ASUS X202EDB21T, 90NFQW125T14224O168U User Manual
Notebook PC
E-Manual
E7620
August 2012
COPYRIGHT INFORMATION
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN
IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identication or
explanation and to the owners’ benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you are
entitled to recover damages from ASUS. In each such instance, regardless of the basis on which
you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for
bodily injury (including death) and damage to real property and tangible personal property;
or any other actual and direct damages resulted from omission or failure of performing legal
duties under this Warranty Statement, up to the listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in
contract, tort or infringement under this Warranty Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its
suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRDPARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS
OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC
CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS
SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at http://support.asus.com
2
Notebook PC E-Manual
Table of Contents
About this manual ............................................................................................. 6
Conventions used in this manual ............................................................... 7
Icons ............................................................................................................... 7
Typography ......................................................................................................... 7
Safety precautions ............................................................................................. 8
Using your Notebook PC................................................................................8
Caring for your Notebook PC ....................................................................... 9
Proper disposal ................................................................................................10
Chapter 1: Hardware Setup
Getting to know your Notebook PC ..........................................................12
Top View .............................................................................................................12
Bottom .............................................................................................................17
Right Side ..........................................................................................................18
Left Side .............................................................................................................19
Chapter 2: Using your Notebook PC
Getting started ..................................................................................................22
Charge your Notebook PC. ..........................................................................22
Lift to open the display panel. ...................................................................23
Press the power button. ...............................................................................23
Gestures for the touch screen (on selected models)
and touchpad ....................................................................................................24
Using the touch screen (on selected models) ......................................24
Using the touchpad .......................................................................................26
Using the keyboard .........................................................................................31
Function keys ...................................................................................................31
Function keys for ASUS Apps .....................................................................32
Windows®8 keys (on selected models) ...................................................32
Chapter 3: Working with Windows® 8
Starting for the first time ...............................................................................34
Windows® 8 lock screen .................................................................................. 34
Windows® UI .......................................................................................................35
Start screen .......................................................................................................35
Notebook PC E-Manual
3
Windows® App .................................................................................................35
Hotspots.............................................................................................................36
Working with Windows® apps ......................................................................38
Launching apps ...............................................................................................38
Customizing apps ...........................................................................................38
Closing apps .....................................................................................................40
Accessing the Apps screen ..........................................................................41
Charm bar ..........................................................................................................43
Snap feature .....................................................................................................45
Other keyboard shortcuts .............................................................................47
Connecting to wireless networks ...............................................................49
Wi-Fi .............................................................................................................49
Bluetooth ..........................................................................................................51
Airplane mode .................................................................................................53
Connecting to wired networks....................................................................54
Conguring a dynamic IP/PPPoE network connection ....................54
Conguring a static IP network connection .........................................58
Turning your Notebook PC off .....................................................................59
Putting your Notebook PC to sleep .........................................................59
Chapter 4: ASUS apps
Featured ASUS Apps .......................................................................................62
LifeFrame ...........................................................................................................62
Power4Gear Hybrid........................................................................................64
Instant On ..........................................................................................................65
Chapter 5: Power-on Self Test (POST)
The Power-on Self Test (POST) ....................................................................68
Using POST to access BIOS and Troubleshoot .....................................68
BIOS ...................................................................................................................68
Accessing BIOS ................................................................................................68
BIOS Settings ....................................................................................................69
Troubleshoot......................................................................................................76
Refresh your PC ...............................................................................................76
Reset your PC ...................................................................................................77
Advanced options ..........................................................................................78
4
Notebook PC E-Manual
Appendices
DVD-ROM Drive Information (on selected models) ...........................82
Blu-ray ROM Drive Information (on selected models) ......................84
Internal Modem Compliancy .....................................................................85
Overview............................................................................................................85
Network Compatibility Declaration .........................................................85
Network Compatibility Declaration ........................................................86
Non-Voice Equipment ..................................................................................86
Federal Communications Commission Statement .............................88
FCC Radio Frequency (RF) Exposure Caution Statement .................90
Declaration of Conformity (R&TTE directive 1999/5/EC) ..................90
CE Marking ........................................................................................................91
IC Radiation Exposure Statement for Canada ......................................91
Wireless Operation Channel for Dierent Domains ...........................92
France Restricted Wireless Frequency Bands .......................................92
UL Safety Notices ............................................................................................94
Power Safety Requirement..........................................................................95
TV Tuner Notices .............................................................................................95
REACH .............................................................................................................95
Nordic Lithium Cautions (for lithium-ion batteries) ...........................95
Optical Drive Safety Information ..............................................................97
CTR 21 Approval (for Notebook PC with built-in Modem) ..............98
ENERGY STAR complied product ..............................................................99
European Union Eco-label ........................................................................ 100
Prevention of Hearing Loss ......................................................................100
Global Environmental Regulation Compliance and Declaration 101
ASUS Recycling/Takeback Services ....................................................... 101
Coating Notice ..............................................................................................101
Notebook PC E-Manual
5
About this manual
NOTE: The following information is only for selected Notebook PC
models pre-installed with Windows® 8.
This manual provides information about the hardware and software
features of your Notebook PC, organized through the following
chapters:
Chapter 1: Hardware Setup
This chapter details the hardware components of your
Notebook PC.
Chapter 2: Using your Notebook PC
This chapter shows you how to use the dierent parts of your
Notebook PC.
Chapter 3: Working with Windows® 8
This chapter provides an overview of using Windows® 8 in your
Notebook PC.
Chapter 4: ASUS Apps
This chapter features the ASUS apps included with your
Notebook PC’s Windows® 8 operating system.
Chapter 5: Power-on Self-test (POST)
This chapter shows you how to use POST to change the settings
of your Notebook PC.
Appendices
This section includes notices and safety statements for your
Notebook PC.
6
Notebook PC E-Manual
Conventions used in this manual
To highlight key information in this manual, some text are presented
as follows:
IMPORTANT! This message contains vital information that must be
followed to complete a task.
NOTE: This message contains additional information and tips that can
help complete tasks.
WARNING! This message contains important information that must
be followed to keep you safe while performing tasks and prevent
damage to your Notebook PC's data and components.
Icons
The icons below indicate the devices you can use for completing a
series of tasks or procedures on your Notebook PC.
= Use the touch screen.
= Use the touchpad.
= Use the keyboard.
Typography
Bold = This indicates a menu or an item that must be selected.
Italic = This indicates sections that you can refer to in this manual.
Notebook PC E-Manual
7
Safety precautions
Using your Notebook PC
This Notebook PC should only be used in environments
with ambient temperatures between 5°C (41°F) and 35°C
(95°F).
Refer to the rating label on the bottom of your Notebook
PC and ensure that your power adapter complies with
this rating.
Do not leave your Notebook PC on your lap or near any
part of your body to prevent discomfort or injury from
heat exposure.
Do not use damaged power cords, accessories, and other
peripherals with your Notebook PC.
While powered on, ensure that you do not carry or cover
your Notebook PC with any materials that can reduce air
circulation.
Do not place your Notebook PC on uneven or unstable
work surfaces.
You can send your Notebook PC through x-ray machines
(used on items placed on conveyor belts), but do not
expose them to magnetic detectors and wands.
Contact your airline provider to learn about related
inight services that can be used and restrictions that
must be followed when using your Notebook PC inight.
8
Notebook PC E-Manual
Caring for your Notebook PC
Disconnect the AC power and remove the battery pack
(if applicable) before cleaning your Notebook PC. Use a
clean cellulose sponge or chamois cloth dampened with
a solution of nonabrasive detergent and a few drops
of warm water. Remove any extra moisture from your
Notebook PC using a dry cloth.
Do not use strong solvents such as thinners, benzene, or
other chemicals on or near your Notebook PC.
Do not place objects on top of your Notebook PC.
Do not expose your Notebook PC to strong magnetic or
electrical elds.
Do not use or expose your Notebook PC near liquids, rain,
or moisture.
Do not expose your Notebook PC to dusty environments.
Do not use your Notebook PC near gas leaks.
Notebook PC E-Manual
9
Proper disposal
Do not throw your Notebook PC in municipal waste.
This product has been designed to enable proper reuse
of parts and recycling. The symbol of the crossed out
wheeled bin indicates that the product (electrical,
electronic equipment and mercury-containing button cell
battery) should not be placed in municipal waste. Check
local regulations for disposal of electronic products.
Do not throw the battery in municipal waste. The symbol
of the crossed out wheeled bin indicates that the battery
should not be placed in municipal waste.
10
Notebook PC E-Manual
Chapter 1: Hardware Setup
Notebook PC E-Manual
11
Getting to know your Notebook PC
Top View
NOTE: The keyboard's layout may vary per region or country. The top
view may also vary in appearance depending on the Notebook PC
model.
12
Notebook PC E-Manual
Microphone
The built-in microphone can be used for video conferencing,
voice narrations, or simple audio recording.
Camera
The built-in camera allows you to take pictures or record videos
using your Notebook PC.
Camera indicator
The camera indicator lights up when the built-in camera is in
use.
Display panel
This high-denition display panel provides excellent viewing
features for photos, videos, and other multimedia les on your
Notebook PC.
NOTE: Some models are equipped with a touch-enabled
panel, allowing you to operate your Notebook PC using touch
gestures.
Power button
Press the power button to turn your Notebook PC on or o.
You can also use the power button to put your Notebook
PC to sleep or hibernate mode and wake it up from sleep or
hibernate mode.
Air vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
WARNING! Ensure that paper, books, clothing, cables, or other
objects do not block any of the air vents or else overheating
may occur.
Notebook PC E-Manual
13
Keyboard
The keyboard provides full-sized QWERTY keys with a
comfortable travel depth for typing. It also enables you to
use the function keys, allows quick access to Windows®, and
controls other multimedia functions.
NOTE: The keyboard layout diers by model or territory.
Touchpad
The touchpad allows the use of multi-gestures to navigate
onscreen, providing an intuitive user experience. It also
simulates the functions of a regular mouse.
NOTE: For more details, refer to the Gestures for the touchpad
section in this manual.
14
Notebook PC E-Manual
Status indicators
The status indicators help identify the current hardware status
of your Notebook PC.
Power indicator
The power indicator lights up when the Notebook PC
is turned on and blinks slowly when the Notebook PC
is in sleep mode
Two-color battery charge indicator
The two-color LED provides a visual indication of the
battery’s charge status. Refer to the following table for
details:
Color Status
Solid Green Battery power is between 95% and
100%.
Solid Orange Battery power is less than 95%.
Blinking Orange Battery power is less than 10%.
Notebook PC E-Manual
15
Drive activity indicator
This indicator lights up when your Notebook PC is
accessing the internal storage drives.
Bluetooth / Wireless indicator (on selected models)
This indicator lights up when your Notebook PC’s
wireless function (Bluetooth or Wi-Fi) is enabled.
Capital lock indicator
This indicator lights up when the capital lock function
is activated. Using capital lock allows you to type
capitalized letters (such as A, B, C) using your Notebook
PC’s keyboard.
16
Notebook PC E-Manual
Bottom
NOTE: The bottom side may vary in appearance depending on model.
WARNING! The bottom of the Notebook PC can get warm to hot
while in use or while charging the battery pack. When working on
your Notebook PC, do not place it on surfaces that can block the
vents.
IMPORTANT! Battery time varies by usage and by the specications
for this Notebook PC. The battery pack cannot be disassembled.
Audio speakers
The built-in audio speakers allow you to hear audio straight
from the Notebook PC. The audio features of this Notebook PC
are software-controlled.
Air vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
WARNING! Ensure that paper, books, clothing, cables, or other
objects do not block any of the air vents or else overheating
may occur.
Notebook PC E-Manual
17
Right Side
Memory card reader
This Notebook PC has a single built-in memory card reader slot
that supports MMC, SD, and SDHC card formats.
Headphone output/microphone input combo jack port
This port allows you to connect your Notebook PC to amplied
speakers or headphones. You can also use this port to connect
your Notebook PC to an external microphone.
USB 2.0 port
This Universal Serial Bus (USB 2.0) port is compatible with USB
2.0 or USB 1.1 devices such as keyboards, pointing devices, ash
disk drives, external HDDs, speakers, cameras and printers.
18
VGA port
This port allows you to connect your Notebook PC to a standard
VGA-compatible device, such as monitors or projectors.
Notebook PC E-Manual
Left Side
Power (DC) input port
Insert the bundled power adapter into this port to charge the
battery pack and supply power to your Notebook PC.
WARNING! The adapter may become warm to hot while in
use. Do not cover the adapter and keep it away from your body
while it is connected to a power source.
IMPORTANT! Use only the bundled power adapter to charge
the battery pack and supply power to your Notebook PC.
LAN port
Insert the network cable into this port to connect to a local area
network (LAN).
NOTE: For more details, refer to the Connecting to wired
networks section in this manual.
Notebook PC E-Manual
19
HDMI port
This port is for a High-Denition Multimedia Interface (HDMI)
connector and is HDCP compliant for HD DVD, Blu-ray, and
other protected content playback.
USB 2.0 ports
These Universal Serial Bus 2.0 (USB 2.0) ports are compatible
with USB 2.0 or USB 1.1 devices such as keyboards, pointing
devices, ash disk drives, external HDDs, speakers, cameras and
printers.
USB 3.0 ports (on selected models)
These Universal Serial Bus 3.0 (USB 3.0) ports are backward
compatible to USB 2.0 and USB 1.1 devices. The actual transfer
rate may dier depending on the USB port and device used.
Kensington® lock port
The Kensington® lock port allows you to secure your Notebook
PC using Kensington® compatible Notebook PC security
products.
20
Notebook PC E-Manual
Chapter 2: Using your Notebook PC
Notebook PC E-Manual
21
Getting started
Charge your Notebook PC.
A. Plug the AC power adapter into a 100V~240V power source.
B. Connect the DC power connector into your Notebook PC’s
power (DC) input.
IMPORTANT!
22
• Ensure that your Notebook PC is connected to the power adapter
before turning it on for the rst time.
• Use only the power adapter bundled with your Notebook PC.
• When using your Notebook PC on power adapter mode, the
socket outlet must be near to the unit and easily accessible.
• Power adapter information:
- Input voltage: 100-240Vac
- Input frequency: 50-60Hz
- Rating output current: 1.75A max. (33W)
- Rating output voltage: 19V
Notebook PC E-Manual
Lift to open the display panel.
Press the power button.
Notebook PC E-Manual
23
Gestures for the touch screen (on selected models) and touchpad
Gestures allow you to launch programs and access the settings of
your Notebook PC. Refer to the following illustrations when using
hand gestures on your touch screen (on selected models) and
touchpad.
Using the touch screen (on selected models)
Left edge swipe Right edge swipe
Swipe from the left edge of the
screen to shue your running
apps.
Zoom out Zoom in
Bring together your two ngers
on the touch panel.
24
Swipe from the right edge
of the screen to launch the
Charm bar.
Spread apart your two ngers
on the touch panel.
Notebook PC E-Manual
Top edge swipe Finger slide
• In the Start screen, swipe
from the top edge of the
screen to view the All Apps
Slide your nger to scroll up
and down and slide your nger
to pan the screen left or right.
bar.
• In a running app, swipe from
the top edge of the screen to
view its menu.
Tap and hold Tap/Double tap
• To move an app, tap and
hold the app tile and drag it
to a new location.
• To close an app, tap and hold
• Tap an app to launch it.
• On Desktop mode, doubletap an application to
launch it.
the top side of the running
app and drag it down to the
bottom of the screen to close
it.
Notebook PC E-Manual
25
Using the touchpad
Moving the pointer
You can tap or click anywhere on the touchpad to activate its
pointer, then slide your nger on the touchpad to move the pointer
onscreen.
Slide horizontally
Slide vertically
Slide diagonally
26
Notebook PC E-Manual
One-nger gestures
Tap/Double tap
• In the Start screen, tap an app to launch it.
• In Desktop mode, double-tap an application to launch it.
Left-click Right-click
• In the Start screen, click an
app to launch it.
• In Desktop mode, doubleclick an application to launch
it.
• In the Start screen, click an
app to select it and launch
the settings bar. You can also
press this button to launch
the All Apps bar.
• In Desktop mode, use this
button to open the rightclick menu.
NOTE: The areas inside the dotted line represent the locations of the
left mouse button and the right mouse button on the touchpad.
Notebook PC E-Manual
27
Drag and drop
Double-tap an item, then slide the same nger without lifting it o
the touchpad. To drop the item to its new location, lift your nger
from the touchpad.
Top edge swipe
• In the Start screen, swipe from the top edge to launch the All
Apps bar.
• In a running app, swipe from the top edge to view its menu.
Left edge swipe Right edge swipe
Swipe from the left edge to shue
your running apps.
28
Swipe the right edge to launch
the Charm bar.
Notebook PC E-Manual
Two-nger gestures
Tap Rotate
Tap two ngers on the touchpad
to simulate the right-click
function.
To rotate an image in Windows®
Photo Viewer, place two ngers on
the touchpad then turn one nger
clockwise or counterclockwise
while the other stays still.
Two-nger scroll (up/down) Two-nger scroll (left/right)
Slide two ngers to scroll up or
down.
Slide two ngers to scroll left or
right.
Zoom out Zoom in
Bring together your two ngers
on the touchpad.
Notebook PC E-Manual
Spread apart your two ngers on
the touchpad.
29
Drag and drop
Select an item then press and hold the left button. Using your other
nger, slide down the touchpad to drag and drop the item to a new
location.
30
Notebook PC E-Manual
Loading...
