FTB-200 v2 Compact Platform

THE INTELLIGENT PLATFORM BUILT FOR THE SUPERTECH

The FTB-200 V2 delivers the best performance on the market for optical, Ethernet and
SONET/SDH testing.

KEY FEATURES

Intel ATOM processor with Windows Embedded Standard for
maximized productivity and unique versatility

Flexible connectivity with USB, mobile, Wi-Fi and
Bluetooth capabilities

Compatible with 11 families of modules for multiple
fi eld testing applications

› CWDM network characterization at eight wavelengths

› 40G and ROADM commissioning with an optical

spectrum analyzer

› Multiservice testing with a next-generation

SONET/SDH analyzer

› Fiber characterization and construction with OTDR,

loss, dispersion and multitest modules

› Business service activation with OTDR and Ethernet

test modules

› Carrier Ethernet testing from 10 Mbit/s to 10 Gbit/s

SPEC SHEET

FTB-200 v2 Compact Platform

A PROVEN SUCCESS MADE EVEN BETTER

Since its introduction in 2006, the FTB-200 has set the standard for application-driven test solutions. It just made sense to build
on this already smart platform and offer our customers the best compact platform yet: the FTB-200 v2.

With tens of thousands of platforms deployed worldwide, EXFO interacted closely with customers who use the platforms everyday
to incorporate key functionalities that enhance and simplify their testing environments—including wireless and mobile connectivity,
web browsing, PDF printing, screen capture and VT100 terminal emulation.

Today’s multimedia networks demand flexible, efficient and cost-effective test solutions. The FTB-200 v2 offers unprecedented
speed and an expanded integrated tool kit for increased autonomy and productivity in multiservice field testing.

DELIVERING UNIQUE PERFORMANCE

Providing the same compatibility as its predecessor, the FTB-200 v2 platform now leverages a powerful Intel ATOM processor to
deliver unmatched speed and performance for the most demanding test applications.

IN-BAND 64 ACQUISITIONS

OSA

10x faster

Baseline

RE-ANALYSIS

FTB-200 v2

OTDR

Baseline

TRACE LOADING

Baseline

RE-ANALYSIS

Baseline

REAL-TIME ACQUISITION

44 % faster

Baseline

8x faster

FTB-200 v2

14x faster

FTB-200 v2

FTB-200 v2

20x faster

T&D

FTB-200 v2

SPEED

AVERAGE EXECUTION

3x faster

Baseline

RESULT PROCESSING

Baseline

FTB-200 v2

10x faster

FTB-200 v2

SPEEDSPEED

FTB-200 v2 Compact Platform

Ports

and

GigE/

10 GigE

Fibre

Channel

First-class

ergonomics

handle

Multiservice

Angled
stance

ROADM

and PTN

ROADM

Service

Activation

CWDM Turn-up Testing

Integrate two metro/CWDM OTDRs to test through CWDM-based mux/demux at ITU-recommended wavelengths.

40G and ROADM Commissioning

House an OSA into a compact portable solution for fast and accurate DWDM commissioning and high-speed
networking—up to 40 Gbit/s.

Fibre

Channel

First-class

ergonomics

ROADM

and PTN

ROADM

Service

Activation

Multiservice Testing

Simultaneously run a 10 gigabit next-generation SONET/SDH analyzer, as well as 1 gigabit and 10 gigabit Ethernet
analyzers, delivering IPTV test capabilities and TCP throughput assessment.

Ethernet

testing

Fibre

Channel

First-class

ergonomics

Multiservice

ROADM
and PTN

ROADM

ROADM/

POTS

10

Gbit/s

Service

Activation

100 Gbit/s

Distributed

PMD

Fiber

analysis

Fiber Characterization and Construction

Combine PMD, CD and OTDR testing in a single solution, and incorporate an OTDR with a multitest module,
for in-depth link characterization.

Fibre

Channel

ROADM

and PTN

ROADM

Business Service Activation

Join an FTTx PON/MDU OTDR featuring a dynamic range of up to 39 dB with a 1/10 gigabit Ethernet testing module,
to simplify and speed up the deployment of Ethernet services.

Ports

and

stylus

GigE/

10 GigE

Fibre

Channel

First-class

ergonomics

handle

Multiservice

Angled
stance

ROADM

and PTN

ROADM

Service

Activation

Carrier Ethernet Testing from 10 Mbit/s to 10 Gbit/s

Benefit from a comprehensive suite of Ethernet testing capabilities, including EtherSAM
(ITU-T Y.156sam), for turn-up and troubleshooting of mobile backhaul, commercial and
wholesale services.

THE POWER YOU NEED, NO MATTER THE APPLICATION

The FTB-200 v2 delivers the processing power of a high-end platform for a variety of advanced applications—all in a conveniently
sized go-anywhere field-testing tool.

CWDM

ROADM

and PTN

Multiservice

Fiber

Service

Activation

Carrier

Ethernet

FTB-200 v2 Compact Platform

TRANSPORT AND DATACOM TEST MODULES

DSn/PDH and SONET/SDH Electrical Test Module FTB-8105 Transport Blazer

SONET/SDH Test Module FTB-8115 Transport Blazer

Next-Generation SONET/SDH Test Modules FTB-8120/8130 Transport Blazer

Multiservice Test Modules FTB-8120NGE/8130NGE Power Blazer

Ethernet Test Modules FTB-8510/8510B Packet Blazer

10 Gigabit Ethernet Test Module FTB-8510G Packet Blazer

Fibre Channel and Ethernet Test Modules FTB-8525/8535 Packet Blazer

ONE PLATFORM, OVER 30 MODULES

Optimized for all phases of the network lifecycle, the FTB-200 v2 houses any of EXFO’s FTB one- or two-slot modules to meet
your evolving needs. Configure your platform by combining optical, transport and datacom modules to cover a wide range of
applications. Offering power, speed and modularity in a compact format, the FTB-200 v2 is the perfect tool for the field.

Optical Test Modules

Discover the industry’s most renowned line of OTDRs, the most advanced dispersion analyzers and optical spectrum analyzers.

OPTICAL TEST MODULES

OTDR FTB-7xxx (D-E Series)

MultiTest Module FTB-3930

Optical Spectrum Analyzers

Single-Ended Dispersion Analyzer FTB-5700

FTB-5240S

FTB-5240S-P

Transport and Datacom Test Modules

Choose from the most compact and powerful SONET/SDH, OTN, Fibre Channel and Ethernet analyzers—the new standards
in next-generation network testing.

DESIGNED FOR EFFICIENCY

ADDITIONAL FEATURES

Fully backward compatible with previous modules and their original GUIs

1 GigE and three USB 2.0 ports

Built-in Bluetooth and Wi-Fi support

Windows Remote Assistance and Remote Control features

EXFO fiber inspection probe connector interface

TFT outdoor-enhanced LCD 6.5 inch display

Telcordia (Bellcore)-compliant

Update Manager to stay up-to-date and manage your fleet

1

FTB-200 v2 Compact Platform

LED indicators

4

5

6

3

7

1

Switch application and keyboard

2

Knob

3

Power meter and VFL

4

Battery

5

Stylus

6

Two slots to house modules

7

USB 2.0 port

8

1 GigE port

9

FIP port

10

Head set

11

AC adapter

12

Two extra USB 2.0 ports

13

2

8

9

10

11

12

13

FTB-200 v2 Compact Platform

TEST, PROCESS, VIEW AND SEND: IT’S THAT EASY

Connectivity

The FTB-200 v2 integrated wireless communication capabilities allow you to send reports anytime, anywhere using mobile, Wi-Fi
or Bluetooth networking connections.

One Easy Way to View Results

01

Test

02

03

Transfer to PC

View results

ETHERNET

Post-processing
Data storage

Update Manager

Stay current with the FTB-200 v2 Update Manager, which enables you to easily manage the applications developed for your test
solution. Thanks to EXFO’s feature enhancement program, it has never been easier to benefit from our latest innovation. Based
on customer feedback, acute market trend analysis and compliance with the latest standards, EXFO is committed to ensuring
that your product is at its best.

FTB-200 v2 Compact Platform

SPECIFICATIONS

a

Display Touchscreen, color, 640 x 480 TFT 163 mm (6.5 in)

Interfaces Three USB 2.0 ports

RJ-45 LAN 10/100/1000 Mbit/s
Fiber inspection probe connector port (video)
Built-in Bluetooth and Wi-Fi (optional)

Storage 8 GB internal memory (flash)

16 GB USB stick (optional)

Battery Rechargeable Li-Ion batteries

8 hours of operation as per Telcordia (Bellcore) GR-196

Power supply AC/DC adapter, input 100-240 VAC, 50-60 Hz,

2 A max, output: 24 VDC, 90 W

Computer Intel ATOM processor

Windows Embedded Standard

VISUAL FAULT LOCATOR (VFL)

(OPTIONAL)

Laser, 650 nm ± 10 nm

CW

Typical P

out

in 62.5/125 µm: 3 dBm (2 mW)

ACCESSORIES

FP4S 400x Fiber Inspection Probe GP-2001 USB keyboard

FP4D 200x/400x Fiber Inspection Probe GP-2016 10 feet RJ-45 LAN cable

GP-10-070 Rigid FTB-200 carrying case GP-2028 Computer security cable kit

GP-10-072 Semi-rigid FTB-200 carrying case GP-2116 Single-slot storage module

GP-302 USB mouse GP-2137 USB-to-RS-232 converter

GP-1002 Headset GP-2138 DC car adapter/inverter

GP-1008 VFL adapter (2.5 mm to 1.25 mm) GP-2144 USB 16G micro-drive

PM-200 BUILT-IN POWER METER SPECIFICATIONS

c

Calibrated wavelengths (nm) 850, 1300, 1310, 1490, 1550, 1625, 1650

Optional CWDM calibrated wavelengths (nm) 1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490, 1510, 1530, 1550,

1570, 1590, 1610, 1383, 1625

Power range (dBm) 10 to —86 (InGaAs)

26 to —64 (GeX)

Uncertainty (%)

d

±5 % ± 3 pW (InGaAs)
±5 % ± 0.4 nW (GeX)

Display resolution (dB)

InGaAs 0.01 = max to —76 dBm

0.1 = —76 dBm to —86 dBm
1 = —86 dBm to min

GeX 0.01 = max to —54 dBm

0.1 = —54 dBm to —64 dBm
1 = —64 dBm to min

Automatic offset nulling range

e

Max power to —63 dBm for InGaAs
Max power to —40 dBm for GeX

Tone detection (Hz) 270/1000/2000

GENERAL SPECIFICATIONS

Temperature

operating
storage

b

–5 oC to 50 oC (23 oF to 122 oF)
–40

o

C to 70 oC (–40 oF to 158 oF)

Relative humidity 0 % to 95 % non-condensing

Size (H x W x D) 322 mm x 197 mm x 109 mm

(12

11

/16 in x 7 ¾ in x 4 5/16 in)

Weight

b

2.1 kg (4.6 lb)

Vibration

<1.5 g at 10 Hz to 500 Hz
(on three main axes)

Mechanical shock <760 mm on six sides and eight main edges

(compliant to GR-196-CORE)

LASER SAFETY

21 CFR 1040.10 AND IEC 60825-1:2007
CLASS 3R WITH VFL OPTION

This product complies with 21 CFR 1040.10 a

n

for deviations pursuant to Laser Notice No.

5

If VFL option is available

Notes

a. All specifications valid at 23

b. Not including internal batteries. Battery maximum storage temperature: 60

c. At 23 ºC ± 1 ºC, 1550 nm and FC connector. With modules in idle mode. Battery operated.

d. Up to 5 dBm.

e. For ±0.05 dB, from 18 ºC to 28 ºC.

o

C (73 oF).

o

C (140 oF).

IEC 60825-1:2007

21 CFR 1040.10

LASER RADIATION

AVOID DIRECT EYE EXPOSURE

CLASS 3R LASER PRODUCT

λ: 650 ±10 nm

P

maximum < 5mW (into free space)

out

ORDERING INFORMATION

FTB-200-V2-XX-XX-XX-XX-XX-XX

FTB-200 v2 Compact Platform

Model

FTB-200-v2 = Compact modular platform

Display

S1 = TFT active screen
S2 = Outdoor-enhanced screen

Wi-Fi/Bluetooth option

00 = Without RF components
RF = With RF capability (Wi-Fi and Bluetooth)

Power meter

00 = Without power meter
VPM2X = VFL platform; PM; Detector 02X
VPM3 = VFL platform; PM; Detector 03
VPM2X-CWDM = VFL platform; PM; Detector 02X; CWDM

wavelengths calibrated (from 1270 nm to 1610 nm)

VPM3-CWDM = VFL platform; PM; Detector 03; CWDM

wavelengths calibrated (from 1270 nm to 1610 nm)

Example: FTB-200-v2-S1-RF-VPM2X-FOA-78-FP4S-IPT

Software option

00 = Without software option
IPT = Ping traceroute software

Probe

00 = Without probe
FP4S = Inspection probe (400x)
FP4D = Inspection probe (200x/400x)

Connector adaptor

FOA-12 = Biconic
FOA-14 = NEC D4: PC, SPC, UPC
FOA-16 = SMA/905, SMA-906
FOA-22 = FC/PC, FC/SPC, FC/ UPC, FC/APC
FOA-28 = DIN 47256, DIN 47256/APC
FOA-32 = ST: ST/PC, ST/SPC, ST/UPC
FOA-54 = SC: SC/PC, SC/SPC, SC/U PC, SC/APC)
FOA-78 = Radiall EC
FOA-96B = E-2000 E-2000/APC
FOA-98 = LC
FOA-99 = MU

WC2 = FOA-FC-ST-SC-LC

EXFO Corporate Headquarters > 400 Godin Avenue, Quebec City (Quebec) G1M 2K2 CANADA | Tel.: [phone] | Fax: [phone] | [e-mail]

Toll-free: [phone] (USA and Canada)

EXFO America 3701 Plano Parkway, Suite 160 Plano, TX 75075 USA Tel.: [phone] Fax: [phone]
EXFO Asia 151 Chin Swee Road, #03-29 Manhattan House SINGAPORE 169876 Tel.: [phone] Fax: [phone]
EXFO China 36 North, 3

Room 1207, Tower C, Global Trade Center

EXFO Europe Omega Enterprise Park, Electron Way Chandlers Ford, Hampshire S053 4SE ENGLAND Tel.: [phone] Fax: [phone]
EXFO NetHawk Elektroniikkatie 2 FI-90590 Oulu, FINLAND Tel.: [phone] Fax: [phone]
EXFO Service Assurance 270 Billerica Road Chelmsford, MA 01824 USA Tel.: [phone] Fax: [phone]

EXFO is certified ISO 9001 and attests to the quality of these products. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. EXFO has made every effort to ensure that the information contained in
this specification sheet is accurate. However, we accept no responsibility for any errors or omissions, and we reserve the right to modify design, characteristics and products at any time without obligation. Units
of measurement in this document conform to SI standards and practices. In addition, all of EXFO’s manufactured products are compliant with the European Union’s WEEE directive. For more information, please
visit www.EXFO.com/recycle. Contact EXFO for prices and availability or to obtain the phone number of your local EXFO distributor.

For the most recent version of this spec sheet, please go to the EXFO website at www.EXFO.com/specs.

In case of discrepancy, the Web version takes precedence over any printed literature.

SPFTB200v2.1AN © 2010 EXFO Inc. All rights reserved.

rd

Ring Road East, Dongcheng District Beijing 100013 P. R. CHINA Tel.: + 86 10 5825 7755 Fax: [phone]

2008

Printed in Canada 10/09

|

www.EXFO.com
