Analog Way ORC-50 Data Sheet

Orchestra

Ref. ORC50

- Ergonomic and Reliable Remote Controller for Rental & Staging / Multi-
venues at an optimal price/performance ratio

- Controls simultaneously up to 6 screens in a single or multiple display
configuration

- Can Store up to 64 presets per screen selection

- For the Control of the Di-VentiX II and the new OPS300, OPS200, Pulse,
Pulse LE, SmartVu and SmartVu LE Mixer Seamless Switchers

- Joystick with Direct Effect Access

Large 7” TFT Color Touch Panel

USB Port

Preset Memories

Screen Selection

Source Selection

(Main)

Context Sensitive Keys

Joystick

Effect Settings

Source Selection

(Preview)

Easy access to preset edition

Large Take

Button

T-Bar with a Convenient

and Large Handle

www.analogway.com

Event Controllers

Technical Specifications

User Controls:

• TFT touch screen, 7» (18 cm)

• Buttons for direct access to inputs

• Buttons for direct access to effects

• User preset buttons

• Take, Freeze, Main and Preview selection

• T-Bar for smooth manually controlled transitions

• Joystick for easy and fast set up of image or effect parameters

Input/Output Connectors:

• RJ45 for TCP/IP Ethernet connection

• USB port

• RS232 Com Port

• Auxiliary VGA

Power Supply:
Internal, universal, automatic 100-250 VAC; 50/60 Hz (130W)
(UL, CSA, GS, CE) On/Off power switch

Supplied with:
1 x Power supply cord
1 x Quick Start guide
1 x User manual
1 x Rack mount ruler and screws
2 x Adjustable feet

Dimensions:

• Compatible 19», 6U

• P 10.5» x L 17.5» x H 4.35»

• P 440 mm x L 450 mm x H 180 mm

Weight: 9 kg (20 lbs)

Warranty:
3 year warranty on parts and labor back to factory

Specifications subject to change without prior notice

ORCHESTRA by Analog Way is a Powerful

intuitive and ergonomic Remote Controller

designed to manage independently or
simultaneously, several Switchers such as

Di-VentiX II as well as the new OPS300,
OPS200, Pulse, Pulse LE, SmartVu and
SmartVu LE system, either as stand-alone

boxes or as any kind of combination, inclu­ding soft-edge blending.

ORCHESTRA offers the control of matrixes

in order to multiply the number of sources,
whatever input number the Analog Way
Switcher provide. Once connected to the

Analog Way Switchers, ORCHESTRA can

control up to 6 independent screen configu­rations in different locations (single display
or multiple projectors in soft-edge blended
mode) and store up to 64 presets per
screen configuration. ORCHESTRA controls
all the effects and functionalities of the

Di-VentiX II and the new OPS300, OPS200,
Pulse, Pulse LE, SmartVu and SmartVu LE
Systems:

- Control of soft-edge blending presentations,
on up to 6 different screens, horizontally or
vertically

- Size, shape, and position of the PIP

- Transition effects

- Configuration of each input/output of the
controlled Switchers

Designed with a 16/9 TFT color touch screen
for preview of all configurations, ORCHESTRA
is especially dedicated to facilitate the setting
and programming of multi-screen events
and presentations. It perfectly fits your every
day or prestigious performances where quic­kness and easiness of configuration is requi­red.

The numerous user friendly, customizable and
configurable presets enable the set up of the
screen configuration, so that they are easily
accessible during the presentation. A last
minute modification is easy thanks to the
direct input/output selection access.

Also equipped with a USB port, the complete
configuration of the event can be saved for
future use.

Thanks to its new ergonomy, ORCHESTRA
will help manage multi-screen and multi­location live presentations with a total peace
of mind, at the most interesting price/perfor­mance ratio.
