ASUS K8V-X SE User Manual

K8V-X SE

User Guide

Motherboard

Checklist

E1931
First Edition

May 2005

Copyright © 2005 ASUSTeK COMPUTER INC. All Rights Reserved.

No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME
WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.

ii

Contents

Notices ...........................................................................................vi

Safety information ......................................................................... vii

About this guide............................................................................ viii

K8V-X SE specifications summary ................................................. ix

Chapter 1: Product introduction

1.1 Welcome! ........................................................................... 1-2

1.2 Package contents............................................................... 1-2

1.3 Special features.................................................................. 1-3

1.3.1 Product Highlights.................................................. 1-3

1.3.2 Unique ASUS features ........................................... 1-4

1.4 Before you proceed ............................................................ 1-5

1.5 Motherboard overview........................................................ 1-6

1.5.1 Motherboard layout ................................................ 1-6

1.5.2 Placement direction ............................................... 1-7

1.5.3 Screw holes ........................................................... 1-7

1.6 Central Processing Unit (CPU)........................................... 1-8

1.6.1 Overview ................................................................ 1-8

1.6.2 Installing the CPU .................................................. 1-9

Features

1.7 System memory ............................................................... 1-10

1.7.1 DIMM sockets location......................................... 1-10

1.7.2 Memory configurations ........................................ 1-10

1.7.3 Installing a DIMM ................................................. 1-13

1.8 Expansion slots ................................................................ 1-13

1.8.1 Standard interrupt assignments ........................... 1-13

1.8.2 IRQ assignments for this motherboard ................ 1-14

1.8.3 PCI slots .............................................................. 1-14

1.8.4 AGP slot............................................................... 1-15

1.9 Jumpers............................................................................ 1-16

1.10 Connectors ....................................................................... 1-18

1.10.1 Rear panel connectors......................................... 1-18

1.10.2 Internal connectors .............................................. 1-20

Chapter 2: BIOS Information

2.1 Managing and updating your BIOS .................................... 2-2

2.1.1 Creating a bootable floppy disk ............................. 2-2

iii

Safeguards

Contents

2.1.2 Using AFUDOS to update the BIOS ...................... 2-3

2.1.3 Using AFUDOS to copy BIOS from PC ................. 2-4

2.1.4 Using ASUS EZ Flash to update the BIOS ............ 2-5

2.1.5 Recovering the BIOS with CrashFree BIOS 2 ....... 2-6

2.2 BIOS Setup program .......................................................... 2-8

2.2.1 BIOS menu screen ................................................ 2-9

2.2.2 Menu bar................................................................ 2-9

2.2.3 Navigation keys ..................................................... 2-9

2.2.4 Menu items .......................................................... 2-10

2.2.5 Sub-menu items................................................... 2-10

2.2.6 Configuration fields .............................................. 2-10

2.2.7 Pop-up window .................................................... 2-10

2.2.8 Scroll bar.............................................................. 2-10

2.2.9 General help ........................................................ 2-10

2.3 Main menu.........................................................................2-11

2.3.1 System Time .........................................................2-11

2.3.2 System Date .........................................................2-11

2.3.3 Legacy Diskette A .................................................2-11

2.3.4 Primary and Secondary IDE Master/Slave .......... 2-12

2.3.5 System Information .............................................. 2-13

2.4 Advanced menu ............................................................... 2-14

2.4.1 CPU Configuration ............................................... 2-14

2.4.2 Chipset................................................................. 2-17

2.4.3 Onboard Devices Configuration........................... 2-20

2.4.4 PCI PnP ............................................................... 2-21

2.4.5 System Frequency/Voltage Configuration ........... 2-22

2.4.6 Instant Music Configuration ................................. 2-23

2.5 Power menu ..................................................................... 2-24

2.5.1 Suspend Mode..................................................... 2-24

2.5.2 Repost Video on S3 Resume............................... 2-24

2.5.3 ACPI 2.0 Support ................................................. 2-24

2.5.4 ACPI APIC Support.............................................. 2-24

2.5.5 APM Configuration............................................... 2-25

2.5.6 Hardware Monitor ................................................ 2-26

2.6 Boot menu ........................................................................ 2-27

2.6.1 Boot Device Priority ............................................. 2-27

2.6.2 Removable Drives ............................................... 2-27

2.6.3 Boot Settings Configuration ................................. 2-28

iv

Contents

2.6.4 Security ................................................................ 2-29

2.7 Exit menu ......................................................................... 2-31

Chapter 3: Software support

3.1 Install an operating system................................................. 3-2

3.2 Support CD information...................................................... 3-2

3.2.1 Running the support CD ........................................ 3-2

3.2.2 Drivers menu ......................................................... 3-3

3.2.3 Utilities menu ......................................................... 3-4

3.2.4 Manual menu ......................................................... 3-5

3.2.5 ASUS Contact Information..................................... 3-5

3.3 ASUS Instant Music Lite..................................................... 3-6

3.4 VIA RAID configurations..................................................... 3-8

3.4.1 Installing hard disks ............................................... 3-8

3.4.2 VIA RAID configurations ........................................ 3-9

3.5 Creating a RAID driver disk.............................................. 3-10

3.6 Cool ‘n’ Quiet!™ Technology .............................................3-11

v

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference that
may cause undesired operation.

The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modifications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

Where to find more information

Refer to the following sources for additional information and for product and
software updates.

1. ASUS Websites

The ASUS website provides updated information on ASUS hardware and
software products. The ASUS websites are listed in the ASUS Contact
Information on the inside front cover.

2. Optional Documentation

Your product package may include optional documentation, such as warranty
flyers, that may have been added by your dealer. These documents are not
part of the standard package.

vi

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.

• When adding or removing devices to or from the system, ensure that the power
cables for the devices are unplugged before the signal cables are connected. If
possible, disconnect all power cables from the existing system before you add a
device.

• Before connecting or removing signal cables from the motherboard, ensure that
all power cables are unplugged.

• Seek professional assistance before using an adpater or extension cord. These
devices could interrupt the grounding circuit.

• Make sure that your power supply is set to the correct voltage in your area. If you
are not sure about the voltage of the electrical outlet you are using, contact your
local power company.

• If the power supply is broken, do not try to fix it by yourself. Contact a qualified
service technician or your retailer.

Operation safety

• Before installing the motherboard and adding devices on it, carefully read all the
manuals that came with the package.

• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product in any
area where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a qualified service
technician or your retailer.

vii

About this guide

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.

WARNING: Information to prevent injury to yourself when trying to
complete a task.

CAUTION: Information to prevent damage to the components when
trying to complete a task.

IMPORTANT: Information that you MUST follow to complete a task.

NOTE: Tips and additional information to aid in completing a task.

Typography

Bold text Indicates a menu or an item to select.

Italics Used to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign

indicates that you must press the enclosed key.
Example: <Enter> indicates that you must press the
Enter or Return key.

<Multiple key names> If you must press two or more keys simultaneously,

the key names are linked with a plus sign (+).
Example: <Ctrl+Alt+D>

Command Means that you must enter the command exactly as

shown then supply the appropriate values that
appear in brackets. Example:

At the DOS prompt, type the command line:

format a:\

viii

K8V-X SE specifications summary

CPU

Chipset

System Bus
Memory

Expansion slots

Storage

Audio

LAN

Socket 754 for AMD Athlon™ 64 / AMD Sempron™

processors

VIA K8T800
VIA VT8237R

800 MHz
2 x 184-pin DDR DIMM sockets for up to 2GB non-ECC

PC3200/PC2700/PC2100 SDRAM memory

1 x AGP 8X/4X
4 x PCI

South Bridge supports

- 2 x UltraATA 133 connectors

- 2 x SATA with RAID 0, RAID 1

ADI AD1888 SoundMAX
S/PDIF out interface support

Realtek® 8201CL LAN controller

®

6-channel audio CODEC

USB
Overclocking

Features

Special features

Back panel I/O

Maximum of eight (8) USB 2.0 ports
SFS (Stepless Frequency Selection) from 200 MHz up to

300 MHz at 1 MHz increment
Adjustable FSB/DDR ratio
ASUS JumperFree

ASUS C.P.R. (CPU Parameter Recall)
ASUS EZ Flash
ASUS CrashFree BIOS2
ASUS MyLogo™
ASUS Instant Music Lite
Cool ‘n’ Quiet!™ Technology

1 x Parallel port
1 x Serial port
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
1 x S/PDIF out
1 x RJ-45 port
Line In/Line Out/Microphone ports

(continued on the next page)

ix

K8V-X SE specifications summary

Internal I/O

BIOS features

Industry standard
Manageability
Power Requirement
Form Factor
Support CD contents

2 x USB 2.0 connector for 4 additional USB ports
CPU/Chassis fan connectors
20-pin/4-pin ATX 12V power connectors
CD/AUX connectors
S/PDIF out connector
Front panel audio connector

4Mb Flash EEPROM
AMI BIOS with enhanced ACPI, PnP, DMI, ASUS EZ Flash,
ASUS MyLogo, SM BIOS 2.3, Multi-Language BIOS,
CrashFree BIOS 2

PCI 2.2, USB 2.0/1.1
WOL by PME, WOR by PME
ATX power supply (with 4-pin 12V plug)
ATX form factor: 12 in x 7.6 in (30.5 cm x 24.5 cm)
Device drivers

ASUS PC Probe
Anti-virus utility

* Specifications are subject to change without notice.

x

Chapter 1

This chapter describes the features of the
motherboard. It includes brief descriptions of the
motherboard components, and illustrations of the
layout, jumper settings, and connectors.

Product introduction

1.1 Welcome!

Thank you for buying the ASUS® K8V-X SE motherboard!

The motherboard delivers a host of new features and latest technologies making it
another standout in the long line of ASUS quality motherboards!

The motherboard combines the powers of the AMD Athlon™ 64 processor and the
VIA K8T800 chipset to set a new benchmark for an effective desktop platform
solution.

Supporting up to 2GB of system memory with PC3200/PC2700/PC2100/PC1600
DDR SDRAM, high-resolution graphics via an AGP 8X slot, Serial ATA RAID, USB

2.0, and 6-channel audio features, the motherboard takes you ahead in the world
of power computing!

Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.

1.2 Package contents

Check your motherboard package for the following items.

ASUS K8V-X SE motherboard
ASUS motherboard support CD
1 x Ultra DMA 133/100/66 cables
1 x Serial ATA cable
1 x IDE cable
1 x Floppy disk cable
I/O shield
Bag of extra jumper caps
User guide

If any of the above items is damaged or missing, contact your retailer.

1-2

Chapter 1: Product introduction

1.3 Special features

1.3.1 Product Highlights

Latest processor technology

The motherboard supports the AMD Athlon™ 64 and AMD Sempron™ desktop
processors. The AMD Athlon™ 64 is based on AMD’s 64-bit architecture, which
represents the landmark introduction of the industry’s first x86-64 technology. This
processor provides a dramatic leap forward in compatibility, performance,
investment protection, and reduced total cost of ownership and development.

The AMD Sempron™ is a 32-bit processor that provides the performance needs of
value-conscious buyers. This processor is designed to deliver best-in-class
performance for everyday computing.

HyperTransport™ Technology

HyperTransport™ Technology is a high-speed, low latency, point-to-point link
designed to increase the communication speed between integrated circuits in
computers, networking and telecommunicatons equipment up to 48 times faster
than other existing technologies.

Cool ‘n’ Quiet!™ Technology

The motherboard supports the AMD® Cool ‘n’ Quiet!™ Technology that dynamically
and automatically changes the CPU speed, voltage and amount of power
depending on the task the CPU performs.

Serial ATA solution

The motherboard supports two interfaces compliant to the Serial ATA (SATA)
specification, an evolutionary replacement of the Parallel ATA storage interface.
The Serial ATA specification allows for thinner, more flexible cables with lower pin
count, reduced voltage requirement, up to 150 MB/s data transfer rate.

AGP 8X support

AGP 8X (AGP 3.0) is the VGA interface specification that enables enhanced
graphics performance with maximum bandwidth speeds of up to 2.12 GB/s.

S/PDIF out

The motherboard supports the S/PDIF technology through the S/PDIF interfaces
on the rear panel. The S/PDIF technology turns your computer into a high-end
entertainment system with digital connectivity to powerful audio and speaker
systems.

USB 2.0 technology

The motherboard implements the Universal Serial Bus 2.0 (USB 2.0) specification,
dramatically increasing the connection speed from the 12 Mbps bandwidth on USB

1.1 to a fast 480 Mbps on USB 2.0. USB 2.0 is backward compatible with USB 1.1.

ASUS K8V-X SE motherboard

1-3

6-Channel Audio solution

The motherboard uses an onboard audio CODEC that lets you enjoy high-quality
6-channel audio without having to buy advanced sound cards.

1.3.2 Unique ASUS features

CrashFree BIOS 2

This feature allows you to restore the original BIOS data from the ASUS support
CD in case when the BIOS codes and data are corrupted. This protection
eliminates the need to buy a replacement ROM chip. See page 2-6.

C.P.R. (CPU Parameter Recall)

The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the
BIOS default settings in case the system hangs due to overclocking. When the
system hangs due to overclocking, C.P.R. eliminates the need to open the system
chassis and clear the RTC data. Simply shut down and reboot the system, and
BIOS automatically restores the CPU previous setting for each parameter.

ASUS MyLogo™

This feature allows you to personalize and add style to your system with
customizable boot logos. See pages 2-32.

ASUS EZ Flash BIOS

With the ASUS EZ Flash, you can easily update the system BIOS even before
loading the operating system. No need to use a DOS-based utility or boot from a
floppy disk. See page 2-5.

Instant Music Lite

This unique feature allows you to playback audio CDs even without booting the
system to Windows®. Just press the ASUS Instant Music special function keys and
enjoy the music! See details on pages 2-26 and 3-6.

1-4

Chapter 1: Product introduction

1.4 Before you proceed

®

d

Take note of the following precautions before you install motherboard components
or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any
component.

2. Use a grounded wrist strap or touch a safely grounded object or to a metal
object, such as the power supply case, before handling components to
avoid damaging them due to static electricity.

3. Hold components by the edges to avoid touching the ICs on them.

4. Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.

5. Before you install or remove any component, ensure that the ATX
power supply is switched off or the power cord is detached from the
power supply. Failure to do so may cause severe damage to the
motherboard, peripherals, and/or components.

Onboard LED

The motherboard comes with a stand-by power LED. When lit, this green LED
indicates that the system is ON, in sleep mode, or in soft-off mode, a reminder that
you should shut down the system and unplug the power cable before removing or
plugging in any motherboard component. The illustration below shows the location
of the onboard LED.

K8V-X SE

K8V-X SE Onboard LED

ON

Standby

Power

SB_PWR

OFF

Powere

Off

ASUS K8V-X SE motherboard

1-5

1.5 Motherboard overview

19.2cm (7.6in)

1.5.1 Motherboard layout

PS/2KBMS
T: Mouse
B: Keyboard

SPDIF_O

KBPWR

PARALLEL PORT

ATX12V

CPU_FAN

COM1

F_USB12

Bottom:

USB3
USB4

Top:Line In
Center:Line Out
Below:Mic In

SPDIF_OUT

Top:

RJ-45

RTL8201CL

VIA

VT6421L

CD AUX

ADI

AD1888

4M

BIOS

USBPWR12
USBPWR34

FLOPPY

FP_AUDIO

ATXPWR

I/O

Accelerated Graphics Port (AGP)

Super

K8T800

PCI1

R

VIA

PCI2

PCI3

K8V-X SE

PCI4

Socket 754

USBPWR56
USBPWR78

USB56

VT8237R

CR2032 3V
Lithium Cell

CMOS Power

USB78

VIA

CLRTC

CHASSIS

DDR DIMM2 (64 bit,184-pin module)

DDR DIMM1 (64 bit,184-pin module)

30.5cm (12.0in)

SATA2

SATA1

CHA_FAN

PANEL

SB_PWR

SEC_IDE PRI_IDE

1-6

Chapter 1: Product introduction

®

1.5.2 Placement direction

When installing the motherboard, make sure that you place it into the chassis in
the correct orientation. The edge with external ports goes to the rear part of the
chassis as indicated in the image below.

1.5.3 Screw holes

Place nine (9) screws into the holes indicated by circles to secure the motherboard
to the chassis.

Do not overtighten the screws! Doing so may damage the motherboard.

Place this side towards
the rear of the chassis

K8V-X SE

ASUS K8V-X SE motherboard

1-7

1.6 Central Processing Unit (CPU)

®

1.6.1 Overview

The motherboard comes with a surface mount 754-pin Zero Insertion Force (ZIF)
socket designed for the AMD Athlon™ 64 processor.

The 128-bit-wide data paths of these processors can run applications faster than
processors with only 32-bit or 64-bit wide data paths.

K8V-X SE

K8V-X SE CPU Socket 754

Incorrect installation of the CPU into the socket may bend the pins and severely
damage the CPU!

Gold Arrow

1-8

Chapter 1: Product introduction

1.6.2 Installing the CPU

Follow these steps to install a CPU.

1. Locate the 754-pin ZIF socket on the motherboard.

2. Unlock the socket by pressing the
lever sideways, then lift it up to a
90°-100° angle.

Socket Lever

Make sure that the socket lever is lifted up to 90°-100° angle, otherwise the
CPU does not fit in completely.

3. Position the CPU above the socket
such that the CPU corner with the
gold triangle matches the socket
corner with a small triangle.

4. Carefully insert the CPU into the
socket until it fits in place.

The CPU fits only in one correct orientation. DO NOT force the CPU into the
socket to prevent bending the pins and damaging the CPU!

5. When the CPU is in place, push
down the socket lever to secure the
CPU. The lever clicks on the side tab
to indicate that it is locked.

Gold triangle

Small triangle

6. Install specifically designed heatsink
and fan assembly.

ASUS K8V-X SE motherboard

1-9

1.7 System memory

®

1.7.1 DIMM sockets location

The following figure illustrates the location of the DDR DIMM sockets.

DIMM1

DIMM2

K8V-X SE

K8V-X SE 184-pin DDR DIMM sockets

• Make sure to unplug the power supply before adding or removing DIMMs or
other system components. Failure to do so may cause severe damage to
both the motherboard and the components.

• When installing long AGP cards, it is recommended to install the memory
modules first. Long AGP cards, when installed, may interfere with the
memory sockets.

80 Pins 104 Pins

1.7.2 Memory configurations

You may install 64MB, 128MB, 256MB, 512MB, and 1GB DDR DIMMs into the
DIMM sockets using the memory configurations in this section.

Important notes

• Installing DDR DIMMs other than the recommended configurations may
cause memory sizing error or system boot failure.

• For optimum compatibility, obtain memory modules from qualified vendors.
See Qualified Vendors List on page 1-11.

• Stacked RAM and DDR DIMM modules with more than 18 chips are not
supported.

• Always install DIMMs with the same CAS Latency. For optimum
compatibility, obtain memory modules from the same vendors.

1-10

Chapter 1: Product introduction

DDR Qualified Vendor List

The following table lists the PC3200 (DDR400) memory modules that have been
tested and qualified for use with this motherboard.

DDR400 Qualified Vendor List (QVL)

Size Vendor Model Brand Side(s) Component A B

256MB KINGSTON KVR400X64C3A/256 Hynix SS HY5DU56822BT-D43 • •
512MB KINGSTON KVR400X64C3A/512 Hynix DS HY5DU56822BT-D43 • •
256MB KINGSTON KVR400X64C3A/256 Infineon SS HYB25D256800BT-5B • •
512MB KINGSTON KVR400X64C3A/512 Infineon DS HYB25D256809BT-5B • •
256MB KINGSTON KVR400X64C3A/256 KINGSTON SS D3208DL2T-5 • •
512MB KINGSTON KHX3200A/512 N/A DS N/A • •
1024MB KINGSTON KVR400X64C3A/1G N/A DS HYB25D512800BE-5B • •
1024MB KINGSTON KHX3200ULK2/1G N/A DS N/A • •
256MB SAMSUNG M368L3223ETM-CCC SAMSUNG SS K4H560838E-TCCC • •
256MB SAMSUNG M368L3223FTN-CCC SAMSUNG SS K4H560838F-TCCC • •
512MB SAMSUNG M368L6423FTN-CCC SAMSUNG DS K4H560838F-TCCC • •
512MB SAMSUNG M368L6523BTM-CCC SAMSUNG SS K4H510838B-TCCC • •
256MB MICRON MT8VDDT3264AG-40BCB MICRON SS MT46V32M8TG-5BC • •
512MB MICRON MT16VDDT6464AG-40BCB MICRON DS MT46V32M8TG-5BC • •
256MB Infineon HYS64D32300HU-5-C Infineon SS HYB25D256800CE-5C • •
512MB Infineon HYS64D64320HU-5-C Infineon DS HYB25D256800CE-5C • •
256MB Infineon HYS64D32301HU-5-C Infineon SS HYB25D512160CE-5C • •
512MB Infineon HYS64D64300HU-5-C Infineon SS HYB25D512800CE-5C • •
1024MB Infineon HYS64D128320HU-5-C Infineon DS HYB25D512800CE-5B • •
256MB CORSAIR CMX256A-3200C2PT Winbond SS W942508BH-5 • •
512MB CORSAIR CMX512-3200C2 Winbond DS N/A • •
512MB CORSAIR VS512MB400 VALUE seLecT DS VS32M8-5 • •
1024MB CORSAIR TWINX2048-3200C2 N/A DS N/A • •
256MB Hynix HYMD232645D8J-D43 Hynix SS HY5DU56822DT-D43 • •
512MB Hynix HYMD264646D8J-D43 Hynix DS HY5DU56822DT-D43 • •
256MB TwinMOS M2G9I08AIATT9F081AADT TwinMOS SS TMD7608F8E50D • •
512MB TwinMOS M2G9J16AJATT9F081AADT TwinMOS DS TMD7608F8E50D • •
512MB TwinMOS M2G9J16A8ATT9F081AADT TwinMOS DS TMD7608F8E50D • •
256MB Transcend TS32MLD64V4F3 SAMSUNG SS K4H560838F-TCCC •
256MB Apacer 77.10636.33G Infineon SS HYB25D256800CE-5C •
512MB Apacer 77.10736.33G Infineon DS HYB25D256800CE-5C •
256MB Apacer 77.10639.60G ProMOS SS V58C2256804SCT5B •
256MB A DATA MDOSS6F3G31Y0K1E0Z SAMSUNG SS K4H560838E-TCCC •
512MB A DATA MDOSS6F3H41Y0N1E0Z SAMSUNG DS K4H560838F-TCCC • •
256MB A DATA MDOHY6F3G31Y0N1E0Z Hynix SS HY5DU56822CT-D43 • •
512MB A DATA MDOHY6F3H41Y0N1E0Z Hynix DS HY5DU56822CT-D43 •
256MB A DATA MDOAD5F3G31Y0D1E02 N/A SS ADD8608A8A-5B •
512MB A DATA MDOAD5F3H41Y0D1E02 N/A DS ADD8608A8A-5B • •
256MB PSC AL5D8B53T-5B1K PSC SS A2S56D30BTP • •
512MB PSC AL6D8B53T-5B1K PSC DS A2S56D30BTP • •
256MB KINGMAX MPXB62D-38KT3R N/A SS KDL388P4LA-50 •
256MB NANYA NT256D64S88C0G-5T N/A SS NT5DS32M8CT-5T • •
512MB NANYA NT512D64S8HC0G-5T N/A DS NT5DS32M8CT-5T • •
256MB NANYA NT256D64SH4B0G-5T N/A SS NT5DS32M16BT-5T •
512MB NANYA NT512D64S88B0G-5T N/A DS NT5DS64M8BT-5T •
256MB BRAIN POWER B6U808-256M-SAM-400 SAMSUNG SS K4H560838D-TCC4 • •
512MB BRAIN POWER B6U808-512M-SAM-400 SAMSUNG DS K4H560838D-TCC4 •
512MB CENTURY DXV2S8SSCCE3K27E SAMSUNG DS K4H560838E-TCCC • •
512MB CENTURY DXV2S8EL5BM3T27C N/A DS DD2508AMTA • •
256MB elixir M2U25664DS88C3G-5T elixir SS N2DS25680CT-5T •
512MB elixir M2U51264DS8HC1G-5T elixir DS N2DS25680CT-5T • •

(Continued on the next page)

ASUS K8V-X SE motherboard

1-11

DDR400 Qualified Vendor List (QVL)

Size Vendor Model Brand Side(s) Component A B

256MB Kreton N/A VT SS VT3225804T-5 •
512MB Kreton N/A VT DS VT3225804T-5 • •
256MB Veritech VT400FMV/2561103 VT SS VT56DD32M8PC-5 •
512MB Veritech VT400FMV/5121003 VT DS VT56DD32M8PC-5 • •
256MB Pmi MD44256VIT3208GMHA01 MOSEL SS V58C2256804SAT5B • •
512MB Pmi MD44512VIT3208GATA03 MOSEL DS V58C2256804SAT5B • •
256MB ProMOS V826632K24SCTG-D0 N/A SS V58C2256804SCT5B • •
512MB ProMOS V826664K24SCTG-D0 N/A DS V58C2256804SCT5B • •
256MB Deutron AL5D8C53T-5B1T PSC SS A2S56D30CTP •
512MB Deutron AL6D8C53T-5B1T PSC DS A2S56D30CTP • •
256MB GEIL GL5123200DC N/A SS GL3LC32G88TG-35 •
512MB GEIL GL1GB3200DC N/A DS GL3LC32G88TG-35 • •
256MB GEIL GLX2563200UP N/A SS GL3LC32G88TG-5A • •
256MB crucial BL3264Z402.8TG Ballistix SS N/A • •
512MB crucial BL6464Z402.16TG Ballistix DS N/A • •
256MB Novax 96M425653CE-40TB6 CEON SS C2S56D30TP-5 •
256MB Aeneon AED560UD00-500C88X Aeneon SS AED83T500 • •
256 CORSAIR CMX256A-3200LL DDR400 N/A DS N/A • •
512 CORSAIR CMX512-3500LL DDR400 N/A DS N/A • •
256 CORSAIR VS256MB400 CORSAIR SS VS32M8-5 2B0409 • •
256 HYNIX HYMD232646B8J-D43 HYNIX SS N/A • •
256 HYNIX HYMD232646D8J-D43 AA HYNIX SS HY5DU56822DT-D43 • •
256 INFINEON HYS64D32300GU-5-C INFINEON SS HYB25D256800CE-5-C • •
256 INFINEON HYS64D32300HU-5-C INFINEON SS HYB25D256800CE-5C • •
512 KINGSTON KVR400X64C3A/512 KINGSTON DS D3208DH1T-5 •
512 KINGSTON VALUE RAM KVR400X64C3A/512 DDR HYNIX DS HY5DU56822DT-D43 • •
256 KINGSTON VALUERAM KVR400X64C3A/256 KINGSTON SS D3208DH1T-5 • •
512 MICRON MT16VDDT6464AG-40BC4 MICRON DS MT46V32M8TG-5BG •
512 MICRON MT16VDDT6464AG-40BGB MICRON DS MT46V32M8TG-5BG •
256 MICRON MT8VDDT3264AG-40BGB MICRON SS MT46V32M8TG-5BG • •
256 SAMSUNG M368L3223FTN-CCC SAMSUNG SS K4H560838F-TCCC • •
512 SAMSUNG M368L6423FTN-CCC SAMSUNG DS K4H560838F-TCCC • •
256 APACER 77.10636.115 INFINEON SS HYB25D256800BT-5B •
256 APACER 77.10636.11G INFINEON SS HYB25D256800BT-5B • •
512 APACER 77.10736.11G INFINEON DS HYB25D256800BT-5B • •
256 BRAIN POWER B6U808-256M-SAMSUNG SAMSUNG SS K4H560838D-TCC4 • •
256 GEIL N/A GEIL SS GL3LC32G88TG-5A • •
512 KINGMAX MPXC22D-38KT3R KINGMAX DS KDL388P4LA-50 • •
256 KINGMAX MPXB62D-38KT3R KINGMAX SS KDL388P4LA-50 • •
512 NANYA NT512D64S8HB1G-5T NANYA DS NT5DS3232M8BT-5T • •
256 PROMOS V826632K24SCTG-D0 MOSEL SS V58C2256804SCT5B • •
256 TRANSCEND TS32MLD64V4F3 MOSEL SS V58C2256804SAT5B •
512 WINBOND U24512ADWBG6H20 WINBOND DS W942508CH-5 • •

Legend:

Side(s): SS - Single Sided DS - Double Sided
A : Supports one module inserted in any slot as Single-channel memory configuration

B : Supports one pair of modules inserted in two slot as Single-channel memory

configuration.

Visit the ASUS website (www.asus.com) for the latest DDR 400 Qualified
Vendor List for this motherboard.

Obtain DDR DIMMs only from ASUS qualified vendors for better system
performance.

1-12

Chapter 1: Product introduction

1.7.3 Installing a DIMM

Follow these steps to install a DIMM.

1. Unlock a DIMM socket by pressing the
retaining clips outward.

2. Align a DIMM on the socket such that the
notch on the DIMM matches the break on
the socket.

3. Firmly insert the DIMM into the socket
until the retaining clips snap back in place
and the DIMM is properly seated.

A DDR DIMM is keyed with a notch so that it fits in only one direction. DO NOT
force a DIMM into a socket to avoid damaging the DIMM.

1.8 Expansion slots

To install and configure an expansion card:

DDR DIMM

Unlocked

1. Install an expansion card following the instructions that came with the chassis.

2. Turn on the system and change the necessary BIOS settings, if any. See
Chapter 2 for BIOS information.

3. Assign an IRQ to the card. Refer to the tables next page.

4. Install the drivers and/or software applications for the expansion card
according to the card documentation.

1.8.1 Standard interrupt assignments

IRQ Priority Standard Function

0 1 System Timer
1 2 Keyboard Controller
2 N/A Programmable Interrupt
3* 11 IRQ holder for PCI steering
4* 12 Communications Port (COM1)
5* 13 IRQ holder for PCI steering
6 14 Floppy Disk Controller
7* 15 Printer Port (LPT1)
8 3 System CMOS/Real Time Clock
9* 4 IRQ holder for PCI steering
10* 5 IRQ holder for PCI steering
11* 6 IRQ holder for PCI steering
12* 7 PS/2 Compatible Mouse Port
13 8 Numeric Data Processor
14* 9 Primary IDE Channel
15* 10 Secondary IDE Channel

* These IRQs are usually available for ISA or PCI devices.

ASUS K8V-X SE motherboard

1-13

1.8.2 IRQ assignments for this motherboard

INT A INT B INT C INT D

PCI slot 1 shared — — —
PCI slot 2 — shared — —
PCI slot 3 — — shared —
PCI slot 4 — — — used
LAN — shared — —
AGP slot shared — — —
Onboard Audio — — shared —
Onboard USB — — shared —
Onboard RAID — shared — —

When using PCI cards on shared slots, ensure that the drivers support “Share
IRQ” or that the cards do not need IRQ assignments. Otherwise, conflicts will
arise between the two PCI groups, making the system unstable and the card
inoperable.

1.8.3 PCI slots

The PCI slots support PCI cards such as a LAN card, SCSI card, USB card, and
other cards that comply with PCI specifications.

1-14

Chapter 1: Product introduction

1.8.4 AGP slot

®

The Accelerated Graphics Port (AGP) slot supports AGP 8X/4X (+1.5V) cards.
When you buy an AGP card, make sure that you ask for one with +1.5V
specification.

Note the notches on the card golden fingers to ensure that they fit the AGP slot on
the motherboard.

Install only +1.5V AGP cards.

K8V-X SE

Keyed for 1.5v

K8V-X SE Accelerated Graphics Port (AGP)

If installing the ATi 9500 or 9700 Pro Series VGA cards, use only the card
version PN xxx-xxxxx-30 or later, for optimum performance and overclocking
stability.

ASUS K8V-X SE motherboard

1-15

1.9 Jumpers

®

S

1. Clear RTC RAM (CLRTC)

This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS.
You can clear the CMOS memory of date, time, and system setup parameters
by erasing the CMOS RTC RAM data. The RAM data in CMOS, that include
system setup information such as system passwords, is powered by the
onboard button cell battery.

To erase the RTC RAM:

1. Turn OFF the computer and unplug the power cord.

2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on
pins 2-3 for about 5~10 seconds, then move the cap back to pins 1-2.

3. Plug the power cord and turn ON the computer.

4. Hold down the <Del> key during the boot process and enter BIOS setup to
re-enter data.

Except when clearing the RTC RAM, never remove the cap on the jumper
default position. Removing the cap will cause system boot failure!

K8V-X SE

K8V-X SE Clear RTC RAM

You do not need to clear the RTC when the system hangs due to overclocking.
For system failure due to overclocking, use the C.P.R. (CPU Parameter Recall)
feature. Shut down and reboot the system so BIOS can automatically reset
parameter settings to its previous values.

CLRTC

12

Normal Clear CMO

(Default)

23

1-16

Chapter 1: Product introduction

2. Keyboard power (3-pin KBPWR)

®

t)

R

3

B

3

B

USBPWR12

This jumper allows you to enable or disable the keyboard wake-up feature. Set
this jumper to pins 2-3 (+5VSB) if you wish to wake up the computer when you
press a key on the keyboard. This feature requires an ATX power supply that
can supply at least 1A on the +5VSB lead, and a corresponding setting in the
BIOS.

KBPWR

3
2
1

+5V +5VSB

K8V-X SE

K8V-X SE Keyboard power setting

2

(Defaul

3. USB device wake-up (3-pin USBPWR12, USBPWR34, USBPWR56,
USBPWR78)

Set these jumpers to +5V to wake up the computer from S1 sleep mode (CPU
stopped, DRAM refreshed, system running in low power mode) using the
connected USB devices. Set to +5VSB to wake up from S3 and S4 sleep
modes (no power to CPU, DRAM in slow refresh, power supply in reduced
power mode).

USBPWR34

2

2

K8V-X SE

K8V-X SE USB device wake up

21

+5V +5VS

(Default)

USBPWR56
USBPWR78

21

+5V +5VS

(Default)

• The USB device wake-up feature requires a power supply that can provide
500mA on the +5VSB lead for each USB port. Otherwise, the system would
not power up.

• The total current consumed must NOT exceed the power supply capability
(+5VSB) whether under normal condition or in sleep mode.

ASUS K8V-X SE motherboard

1-17

1.10 Connectors

RJ45

1

4
5
6

2 3

This section describes and illustrates the motherboard rear panel and internal
connectors.

1.10.1 Rear panel connectors

11

1. PS/2 mouse port. This green 6-pin connector is for a PS/2 mouse.

2. Parallel port. This 25-pin port connects a parallel printer, a scanner, or other

devices.

3. RJ-45 port. This port allows connection to a Local Area Network (LAN) through
a network hub. Refer to the table below for the LAN port LED indications.

910

8

7

LAN port LED indications

ACT/LINK LED SPEED LED

Status Description Status Description

OFF No link OFF No Link
Orange 100Mbps connection Green 10Mbps connection
Blinking Acting Blinking Acting

4. Line In jack. This Line In (light blue) jack connects a tape player or other audio
sources. In 6-channel mode, the function of this jack becomes Bass/Center.

SPEEDACT/LNK

5. Line Out jack. This Line Out (lime) jack connects a headphone or a speaker.
In 6-channel mode, the function of this jack becomes Front Speaker Out.

6. Microphone jack. This Mic (pink) jack connects a microphone. In 6-channel
mode, the function of this jack becomes Rear Speaker Out.

The functions of the Line Out, Line In, and Microphone jacks change when you
select the 6-channel audio configuration as shown in the following table.

1-18

Chapter 1: Product introduction

Audio 2, 4 or 6-channel configuration

Headphone/
2-Speaker 4-Speaker 6-Speaker

Light Blue Line In Line In Bass/Center
Lime Line Out Front Speaker Out Front Speaker Out
Pink Mic In Rear Speaker Out Rear Speaker Out

7. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports are
available for connecting USB 2.0 devices.

8. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports are
available for connecting USB 2.0 devices.

9. Serial connector. This 9-pin COM1 port is for serial devices.

10. S/PDIF out jack. This jack connects to external audio output devices.

11. PS/2 keyboard port. This purple connector is for a PS/2 keyboard.

ASUS K8V-X SE motherboard

1-19

1.10.2 Internal connectors

®

s

®

n

1. IDE connectors (40-1 pin PRI_IDE, SEC_IDE)

This connector supports the provided UltraATA133 IDE hard disk ribbon cable.
Connect the cable’s blue connector to the primary (recommended) or secondary
IDE connector , then connect the gray connector to the UltraATA133 slave device
(hard disk drive) and the black connector to the UltraATA133 master device.

• Follow the hard disk drive documentation when setting the device in master
or slave mode.

• Pin 20 on each IDE connector is removed to match the covered hole on the
UltraATA cable connector. This prevents incorrect orientation when you
connect the cables.

• The hole near the blue connector on the UltraATA cable is intentional.

PRI_IDE

K8V-X SE

NOTE: Orient the red marking

SEC_IDE

K8V-X SE IDE connectors

(usually zigzag) on the IDE
ribbon cable to PIN 1.

2. Floppy disk drive connector (34-1 pin FLOPPY)

This connector supports the provided floppy drive ribbon cable. After
connecting one end to the motherboard, connect the other end to the floppy
drive. (Pin 5 is removed to prevent incorrect insertion when using ribbon cables
with pin 5 plug).

FLOPPY

PIN 1

K8V-X SE

NOTE: Orient the red markings o

the floppy ribbon cable to PIN 1.

K8V-X SE Floppy disk drive connector

1-20

Chapter 1: Product introduction

3. ATX power connectors (20-pin ATXPWR, 4-pin ATX12V)

®

ATX12V

®

l

These connectors connect to an ATX 12V power supply. The plugs from the
power supply are designed to fit these connectors in only one orientation. Find
the proper orientation and push down firmly until the connectors completely fit.

In addition to the 20-pin ATX power connector, this motherboard requires that
you connect the 4-pin ATX +12V power plug to provide sufficient power to the
CPU.

Make sure that your ATX 12V power supply can provide 8A on the +12V lead
and at least 1A on the +5-volt standby lead (+5VSB). The minimum
recommended wattage is 300W or 350W for a fully configured system. The
system may become unstable and may experience difficulty powering up if the
power supply is inadequate.

+12V DCGND

ATXPWR

+12.0VDC

+5VSB

PWR_OK

COM

+5.0VDC

COM

+5.0VDC

COM
+3.3VDC
+3.3VDC

Pin 1

+5.0VDC
+5.0VDC

-5.0VDC
COM
COM
COM
PS_ON#
COM

-12.0VDC
+3.3VDC

+12V DCGND

K8V-X SE

K8V-X SE ATX power connectors

4. Internal audio connectors (4-pin CD, AUX)

These connectors allow you to receive stereo audio input from sound sources
such as a CD-ROM, TV tuner, or MPEG card.

CD (Black)

K8V-X SE

K8V-X SE Internal audio connectors

AUX (White)

Left Audio Channel
Ground
Right Audio Channe

ASUS K8V-X SE motherboard

1-21

5. CPU and chassis fan connectors (3-pin CPU_FAN, CHA_FAN)

®

®

The fan connectors support cooling fans of 350mA~740mA (8.88W max.) or a
total of 1A~2.22A (26.64W max.) at +12V. Connect the fan cables to the fan
connectors on the motherboard, making sure that the black wire of each cable
matches the ground pin of the connector.

Do not forget to connect the fan cables to the fan connectors. Lack of sufficient
air flow within the system may damage the motherboard components. These
are not jumpers! DO NOT place jumper caps on the fan connectors!

CPU_FAN

GND

+12V

Rotation

CHA_FAN

K8V-X SE

GND

Rotation

+12V

K8V-X SE Fan connectors

6. USB header (10-1 pin USB56, USB78)

If the USB ports on the rear panel are inadequate, a USB header is available
for additional USB ports. Connect the USB cable of the USB 2.0 module to this
header. You may install the USB module in the chassis front panel. The
module has two USB 2.0 ports for connecting next generation USB peripherals
such as high resolution cameras, scanners, and printers.

USB+5V

USB_P6-

USB_P6+

GND

K8V-X SE

USB56

NC

USB78

1

1

USB+5V

USB_P8-

USB_P8+

GND

NC

K8V-X SE USB 2.0 connectors

USB+5V

USB_P5-

USB_P5+

GND

USB+5V

USB_P7-

USB_P7+

GND

• The USB 2.0 module is purchased separately.

• Install the USB 2.0 driver before using the USB 2.0 feature.

1-22

Chapter 1: Product introduction

7. Front panel audio connector (10-1 pin FP_AUDIO)

®

®

t)

This is an interface for the front panel cable that allows convenient connection
and control of audio devices.

Be default, the pins labeled LINE OUT_R/BLINE_OUT_R and the pins
LINE OUT_L/BLINE_OUT_L are shorted with jumper caps. Remove the caps
only when you are connecting the front panel audio cable.

FP_AUDIO

BLINE_OUT_L

BLINE_OUT_R

K8V-X SE

+5VA

AGND

K8V-X SE Front panel audio connector

Line out_L
NC
Line out_R
MICPWR
MIC2

8. Chassis intrusion connector (4-1 pin CHASSIS1)

This lead is for a chassis designed with intrusion detection feature. This
requires an external detection mechanism such as a chassis intrusion sensor
or microswitch. When you remove any chassis component, the sensor triggers
and sends a high-level signal to this lead to record a chassis intrusion event.

By default, the pins labeled “Chassis Signal” and “Ground” are shorted with a
jumper cap. If you wish to use the chassis intrusion detection feature, remove
the jumper cap from the pins.

+5VSB_MB

Chassis Signal

GND

K8V-X SE

CHASSIS1

(Defaul

K8V-X SE Chassis intrusion connector

ASUS K8V-X SE motherboard

1-23

9. Serial ATA connectors (7-pin SATA1, SATA2)

®

®

These next generation connectors support the thin Serial ATA cables for
primary internal storage devices. The current Serial ATA interface allows up to
150 MB/s data transfer rate, faster than the standard parallel ATA with 133MB/s
(Ultra A T A/133).

SATA2

GND
RSATA_TXP2
RSATA_TXN2

GND
RSATA_RXP2

RSATA_RXN2

GND

SATA1

GND

RSATA_TXP1
RSATA_TXN1

GND

RSATA_RXP1

K8V-X SE

K8V-X SE SATA connectors

RSATA_RXN1

GND

10. Digital Audio connector (6-1 pin SPDIF_OUT)

This connector is for the S/PDIF audio module to allow digital sound output.
Connect one end of the S/PDIF audio cable to this connector and the other
end to the S/PDIF module.

SPDIF_OUT

GND

SPDIFOUT

K8V-X SE

K8V-X SE Digital audio connector

The S/PDIF out module is purchased separately.

+5V

1-24

Chapter 1: Product introduction

11. System panel connector (10-1 pin PANEL)

®

.

This connector accommodates several system front panel functions.

PLED

PLED+

PLED-

SPEAKER

Speaker

Ground

+5V

Ground

PANEL

PWR

Reset

Ground

Ground

RESET

PWRSW

K8V-X SE

IDE_LED-

IDE_LED+

IDE_LED

* Requires an ATX power supply

K8V-X SE System panel connector

• System Power LED Lead (Green 3-pin PLED)

This 3-pin connector connects to the system power LED. The LED lights up
when you turn on the system power, and blinks when the system is in sleep
mode.

• System Warning Speaker Lead (Orange 4-pin SPEAKER)

This 4-pin connector connects to the case-mounted speaker and allows you to
hear system beeps and warnings.

• Reset Switch Lead (Blue 2-pin RESET)

This 2-pin connector connects to the case-mounted reset switch for rebooting
the system without turning off the system power.

• ATX Power Switch / Soft-Off Switch Lead (Light Green 2-pin PWRSW )

This connector connects a switch that controls the system power. Pressing the
power switch turns the system between ON and SLEEP, or ON and SOFT
OFF, depending on the BIOS or OS settings. Pressing the power switch while
in the ON mode for more than 4 seconds turns the system OFF.

• Hard disk activity LED (Red 2-pin IDE_LED)

This connector supplies power to the hard disk activity LED. Any read or write
activity of an IDE device cause this LED to light up.

The System Panel connector is color-coded for easy and foolproof connection.
Take note of the specific connector colors as described.

ASUS K8V-X SE motherboard

1-25

1-26

Chapter 1: Product introduction

Chapter 2

This chapter tells how to change system settings
through the BIOS Setup menus. Detailed
descriptions of the BIOS parameters are also
provided.

BIOS information

ASUS K8V-X SE motherboard

2-1

2.1 Managing and updating your BIOS

The following utilities allow you to manage and update the motherboard Basic
Input/Output System (BIOS) setup.

1. ASUS AFUDOS - Updates the BIOS using a bootable floppy disk in DOS
mode.

2. ASUS EZ Flash - Updates the BIOS using a floppy disk during POST.

3. ASUS CrashFree BIOS 2 - Updates the BIOS using a bootable floppy disk or
the motherboard support CD.

Refer to the corresponding sections for details on these utilities.

Important notes

• It is recommended that you save a copy of the original motherboard
BIOS file to a bootable floppy disk in case you need to restore the BIOS

in the future. Copy the original motherboard BIOS using AFUDOS (refer to
section “2.1.3 Using AFUDOS to copy BIOS from PC”)

• Visit the ASUS website and download the latest BIOS file for this
motherboard using the ASUS Update utility.

2.1.1 Creating a bootable floppy disk

1. Do either one of the following to create a bootable floppy disk.

DOS environment

Insert a 1.44 MB floppy disk into the drive. At the DOS prompt, type:

format A:/S then press <Enter>.

®

Windows

a. Insert a 1.44 MB floppy disk into the floppy disk drive.
b. From your Windows desktop, click on Start, then select My Computer.
c. Select the 3 1/2 Floppy Drive icon.
d. Click File from the menu, then select Format. A Format 3 1/2 Floppy Disk

window appears.

e. If you are using Windows

from the format options field, then click Start.
OR
If you are using Windows

format type, then click Start.

Windows

To create a set of boot disks for Windows
from the Windows® 2000 CD:

98SE/ME/XP environment

®

XP, select Create an MS-DOS startup disk

®

98SE/ME, select Full option button from the

®

2000 environment

®

2000, run the Makeboot.exe tool

2-2

a. Insert a 1.44 MB floppy disk into the floppy disk drive.

®

b. Insert the Windows

2000 CD into the CD-ROM drive.

Chapter 2: BIOS Setup

c. Click Start, then select Run.
d. From the Open box, type

D:\bootdisk\makeboot a: then press <Enter>,
assuming that D: is your CD-ROM drive.

e. Follow succeeding screen instructions.

2. Copy the original (or the latest) motherboard BIOS to the bootable floppy disk.

2.1.2 Using AFUDOS to update the BIOS

To update the BIOS using the AFUDOS.EXE utility:

1. Visit the ASUS website (www.asus.com) to download the latest BIOS file for
your motherboard. Save the BIOS file to a bootable floppy disk.

Write the BIOS file name on a piece of paper. You need to type the exact BIOS
file name at the prompt.

2. Copy the AFUDOS.EXE utility from the support CD to the bootable floppy disk
that contains the BIOS file.

3. Boot the system from the floppy disk.

4. At the DOS prompt, type the command line:

afudos /i[filename]

where [filename] means the latest (or original) BIOS file that you copied to
the bootable floppy disk.

5. Press <Enter>. The succeeding screen displays the status of the update
process.

The BIOS information on the screen is for reference only. What you see on your
screen may not be exactly the same as shown.

A:\>afudos /iK8VXSE.ROM
AMI Firmware Update Utility - Version 1.10
Copyright (C) 2002 American Megatrends, Inc. All rights reserved.

Reading file ..... done

Erasing flash .... done

Writing flash .... 0x0008CC00 (9%)

DO NOT shutdown or reset the system while updating the BIOS! Doing so may
cause system boot failure!

ASUS K8V-X SE motherboard

2-3

When the BIOS update process is complete, the utility returns to the DOS
prompt.

A:\>afudos /iK8VXSE.ROM
AMI Firmware Update Utility - Version 1.10
Copyright (C) 2002 American Megatrends, Inc. All rights reserved.

Reading file ..... done

Erasing flash .... done

Writing flash .... 0x0008CC00 (9%)

Verifying flash .. done

A:\>

5. Reboot the system from the hard disk.

2.1.3 Using AFUDOS to copy BIOS from PC

You can use the AFUDOS.EXE utility to copy the current system BIOS to a floppy
or hard disk and use it as a backup in case the system BIOS fails or gets
corrupted.

To copy the BIOS from your PC using AFUDOS.EXE:

1. At the DOS prompt, type the command line:

afudos /o[filename]

where [filename] string of not more than eight (8) alpha-numeric characters
for the main filename and three (3) alpha-numeric characters for the extension
name.

2. Press <Enter>.

The BIOS information on the screen is for reference only. What you see on your
screen may not be exactly the same as shown.

Main filename

Extension name

A:\>afudos /oMYBIOS03.rom

AMI Firmware Update Utility - Version 1.10

Copyright (C) 2002 American Megatrends, Inc. All rights reserved.

2-4

Reading flash ..... 0x0008CC00 (9%)

Chapter 2: BIOS Setup

3. The utility will copy the current system BIOS by default to the floppy disk. Make
sure that the floppy disk has at least 600KB of free disk space and is not write­protected.

A:\>afudos /oMYBIOS03.ROM
AMI Firmware Update Utility - Version 1.10
Copyright (C) 2002 American Megatrends, Inc. All rights reserved.

Reading flash ..... done

A:\>

When the copy process is complete, the utility returns to the DOS prompt.

2.1.4 Using ASUS EZ Flash to update the BIOS

The ASUS EZ Flash feature allows you to easily update the BIOS without having to
go through the long process of booting from a diskette and using a DOS-based
utility. The EZ Flash is built-in the BIOS firmware so it is accessible by simply
pressing <Alt + F2> during the Power-On Self Tests (POST).

To update the BIOS using ASUS EZ Flash:

1. Visit the ASUS website (www.asus.com) to download the latest BIOS file for
your motherboard and rename the downloaded file as K8VXSE.ROM. Save
the BIOS file to a floppy disk.

2. Reboot the system.

3. To launch EZ Flash, press <Alt+F2> during POST to display the following.

User recovery requested. Starting BIOS recovery...

Checking for floppy...

• If there is no floppy disk in the drive, the error message
“Floppy not found!” appears.

• If the correct BIOS file is not in the floppy disk, the error message “Floppy
not found!” is displayed. Make sure to rename the downloaded BIOS file as
“K8VXSE.ROM”.

4. Insert the floppy disk that contains the BIOS file. If all the necessary files are
found in the floppy disk, EZ Flash performs the BIOS update process and
automatically reboots the system when done.

ASUS K8V-X SE motherboard

2-5

DO NOT shutdown or reset the system while updating the BIOS! Doing so may
cause system boot failure!

User recovery requested. Starting BIOS recovery...
Checking for floppy...
Floppy found!
Reading file “K8VXSE.ROM”. Completed.
Start flashing...

Flashed successfully. Rebooting.

2.1.5 Recovering the BIOS with CrashFree BIOS 2

The CrashFree BIOS 2 auto recovery tool allows you to restore BIOS from the
motherboard support CD, or from a floppy disk that contains the BIOS file, in case
the current BIOS on the motherboard fails or gets corrupted.

• Prepare the support CD that came with the motherboard or a floppy disk
that contains the motherboard BIOS before proceeding with the BIOS
update process.

• If you have saved a copy of the original motherboard BIOS to a bootable
floppy disk, you may also use this disk to restore the BIOS. See section
“2.1.1 Creating a bootable floppy disk.”

To recover the BIOS from a floppy disk:

1. Boot the system.

2. When a corrupted BIOS is detected, the following screen message appears.

Bad BIOS checksum. Starting BIOS recovery...

Checking for floppy...

3. Insert a floppy disk that contains the original or the latest BIOS file for this
motherboard. If all the necessary files are found in the floppy disk, the BIOS
update process continues.

Make sure that the BIOS file in the floppy disk is renamed as “K8VXSE.ROM”.

2-6

Chapter 2: BIOS Setup

Bad BIOS checksum. Starting BIOS recovery...
Checking for floppy...
Floppy found!
Reading file “K8VXSE.ROM”. Completed.

Start flashing...

DO NOT shut down or reset the system while updating the BIOS! Doing so may
cause system boot failure!

2. When the BIOS update process is complete, reboot the system.

To recover the BIOS from the support CD:

1. Boot the system.

2. When a corrupted BIOS is detected, the following screen message appears.

Bad BIOS checksum. Starting BIOS recovery...
Checking for floppy...

If there is no floppy disk found in the drive, the system automatically checks the
CD-ROM.

3. Place the support CD in the CD-ROM. The support CD contains the a working
BIOS for this motherboard.

Bad BIOS checksum. Starting BIOS recovery...
Checking for floppy...
Floppy not found!
Checking for CD-ROM...
CD-ROM found.
Reading file “K8VXSE.ROM”. Completed.

Start flashing...

DO NOT shut down or reset the system while updating the BIOS! Doing so may
cause system boot failure!

2. When the BIOS update process is complete, reboot the system.

The recovered BIOS may not be the latest BIOS version for this motherboard.
Visit ASUS website (www.asus.com) to download the latest BIOS file.

ASUS K8V-X SE motherboard

2-7

2.2 BIOS Setup program

This motherboard supports a programmable firmware chip that you can update
using the provided utility described in section “2.1 Managing and updating your
BIOS.”

Use the BIOS Setup program when you are installing a motherboard, reconfiguring
your system, or prompted to “Run Setup”. This section explains how to configure
your system using this utility.

Even if you are not prompted to use the Setup program, you may want to change
the configuration of your computer in the future. For example, you may want to
enable the security password feature or change the power management settings.
This requires you to reconfigure your system using the BIOS Setup program so
that the computer can recognize these changes and record them in the CMOS
RAM of the firmware hub.

The firmware hub on the motherboard stores the Setup utility. When you start up
the computer, the system provides you with the opportunity to run this program.
Press <Del> during the Power-On Self Test (POST) to enter the Setup utility.
Otherwise, POST continues with its test routines.

If you wish to enter Setup after POST, restart the system by pressing
<Ctrl+Alt+Delete>, or by pressing the reset button on the system chassis. You can
also restart by turning the system off and then back on. Do this last option only if
the first two failed.

The Setup program is designed to make it as easy to use as possible. It is a menu­driven program, which means you can scroll through the various sub-menus and
make your selections from the available options using the navigation keys.

The default BIOS settings for this motherboard apply for most conditions to
ensure optimum performance. If the system becomes unstable after changing
any BIOS settings, load the default settings to ensure system compatibility and
stability. Select the Load Default Settings item under the Exit Menu. See
section “2.7 Exit Menu.”

The BIOS setup screens shown in this chapter are for reference purposes only,
and may not exactly match what you see on your screen.

Visit the ASUS website (www.asus.com) to download the latest product and
BIOS information.

2-8

Chapter 2: BIOS Setup

2.2.1 BIOS menu screen

Menu items

System Time [11:51:19]
System Date [Thu 08/05/2003]
Legacy Diskette A [1.44M, 3.5 in]

Primary IDE Master :[ST320413A]
Primary IDE Slave :[ASUS CD-S340]
Secondary IDE Master :[Not Detected]
Secondary IDE Slave :[Not Detected]

System Information

Configuration fields

Sub-menu items

General helpMenu bar

Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.

Use [+] or [-] to
configure system time.

Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit

Navigation keys

2.2.2 Menu bar

The menu bar on top of the screen has the following main items:

Main For changing the basic system configuration
Advanced For changing the advanced system settings
Power For changing the advanced power management (APM)

configuration

Boot For changing the system boot configuration
Exit For selecting the exit options and loading default settings

To select an item on the menu bar, press the right or left arrow key on the keyboard
until the desired item is highlighted.

2.2.3 Navigation keys

At the bottom right corner of a menu screen are the navigation keys for that
particular menu. Use the navigation keys to select items in the menu and change
the settings.

Some of the navigation keys differ from one screen to another.

ASUS K8V-X SE motherboard

2-9

2.2.4 Menu items

The highlighted item on the menu bar
displays the specific items for that menu. For
example, selecting Main shows the Main
menu items.

System Time [11:51:19]
System Date [Thu 08/05/2003]
Legacy Diskette A [1.44M, 3.5 in]
Language [English]

Primary IDE Master :[ST320413A]
Primary IDE Slave :[ASUS CD-S340]
Secondary IDE Master :[Not Detected]
Secondary IDE Slave :[Not Detected]

System Information

Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.

Use [+] or [-] to
configure system time.

Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit

The other items (Advanced, Power, Boot,
and Exit) on the menu bar have their

Main menu items

respective menu items.

2.2.5 Sub-menu items

An item with a sub-menu on any menu screen is distinguished by a solid triangle
before the item. To display the sub-menu, select the item and press <Enter>.

2.2.6 Configuration fields

These fields show the values for the menu items. If an item is user- configurable,
you may change the value of the field opposite the item. You can not select an item
that is not user-configurable.

A configurable field is enclosed in brackets, and is highlighted when selected. To
change the value of a field, select it then press <Enter> to display a list of options.
Refer to “2.2.7 Pop-up window.”

2.2.7 Pop-up window

Select a menu item then press Enter to display a pop-up window with the
configuration options for that item.

2.2.8 Scroll bar

A scroll bar appears on the right side of a
menu screen when there are items that do
not fit on the screen. Press Up/Down
arrow keys or PageUp/PageDown keys
to display the other items on the screen.

2.2.9 General help

At the top right corner of the menu screen
is a brief description of the selected item.

Primary Graphics Adapter [AGP]
Search for MDA Resources [Yes]

AGP Mode [AGP 8X]
AGP Fast Write [Enabled]
Graphics Aperture Size [64MB]

Pop-up window

Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit

Scroll bar

2-10

Chapter 2: BIOS Setup

2.3 Main menu

When you enter the BIOS Setup program, the Main menu screen appears giving
you an overview of the basic system information.

Refer to section “2.2.1 BIOS menu screen” for information on the menu screen
items and how to navigate through them.

System Time [11:51:19]
System Date [Thu 03/30/2005]
Legacy Diskette A [1.44M, 3.5 in]

Primary IDE Master : [ST320413A]
Primary IDE Slave : [ASUS CD-S340]
Secondary IDE Master : [Not Detected]
Secondary IDE Slave : [Not Detected]

System Information

Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.

Use [+] or [-] to
configure system time.

2.3.1 System Time [xx:xx:xxxx]

Allows you to set the system time.

2.3.2 System Date [Day xx/xx/xxxx]

Allows you to set the system date.

2.3.3 Legacy Diskette A [1.44M, 3.5 in.]

Sets the type of floppy drive installed.
Configuration options: [Disabled] [360K, 5.25 in.] [1.2M , 5.25 in.] [720K , 3.5 in.]
[1.44M, 3.5 in.] [2.88M, 3.5in.]

ASUS K8V-X SE motherboard

2-11

2.3.4 Primary and Secondary IDE Master/Slave

While entering Setup, BIOS auto-detects the presence of IDE devices. There is a
separate sub-menu for each IDE device. Select a device item then press <Enter>
to display the IDE device information.

Primary IDE Master

Device : Hard Disk
Vendor : ST320413A
Size : 20.0GB
LBA Mode : Supported
Block Mode : 16 Sectors
PIO Mode : Supported
Async DMA : MultiWord DMA-2
Ultra DMA : Ultra DMA-5
SMART Monitoring: Supported

Type [Auto]
LBA/Large Mode [Auto]
Block(Multi-sector Transfer) [Auto]
PIO Mode [Auto]
DMA Mode [Auto]
Smart Monitoring [Auto]
32Bit Data Transfer [Disabled]

Select the type
of device connected
to the system

The values opposite the dimmed items (Device, Vendor, Size, LBA Mode, Block
Mode, PIO Mode, Async DMA, Ultra DMA, and SMART monitoring) are auto­detected by BIOS and are not user-configurable. These items show N/A if no IDE
device is installed in the system.

Type [Auto]

Selects the type of IDE drive. Setting to Auto allows automatic selection of the
appropriate IDE device type. Select CDROM if you are specifically configuring
a CD-ROM drive. Select ARMD (ATAPI Removable Media Device) if your
device is either a ZIP, LS-120, or MO drive.
Configuration options: [Not Installed] [Auto] [CDROM] [ARMD]

2-12

LBA/Large Mode [Auto]

Enables or disables the LBA mode. Setting to Auto enables the LBA mode if
the device supports this mode, and if the device was not previously formatted
with LBA mode disabled. Configuration options: [Disabled] [Auto]

Block (Multi-sector Transfer) [Auto]

Enables or disables data multi-sectors transfers. When set to Auto, the data
transfer from and to the device occurs multiple sectors at a time if the device
supports multi-sector transfer feature. When set to Disabled, the data transfer
from and to the device occurs one sector at a time.
Configuration options: [Disabled] [Auto]

Chapter 2: BIOS Setup

PIO Mode [Auto]

Selects the PIO mode. Configuration options: [Auto] [0] [1] [2] [3] [4]

DMA Mode [Auto]

Selects the DMA mode. Configuration options: [Auto] [SWDMA0] [SWDMA1]
[SWDMA2] [MWDMA0] [MWDMA1] [MWDMA2] [UDMA0] [UDMA1] [UDMA2]
[UDMA3] [UDMA4] [UDMA5]

SMART Monitoring [Auto]

Sets the Smart Monitoring, Analysis, and Reporting Technology.
Configuration options: [Auto] [Disabled] [Enabled]

32Bit Data Transfer [Disabled]

Enables or disables 32-bit data transfer.
Configuration options: [Disabled] [Enabled]

2.3.5 System Information

This menu gives you an overview of the general system specifications. The items
in this menu are auto-detected by BIOS.

AMI BIOS
Version : 08.00.09
Build Date : 04/21/05
ID : A0232008

System Memory
Size : 256MB

AMI BIOS

Displays the auto-detected BIOS information.

System Memory

Displays the auto-detected system memory.

ASUS K8V-X SE motherboard

2-13

2.4 Advanced menu

The Advanced menu items allow you to change the settings for the CPU and other
system devices.

Take caution when changing the settings of the Advanced menu items.
Incorrect field values may cause the system to malfunction.

CPU Configuration
Chipset
Onboard Devices Configuration
PCI PnP
System Frequency/Voltage Configuration
Instant Music Configuration

2.4.1 CPU Configuration

The items in this menu show the CPU-related information auto-detected by BIOS.

HyperTransport(HT) Configuration
Memory Configuration
AMD Cool & Quiet Configuration

Processor
Type : AMD Athlon(tm) 64 Processor 3200+
Speed : 2200MHz

HyperTransport Configuration

HyperTransport Configuration

HT Frequency [800 MHz]
HT DATA Width (Upstream) [16 BIT]
HT DATA Width (Downstream) [16 BIT]

HyperTransport
Configuration
Options

Enabled link tristate
during the disconnect
state of an LDTSTOP

HT Frequency [800 MHz]

Allows frequency selection of HyperTransport transfer from K8 CPU to AGP.
Configuration options: [200 MHz] [400 Mhz] [600 Mhz] [800 Mhz]

2-14

Chapter 2: BIOS Setup

HT DATA Width (Upstream) [16 BIT]

Allows selection of HyperTransport upstream data width.
Configuration options: [16 BIT] [8 BIT]

HT DATA Width (Downstream) [16 BIT]

Allows selection of HyperTransport downstream data width.
Configuration options: [16 BIT] [8 BIT]

Memory Configuration

Memory Configuration

Memory Configuration

Memory Configuration

The Memory configuration menu item allows you to change thememory settings.
Select an item then press <Enter> to display the sub-menu.

Memory Configuration

Memclock Mode [Auto]
Software Memory Hole [Enabled]
Bank Interleaving [Auto]
Burst Length [4 Beats]
MCT Timing Mode [Auto]
TWCL [Auto]
TWR [Auto]

AsyncLat [Auto]
Read Preamble Setting [Auto]
2T Command [Auto]

MEMCLK can be set
by the code using
AUTO, or if you use
LIMIT, you can set
one of the standard
values.

Memclock Mode [ Auto]

Allows you to set the memory clock mode. Set by the code using [Auto] or
select [Manual] to set using one of the standard values.
Configuration options: [Auto] [Limit]

Software Memory Hole [Enabled]

Enables or disables the software memory remapping around the memory hole.
Configuration options: [Auto] [Disabled]

Bank Interleaving [ Auto]

Sets whether to allow memory accesses to be spread out over BANKS on the
same node or across nodes, decreasing access contention.
Configuration options: [Auto] [Disabled]

Burst Length [4 Beats]

Sets the Burst Length. Configuration options: [8 Beats] [4 Beats] [2 Beats]

ASUS K8V-X SE motherboard

2-15

MCT Timing Mode [ Auto]

Sets the MCT Timing mode. Configuration options: [Auto] [Manual]

CAS Latency (CL) [2.5]

Sets the CAS Latency. Configuration options: [Auto] [2.0] [2.5] [3.0]

TRAS [8 CLK]

Sets the TRAS. Configuration options: [5 CLK] [6 CLK] [7 CLK] [8 CLK]
[9 CLK] [10 CLK] [11 CLK] [12 CLK] [13 CLK] [14 CLK] [15 CLK]

TRP [4 CLK]

Sets the TRP. Configuration options: [2 CLK] [3 CLK] [4 CLK] [5 CLK]
[6 CLK]

TRCD [Auto]

Sets the TRCD. Configuration options: [2 CLK] [3 CLK] [4 CLK] [5 CLK]
[6 CLK]

TRRD [2T]

Sets the TRRD. Configuration options: [2T] [3T] [4T]

TRC [12T]

Sets the TRC. Configuration options: [7T] [8T] [9T] [10T] [11T] [12T] [13T]
[14T] [15T] [16T] [17T] [18T] [19T] [20T] [21T] [22T]

TRFC [24T]

Sets the TRFC. Configuration options: [9T] [10T] [11T] [12T] [13T] [14T]
[15T] [16T] [17T] [18T] [19T] [20T] [21T] [22T] [23T] [24T]

TRWT [4 CLK]

Sets the TRWT. Configuration options: [1 CLK] [2 CLK] [3 CLK] [4 CLK]
[5 CLK] [6 CLK]

TWCL [Auto]

Sets the TWCL. Configuration options: [Auto] [1 CLK] [2 CLK]

TWR [Auto]

Sets the TWR. Configuration options: [Auto] [2 CLK] [3 CLK]

Asynclat [Auto]

Sets the system Asynclat.
Configuration options: [Auto] [4 CLK] [5 CLK] [6 CLK] [7CLK] [8 CLK] [9 CLK]

Read Preamble Setting [Auto]

Allows you to configure the read preamble setting. Configuration options:
[Auto] [2.0 ns] [2.5 ns] [3.0 ns] [3.5 ns] [4.0 ns] [4.5 ns] [5.0 ns] [5.5 ns] [6.0 ns]
[6.5 ns] [7.0 ns] [7.5 ns] [8.0 ns] [8.5 ns] [9.0 ns] [9.5 ns]

2-16

2T Command [Auto]

Sets the 2T command. Configuration options: [Auto] [Enabled] [Disabled]

Chapter 2: BIOS Setup

AMD Cool & Quiet Configuration

AMD Cool & Quiet Configuration

Cool N’Quiet [Disabled]

Enable/Disable AMD
K8 Cool N’Quiet
function.

Cool N’ Quiet [Disabled]

Allows you to enable or disable the AMD Cool ‘n’ Quiet!™ Technology feature.
Configuration options: [Enabled] [Disabled]

• Make sure that the above item is set to Enabled if you want to use the
AMD CPU Cool ‘n’ Quiet!™ Technology feature.

• This feature requires the AMD CPU heatsink and fan package with monitor
chip. If you purchased a separate heatsink and fan package, use the
ASUS Q-Fan Technology feature to automatically adjust your CPU fan
speed according to your system loading.

Processor

Displays the processor type and speed.

2.4.2 Chipset

The Chipset menu items allow you to change the advanced chipset settings. Select
an item then press <Enter> to display the sub-menu.

AGP Bridge Configuration
SouthBridge Configuration
USB Configuration

AGP Bridge Configuration

Primary Graphics Adapter [AGP]
Search for MDA Resources [Yes]

AGP Mode [AGP 8X]
AGP Fast Write [Enabled]
Graphics Aperture Size [64MB]

Options for VIA AGP
Chipset

2-17

Primary Graphics Adapter [AGP]

Switches the PCI Bus scanning order while searching for a video card. This allows
you to select the type of Primary VGA in case of multiple video controllers.
Configuration options: [PCI] [AGP]

AGP Mode [AGP 8X]

Allows you to set the data throughput of your AGP graphics card. This
motherboard supports the AGP 8X interface that transfers video data at 2.12GB/s.
The default and configuration options vary depending on the speed of AGP card
you installed. If you installed an AGP 8X graphics card, the configuration options
are as follows: [8X] [4X] or if you installed an AGP 4X graphics card, the
configuration options are as follows: [8X] [4X].

AGP Fast Write [Enabled]

Enables or disables the AGP Fast Write feature.
Configuration options: [Disabled] [Enabled]

Graphics Aperture Size [64MB]

Allows you to select the size of mapped memory for AGP graphic data.
Configuration options: [32MB] [64MB] [128MB] [256MB]

SouthBridge Configuration

MPS Revision [1.4]
PCI Delay Transaction [Disabled]

MPS Revision [1.4]

Sets the MPS revision value. Configuration options: [1.1] [1.4]

PCI Delay Transaction [Disabled]

Enables or disables the PCI Delay transaction feature.
Configuration options: [Disabled] [Enabled]

2-18

USB Configuration

The items in this menu allows you to change the USB-related features. Select an
item then press <Enter> to display the configuration options.

USB Configuration

Module Version - 2.23.2-7.4
USB Devices Enabled: None

USB 1.1 Ports Configuration [USB 8 Ports]
USB 2.0 Controller [Enabled]
Legacy USB Support [Auto]
USB 2.0 Controller Mode [FullSpeed]

The Module Version and USB Devices Enabled items show the auto-detected
values. If no USB device is detected, the item shows None.

Enables USB
host controllers.

USB 1.1 Ports Configuration [USB 8 Ports]

Allows you to set the number of USB ports to activate.
Configuration options: [Disabled] [USB 2 Ports] [USB 4 Ports] [USB 6 Ports]
[USB 8 Ports]

USB 2.0 Controller [Enabled]

Allows you to enable or disable the USB 2.0 ports controller.
Configuration options: [Disabled] [Enabled]

Legacy USB Support [Auto]

Allows you to enable or disable support for legacy USB devices. Setting to Auto
allows the system to detect the presence of USB devices at startup. If detected,
the USB controller legacy mode is enabled. If no USB device is detected, the
legacy USB support is disabled. Configuration options: [Disabled] [Enabled] [Auto]

USB 2.0 Controller Mode [FullSpeed]

Allows you to configure the USB 2.0 controller in HiSpeed (480 Mbps) or Full
Speed (12 Mbps). Configuration options: [HiSpeed ] [Full Speed]

ASUS K8V-X SE motherboard

2-19

2.4.3 Onboard Devices Configuration

Onboard AC’97 Audio [Enabled]
OnChip SATA BOOTROM [Enabled]
OnBoard LAN [Enabled]
OnBoard LAN Boot ROM [Disabled]

Serial Port1 Address [3F8/IRQ4]
Parallel Port Address [378]
Parallel Port Mode [ECP]

ECP MOde DMA Channel [DMA3]

Parallel Port IRQ [IRQ7]

OnBoard AC’97 Audio [Enabled]

[Auto] allows the BIOS to detect whether you are using any audio device. If an
audio device is detected, the onboard audio controller is enabled; if no audio
device is detected, the controller is disabled.
Configuration options: [Disabled] [Enabled]

OnChip SATA Boot ROM [Enabled]

Allows you to enable or disable the onchip Serial ATA boot ROM.
Configuration options: [Disabled] [Enabled]

OnBoard LAN [Enabled]

Allows you to enable or disable the onboard LAN controller.
Configuration options: [Disabled] [Enabled]

OnBoard LAN Boot ROM [Disabled]

Allows you to enable or disable the onboard LAN boot ROM.
Configuration options: [Disabled] [Enabled]

Serial Port1 Address [3F8/IRQ4]

Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]

Parallel Port Address [378]

Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]

Parallel Port Mode [ECP]

Allows you to select the Parallel Port mode.
Configuration options: [Normal] [Bi-Directional] [EPP] [ECP]

2-20

EPP Version [1.9]

Appears only when the Parallel Port Mode is set to [EPP]. This item allows you
to to select the Parallel Port EPP version. Configuration options: [1.9] [1.7]

Chapter 2: BIOS Setup

ECP Mode DMA Channel [DMA3]

Appears only when the Parallel Port Mode is set to [ECP]. This item allows you
to set the Parallel Port ECP DMA.
Configuration options: [DMA0] [DMA1] [DMA3]

Parallel Port IRQ [IRQ7]

Sets the Parallel Port IRQ. Configuration options: [IRQ5] [IRQ7]

2.4.4 PCI PnP

The PCI PnP menu items allow you to change the advanced settings for PCI/PnP
devices. The menu includes setting IRQ and DMA channel resources for either
PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA
devices.

Take caution when changing the settings of the PCI PnP menu items.
Incorrect field values may cause the system to malfunction.

Advanced PCI/PnP Settings

WARNING: Setting wrong values in below sections

may cause system to malfunction.

Plug And Play O/S [No]
PCI Lantency Timer [64]
Allocate IRQ to PCI VGA [Yes]
Palette Snooping [Disabled]

IRQ3 [PCI Device]
IRQ4 [PCI Device]
IRQ5 [PCI Device]
IRQ7 [PCI Device]
IRQ9 [PCI Device]
IRQ10 [PCI Device]
IRQ11 [PCI Device]
IRQ14 [PCI Device]
IRQ15 [PCI Device]

NO: Lets the BIOS
configure all the
devices in the system.
YES: Lets the
operating system
configure Plug and
Play (PnP) devices not
required for boot if
your system has a Plug
and Play operating
system.

Plug and Play O/S [No]

When set to [No], BIOS configures all the devices in the system. When set to [Yes]
and if you installed a Plug & Play operating system, the operating system
configures the Plug & Play devices not required for boot. Configuration options:
[No] [Yes]

PCI Latency Timer [64]

Allows you to select the value in units of PCI clocks for the PCI device latency
timer register. Configuration options: [32] [64] [96] [128] [160] [192] [224] [248]

ASUS K8V-X SE motherboard

2-21

Allocate IRQ to PCI VGA [Yes]

When set to [Yes], BIOS assigns an IRQ to PCI VGA card if the card requests for
an IRQ. When set to [No], BIOS does not assign an IRQ to the PCI VGA card even
if requested. Configuration options: [Yes] [No]

Palette Snooping [Disabled]

When set to [Enabled], the pallete snooping feature informs the PCI devices that
an ISA graphics device is installed in the system so that the latter can function
correctly. Setting to [Disabled] deactivates this feature.
Configuration options: [Disabled] [Enabled]

IRQ xx [Available]

When set to [Available], the specific IRQ is free for use of PCI/PnP devices. When
set to [Reserved], the IRQ is reserved for legacy ISA devices.
Configuration options: [Available] [Reserved]

2.4.5 System Frequency/Voltage Configuration

Config System Frequency/Voltage

CPU FSB Frequency [200 MHz]
CPU Speed/Voltage Setting [Auto]
AGP/PCI Frequency (MHz) [Auto]
CPU Voltage Adjust [None]

CPU FSB Frequency [200MHz]

Allows you to adjust the CPU FSB operating frequency.
Configuration options: [200MHz] [201 MHz] ~ [300MHz]

CPU Speed/Voltage Setting [Auto]

Allows you to set the CPU speed and voltage setting.
Configuration options: [Auto] [Manual]

CPU Multiplier [4.0]

Allows you to manuallyset the CPU speed. The configuration options vary
depending on the speed of the processor installed. This item appears only
when the CPU Speed/Voltage Setting item is set to Manual.

2-22

CPU Voltage [1.450 V]

Allows you to manually set the CPU voltage. The configuration options vary
depending on the speed of the processor installed. This item appears only
when the CPU Speed/Voltage Setting item is set to Manual.

Setting a low CPU voltage can cause system boot failure!

Chapter 2: BIOS Setup

AGP/PCI Frequency [Auto]

Allows you to automatically detect or set the AGP/PCI frequency.
Configuration options: [Auto] [66.66/33.33] [75.4/37.7]

CPU Voltage Adjust [None]

Sets the CPU Vcore offset voltage.
Configuration options: [None] [+0.1V]

2.4.6 Instant Music Configuration

Instant Music Option

Instant Music [Disabled]

If enabled, power up
by PS/2 keyboard
function will be
disabled.

Instant Music [Disabled]

Allows you to enable or disable the Instant Music feature in BIOS.
Configuration options: [Disabled] [Enabled]

When Instant Music is enabled, the PS/2 keyboard power up feature is
automatically disabled. See page 3-5 for details.

Instant Music CD-ROM Drive [IDE Secondary Master]

Allows you to select the CD-ROM drive that you wish to use for the Instant Music
CD playback. Configuration options: [IDE Primary Master] [IDE Primary Slave]
[IDE Secondary Master] [IDE Secondary Slave]

The above item appears only if you enabled the Instant Music item.

ASUS K8V-X SE motherboard

2-23

2.5 Power menu

The Power menu items allow you to change the settings for the Advanced Power
Management (APM) feature. Select an item then press <Enter> to display the
configuration options.

Suspend Mode [S1 (POS) & S3 (STR]
Repost Video on S3 Resume [No]
ACPI 2.0 Support [No]
ACPI APIC Support [Enabled]

APM Configuration
Hardware Monitor

Select the ACPI state
used for System
Suspend.

2.5.1 Suspend Mode [S1 (POS) & S3 (STR)]

Allows you to select the ACPI state to be used for system suspend.
Configuration options: [S1 (POS) Only] [S3 Only] [S1 (POS) & S3 (STR) Auto]

2.5.2 Repost Video on S3 Resume [No]

Determines whether to invoke VGA BIOS POST on S3/STR resume.
Configuration options: [No] [Yes]

2.5.3 ACPI 2.0 Support [No]

Allows you to add more tables for ACPI 2.0 specifications.
Configuration options: [No] [Yes]

2.5.4 ACPI APIC Support [Enabled]

Enables or disables the ACPI support in the ASIC. When set to Enabled, the ACPI
APIC table pointer is included in the RSDT pointer list.
Configuration options: [Disabled] [Enabled]

2-24

Chapter 2: BIOS Setup

2.5.5 APM Configuration

Power Management/APM [Enabled]

Restore on AC Power Loss [Last State]

Power On By RTC Alarm [Disabled]
Power On External Modems [Disabled]
Power On PCI Device [Disabled]
Power On PS/2 Keyboard [Disabled]
Power On PS/2 Mouse [Disabled]
OnBoard LAN P.M.E. [Disabled]

Power Management/APM [Enabled]

Allows you to enable or disable the Advanced Power Management (APM) feature.
Configuration options: [Disabled] [Enabled]

The following items appear only when the Power Management/APM item is set
to [Enabled].

Restore on AC Power Loss [Last State]

When set to Power Off, the system goes into off state after an AC power loss.
When set to Power On, the system goes on after an AC power loss. When set to
Last State, the system goes into either off or on state whatever the system state
before the AC power loss.
Configuration options: [Power Off] [Power On] [Last State]

Power On By RTC Alarm [Disabled]

Allows you to enable or disable RTC to generate a wake event. When this item is
set to Enabled, the items RTC Alarm Date, RTC Alarm Hour, RTC Alarm Minute,
and RTC Alarm Second appear with set values.
Configuration options: [Disabled] [Enabled]

Power On External Modems [Disabled]

Allows either settings of [Enabled] or [Disabled] for powering up the computer
when the external modem receives a call while the computer is in Soft-off mode.
Configuration options: [Disabled] [Enabled]

The computer cannot receive or transmit data until the computer and
applications are fully running. Thus, connection cannot be made on the first try.
Turning an external modem off and then back on while the computer is off
causes an initialization string that turns the system power on.

Power On PCI Device [Disabled]

Allows you to enable or disable power on PCI device feature. This feature requires
an ATX power supply that provides at least 1A on the +5VSB lead.
Configuration options: [Disabled] [Enabled]

ASUS K8V-X SE motherboard

2-25

Power On PS/2 Keyboard [Disabled]

Allows you to enable or disable the keyboard wake-up feature. This feature
requires an ATX power supply that provides at least 1A on the +5VSB lead.
Configuration options: [Disabled] [Enabled]

Power On PS/2 Mouse [Disabled]

When set to [Enabled], this parameter allows you to use the PS/2 mouse to
resume the system. This feature requires an ATX power supply that provides at
least 1A on the +5VSB lead. Configuration options: [Disabled] [Enabled]

OnBoard LAN P.M.E [Disabled]

When set to [Enabled], this parameter allows you to use onboard LAN PME
devices to resume the system. This feature requires an ATX power supply that
provides at least 1A on the +5VSB lead. Configuration options: [Disabled]
[Enabled]

2.5.6 Hardware Monitor

Hardware Monitor

CPU Temperature [40.5ºC/102.5ºF]
MB Temperature [33ªC/91ºF]

CPU Fan Speed [3260RPM]
Chassis Fan Speed [N/A]

VCORE Voltage [ 1.504V]

3.3V Voltage [ 3.360V]
5V Voltage [ 5.160V]
12V Voltage [11.328V]

CPU Temperature

CPU Temperature [xxx ºC/xxx ºF]
MB Temperature [xxx ºC/xxx ºF]

The onboard hardware monitor automatically detects and displays the
motherboard and CPU temperatures. Select Disabled if you do not wish to display
the detected temperatures.

CPU Fan Speed [xxxxRPM] or [N/A]
Chassis Fan Speed [xxxxRPM] or [N/A]

The onboard hardware monitor automatically detects and displays the CPU and
chassis fan speeds in rotations per minute (RPM). If any of the fans is not
connected to the motherboard, the specific field shows N/A.

VCORE Voltage, +3.3V Voltage, +5V Voltage, +12V Voltage

The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.

2-26

Chapter 2: BIOS Setup

2.6 Boot menu

The Boot menu items allow you to change the system boot options. Select an item
then press <Enter> to display the sub-menu.

Boot Settings

Boot Device Priority

Boot Settings Configuration
Security

2.6.1 Boot Device Priority

Boot Device Priority

1st Boot Device [1st FLOPPY DRIVE]
2nd Boot Device [PM-ST320413A]
3rd Boot Device [SM-ASUS CD-S360]

Specifies the Boot
Device Priority
sequence.

1st ~ xxth Boot Device [1st Floppy Drive]

These items specify the boot device priority sequence from the available devices.
The number of device items that appear on the screen depends on the the number
of devices installed in the system. Configuration options: [1st Floppy Drive] [XXXX]

2.6.2 Removable Drives

Removable Drives

1st Drive [1st Floppy Drive]
2nd Drive [USB Drive]

1st ~ xxth Drive

These items specify the hard disk priority sequence from the available removable
drives. Configuration options: [1st Floppy Drive] [XXXXXX]

ASUS K8V-X SE motherboard

2-27

2.6.3 Boot Settings Configuration

Boot Settings Configuration

Quick Boot [Enabled]
Full Screen Logo [Enabled]
AddOn ROM Display Mode [Force BIOS]
Bootup Num-Lock [On]
PS/2 Mouse Support [Auto]
Wait for ‘F1’ If Error [Enabled]
Hit ‘DEL’ Message Display [Enabled]
Interrupt 19 Capture [Disabled]

Allows BIOS to skip
certain tests while
booting. This will
decrease the time
needed to boot the
system.

Quick Boot [Enabled]

Enabling this item allows the BIOS to skip some Power On Self Tests (POST) while
booting to decrease the time needed to boot the system. When set to [Disabled],
BIOS performs all the POST items. Configuration options: [Disabled] [Enabled]

Full Screen Logo [Enabled]

Allows you to enable or disable the full screen logo display feature.
Configuration options: [Disabled] [Enabled]

Make sure that the above item is set to [Enabled] if you wish to use the ASUS
MyLogo™ feature.

Add On ROM Display Mode [Force BIOS]

Sets the display mode for option ROM.
Configuration options: [Force BIOS] [Keep Current]

Bootup Num-Lock [On]

Allows you to select the power-on state for the NumLock.
Configuration options: [Off] [On]

PS/2 Mouse Support [Auto]

Allows you to enable or disable support for PS/2 mouse.
Configuration options: [Disabled] [Enabled] [Auto]

Wait for ‘F1’ If Error [Enabled]

When set to Enabled, the system waits for F1 key to be pressed when error
occurs. Configuration options: [Disabled] [Enabled]

Hit ‘DEL’ Message Display [Enabled]

When set to Enabled, the system displays the message “Press DEL to run Setup”
during POST. Configuration options: [Disabled] [Enabled]

2-28

Chapter 2: BIOS Setup

Interrupt 19 Capture [Disabled]

When set to [Enabled], this function allows the option ROMs to trap Interrupt 19.
Configuration options: [Disabled] [Enabled]

2.6.4 Security

The Security menu items allow you to change the system security settings. Select
an item then press <Enter> to display the configuration options.

Security Settings

Supervisor Password : Not Installed
User Password : Not Installed

Change Supervisor Password
Change User Password
Clear User Password

Boot Sector Virus Protection [Disabled]

<Enter> to change
password.
<Enter> again to
disable password.

Change Supervisor Password

Select this item to set or change the supervisor password. The Supervisor
Password item on top of the screen shows the default Not Installed. After you
have set a password, this item shows Installed.

To set a Supervisor Password:

1. Select the Change Supervisor Password item and press <Enter>.

2. From the password box, type a password combination of at least six (6) letters
and/or numbers, then press <Enter>.

3. Confirm the password when prompted. The message “Password Installed”
appears after you have successfully set your password.
The Supervisor Password item now shows Installed.

To change the supervisor password, follow the same steps as in setting a user
password.

To clear the supervisor password, select the Change Supervisor Password then
press <Enter>. The message “Password Uninstalled” appears.

If you forget your BIOS password, you can clear clear it by erasing the CMOS
Real Time Clock (RTC) RAM. See section “1.9 Jumpers” for information on how
to erase the RTC RAM.

After you have set a supervisor password, the other items appear to allow you to
change other security settings.

ASUS K8V-X SE motherboard

2-29

Security Settings

Supervisor Password : Installed
User Password : Not Installed

Change Supervisor Password
User Access Level [Full Access]
Change User Password
Clear User Password
Password Check [Setup]

Boot Sector Virus Protection [Disabled]

<Enter> to change
password.
<Enter> again to
disabled password.

User Access Level (Full Access]

Allows you to select the access restriction to the Setup items.
Configuration options: [No Access] [View Only] [Limited] [Full Access]

No Access prevents user access to the Setup utility.
View Only allows access but does not allow change to any field.
Limited allows change only to selected fields, such as Date and Time.
Full Access allows viewing and changing all the fields in the Setup utility.

Change User Password

Select this item to set or change the user password. The User Password item on
top of the screen shows the default Not Installed. After you have set a password,
this item shows Installed.

To set a User Password:

1. Select the Change User Password item and press <Enter>.

2. On the password box that appears, type a password combination of at least six
(6) letters and/or numbers, then press <Enter>.

3. Confirm the password when prompted. The message “Password Installed”
appears after you have successfully set your password.
The User Password item now shows Installed.

To change the user password, follow the same steps as in setting a user password.

Clear User Password

Select this item if you wish to clear the user password.

Password Check [Setup]

When set to [Setup], BIOS checks for user password when accessing the Setup
utility. When set to [Always], BIOS checks for user password both when accessing
Setup and booting the system. Configuration options: [Setup] [Always]

Boot Sector Virus Protection [Disabled]

Allows you to enable or disable the boot sector virus protection.
Configuration options: [Disabled] [Enabled]

2-30

Chapter 2: BIOS Setup

2.7 Exit menu

The Exit menu items allow you to load the optimal or failsafe default values for the
BIOS items, and save or discard your changes to the BIOS items.

Exit Options

Exit & Save Changes
Exit & Discard Changes
Discard Changes

Load Setup Defaults

Pressing <Esc> does not immediately exit this menu. Select one of the options
from this menu or <F10> from the legend bar to exit.

Exit system setup
after saving the
changes.

F10 key can be used
for this operation.

Exit & Save Changes

Once you are finished making your selections, choose this option from the Exit
menu to ensure that the values you selected are saved to the CMOS RAM. An
onboard backup battery sustains the CMOS RAM and stays on even when the PC
is turned off. When you select this option, a confirmation window appears. Select
Ok to save changes and exit.

If you attempt to exit the Setup program without saving your changes, the
program prompts you with a message asking if you want to save your changes
before exiting. Press <Enter> to save the changes while exiting.

Exit & Discard Changes

Select this option only if you do not want to save the changes that you made to the
Setup program. If you made changes to fields other than System Date, System
Time, and Password, the BIOS asks for a confirmation before exiting.

Discard Changes

Allows you to discard the selections you made and restore the previously saved
values. After selecting this option, a confirmation appears. Select Ok to discard any
changes and load the previously saved values.

Load Setup Defaults

This option allows you to load the default values for each of the parameters on the
Setup menus. When you select this option or if you press <F5>, a confirmation
window appears. Select Ok to load default values. Select Exit & Save Changes or
make other changes before saving the values to the non-volatile RAM.

ASUS K8V-X SE motherboard

2-31

2-32

Chapter 2: BIOS Setup

Chapter 3

This chapter describes the contents of the
support CD that comes with the motherboard
package.

Software support

3.1 Install an operating system

This motherboard supports Windows® 98SE/ME/2000/XP operating system (OS).
Always install the latest OS version and corresponding updates to maximize the
features of your hardware.

Motherboard settings and hardware options vary, so use the setup procedures
presented in this chapter for general reference only. Refer to your OS
documentation for more information.

3.2 Support CD information

The support CD that came with the motherboard contains useful software and
several utility drivers that enhance the motherboard features.

The contents of the support CD are subject to change at any time without
notice. Visit the ASUS website for updates.

3.2.1 Running the support CD

To begin using the support CD, simply insert the CD into your CD-ROM drive. The
CD automatically displays the Drivers menu if Autorun is enabled in your
computer. Click on an item to install.

3-2

Click an item to install

If Autorun is NOT enabled in your computer, browse the contents of the
support CD to locate the file ASSETUP.EXE from the BIN folder. Double-click
the ASSETUP.EXE to run the CD.

Click an icon to display
more information

Chapter 3: Software support

3.2.2 Drivers menu

The drivers menu shows the available device drivers if the system detects installed
devices. Install the necessary drivers to activate the devices.

VIA 4 in 1 drivers

This item installs the following drivers:

- VIA Registry (INF) driver

- VIA AGP VxD driver

- VIA ATAPI vendor support driver

- VIA PCI IRQ Miniport driver.

VIA RAID Controller driver

Installs the VIA 6420 RAID controller driver and application.

ADI1888 SoundMAX Audio Driver

Installs the ADI1888 SoundMAX audio driver and application.

VIA Rhine II Fast Ethernet Driver

Installs the VIA® Rhine II Fast Ethernet LAN drivers for 10/100 LAN solution that
provides up to 100Mbps data transfer rates.

USB 2.0 Driver

Installs the USB 2.0 driver to upgrade your USB 1.1 ports to USB 2.0.

Cool ‘n’ Quiet readme

Launches the AMD Cool ‘n’ Quiet!™ Technology readme file.

Cool ‘n’ Quiet driver

Installs the AMD Cool ‘n’ Quiet!™ Technology driver.

For Windows® XP users, make sure to install Windows® XP Service Pack 1 or
later to support USB 2.0.

ASUS K8V-X SE motherboard

3-3

3.2.3 Utilities menu

The Utilities menu shows the applications and other software that the motherboard
supports.

ASUS PC Probe

This smart utility monitors the fan speed, CPU temperature, and system voltages,
and alerts you on any detected problems. This utility helps you keep your computer
at a healthy operating condition.

ASUS Update

This program allows you to download the latest version of the BIOS from the ASUS
website. Before using the ASUS Update, make sure that you have an Internet
connection so you can connect to the ASUS website. Installing ASUS Update also
installs ASUS Mylogo2™.

Microsoft DirectX Driver

Installs the Microsoft DirectX™driver.

Anti-virus Utility

The anti-virus application scans, identifies, and removes computer viruses. View
the online help for detailed information.

Acrobat Reader

Installs the Adobe Acrobat® Reader V5.0. The Acrobat® Reader software is for
viewing files saved in Portable Document Format (PDF).

ASUS Screen Saver

Installs the ASUS screen saver.

Cool ’n’ Quiet Software

Installs the ASUS AMD® Cool ‘n’ Quiet software.

3-4

Chapter 3: Software support

3.2.4 Manual menu

The Manual menu contains a list of supplementary user manuals. Click an item to
open the manual.

Install the Adobe® Acrobat® Reader from the Utilities menu to open the manual
files in PDF.

3.2.5 ASUS Contact Information

Clicking the ASUS Contact Information tab displays as stated. You may also find
this information on the inside front cover of this user guide.

ASUS K8V-X SE motherboard

3-5

3.3 ASUS Instant Music Lite

The motherboard is equipped with a BIOS-based audio playback feature called
Instant Music Lite. This feature is supported by the onboard audio AC’97 Codec,
and requires an optical drive (CD-ROM, DVD-ROM, or CD-RW).

• Instant Music Lite only supports CDs in audio format.

• Instant Music Lite does not work if you installed and enabled an add-on
sound card.

• Instant Music Lite only supports PS/2 keyboard.

To enable ASUS Instant Music Lite:

1. Connect the analog audio cable from the optical drive (CD-ROM, DVD-ROM,
or CD-RW drive) to the 4-pin CD-In connector (labeled CD1) on the
motherboard. See section “1.10 Connectors” for the connector location.

Make sure to connect the CD-ROM audio cable. Otherwise, you cannot control
the audio volume using the Instant Music Lite function keys.

2. Turn on the system and enter the BIOS by pressing the <Del> key during the
Power On Self-Tests (POST).

3. In the Advanced Configuration menu, select the item Instant Music and set
it to Enabled. See section “2.4 Advanced Menu” in the user guide.

4. Highlight the Instant Music CDROM item and press Enter to display the
CD-ROM options. Select the CD-ROM drive that you wish to use for this
feature. See section “2.4 Advanced Menu” in the user guide.

If you have only one optical drive (either CD-ROM, DVD-ROM, or CD-RW)
installed in the system, you don’t have to set Instant Music CDROM item. BIOS
automatically detects and displays the installed drive type.

5. Save your changes and exit BIOS Setup.

• The Scroll Lock LED is fixed to ON after enabling Instant Music.

• The Caps Lock LED is turns ON when you pause the CD playback.

• When set to Instant Music Lite mode, the system wake-up features (LAN,
keyboard, mouse, USB) are deactivated. In this case, power up the system
using the power switch.

• If the system loses connection or does not detect any optical drive, the
Instant Music Lite feature turns OFF (disabled) automatically. A “beep”
indicates this condition.

3-6

Chapter 3: Software support

To use ASUS Instant Music Lite:

SCROLL

CAPS

1. Ensure that the power cord is plugged to a grounded power source, so that the
system has a standby power.

2. Use either one of the two sets of special function keys on your keyboard to
play audio CDs. These keys only function as indicated if you enabled the
Instant Music item in the BIOS.

Instant Music function keys (Set 1)

CD
ON/OFF

Esc F1 F2 F3 F4 F5 F6 F7 F8

PLAY/PAUSE STOP/EJECT PREVIOUS NEXT VOL. DOWN VOL. UP

Instant Music function keys (Set 2)

LOCK

LOCK

LED

CD ON/OFF

PLAY/PAUSE

STOP/EJECT

PREVIOUS NEXT

VOL. DOWN VOL. UP

LED

3. Connect speakers or a headphone to the Line Out (lime colored) port on the
rear panel for audio output. You may also connect a headphone to the
headphone jack on the CD-ROM drive front panel.

4. Press <Esc> to turn ON Instant Music Lite.

5. Place an audio CD into the drive.

6. Press <F1> or the <Space Bar> to play the first track on the CD.

If there is no CD in the drive and you press F1 or Space Bar, the drive tray
ejects.

7. Refer to the Instant Music function key definitions on the previous page to
select other tracks or control the volume.

8. Press <F2> or <Enter> once to stop playing the CD.
Press <F2> or <Enter> one more time to eject the CD.

ASUS K8V-X SE motherboard

3-7

3.4 VIA RAID configurations

The motherboard includes a high performance IDE RAID controller integrated in
the VIA VT8237 southbridge chipset. It supports RAID 0 and RAID 1 with two
independent Serial ATA channels.

RAID 0 (called data striping) optimizes two identical hard disk drives to read and
write data in parallel, interleaved stacks. Two hard disks perform the same work as
a single drive but at a sustained data transfer rate, double that of a single disk
alone, thus improving data access and storage.

RAID 1 (called data mirroring) copies and maintains an identical image of data
from one drive to a second drive. If one drive fails, the disk array management
software directs all applications to the surviving drive as it contains a complete
copy of the data in the other drive. This RAID configuration provides data
protection and increases fault tolerance to the entire system.

If you use either Windows® XP or Windows® 2000 operating system (OS), copy
first the RAID driver from the support CD to a floppy disk before creating RAID
configurations. Refer to section “3.5 Creating a RAID driver disk” for details.

3.4.1 Installing hard disks

The motherboard supports UltraDMA 133/100/66 and Serial ATA hard disk drives.
For optimal performance, install identical drives of the same model and capacity
when creating a disk array.

• If you are creating a RAID 0 (striping) array for performance, use two new
drives.

• If you are creating a RAID 1 (mirroring) array for protection, you can use
two new drives or use an existing drive and a new drive (the new drive
must be of the same size or larger than the existing drive).

Installing Parallel ATA hard disks

To install the hard disks for RAID configuration:

1. Set the jumpers of each hard disk as Master/Slave.

2. Install the hard disks into the drive bays.

3. Connect the HDD signal cable.

4. Connect the power cable to the power connector on each drive.

Installing Serial ATA (SATA) hard disks

To install the SATA hard disks for RAID configuration:

1. Install the Serial ATA hard disks into the drive bays.

2. Connect the Serial ATA signal cables.

3. Connect the SATA power cable to the power connector on each drive.

3-8

Chapter 3: Software support

3.4.2 VIA RAID configurations

The motherboard includes a high performance IDE RAID controller integrated in
the VIA 8237 chipset. It supports RAID 0 and RAID 1 configurations. Use the VIA
RAID utility to configure a disk array.

Setting BIOS RAID items

After installing the hard disk drives, make sure to set the necessary RAID items in
the BIOS before setting your RAID configuration.

To set the BIOS RAID items:

1. Boot the system and press <Del> during the Power-On Self-Test (POST) to
enter the BIOS Setup Utility.

2. Go to the Advanced > Onboard Devices Configuration > OnChip SATA
Boot ROM menu item in the BIOS.

3. Make sure that the OnChip SATA Boot ROM item is Enabled.

4. Save your changes and Exit Setup.

Entering VIA RAID BIOS Utility

To enter the VIA RAID BIOS utility:

1. Boot your computer.

2. During POST, press <Tab> to enter the VIA RAID configuration utility.

For detailed descriptions on the VIA RAID configuration, refer to the “RAID
Controller Quick Setup Guide” found in the Manual menu of your motherboard
support CD. See page 3-5.

ASUS K8V-X SE motherboard

3-9

3.5 Creating a RAID driver disk

A floppy disk with a RAID driver is required when installing Windows
operating system. You can create a RAID driver disk using Makedisk.exe utility.

To create a RAID driver disk:

1. Insert the motherboard support CD into the CD-ROM drive and locate the
Makedisk.exe utility for your RAID controller. The Makedisk.exe utility for the
VIA RAID driver is located in \Drivers\VIARAID\6420RAID\DriverDisk\
Makedisk.exe” of the motherboard support CD.

2. Insert a clean floppy disk into the floppy disk drive and execute Makedisk.exe.
Follow succeeding screen instructions to complete the process.

3. Write-protect the floppy disk to avoid computer virus infection.

To install the RAID driver:

1. During the OS installation, the system prompts to press the F6 key to install
third-party SCSI or RAID driver.

2. Press <F6> then insert the floppy disk with RAID driver into the floppy disk
drive.

®

XP/2000

3. Follow the succeeding screen instructions to complete the installation.

For additional information on VIA RAID installation and configuration, refer to
the “VT6420 Serial ATA RAID Controller Quick Setup Guide” found in the
Manual menu of your motherboard support CD. See page 3-5.

3-10

Chapter 3: Software support

3.6 Cool ‘n’ Quiet!™ Technology

The motherboard supports the AMD Cool ‘n’ Quiet!™ Technology that dynamically
and automatically change the CPU speed, voltage and amount of power
depending on the task the CPU performs.

3.6.1 Enabling Cool ‘n’ Quiet!™ Technology

To enable Cool ‘n’ Quiet!™ technology:

1. Turn on the system and enter BIOS by pressing the <Del> key during the
Power On Self-Tests (POST).

2. In the Advanced > CPU Configuration > AMD CPU Cool & Quiet
Configuration menu, select the item Cool N’Quiet and set it to Enabled. See
section “2.4 Advanced Menu” for details.

3. In the Power menu, select the item ACPI 2.0 Support and set it to Yes. See
section “2.5 Power Menu” for details.

4. Save your changes and exit BIOS Setup.

5. Reboot your computer and set your Power Option Properties depending on
your operating system.

®

Windows

1. From the Windows
Settings, then Control Panel.

2. Make sure the Control Panel is set to Classic View.

3. Double-click the Display icon in the
Control Panel then select the Screen
Saver tab.

4. Click the Power... button. The
following dialog box appears.

5. From the Power schemes combo
list box, select Minimal Power
Management.

6. Click OK to effect settings.

2000/XP:

®

2000/XP operating system, click the Start button. Select

Make sure to install the Cool ‘n’ Quiet!™ driver and application when using this
feature.

ASUS K8V-X SE motherboard

3-11

Windows® 98SE/ME:

®

1. From the Windows

98SE/ME operating system, click the Start button. Select

Settings, then Control Panel.

2. Double-click the Display icon in the
Control Panel then select the Screen
Saver tab.

3. From the Energy saving features of
monitor group, click the Settings...
button.

4. From the Power Options

Properties dialog box, select the
AMD’s Cool ‘n’ Quiet(tm)
Technology tab.

5. Click the Performance combo list
box to select desired mode.
Automatic Mode is the
recommended setting.

6. Click OK to effect settings.

• Make sure to install the AMD Cool ‘n’ Quiet!™ driver and application before
using this feature.

• The AMD Cool ‘n’ Quiet!™ Technology feature works only with the AMD
heatsink and fan assembly with monitor chip.

3-12

Chapter 3: Software support

3.6.2 Launching the Cool ‘n’ Quiet!™ software

The motherboard support CD includes the Cool ‘n’ Quiet!™ software that enables
you to view your system’s real-time CPU frequency and voltage.

Make sure to install the Cool ‘n’ Quiet!™ software from the motherboard support
CD. Refer to section “3.2.3 Utilities” for details.

To launch the Cool ‘n’ Quiet!™ program:

®

1. If you are using Windows

Programs > ASUS > Cool & Quiet > Cool & Quiet.

2. If you are using Windows

ASUS > Cool & Quiet > Cool & Quiet.

3. The Cool ‘n’ Quiet!™ technology screen appears and displays the current CPU
Frequency and CPU Voltage.

98SE/ME/2000, click the Start button. Select

®

XP, click the Start button. Select All Programs >

ASUS K8V-X SE motherboard

3-13

3-14

Chapter 3: Software support
