User Guide
Manuel de l’utilisateur
Manual del usuario
Congratulations on your new iPhone Bluetooth®
Headset. Follow the instructions to get started.
Pair the Headset with iPhone
1 Connect the included iPhone Bluetooth Travel Cable to a
USB 2.0 port on your computer (not on the keyboard).
2 Connect iPhone and the headset to the cable. The
headset pairs with iPhone automatically.
Cable
The fi rst time you connect the headset, let it charge for
about an hour until the status light on the headset turns
from amber to green.
3 Remove iPhone and the headset from the cable.
To connect the headset to iPhone, press the button on
top of the headset. This allows calls to be routed through
the headset.
In some cases, you may need to reconnect the headset to
iPhone. See page 6.
English 3
Make or Answer a Call
1 Place the headset in either ear with the microphone
pointed towards your mouth.
Microphone
Placing the included foam pad over the speaker may
provide a more comfortable fi t.
2 Make a call on iPhone. Press the button on top of the
headset to answer an incoming call.
Button Status light
If you answer an incoming call by tapping the iPhone
touchscreen, audio is routed through iPhone instead.
3 When you fi nish, press the button to end the call.
4 English
Adjust the Volume
m Use the volume buttons on the side of iPhone.
WARNING: For important safety information about
avoiding hearing loss, see page 14.
What Else You Can Do
To Do this
Decline incoming call Press button for about one second, until
Switch to incoming or
on-hold call and put
current call on hold
Switch to incoming or
on-hold call and end
current call
Check whether
headset is turned on
Turn headset on Press and hold button for about three
Turn headset o∂ Press and hold button for about four
you hear a beep.
Press button.
Press button for about one second, until
you hear a beep.
Press button. If headset is on, status
light blinks green and headset beeps.
seconds, until you see the status light
blink green or hear four rising tones.
seconds, until you see the status light
blink amber or hear four falling tones.
English 5
Switch from the Headset to iPhone
To stop using the headset and hear calls through iPhone
instead, you can either:
m Turn the headset o∂ . You can turn it on again at any time
to use it with iPhone.
m During a call, tap Audio Source on iPhone and choose
iPhone or Speaker (for speakerphone).
Reconnect the Headset to iPhone
You can tell that calls will be routed through the headset
if the Bluetooth icon (◊) in the iPhone status bar is blue
or white (depending on which application you’re using).
If the headset gets disconnected from iPhone, two low
beeps sound from the headset. You can tell that the
headset is disconnected from iPhone if the Bluetooth
icon in the status bar is gray or isn’t present.
To route calls through the headset:
m Press the button to reinitiate a connection.
m If that doesn’t work, make sure the headset is turned on,
charged, and in range of iPhone (within about 30 feet).
m If that doesn’t work, on iPhone make sure Bluetooth is
turned on. From the Home screen, choose Settings >
General > Bluetooth and turn Bluetooth on.
6 English
m If that doesn’t work, pair the headset with iPhone again.
See page 3.
If the headset is paired with other Bluetooth devices,
you’ll need to reconnect it to iPhone after turning the
headset o∂ or after using it with one of the other devices.
Charge the Headset
When the headset doesn’t have much charge left, a long
beep sounds every ten seconds.
To charge the headset:
1 Connect the included iPhone Bluetooth Travel Cable to
your computer. Or connect it to the Apple USB Power
Adapter that comes with iPhone and connect the adapter
to a power outlet.
2 Connect the headset to the cable.
A fully depleted headset recharges in about an hour
and a half.
Status light amber = Charging
Status light green = Completely charged
3 Remove the headset from the cable. Press the button to
connect the headset to iPhone, so that calls are routed
through the headset.
English 7
To see how much charge is left:
m Connect the iPhone Bluetooth Travel Cable to your
computer or an Apple USB Power Adapter plugged
into a power outlet. Then connect iPhone and the
headset to the cable. The iPhone screen shows the
headset’s battery level.
The headset contains an internal, non–user-replaceable
battery. Rechargeable batteries have a limited number
of charge cycles and will eventually wear out. Battery life
and number of charge cycles vary by use and settings.
For more information, go to www.apple.com/batteries.
For more information about disposal of the headset,
see page 57.
WARNING: For important safety information about
charging the headset, see page 13.
Use the Headset with Another Phone
or Device
You can use the headset with some other Bluetooth
devices, such as another phone. And you can pair the
headset with iPhone manually, if you don’t have the
iPhone Bluetooth Travel Cable handy.
8 English
You can also pair the headset with some Bluetooth
enabled computers and talk to friends using an audioenabled instant messaging application like iChat.
To set the headset to be discoverable, so the other
device can sense it:
1 Turn the headset o∂ .
2 Press and hold the headset button for about eight
seconds, until you hear the startup tones and then fi ve
quick high beeps.
The headset remains discoverable for about fi ve minutes.
The status light blinks green for as long as the headset
is discoverable.
To pair the headset with another phone or pair it with
iPhone manually:
1 On the phone, turn Bluetooth on and set the phone to
search for other Bluetooth devices. On iPhone, you do
this by choosing Settings > General > Bluetooth and
turning Bluetooth on.
2 Set the headset to be discoverable (see above).
3 On the phone, choose iPhone Bluetooth Headset and
enter the PIN code 0000.
See the instructions that came with your phone for more
information about pairing it with Bluetooth devices.
English 9
To pair the headset with a Bluetooth enabled Mac using
Mac OS X version 10.4.9 or later:
1 Open System Preferences and click Bluetooth.
2 If this is the fi rst Bluetooth device you’ve set up, click the
Set Up New Device button. Otherwise, click the Add (+)
button below the list of your existing devices.
3 Choose Headset.
4 Set the headset to be discoverable.
5 Follow the onscreen instructions. When prompted for a
passkey, enter 0000.
To use the headset with iChat:
1 Pair the headset with your Mac.
2 In iChat, choose iChat > Preferences and click Audio/
Video.
3 Choose iPhone Bluetooth Headset from the Microphone
and Sound Output pop-up menus.
4 Start an audio or video chat.
To pair the headset with another computer (such as a
Windows PC) or Bluetooth device:
Follow the instructions that came with the computer or
device. When prompted for a passkey or PIN, enter 0000.
10 English
Tips and Troubleshooting
If the headset isn’t responding or working correctly, try
these steps in order until it starts working.
m Make sure the headset is on. Press the button. If the
status light doesn’t blink green, press and hold the
button for about three seconds, until you see the status
light blink green or hear four rising tones.
m Make sure iPhone is turned on.
m Make sure the headset and iPhone are charged.
m During a call, make sure iPhone is set to play sound
through the headset. Tap Audio Source and choose
iPhone Bluetooth Headset.
m Make sure iPhone is paired with the headset. See page 3.
m On iPhone, make sure Bluetooth is turned on. From the
Home screen, choose Settings > General > Bluetooth and
turn Bluetooth on.
m On iPhone, choose Settings and turn Airplane Mode on.
Then wait about three seconds and turn it o∂ again.
For more tips and troubleshooting, go to:
www.apple.com/support/iphone
English 11
Read all safety information below and operating
instructions before using the iPhone Bluetooth
±
Headset to avoid injury.
Important Safety Information
WARNING: Failure to follow these safety instructions could
result in fi re, electric shock, or other injury or damage.
Handling the iPhone Bluetooth Headset
Do not drop, disassemble or open, crush, bend or deform,
puncture, shred, microwave, incinerate, paint, or insert
foreign objects into the iPhone Bluetooth Headset.
Avoiding Water and Wet Locations
Do not use the iPhone Bluetooth Headset in rain, or near
washbasins or other wet locations. Take care not to spill any
food or liquid on the iPhone Bluetooth Headset. In case the
iPhone Bluetooth Headset gets wet, turn it o∂ (press and
hold the button for about four seconds, until the status light
blinks amber) before cleaning, and allow it to dry thoroughly
before turning it on again. Do not attempt to dry the iPhone
Bluetooth Headset with an external heat source, such as a
microwave oven or hair dryer.
12 English
Repairing the iPhone Bluetooth Headset
Never attempt to repair or modify the iPhone Bluetooth
Headset yourself. The iPhone Bluetooth Headset does not
contain any user-serviceable parts. If the iPhone Bluetooth
Headset has been submerged in water, punctured, or
subjected to a severe fall, do not use it until you take it to an
Apple Authorized Service Provider.
Charging the iPhone Bluetooth Headset
To charge the iPhone Bluetooth Headset, use only the
iPhone Bluetooth Travel Cable with an Apple USB Power
Adapter or a high-power USB port on another device that
is compliant with the USB 2.0 or 1.1 standards, or another
Apple-branded product or accessory designed to work with
the iPhone Bluetooth Headset.
Read all safety instructions for any products and accessories
before using with the iPhone Bluetooth Headset. Apple is
not responsible for the operation of third-party accessories
or their compliance with safety and regulatory standards.
When you use the Apple USB Power Adapter to charge
the iPhone Bluetooth Headset, make sure that the power
adapter is fully assembled before you plug it into a power
outlet. Then insert the Apple USB Power Adapter fi rmly into
the power outlet. Do not connect or disconnect the Apple
USB Power Adapter with wet hands. Do not use any power
English 13
adapter other than the Apple USB Power Adapter to charge
the iPhone Bluetooth Headset.
Avoiding Hearing Loss
Permanent hearing loss may occur if the iPhone Bluetooth
Headset is used at high volume. You can adapt over time to
a higher volume of sound, which may sound normal but can
be damaging to your hearing. Set the volume to a safe level
before that happens. If you experience ringing in your ears
or speech sounds muπ ed, reduce the volume or discontinue
use of your headset and have your hearing checked. The
louder the volume, the less time is required before your
hearing could be a∂ ected. Hearing experts suggest that to
protect your hearing:
 Limit the amount of time you use your headset at high
volume.
Â
Avoid turning up the volume to block out noisy
surroundings.
Â
Turn the volume down if you can’t hear people speaking
near you.
In Case of Skin Irritation
Headsets can sometimes lead to ear infections if not
properly cleaned. Clean the speaker of your iPhone
Bluetooth Headset when necessary using water or an
14 English
antiseptic, such as isopropyl alcohol, on a slightly damp, lintfree cloth. If skin irritation develops, discontinue use. If the
problem persists, consult a physician.
Driving Safely
Check and obey the laws and regulations on the use of
mobile devices like iPhone in the areas where you drive.
Be careful and attentive while driving. If you decide to use
iPhone while driving, keep in mind the following guidelines:
Give full attention to driving and to the road. Using a
mobile device while driving may be distracting. If you fi nd it
disruptive or distracting while operating any type of vehicle,
riding a bicycle, or performing any activity that requires your
full attention, pull o∂ the road and park before making or
answering a call if driving conditions require.
Choking Hazards
The iPhone Bluetooth Headset is small and may present a
choking hazard to small children. Keep from small children.
For Vehicles Equipped with an Air Bag
An air bag infl ates with great force. Do not store the iPhone
Bluetooth Headset or any of its accessories in the area over
the air bag or in the air bag deployment area.
English 15
Radio Frequency Interference
Nearly every electronic device is subject to radio frequency
interference from external sources if inadequately shielded,
designed, or otherwise confi gured to be compatible. As a
result, the iPhone Bluetooth Headset may cause interference
with other devices. Follow these instructions to avoid
interference problems.
Aircraft
Federal Aviation Administration (FAA) regulations may
prohibit using wireless devices while in the air. Turn the
iPhone Bluetooth Headset o∂ when on an airplane.
Vehicles
RF signals may a∂ ect installed or inadequately shielded
electronic systems in motor vehicles. Check with the
manufacturer or its representative regarding your vehicle.
Electronics Devices
Most modern electronic equipment is shielded from RF
signals. However, certain electronic equipment may not be
shielded against the RF signals from the iPhone Bluetooth
Headset.
16 English
Hearing Aids
The iPhone Bluetooth Headset may interfere with some
hearing aids. If it does, consult the hearing aid manufacturer
or your physician for alternatives or remedies.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device or your physician to determine
if it is adequately shielded from external RF energy.
Turn the iPhone Bluetooth Headset o∂ in health care
facilities when any regulations posted in these areas instruct
you to do so. Hospitals or health care facilities may be using
equipment that could be sensitive to external RF energy.
Posted Facilities
Turn o∂ the iPhone Bluetooth Headset in any facility where
posted notices so require.
Blasting Areas
To avoid interfering with blasting operations, turn o∂ the
iPhone Bluetooth Headset when in a “blasting area” or in
areas posted “Turn o∂ two-way radio.” Obey all signs and
instructions.
English 17
Important Handling Information
NOTICE: Failure to follow these handling instructions
could result in damage to the iPhone Bluetooth Headset
or other property.
Using Connectors and Ports
Never force a connector into a port. Check for obstructions
on the port. If the connector and port don’t join with
reasonable ease, they probably don’t match. Make sure
that the connector matches the port and that you have
positioned the connector correctly in relation to the port.
Keeping the iPhone Bluetooth Headset Within Acceptable
Temperatures
Operate the iPhone Bluetooth Headset in a place where the
temperature is always between 0º and 35º C (32º to 95º F).
The iPhone Bluetooth Headset battery life might temporarily
shorten in low-temperature conditions.
Store the iPhone Bluetooth Headset in a place where the
temperature is always between -20º and 45º C (-4º to 113º
F). Don’t leave the iPhone Bluetooth Headset in your car,
because temperatures in parked cars can exceed this range.
18 English
Loading...
