ASUS A7V333 User Manual

®

A7V333

User Guide

Motherboard

Checklist

Product Name: A7V333
Manual Revision: 1.01 E1010
Release Date: March 2002

Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved.

No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any
form or by any means, except documentation kept by the purchaser for backup purposes,
without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.

Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification
or explanation and to the owners’ benefit, without intent to infringe.

• Intel and Pentium are registered trademarks of Intel Corporation.

• VIA is a registered trademark of VIA Technologies, Inc.

• 3Com is a registered trademark of 3Com Corporation.

• C-Media is a registered trademark of C-Media Electronics Inc.

• Windows and MS-DOS are registered trademarks of Microsoft Corporation.

• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.

• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.

• Symbios is a registered trademark of Symbios Logic Corporation.

• nVidia is a registered trademark of NVIDIA Corporation.

The product name and revision number are both printed on the product itself. Manual revisions
are released for each product design represented by the digit before and after the period of
the manual revision number. Manual updates are represented by the third digit in the manual
revision number.

For previous or updated manuals, BIOS, drivers, or product release information, contact
ASUS at: http://www.asus.com or through any of the means indicated on the following page.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN
THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

ii

About this guide

This user manual contains complete information for installing the ASUS
A7V333 motherboard.

How this guide is organized

• Chapter 1: Product introduction. A summary of product features and

special attributes of new technologies.

• Chapter 2: Hardware information. A list of hardware setup procedures
and descriptions of all jumpers and connectors on the motherboard.

• Chapter 3: Powering up. Describes the power up sequence with
information on BIOS beep codes.

• Chapter 4: BIOS setup. How to change system settings using onboard
BIOS firmware. Detailed descriptions of the BIOS parameters are supplied.

• Chapter 5: Software support. A summary of contents on the
motherboard support CD ROM.

• Appendix and Glossary . Optional components and technical definitions.

• Index

Conventions used in this guide

Features

T o make sure that you perform set-up tasks properly , take note of the following
symbols used throughout this manual.

WARNING! Information to prevent injury to yourself.

CAUTION! Information to prevent damage to the components.

IMPORTANT! Information that you MUST follow to complete a task.

NOTE! T ips and helpful information.

iii

Contents

Safeguards

About this guide .............................................................................. iii

How this guide is organized.................................................... iii

Conventions used in this guide............................................... iii

Safety information ...........................................................................vi

FCC/CDC statements .................................................................... vii

ASUS contact information ............................................................. viii

Chapter 1: Product introduction ............................................. 1

Welcome!........................................................................................ 1

1.1 Package contents .................................................................. 1

1.2 Core Specifications ................................................................ 2

1.3 Special Features .................................................................... 3

1.4 Motherboard Components...................................................... 4

1.4.1 Component Locations................................................ 5

Chapter 2: Hardware information ............................................ 1

2.1 Motherboard installation ......................................................... 7

2.1.1 Placement direction ................................................... 7

2.1.2 Screw holes............................................................... 7

2.2 Motherboard layout ................................................................ 8

2.2.1 Layout contents ......................................................... 9

2.3 Before you proceed...............................................................11

2.4 Central Processing Unit (CPU)............................................. 12

2.4.1 Overview ..................................................................12

2.4.2 Installing the CPU .................................................... 13

2.5 System memory ....................................................................14

2.5.1 Overview ..................................................................14

2.5.2 Memory configurations ............................................ 15

2.5.3 Installing a DIMM ..................................................... 15

2.6 Expansion slots.....................................................................16

2.6.1 Installing an expansion card..................................... 16

2.6.2 Configuring an expansion card ................................ 16

2.6.3 PCI slots ...................................................................18

2.6.4 AGP slot ...................................................................18

2.7 Switches and jumpers ...........................................................19

2.8 Connectors ...........................................................................29

Chapter 3: Powering up ........................................................... 1

3.1 Starting up for the first time................................................... 45

3.2 Vocal POST Messages .........................................................46

iv

Contents

3.3 Powering off the computer.................................................... 48

Chapter 4: BIOS setup ............................................................. 1

4.1 Managing and updating your BIOS....................................... 49

4.1.1 Using the computer system for the first time ............ 49

4.1.2 Updating BIOS procedures ...................................... 51

4.2 BIOS Setup program.............................................................53

4.2.1 BIOS menu bar.........................................................54

4.2.2 Legend bar ...............................................................54

4.3 Main Menu ............................................................................56

4.3.1 Primary and Secondary Master/Slave...................... 57

4.3.2 Keyboard Features .................................................. 61

4.4 Advanced Menu ....................................................................63

4.4.1 Chip Configuration ................................................... 65

4.4.2 I/O Device Configuration.......................................... 68

4.4.3 PCI Configuration .................................................... 70

4.5 Power Menu..........................................................................73

4.5.1 Power Up Control .................................................... 75

4.5.2 Hardware Monitor .................................................... 77

4.6 Boot Menu ............................................................................78

4.7 Exit Menu..............................................................................80

Chapter 5: Software support ................................................... 1

5.1 Install an operating system................................................... 83

5.2 Support CD information.........................................................83

5.3 A7V333 Motherboard Support CD........................................ 84

5.4 Using the Promise Chip for RAID 0 or 1 ............................... 86

5.5 Manual Installation of IDE/RAID Drivers ............................... 93

5.4 ASUS PC Probe....................................................................94

5.5 ASUS Live Update ................................................................99

5.6 3Deep Color Tuner..............................................................100

5.7 Winbond Voice Editor ..........................................................102

5.8 ITE GSM Editor...................................................................106

Glossary .................................................................................111

Index ...................................................................................... 115

v

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.

• When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. Disconnect all power cables from the existing system before
you add a device.

• Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.

• Seek professional assistance before using an adpater or extension cord.
These devices could interrupt the grounding circuit.

• Make sure that your power supply is set to the voltage available in your
area.

• If the power supply is broken, contact a qualified service technician or your
retailer.

Operational safety

• Before installing the motherboard and adding new devices, carefully read
all the manuals that came with the package.

• Before use ensure all cables are correctly connected and the power cables
are not damaged. If you detect any damage, contact the dealer immediately .

• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product
in any area where it may become wet.

• Mount the motherboard inside a standard PC enclosure.

• If you encounter technical problems with the product, contact a qualified

service technician or the dealer.

vi

FCC/CDC statements

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

vii

ASUS contact information

ASUSTeK COMPUTER INC. (Asia-Pacific)

Marketing

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [e-mail]

Technical Support

Tel (English): [phone]
Tel (Chinese): [phone]
Fax: [phone]
Email: [e-mail]
Newsgroup: cscnews.asus.com.tw
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER INTERNATIONAL (America)

Marketing

Address: 6737 Mowry Avenue, Mowry Business Center, Building 2

Newark, CA 94560, USA
Fax: [phone]
Email: [e-mail]

Technical Support

Tech Support [phone]
Fax: [phone]
BBS: [phone]
Email: [e-mail]
WWW: www.asus.com
FTP: ftp.asus.com/pub/ASUS

ASUS COMPUTER GmbH (Europe)

Marketing

Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [e-mail] (for marketing requests only)

Technical Support

Hotline: MB/Others: [phone]

Notebook: [phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

viii

Chapter 1

Product introduction

ASUS A7V333 motherboard

Welcome!

Thank you for buying the ASUS® A7V333 motherboard!

The A7V333 is powered by AMD
and supplies advanced features to ensure long-lasting, superlative

®

performance. The ASUS
PCs and workstations.

~ CPU Thermal Protection
~ Up to 3GB of system memory of the latest DDR RAM
~ High-resolution graphics via an AGP 4X slot
~ Digital Audio Interface for 3D sound
~ Promise IDE RAID 0/1 Controller onboard
~ 1394 Interface ready
~ Memory Stick
~ Four USB 2.0 ports
~ UltraDMA 133 data rates

The A7V333 is the perfect vehicle to get ahead in the world of power
computing!

A7V333 motherboard is the prime choice for home

™

®

Athlon™, Athlon™ XP and Duron™ processors

& Secure Digital ™ memory support.

1.1 Package contents

Check your A7V333 package for the following items.

ASUS A7V333 motherboard (ATX form factor: 12.0 in x 9.6 in)
ASUS A7V333 support CD
ASUS 2-port USB/Game Port module
80-conductor ribbon cable for UltraDMA/33/66/100/133 IDE drives
40-conductor IDE cable
Ribbon cable for a 3.5-inch floppy drive
Bag of extra jumper caps
I/O Plate
User Guide

If any of the above items is damaged or missing, contact your retailer.

ASUS A7V333 motherboard user guide

1

1.2

Core Specifications

The A7V333 motherboard is designed and assembled according to the highest
standards. This ASUS motherboard represents the latest advances and
offers users the finest componentry available today...

®

AMD

Athlon™/ Athlon™ XP and Duron™ Socket A (462) Processor

North Bridge Chipset: the VIA

®

KT333 supports AGP 4X/2X mode,
133/100MHz Front Side Bus, and the fastest 333/266/200MHz memory
bus.

®

South Bridge Chipset: the VIA

VT8233A integrated peripheral controller

supports UltraDMA133/100/66/33 for burst mode data transfer rates of
up to 133MB/sec, and USB controller with two root hubs for four USB
ports.

PC2700 / PC2100 / PC1600 DDR Support: Equipped with three Double

Data Rate Dual Inline Memory Module (DDR DIMM) sockets to support
up to 3GB of DDR333 SDRAM, the newest memory standard with the
highest bandwidth and lowest latency currently available. DDR memory
technology increases performance by executing two process actions per
clock cycle.

UltraDMA/133 Support: Comes with an onboard PCI Bus Master IDE

controller with two connectors that support four IDE devices on two
channels. Supports UltraDMA133/100/66/33, PIO Modes 3 & 4, Bus
Master IDE DMA Mode 2, and Enhanced IDE devices, such as DVD­ROM, CD-ROM, CD-R/RW, LS-120, and Tape Backup drives.

Multi-I/O Chipset: Offers complete support for a variety of I/O functions.

Provides two high-speed UART compatible serial ports and one parallel
port with EPP and ECP capabilities. UART2 can also be directed from
COM2 to the Infrared Module for wireless connections. The Super I/O
controller supports a floppy disk drive, PS/2 keyboard, and PS/2 mouse.

Smart BIOS: 2Mb firmware enables Vcore and CPU/DDR SDRAM frequency

adjustments, boot block write protection, and HD/SCSI/MO/ZIP/CD/Floppy
boot selection.

Expansion: One AGP PRO 4X, four USB 2.0 ports, four USB 1.1 ports, five

PCI slots, SPDIF digital audio connector , 1394 header , game connector,
MS & SD headers, iPanel connector , front audio panel connector, smart
card connector, infrared port.

Connections: Parallel Port, PS/2 mouse Port, PS/2 keyboard, 4 USB ports,

Microphone, Line In Jack, Line Out Jack, Standard ATX power.

2

Chapter 1: Product introduction

1.3 Special Features

Easy Overclocking

™

• Quickly adjust CPU frequency multiples with BIOS in JumperFree

• Adjustable FSB/MEM/PCI frequency ratio

• Stepless Frequency Selection (SFS) for fine-tuning system bus frequency

from at 1MHz increments

• Optimal system performance available with BIOS built-in Turbo Mode

• Adjustable Vcore Voltage and VIO

• Alternatively, easy-to-use DIP switches permit manual adjustment of the

processor external/internal frequency settings.

Mode

C.O.P (CPU Overheating Protection): With AMD

®

Athlon XP™ installed,
the motherboard offers automatic CPU Overheating Protection to prolong
the life of the entire system. If the CPU temperature exceeds the set
criteria, the PC shuts down automatically.

T emperature, Fan and V oltage Monitoring: CPU temperature is monitored

by the ASUS ASIC through the CPU’s internal thermal diode to prevent
overheating and damage. The CPU and system fans can be monitored
for RPM and failure. System voltage levels are monitored to ensure
stable voltage to critical motherboard components.

ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more

Energy Saving Features for operating systems that support OS Direct
Power Management (OSPM).

Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI

master busses to the memory and processor.

Auto Fan Off: The system fans powers off automatically even in sleep mode.
Dual Function Power Button: Push the power button for less than 4 seconds

when the system is operating places the system into sleep or soft-off
modes, depending on the BIOS or OS setting. If the power button is
pressed for more than 4 seconds, the system enters the soft-off mode
regardless of the BIOS setting.

ASUS A7V333 motherboard user guide

3

1.4

Motherboard Components

Before installing the A7V333 motherboard, take time to familiarize yourself
with its configuration: understanding the motherboard makes upgrading easy .
Sufficient knowledge of specifications prevents accidental damage.

Location

Processor Support Socket A for AMD

Feature Setting DIP Switches ......................................... 9

Chipsets VIA

Main Memory 3 DDR DIMM Sockets (3GB) ..........................................3

Expansion Slots 5 PCI Slots .................................................................... 26

System I/O 1 Floppy Disk Drive Connector .....................................18

Hardware Monitoring System Voltage Monitor (integrated in ASUS ASIC) .....12

Special Feature Onboard LED ................................................................16

Audio Features (on audio models only)

Power ATX Power Supply Connector ......................................... 5

Form Factor ATX

®

KT333 North Bridge ................................................ 1

2Mbit Programmable Flash EEPROM ............................4

®

VT8233A South Bridge.......................................... 11

VIA

Promise IDE RAID 0/1 Controller (Optional) ................... 8

Multi-I/O Controller ........................................................ 19

USB 2.0 Controller ........................................................ 28

1394 Controller (Optional) .............................................29

1 Accelerated Graphics Port (AGP) 4X Slot .................. 30

2 IDE Connectors (Optional Promise RAID Support)......6

2 IDE Connectors (UltraDMA/133 Support) .................... 7

MS / SD Connector ....................................................... 10

1 Panel Connector ........................................................14

1 Infrared Connector ..................................................... 15

USB Headers (Ports 2_3) .............................................17

USB Headers (Ports 20_34) .........................................27

Smart Card Connector .................................................. 20

Game Connector ........................................................... 21

ASUS iPanel Connector ................................................ 13

1394 Header .................................................................31

1 Parallel Port................................................................33

2 Serial Ports (COM1/COM2) .......................................38

USB 2.0 Connectors .....................................................37

USB 1.1 Connectors .....................................................39

1 PS/2 Mouse Connector .................................(green) 32

1 PS/2 Keyboard Connector .......................... (purple) 40

SPDIF Digital Audio Connector ..................................... 23

Audio Connectors..........................................................24

Audio Controller Chipset ............................................... 25

1 ASUS Front Audio Panel Connector ..........................22

1 Line Out Connector ......................................... (lime) 35

1 Line In Connector ................................... (light blue) 34

1 Microphone Connector .................................... (pink) 36

®

Athlon™ and Duron™ Processors....... 2

4

Chapter 1: Product introduction

1.4.1 Component Locations

31
30

29

1

253

4

6

7

8
9

28
27

26
25

24

32 33

18

19 15

16202122

10

11

12
13

141723

34
35
36

40 39 38

ASUS A7V333 motherboard user guide

37

5

Chapter 2

Hardware information

ASUS A7V333 motherboard

2.1 Motherboard installation

The A7V333 uses the A TX form factor , measuring 24.5 cm (9.6 in.) x 30.5 cm
(12 in.) - a standard fit for most large chassis.

WARNING! Unplug the power cord before installing the motherboard.

Failure to do so may cause you physical injury and damage motherboard
components.

2.1.1 Placement direction

When installing the motherboard, take care to orient the chassis correctly:
The edge with external ports goes to the rear part of the chassis. Refer to the
image below. It may be more convenient to install major cables, the CPU
and modular components before fixing the motherboard inside the case frame.

2.1.2 Screw holes

Place nine screws into the holes indicated by circles to secure the
motherboard to the chassis.

CAUTION! Do not overtighten the screws! Doing so may damage the

motherboard.

Place this side towards
the rear of the chassis

ASUS A7V333 motherboard user guide

7

2.2 Motherboard layout

®

24.5cm (9.6in)

PS/2KBMS
T: Mouse
B: Keyboard

USB1.1

T: USB0
B: USB1

COM1

KBWK
USB01_PWR

Socket 462

VID4
VID3
VID2
VID1

SPEECH

SPEECH
Controller

COM2

USB2.0

T: USB1
B: USB2

Top:Line In
Center:Line Out
Below:Mic In

1394HEAD

1394

Physical

Layer

Chip

VIA

VT6202

Chipset

LINE_IN

BCS1

CD

PARALLEL PORT

CPU_FAN PWR_FAN

JP1 JP2

MODEM

C-Media

CMI8738 6CH

Audio Controller

BCS2

IPANEL

AUX

BACK_LT

VIA

DDR DIMM2 (64/72 bit, 184-pin module)

KT333

Chipset

Accelerated Graphics Port (AGP Pro)

PCI1

PCI2

USB20_34

USBWP2_EN
USBWP1_EN

SPDIF_C

BACK_RT

1394_EN

PCI3

PCI4

PCI5

GAME

AUDIO_EN

A7V333

SMARTCARD

DDR DIMM1 (64/72 bit, 184-pin module)

2 3

0 1

CR2032 3V
Lithium Cell

CMOS Power

Super

I/O

USB_EN

PROMISE IDE2

DDR DIMM3 (64/72 bit, 184-pin module)

4 5

SYSCLK

2Mbit

Firmware

Hub

ATX Power Connector

RAID_EN

ROMSIP

PROMISE

PDC20276

ATA133

Controller

VIA

CLR_RTC

USB2_3

VT8233A

Chipset

FLOPPY

CHA_FAN

LED1

USB23_PWR

with Hardware

MS_SD_EN

AFPANEL

IR_CON

SMART

ASUS

ASIC

Monitor

PRIMARY IDE

BUZZER

SMB_CON

PANEL

PROMISE IDE1

SDMS

JTPWR
VID

JEN

CHASSIS

IDELED

SECONDARY IDE

30.5cm (12.0in)

Optional components are grayed in the above motherboard layout.

8

Chapter 2: Hardware information

2.2.1 Layout contents

CPU, Memory and Expansion Slots

1) Socket 462 p. 12 CPU Support

2) DIMM 1/2/3 p. 14 System Memory Support

3) PCI 1/2/3/4/5 p. 16 32-bit PCI Bus Expansion Slots

4) AGP PRO p. 18 Accelerated Graphics Slot

Motherboard Settings (Switches and Jumpers)

1) JEN p. 19 JumperFree Mode Setting (Disable/Enable)

2) DIP_SW p. 20 CPU External Frequency Selection

3) RAID_EN p. 21 RAID Controller (Enable/Disable)

4) ROMSIP p. 21 ROM Setting

5) VID1-4 p. 22

6) VID p. 22 Voltage Regulator Output Limit (Limit/Unlimited)

7) KBWK p. 23 Keyboard Wake Up (Enable/Disable)

8)

USB_EN

9)

USBWP2 & 1_EN

10)

USB01_,23_,45_PWR

11) 1394_En p. 26 IEEE-1394 Device Enable (Enable/Disable)

12) MS_SD_EN p. 26 MS SD Device Enable (Enable/Disable)

13) BCS1, BCS2 p. 27

14) SPEECH p. 27

15) AUDIO_EN p. 28 Audio Setting (Enable/Disable)

16) CLR_RTC p. 28 Clear RTC RAM

Connectors

p. 24 USB 2.0 Compliant Device Enable
p. 24 USB Wakeup Enable (Disable/Enable)
p. 25 USB Device Wake-up (Disable/Enable)

Voltage Regulator Output Setting (1.85-1.675 volts)

Bass Center Setting (CENTER/BASS, BASS/CENTER)
Speaker Selector (Buzzer/Back Panel)

(

Hardware/Software

(Switches 1–6)

)

(Disable/Enable)

1) PS2KBMS p. 29 PS/2 Mouse Port (6 pin female)

2) PS2KBMS p. 29 PS/2 Keyboard Port (6 pin female)

3) USB p. 30 U

4) PRINTER p. 30 Parallel Port (25 pin female)

5) COM1/COM2 p. 30 Serial Ports (9 pin /10-1 pin male)

6) AUDIO p. 31 Audio Connectors (Three 1/8” AUDIO) (optional)

7) IDELED p. 32 IDE Activity LED (2 pin)

8) FLOPPY p. 32 Floppy Disk Drive Connector (34-1 pin)

9) PRIMARY / SEC. IDE p. 33 IDE Connectors (Four 40-1 pin)
PROMISE 1 / 2 IDE

10)

CPU_,PWR_,CHA_F AN

11) IR_CON p. 35 Infrared Module Connector (10-1 pin)

12) AFPANEL p. 35 ASUS iPanel Connector (24-1 pin)

p. 34

niversal Serial Bus Ports 0, 1, 2 & 3 (Two 4 pin female)

CPU, Power, and Chassis Fan Connectors (Three 3 pin)

ASUS A7V333 motherboard user guide

9

13) ATXPWR p. 36 ATX Power Supply Connector (20 pin)

14) SMB p. 36 SMBus Connector (5-1 pin)

15) CD / AUX / MODEM p. 37 Internal Audio Connectors

16) JTPWR p. 34 Power Supply Thermal Sensor Connector (2 pin)

17) SMARTCARD p. 38 Smart Card Reader Connector (14-1 pin)

18) SD, MS p. 38 SD and MS Connectors (Two 10 pin)

19) GAME p. 39 Game Connector (16-1 pin)

20) SPDIF_C p. 39 Digital Audio Interfaces (2 pin)

21) USB20_34, USB2_3 p. 40 USB Headers (Two 10-1 pin)

22) CHASSIS p. 41 Chassis Open Alarm Lead (2 pin)

23) BACK_LT / BACK_RT p. 42 Line-out Selector Jumpers (4 pin)

24) LINE_IN p. 42 Audio Input Line In Header (5 pin)

25) IPANEL p. 43 ASUS Front Panel Audio Connector (10-1 pin)

26) 1394HEAD p. 43 IEEE-1394 Header (8 pin)

27) PLED (PANEL) p. 44 System Power LED Lead (3-1 pin)

28) KEYLOCK

29) SPEAKER (PANEL) p. 44 System Warning Speaker Lead (4 pin)

30) MLED (PANEL) p. 44 System Message LED Lead (2 pin)

(

PANEL)p. 44 System Keyboard Lock Switch Lead (2 pin)

(Three 4-1 pin) (optional)

31) SMI (PANEL) p. 44 System Management Interrupt Lead (2 pin)

32) PWR (PANEL) p. 44 ATX / Soft-Off Switch Lead (2 pin)

33) RESET (PANEL) p. 44 Reset Switch Lead (2 pin)

10

Chapter 2: Hardware information

2.3 Before you proceed

Take note of the following precautions before you install motherboard
components or change any motherboard settings.

CAUTION!

1. Unplug the power cord from the wall socket before touching any
component.

2. Use a grounded wrist strap or touch a safely grounded object or to a
metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity.

3. Hold components by the edges and do not to touch the ICs on them.

4. Whenever you uninstall any component, place it on a grounded
antistatic pad or in the bag that came with the component.

5. Before you install or remove any component, ensure that the

A TX power supply is switched off or the power cord is detached
from the power supply . Failure to do so may cause severe damage

to the motherboard, peripherals, and/or components.

NOTE! When lit, the onboard LED indicates that the system is ON, in

sleep mode or in soft-off mode, not powered OFF. See the illustration
below.

LED1

A7V333

A7V333 Onboard LED

®

ON

Standby

Power

OFF

Powered

Off

ASUS A7V333 motherboard user guide

11

2.4 Central Processing Unit (CPU)

2.4.1 Overview

The motherboard provides a Socket A (462) for CPU installation. AMD
processors offer gigahertz speeds to support all the latest computing platforms

™

and applications. The A7V333 supports Athlon
“QuantiSpeed” data processing, large data caches, 3D enhancements and
266MHz bus speeds.

XP processors with

LOCK

CPU NOTCH
TO INNER
CORNER

A7V333

AMD™ CPU

®

CPU NOTCH

LEVER

A7V333 Socket A

Each AMD CPU has a “marked” corner. This corner is indicated with a notch,
and/or a golden square or triangle. Refer to this indicator while orienting the
CPU. See the next section for installation details.

A fan and heatsink should be attached to the CPU to prevent overheating.

12

Chapter 2: Hardware information

2.4.2 Installing the CPU

Follow these steps to install a CPU:

1. Locate the Socket 462 and open it by
pulling the lever gently sideways away
from the socket. Then lift the lever
upwards. The socket lever must be fully
opened (90 to 100 degrees).

2. Insert the CPU with the correct
orientation. The notched or golden
corner of the CPU must be oriented
toward the inner corner of the socket
base nearest to the lever hinge.

CAUTION! The CPU should drop easily into place. Do not force the

CPU into the socket to avoid bending the pins. If the CPU does not fit,

check its alignment and look for bent pins.

4. Once completely inserted, press the CPU firmly and close the socket
lever until it snaps shut.

5. Place the CPU fan and heatsink on the CPU. The heatsink should entirely
cover the CPU. Carefully attach the heatsink locking brace to the plastic
clips on the socket base. With the added weight of the CPU fan and
heatsink locking brace, no extra force is required to keep the CPU in
place

CAUTION! Take care not to scrape the motherboard surface when

mounting a clamp-style processor fan, or else damage may occur . When
mounting a heatsink onto your CPU, make sure that exposed CPU
capacitors do not touch the heatsink, or damage may occur!

NOTE! Do not neglect to set the correct Bus Frequency and leave the

CPU Multiple setting at default to avoid start-up problems.

ASUS A7V333 motherboard user guide

13

2.5 System memory

2.5.1 Overview

This motherboard uses only Double Data Rate (DDR) Synchronous Dynamic
Random Access Memory (SDRAM) Dual Inline Memory Modules (DIMMs).
These sockets support up to 3GB system memory using non-ECC 200/266/
333MHz DIMMs.

Each DIMM socket/module is two-sided: each side defines one “row” of
memory. DIMMs come in combinations of single or double-sided types
ranging through 64MB, 128MB, 256MB, 512MB and 1GB to form a total
memory size of 64MB to 3GB.

~ Three (3) sockets are available for both 333MHz-PC2700, 266MHz-PC2100
or 200MHz-PC1600 DDR DIMMs to form a memory size of 64MB to 3GB.

80 Pins

104 Pins

A7V333

®

A7V333 184-Pin DDR DIMM Sockets

CAUTION! DIMMs are keyed to fit into notches with only one direction.

DO NOT force a DIMM into a socket to avoid damaging the DIMM.

• DIMMs with more than 18 chips are not supported.

• ASUS motherboards support SPD (Serial Presence Detect)DIMMs.

This is the memory of choice for best performance vs. stability

• BIOS shows DDR SDRAM memory on bootup screen.

• This motherboard supports three pairs of differential clock signals

per DIMM.

• For best performance, always use the “Performance” or “OEM”
grade of RAM.

14

Chapter 2: Hardware information

2.5.2 Memory configurations

Install DIMMs in any of the following combinations.

DIMM Location 184-pin DIMM (DDR) Total Memory

Socket 1 (Rows 0&1) 64MB, 128MB, 256MB, 512MB, 1GB x1
Socket 2 (Rows 2&3) 64MB, 128MB, 256MB, 512MB, 1GB x1
Socket 3 (Rows 4&5) 64MB, 128MB, 256MB, 512MB, 1GB x1

Total system memory (Max. 3GB) =

2.5.3 Installing a DIMM

CAUTION! Make sure to unplug the power supply before adding or

removing DIMMs or other system components. Failure to do so may cause
severe damage to both the motherboard and the components.

Installing a DIMM:

1. Unlock a DIMM socket by pressing the retaining clips outward.

2. Align a DIMM on the socket such that the notches on the DIMM exactly
match the notches in the socket.

3. Firmly insert the DIMM into the socket until the retaining clips snap back
in place.

Unlocked Retaining Clip Locked Retaining Clip

ASUS A7V333 motherboard user guide

15

2.6 Expansion slots

The motherboard has five PCI slot and one Accelerated Graphics Port (AGP)
slot.. The following sub-sections describe the slots and the expansion cards
that they support.

WARNING! Unplug your power supply when adding or removing

expansion cards or other system components. Failure to do so may cause
you physical injury and damage motherboard components.

2.6.1 Installing an expansion card

Follow these steps to install an expansion
card.

1. Before installing the expansion card, read
the documentation that came with it and
make the necessary hardware settings.

2. Remove the system unit cover (if your
motherboard is already installed in a
chassis).

3. Remove the bracket opposite the PCI slot.
Keep the screw for later use.

4. Align the card connector with the slot and
press firmly until the card is completely
seated on the slot.

5. Secure the card to the chassis with the
screw you removed earlier.

6. Replace the system cover.

7. Set up the BIOS if necessary.

8. Install the necessary software drivers for your expansion card.

2.6.2 Configuring an expansion card

Some expansion cards need an IRQ to operate. Generally , an IRQ must be
exclusively assigned to one function at a time. In a standard design
configuration, 16 IRQs are available but most are already in use. Normally,
6 IRQs are free for expansion cards. If the motherboard has PCI audio
onboard, an additional IRQ will be used. If your motherboard also has MIDI
enabled, another IRQ will be used, leaving 4 IRQs free. Sometimes IRQs
are “shared” by more than one function; in this case, IRQ assignments are
swapped automatically or adjusted through the BIOS firmware.

16

Chapter 2: Hardware information

IMPORTANT! When using PCI cards on shared slots, ensure that the

drivers support “Share IRQ” or that the cards do not need IRQ
assignments. Otherwise, conflicts will arise between the two PCI groups,
making the system unstable and the card inoperative.

Standard Interrupt Assignments

IRQ Priority Standard Function

0 1 System Timer
1 2 Keyboard Controller
2 N/A Programmable Interrupt
3* 11 Communications Port (COM2)
4* 12 Communications Port (COM1)
5* 13 Sound Card (sometimes LPT2)
6 14 Floppy Disk Controller
7* 15 Printer Port (LPT1)
8 3 System CMOS/Real Time Clock
9* 4 ACPI Mode when used
10* 5 IRQ Holder for PCI Steering
11* 6 IRQ Holder for PCI Steering
12* 7 PS/2 Compatible Mouse Port
13 8 Numeric Data Processor
14* 9 Primary IDE Channel
15* 10 Secondary IDE Channel

*These IRQs are usually available for ISA or PCI devices.

Interrupt Request Table for this Motherboard

This table lists the default IRQ assignments: they are applicable only for OS
Win98, WinME; for WinXP, system runs in APIC mode by default.

ABCD

PCI slot 1 ———shared
PCI slot 2 shared ———
PCI slot 3 — shared ——
PCI slot 4 ——shared —
PCI slot 5 ———shared
Onboard USB controller HC0 ———shared
Onboard USB controller HC1 ———shared
AGP shared ———
Onboard Audio — shared ——
USB 2.0 ———shared
Promise ———shared
TI 1394 — shared ——

ASUS A7V333 motherboard user guide

17

2.6.3 PCI slots

Five 32-bit PCI slots are available on this motherboard. The slots support
PCI cards such as a LAN card, SCSI card, USB card, and other cards that
comply with PCI specifications.

This figure shows a typical PCI card installed into a slot:

2.6.4 AGP PRO slot

This motherboard provides an Accelerated Graphics Port (AGP PRO) slot to
support AGP graphics cards. Take note of the notches on the card golden
fingers to ensure that they fit the AGP slot on your motherboard. Below is an
example of a +1.5V AGP card.

A7V333

®

A7V333 Accelerated Graphics Port (AGP)

CAUTION! To avoid damaging your AGP/AGP Pro graphics card, your

computer’s power supply should be unplugged before inserting your
graphics card into the slot.

Keyed for 1.5v

18

Chapter 2: Hardware information

2.7 Switches and jumpers

The jumpers on the motherboard allow you to change some feature
settings to suit your customized system configuration.

Motherboard Frequency Settings (DIP Switches)

The motherboard frequency is adjusted through the DSW switches. The
illustration below shows the default position:

SYSCLK

ON

12345

6

A7V333

®

A7V333 DIP Switches

ON

OFF

1.Frequency Selection

2.Frequency Selection

3.Frequency Selection

4.Frequency Selection

5.Frequency Selection

6.Frequency Selection

IMPORTANT! To use the DSW switches to make changes to speed

seettings, the JEN jumper must be reset to pins 1-2 (jumper mode).
Otherwise, setting the DSW switches does not produce any effect.

1) JumperFree™ Mode (3 pin JEN)

This jumper allows you to enable or disable the JumperFree™ mode. The
JumperFree™ mode allows processor settings to be made through the BIOS
setup.

A7V333

®

12

Jumper Mode

A7V333 JumperFree™ Mode Setting

NOTE! The JEN jumper is set in conjunction with the DIP switches. In

JumperFree™ mode, set all DIP switches (DIP_SW) to OFF.

ASUS A7V333 motherboard user guide

JEN

SYSCLK

ON

12345

23

Jumper Free

(Default)

6

19

2) CPU External Frequency Selection (DIP_SW Switches 1–4)

This option tells the clock generator what frequency to send to the CPU,
DRAM, and the PCI bus. This allows the selection of the CPU’s External
frequency (or BUS Clock). The BUS Clock multiplied by the Frequency
Multiple equals the CPU’s Internal frequency (the advertised CPU speed).

SYSCLK

ON

ON

ON

ON

A7V333

12345

CPU

CPU

®

CPU

100MHz

ON

12345

150MHz

ON

12345

200MHz

6

6

6

12345

133MHz

ON

12345

170MHz

ON

12345

210MHz

6

6

6

12345

166MHz

ON

12345

180MHz

ON

12345

220MHz

6

6

6

12345

140MHz

ON

12345

190MHz

ON

12345

230MHz

6

6

6

A7V333 CPU
External Frequency Selection

Frequency Table
DSW

CPU MHz 1 2 3 4 5 6
100 [OFF] [OFF] [OFF] [OFF] [ON] [ON]

133 [ON] [OFF] [OFF] [OFF] [OFF] [ON]
166 [ON] [ON] [OFF] [OFF] [OFF] [OFF]
140 [OFF] [ON] [ON] [OFF] [OFF] [ON]
150 [ON] [OFF] [OFF] [ON] [OFF] [ON]
170 [OFF] [OFF] [OFF] [ON] [OFF] [OFF]
180 [ON] [ON] [OFF] [ON] [OFF] [OFF]
190 [OFF] [ON] [OFF] [ON] [OFF] [OFF]
200 [ON] [OFF] [ON] [ON] [OFF] [OFF]
210 [OFF] [OFF] [ON] [ON] [OFF] [OFF]
220 [ON] [ON] [ON] [ON] [OFF] [OFF]
230 [OFF] [ON] [ON] [ON] [OFF] [OFF]

20

WARNING! Set the SYSCLK frequency only to the recommended

settings. Frequencies other than the recommended CPU bus frequencies
are not guaranteed to be stable. Overclocking the processor is not
recommended. It may result in a slower speed.

Chapter 2: Hardware information

3) RAID Controller (3 pin RAID_EN)

This jumper enables or disables the Promise IDE-RAID controller . The default
setting, [1-2], enables both the IDE 133 and RAID functions. To disable it,
reset the jumper cap to [2-3]. This jumper overrides all BIOS settings.

RAID_EN

12 23

A7V333

®

ENABLE DISABLE

(Default)

A7V333 PROMISE Setting

4) ROM Setting (3 pin ROMSIP)

This jumper selects the source for data to set functional parameters for the
CPU. The default jumper [2-3] enables the use of BIOS to set CPU
parameters. Resetting the jumper to [1-2], enables the use of preset ROM
data from the chip.

ROMSIP

22

A7V333

®

1

HARDWARE

ROMSIP

A7V333 ROMSIP Setting

ASUS A7V333 motherboard user guide

3

SOFTWARE

ROMSIP

(Default)

21

5) Voltage Regulator Output Setting (4x3 pin VID1 - 4)

This jumpers allow you to manually adjust the CPU core voltage. For each
jumper setting, there are two voltage options, depending on the CPU used.
The factory default sets all jumpers to [2-3], for use with JumperFree™ mode.

321

1.8/1.775Volts
321

1.7/1.675Volts

A7V333

VID4
VID3
VID2
VID1

VID4

®

VID3
VID2
VID1

321

1.85/1.825Volts
321

1.75/1.725Volts

A7V333 CPU Core Voltage
Selection

WARNING! CPU ove-voltage is not recommended. The CPU may fail

prematurely or inhibit speed performance.

6) Voltage Regulator Output Limit (3 pin VID)

321

JumperFree

(Default)

This jumpers offers extra security and control over the VID core voltage
settings. The default setting limits the voltage output to the default, and
does not allow any excess voltage emission to occur . Resetting the jumper
to [2-3] does not restrict voltage.

VID

12 23

A7V333

®

A7V333 VID Setting

LIMIT

(Default)

UNLIMITED

22

Chapter 2: Hardware information

7) Keyboard Wake Up (3 pin KBWK)

This allows you to disable or enable the keyboard power up function. Set this
jumper to Enable if you wish to use your keyboard (by pressing <Spacebar>)
to power up your computer . This feature requires an ATX power supply that
can supply at least 300mA on the +5VSB lead. The default is set to Enable.
(The computer will not power ON if you set this to Enable but do not have the
correct ATX power supply. NOTE: This jumper must be set in conjunction
with Wake On PS2 KB/PS2 Mouse/CIR in 4.5.1 Power Up Control.

KBWK

A7V333

®

A7V333 Keyboard Wake Up

2

1

Enable

(Default)

23

Disable

ASUS A7V333 motherboard user guide

23

8) USB 2.0 Compliant Device Enable (3 pin USB)

This jumper enables or disables the Universal Serial Bus (USB) 2.0 capability .
The default is set to enable [1-2] for use with USB 2.0 compliant devices.
NOTE: This jumper activates rear panel ports USB20_12.

USB_EN

A7V333

®

12

USB2.0 ENABLE

(Default)

23

USB2.0 DISABLE

A7V333 USB Setting

9) USB Wakeup Enable (2x3 pin USBWP2_EN, USBWP1_EN)

By default, these jumpers enable Wakeup power to the USB ports. The
circuit facilitates external power up from a USB device source. Switching
the jumper caps to [2-3] disables all device wakeup power to the USB ports.

24

A7V333

®

A7V333 USB Wake Up Setting

USBWP2_EN
USBWP1_EN

2312

WAKEUP

ENABLE
(Default)

WAKEUP
DISABLE

Chapter 2: Hardware information

10) USB Device Wake-up (2x3 pin USB01_PWR/USB23_PWR)

Set these jumpers to +5V to allow wake up from the S1 sleep state (CPU
stopped; RAM refreshed; system running in low power mode) using the
connected USB devices. Set to +5VSB to allow wake up from S3 sleep state
(no power to CPU; RAM in slow refresh; power supply in reduced power
mode). The default setting for the three jumpers is 1-2 to select +5V (because
not all computers have the appropriate power supply).

The USBO1_PWR jumper activates the rear panel USB ports. The
USB23_PWR jumper activates the internal header, USB2_3.

USB01_PWR

12

23

A7V333

®

A7V333 USB Device Wake Up

NOTE! This feature requires an ATX power supply that can supply at

least 2A on the +5VSB lead when these jumpers are set to +5VSB.
Otherwise, the system does not power up. The total current consumed
must NOT exceed the power supply capability (+5VSB) whether under
normal working conditions or in sleep mode.

+5V

(Default)

USB23_PWR

12

+5V

(Default)

+5VSB

23

+5VSB

ASUS A7V333 motherboard user guide

25

11) IEEE-1394 Device Enable (3 pin 1394_En)

This jumper opens the circuit to the 1394 headers. By default, [1-2] the
circuit is already open. Set to pins [2-3] to disable power to the 1394 header .

1394_EN

A7V333

12

®

1394
ENABLE
(Default)

23

1394

DISABLE

A7V333 1394HEAD Setting

12) MS SD Device Enable (3 pin MS_SD_EN)

This jumper opens the circuit to the MS SD headers. By default, [1-2] the
circuit is already open. Set to pins [2-3] to disable power to the MS SD
header.

26

A7V333

®

A7V333 MS SD Seeting

MS_SD_EN

3
2
1

MS SD

ENABLE
(Default)

2

MS SD

DISABLE

Chapter 2: Hardware information

13) Bass Center Setting (2x3 pin CENTER/BASS, BASS/CENTER)

Use these jumpers in conjunction with the C-Media PCI Audio Driver and to
adjust output for 4 or 6 speaker audio. No audio standard exists for the three
pick-up surfaces on male audio jacks, therefore it may be necessary to switch
jumpers from the default position, type 1, to type 2, in order to reroute signals
among the internal leads in the Line-In, Line-Out, Mic female sockets. Make
sure a test is made using the Audio Driver software setup available on the
Support CD.

23

BCS2

BCS1

TYPE 2 BASS

A7V333

12

®

TYPE 1 BASS

BCS1

(Default)

BCS2

A7V333 Bass Center Setting

14) Speaker Selector (3 pin SPEECH)

This jumper specifies which speaker to use for the ASUS POST Reporter
function. The default setting to pins [2-3] feeds an external speaker to the
Line-out jack (lime color). Set to pins [1-2] to use the internal buzzer (usually
included in the chassis).

SPEECH

12

BACK PANELBUZZER

A7V333

®

A7V333 Speaker Selector

ASUS A7V333 motherboard user guide

3

2

(Default)

27

15) Audio Setting (3 pin Audio_En)

The onboard 6 channel audio chip may be enabled or disabled using these
jumpers. The default, [1-2], enables the audio setting. Disable the onboard
audio system if using a PCI audio card on any of the expansion slots.

AUDIO_EN

A7V333

®

21

32

Disable

A7V333 Audio Codec Setting

Enable

(Default)

16)Clear RTC RAM (CLR_RTC)

This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS.
Y ou can clear the CMOS memory of date, time, and system setup parameters
by erasing the CMOS RTC RAM data. The RAM data in CMOS is powered
by the onboard button cell battery.

To erase the RTC RAM:

1. Turn OFF the computer and unplug the power cord.

2. Remove the battery.

3. Short the two solder points by touching a conductive metal object
to both points, like a paperclip or a screwdriver head.

4. Re-install the battery.

5. Plug the power cord and turn ON the computer.

6. Hold down the <Del> key during the boot process and enter BIOS
setup to re-enter data.

28

A7V333

®

A7V333 Clear RTC RAM

CLR_RTC

Short solder points
to Clear CMOS

Chapter 2: Hardware information

2.8 Connectors

This section describes and illustrates the internal connectors on the
motherboard.

WARNING! Some pins are used for connectors or power sources. These

are clearly distinguished from jumpers in the Motherboard Layout. Placing
jumper caps over these connector pins will cause damage to your
motherboard.

IMPORTANT! Ribbon cables should always be connected with the red

stripe to Pin 1 in the connector scoket.

1) PS/2 Mouse Port (Green 6-pin PS2KBMS)

The system automatically directs IRQ12 to the PS/2 mouse if one is detected.
If no mouse is detected, IRQ12 become available to expansion cards. See
PS/2 Mouse Function Control in 4.4 Advanced Menu.

PS/2 Mouse (6-pin Female)

2) PS/2 Keyboard Port (Purple 6-pin PS2KBMS)

This connection is for a standard keyboard using an PS/2 plug (mini DIN).
This connector does not allow standard AT size (large DIN) keyboard plugs.
You may use a DIN to mini DIN adapter on standard AT keyboards.

PS/2 Keyboard (6-pin Female)

ASUS A7V333 motherboard user guide

29

3) Universal Serial Bus Ports 0, 1, 2 & 3 (Black two 4-pin USB)

Four USB ports are available for connecting USB devices.

USB 0

USB 1

(Universal Serial Bus “1.1”)

USB 2
(Universal Serial Bus “2.0”)

USB 1

4) Parallel Port (Burgundy 25-pin PRINTER)
You can enable the parallel port and choose the IRQ through Onboard

Parallel Port (see 4.4.2 I/O Device Configuration).

NOTE! Serial printers must be connected to the serial port.

Parallel Port (25-pin Female)

5) Serial Ports (Teal/Turquoise 9-pin COM1 / 9-pin COM2)

T wo serial ports can be used for pointing devices or other serial devices. To
enable these ports, see Onboard Serial Port 1 / Onboard Serial Port 2 in

4.4.2 I/O Device Configuration for the settings.

COM2 COM1

Serial Ports (9-pin Male)

30

Chapter 2: Hardware information

6) Audio Connectors (Three 1/8” AUDIO) (optional)

The Line Out (lime) connects a headphone or speakers. The Line In (light
blue) connects a tape players or other audio sources. The Mic (pink) connects
a microphone.

NOTE! The functions of the audio connectors Line Out, Line In, and Mic

change when the 6-channel audio feature is enabled. Refer to Chapter

5. SOFTW ARE SETUP.

Audio Connectors

In

Out

Mic

ASUS A7V333 motherboard user guide

31

7) IDE Activity LED (2-pin IDELED)

This connector supplies power to the cabinet’s IDE activity LED. Read and
write activity by devices connected to the Primary or Secondary IDE
connectors cause the IDE LED to light up.

TIP: If the case-mounted LED does not
light, try reversing the 2-pin plug.

A7V333

®

IDELED

A7V333 IDE Activity LED

8) Floppy Disk Drive Connector (34-1 pin FLOPPY)

This connector supports the provided floppy drive ribbon cable. After
connecting the single end to the board, connect the two plugs on the other
end to the floppy drives. (Pin 5 is removed to prevent inserting in the

wrong orientation when using ribbon cables with pin 5 plugged).

32

A7V333

®

PIN 1

NOTE: Orient the red markings on
the floppy ribbon cable to PIN 1.

A7V333 Floppy Disk Drive Connector

FLOPPY

Chapter 2: Hardware information

9) Primary (Blue) / Secondary (Black) IDE Connectors

(40-1 pin PRIMARY IDE and SECONDARY IDE)

(40-1 pin PROMISE IDE1 and PROMISE2 IDE)
The Primary and Secondary IDE connectors support the IDE hard disk ribbon
cables supplied with the motherboard. Connect the cable’s blue connector
to the motherboard’s primary IDE connector (recommended) or the secondary
IDE connector . Connect the opposite end of the cable to your UltraDMA133/
100/66 device (hard disk drive). If a second hard disk drive is connected,
you may reset its jumper to Slave or Master/Slave mode. Non-UltraDMA133/
100/66 devices should be connected to the secondary IDE connector . BIOS
supports specific device bootup (see 4.6 Boot Menu.) UltraDMA/133 is
backward compatible with DMA100/66/33 and with all with existing DMA
devices and systems.

~ The A7V333 motherboard is supplied with two extra onboard IDE
connectors: one Promise IDE1 and one Promise IDE2. Use them to setup
the RAID 0 or 1 arrays and to support extra ATAPI devices. A total of eight
hard-disks, two on each IDE connector, can be connected to the A7V333;
but, only two can function in a RAID array. See 5.4 Software Setup for
more information about setting up a RAID array.

NOTE! For high-performance and RAID 0 or 1 set ups, always setup

two hard disks with two separate ribbon cables, one for the primary IDE
connector and another for the secondary IDE connector. Usually, both
disks must be set to the Master settings. Also, you may install one
operating system on an IDE drive and another on a SCSI drive and select
the boot disk through BIOS. (See 4.6 Boot Menu.) Do not connect any
other types of IDE devices to the Promise IDE connectors; they support
hard disk drive devices only.

IMPORTANT! UltraDMA100 and UltraDMA133 IDE devices require a

40-pin 80-conductor cable and RAID arrays only operate with such cables.

NOTE: Orient the red
markings(usually zigzag)
on the IDE ribbon
cable to PIN 1.

A7V333

Primary IDE Connector

A7V333 PROMISE IDE Connectors

PIN 1

ASUS A7V333 motherboard user guide

Secondary IDE Connector

PROMISE IDE2

PIN 1

PROMISE IDE1

33

10) CPU Fan, Power Fan, and Chassis Fan Connectors
(3x3 pin CPU_, PWR_, CHA_FAN)

Three fan connectors support cooling fans of 350mA (4.2 Watts) or less.
Orient the fans so that airflow flows across the onboard heat sinks instead of
expansion slots. The fan wiring and plug vary depending on the type
employed. Connect the fan cable to the connector, ensuring that the black
wire matches the ground pin. (Use the “Rotation” signal only with a specially
designed fan with a rotation signal. Y ou can monitor the Rotations Per Minute
(RPM) using ASUS PC Probe (see 6. SOFTWARE REFERENCE).

WARNING! Make sure to connect the fan cables to the fan connectors.

Lack of sufficient airflow within the system could cause damage to the
motherboard. These are not jumpers, do not place jumper caps over

these connectors!

A7V333

®

A7V333 12-Volt Fan Connectors

CPU_FAN PWR_FAN

Rotation

+12V
GND

Rotation

+12V

GND

CHA_FAN

Rotation

+12V

GND

34

Chapter 2: Hardware information

11) Infrared Module Connector (10-1 pin IR_CON)

This connector supports an optional wireless transmitting and receiving
infrared module. This module mounts to a small opening on system cases
that support it. Configure the IR setting through UART2 Use Infrared to
select whether UART2 is directed for use with COM2 or IrDA (see 4.4.2 I/O
Device Configuration). Use the five pins as shown and connect a ribbon
cable from the module to the motherboard SIR connector according to the
pin definitions. (A SIR module does not come with the motherboard package.
The CIR module is currently unavailable.)

Standard Infrared (SIR)

Front View Back View

IRTX
GND

IRRX

+5V
(NC)

A7V333

+5V

GND

IRTX

IRRX

SIR

GND

IRTX

®

CIRRX

CIR+5V

A7V333 Infrared Module Connector

12)ASUS iPanel Connector (24-1 pin AFPANEL)

This connector supports an optional ASUS iPanel, an easy to access drive
bay with front I/O ports, status LEDs, and space reserved for a hard disk
drive. Alternatively , if not using an ASUS iPanel, connect an optional wireless
transmitting and receiving infrared module to the SIR connector.

AFPANEL

A7V333

®

A7V333 iPanel Connector

SIR
CIR

+5 V

NC

GND

+5 V

NC

GND

IR_CON

IRRX

NC

IRRX

NC

GND

NC

GND

NC

SMBDATA

IRTX

+5VSB

CHASSIS#

IRTX

+5VSB

+3VSB

NCNCNC

+5V SMBCLK

MLED-

EXTSMI#

NC

NC

BATT

PCIRST#

ASUS A7V333 motherboard user guide

35

13) Power Supply Connectors (20-pin block ATXPWR)

This connector supports an A TX 12V power supply . The plug from the power
supply fits in only one orientation. Push down firmly ensuring that the pins
are aligned.

IMPORTANT! Make sure that the ATX 12V power supply (minimum

recommended wattage: 230W) can supply at least 10mA on the +5-volt
standby lead (+5VSB). The system may become unstable and may
experience difficulty powering up if the power supply is inadequate. For
Wake-On-LAN support, the A TX power supply must supply at least 720mA
+5VSB.

ATXPWR

Pin 1

A7V333

+12.0VDC

+5VSB

PWR_OK

COM

+5.0VDC

COM

®

+5.0VDC

COM
+3.3VDC
+3.3VDC

+5.0VDC
+5.0VDC

-5.0VDC
COM
COM
COM
PS_ON#
COM

-12.0VDC
+3.3VDC

A7V333 ATX Power Connectors

14) SMBus Connector (5-1 pin SMB)

This connector supports SMBus (System Management Bus) devices. SMBus
devices communicate by means of the SMBus with an SMBus host and/or
other SMBus devices. SMBus is a multi-device bus that permits multiple
chips to connect to the same bus and enable each one to act as a master by
initiating data transfer.

SMB

A7V333

®

A7V333 SMBus Connector

1

Ground

SMBCLK

+3V

SMBDATA

36

Chapter 2: Hardware information

15) Internal Audio Connectors (4 pin CD, AUX, MODEM) (optional)

These connectors allow you to receive stereo audio input from sound sources
as a CD-ROM, TV tuner, or MPEG card. The MODEM connector allows the
onboard audio to interface with a voice modem card with a similar connector .
It also allows the sharing of mono_in (such as a phone) and a mono_out
(such as a speaker) between the audio and a voice modem card.

MODEM

Modem-Out
Ground
Ground
Modem-In

A7V333

®

A7V333 Internal Audio Connectors

CD(Black) AUX (White)

Ground

Ground

Left Audio Channel

Right Audio Channel

Ground

Ground

Left Audio Channel

Right Audio Channel

16) Power Supply Thermal Sensor Connector (2 pin JTPWR)

If you have a power supply with thermal monitoring, connect its thermal sensor
cable to this connector.

JTPWR

A7V333

®

Power Supply
Thermal Sensor

A7V333 Thermal Sensor Connector

ASUS A7V333 motherboard user guide

37

17) Smart Card Reader Connector (14-1 pin SMARTCARD)

This connector accommodates a Smart Card Reader that allows you to
conveniently make transactions such as financial, health care, telephony , or
traveling services through a Smart Card user interface software. When using
this connector , configure the UART2 Use As parameter in BIOS to set UART2
for use with Smart Card. See Advanced BIOS sub-menu, “I/O Device
Configuration” for details.

SMARTCARD

SCIO

A7V333

NC

NC

®

NC

SCRREST

SCRRES#

1

VCC

A7V333 Smartcard

NC

SCPWR#

NC

SCRCLK

GND

NC2

18) SD and MS Connector (2 x 10 pin SD, MS)

These connectors support sophisticated memory devices: Secure Digital (SD)
memory card and Memory Sticks (MS). They facilitate fast and secure
downloading of all types of digital files. The SD and MS media may also be
used to record photos, music and movies.

A7V333

MS

1

GND

MSDA1

+3V

MSDA2

SDA3

®

SDA4
SDA5

SDACLK

SDAPWCTL#

SDALED

SDBCLK

SDBPWCTL#

SDBLED

GND

SDB1

+3V
SDB2
SDB3
SDB4
SDB5

SD

1

38

A7V333 SD MS Connectors

Chapter 2: Hardware information

19) Game Connector (16-1 pin GAME)

This connector supports an external game port. An example of a PCI game
port is illustrated.

A7V333

®

GAME

A7V333 Game Connector

+5V

J2B1

J2CX

MIDI_OUT

J2CY

J2B2

GND

J1CX

GND

J1CY

MIDI_IN

16

8

+5V

J1B2

9

1

+5V

J1B1

20) Digital Audio Interfaces (6-1 pin SPDIF_C)

These connectors supply an SPDIF audio cable that outputs digital instead
of analog sound from CD-ROM, DVD-ROM, CD-RW, and advanced sound
cards such as SoundBlaster Live. (The SPDIF module is not included in this
product.)

SPDIF_C

GND

GND

1

A7V333

®

A7V333 Digital Audio Connector

+5V

SPDIF_IN

SPDIF_OUT

ASUS A7V333 motherboard user guide

39

21) USB Headers (10-1 pin USB20_34, USB2_3)

If the USB port connectors on the back panel are inadequate, two USB
headers are available for four additional USB port connectors. Connect a
2-port USB connector set to a USB header and mount the USB bracket to an
open slot in the chassis. The USB20_34 header supports the USB 2.0
protocol and the USB2_3 header supports the USB 1.1 header .

GND

LDP2

LDM2

USB+5V

GND

LDP1

610
15

LDM1

USB+5V

A7V333

®

A7V333 USB 2.0 Header

USB20_34

(Blue)

NC

A7V333

®

A7V333 USB1.1 Header

USB2_3

(White)

GND

USBP3+

USBP3–

NC

GND

USBP2–

USBP2+

USB Power

610
15

USB Power

40

Chapter 2: Hardware information

22) Chassis Open Alarm Lead (4-1 pin CHASSIS)

This lead is intended for a chassis designed to support intrusion detection.
The lead requires an external detection mechanism such as a chassis
intrusion monitor/sensor or microswitch. When any chassis component is
removed, the sensor is triggered and a high-level signal is sent to this lead to
record a chassis intrusion event. The event is then be processed by software
such as LDCM. When not using the chassis intrusion lead, place a jumper
cap over the pins to close the circuit. Removing the jumper cap will prevent
the system from booting up.

CHASSIS

A7V333

®

A7V333 Chassis Alarm Lead

+5VSB_MB

Chassis Signal

GND

ASUS A7V333 motherboard user guide

41

23) Line-out Selector Jumpers (4 pin BACK_LT / BACK_RT)

By default, these jumpers are shorted (jumpers on) to route the signal from
the audio controller to the rear panel Line Out jack to make it available for
audio out devices such as speakers or a headphone. If you connect the Intel
Front Panel audio cable to the IPANEL connector (see next page), then
remove the caps from these two jumpers to permit automatic switching of
audio signals between the rear panel Line Out jack and the Intel audio cable.

BLOL

FLOL

BLOR

A7V333

®

FLOR

BACK_LT

BACK_RT

A7V333 Internal Line Out Connectors

24) Audio Input Line In Header (LINE_IN)

This connector suports audio input on left and right stereo audio channels.
NOTE: The motherboard ships with Jumper caps over pins 1-2 and 4-5.
Remove them only when making audio input connections.

LINE_IN

AGND

BLINE_LIN_L

A7V333

®

BLINE_IN_R

ALINE_LIN_L

LINE_IN_R

42

A7V333 LINE_IN Connector

Chapter 2: Hardware information

25) ASUS Front Panel Audio Connector (10-1 pin IPANEL)

Connect the audio cable for front panel audio control.

IPANEL

NC

Line out_R

MICPWR+5VA

Line out_L

MIC2

A7V333

®

BLINE_OUT_L

AGND

BLINE_OUT_R

A7V333 Front Panel Audio Connector

26) IEEE-1394 Header (8-pin 1394HEAD) (Optional)

This header supports an IEEE-1394 serial connector cable set that mounts
to a standard expansion slot in the computer case. 1394-compliant internal
fixed disk drives may also be connected to these headers.

+12V
Ground
TPB­TPB+
TPA­TPA+
Ground

A7V333

®

Ground

1394HEAD

A7V333 IEEE-1394 Headers

ASUS A7V333 motherboard user guide

43

The following 20-pin PANEL illustration is for items 27-33.

PLED

Keylock

MLED

ExtSMI#

Ground

Ground

Speaker
Connector

Ground

Speaker

Ground

+5V

PWR

Reset

Ground

Ground

Reset SW

ATX Power
Switch*

A7V333

Keyboard Lock

Power LED

+5 V

+5 V

®

Message LED

SMI Lead

*

Requires an ATX power supply.

A7V333 System Panel Connectors

27) System Power LED Lead (3-1 pin PLED)

This 3-1 pin connector supplies the system power LED. The LED lights up
when the system power is on, and the LED blinks when the system is in
sleep or soft-off mode.

28) Keyboard Lock Switch Lead (2 pin KEYLOCK)

This 2-pin connector supplies the case-mounted key switch for keyboard
locking.

29) System Warning Speaker Lead (4 pin SPEAKER)

This 4-pin connector supplies the case-mounted speaker to sound system
beeps and warnings.

30) System Message LED Lead (2 pin MLED)

This 2-pin connector supports the system message LED to indicate receipt
of messages from a fax/modem. The normal status for this LED is ON,
when there is no incoming data signal. The LED blinks when data is received.
The system message LED feature requires an ACPI OS and driver support.

31) System Management Interrupt Lead (2 pin SMI)

This 2-pin connector permits switching to suspend mode, or “Green” mode,
in which system activity is instantly decreased to save power and to expand
the life of certain system components. Attach the case-mounted suspend
switch this 2-pin connector.

32) ATX Power Switch / Soft-Off Switch Lead (2 pin PWR)

The system power is controlled by a momentary switch attached to this
connector . Pressing the button switches the system between ON and SLEEP ,
or ON and SOFT OFF, depending on the BIOS or OS settings. Pressing the
button while in the ON mode for more than 4 seconds turns the system off.

33) Reset Switch Lead (2-pin RESET)

This 2-pin connector supports the case-mounted reset switch for rebooting
the system without turning off the power switch.

44

Chapter 2: Hardware information

Chapter 3

Powering up

ASUS A7V333 motherboard

3.1 Starting up for the first time

1. After making all the connections, replace the system case cover.

2. Be sure that all switches are off.

3. Connect the power cord to the power connector at the back of the
system chassis.

4. Connect the power cord to a power outlet that is equipped with a surge
protector.

5. Turn on the devices in the following order:

a. Monitor
b. External SCSI devices (starting with the last device on the chain)
c. System power (if you are using an ATX power supply, you need to

switch on the power supply as well as press the ATX power switch
on the front of the chassis).

6. After applying power, the power LED on the system front panel case
lights up. For ATX power supplies, the system LED lights up when you
press the ATX power switch. If your monitor complies with “green”
standards or if it has a “power standby” feature, the monitor LED may
light up or switch between orange and green after the system LED
turns on. The system then runs the power-on tests. While the tests are
running, the BIOS beeps or additional messages appear on the
screen. If you do not see anything within 30 seconds from the time you
turned on the power, the system may have failed a power-on test.
Check the jumper settings and connections or call your retailer for
assistance.

Award BIOS Beep Codes

Beep Meaning

One short beep when No error during POST
displaying logo

Long beeps in an endless loop No DRAM installed or detected
One long beep followed by Video card not found or video card

three short beeps memory bad
High frequency beeps when CPU overheated;

system is working System running at a lower frequency

You will not hear the BIOS beeps when the ASUS POST Reporter is
enabled. You will hear the vocal POST messages instead.

7. At power on, hold down <Delete> to enter BIOS Setup. Follow the
instructions in Chapter 4.

ASUS A7V333 motherboard user guide

45

3.2 Vocal POST Messages

This motherboard includes the Winbond speech controller to support a
special feature called the ASUS POST Reporter™. This feature gives you
vocal POST messages and alerts to inform you of system events and boot
status. In case of a boot failure, you will hear the specific cause of the
problem.

These POST messages are customizable using the Winbond Voice Editor
software that came with your package. You can record your own
messages to replace the default messages.

Following is a list of the default POST messages and their corresponding
actions, if any.

POST Voice Message Action

No CPU installed • Install an Intel Pentium 4

478/Northwood Processor into the
CPU socket.

System failed CPU test • Check the CPU if properly installed.

• Call ASUS technical support for
assistance. See the “ASUS contact
information” and www.asus.com

System failed memory test • Install 184-pin unbuffered

DDR modules into the DIMM
sockets.

• Check if the DIMMs on the DIMM
sockets are properly installed.

• Make sure that your DIMMs are
not defective.

System failed VGA test • Install a PCI VGA card into one of

the PCI slots, or a 1.5V AGP card
into the AGP slot.

• Make sure that your VGA/AGP card
is not defective.

System failed due to CPU • In JumperFree mode, check your
over-clocking CPU settings in BIOS and make

sure you only set to the recom­mended settings. See section “4.4
Advanced menu.”

• In jumper mode, refer to section
“2.7 Switches and jumpers.”

46

Chapter 3: Powering up

POST Message Action

No keyboard detected • Check your keyboard if properly

connected to the purple PS/2
connector on the rear panel.

• See section “1.4.1 Component
Locations” for the location of the
keyboard connector.

No floppy disk detected • Make sure you have connected a

floppy disk to the floppy disk
connector on the motherboard.

• See section “2.8 Connectors.”

No IDE hard disk detected • Make sure you have connected an

IDE hard disk drive to the one of the
IDE connectors on the motherboard.

• See section “2.8 Connectors.”

CPU temperature too high • Check CPU fan if working properly.
CPU fan failed • Check the CPU fan and make sure

it turns on after you applied power
to the system.

CPU voltage out of range • Check your power supply and

make sure it is not defective.

• Call ASUS technical support for
assistance. See the “ASUS contact
information” on page x.

System completed Power-On Self Test • No action required
Computer now booting from operating • No action required

system

You may disable the ASUS POST Reporter in the BIOS setup. See
section “4.4.2 I/O Device Configuration”.

ASUS A7V333 motherboard user guide

47

3.3 Powering off the computer

You must first exit the operating system and shut down the system before
switching off the power. For ATX power supplies, you can press the ATX
power switch after exiting or shutting down the operating system. If you
use Windows 95/98/2000/XP, click the Start button, click Shut Down, then
click the OK button to shut down the computer. The power supply should
turn off after Windows shuts down.

The message “You can now safely turn off your computer” does not
appear when shutting down with ATX power supplies.

48

Chapter 3: Powering up

Chapter 4

BIOS setup

ASUS A7V333 motherboard

4.1 Managing and updating your BIOS

4.1.1 Using the computer system for the first time

It is recommended that you save a copy of the original motherboard BIOS
along with a Flash Memory Writer utility (AFLASH.EXE) to a bootable floppy
disk in case you need to reinstall the BIOS later. AFLASH.EXE is a Flash
Memory Writer utility that updates the BIOS by uploading a new BIOS file to
the programmable flash ROM on the motherboard. This file works only in
DOS mode. To determine the BIOS version of your motherboard, check the
last four numbers of the code displayed on the upper left-hand corner of your
screen during bootup. Larger numbers represent a newer BIOS file. Proceed
to the next page for more information on using AFLASH from a floppy disk.

ASUS POST Flash Utility

An alternative utility for flashing a new BIOS is now available: ASUS POST
Flash; press <AL T> <F2> just after the memory test during boot-up. ASUS
POST Flash functions much like regular AFLASH, but no floppy disk is

required: ASUS POST Flash is built-in to the existing BIOS firmware of
new BIOS editions. First, visit the ASUS website to download the BIOS
that you want to copy it to a floppy disk. To better protect the system,
download both the new version of the BIOS and the BIOS version presently
in use, then copy them to a floppy disk in case you need to reflash the
original BIOS, or if the new one does not function.

To flash a new BIOS using POST Flash Utility, type the filename of the
new BIOS file at the prompt and press <enter>. Then, select the type of
update and select (Y). The new BIOS is recorded into the firmware
memory. Press <ESC> to reboot.

ASUS A7V333 motherboard user guide

49

Using AFLASH from a Floppy Disk:

1. T ype FORMAT A:/S at the DOS prompt to create a bootable system disk.
DO NOT copy AUTOEXEC.BAT and CONFIG.SYS to the disk.

2. T ype COPY D:\AFLASH\AFLASH.EXE A:\ (assuming D is your CD-ROM
drive) to copy AFLASH.EXE to the boot disk you created.

NOTE! AFLASH works only in DOS mode. It does not function in the

DOS prompt within Windows, and does not function with certain memory
drivers that may be loaded when you boot from the hard drive. It is
recommended that you reboot using a floppy disk. Use only a DOS 6.2,
WIN95 / WIN98 boot disk.

3. Reboot the computer from the floppy disk.

NOTE! BIOS setup must specify “Floppy” as the first item in the boot

sequence.

4. In DOS mode, type A:\AFLASH <Enter> to run AFLASH.

IMPORTANT! If the word “unknown” appears after Flash Memory:, the

memory chip is either not programmable or is not supported by the ACPI
BIOS and therefore, cannot be programmed by the Flash Memory Writer
utility.

5. Select 1. Save Current BIOS to File from the Main menu and press
<Enter>. The Save Current BIOS To File screen appears.

6. Type a filename and the path, for example, A:\XXX-XX.XXX, then
press <Enter>.

50

Chapter 4: BIOS Setup

4.1.2 Updating BIOS procedures

CAUTION! Update the BIOS only if you have problems with the

motherboard and you are sure that the new BIOS revision will solve your
problems. Careless updating may result to more problems with the
motherboard!

1. FTP) (see ASUS CONTACT INFORMATION on page x for details) and
save to the boot floppy disk you created earlier.

2. Boot from the floppy disk.

3. At the “A:\” prompt, type AFLASH and then press <Enter>.

4. At the Main Menu, type 2 then press <Enter>. The Update BIOS Including
Boot Block and ESCD screen appears.

5. Type the filename of your new BIOS and the path, for example, A:\XXX­XX.XXX, then press <Enter>.

To cancel this operation, press <Enter>.

6. When prompted to confirm the BIOS update, press Y to start the
update.

ASUS A7V333 motherboard user guide

51

7. The utility starts to program the new BIOS information into the Flash
ROM. The boot block is updated automatically only when necessary.
This minimizes the possibility of boot problems in case of update failures.
When the programming is done, the message “Flashed Successfully”
appears.

8. Follow the onscreen instructions to continue.

52

WARNING! If you encounter problems while updating the new BIOS,

DO NOT turn off the system because this may cause boot problems.
Just repeat the process, and if the problem persists, load the original
BIOS file you saved to the boot disk. If the Flash Memory Writer utility is
not able to successfully update a complete BIOS file, the system may not
boot. If this happens, call the ASUS service center for support.

Chapter 4: BIOS Setup

4.2 BIOS Setup program

This motherboard supports a programmable EEPROM that you can update
using the provided utility described in section “4.1 Managing and updating

your BIOS.”

Use the BIOS Setup program when you are installing a motherboard,
reconfiguring your system, or prompted to “Run Setup”. This section explains
how to configure your system using this utility.

Even if you are not prompted to use the Setup program, you may want to
change the configuration of your computer in the future. For example, you
may want to enable the security password feature or make changes to the
power management settings. This requires you to reconfigure your system
using the BIOS Setup program so that the computer can recognize these
changes and record them in the CMOS RAM of the EEPROM.

The EEPROM on the motherboard stores the Setup utility. When you start
up the computer, the system provides you with the opportunity to run this
program. Press <Delete> during the Power-On Self Test (POST) to enter the
Setup utility, otherwise, POST continues with its test routines.

If you wish to enter Setup after POST, restart the system by pressing <Ctrl>
+ <Alt> + <Delete>, or by pressing the reset button on the system chassis.
You can also restart by turning the system off and then back on. Do this last
option only if the first two failed.

The Setup program is designed to make it as easy to use as possible. It is a
menu-driven program, which means you can scroll through the various sub­menus and make your selections among the predetermined choices.

NOTE! Because the BIOS software is constantly being updated, the

following BIOS setup screens and descriptions are for reference purposes
only, and may not exactly match what you see on your screen.

ASUS A7V333 motherboard user guide

53

4.2.1 BIOS menu bar

The top of the screen has a menu bar with the following selections:
MAIN Use this menu to make changes to the basic system

configuration.

ADVANCED Use this menu to enable and make changes to the

advanced features.

POWER Use this menu to configure and enable Power Management

features.

BOOT Use this menu to configure the default system device used

to locate and load the Operating System.

EXIT Use this menu to exit the current menu or to exit the Setup

program.

T o access the menu bar items, press the right or left arrow key on the keyboard
until the desired item is highlighted.

4.2.2 Legend bar

At the bottom of the Setup screen is a legend bar . The keys in the legend bar
allow you to navigate through the various setup menus. The following table
lists the keys found in the legend bar with their corresponding functions.

Navigation Key(s) Function Description

<F1> or <Alt + H> Displays the General Help screen from any-

where in the BIOS Setup

<Esc> Jumps to the Exit menu or returns to the main

menu from a sub-menu

Left or Right arrow Selects the menu item to the left or right
Up or Down arrow Moves the highlight up or down between fields

- (minus key) Scrolls backward through the values for the

highlighted field

+ (plus key) or spacebar Scrolls forward through the values for the high-

lighted field

<Enter> Brings up a selection menu for the highlighted

field

<Home> or <PgUp> Moves the cursor to the first field
<End> or <PgDn> Moves the cursor to the last field
<F5> Resets the current screen to its Setup Defaults
<F10> Saves changes and exits Setup

54

Chapter 4: BIOS Setup

General help

In addition to the Item Specific Help window, the BIOS setup program also
provides a General Help screen. You may launch this screen from any menu
by simply pressing <F1> or the <Alt> + <H> combination. The General Help
screen lists the legend keys and their corresponding functions.

Saving changes and exiting the Setup program

See “4.7 Exit Menu” for detailed information on saving changes and exiting
the setup program.

Scroll bar

When a scroll bar appears to the right of a help window, it indicates that
there is more information to be displayed that will not fit in the window. Use
<PgUp> and <PgDn> or the up and down arrow keys to scroll through the
entire help document. Press <Home> to display the first page, press <End>
to go to the last page. To exit the help window, press <Enter> or <Esc>.

Sub-menu

Note that a right pointer symbol (as shown
on the left) appears to the left of certain
fields. This pointer indicates that you
can display a sub-menu from this field.
A sub-menu contains additional options for
a field parameter. To display a sub-menu,
move the highlight to the field and press
<Enter>. The sub-menu appears. Use the
legend keys to enter values and move
from field to field within a sub-menu as
you would within a menu. Use the <Esc>
key to return to the main menu. Take some
time to familiarize yourself with the legend
keys and their corresponding functions.
Practice navigating through the various menus and sub-menus.
If you accidentally make unwanted changes to any of the fields, use the set
default hot key <F5> to load the Setup default values. While moving around
through the Setup program, note that explanations appear in the Item Specific
Help window located to the right of each menu. This window displays the
help text for the currently highlighted field.

ASUS A7V333 motherboard user guide

55

4.3 Main Menu

When you enter the Setup program, the following screen appears.

System Time [XX:XX:XX]

Sets the system to the time that you specify (usually the current time). The
format is hour , minute, second. V alid values for hour , minute and second are
Hour: (00 to 23), Minute: (00 to 59), Second: (00 to 59). Use the <Tab> or
<Shift> + <Tab> keys to move between the hour, minute, and second fields.

System Date [XX/XX/XXXX]

Sets the system to the date that you specify (usually the current date). The
format is month, day , year. Valid values for month, day , and year are Month:
(1 to 12), Day: (1 to 31), Year: (up to 2084). Use the <Tab> or <Shift> +
<Tab> keys to move between the month, day, and year fields.

Legacy Diskette A [1.44M, 3.5 in.]
Legacy Diskette B [None]

Sets the type of floppy drive installed. Configuration options: [None] [360K,

5.25 in.] [1.2M , 5.25 in.] [720K , 3.5 in.] [1.44M, 3.5 in.] [2.88M, 3.5 in.]

Floppy 3 Mode Support [Disabled]

This is required to support older Japanese floppy drives. The Floppy 3 Mode
feature allows reading and writing of 1.2MB (as opposed to 1.44MB) on a

3.5-inch diskette. Configuration options: [Disabled] [Enabled]

56

Chapter 4: BIOS Setup

4.3.1 Primary and Secondary Master/Slave

Type [Auto]

Select [Auto] to automatically detect an IDE hard disk drive. If automatic
detection is successful, Setup automatically fills in the correct values for the
remaining fields on this sub-menu. If automatic detection fails, this may be
because the hard disk drive is too old or too new . If the hard disk was already
formatted on an older system, Setup may detect incorrect parameters. In
these cases, select [User Type HDD] to manually enter the IDE hard disk
drive parameters. Refer to the next section for details.

CAUTION! Before attempting to configure a hard disk drive, make sure

you have the correct configuration information supplied by the drive
manufacturer. Incorrect settings may cause the system to fail to recognize
the installed hard disk.

ASUS A7V333 motherboard user guide

57

[User Type HDD]

Manually enter the number of cylinders, heads and sectors per track for the
drive. Refer to the drive documentation or on the drive label for this information.

NOTE! After entering the IDE hard disk drive information into BIOS, use

a disk utility, such as FDISK, to partition and format new IDE hard disk
drives. This is necessary so that you can write or read data from the hard
disk. Make sure to set the partition of the Primary IDE hard disk drives to
active.

If no drive is installed or if you are removing a drive and not replacing it,
select [None].

Other options for the Type field are:

[CD-ROM] - for IDE CD-ROM drives
[LS-120] - for LS-120 compatible floppy disk drives
[ZIP] - for ZIP-compatible disk drives
[MO] - for IDE magneto optical disk drives
[Other A TAPI Device] - for IDE devices not listed here

After making your selections on this sub-menu, press the <Esc> key to return
to the Main menu. When the Main menu appears, the hard disk drive field
displays the size for the hard disk drive that you configured.

58

Chapter 4: BIOS Setup

Translation Method [LBA]

Select the hard disk drive type in this field. When Logical Block Addressing
(LBA) is enabled, the 28-bit addressing of the hard drive is used without
regard for cylinders, heads, or sectors. Note that LBA Mode is necessary for
drives with more than 504MB storage capacity . Configuration options: [LBA]
[LARGE] [Normal] [Match Partition Table] [Manual]

Cylinders

This field configures the number of cylinders. Refer to the drive documentation
to determine the correct value. To make changes to this field, set the Type
field to [User Type HDD] and the Translation Method field to [Manual].

Head

This field configures the number of read/write heads. Refer to the drive
documentation to determine the correct value. To make changes to this field,
set the Type field to [User Type HDD] and the Translation Method field to
[Manual].

Sector

This field configures the number of sectors per track. Refer to the drive
documentation to determine the correct value. To make changes to this field,
set the Type field to [User Type HDD] and the Translation Method field to
[Manual].

CHS Capacity

This field shows the drive’s maximum CHS capacity as calculated by the
BIOS based on the drive information you entered.

Maximum LBA Capacity

This field shows the drive’s maximum LBA capacity as calculated by the
BIOS based on the drive information you entered.

Multi-Sector Transfers [Maximum]

This option automatically sets the number of sectors per block to the highest
number that the drive supports. Note that when this field is automatically
configured, the set value may not always be the fastest value for the drive.
You may also manually configure this field. Refer to the documentation that
came with the hard drive to determine the optimum value and set it manually .
To make changes to this field, set the Type field to [User Type HDD].
Configuration options: [Disabled] [2 Sectors] [4 Sectors] [8 Sectors] [16
Sectors] [32 Sectors] [Maximum]

ASUS A7V333 motherboard user guide

59

SMART Monitoring [Disabled]

This field allows you to enable or disable the S.M.A.R.T. (Self-Monitoring,
Analysis and Reporting Technology) system that utilizes internal hard disk
drive monitoring technology. This parameter is normally disabled because
the resources used in the SMART monitoring feature may decrease system
performance. Configuration options: [Disabled] [Enabled]

PIO Mode [0]

This option lets you set a PIO (Programmed Input/Output) mode for the IDE
device. Modes 0 through 4 provide successive increase in performance.
Configuration options: [0] [1] [2] [3] [4]

Ultra DMA Mode [Disabled]

Ultra DMA capability allows improved transfer speeds and data integrity for
compatible IDE devices. Set to [Disabled] to suppress Ultra DMA capability.
To make changes to this field, set the Type field to [User Type HDD].
Configuration options: [0] [1] [2] [3] [4] [5] [Disabled]

60

Chapter 4: BIOS Setup

4.3.2 Keyboard Features

Boot Up NumLock Status [On]

This field enables users to activate the Number Lock function upon system
boot. Configuration options: [Off] [On]

Keyboard Auto-Repeat Rate [12/Sec]

This controls the speed at which the system registers repeated keystrokes.
Options range from 6 to 30 characters per second. Configuration options: [6/
Sec] [8/Sec] [10/Sec] [12/Sec] [15/Sec] [20/Sec] [24/Sec] [30/Sec]

Keyboard Auto-Repeat Delay [1/4 Sec]

This field sets the time interval for displaying the first and second characters.
Configuration options: [1/4 Sec] [1/2 Sec] [3/4 Sec] [1 Sec]

ASUS A7V333 motherboard user guide

61

Language [English]

This field displays the BIOS language version.

Supervisor Password [Disabled] / User Password [Disabled]

These fields allow you to set passwords. To set a password, highlight the
appropriate field and press <Enter>. T ype in a password then press <Enter>.
You can type up to eight alphanumeric characters. Symbols and other
characters are ignored. To confirm the password, type the password again
and press <Enter>. The password is now set to [Enabled]. This password
allows full access to the BIOS Setup menus. To clear the password, highlight
this field and press <Enter>. The same dialog box as above appears. Press
<Enter>. The password is set to [Disabled].

A note about passwords

The BIOS Setup program allows you to specify passwords in the Main
menu. The passwords control access to the BIOS during system startup.
Passwords are not case sensitive, meaning, passwords typed in either
uppercase or lowercase letters are accepted. The BIOS Setup program
allows you to specify two different passwords: a Supervisor password
and a User password. If you did not set a Supervisor password, anyone
can access the BIOS Setup program. If you did, the Supervisor password
is required to enter the BIOS Setup program and to gain full access to
the configuration fields.

Forgot the password?

If you forget your password, you can clear it by erasing the CMOS Real
Time Clock (RTC) RAM. The RAM data containing the password
information is powered by the onboard button cell battery. See section
“2.7Switches and jumpers” for information on how to erase the R TC
RAM.

Halt On [All Errors]

This field specifies the types of errors that will cause the system to halt.
Configuration options: [All Errors] [No Error] [All but Keyboard] [All but Disk]
[All but Disk/Keyboard]

Installed Memory [XXX MB]

This field automatically displays the amount of conventional memory detected
by the system during the boot process.

62

Chapter 4: BIOS Setup

4.4 Advanced Menu

CPU Speed [Manual]

When the motherboard is set to JumperFree™ mode, this field allows you to
select the internal frequency of the CPU. Select [Manual] if you want to make
changes to the two subsequent fields. Note that selecting a frequency higher
than the CPU manufacturer recommends may cause the system to hang or
crash.

CPU Frequency Multiple (when CPU Speed is set to [Manual])

This field applies to unlocked processors only. If your processor frequency
multiple is locked, you cannot access this field. This field sets the frequency
multiple between the CPU’s internal frequency (CPU speed) and external
frequency . Set this field in conjunction with CPU Frequency (MHz) to match
the speed of the CPU. Configuration options: [5.0X]...[14.0X]

CPU/PCI Frequency (MHz) (when CPU Speed is set to [Manual])

This feature tells the clock generator what frequency to send to the system
bus and PCI bus. The bus frequency (external frequency) multiplied by the
bus multiple equals the CPU speed. Configuration options: [100:33]...
[227:45]

CPU/Memory Frequency Ratio [Auto]

This field determines whether the memory clock frequency is set to be in
synchronous or asynchronous mode with respect to the system frequency.
If available, the options that appear in the popup menu vary according to the
CPU Frequency (MHz). Configuration options: [Auto]

ASUS A7V333 motherboard user guide

63

CPU VCore Setting [Auto]

This field determines if the CPU Vcore is automatically scaled or set manually
by the user. The default for this field is [Auto], so the CPU vcore voltage is
set for maximum performance without stressing the CPU. Configuration
options: [Manual] [Auto]

CPU VCore [1.850V]

When the CPU VCore Setting parameter is set to [Manual], this item allows
you to select a specific CPU core voltage. This field is not accessible when
the CPU VCore Setting parameter is set to [Auto]. Configuration options:
[1.100V] ...[1.850V]

CAUTION! Refer to the CPU documentation before setting this field.

A very high core voltage may severely damage the CPU.

CPU Level 1 Cache, CPU Level 2 Cache [Enabled]

These fields allow you to choose from the default of [Enabled] or choose
[Disabled] to turn on or off the CPU Level 1 and Level 2 built-in cache.
Configuration options: [Disabled] [Enabled]

PS/2 Mouse Function Control [Auto]

The default setting [Auto] allows the system to detect a PS/2 mouse at startup.
If a mouse is detected, the BIOS assigns IRQ12 to the PS/2 mouse.
Otherwise, IRQ12 can be used for expansion cards. When you set this field
to [Enabled], BIOS reserves IRQ12, whether or not a PS/2 mouse is detected
at startup. Configuration options: [Enabled] [Auto]

USB Legacy Support [Auto]

This motherboard supports Universal Serial Bus (USB) devices. The default
of [Auto] allows the system to detect a USB device at startup. If detected, the
USB controller legacy mode is enabled. If not detected, the USB controller
legacy mode is disabled. When you set this field to [Disabled], the USB
controller legacy mode is disabled whether or not you are using a USB device.
Configuration options: [Disabled] [Enabled] [Auto]

OS/2 Onboard Memory > 64M [Disabled]

When using OS/2 operating systems with installed DRAM of greater than
64MB, you need to set this option to [Enabled]. Otherwise, leave to the default
setting [Disabled]. Configuration options: [Disabled] [Enabled]

64

Chapter 4: BIOS Setup

4.4.1 Chip Configuration

(Scroll down to view all items on the menu.)

SDRAM Configuration [By SPD]

This parameter allows you to set the optimal timings for items 2–5, depending
on the memory modules that you are using. The default setting is [By SPD],
which configures items 2–5 by reading the contents in the SPD (Serial
Presence Detect) device. The EEPROM on the memory module stores critical
information about the module, such as memory type, size, speed, voltage
interface, and module banks. Configuration options: [User Defined] [By SPD]

NOTE! The following 5 SDRAM parameters appear only when you set

the SDRAM Configuration to [User Defined].

SDRAM CAS Latency [2.5T(DDR)/3T(SDR]

This item controls the latency between the SDRAM read command and the
time the data actually becomes available.

SDRAM RAS to CAS Delay [3T]

This item controls the latency between the SDRAM active command and the
read/write command.

SDRAM RAS Precharge Time [3T]

This item controls the idle clocks after issuing a precharge command to the
SDRAM.

ASUS A7V333 motherboard user guide

65

SDRAM Active to Precharge Delay [6T]

This item controls the number os SDRAM clocks used for SDRAM
parameters.

SDRAM 1T Command Control [Disabled]

This item controls the pulse signal for DDR commands. The [Disabled]
default is equivalent to 2T and enabled, to 1T. Configuration options:
[Disabled] [Enabled] [Auto]

SDRAM Bank Interleave [Auto]

Configuration options: [None] [2 banks] [4 banks] [Auto]

Graphics Aperture Size [64MB]

This feature allows you to select the size of mapped memory for AGP
graphic data. Configuration options: [4MB] [8MB] [16MB] [32MB] [64MB]
[128MB] [256MB]

AGP Capability [4X Mode]

This motherboard supports the AGP 4X interface that transfers video data
at 1066MB/s. AGP 4X is backward-compatible, so you may keep the
default [4X Mode] even if you are using an AGP 1X video card. When set
to [1X Mode], the AGP interface only provides a peak data throughput of
266MB/s even if you are using an AGP 4x card.
Configuration options: [1X Mode] [4X Mode]

AGP Drive Strength [Auto]

Configuration options: [Auto] [Manual]

AGP Drive N Control [E]

Useful test parameters. Configuration options: [Auto] [Manual]

AGP Drive P Control [F]

Useful test parameters. Configuration options: [Auto] [Manual]

Video Memory Cache Mode [UC]

USWC (uncacheable, speculative write combining) is a new cache technology
for the video memory of the processor. It can greatly improve the display
speed by caching the display data. You must set this to UC (uncacheable) if
your display card does not support this feature, otherwise the system may
not boot. Configuration options: [UC] [USWC]

Memory Hole At 15M-16M [Disabled]

This field allows you to reserve an address space for ISA expansion cards.
Setting the address space to a particular setting makes that memory space
unavailable to other system components. Expansion cards can only access
memory up to 16MB. Configuration options: [Disabled] [Enabled]

PCI 2.1 Latency Compliant [Disabled]

Select enable for undetected PCI cards or for nonPCI 2.2 compliancy.
Configuration options: [Enabled] [Disabled]

66

Chapter 4: BIOS Setup

Onboard PCI IDE Controller [Both]

This field allows you to enable either the primary IDE channel or secondary
IDE channel, or both. You can also set both channels to [Disabled].
Configuration options: [Both] [Primary] [Secondary] [Disabled]

S2K Bus Driving Strength [Auto]

This item controls the host bus between the AMD K7 processor and the
north bridge. Configuration options: [Auto] [Manual]

S2K Strobe P Control [2]
S2K Strobe N Control [3]

Useful test parameters. Configuration options: [0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A,
B, C, D, E, F ]

DQS Driving Strength [Auto]

The DQS items are DRAM data strobes. The setting of “driving strengths”
determines the strength of electrical current to the DRAM. They are useful
test parameters. Configuration options: [Auto] [Manual]

DQS P Contol [2]
DQS N Contol [E]

Useful test parameters. Configuration options: [0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A,
B, C, D, E, F ]

DQS output delay contol [Auto]

Useful test parameters. Configuration options: [Auto] [Manual]

DQS output delay 4MSB [E]
DQS output delay 4LSB [2]

Useful test parameters. Configuration options: [0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A,
B, C, D, E, F ]

DQS input delay contol [Auto]

Useful test parameters. Configuration options: [Auto] [Manual]

DQS input delay 4MSB [E]
DQS input delay 4LSB [2]

Useful test parameters. Configuration options: [0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A,
B, C, D, E, F ]

DRAM Burst Length [4]

This item controls the pulse signal for DDR commands. The [Disabled]
default is equivalent to 2T and enabled, to 1T. Configuration options:
[Disabled] [Enabled] [Auto]

ASUS A7V333 motherboard user guide

67

4.4.2 I/O Device Configuration

Onboard FDC Swap A & B [No Swap]

This field reverses the hardware drive letter assignments of floppy disk drivers.
Configuration options: [No Swap] [Swap AB]

Floppy Disk Access Control [R/W]

This field sets the capacity of the floppy disk drivers to read and/or write.
Configuration options: [R/W] [Read only]

Onboard Serial Port 1 [3F8H/IRQ4]
Onboard Serial Port 2 [2F8H/IRQ3]

These fields set the addresses for the onboard serial connectors. Serial Port
1 and Serial Port 2 must have different addresses. Configuration options:
[3F8H/IRQ4] [2F8H/IRQ3] [3E8H/IRQ4] [2E8H/IRQ10] [Disabled]

UART2 Function Selection [COM2]

This field selects the device on which to assign UART2. (Only the COM2 or
the infrared, or the Smart Card Reader may be supported at any given time.
Configuration options: [COM2] [Standard Infrared] [Smart Card Reader]

Onboard Parallel Port [378H/IRQ7]

This field sets the address of the onboard parallel port connector. If you
disable this field, the Parallel Port Mode and ECP DMA Select configurations
are not available. Configuration options: [Disabled] [378H/IRQ7] [278H/IRQ5]

68

Chapter 4: BIOS Setup

Parallel Port Mode [ECP+EPP]

This field sets the operation mode of the parallel port. [Normal] allows normal­speed operation but in one direction only; [EPP] allows bidirectional parallel
port operation; [ECP] allows the parallel port to operate in bidirectional DMA
mode; [ECP+EPP] allows normal speed operation in a two-way mode.
Configuration options: [Normal] [EPP] [ECP] [ECP+EPP]

ECP DMA Select [3]

This field configures the parallel port DMA channel for the selected ECP
mode. This selection is available only if you select [ECP] or [ECP+EPP] in
Parallel Port Mode above. Configuration options: [1] [3]

Onboard Card Reader Type [Disabled]

This field enables or disables two different types of external memory media
devices: memory stick and secure digital. Configuration options: [Memory
Stick] [Secure Digital] [Disabled].

Speech POST Reporter [Enabled]

This field enables or disables the ASUS POST Reporter™feature. More
information is available in section 3.2, V ocal POST Messages. Configuration
options: [Enabled] [Disabled].

ASUS A7V333 motherboard user guide

69

4.4.3 PCI Configuration

Slot 1/5, 2, 3, 4 IRQ [Auto]

These fields automatically assign the IRQ for each PCI slot. The default
setting for each field is [Auto], which utilizes auto-routing to determine IRQ
assignments. Configuration options: [Auto] [NA] [3] [4] [5] [7] [9] [10] [1 1] [12]
[14] [15]

PCI/VGA Palette Snoop [Disabled]

Some non-standard VGA cards, like graphics accelerators or MPEG video
cards, may not show colors properly. Setting this field to [Enabled] corrects
this problem. If you are using standard VGA cards, leave this field to the
default setting [Disabled]. Configuration options: [Disabled] [Enabled]

PCI Latency Timer [32]

Leave this field to the default setting [32] for best performance and stability.

USB Function [Enabled]

Set this field to [Enabled] if you want to use Universal Serial Bus (USB)
devices. Configuration options: [Disabled] [Enabled]

Primary VGA BIOS [PCI VGA Card]

This field allows you to select the primary graphics card. Configuration
options: [PCI VGA Card] [AGP VGA Card]

70

Chapter 4: BIOS Setup

4.4.3.1 Onboard PCI Devices Control

Onboard PCI Audio [Enabled]

[Auto] allows the BIOS to detect whether you are using any audio device. If
an audio device is detected, the onboard audio controller is enabled; if no
audio device is detected, the controller is disabled. If there are conflicts with
the onboard modem/audio controller, set the appropriate field to [Disabled].
Configuration options: [Disabled] [Enabled]

ASUS A7V333 motherboard user guide

71

4.4.3.2 PCI IRQ Resource Exclusion

IRQ XX Used By ISA [No/ICU]

These fields indicate whether or not the displayed IRQ for each field is
being used by a legacy (non-PnP) ISA card. The setting [No/ICU] for an
IRQ field indicates that you are using the ISA Configuration Utility (ICU),
and that this particular IRQ is NOT required by a legacy ISA card. Set the
IRQ field to [Yes] if you install a legacy ISA card that requires a unique IRQ
and you are NOT using ICU Also, it is required to reserve the IRQ, ie.: set
to [Yes] if using a Non-Maskable-Interrupt (NMI); the NMI setting is
effective only for Win9X but not for Win2K or XP operating systems.
Configuration options: [No/ICU] [Yes]

Onboard ATA Device First [No]

This setting controls the priority of the detect sequence of the onboard RAID
and the PCI slot option. Select [Yes] to command the onboard RAID
controller ROM to initiate first. The default is [No]. Configuration options:
[Yes] [No]

72

Chapter 4: BIOS Setup

4.5 Power Menu

The Power menu allows you to reduce power consumption. This feature
turns off the video display and shuts down the hard disk after a period of
inactivity.

Power Management [User Defined]

This field allows you to activate or deactivate the automatic power saving
features. When set to [Disabled], the power management features do not
function regardless of the other settings on this menu. The [User Defined]
option allows you to set the period of inactivity before the system enters
suspend mode. Refer to “Suspend Mode” later in this section.

When set to [Max Saving], system power is conserved to its greatest amount.
This setting automatically puts the system into suspend mode after a brief
period of system inactivity . [Min Saving] allows the least power saving as the
system enters suspend mode only after a long period of inactivity.
Configuration options: [User Defined] [Disabled] [Min Saving] [Max Saving]

IMPORTANT! You should install the Advanced Power Management

(APM) utility to keep the system time updated even when the computer
enters suspend mode. In Windows 3.x and Windows 95, you need to
install Windows with the APM feature. In Windows 98 or later, APM is
automatically installed as indicated by a battery and power cord icon
labeled “Power Management” in the Control Panel. Select the item
“Advanced” in the Power Management Properties dialog box.

ASUS A7V333 motherboard user guide

73

Video Off Option [Suspend -> Off ]

This field determines when to activate the video off feature for monitor power
management. Configuration options: [Always On] [Suspend -> Off]

Video Off Method [DPMS OFF]

This field defines the video off features. The Display Power Management
System (DPMS) feature allows the BIOS to control the video display card if it
supports the DPMS feature. [Blank Screen] only blanks the screen. Use this
for monitors without power management or “green” features.

NOTE! Even if installed, your screen saver does not display when you

select [Blank Screen] for the above field.

[V/H SYNC+Blank] blanks the screen and turns off vertical and horizontal
scanning. Configuration options: [Blank Screen] [V/H SYNC+Blank] [DPMS
Standby] [DPMS Suspend] [DPMS OFF] [DPMS Reduce ON]

HDD Power Down [Disabled]

Shuts down any IDE hard disk drives in the system after a period of inactivity
as set in this user-configurable field. This feature does not affect SCSI hard
drives. Configuration options: [Disabled] [1 Min] [2 Min] [3 Min]...[15 Min]

ACPI Suspend-to-RAM [Disabled]

This field allows you to enable or disable the ACPI Suspend-to-RAM feature.
To support this feature, the +5VSB of the power supply should have the
capacity to provide more than 720mA current. Configuration options:
[Disabled] [Enabled]

Suspend Mode [Disabled]

Sets the time period before the system goes into suspend mode. Configuration
options: [Disabled] [1~2 Min] [2~3 Min] [4~5 min] [8~9 Min] [20 Min] [30 Min]

PWR Button < 4 Secs [Soft Off]

When set to [Soft off], the A TX switch can be used as a normal system power­off button when pressed for less than 4 seconds. [Suspend] allows the button
to have a dual function where pressing less than 4 seconds puts the system
in sleep mode. Regardless of the setting, holding the ATX switch for more
than 4 seconds powers off the system. Configuration options: [Soft off]
[Suspend]

74

Chapter 4: BIOS Setup

4.5.1 Power Up Control

AC PWR Loss Restart [Disabled]

This allows you to set whether or not to reboot the system after power
interruptions. [Disabled] leaves your system off while [Enabled] reboots the
system. [Previous State] sets the system back to the state it was before the
power interruption. Configuration options: [Disabled] [Enabled] [Previous
State]

Wake/Power Up On Ext. Modem [Disabled]

The computer may be powered up the computer if the external modem
receives a call while the system is in Soft-off mode. Configuration options:
[Disabled] [Enabled]

NOTE! The computer cannot receive or transmit data until the computer

and applications are fully running. Thus, connection cannot be made on
the first try. Turning an external modem off and then back on while the
computer is off sends an initialization string that turns system power on.

Power Up On PCI Card [Disabled]

When set to [Enabled], the system through a network or a PCI modem. This
feature requires an A TX power supply that provides at least 1A on the +5VSB
lead. Configuration options: [Disabled] [Enabled]

Power On By PS/2 Keyboard [Disabled]

This parameter allows you to use specific keys on the keyboard to turn on
the system. This feature requires an A TX power supply that provides at least
1A on the +5VSB lead. Configuration options: [Disabled] [Space Bar] [Ctrl­Esc] [Power Key]

ASUS A7V333 motherboard user guide

75

Power On By PS/2 Mouse [Disabled]

When set to [Enabled], this parameter allows you to use the PS/2 mouse to
turn on the system. This feature requires an ATX power supply that provides
at least 1A on the +5VSB lead. Configuration options: [Disabled] [Enabled]

Automatic Power Up [Disabled]

This allows an unattended or automatic system power up. Y ou may configure
your system to power up at a certain time of the day by selecting [Everyday]
or at a certain time and day by selecting [By Date]. Configuration options:
[Disabled] [Everyday] [By Date]

76

Chapter 4: BIOS Setup

4.5.2 Hardware Monitor

MB Temperature [xxxC/xxxF]
CPU Temperature [xxxC/xxxF]

POWER Temperature [N/A]

The onboard hardware monitor automatically detects the MB (motherboard)
and CPU temperatures.

CPU Fan Speed [xxxxRPM]
POWER Fan Speed [N/A]
CHASSIS Fan Speed [N/A]

The onboard hardware monitor automatically detects the CPU and chassis
fan speeds in rotations per minute (RPM).

VCORE Voltage, +3.3V Voltage, +5V Voltage, +12V Voltage

The onboard hardware monitor automatically detects the voltage output
through the onboard voltage regulators.

NOTE! If any of the monitored items is out of range, the following error

message appears: “Hardware Monitor found an error. Enter Power setup
menu for details”. You will then be prompted to “Press F1 to continue or
DEL to enter SETUP”.

ASUS A7V333 motherboard user guide

77

4.6 Boot Menu

Boot Sequence

The Boot menu allows you to select among the four possible types of boot
devices listed using the up and down arrow keys. By using the <+> or <Space>
key, you can promote devices and by using the <-> key, you can demote
devices. Promotion or demotion of devices alters the priority which the system
uses to search for a boot device on system power up. Configuration fields
include Removable Devices, IDE Hard Drive, ATAPI CD-ROM, and Other
Boot Device.

Removable Device [Legacy Floppy]

Configuration options: [Disabled] [Legacy Floppy] [LS-120] [ZIP] [A T APIMO]

IDE Hard Drive

This field allows you to select which IDE hard disk drive to use in the boot
sequence. Pressing [Enter] will show the product IDs of all connected IDE
hard disk drives.

ATAPI CD-ROM

This field allows you to select which AT API CD-ROM drive to use in the boot
sequence. Pressing [Enter] will show the product IDs of all your connected
ATAPI CD-ROM drives.

Other Boot Device Select [INT18 Device (Network)]

Configuration options: [Disabled] [SCSI Boot Device] [INT18 Device
(Network)]

78

Chapter 4: BIOS Setup

Plug & Play O/S [No]

This field allows you to use a Plug-and-Play (PnP) operating system to
configure the PCI bus slots instead of using the BIOS. When [Y es] is selected,
interrupts may be reassigned by the OS. If you installed a non-PnP OS or if
you want to prevent reassigning of interrupt settings, keep the default setting
[No]. Configuration options: [No] [Yes]

Reset Configuration Data [No]

The Extended System Configuration Data (ESCD) contains information about
non-PnP devices. It also holds the complete record of how the system was
configured the last time is was booted. Select [Y es] if you want to clear these
data during the Power-On-Self-Test (POST). Configuration options: [Yes]
[No]

Quick Power On Self Test [Enabled]

This field speeds up the Power-On-Self Test (POST) routine by skipping
retesting a second, third, and fourth time. Configuration options: [Disabled]
[Enabled]

Boot Up Floppy Seek [Enabled]

If enabled, this field speeds up the Power On Self Test (POST) routine by
skipping and retesting a second, third and fourth time. Configuration options:
[Disabled] [Enabled]

Full Screen Logo [Enabled]

When enabled, the BIOS displays the characteristic A7V333 Bios screen.
Configuration options: [Disabled] [Enabled]

Interrupt Mode [APIC]

This item controls the IRQ structure. The new APIC creates a range of IRQs
larger than the standard 16 IRQ channels. The standard setting of PIC limits
the number of IRQs to the standard IRQ0 to IRQ15. Windows 2000 and XP
support APIC settings. Select between new APIC or PIC. Configuration
options: [APIC] [PIC]

ASUS A7V333 motherboard user guide

79

4.7 Exit Menu

When you have made all of your selections from the various menus in the
Setup program, save your changes and exit Setup. Select Exit from the
menu bar to display the following menu.

NOTE! Pressing <Esc> does not immediately exit this menu. Select

one of the options from this menu or <F10> from the legend bar to exit.

Exit Saving Changes

Once you are finished making your selections, choose this option from the
Exit menu to ensure the values you selected are saved to the CMOS RAM.
The CMOS RAM is sustained by an onboard backup battery and stays on
even when the PC is turned off. When you select this option, a confirmation
window appears. Select [Yes] to save changes and exit.

NOTE! If you attempt to exit the Setup program without saving your

changes, the program prompts you with a message asking if you want to
save your changes before exiting. Pressing <Enter> saves the changes
while exiting.

Exit Discarding Changes

Select this option only if you do not want to save the changes that you made
to the Setup program. If you made changes to fields other than system date,
system time, and password, the BIOS asks for a confirmation before exiting.

80

Chapter 4: BIOS Setup

Load Setup Defaults

This option allows you to load the default values for each of the parameters
on the Setup menus. When you select this option or if you press <F5>, a
confirmation window appears. Select [Y es] to load default values. Select Exit
Saving Changes or make other changes before saving the values to the
non-volatile RAM.

Discard Changes

This option allows you to discard the selections you made and restore the
previously saved values. After selecting this option, a confirmation appears.
Select [Yes] to discard any changes and load the previously saved values.

Save Changes

This option saves your selections without exiting the Setup program. You
can then return to other menus and make further changes. After you select
this option, a confirmation window appears. Select [Y es] to save any changes
to the non-volatile RAM.

ASUS A7V333 motherboard user guide

81

82

Chapter 4: BIOS Setup

Chapter 5

Software support

ASUS A7V333 motherboard
