tests and service performance test as per ITU-T Y.1564.

Tests can be performed to a loopback or dual test set mode for bidirectional results.

RFC 2544 Throughput, back-to-back, frame loss and latency measurements according to RFC 2544.

Frame size: RFC-defined sizes, user-configurable.

BERT Unframed, framed layer 1, framed layer 2 supported with or without VLAN Q-in-Q.

Patterns (BERT) PRBS 2E9-1, PRBS 2E11-1, PRBS 2E15-1, PRBS 2E20-1, PRBS 2E23-1, PRBS 2E31-1, and up to 10 user patterns.

Error insertion (BERT) FCS, bit, 64B/66B Block

Error measurement LAN/WAN: jabber/giant, runt, undersize, oversize, FCS, 64B/66B Block

WAN: B1, B2, B3, REI-L, REI-P
UDP, TCP and IP header checksum

Error measurement (BERT) Bit error, bit mismatch 0, bit mismatch 1, performance monitoring (G.821 and G.826)

Alarm insertion LOS, link down, local fault, remote fault, pattern loss (BERT)

WAN: SEF, LOF, AIS-L, RDI-L, AIS-P, RDI-P, LCD-P, LOP-P, ERDI-PSD, ERDI-PCD, ERDI-PPD, UNEQ-P

Alarm detection LOS, link down, local fault, remote fault, frequency offset, pattern loss (BERT)

WAN: SEF, LOF, AIS-L, RDI-L, AIS-P, RDI-P, LCD-P, LOP-P, ERDI-PSD, ERDI-PCD, ERDI-PPD, PLM-P, UNEQ-P, link (WIS)

Service disruption time (SDT)
measurement (BERT)

Defect or No Traffic mode. Disruption time statistics include shortest, longest, last, average, total and count.

VLAN stacking Capability to generate one stream with up to three layers of VLAN (including IEEE802.1ad Q-in-Q tagged VLAN).

Flow-control statistics Pause time, last pause time, max. pause time, min. pause time, paused frames, abort frames, frames Tx, frames Rx.

Multistream generation Capability to transmit up to 10 streams. Configuration parameters are packet size, transmission mode (N-Frames, Burst, N-Burst, Ramp, N-Ramp and Continuous),

MAC source/destination address, VLAN ID, VLAN priority, IP source/destination address, ToS field, DSCP field, TTL, UDP source/destination port and payload.
(Available with Frame-Analyzer software option.) Selectable predefined stream profiles are also available for VoIP, video and data streams.
VoIP codecs (G.711, G.723.1, G.729), video (MPEG-2 SDTV, MPEG-2 HDTV, MPEG-4 HDTV).

Traffic filtering Capability to analyze the incoming traffic and provide statistics according to a set of up to 10 configurable filters. Filters can be configured for MAC source/

destination address, VLAN ID, VLAN priority, IP source/destination address, ToS field, DSCP field, TCP source/destination port and UDP source/destination port.
VLAN filtering can be applied to any of the stacked VLAN layers. (Available with Frame-Analyzer software option.)

Multistream analysis Capability to analyze per stream statistics: packet jitter, latency, throughput, frame loss and out-of-sequence (available with Frame-Analyzer software option)

Ethernet statistics Multicast, broadcast, unicast, N-unicast, pause frame, frame size distribution, bandwidth, utilization, frame rate, frame loss, out-of-sequence frames

and in-sequence frames. (Available with Frame-Analyzer software option.)

Packet jitter statistics Delay variation statistics (ms)—min., max., last, average and jitter measurement estimate (RFC 3393) (available with Frame-Analyzer option).

PBB-TE

a

Capability to generate and analyze streams with PBB-TE data traffic including configuration of B-MAC (source and destination), B-VLAN and I-tag
(as per 802.1ah) and to filter received traffic by any of these fields.

MPLS

a

Capability to generate and analyze streams with up to two layers of MPLS labels and to filter received traffic by MPLS label or COS.

IPv6

a

Capability to perform BERT, RFC 2544, traffic generation and analysis and Smart Loopback tests over IPv6; ping, traceroute, neighbor discovery and stateless
auto-configuration.

Advanced filtering

a

Capability to enhance the filters with up to four (4) fields each, which can be combined with AND/OR/NOT operations.
A mask is also provided for each field value to allow for wildcards. Complete statistics are gathered for each defined filter.

Data capture

a

Capability to perform 10/100/1000M full-line-rate data capture and decode.
Capability to configure detailed capture filters and triggers as well as capture slicing parameters.

One-way delay Capability to measure one-way frame delay as part of EtherSAM (Y.1564) and RFC 2544

ADDITIONAL TEST AND MESUREMENT FUNCTIONS (10 GIGE)

Power measurement Supports optical power measurement, displayed in dBm.

Frequency generation
and measurement

Supports clock frequency generation and measurements (i.e., received frequency and deviation of the input signal clock from nominal frequency).
Frequency offset generation:
Range: ±50 ppm
Resolution: ±1 ppm
Uncertainty (accuracy): ±4.6 ppm

Frequency offset measurement:
Range: ±135 ppm
Resolution: ±1 ppm
Uncertainty (accuracy): ±4.6 ppm

Signal label control
and monitoring

Ability to configure and monitor J0 Trace, J1 Trace and payload signal label C2 (WAN).

Dual test set

Performs end-to-end, bidirectional performance testing (as required by leading standards bodies)—remote FTB-8120NGE/8130NGE controlled via the LAN
connection under test.

DHCP client Capability to connect to a DHCP server to obtain its IP address and subnet mask to connect to the network.

Smart Loopback Capability to return traffic to the local unit by swapping packet overhead up to layer 4 of the OSI stack.

IP tools Capability to perform ping and traceroute functions.

ETHERNET FUNCTIONAL SPECIFICATIONS (CONT’D)

FTB-8120NGE/8130NGE Power Blazer

Note

a. Available as a software option.

ADDITIONAL FEATURES

Expert mode Ability to set thresholds in RFC 2544 and BERT mode to provide a pass/fail status.

Scripting

The built-in Visual Basic .NET scripting engine and embedded macrorecorder provide a simple means of automating test cases and routines.
Embedded scripting routines provide a powerful means of creating advanced test scripts.

a

Event logger Supports logging of test results, and the ability to print, export (to a file), or export the information contained in the logging tool.

Power up and restore

a

In the event of a power failure to the unit, the active test configuration and results are saved and restored upon bootup.

Save and load configuration Ability to store and load test configurations to/from non-volatile memory.

Configurable test views

Allows users to customize their test views; i.e., to dynamically insert or remove test tabs/windows, in addition to creating new test windows,
so as to accurately match their testing needs.

a

Configurable test timer Allows a user to set a specific start, stop and duration for tests.

Test favorites Capability to select and load from predefined or user-modified test conditions.

Report generation Ability to generate test reports in the following user-selectable formats: .pdf, .html, .txt and .csv.

Graph Allows to graphically display the test statistics of the performance (RFC 2544).

Screen capturing

b

Capability to gather a snap-shot of the screen for future use.

Logger printing

b

Capability to send logger messages to a supported local printer.

Remote control Remote control through Visual Guardian Lite software or VNC.

FC-1X/2X/4X

Wavelength (nm) 850 1310 1310 1550

Tx level (dBm) –9 to –2.5 –8.4 to –3 0 to 5 1 to 5

Rx level sensitivity (dBm) –15 at FC-4

–18 at FC-2
–20 at FC-1

–18 at FC-4
–21 at FC-2
–22 at FC-1

–18 at FC-4
–21 at FC-2
–22 at FC-1

–16.5 at FC-4
–20.5 at FC-2
–22 at FC-1

Maximum reach 500 m on 50/125 µm MMF

c

300 m on 62.5/125 µm MMF

c

4 km 30 km 40 km

Transmission bit rate (Gbit/s) 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25

Reception bit rate (Gbit/s) 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25

Tx operational wavelength range (nm) 830 to 860 1260 to 1350 1285 to 1345 1544.5 to 1557.5

Measurement uncertainty (accuracy)
Frequency (ppm)
Optical power (dB)

±4.6
±2

±4.6
±2

±4.6
±2

±4.6

±2
Max Rx before damage (dBm) 3 3 3 3

Jitter compliance ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2

FC classification ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2

Laser type VCSEL Fabry-Perot DFB DFB

Eye safety Class 1 Class 1 Class 1 Class 1

Connector LC LC LC LC

Transceiver type SFP SFP SFP SFP

FC-10X

Wavelength (nm) 850 1310 1310 1550 1550

Tx level (dBm) –5 to –1 0.5 max –6 to –1 –1 to 2 0 to 4

Rx level sensitivity (dBm) –11.1 –12.6 –14.4 –16 –23

Maximum reach 300 m on 50/125 µm MMF

30 m on 62.5/125 µm MMF

10 km 10 km 40 km 80 km

Transmission bit rate (Gbit/s) 10.5 10.5 10.5 10.5 10.5

Reception bit rate (Gbit/s) 10.5 10.5 10.5 10.5 10.5

Tx operational wavelength range (nm) 840 to 860 1260 to 1355 1290 to 1330 1530 to 1565 1530 to 1565

Measurement uncertainty (accuracy)
Frequency (ppm)
Optical power (dB)

±4.6
±2

±4.6
±2

±4.6
±2

±4.6
±2

±4.6
±2

Max Rx before damage (dBm) 6 6 6 2 4

Jitter compliance ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3

FC classification ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3 ANSI FC-PI-3

Laser type VCSEL DFB DFB EML EML

Eye safety Class 1 Class 1 Class 1 Class 1 Class 1

Connector LC LC LC LC LC

Transceiver type XFP XFP XFP XFP XFP

ETHERNET FUNCTIONAL SPECIFICATIONS (CONT’D)

FIBRE CHANNEL INTERFACES

FTB-8120NGE/8130NGE Power Blazer

Notes

a. Available on the FTB-500 platform only.

b. Available on the FTB-200 platform only.

c. Values in the table correspond to FC-1 rate. For FC-2, maximum reach is 300 m on 50/125 µm MMF and 150 m on

62.5/125 µm MMF. For FC-4, maximum reach is 150 m on 50/125 µm MMF and 70 m on 62.5/125 µm MMF.

FTB-8120NGE

a

FTB-8130NGE

a

Next-generation SONET/SDH 2.5 Gbit/s and OTN 2.7 Gbit/s Next-generation SONET/SDH 10 Gbit/s and OTN 10.7 Gbit/s

Supports up to 2.5/2.7 Gbit/s optical rates, as well as electrical DSn/PDH interfaces Supports up to 10/10.7 Gbit/s optical rates, as well as electrical DSn/PDH interfaces

Test Interfaces

OTN: OTU1 (2.7 Gbit/s) OTN: OTU1 (2.7 Gbit/s), OTU2 (10.7 Gbit/s)

OTU1e (11.0491 Gbit/s), OTU2e (11.0957 Gbit/s)
OTU1f (11.2701 Gbit/s), OTU2f (11.3176 Gbit/s)

SONET: STS-1e, STS-3e, OC-3, OC-12, OC-48 SONET: STS-1e, STS-3e, OC-3, OC-12, OC-48, OC-192

SDH: STM-0e, STM-1e, STM-0, STM-4, STM-16 SDH: STM-0e, STM-1e, STM-0, STM-4, STM-16, STM-64

DSn: DS1, DS3, Dual DS1 Rx, Dual DS3 Rx DSn: DS1, DS3, Dual DS1 Rx, Dual DS3 Rx

PDH: E1, E2, E3, E4 PDH: E1, E2, E3, E4

Ethernet: 10/100/1000M electrical and 100/1000M optical Ethernet: 10/100/1000M electrical, 100/1000M optical and 10 GigE LAN/WAN

FC: 1x, 2x, 4x FC: 1x, 2x, 4x, 10x

GENERAL SPECIFICATIONS

FTB-8120NGE FTB-8130NGE

Weight (without transceiver) 0.9 kg (2.0 lb) 0.9 kg (2.0 lb)

Size (H x W x D) 96 mm x 51 mm x 288 mm (3

3

/8 in x 2 in x 11 3/8 in) 96 mm x 51 mm x 288 mm (3 3/8 in x 2 in x 11 3/8 in)

Temperature
operating
storage

0 °C to 40 °C (32 °F to 104 °F)
–40 °C to 60 °C (–40 °F to 140 °F)

0 °C to 40 °C (32 °F to 104 °F)
–40 °C to 60 °C (–40 °F to 140 °F)

FIBRE CHANNEL FUNCTIONAL SPECIFICATIONS

TESTING (1X, 2X, 4X AND 10X)

BERT Unframed, framed FC-1, framed, FC-2

Patterns (BERT) PRBS 2E31-1, 2E23-1, 2E20-1, 2E15-1, 2E11-1, 2E9-1 CSPAT, CRPAT, CJTPAT, and 10 user-defined 32 bits patterns

Error insertion Bit error, symbol error, oversize error, CRC error, undersize error and block error

Error measurement Bit error, symbol error, oversize error, CRC error, undersize error and block error

Alarm insertion LOS, pattern loss

Alarm detection LOS, pattern loss

Buffer-to-buffer credit testing Buffer-to-buffer credit estimation based on latency

Latency Round-trip latency measurement

ADDITIONNAL TEST AND MEASUREMENT FUNCTIONS (1X, 2X, 4X AND 10X)

Power measurement Supports optical power measurement, displayed in dBm.

Frequency measurement Supports clock frequency measurements (i.e., received frequency and deviation of the input signal clock from nominal frequency).

Frequency offset measurement Range: ±120 ppm

Resolution: 1 ppm
Uncertainty (accuracy): ±4.6 ppm

ADDITIONAL SPECIFICATIONS

FTB-8120NGE/8130NGE Power Blazer

Note

a. Modules can also be purchased as FTB-8120NGE-FLEX and FTB-8130NGE-FLEX, which provides maximum configuration

flexibility, allowing all rates and options shown in “Ordering Information” to be ordered individually.

ORDERING INFORMATION

Model

See models listed in previous page

SONET/SDH Rate Options

155 = 155 Mbit/s (OC-3/STM-1)
622 = 622 Mbit/s (OC-12/STM-4)

2.5G = 2.5 Gbit/s (OC-48/STM-16)
10G = 10G Gbit/s (OC-192/STM-64)

OTN Rate Options

OTU1 = OTN optical rate 2.7 Gbit/s
OTU2 = OTN optical rate 10.7 Gbit/s
OTU2-1e-2e = OTN optical rates 11.0491/ 11.0957 Gbit/s
OTU2-1f-2f = OTN optical rates 11.2701 Gbit/s and 11.3176 Gbit/s

Ethernet Rate Options

LAN/WAN 10GigE = 10 GigE LAN/WAN
10M/100M/1000M = 10/100/1000Base and GigE optical
100M-O-AP = 100M optical

Fibre Channel Rate Options

FC1X = 1X Fibre Channel interface
FC2X = 2X Fibre Channel interface
FC4X = 4X Fibre Channel interface
FC10X = 10X Fibre Channel interface

SONET/SDH Options

SONET = SONET-BASE-SW
SDH = SDH-BASE-SW
SONET-SDH = Software option for combined SONET/SDH functionality
G.747 = E1/2M in DS3/45M analysis, as per ITU-T G.747 recommendation
DS1-FDL = DS1 facility data-link generation/analysis
DS3-FEAC = DS3 far-end alarms and loopback code words
DUAL RX = Dual receiver testing mode for DS1 and DS3 interfaces
TCM = Tandem connection monitoring
INTR-THRU-MODE = SONET/SDH intrusive Through mode
SMARTMODE = Real-time signal discovery and alarm/error monitoring per channel

OTN Options

ODUMUX = ODU MUX functionality
ODU0 = ODU0 mapping
ODUflex = ODUflex functionality
OTN-INTR-THRU = OTN intrusive Through mode
EoOTN = Ethernet-over-OTN functionality
OTU2-GFP-F = 10GigE LAN mapping into ODU2 using GFP-F
MULTI-CH-SDT = Multichannel SDT measurements

Next-Generation options

HO-VCAT = High-order virtual concatenation
LO-VCAT = Low-order virtual concatenation
LCAS = Link capacity adjustment scheme
GFP-F = Generic framing procedure—framed
EoS = Ethernet-over-SONET/SDH

Ethernet Options

100optical = 100 Mbit/s optical Ethernet
Frame-Analyzer = Multiple stream generation and analysis
PBB-TE = PBB-TE testing
MPLS = MPLS testing
Adv_filtering = Advanced filtering capabilities
IPv6 = IPv6 testing capabilities
TCP-THPUT= TCP throughput testing
EtherSAM = EtherSAM (Y.156sam) testing
Data_Capture = Data capture and decode capabilities
TRAFFIC-SCAN = VLAN/MPLS traffic scan

FTB-8120NGE/8130NGE Power Blazer

FTB-81XX-XX-XX-XX-XX-XX-XX-XX-XX-XX-XX-XX

Transceivers XFP test port

00 = Without XFP telecom

FTB-81900 = Multirate (10-11.3 Gbit/s) optical XFP transceiver module

FTB-81901= Multirate (10/10.7 Gbit/s) optical XFP transceiver module

a

FTB-81902 = Multirate (10/10.7 Gbit/s) optical XFP transceiver module

FTB-85900 = 10GBase-SR/-SW (850 nm, LAN /WAN PHY)

a

b

a

a

FTB-85901 = 10GBase-LR/-LW (1310 nm, LAN/WAN PHY)

FTB-85902 = 10GBase-ER/-EW (1550 nm, LAN/WAN PHY)

Transceivers SFP Ethernet add/drop port

00 = Without Ethernet add/drop

FTB-8190 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/ FC/2FC)

FTB-8191 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC)

a

FTB-8192 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC)

FTB-8193 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC)

FTB-8590 = GigE/FC/2FC optical SFP transceiver module with LC

FTB-8591 = GigE /FC/2FC optical SFP transceiver module with LC

FTB-8592 = GigE /FC/2FC optical SFP transceiver module with LC

Transceivers SFP test port

d

a, c

e

d

f

00 = SFP test port

FTB-8190 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/ FC/2FC)

FTB-8191 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC)

FTB-8192 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC)

FTB-8193 = Multirate (155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC)

g

h

FTB-85910

FTB-85911

FTB-85912

FTB-85913

FTB-85914

FTB-85915

with LC connector; 1310 nm; 10 km reach

with LC connector; 1550 nm; 40 km reach

with LC connector; 1550 nm; 80 km reach

LC connectors; optical XFP transceiver module

LC connectors; optical XFP transceiver module

LC connectors; optical XFP transceiver module

optical SFP transceiver module with LC connector;
1310 nm; 15 km reach

optical SFP transceiver module with LC connector;
1310 nm; 40 km reach

optical SFP transceiver module with LC connector;
1550 nm; 80 km reach

optical SFP transceiver module with LC connector;
1550 nm; 40 km reach

connector; 850 nm; MMF, <500 m reach

connector; 1310 nm; 10 km reach

connector; 1550 nm; 90 km reach

optical SFP transceiver module with LC connector;
1310 nm; 15 km reach

optical SFP transceiver module with LC connector;
1310 nm; 40 km reach

optical SFP transceiver module with LC connector;
1550 nm; 80 km reach

optical SFP transceiver module with LC connector;
1550 nm; 40 km reach

j

= 100Base-FX (1310 nm) MM, LC connectors; optical SFP

transceiver module for FTB-8510B Packet Blazer

j

= 100Base-LX (1310 nm) SM, LC connectors; optical SFP

transceiver module for FTB-8510B Packet Blazer

i

= SFP modules GigE/FC/2FC/4FC at 850 nm, M MF,

<500 m

i

= SFP modules GigE/FC/2FC/4FC at 1310 nm, SM F,

<4 km

i

= SFP modules GigE/FC/2FC/4FC at 1310 nm, SM F,

<30 km

i

= SFP modules GigE/FC/2FC/4FC at 1550 nm, SMF,

<40 km

a

a, i

a

Example: FTB-8120NGE-SONET-SDH-155-622-2.5G-OTU1-HO-VCAT-8190-8590

NOTES

a. Applies only to FTB-8130NGE, except the FTB-8130NGE-2.5G.

b. Applies only to FTB-8130NGE and FTB-8130NGE-2.5G.

c. Must be combined with the OTU1 and OTU2 options.

d. Must be combined with the OTU1 or OTU2 option.

e. Applicable for FTB-8130NGE modules only (except the FTB-8130NGE-2.5G) and must be combined with the OTU2 option.

f. Must be combined with the OTU2-1e-2e or OTU2-GFP-F or ODU0 option.

g. Must be combined with the HO-VCAT or LO-VCAT option.

h. Must be combined with the GFP-F option.

i. Available with 4x Fibre Channel interface only.

j. Multiple options can be purchased to suit the required test application.

FTB-8120NGE/8130NGE Power Blazer

EXFO Headquarters > Tel.: [phone] | Toll-free: [phone] (USA and Canada) | Fax: [phone]

|

[e-mail]

|

www.EXFO.com

EXFO serves over 2000 customers in more than 100 countries. To find your local office contact details, please go to www.EXFO.com/contact.

EXFO is certified ISO 9001 and attests to the quality of these products. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. EXFO has made every effort to ensure that the information contained in
this specification sheet is accurate. However, we accept no responsibility for any errors or omissions, and we reserve the right to modify design, characteristics and products at any time without obligation. Units of
measurement in this document conform to SI standards and practices. In addition, all of EXFO’s manufactured products are compliant with the European Union’s WEEE directive. For more information, please visit

www.EXFO.com/recycle. Contact EXFO for prices and availability or to obtain the phone number of your local EXFO distributor.

For the most recent version of this spec sheet, please go to the EXFO website at www.EXFO.com/specs.

In case of discrepancy, the Web version takes precedence over any printed literature.

SPFTB8120NGE/8130NGE.13AN © 2013 EXFO Inc. All rights reserved.

2008

Printed in Canada 13/06
