ASRock p4fsb1333-650 User Manual

P4FSB1333-650

User Manual

Version 1.0

Published July 2007

No part of this manual may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRock Inc. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe.

Disclaimer:Disclaimer:

Disclaimer:

Disclaimer:Disclaimer:

Specifications and information contained in this manual are furnished for informational use only and subject to change without notice, and should not be constructed as a commitment by ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this manual. With respect to the contents of this manual, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no event shall ASRock, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from a n y defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance controlled in Perchlorate Best Management Practices (BMP) regulations passed by the California Legislature. When you discard the Lithium battery in California, USA, please follow the related regulations in advance. “Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

ContentsContents

Contents

ContentsContents

1 Introduction1 Introduction

1 Introduction

1 Introduction1 Introduction

1.1 Package Contents.......................................................... 5

1.2 Spec if ic at io ns ................................................................ 6

1.3 Minimum Hardware Requirement Table for Windows

VistaTM Premium 2007 and Basic Logo.......................... 9

1.4 Motherboard Layout ...................................................... 10

1.5 HD 8CH I/O ..................................................................... 11

2 Installation2 Installation

2 Installation

2 Installation2 Installation

2.1 Screw Holes ................................................................. 12

2.2 Pre-installation Precautions........................................... 1 2

2.3 CPU Installation .............................................................. 13

2.4 Installation of Heatsink and CPU fan ............................. 15

2.5 Installation of Memory Modules (DIMM)......................... 16

2.6 Expansion Slots (PCI, HDMR, and PCI Express Slots) ....... 17

2.7 Jumpers Setup .............................................................. 18

2.8 Onboard Headers and Connectors .............................. 19

2.9 SATAII Hard Disk Setup Guide ....................................... 23

2.10 Serial ATA (SATA) / Serial ATAII (SATAII) Hard Disks

Installation ...................................................................... 24

2.11 Driver Installation Guide .............................................. 24

2.12 HDMR Card and Driver Installation .............................. 24

2.13 Untied Overclocking Technology................................... 2 4

3 BIOS S3 BIOS S

3 BIOS S

3 BIOS S3 BIOS S

ETUP UTILITYETUP UTILITY

ETUP UTILITY

ETUP UTILITYETUP UTILITY

3.1 Introduction .................................................................... 2 5

3.1.1 BIOS Menu Bar .................................................... 25

3.1.2 Navigation Keys................................................... 26

3.2 Main Screen................................................................... 26

3.3 Advanced Screen ......................................................... 26

3.3.1 CPU Configuration................................................ 27

3.3.2 Chipset Configuration .......................................... 29

3.3.3 ACPI Configuration............................................... 32

3.3.4 IDE Configuration ................................................. 3 3

3.3.5 PCIPnP Configuration ........................................... 35

3.3.6 Floppy Configuration ........................................... 36

3.3.7 Super IO Configuration ........................................ 36

3.3.8 USB Configuration ............................................... 37

3.4 Hardware Health Event Monitoring Screen .................. 39

......................................................................................................

...................................................

......................................................................................................

............................................................................................................

......................................................

............................................................................................................

......................................................................................

...........................................

......................................................................................

5 5

12 12

25 25

3.5 Boot Screen................................................................... 39

3.5.1 Boot Settings Configuration.................................. 39

3.6 Security Screen ............................................................ 40

3.7 Exit Screen .................................................................... 41

4 Software Support4 Software Support

4 Software Support

4 Software Support4 Software Support

4.1 Install Operating System ............................................... 42

4.2 Support CD Information ................................................. 42

4.2.1 Running Support CD ............................................ 42

4.2.2 Drivers Menu........................................................ 42

4.2.3 Utilities Menu ........................................................ 42

4.2.4 Contact Information.............................................. 42

......................................................................................

...........................................

......................................................................................

42 42

Chapter 1 IntroductionChapter 1 Introduction

Chapter 1 Introduction

Chapter 1 IntroductionChapter 1 Introduction

Thank you for purchasing ASRock P4FSB1333-650 motherboard, a reliable motherboard produced under ASRock’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock’s commitment to quality and endurance. In this manual, chapter 1 and 2 contain introduction of the motherboard and step-bystep guide to the hardware installation. Chapter 3 and 4 contain the configuration guide to BIOS setup and information of the Support CD.

Because the motherboard specifications and the BIOS software might be updated, the content of this manual will be subject to change without notice. In case any modifications of this manual occur, the updated version will be available on ASRock website without further notice. You may find the latest VGA cards and CPU support lists on ASRock website as well. ASRock website

1.1 Package Contents1.1 Package Contents

1.1 Package Contents

1.1 Package Contents1.1 Package Contents

ASRock P4FSB1333-650 Motherboard Bundled With Selected CPU Operating at FSB1333 / 2.66GHz

(Micro ATX Form Factor: 9.6-in x 9.0-in, 24.4 cm x 22.9 cm) ASRock P4FSB1333-650 Quick Installation Guide ASRock P4FSB1333-650 Support CD One 80-conductor Ultra ATA 66/100 IDE Ribbon Cable One Ribbon Cable for a 3.5-in Floppy Drive One Serial ATA (SATA) Data Cable (Optional) One Serial ATA (SATA) HDD Power Cable (Optional) One HD 8CH I/O Shield One COM Port Bracket

http://www.asrock.com

1.21.2

SpecificationsSpecifications

1.2

Specifications

1.21.2

SpecificationsSpecifications

Platform - Micro ATX Form Factor: 9.6-in x 9.0-in, 24.4 cm x 22.9 cm

CPU - Bundle with selected CPU operating at

FSB1333 / 2.66GHz

* This motherboard also supports below CPU specifications:

- LGA 775 for Intel / Pentium Celeron

- Compatible with all FSB1333/1066/800/533MHz CPUs except Quad Core (see CAUTION 1)

- Supports Hyper-Threading Technology

- Supports Untied Overclocking Technology (see CAUTION 2)

- Supports EM64T CPU

Dual Core CoreTM 2 Extreme / CoreTM 2 Duo

D / Pentium® Dual Core / Pentium® 4 / Celeron® /

Chipset - Northbridge: Intel® 945GC A2

- Southbridge: Intel® ICH7

Memory - Dual Channel DDRII Memory Technology (see CAUTION 3)

- 2 x DDRII DIMM slots

- Support DDRII667/533 (see CAUTION 4). This motherboard will automatically optimize the condition of CPU and memory frequency according to the bundled CPU a nd memory module.

- Max. capacity: 4GB (see CAUTION 5)

Hybrid Booster - CPU Frequency Stepless Control (see CAUTION 6)

- ASRock U-COP (see CAUTION 7)

- Boot Failure Guard (B.F.G.)

Expansion Slot - 1 x PCI Express x16 slot

- 1 x PCI Express x1 slot

- 2 x PCI slots

- 1 x HDMR slot

Graphics - Intel® Graphics Media Accelerator 950

- Pixel Shader 2.0, DirectX 9.0

- Max. shared memory 224MB (see CAUTION 8)

Audio - 7.1 CH Windows® VistaTM Premium Level HD Audio

(ALC888 Audio Codec)

LAN - Realtek PCIE x1 LAN 8101E

- Speed: 10/100 Ethernet

- Supports Wake-On-LAN

Rear Panel I/O HD 8CH I/O

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x VGA Port

- 1 x Parallel Port (ECP/EPP Support)

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port

- HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/ Line in/Front Speaker/Microphone (see CAUTION 9)

Connector - 4 x SATAII 3.0 Gb/s connectors (No Support for RAID and

“Hot Plug” functions) (see CAUTION 10)

- 1 x ATA100 IDE connector (supports 2 x IDE devices)

- 1 x Floppy connector

- 1 x IR header

- 1 x COM port header

- CPU/Chassis FAN connector

- 20 pin ATX power connector

- 4 pin 12V power connector

- CD in header

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports) (see CAUTION 11)

BIOS Feature - 4Mb AMI BIOS

- AMI Legal BIOS

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wa ke Up Events

- Supports jumperfree

- AMBIOS 2.3.1 Support Support CD - Drivers, Utilities, AntiVirus Software (Trial Version) Hardware - CPU Temperature Sensing Monitor - Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU Quiet Fan

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore OS - Microsoft® Windows® 2000/XP/XP 64-bit/VistaTM/

VistaTM 64-bit compliant (see CAUTION 12)

Certifications - FCC, CE, WHQL

WARNING

Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using the thirdparty overclocking tools. Overclocking may affect your system stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.

CAUTION!

1. FSB1333-CPU will operate in overclocking mode. Under this situation, PCIE frequency will also be overclocked to 115MHz.

2. This motherboard supports Untied Overclocking Technology. Please read “Untied Overclocking Technology” on page 24 for details.

3. This motherboard supports Dual Channel Memory Technology. Before you implement Dual Channel Memory Technology, make sure to read the installation guide of memory modules on page 16 for proper installation.

4. Please check the table below for the CPU FSB frequency and its corresponding memory support frequency.

CPU FSB Frequency Memory Support Frequency

1333 DDRII533*, DDRII667 1066 DDRII533, DDRII667

800 DDRII400, DDRII533, DDRII667 533 DDRII400, DDRII533

* When you use a FSB1333-CPU on this motherboard, it will run at

DDRII500 if you adopt a DDRII533 memory module.

5. Due to the chipset limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows XP 64-bit, Windows® VistaTM and Windows® VistaTM 64-bit.

6. Although this motherboard offers stepless control, it is not recommended to perform over-clocking. Frequencies other than the recommended CPU bus frequencies may cause the instability of the system or damage the CPU.

7. While CPU overheat is detected, the system will automatically shutdown. Before you resume the system, please check if the CPU fan on the motherboard functions properly and unplug the power cord, then plug it back again. To improve heat dissipation, remember to spray thermal grease between the CPU a nd the heatsink when you in stall the PC system.

8. The maximum shared memory size is defined by the chipset vendor and is subject to change. Please check Intel

website for the latest information.

9. For microphone input, this motherboard supports both stereo and mono modes. For audio output, this motherboard supports 2-channel, 4-channel, 6-channel, and 8-channel modes. Please check the table on page 11 for proper connection.

10. Before installing SATAII hard disk to SAT AII conne ctor, please read the “SATAII Hard Disk Setup Guide” on page 23 to adjust your SATAII hard disk drive to SATAII mode. You can also connect SATA hard disk to SATAII connector directly.

11. Power Management for USB 2.0 works fine under Microsoft VistaTM 64-bit / VistaTM / XP 64-bit / XP SP1 or SP2 / 2000 SP4.

12. Microsoft

Windows® VistaTM / VistaTM 64-bit driver keeps on updating now. As long as we have the latest driver, we will update it to our website in the future. Please visit our website for Microsoft® Windows® VistaTM / VistaTM 64-bit driver and related information. ASRock website http://www.asrock.com

XP, Windows

Windows

1.31.3

Minimum Hardware RMinimum Hardware R

1.3

Minimum Hardware R

1.31.3

Minimum Hardware RMinimum Hardware R

TMTM

VistaVista

Vista

VistaVista

For system integrators and users who purchase this motherboard and plan to submit Windows® VistaTM Premium 2007 and Basic logo, please follow below table for minimum hardware requirements.

Memory 512MB x 2 Dual Channel (Premium)

VGA DX9.0 with WDDM Driver

Premium 2007 and Basic Logo Premium 2007 and Basic Logo

Premium 2007 and Basic Logo

Premium 2007 and Basic Logo Premium 2007 and Basic Logo

512MB Single Channel (Ba sic) 256MB x 2 Dual Channel (Basic)

equirement Tequirement T

equirement T

equirement Tequirement T

able for Wable for W

able for W

able for Wable for W

indowsindows

indows

indowsindows

®®

* If you plan to use onboard VGA to submit Windows default setting of “DVMT Mode Select” option under BIOS. * If you plan to use external graphics card on this motherboard, please refer to Premium Discrete requirement at * After June 1, 2007, all Windows minimum hardware requirements in order to qualify for Windows 2007 logo.

http://www.asrock.com

VistaTM systems are required to meet above

VistaTM logo, please keep the

VistaTM Premium

1.4 Motherboard Layout1.4 Motherboard Layout

1.4 Motherboard Layout

1.4 Motherboard Layout1.4 Motherboard Layout

22.9cm (9.0 in)

PS2_USB_PWR1

PS2

Mouse

Keyboard

PARALLEL PORT

CPU_FAN1

PS2

ATX12V1

VGA1

IR1

USB 2.0 T: U SB 2 B: USB3

USB2.0 T:USB0 B:USB1

Bottom:

CTR BASS

Bottom:

MIC IN

REAR SPK

FRONT

Center:

LAN PHY

AUDIO CODEC

Top: RJ-45

Top:

SIDE SPK

Top:

LINE IN

CD1

HD_AUDIO1

COM1

Super

4Mb

PCIE2

7.1CH HD

HDMR1

ATXPWR1

BIOS

PCI

EXPRESS

PCIE1

PCI1

PCI2

FLOPPY1

SATAII

945GC A2

Chipset

RoHS

Intel

Intel ICH7

USB4_5

USB2.0

23 22

DDRII667

FSB1333

Presler

FSB800

Dual CoreCPU

Conroe

DDRII_1 (64/72bit, 240-pin module)

P4FSB1333-650

Dual Channel

CMOS Battery

SATAII_3

SATAII_1

USB6_7

SPEAKER1

HDLED RESET

CHA_FAN1

1516

FSB800

DDRII_2 (64/72bit, 240-pin module)

IDE1

CLRCMOS1

SATAII_4

SATAII_2

PANEL1

PLEDPWRBTN

1314

24.4cm (9.6 in)

8 9

11 12

1 PS2_USB_PWR1 Jumper 15 Chassis Speaker Header (SPEAKER 1) 2 A TX 12V Connector (A TX12V1) 16 Chassis Fan Connector (CHA_FAN1) 3 CPU Fan Connector (CPU_FAN1) 17 USB 2.0 Header (USB6_7, Blue) 4 775-Pin CPU Socket 18 USB 2.0 Header (USB4_5, Blue) 5 North Bridge Controller 19 Floppy Connector (FLOPPY1) 6 2 x 240-pin DDRII DIMM Slots 20 HDMR Slot (HDMR1)

(Dual Channel: DDRII_1, DDRII_2; Yellow) 21 Front Panel Audio Header (HD_AUDIO1) 7 IDE1 Connector (IDE1, Blue) 22 PCI Slots (PCI1- 2) 8 Clear CMOS Jumper (CLRCMOS1) 23 Internal Audio Connector: CD1 (Black) 9 South Bridge Controller 24 PCI Express x1 Slot (PCIE2) 10 Third SAT AII Connector (SA T AII_3; Ora nge) 25 PCI Express x16 Slot (PCIE1) 11 Fourth SAT AII Connector (SATAII_4; Orange) 26 ATX Power Connector (ATXPWR1) 12 Secondary SAT AII Connector (SA T AII_2; Red) 27 BIOS FWH Chip 13 System Panel Hea der (PANEL1) 28 Serial Port Connector (COM1) 14 Primary SAT AII Connector (SAT AII_1; Red) 29 Infrared Module Header (IR1)

1010

1.51.5

1.5

1.51.5

HD 8CH I/OHD 8CH I/O

HD 8CH I/O

HD 8CH I/OHD 8CH I/O

1213

1 Parallel Port 8 Microphone (Pink) 2 RJ-45 Port 9 USB 2.0 Ports (USB01) 3 Side Speaker (Gray) 10 USB 2.0 Ports (USB23) 4 Rear Speaker (Black) 11 V GA Port 5 Central / Bass (Orange) 12 PS/2 Keyboard Port (Purple) 6 Line In (Light Blue) 13 PS/2 Mouse Port (Green)

*7 Front Speaker (Lime)

* If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See

the table below for connection details in accordance with the type of speaker you use.

Audio Output Channels Front Speaker Rear Speaker Central / Bass Side Speaker

2 V -- -- -4VV---6VVV-8VVVV

TABLE for Audio Output Connection

(No. 7) (No. 4) (No. 5) (No. 3)

* To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

panel audio header. After restarting your computer, you will find “Mixer” tool on your system. Please select “Mixer ToolBox” , click “Enable playback multi-streaming”, and click

“ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker, Central/Bass, and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio.

1111

Chapter 2 InstallationChapter 2 Installation

Chapter 2 Installation

Chapter 2 InstallationChapter 2 Installation

P4FSB1333-650 is a Micro ATX form factor (9.6" x 9.0", 24.4 x 22.9 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.

Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components.

2.1 Screw Holes2.1 Screw Holes

2.1 Screw Holes

2.1 Screw Holes2.1 Screw Holes

Place screws into the holes indicated by circles to secure the motherboard to the chassis.

Do not over-tighten the screws! Doing so may damage the motherboard.

2.2 Pre-installation Precautions2.2 Pre-installation Precautions

2.2 Pre-installation Precautions

2.2 Pre-installation Precautions2.2 Pre-installation Precautions

Take note of the following precautions before you install motherboard components or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any component.

2. To avoid damaging the motherboard components due to static electricity, NEVER place your motherboard directly on the carpet or the like. Also remember to use a grounded wrist strap or touch a safety grounded object before you handle components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that comes with the component.

1212

Before you install or remove any component, ensure that the power is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, and/or components.

2.3 CPU Installation2.3 CPU Installation

2.3 CPU Installation

2.3 CPU Installation2.3 CPU Installation

This motherboard is bundled with one selected CPU operating at FSB1333 /

2.66GHz. Please do not re move ASRock CPU stickers on both sides of CPU socket on this motherboard. If the stickers are

damaged, removed or bear the word “VOID”, ASRock is not responsible for the after service of this CPU.

In the future, you may adopt other compatible Intel 775-LAND CPU on this motherboard for upgrade purpose. For the installation of Intel 775-LAND CPU, please follow the steps below. ASRock reminds you that as long as you adopt other CPU on this motherboard, we will not be responsible for the after service of the bundled CPU.

Before you insert the 775-LAND CPU into the socket, please check if the CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found. Otherwise, the CPU will be seriously damaged.

Step 1. Open the socket:

Step 1-1. Disengaging the lever by depressing

down and out on the hook to clear retention tab.

ASRock CPU Sticker

775-Pin Socket Overview

Step 1-2. Rotate the load lever to fully open po-

sition at approximately 135 degrees.

Step 1-3. Rotate the load plate to fully open po-

sition at approximately 100 degrees.

Step 2. Insert the 775-LAND CPU:

Step 2-1. Hold the CPU by the edges where are

marked with black lines.

black line

1313

+ 29 hidden pages
