Antari M-1 User Manual

User Manual for the Antari M-1 Mobile Fog Machine

Congratulations on the purchase of your new

ANTARI M-1 Mobile Fog Machine

 Save and read these instructions

 Bitte lesen Sie und sichern Sie diese Anweisungen

 Lisez et Gardez ces instructions

 © 2007 Antari Lighting and Effects Ltd.

M-1 Mobile Fogger

2

INTRODUCTION

Thank you for choosing Antari’s M-1 Mobile Fogger. You now own a sturdy and

portable state-of-the-art fog machine. Prior to use, we suggest that you carefully read

all of the instructions. By following the suggestions found in this user manual, you can

look forward to exceptional performance from your Antari Mobile Fog Machine for

years to come.

Please follow these operations, safety and maintenance instructions to ensure a long

and safe life for your fog machine.

Specifications

 Output: 300 cu.ft. / min
 Power Consumption: 75 W
 Tank Capacity: 110 cc
 Battery: DC 12V / 2.3 Ah
 Consumption: 2 cc / min
 Liquid Used: Antari FLM-05 (Fog liquid for M1) Only
 Optional Remotes: MCT-1 (Timer Remote)

MCR-1 (Wireless Remote)

 Weight: 1.8 Kg (M-1 only) 12Kg (with Flightcase)
 Dimensions (mm): L 227 W 66 H 81
 Continuous Output Duration: 10-12 minutes (battery)

Unlimited (power adaptor)

CAUTION!

Pay attention to all warning labels and instructions printed on the exterior of your

Antari M-1 Fog Machine

Danger of Electric Shock

 Keep this device dry.
 Always remove the battery or unplug the power adaptor to your Antari M-1 Fog

Machine before filling the liquid tank.

 Keep fog machine upright.
 Remove the battery or unplug the power adaptor when not in use.
 This machine is not waterproof or splash proof. If moisture, water, or fog liquid

gets inside the housing, immediately remove power and contact a service

technician or your Antari dealer before using it again.

3

 No user serviceable parts inside. Refer to your Antari dealer or other qualified

service personnel.

Danger of Burns
 For adult use only. Fog machine must be installed out of the reach of children.

Never leave the unit running unattended.

 Keep nozzle at least 50 cm (20 in.) away from contact with anything while in

operation.

 The fog vapor at point of release is under pressure and is extremely hot.
 Never aim the output nozzle directly at people.
 Fog machine output is hot. Avoid coming within 50 cm of the output nozzle during

operation.

 Place the fog machine in a well-ventilated area. Never cover the vents on the front

of the M-1. Never aim the output nozzle at open flames.

 The output nozzle becomes hot during operation. Keep flammable materials at

least 50 cm away from the nozzle.

 Always allow your Antari Fog Machine to cool down before attempting to clean or

service it.

Danger of Explosion
 Do not expose the battery to excessive heat, keep away from open flames and do

not attempt to remove the case.

 Never add flammable liquids of any kind (oil, gas, perfume) to the fog liquid.
 Use only the high quality, water/glycol based fog liquid that your Antari dealer

recommends. (For M-1 only FLM-05) Other fog liquids may generate a poor fog

effect, clog the internal components or “spit” fog liquid.

 Always make sure there is sufficient liquid in the fog liquid tank. The fluid level can

be monitored via the window at the back of the machine.

 Operating this unit without liquid will cause damage to the pump and the heater.
 If your Antari M-1 MobileFog Machine fails to work properly, discontinue use

immediately. Drain all fog liquid from the tank, pack the unit securely (preferably in

the original packing material), and return it to your Antari dealer for service.

 Always drain fog liquid from the tank before shipping or transporting this unit.
 Never drink fog liquid. If it is ingested, call a doctor immediately. If fog liquid comes

in contact with skin or eyes, rinse thoroughly with water.
