AOC L1702, F7317 Service Manual

HP L1702/FP7317 Service Manual

SERVICE MANUAL

17” LCD Monitor

HP Compaq

L1702 Model

F7317 Model

THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER THE DATE OF PUBLICATION AND DISCLAIMS RELIABILITY FOR CHANGES, ERRORS OR OMISSIONS.

MANUFACTURE DATA Jan-12-2004

Update DATA Jun-10-2004

Page 1 of 143

		HP L1702/FP7317 Service Manual
		Table of Contents
Table of Contents ----------------------------------------------------------------------------------			02
Revision List		----------------------------------------------------------------------------------------	04
1.Configurations ---------------------------------------------------------------------			05
2.Product Feature ---------------------------------------------------------------------			05
3. LCD Monitor Description ---------------------------------------------------------------			06
4. Operation Instructions --------------------------------------------------------------------			07
4.1	General	Instructions ------------------------------------------------------------------	07
4.2	Control -------------------------------------------------------------------------	Button	07
4.3	Adjusting ----------------------------------------------------------------The Picture		08
5. Input/Output ------------------------------------------------------------------Specification			09
5.1 Input Signal ------------------------------------------------------------------Connector			09
	5.1.1 Analog -------------------------------------------------------D-SUB Connector		09
5.2 Factory --------------------------------------------------------Preset Display Modes			10
5.3 Power Supply ----------------------------------------------------------Requirements			10
	5.3.1 Input/Output ------------------------------------------------------Requirements		10
	5.3.2 Inverter -----------------------------------------------------------Max Brightness		11
	5.3.3 Inverter ------------------------------------------------------------Min Brightness		11
5.4 Panel Specification ---------(AU EN05/QDI L07/Hydis E13-100/LG E01)			12
	5.4.1 Panel ---------------------------------------------------------------------Feature		12
	5.4.2 Display ------------------------------------------------------------Characteristics		13
	5.4.3 Optical -----------------------------------------------------------Characteristics		15
	5.4.4 Parameter --------------------------------guide line for CCFL Inverter		19
6. Block Diagram -----------------------------------------------------------------------------------			20

Page 2 of 143

	HP L1702/FP7317 Service Manual
6.1 Monitor Exploded View ----------------------------------------------------------------	20
6.2 Software Flow Chart ---------------------------------------------------------------------	22
6.3 Electrical Block Diagram ----------------------------------------------------------------	23
6.3.1 Scalar Board ----------------------------------------------------------------------	23
6.3.2 Inverter/Power Board -----------------------------------------------------------	24
7. Schematic -----------------------------------------------------------------------------------------	26
7.1 Scalar Board ----------------------------------------------------------------------------	26
7.2 Inverter/Power Board --------------------------------------------------------------	29
7.3 Key Pad Board -------------------------------------------------------------------------	31
7.4 Audio Board ---------------------------------------------------------------------------	32
8. PCB Layout --------------------------------------------------------------------------------------	33
8.1 Main Board -----------------------------------------------------------------------------	33
8.2 Inverter/Power Board ----------------------------------------------------------------	34
8.3 Keypad Board -------------------------------------------------------------------------	36
8.4 Audio Board ---------------------------------------------------------------------------	37
9. Maintainability -----------------------------------------------------------------------------------	37
9.1 Equipments and Tools Requirements ---------------------------------------------	37
9.2 Trouble Shooting -----------------------------------------------------------------------	38
9.2.1 Main Board -------------------------------------------------------------------	38
9.2.2 Power/Inverter Board -------------------------------------------------------	39
9.2.3 Key Pad Board -----------------------------------------------------------------	41
10. White-Balance, Luminance Adjustment -----------------------------------------------	42
11. EDID Content -----------------------------------------------------------------------------------	43
12. BOM List ---------------------------------------------------------------------------------	44 143

Page 3 of 143

	HP L1702/FP7317 Service Manual
12.1 L1702 Model ---------------------------------------------------------------------	44 75
12.2 F7317 Model --------------------------------------------------------------------	75~107
12.3 LG Panel Model --------------------------------------------------------------	108~125
12.4 Hydis Panel Model -----------------------------------------------------------	125~143

		Revision List
Revision	Date	Change Description
V1.0	Jan-12	Initial Release
V2.0	Jun-10	Add Panel Spec and BOM of LG & Hydis panel model
		Update the BOM list of AU Panel model

Page 4 of 143

HP L1702/FP7317 Service Manual

1.CONFIGURATIONS

The configurations information in this section is provided for reference only. Consult the SKU Matrix for each kit (typically a boxed monitor assembly with cushions, power cord, etc.)

	MODEL	BRANDING	COLORS	SPEAKERS	BEZEL	EDID #
	FP7317	Compaq	Compaq Silver	Yes	FP7317	CPQ 145B
		Consumer	Carbon
	F1723	HP	Platinum Blue	Yes	f1723	HWP 2609
		Consumer	Dusk Lake
	VF17	HP CTO	Platinum Blue	No	vf17	HWP 260A
			Dusk Lake
	FP17	Compaq	Compaq Silver	No	FP17	CPQ 145E
		CTO	Carbon
	L1702	HP	Compaq Silver	No	1702	HWP 2601
		Commercial	Carbonite
	L1702m	HP	Compaq Silver	Yes	1702m	HWP 2601
		Commercial	Carbonite
	L1702C	HP	Carbonite	No	1702	HWP 2601
		Commercial

2. PRODUCT FEATURE

43.2cm(17”) a-si TFT Active matrix LCD panel, 0.264mm dot pitch Scalar chipset MST9151B

16 factory presets, 20 new modes

Vertical refresh rate 55Hz to 75Hz; Horizontal frequency 30kHz to 83kHz Power Internal AC 100V-240V(+/-10%)

Tilt -5 ° to 20 ° CE mark TCO 99 mark

VESA DPMS compliant VESA DDC2B compliant

Page 5 of 143

HP L1702/FP7317 Service Manual

3. LCD MONITOR DESCRIPTION

The LCD Monitor will contain main board, power board, key board and which house the flat panel control logic, brightness control logic and DDC.

The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage.

Monitor Block Diagram

	CCFT Drive.	Flat Panel and
		CCFL backlight

Power Board			Main Board
								RS232 Connector
								For white balance
								adjustment in
								factory mode
			Keyboard
AC-IN
				HOST Computer			Video signal, DDC
90V-264V

Page 6 of 143

HP L1702/FP7317 Service Manual

4. OPERATION INSTRUCTIONS

4.1 General Instructions

Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor. By changing these settings, the picture can be adjusted

to your personal performance.

-The power cord should be connected and insert to adaptor.

-Connect the video cable from the monitor to the computer VGA card.

-Press the power button to turn on the monitor, the power indicator will light up to Green.

4.2Control Buttons

-Power Button:

When pressed, the monitor enters the off mode, and the LED turns blank. Press again to restore normal status.

-(Down/ Auto) and + (Up) Button:

The -/+ Button is browse OSD key. Press a select into adjustment.

The Auto Adjust Key is used to automatically set the H Position, V Position, Clock and Phase.

- Select Key:

Select key is into OSD sub-menu hot key when OSD turn on.

- Power Indicator:

Green — Power On mode. Amber — Power Saving mode.

Blank — Power Off Mode.

CONTROL BUTTONS

Model:

L1702

Select Button		Down / Auto Button		Up Button	On/Off Switch
Model:
F7317					Speaker

Select Button

Down / Auto Button

Up Button

On/Off Switch

Page 7 of 143

HP L1702/FP7317 Service Manual

4.3 Adjust The Picture

1.		Brightness	Adjust the brightness.
2.		Contrast	Adjust the contrast
			Adjust the:
			z Auto Adjustment: Adjusts the main settings and produces a
			stable, centered image.
3.		Image Control	z H-Position: horizontal position of the screen image.
			z V-Position: vertical position of the screen image.
			z Clock: frequency of the pixel clock to minimize vertical bar.
			z Phase: phase value to minimize horizontal jitters.
			z 9300K: recall 9300K color
3.		Color	z 6500K-sRGB: recall 6500K sRGB color
			z Custom Color: adjusts the color tint of white, and the red,
			green, and blue (RGB) mix for colors.
		Language	Shows the language of the OSD window.
4.
5.			z Power Saver: enable/disable power saving
			z Power On Recall: enable/disable power recall
		Management	z Mode Display: enable/disable mode display
			z Sleep Timer: set sleep timer
			z Basic Menu: set to basic menu
		OSD Control	OSD (on Screen Display) settings: adjusts the H/V position,
6.
			timeout, On Screen Display window.
7.		Factory Reset	Resets the display to original factory settings for color, brightness,
			phase, and clock.
8.		Exit	Closes the OSD window.

Page 8 of 143

HP L1702/FP7317 Service Manual

5. Input/Output Specification

5.1 Input Signal Connector

5.1.1 Analog D-SUB Connector

PIN	MNEMONIC	SIGNAL
1	RV	Red Video
2	GV	Green Video
3	BV	Blue Video
4	NC	None
5	GND	Ground (DDC Return)
6	RG	Red GND
7	GG	Green GND
8	BG	Blue GND
9	+5 V	+5 V (from PC)
10	SG	Sync Ground
11	NC	None
12	SDA	DDC Data
13	HS	Horizontal Sync
14	VS	Vertical Sync
15	SCL	DDC Clock

VGA connector layout

PIN 1	PIN 5
PIN 11

Page 9 of 143

HP L1702/FP7317 Service Manual

5.2 Factory Preset Display Modes

	Preset		Pixel		Horz			Horz	Vert Freq	Vert	Pixel Clk		Source
			Format		Freq (KHz)			Polarity	(Hz)	Polarity	(MHz)
	1		640 x 480		31.469			-	59.940	-	25.175		VGA
	2		640 x 480		37.861			-	72.809	-	31.500		VESA
	3		640 x 480		37.500			-	75.000	-	31.500		VESA
	4		720 x 400		31.469			-	70.087	+	28.322		VGA
	5		800 x 600		37.879			+	60.317	+	40.000		VESA
	6		800 x 600		48.077			+	72.188	+	50.000		VESA
	7		800 x 600		46.875			+	75.000	+	49.500		VESA
	8		832 x 624		49.726			±	74.551	±	57.284		MAC
	9		1024 x 768		48.363			-	60.004	-	65.000		VESA
	10		1024 x 768		56.476			-	70.069	-	75.000		VESA
	11		1024 x 768		60.023			+	75.029	+	78.750		VESA
	12		1152 x 870		68.68			-	75.06	-	100.000		Mac
	13		1152 x 900		71.71			-	76.05	-	105.561		Sun
	14		1280 x 1024		63.98			+	60.02	+	108.000		VESA
	15		1280 x 1024		79.97			+	75.02	+	135.000		VESA
5.3 Power Supply Requirements
5.3.1 Input / Output Requirements
			PARAMETER						RANGE
		AC Input Voltage				90 to 264V
		AC Input Frequency				47 to 63 Hz
		AC Input Current				1.5A MAX
		Inrush Current				60A MAX AT 264VAC COLD START
		Leakage Current				3.5 mA MAX and less than 0.25mA at 100Vac
		Output voltage / current				12V / 2.5A , 5V / 2A
		Output power				45W Max
		Efficiency				>80%
		Saving Mode				<2W Max @5V/0.1A , 12V/0A

Page 10 of 143

HP L1702/FP7317 Service Manual

5.3.2 Inverter Max Brightness

(Vadj:4.5v), LOAD=100KΩX4			(ROOM TEMPERATURE 25 ±4 )
PWPC1742AUH1
ITEM	SYMBOL		MIN.	TYP.	MAX.		UNIT		REMARK
Input voltage	Vin		10.8	12	13.2		V	---
Input current	Iin		---	2250	2500		mA		FOR 4 LOAD
Output Current	Iout		13.5	14.0	14.5		mA		FOR 1 LOAD
Frequency	F		50	55	60		KHZ		FOR 1 LOAD
H.V Load	Vload		600	700	800		Vrms		RL=100KΩ
Start voltage	Vst		1450	1700	1800		Vrms		RL=CCFL
Protect delay time	PDT		---	1			Sec	---
PWPC1742QDH1
ITEM	SYMBOL		MIN.	TYP.	MAX.		UNIT		REMARK
Input voltage	Vin		10.8	12	13.2		V
Input current	Iin			2250	2500		mA		FOR 4 LOAD
Output Current	Iout		6.5	7.0	7.5		mA		FOR 1 LOAD
Frequency	F		50	55	60		KHZ		FOR 1 LOAD
H.V Load	Vload		625	725	825		Vrms		RL=100KΩ
Start voltage	Vst		1450	1700	1800		Vrms		RL=CCFL
Protect delay time	PDT			1			Sec

5.3.3 Inverter Min Brightness

(Vadj:0.0v), LOAD=100KΩX4		(ROOM TEMPERATURE 25 ±4 )
PWPC1742AUH1
ITEM	SYMBOL	MIN.	TYP.	MAX.	UNIT		REMARK
Input voltage	Vin	10.8	12	13.2	V
Input current	Iin		700	900	mA		FOR 4 LOAD
Output Current	Iout	3.0	3.5	4.0	mA		FOR 1 LOAD
Frequency	F	---	---	---	KHZ		---
Start voltage	Vst	---	---	---	Vrms		---
H.V Load	Vload	---	---	---	Vrms		RL=100KΩ

Page 11 of 143

HP L1702/FP7317 Service Manual

PWPC1742QDH1

ITEM	SYMBOL	MIN.	TYP.	MAX.	UNIT	REMARK
Input Voltage	Vin	10.8	12	13.2	V
Input Current	Iin		700	900	mA	FOR 4 LOAD
Output Current	Iout	3.0	3.5	4.0	mA	FOR 1 LOAD
Frequency	F	---	---	---	KHZ
Start Voltage	Vst	---	---	---	Vrms
H.V Load	Vload	---	---	---	Vrms	RL=100KΩ

5.4 PANEL SPECIFICATION (AU EN05/ QDI L07/ Hydis E13-100/LG E01) 5.4.1 Panel Feature

AU EN05

–This specification applies to the 17.0 inch Color TFT-LCD Module M170EN05

–The display supports the SXGA (1280(H) x 1024(V)) screen format and 262k colors(RGB 6-bits data) –All input signals are 2 Channel LVDS interface compatible

–This module does not contain an inverter card for backlight

QDI L07

–High aperture panel; high-brightness or low power consumption –Brilliant and high contrast image

–Small footprint and thin shape –SXGA resolution

–LVDS interface

–Low power consumption –Wide viewing angle

Hydis E13-100

–LVDS interface with 2 pixels / clock –High-speed response

–Lower power consumption

–6 bits(FRC) colors, display 16,194,227 –Incorporated edge type back-light(Four lamps)

–High luminance and contrast ratio, Lowe reflection and wide viewing angle –DE(Data Enable) & H-Sync & V-Sync mode

LG E01

–This TFT-LCD has a 17.0 inch diagonal measured display area with SXGA resolution(1024 vertical by 1280 horizontal pixel array)

–8-bit gray scale signal for each dot, thus, presenting a palette of more than 16.2M colors with FRC. –Lowe power, high speed ,low EMI.

–Thin thickness, wide viewing angle, lower power are critical factors and graphic displays.

Page 12 of 143

						HP L1702/FP7317 Service Manual
	5.4.2 Display Characteristics
	AU EN05
	ITEM		UNIT		SPECIFICATIONS
Screen Diagonal			[mm]	432(17.0”)
Active Area			[mm]	337.920(H) x 270.336(V)
Pixel Pitch H x V				1280(x3) x 1024
Pixel Arrangement			[mm]	0.264(per one triad) x 0.264
Display Mode				R.G.B Vertical Stripe
White Luminance (Center)			[cd/m²]	260 cd/m²@7mA (Typ)
Contrast Ratio				450:1(Typ)
Optical Response Time			[msec]	16(Typ)
Color saturation				72% NTSC
Nominal input Voltage VDD			[Volt]	+5.0V
Power consumption			[Watt]	25W (Typ.) (w/o Inverter, All white pattern)
(VDD line + CCFL line)
Weight			[Grams]	2000(Typ)
Physical Size			[mm]	358.5(W) x 296.5(H) x 19.0(D)(Typ)
Electrical Interface				Even/Odd R/G/B data, 3 sync signal clock
Support Color				262K colors (RGB 6-bit data)
Temperature Range			[ ]	0 to +50
Operating Storage (Shopping )			[ ]	-20 to +60
	QDI L07
	PARAMETER		SPECIFICATION			UNIT
	Display Size	43(17") Diagonal				cm
	Active area	337.9(H) x 270.3(V)				mm
	Pixel format	1280(H) x 1024(V)				pixel
		(1 Pixel=R+G+B dots)
	Pixel pitch	0.264(H) x 0.264(V)				mm
	Pixel configuration	R, G, B vertical stripe
	Display mode	Normally White
	Unit outline dimensions (typ.)*1	358.5 x 296.5x 16.5				mm
	weight	1970(Max.)				g
	Surface treatment	Anti-glare and hard-coating 3H
		Low reflection (~ 5%)
	Lamp Quantity	4				pcs
	1.Note: Excluding backlight cables.

Page 13 of 143

HP L1702/FP7317 Service Manual

Hydis E13-100
Parameter			Specification		Unit
Active area		337.92(H) x 270.336(V)			mm
Number of pixels		1280(H) x1024(V)			pixels
Pixel pitch		0.264(H) x 0264(V)			mm
Pixel arrangement		RGB Vertical stripe
Display colors		16,194,227			colors
Display mode		Normally White
Dimensional		358.5(H)x 296.5(V)x 17.0(D)typ.			mm
outlint
Weight		1900 max			gram
Back-light		Top/Bottom edge side 4-CCFL type				Note1
LG E01
Active screen size			17.0 inch (43.27cm)diagonal
Outline Dimension			358.5(H)x296.5(V)x17.0(D)mm(Typ.)
Pixel Pitch			0.264mm x 0.264mm
Pixel Format			1280(H)x 1024(V)Pixels. RGB stripe arrangement
Display colors			16.2M colors
Luminance, white			250cd/ (Typ. Center 1 point)
Power Consumption			19.05 Watts(Typ.)
Weight			1890g(Typ.)
Display operating mode			Transmissive mode, normally white
Surface treatments			Hard coating(3H),Anti-glare treatment of the front polarizer

Page 14 of 143

HP L1702/FP7317 Service Manual

5.4.3 Optical Characteristics

QDI L07

Parameter		Symbol	Condition	Min	Typ.	Max.	Unit	Remark
	Horizontal	θ21, θ22		65	75		Deg
	Vertical	θ11	CR>10	55	65		Deg
Viewing angle		θ12		50	60		Deg	Note1,4
range	Horizontal	θ21, θ22			85		Deg
	Vertical	θ11	CR>5		75		Deg
		θ12			70		Deg
Contrast ratio		CR	θ=0°	300	450	—		Note2, 4
Response time		t	θ=0°	—	20		ms
Rise time	tr				4		ms	Note3, 4
Fall time	td				16		ms
Chromaticity of White(CIE 1931)		Wx		0.283	0.313	0.343
		Wy		0.299	0.329	0.359
Chromaticity of Red(CIE 1931)		Rx		0.603	0.633	0.663
		Ry		0.306	0.336	0.366		Note4
Chromaticity of Green(CIE 1931)		Gx		0.270	0.300	0.330
		Gy		0.556	0.586	0.616
Chromaticity of Blue(CIE 1931)		Bx		0.116	0.146	0.176
		By		0.073	0.103	0.133
Luminance of white		YL		240	300		cd/	IL=7.0
Note 4[Note 4]								mArms
White Uniformity		δw		—	1.25	1.33		Note5
Cross talk						1.50%		Note6

Page 15 of 143

HP L1702/FP7317 Service Manual

AU EN05

The optical characteristics are measured under stable conditions at 25 (Room Temperature):

	ITEM	UNIT	CONDITIONS	MIN	TYP.	MAX.
		[degree]	Horizontal(Right)	60	70	–
		[degree]	CR=10(Left)	60	70	–
		[degree]	Vertical(Up)	60	70	–
	Viewing Angle	[degree]	CR=10(Down)	60	70	–
		[degree]	Horizontal(Right)	70	80	–
		[degree]	CR=5(Left)	70	80	–
		[degree]	Vertical(Up)	70	80	–
		[degree]	CR=5(Down)	70	80	–
	Contrast ratio		Normal Direction	250	450	–
		[m sec]	Raising Time	–	4	5
	Response Time (Note 1)	[m sec]	Falling Time	–	12	20
		[m sec]	Raising +Falling	–	16	25
			Red x	0.61	0.64	0.67
			Red y	0.31	0.34	0.37
	Color /Chromaticity		Green x	0.26	0.29	0.32
	Coordinates(CIE)		Green y	0.58	0.61	0.64
			Blue x	0.11	0.14	0.17
			Blue y	0.04	0.07	0.10
	Color Coordinates (CIE) White		White x	0.28	0.31	0.34
			White y	0.30	0.33	0.36
	White Luminance	[cd/ ]		200	260	–
	@CCFL 7.0mA (center)
	Luminance Uniformity(Note 2)	[%]		75	80	–
	TCO99 1.5.2B luminance					1.7
	uniformity (Note 3)
	Crosstalk (in 75Hz)(Note 4)	[%]				1.5

Page 16 of 143

HP L1702/FP7317 Service Manual

Hydis E13-100

Page 17 of 143

HP L1702/FP7317 Service Manual

LG E01

Page 18 of 143

HP L1702/FP7317 Service Manual

5.4.4 Parameter guide line for CCFL Inverter

Back-Light Unit

	AU EN05
	SYMBOL	PARAMETER	MIN	TYP	MAX	UNITS	CONDITION
	(L63)	White Luminance	200	260	–	[cd/ ]	(Ta=25 )
	ISCFL	CCFL standard current	6.5	7.0	7.5	[mA]	(Ta=25 )
						rms
	IRCFL	CCFL operation range	3.0	7.0	7.5	[mA]	(Ta=25 )
						rms
	ICFL	CCFL Inrush current	–	26	34	[mA]	Note 1
		CCFL Frequency	40	50	80	[KHz]	(Ta=25 )
	fCFL						Note 2
	ViCFL	CCFL ignition Voltage	1700			[Volt]	(Ta=0 )
	(0 )					rms	Note 3
	ViCFL	CCFL ignition Voltage	1200			[Volt]	(Ta=25 )
	(25 )					rms	Note 3
	TCFL	CCFL Dark start time			1.0	sec	(Ta=25 )
	VCFL	CCFL Discharge Voltage		700	860	[Volt]	(Ta=25 )
		(Reference)				rms	Note 4
	PCFL	CCFL Power consumption		19.6	25.8	[Watt]	(Ta=25 )
							Note 4

QDI L07

The backlight system is an edge-lighting type with 2- CCFL(Cold Cathode Fluorescent Lamp). The characteristics of four lamps are shown in the following tables.

PARAMETER	SYMBOL	MIN	TYP	MAX	UNIT	REMARK
Lamp current range	IL	3.0	7.0	8.0	mArms	Note1
Lamp voltage	VL		725		Vrms
Lamp power consumption	PL		5.1		W	Note2 IL=7.0mA
Lamp frequency	FL		52		kHz	Note3
Established starting voltage	Vs			1100	Vrms	Ta=25	Note4
				1420	Vrms	Ta=0
Lamp life time	LL	40000	50000		hour	Note5

Page 19 of 143

HP L1702/FP7317 Service Manual

6. Block Diagram

6.1 Monitor Exploded View

L1702 Model

Page 20 of 143

HP L1702/FP7317 Service Manual

F7317 Model

Page 21 of 143

HP L1702/FP7317 Service Manual

6.2 Software Flow Chart

1

2 Y 3

N

4

5 N

Y

6

7 N 8

Y

9

10	N	11
Y
N 12		13	N
Y		Y
14		15	N	16
		Y
		17

1)MCU initialize.

2)Is the eeprom blank?

3)Program the eeprom by default values.

4)Get the PWM value of brightness from eeprom. Check the pin PANEL1 and PANEL2 to tell which panel to get with it.

5)Is the power key pressed?

6)Clear all global flags.

7)Are the AUTO and SELECT keys pressed?

8)Enter factory mode.

9)Saving the power key status into eeprom. Turn on the LED and set it to green color. Scalar initializes.

10)In standby mode?

11)Update the lifetime of back light.

12)Check the analog and digital port, are there any signals coming?

13)Does the scalar send out a interrupt request?

14)Wake up the scalar.

15)Are there any signals coming from analog or digital port?

16)Display " No Input Signal " message. And go into standby mode after the message disappear.

17)Program the scalar to be able to show the coming mode.

18)Process the OSD display.

19)Read the keyboard. Is the power key pressed?

18	N 19
	Y

Page 22 of 143

HP L1702/FP7317 Service Manual

6.3 Electrical Block Diagram

6.3.1 Scalar Board Block Diagram

Page 23 of 143

HP L1702/FP7317 Service Manual

6.3.2 Inverter / Power Board Block Diagram

Inverter Block Diagram

Page 24 of 143

HP L1702/FP7317 Service Manual

Power Block Diagram

Page 25 of 143

HP L1702/FP7317 Service Manual

7.SCHEMATIC

7.1 SCALAR BOARD

CN303

RXD

RXD

6

TXD

1

PC5V

D327 MLL5232B 5.6V

TXD

6

HSI-1

2

VSI-1

3

CLK_DDC

CN301

4

DAT_DDC

NC DB15

5

TXD

11

1

AR+

FB301

0 1/16W

R302

100 1/16W

C302

0.047uF

RIN

4

6

RXD

6

AR-

7

VGA_CON

D329

12

2

AG+

FB302

0 1/16W

R303

100 1/16W

C303

0.047uF

GIN

4

8

AB+

7

AG-

9

AB-

MLL5232B 5.6V

13

3

AB+

FB303

0 1/16W

R304

100 1/16W

C304

0.047uF

BIN

4

10

AG+

8

AB-

75 1/16W

NC

R306 1/16W

NC

R307

1/16W

NC

14

AG-

14

10

VGA_CON

R305

470 1/16W

C305

0.001uF

11

4

SOG

4

12

AR+

9

PC5V

R301

C301

C306

C307

13

AR-

15

5

75

75

CONN

D328

R308

100 1/16W

C308

0.047uF

GNDR

4

R309

100 1/16W

C309

0.047uF

MLL5232B 5.6V

GNDG

4

R310

100 1/16W

C310

0.047uF

GNDB

4

3

D301

3

D302

3

D303

BAV99

BAV99

BAV99

VCC5V

VCC5V

R311

2

1

2

1

2

1

10K 1/16W

R312

100 1/16W

ST_DET1

6

VCC5V

PC5V

HSI-1

FB304

150 OHM

R313

1K 1/16W

1

2

HSYNC

4

D304

VSI-1

R314

100 1/16W

R315

1K 1/16W

VSYNC

4

BAV70

D305

D306

R316

C311

R317

C312

D307

3

MLL5232B 5.6V

MLL5232B 5.6V

MLL5232B 5.6V

R318

R319

2.2K 1/16W

33pF

10K 1/16W

220pF

4.7K 1/16W

4.7K 1/16W

U301

C313

8

1

0.1uF

VCC

A0

R342

22 1/16W

7

2

CLK_DDC

R320

47 1/16W

SCL/I

6

WP

A1

3

DAT_DDC

R321

47 1/16W

SDA/I

5

SCL

A2

4

SDA

GND

D308

D309

AT24C02N-10SC

MLL5232B 5.6V

MLL5232B 5.6V

R351

0 1/16W

VCC5V

VCC5V

G

1

5

R356

Q302

G

D

R358

2

S

4

S

Q303

4.7K 1/16W

SCL/I

3

R354

D

NC

4.7K 1/16W

NC

0 1/16W

SOT23

R357

R359

6

DDC_DAT

0 1/16W

SDA/I

6

DDC_CLK

0 1/16W

0 1/16W

R355

Page 26 of 143

HP L1702/FP7317 Service Manual

CN303

RXD

RXD

6

TXD

1

PC5V

D327 MLL5232B 5.6V

TXD

6

HSI-1

2

VSI-1

3

CLK_DDC

CN301

4

DAT_DDC

NC DB15

5

TXD

11

1

AR+

FB301

0 1/16W

R302

100 1/16W

C302

0.047uF

RIN

4

6

RXD

6

AR-

7

VGA_CON

D329

12

2

AG+

FB302

0 1/16W

R303

100 1/16W

C303

0.047uF

GIN

4

8

AB+

7

AG-

9

AB-

MLL5232B 5.6V

13

3

AB+

FB303

0 1/16W

R304

100 1/16W

C304

0.047uF

BIN

4

10

AG+

8

AB-

11

AG-

14

4

R305

470 1/16W

C305

0.001uF

SOG

4

12

AR+

9

PC5V

R301

C301

1/16W

C306

1/16W

C307

14

13

AR-

15

5

R306

R307

VGA_CON

75 1/16W

NC

NC

NC

10

75

75

CONN

D328

R308

100 1/16W

C308

0.047uF

GNDR

4

R309

100 1/16W

C309

0.047uF

MLL5232B 5.6V

GNDG

4

R310

100 1/16W

C310

0.047uF

GNDB

4

3

D301

3

D302

3

D303

VCC5V

BAV99

BAV99

BAV99

VCC5V

R311

2

1

2

1

2

1

10K 1/16W

R312

100 1/16W

ST_DET1

6

VCC5V

PC5V

HSI-1

FB304

150 OHM

R313

1K 1/16W

1

2

HSYNC

4

D304

VSI-1

R314

100 1/16W

R315

1K 1/16W

VSYNC

4

BAV70

D305

D306

R316

C311

R317

C312

D307

R318

3

MLL5232B 5.6V

MLL5232B 5.6V

MLL5232B 5.6V

R319

2.2K 1/16W

33pF

10K 1/16W

220pF

4.7K 1/16W

4.7K 1/16W

U301

C313

8

VCC

A0

1

0.1uF

R342

22 1/16W

7

2

CLK_DDC

R320

47 1/16W

SCL/I

6

WP

A1

3

DAT_DDC

R321

47 1/16W

SDA/I

5

SCL

A2

4

SDA

GND

D308

D309

AT24C02N-10SC

MLL5232B 5.6V

MLL5232B 5.6V

R351

0 1/16W

1		5
2		4
3
	SOT23

		VCC5V
		G
	R354	Q303
	S	D
	4.7K 1/16W	NC
6	DDC_DAT
6	DDC_CLK	0 1/16W
		R355

VCC5V
G
Q302
R356		R358
S	D
4.7K 1/16W		SCL/I
NC
		0 1/16W
R357		R359
0 1/16W		SDA/I
		0 1/16W

Page 27 of 143

4	PA[0..9]	PA[0..9]		PA0	LVA3P
				PA1	LVA3M
				PA2	LVACKP
				PA3	LVACKM
				PA4	LVA2P
				PA5	LVA2M
				PA6	LVA1P
				PA7	LVA1M
		PB[0..9]		PA8	LVA0P
4	PB[0..9]			PA9	LVA0M
				PB0	LVB3P
				PB1	LVB3M
				PB2	LVBCKP
				PB3	LVBCKM
				PB4	LVB2P
				PB5	LVB2M
				PB6	LVB1P
				PB7	LVB1M
				PB8	LVB0P
				PB9	LVB0M

HP L1702/FP7317 Service Manual

CN503

LVB0M

RXO0-

1

2

RXO0+

LVB0P

LVB1M

RXO1-

3

4

RXO1+

LVB1P

LVB2M

RXO2-

5

6

RXO2+

LVB2P

LVBCKM

RXOC-

7

8

RXOC+

LVBCKP

LVB3M

RXO3-

9

10

RXO3+

LVB3P

LVA0M

RXE0-

11

12

RXE0+

LVA0P

LVA1M

RXE1-

13

14

RXE1+

LVA1P

LVA2M

RXE2-

15

16

RXE2+

LVA2P

LVACKM

RXEC-

17

18

RXEC+

LVACKP

LVA3M

RXE3-

19

20

RXE3+

LVA3P

21

22

23

24

CON24A

R502

VLCD

0 1/16W

VLCD

2

C509

C510

C511

+

47uF/25V

0.1uF

0.1uF

Page 28 of 143

HP L1702/FP7317 Service Manual

7.2 Power Board

PWPC1742AUH1

R920

C920

47 1/2W

0.001uF/500V

D910

T901

FMB26L10A/100V

1

L903

1

2

4

+12V

O

9

3

+

DB901

+ C922

+

R906

R904

C905

R903

C926

2KBP06M

1000uF/16V

C924

1

3

+

C904

1M 1/8W

1M 1/8W

1500P/2KV

100K 2W

R921

C921

470uF/16V

ZD904

0.1uF

O 7

47 1/2W

100uF/400V

D901

SML4736

-

R907

R905

0.001uF/500V

UF4007

1M 1/8W

1M 1/8W

1

D911

L904

2

3

8

3

2

+5V

2

3

5

+ C923

+

+

FMB26L10A/60V

1000uF/16V

C925

C927

L901

C907

C906

D902

R908

10

470uF/16V

0.1uF

73L174-25-LS

PS102R

5.1 1/10W

1

4

C901

0.1uF

22uF

6O

102PF/250V

C902

2

2

3

102PF/250V

IC901

3

7

Q903

SG6841

1

L902

4

8

2SK2996

73L174-29-LS

SG6841

R915

3

1

4

R914

10 1/10W

24K 1/10W

5

6

C912

R929

0.0033uF/250V

100 1/8W

FB901

1

2

C903

0.1uF/275V

BEAD

CON102

R916

CONN 33L8009-12L-H

R913

10K 1/10W

2

1

DIM

ON/OFF

R901

R902

10K 1/10W

ZD902

ZD903

+5V

4

3

1M/1206

1M/1206

R917

HZ12B2

HZ5C1

6

5

C910

0.39 2W

8

7

1M/1206

0.001uF

10

9

+12V

12

11

R900

NR901

61L58-050-WT

4

1

R928

IC902

R909

1K 1/10W

PC123FY82 4P

R925

4.7K 1/10W

3

2

1K 1/10W

D903

R910

1N4148

R922

R923

F901

ZD901

C908

C929

R927

4.7K 1/10W

33K 1/10W

3.6K 1/10W

2A/250V

MTEJ20B

0.1uF

0.1uF

0 1/10W

R926

R912

Q901

IC903

1K 1/10W

100 1/8W

2PA733P

Q902

HTL431

R924

R911

2PC945P

3

C909

2.4K 1/10W

4.7K 1/10W

2

1

0.1uF

CN901

AOC (Top Victory) Electronics Co., Ltd.

Title

1.POWER OUTPUT 12V & 5 V

Size

Document Number

Rev

B

PWPC1742AUH1

A

2

1

Date:

Thursday, January 08, 2004

Sheet

of

L201

R224

R225

C215

C228

J2

Q203 SI4431 OR AO4411

120UH

1.5K 1/8W

1.5K 1/8W

39pF/3KV

39pF/3KV

+12V

1

8

1

2

7

2

+

3

6

R227

C216

C229

3

R212

4

5

D201

R226

1.5K 1/8W

PT201

39pF/3KV

39pF/3KV

4

C201

C202

2

C225

R214

3.9K 1/10W

SR24

ZD203

1.5K 1/8W

1

EEL-19

8

220uF/25V

104

RLZ11B

1

Q202

NC

2.2K 1/10W

2

DTA144WKA

CONN

3

R242

PROTECT

3

3

R243

R220

1

Q205

R216

3

10K 1/10W

1

Q201

NC

15K 1/10W

C213

9

ON/OFF

PMBS3904

22 1/10W

DTC144WKA

10

2

4

2

0.22uF/250V2

R201

R202

2

Q209

5

NC

NC

2SD5706(DIP&SMD)

DIM

R218

2

R222

1

1

6

22 1/10W

12K 1/10W

1

Q207

7

11

R208

R210

Q210

PMBS3906

3

3

2SD5706(DIP&SMD)

C203

1K 1/10W

33K 1/10W

NC

3

R232

D209

D205

1K 1/10W

1N4148

R205

1N4148

47K 1/10W

C209

R240

D207

R234

0.11uF/25V

51K 1/10W

1N4148

910 1/10W

C205

BU_L

0.1uF

C221

R238

C219

R236

0.15uF/25V

12K 1/10W

0.1uF/25V

560 1/10W

+

C207

R207

16

15

14

13

12

11

10

9

+ C223

4.7uF

NC

C204

C217

C226

J1

REF

SCP

2IN+

2IN-

2FBK

2DTC

2OUT

Vcc

150uF/25V

0.1uF/25V

L202

R228

39pF/3KV

39pF/3KV

Q204 SI4431 OR AO4411

120UH

1.5K 1/8W

R229

R230

R231

PT202

1

1FBK

1DTC

1OUT

1.5K 1/8W

1.5K 1/8W

1.5K 1/8W

2

1IN+

1IN-

GND

U201

1

8

EEL-19

C218

C227

3

CT

RT

TL1451ACNSR

2

7

1

8

39pF/3KV

39pF/3KV

4

3

6

C206

1

2

3

4

5

6

7

8

R213

4

5

D202

ZD204

2

0.1uF

3.9K 1/10W

SR24

C224

R215

RLZ11B

CONN

R206

NC

2.2K 1/10W

3

9

47K 1/10W

R244

3

R221

4

10

NC

1

Q206

R217

15K 1/10W

C214

5

C210

PMBS3904

22 1/10W

0.22uF/250V

6

0.1uF/25V

2

2

2

C208

R204

7

11

330pF

10K 1/10W

R209

R219

R223

1

1

R233

R203

1K 1/10W

2

1K 1/10W

22 1/10W

12K 1/10W

NC

1

Q208

Q211

PMBS3906

2SD5706(DIP&SMD)

Q212

3

3

3

2SD5706(DIP&SMD)

D210

D206

1N4148

1N4148

R211

is power GND

33K 1/10W

BU_R

is signal GND

51K 1/10W

1N4148

910 1/10W

R241

D208

R235

AOC (Top Victory) Electronics Co., Ltd.

Title	PWPC1742AUH1
Size	Document Number			Rev
B	Thursday, January 08, 2004			2
Date:		Sheet	2 of 2

C222	R239	C220	R237
0.15uF/25V	12K 1/10W	0.1uF/25V	560 1/10W

Page 29 of 143

HP L1702/FP7317 Service Manual

PWPC1742QDH1

	4
	+	DB901
		2KBP06M
1		3
	-
	2
2		3
		L901
		73L174-25-LS
1		4

C901

102PF/250V

	C902
	102PF/250V
2	3
	L902
	73L174-29-LS
1	4
C903	0.1uF/275V
R901	R902
1M/1206	1M/1206

1M/1206

R900

NR901 61L58-050-WT

F901

2A/250V

3

2 1

					R920	C920
					47 1/2W	0.001uF/500V
					D910
				T901	FMB26L10A/100V
					1	L903
			1			2
			O	9	3	+ C922
R906	R904	C905	R903
					R921	1000uF/16V
1M 1/8W	1M 1/8W	1500P/2KV	100K 2W
+ C904				O 7	47 1/2W	C921
100uF/400V

R907	R905	D901			0.001uF/500V
		UF4007
1M 1/8W	1M 1/8W			1	D911	L904
		3	8	3	2

						5	FMB26L10A/60V		+ C923
		+		D902		R908			1000uF/16V
C907			C906				10
				PS102R		5.1 1/10W
0.1uF			22uF			6O
IC901	3	7			2	Q903
SG6841
	4	8		1		2SK2996
R914	SG6841	R915			3
		10 1/10W				C912
24K 1/10W	5	6
						0.0033uF/250V
	1	2				FB901
						BEAD
			R916
R913			10K 1/10W
								R929	R922
10K 1/10W						R917
								100 1/8W	33K 1/10W
		C910				0.39 2W
		0.001uF
						4	1	R928
							IC902
								1K 0805
R909							PC123FY82 4P
4.7K 1/10W						3	2
						D903
			R910			1N4148		C929
ZD901		C908
			4.7K 1/10W					0.1uF
MTEJ20B		0.1uF
R912	Q901						R927
100 1/8W	2PA733P						0 0805	R926
			Q902			IC903		1K 0508
		R911	2PC945P			HTL431
	C909								R924
		4.7K 1/10W
	0.1uF								2.4K 1/10W

		+12V
+
C924		C926
470uF/16V	ZD904	0.1uF
	P6KE10A
		+5V
+
C925		C927
470uF/16V		0.1uF

R923	ZD902	ZD903
3.6K 1/10W HZ16B		HZ6.2

R925

1K 0805

									CON102
								CONN 33L8009-12L-H
				DIM			2					1					ON/OFF
+5V							4					3
						6						5
							8					7
								10				9
	+12V							12				11

CN901

AOC (Top Victory) Electronics Co., Ltd.

Title

1.POWER OUTPUT 12V & 5 V

Size	Document Number	Rev
B	PWPC1742QDH1	A

Date:

Monday, January 05, 2004

Sheet

2

of

1

C215

C228

L201

R224

R225

39pF/3KV

39pF/3KV

CN201

AC

Q203 SI4431 OR AO4411

120UH

1.5K 1/8W

1.5K 1/8W

1

-2D-

+12V

1

8

2

7

33L8021

+

R212

D201

R226

1.5K 1/8W

PT201

2

4

5

3

6

R227

C201

C202

2

C225

R214

3.9K 1/10W

SR24

ZD203

1.5K 1/8W

1

EEL-19

C216

C229

220uF/25V

104

RLZ11B

8

CN202

1

Q202

1uF/25V

2.2K 1/10W

2

39pF/3KV

39pF/3KV

AC

DTA144WKA

1

3

2D-

R242

PROTECT

3

R243

R220

6.8K 1/10W

3

1K 1/10W

1

2

R216

15K 1/10W

3

.

-33L8021

Q205

C213

L203

ON/OFF

1

Q201

PMBS3904

24 1/10W

C211

9

A

1

4

2

DTC144WKA

NC

10

4

2

2

0.18uF/250V2

.3

R201

R202

Q209

5

NC

NC

R218

2SD5706(DIP&SMD)

1

6

2

B

DIM

2

R222

1

24 1/10W

12K 1/10W

73L174-30-YS

1

Q207

7

11

R208

R210

Q210

C203

PMBS3906

3

3

2SD5706(DIP&SMD)

0 1/10W

15K 1/10W

NC

3

R232

D209

910 1/10W

1N4148

D205

R205

1N4148

47K 1/10W

C209

R240

D207

R234

104uF/25V

51K 1/10W

1N4148

910 1/10W

C205

BU_L

0.1uF

C221

R238

C219

R236

0.022uF/25V

12K 1/10W

0.2uF/25V

510 1/10W

+

C207

R207

16

15

14

13

12

11

10

9

+

C223

4.7uF

NC

REF

SCP

2IN+

2IN-

2FBK

2DTC

2OUT

Vcc

C204

150uF/25V

C217

C226

CN203

1uF

Q204 SI4431 OR AO4411

120UH

1.5K

1/8W

R229

R230

R231

39pF/3KV

39pF/3KV

AC

L202

R228

1.5K 1/8W

1.5K 1/8W

1.5K 1/8W

PT202

1

-2D-

CT

RT

1IN+

-1IN

1FBK

1DTC

1OUT

GND

U201

1

8

EEL-19

1

2

3

4

5

6

7

8

TL1451ACNSR

2

7

1

8

33L8021

3

6

2

C206

R213

4

5

D202

2

0.1uF

C224

R215

3.9K 1/10W

SR24

ZD204

C218

C227

RLZ11B

CN204

R206

1uF/25V

2.2K 1/10W

3

9

39pF/3KV

39pF/3KV

AC

1

47K 1/10W

3

10

-2D-

R244

R221

4

L204

1K 1/10W

1

Q206

R217

C212

15K 1/10W

C214

5

C

1

4

33L8021

C210

2

24 1/10W

NC

0.18uF/250V

.

PMBS3904

2

104uF/25V

6

.3

C208

R204

2

2

7

11

2

D

330pF

10K 1/10W

R209

R233

R203

0 1/10W

R219

2

R223

1

1

911 1/10W

73L174-30-YS

24 1/10W

12K 1/10W

NC

1

Q208

Q211

PMBS3906

2SD5706(DIP&SMD)

Q212

3

3

3

2SD5706(DIP&SMD)

D210

D206

1N4148

1N4148

is power GND

R211

BU_R

15K 1/10W

is signal GND

51K 1/10W

1N4148

910 1/10W

R241

D208

R235

AOC (Top Victory) Electronics Co., Ltd.

Title	PWPC1742QDH1
Size	Document Number			Rev
B	Monday, January 05, 2004			2
Date:		Sheet	2 of 2

C222	R239	C220	R237
0.022uF/25V	12K 1/10W	0.2uF/25V	510 1/10W

Page 30 of 143
