ASUS V70 User Manual

User Manual

Preface

Congratulations on your purchase of a mobile telephone. Read this manual carefully and keep it in a safe place for future reference.

About this manual

Every effort has been made to ensure that the contents of this manual are correct and up to date. However, no guarantee is made regarding the accuracy of the contents, and the manufacturer reserves the right to make changes without notice.

Additional Information

The use of this equipment may be subject to local rules and regulations. The following rules and regulations may be relevant in some or all areas where your handset will be in operation.

FCC Regulations

This model phone complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/ TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this

Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment.

The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

This EUT is in compliance with SAR for general population /uncontrolled exposure limits in ANSI/ IEEE C95.1-1999 and had been tested in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C.

European Notice

Products with the mark comply with the Radio & Telecommunication Terminal Equipment Directive (1999/5/EEC), the Electromagnetic Compatibility Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) - as amended by Directive 93/68/ECC - issued by the Commission of the European Community.

Compliance with these directives implies conformity to the following European Standards:

• 1999/5/EEC Radio & Telecommunication Terminal Equipment Directive (R&TTE) EN 301 511

• Specific Absorption Rate (SAR) S tandard: EN 50360, EN 50361

• 73/23/EEC Low Voltage Directive (LVD) Standard: EN 60950:2000

• 89/336/EEC Electromagnetic Compatibility (EMC-Directive) Standard: EN301489-1/7

• The manufacturer cannot be held responsible for modifications made by the user and the consequences thereof, which may alter the conformity of the product with the mark.

exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.

The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is 0.233 W/kg and when worn on the body, as described in this user guide, is 0.615 W/kg. (Bodyworn measurements differ among phone models, depending upon avail-able enhancements and FCC requirements.

RF Exposure Information (SAR)

This model phone meets the government’s requirements for exposure to radio waves. This phone is designed and manufactured not to

While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement.

iii

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of tap:// www.fcc.gov/oet/fccid after searching on FCC ID: SNFCAS

For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and the positions the handset a minimum of 1.5 cm from the body. Use of other enhancements may not ensure compliance with FCC RF exposure guidelines. If you do not use a body-worn accessory and are not holding the phone at the ear, position the handset a minimum of 1.5 cm from your body when the phone is switched on.

Proper Disposal

The symbol of the crossed out bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Please check local regulations for disposal of electronic products.

Safety Warnings

Read the following safety warnings carefully before using your cell phone.

• This equipment is intended for use with power supplied from supplied battery charger(s) and/or power supply unit(s). Other usage will invalidate any certification given to this apparatus and may be dangerous.

• Switch off your cellular telephone when in an aircraft. The use of cellular telephones in an

aircraft may be dangerous to the operation of the aircraft, disrupt cellular networks, and may be illegal. Failure to observe this instruction may lead to suspension or denial of cellular telephone services to the offender, legal action or both.

• Do not use the phone or phone equipment when at a refueling point.

• Observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress.

• The use of the Alert device to operate a vehicle’s lights or horn on public roads is not permitted.

You MUST exercise proper control of your vehicle at all times. Observe the following safety precautions when driving:

• Do not use a hand-held telephone or microphone while you are driving.

• When driving, find a safe place to stop the vehicle before using the phone.

• Do not speak into a hands-free micro- phone if it will distract you from driving.

• You MUST NOT stop on the hard shoulder of a motorway to answer or make a call, except in an emergency.

• The radio equipment should be connected to the antenna via a non-radiating cable

• (e.g. coaxial cable). The antenna must be mounted in a position such that no part of the

human body will normally rest close to any part of the antenna unless there is an intervening metallic screen, such as a metallic roof.

NOTES:

• In some areas where electric current is unstable, it is recommended that you plug the charger to an AVR (AC Voltage Regulator) instead of direct connection to a power outlet. Unstable power current may damage the charger and / or the device.

• You can connect the USB charger or USB data cable to the device in only one orientation. Incorrect insertion of the cable connector may cause a short circuit and may damage the device.

WELCOME

Package Contents............................. 1

Overview......................................... ... 2

Specifications .................................... 3

Menu Map.......................................... 4

Getting Started

Inserting the SIM card, Mini SD

card, and battery................................ 9

Charging the Battery........................ 10

Turning the Phone On and Off ........ 11

Function Keys.................................. 11

Features .......................................... 13

Unlocking the Keypad and Slide lock 15

Standby Mode ................................. 16

Using the Menu ............................... 16

Text Entry........................................ 18

Connecting to a Computer............... 20

Phonebook

Adding Contacts.............................. 21

Searching for a Contact................... 21

Shortcut to Contact Entries.............. 22

Copy Contacts................................. 22

Deleting Contacts............................ 23

Caller Groups................................... 23

Extra Number................................... 24

Settings.................. .......................... 25

My vCard ......................................... 26

Messages

SMS................................................. 27

MMS ................................................ 29

Chat............................... .................. 31

E-mail............................................... 32

Voice Mail Server............................. 32

Broadcast Message......................... 32

Calls and Call History

Making a Call................................... 35

Answering a Call.................... ... ....... 35

Answer Mode................................... 35

Canceling an Incoming Call............. 36

Diverting a Call ................................ 36

Redialing a Number......................... 36

Call History ...................................... 36

Returning a Missed Call................... 36

Call Log Options.............................. 37

Deleting Call Logs............................ 37

Call Time/Cost................................. 37

SMS Counter................................... 38

GPRS Counter................................ 38

Options During a Call...................... 38

Other call options............................ 38

Display Settings

Phone Setup................................... 39

Themes........................................... 42

Call Setup ....................................... 43

Network Setup ................................ 46

Security Setup................................. 47

Restore Factory Settings ................ 48

Sound Effect ................................... 49

Multimedia

Camera........................................... 51

Image Viewer.................................. 51

Video Recorder............................... 52

Video Player.................................... 52

Photo Artist ..................................... 52

Audio Player.................................... 52

Sound Recorder.............................. 54

Melody Composer........................... 55

File Manager

Phone.............................................. 57

DRM Rights..................................... 57

Fun and Games

Java ................................................ 59

Games............................................. 59

Stopwatch ....................................... 60

Image Editor.................................... 61

Game Setting.................................. 61

User Profiles

Profile Settings................................ 63

Organizer

Calendar..................................... ... .. 65

To Do List........................................ 65

Alarm............................................... 66

World Clock..................................... 67

Services

Service Provider Settings................ 69

WAP................................................ 69

Data Account................................. .. 70

Extra

Calculator................................. .. ..... 71

Units Converter............................... 72

Currency Converter......................... 72

Health.............................................. 73

Bluetooth.................................... ..... 73

Shortcuts

Creating Shortcuts .......................... 75

Editing Shortcuts ............................. 75

Creating Joystick Shortcut............... 75

Camera and Video Recorder

Taking Photos.................................. 77

Viewing and Managing Photos........ 77

Photo Capture Settings ................... 78

Recording Videos............................ 80

Viewing and Managing Videos ........ 80

Video Capture Settings.................... 81

WELCOME

Congratulations on your purchase of a cell phone. The following illustration displays the package contents of your new phone.

Package Contents

WELCOME

Cell phone

Rechargeable Li Ion Battery

Headset

AC Adapter

User Manual

Overview

This is a stylish and fashionable new phone, with all the functions and utilities to make it a useful tool in today’s mobile world. The phone comes equipped with a built-in camera, MMS/SMS messaging capability, organizer, java games, audio player, WAP, GPRS, and a mini SD card slot. In addition to the internal 60

MB phone memory, the mini SD card mation, messages, text, graphics, and audio files. The audio player enables you to play back your favorite music.

• Wide variety of calling and messaging functions

• Built-in camera

• Media center with audio player, FM radio receiver, and games for your entertainment

• MMS and SMS messaging capability

• Personal information organizer with alarm, calendar, calculator and other useful tools to manage your time

• WAP and GPRS capability to check e-mail or browse web services

provides additional memory where you can store your contact infor-

1. The Mini SD card may be supplied only as an optional extra in some regions.

Specifications

System supported GSM900/1800/1900, GPRS Class B/Multi-Slot Size 90 x 45 x 24 mm Weight 85g Battery 750 mAh Li-ion Standby Time 140-200 hours Talk Time 2.5 ~ 5 hours Display 1.8-inch, 256K colors, TFT, 176x220 Camera 1.3mega pixel CMOS Supports video recording 1/3/5 continuous shots WAP Supports WAP 2.0 Java Supports J2ME (CLDC + MiDP 1.0.3) Messaging Supports SMS, EMS, MMS Ring tone 64 polyphonic ring tones

Supports MP3 Record Record an unlimited number of files, up to memory capacity Internal Memory 60 MB External storage Mini-SD card

WELCOME

Note: All specifications are subject to change without notice.

Menu Map

Phonebook

• Quick Search

• Search Entry

• Add New Entry

-To SIM

-To Phone

• Copy All

-From SIM

- From Phone

• Delete

-From SIM

- From Phone

-One By One

• Caller Group

- Friends

-Family

-VIP

- Business

-Others

• Extra number

- Owner Number

- Service Dial Number

- SOS Number

• Settings

- Memory Status

- Preferred Storage

-Fields

-My vCard

- Human Voice Prompt

Messages

•SMS

- Inbox

- Outbox

- Write Message

- Template

- Message Settings

• MMS

- Write Message

- Inbox

- Outbox

- Drafts

- Templates

- Message Settings

• Chat

- Chat Room 1

- Chat Room 2

•Email

- Send and Receive

• Voice Mail Server

-Voice Mail

-Empty

• Broadcast Message

- Receive Mode

- Read Message

- Languages

- Channel setting

Call History

• Missed Calls

• Dialed Calls

• Received Calls

• Delete Call Log

- Missed Calls

- Dialed Calls

- Received Calls

- Delete All

•Call Time

- Last Call Time

- Total Sent

- Total Received

- Reset All Time

•Call Cost

- Last Call Cost

- Total Cost

- Reset Cost

-Max Cost

-Price Per Unit

• SMS Counter

- Sent

- Received

• GPRS Counter

- Last Sent

- Last Received

- All Sent

- All Received

- Reset Counter

Settings

• Phone Setup

- Time and Date

- Schedule Power On/Off

- Language

- Preferred Input Method

- Display Setting

- Greeting Text

- Speed Dial

- Dedicated Key

- Auto Update of Date and Time

•Call Setup

- Caller ID

- Call Waiting

- Call Divert

- Call Barring

- Line Switching

- Call Time Reminder

- Call Time Display

- Auto Redial

- Closed User Group

• Network Setup

-Network Selection

- Preferred Networks

- Band Selection

- GPRS Connection

• Security Setup

- SIM Lock

- Phone Lock

- Auto Keypad Lock

- Slide Keypad Lock

- Fixed Dial

WELCOME

- Barred Dial

- Change Password

• Restore Factory Settings

• Sound Effect

- Equalizer

MultiMedia

• Camera

• Image Viewer

• Video Recorder

• Video Player

• Photo Artist

• Audio Player

• Sound Recorder

• Melody Composer

File Manager

• Phone

-Open

- Create Folder

-Format

• DRM Rights

Fun and Games

•Java

• Games

- Robot

-UFO

- Dance

• Stopwatch

- Typical Stopwatch

- nWay Stopwatch

• Image Editor

• Game Setting

- Game Audio

- Game Vibration

User Profiles

• General

• Meeting

• Outdoor

• Indoor

• Headset

Organizer

• Calendar

•To Do List

•Alarm

• World Clock

Services

•WAP

- Homepage

- Bookmarks

- Recent Pages

- Enter Address

- Service Inbox

- Settings

• Data Account

-GSM Data

-GPRS

Extra

•Calculator

• Units Converter

- Weight

- Length

• Currency Converter

• Health

-BMI

- Menstrual

• Bluetooth

- Power

- Search Audio Device

- My Device

- Setting

Shortcuts

• Search Entry

• Inbox

• Write Message

• Missed Calls

• Received Calls

• Tone Setup

•Alarm

•Alert Type

•Call Divert

• Preferred Storage

WELCOME

Getting Started

Inserting the SIM card, Mini SD card, and battery

When you register with a service provider, you receive a SIM card (Subscriber Identity Module card). Your phone must have a SIM card in order to make calls. The SIM card is a computer chip that contains your phone number, phonebook information, and service provider information. Handle it with care and do not bend it or expose it to static electricity or dirt. Be sure the power to your phone is off before you insert your SIM card.

The SIM card and the mini SD card slots are situated underneath the battery. To insert the cards, follow these steps:

1. Press the back cover and slide the cover off to remove it.

2. Remove the battery. The battery has a tab at the top to make it easier to grasp and remove.

3. Insert the SIM card into the holder with the correct orientation. The gold contacts of the SIM card should face down.

4. Place the mini SD card in the slot with the gold contacts facing down.

Note: Note: In some regions the mini SD card may be supplied as an optional accessory only.

SIM

MINI SD

5. Place the battery back into the battery compartment noting the correct polarity.

6. Place the back cover against the phone case, make sure to put the pins in the bottom case first, then slide it upwards to lock into place.

Caution: Use only the battery recommended by the manufacturer. Using an incompatible battery with the phone may cause risk of an explosion.

Dispose of the used batteries as instructed by the manufacturer or ask your local authorities for assistance.

Charging the Battery

1. Connect the charger plug to a power outlet.

2. Connect the charger to the socket at the bottom of the phone. The connector can only be inserted one way.

Note: For best battery performance, allow the battery to charge and discharge completely the first few times you use it.

Low Battery Indicator

The battery indicator in the upper right corner of the screen indicates how much charge remains in the battery. As additional reminders, when the battery is low, the phone emits a double beep. The message “battery low” also appears on the screen.

Note: If the battery has been deeply discharged, it may take several minutes before the battery level indicator is displayed.

Turning the Phone On and Off

To turn the phone on, do the following:

1. Hold down the power/end key until the screen lights up.

2. If needed, enter your SIM card PIN code and press the Enter key.

To turn the phone off, do the following:

• Press the power/end key and hold until the phone shuts down.

Note: If you set an alarm using the Organizer menu and turn off the phone, the phone will turn itself on when the alarm is activated. After you disable the alarm, the phone prompts you if you want to keep the phone turned on or off. See the Organizer section for details about setting an alarm.

Function Keys

The following table lists the phone keys and their functions.

Call key

• Press to dial or answer calls.

• Hold to redial the last number called.

Left soft key

• Press to display the menu.

• Press to perform the function currently displayed in the lower left corner of the screen.

• Press to move left while navigating menus.

Right soft key

• Press to view phone book when the phone is in idle mode.

• Press to perform the function currently displayed in the lower right corner of the screen.

• Press to move right while navigating menus.

Getting Started

Power/end key

Hold to turn the phone on or off.

• Press to stop an incoming call or cancel a call you are dialing.

• Press to exit a menu or submenu

Up joystick key

• Press to scroll up through menu items.

• Press to display the SMS inbox when the phone is in

standby mode

1111

Down joystick key

• Press to scroll down through menu items.

• Press to display a list of your shortcuts when the phone is in standby mode.

Left joystick key

• Press to scroll left through menu items.

• Press to display the Camera menu when the phone is in standby mode.

Right joystick key

• Press to scroll right through menu items.

• Press to display the Media Center menu when the phone is in standby mode.

Enter key

• Press to display the main menu.

• Press to confirm selection of a menu item when the phone is in standby mode.

Features

Front View

Closed

Getting Started

Open

Speaker

Screen

Up /down buttons

Charger/USB cable socket

1313

Left View Right View

Headphone jack

Volume up

Volume down

Rear View

Getting Started

Headset jack

Battery Cover

Unlocking the Keypad and Slide lock

The keypad and the slide lock of the phone can be locked automatically after a specific time interval to prevent tampering or accidental pressing of any buttons. Refer to Security Setup in the Settings section to learn how to lock the keypad and slide lock.

Camera lens

To unlock the keypad, do the following:

1. The screen shows Unlock in the lower right corner of the screen. Select this option by

pressing the right soft key which is just under the word Unlock on the screen.

2. Press the left soft key on the keypad to unlock the keypad as prompted on the screen.

3. Or Long press # key to unlock.

1515

The keypad and slide is then unlocked.

Phone is in roaming mode.

Standby Mode

When your phone is on, but not in use, it is in standby mode. During standby mode, the upper part of the display screen shows various icons.

The date and time is displayed at the lower center of the screen. Beneath the date and time are Menu in the left corner and Name in the right corner. Press the left soft key to view the main menu, and the right soft key to view the phone book.

Vertical bars indicate the strength of the GSM network signal. Four bars indicates that your current position has the best reception.

Line 1 or Line 2 is selected for calls.

Alarm has been set. A text message has been received. A

multimedia message has been received. Icon blinks if SMS memory is full

Indicates battery charge status.

Phone is using GPRS network.

Ringtone is enabled. Indicates a missed call. Call forward

Ring disabled

Using the Menu

In the standby mode, press the left soft key to view the main menu.

Follow these tips to navigate through the menu and menu options.

• To view the menu, press the left soft key or the Enter key.

• Use the up, down, left, and right joystick keys to move through the various menu items.

• The lower left corner of the screen displays

OK while the lower right corner displays Back. Press the left soft key (situated

under OK) to select the menu item. Press the right soft key which is situated under Back to exit the menu.

• Each menu item also displays a small number to the right of the Menu Options title. You can also press the number corresponding to a menu item, on the keypad to select the item.

• To quickly exit from the menu, press the Power/End key.

• Use the joystick keys to select the submenu items and options. The right and left soft keys can also be used for selecting various options in submenus.

For example, to view missed calls, do the following:

1. Use the joystick keys to select Calls from

the main menu.

2. Press the left soft key to confirm the selection. The Calls submenu opens.

3. Press the left soft key to select the Missed Calls option. A list of missed calls opens.

The following table provides a list of all the main menu items:

Multimedia: Consists of a camera, image viewer, video recorder, video player, photo artist, audio player, sound recorder a melody composer.

Extra: Consists of a calculator, unit convertor, currency convertor, health and bluetooth.

File Manager: Enables you to manage your phone and DRM files.

Shortcut: Enables you to create shortcut to your most used functions.Also contains presets.

Services: Enables you to specify the WAP and data account settings and set up GSM and GPRS settings. Enables access to the internet and to STK SIM card services.

Messages: Gives you access to messages received. Compose and send text (SMS) and multimedia (MMS) messages here. You can also check email, chat, and broadcast a me sage using this menu.

User Profile: Enables you to select and customize the Phone Setup including the ring tone, volume, ring type, and answer mode.

Settings: Lets you adjust the phone setup such as call setup, network setup, and security setup. You can also restore all settings to their factory default from this menu and change sound effects.

Fun and Games: Consists of java, games, themes, stopwatch, image editor, game setting and java setting

Getting Started

1717

+ 66 hidden pages
