AL802ULADA
NAC Power Extender
Installation Guide
(See Application Guide for additional information)
Altronix Corp.
Rev. 042010
AL802ULADA - NAC Power Extender
Overview:
The Altronix AL802ULADA is an extremely cost effective 8 amp remote power supply/battery charger. It may be connected to any 12 or 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC such as strobes and horns) expansion support to meet ADA requirements. It also provides auxiliary power to support system accessories. The unit delivers electronically regulated and filtered 24 volt power to Class B, Style W, X, Y or Class A, Style Z NAC loop circuits. Additionally, a separate 1.0A auxiliary output for four (4)-wire smoke detectors is available. The 8 amp max. alarm current can be divided between the four (4) outputs for powering NAC devices. Each output is rated at 2.5 amp max., and can be independently programmed for Steady, Temporal Code 3 or Strobe Synchronization. All outputs may be programmed for Input to Output Follower Mode (output will follow input). An individual output of 4 amp is achieved by paralleling 2 outputs. In non-alarm condition independent loop supervision for Class A, Style Z and/or Class B, Style W, X, Y FACP NAC circuits is provided. In the event of a loop trouble, the FACP will be notified via the steered input (input 1 or input 2). In addition, there are common trouble output terminals (NC, C, NO) which are used to indicate general loop/system trouble. A common trouble input is provided for optional NC (normally closed) devices to report trouble to the FACP. Two
(2) FACP signaling outputs can be employed and directed to control supervision and power delivery to any combination of the four (4) outputs.
Specifications:
Agency Listings:
•UL Listed Control Units for Fire Protective Signaling Systems (UL 864).
•MEA - NYC Department of Buildings Approved.
•CSFM - California State Fire Marshal Approved.
•FM - Factory Mutual Approved.
•NFPA 72 Compliant.
Input:
•Power input 120VAC 60 Hz, 5 amp.
•Two (2) Class A, Style Z or two (2) Class B, Style W, X, Y FACP inputs.
•Two (2) NC dry contact trigger inputs.
Output:
•Class 2 Rated power limited outputs.
•24VDC @ 8 amp max total alarm current.
•2.5 amp max current per output.
•Separate 1.0 amp auxiliary output.
•Two (2) outputs may be paralleled for more power on an indicating circuit (see Application Guide).
•Programmable supervised indicating circuit outputs: Four (4) Class B, Style W, X, Y or Two (2) Class A, Style Z or One (1) Class A, Style Z and Two (2)
Class B, Style W, X, Y (see Application Guide).
•Thermal and short circuit protection with auto reset.
Battery Backup:
•Built-in charger for sealed lead acid or gel type batteries.
•Automatic switchover to stand-by battery when AC Fails.
•Zero voltage drop when switching over to battery backup.
Supervision:
•AC fail supervision (form “C” contact, 1 amp / 28VDC). Factory set for 30 seconds with optional 2.5 to 3 hour delay setting (field selectable).
•Instant local AC trouble reporting relay (form “C” contact, 1 amp / 28VDC).
•Battery presence and low battery supervision (form “C” contact, 1 amp / 28VDC).
Visual Indicators:
•Input and output status LED indicators.
Special Features:
•2-wire horn/strobe Sync mode allows audible notification appliances (horns) to be silenced while visual notification appliances (strobes) continue to operate.
•Sync protocols include Potter/Amseco, Faraday, Gentex®, System Sensor®, and CooperWheelock®.
•Temporal Code 3, Steady Mode, Input to Output Follower Mode (maintains synchronization of notification appliances circuit).
•Compatible with 12VDC or 24VDC fire panels.
•Output loop supervision steered to input 1 or input 2.
•Signal circuit trouble memory (helps identify intermittent loop problems).
•Common trouble input and output.
•Ground fault detection.
•Unit includes power supply, red enclosure, cam lock, and battery leads.
Enclosure Dimensions (approx. H x W x D):
15.5” x 12” x 4.5” (393.7mm x 304.8mm x 114.3mm).
- 2 - |
AL802ULADA |
|
Power Supply Specifications: |
|
|
AC Input: |
120VAC 60Hz, 5 amp, supplied by a maximum 15 amp dedicated branch circuit. |
|
|
Output: |
Four (4) regulated supervised NAC output circuits, 24VDC, 2.5 amp maximum current. |
|
One (1) aux. special application 24VDC power output circuit 1 amp, non-supervised |
|
total output current must not exceed current 8 amp in Alarm Condition. |
|
|
Battery: |
Use two (2) 12VDC / 12AH or two (2) 12VDC / 7AH batteries connected in series. |
|
|
Stand-by/Alarm Current |
90mA/175mA |
Consumption: |
|
|
|
EOL Resistor |
2.2K (2200 ohm), Altronix Model # AL-EOL22 (included). |
(end of line): |
|
|
|
Ground fault maximum |
1000 ohm. |
test impedance: |
|
|
|
Stand-by Specifications:
Stand-by Batteries |
Stand-by Time Total Amp/Minutes |
Alarm Output Current |
Aux. Output |
|
|
|
|
|
|
24VDC/7AH |
24 Hours |
8 amp/5 minutes |
--- |
|
|
|
|
|
|
24VDC/12AH |
24 Hours |
8 amp/5 minutes |
50mA |
|
(use two (2) 12VDC batteries in series) |
||||
|
|
|
||
|
|
|
|
|
24VDC/36AH |
24 Hours |
8 amp/5 minutes |
1 amp |
|
|
|
|
|
Note: Unit is equipped with 1 amp max. auxiliary output: “AUX” will remain battery backed up during power outage. For loads connected to “AUX” please refer to battery “Stand-by Specifications” above for ratings. When loads are connected to “AUX” output during alarm condition, the remaining outputs may, not exceed 8 amp total alarm current (example: AUX = 1 amp, outputs up to 7 amp).
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with all local codes and authorities having jurisdiction.
Product is intended for indoor use only. |
|
ground |
||||||
Carefully review: |
|
|
|
|
|
|
|
|
Application Guide for AL602ULADA, AL802ULADA, AL1002ULADA |
|
|
|
|
|
|
||
Power Supply Specifications |
(pg. 3) |
|
|
|
|
|
|
|
Stand-by Specifications |
(pg. 3) |
|
|
L |
|
N |
|
|
|
|
|
|
|||||
line |
||||||||
Output Programming Selection Table |
(pg. 4) |
|||||||
|
|
neutral |
||||||
Sync Mode Selection Table |
(pg. 4) |
|
|
|
|
|
|
|
Terminal Identification Table |
(pgs. 5-6) |
|
|
|
Fig. 1 |
|||
LED Status Indication Table |
(pg. 6) |
|
|
|
||||
|
|
|
|
|
|
|||
1.Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the enclosure. Drill the lower holes and install two fasteners. Place the enclosure’s upper keyholes over the two upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 12).
Secure enclosure to earth ground (Fig. 1, pg. 3).
2.Connect the line (L) and neutral (N) terminals to a separate unswitched AC circuit (120VAC, 60Hz) dedicated to the Fire Alarm System.
3.Measure output voltage before connecting devices.This helps avoiding potential damage.
4.Connect battery to the terminals marked [+ BAT --] on the Power Supply Board (battery leads included). Use two (2) 12VDC batteries connected in series.
5.Set output selection switches marked [OUT1 through OUT4] to follow corresponding input [IN1 & IN2] and desired output signal type (Output Programming Selection Table, pg. 4).
6.Connect FACP output to the desired AL800LGK9E logic board inputs, and notification appliances to the desired AL800LGK9E logic board outputs (see Application Guide).
Note: The 2-wire horn/strobe sync mode will only synchronize horns, horn/strobes, strobes with synchronization capability.
7.For connection of smoke detectors, digital dialer see Optional Hookup Diagram, pg. 7.
AL802ULADA |
- 3 - |
Class A, Style Z Class B, Style W, X, Y, SW1 & SW2 Settings:
•For all Class B, Style W, X, Y, hookups SW1 & SW2 on the AL800LGK logic board must be open. For all Class A, Style Z hookups SW1 & SW2 on the AL800LGK logic board must be closed.
Output Programming Selection Table:
Outputs must be programmed independently (OUT1 - OUT4)
Function |
|
|
Switch Positions |
Descriptions |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ON |
|
OFF |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input to Output Follower |
1 |
2, 3 |
Output follows signal it receives from the corresponding input (i.e. |
|||||||
Mode |
|
|
|
|
|
FACP Sync module - maintains synchronization of |
||||
|
|
|
|
|
|
notification appliance circuit). |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Temporal Code 3 Mode |
3 |
1, 2 |
Enables Temporal Code 3 signal generation output. |
|||||||
|
|
|
|
|
|
This mode will accept a steady or a pulsing input. |
||||
|
|
|
|
|
|
|
|
|
|
|
Steady Mode |
|
|
|
1, 2, 3 |
A steady output signal will be generated. |
|
|
|
|
|
|
|
|
|
|
|
This mode will accept steady or pulsing input. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
For the above modes Dip Switch 4 determines which Input controls |
(AL800LGK9E Board) |
|||||||||
the corresponding output: |
|
|
|
|
|
|
Output Dip Switches |
|||
Switch 4 in the ON position causes output(s) to be controlled by input 1. |
|
|
|
INPUT SELECT |
||||||
|
|
|
||||||||
Switch 4 in the OFF position causes output(s) to be controlled by input 2. |
|
|
|
|||||||
|
|
|
TEMPORAL |
|||||||
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
STROBE SYNC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Sync Mode Selection Table: |
|
|
|
IN>OUT SYNC |
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
Function |
Switch Positions |
|
Descriptions |
|
|
|
|
|||
ON |
|
OFF |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
This mode is designed to work with the Amseco series of horns, strobes, and |
|||||
Amseco Sync |
1, 3, |
|
2 |
|
horn/strobes to provide a means of synchronizing the Temporal-coded horns, |
|||||
Mode* |
4 |
|
|
synchronizing the flash timing of the strobe, and silencing the horns of the horn/ |
||||||
|
|
|
||||||||
|
|
|
|
|
strobe combination over a two-wire circuit while leaving strobes active. |
|||||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
This mode is designed to work with the Faraday series of horns, strobes, and horn/ |
|||||
Faraday |
2, 4 |
|
1, 3 |
|
strobes to provide a means of synchronizing the Temporal-coded horns, synchro- |
|||||
Sync Mode* |
|
|
nizing the flash timing of the strobe, and silencing the horns of the horn/strobe |
|||||||
|
|
|
|
|||||||
|
|
|
|
|
combination over a two-wire circuit while leaving strobes active. |
|||||
|
|
|
|
|
|
|
|
|
||
Gentex® |
|
|
|
|
This mode is designed to work with the Gentex® series of horns, strobes, and horn/ |
|||||
1, 2, |
|
|
|
strobes to provide a means of synchronizing the Temporal-coded horns, synchro- |
||||||
Sync Mode* |
|
|
|
|||||||
3, 4 |
|
|
|
nizing the flash timing of the strobe, and silencing the horns of the horn/strobe |
||||||
Gentex is a registered trademark |
|
|
|
|||||||
of Gentex Corporation. |
|
|
|
|
combination over a two-wire circuit while leaving strobes active. |
|||||
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
||
System Sensor® |
|
|
|
|
This mode is designed to work with the System Sensor® series of horns, strobes, |
|||||
|
|
|
|
and horn/strobes to provide a means of synchronizing the Temporal-coded horns, |
||||||
Sync Mode* |
1, 2, 4 |
|
3 |
|
||||||
|
|
synchronizing the one-second flash timing of the strobe, and silencing the horns of |
||||||||
System Sensor is a registered |
|
|
|
|
||||||
trademark of Honeywell. |
|
|
|
|
the horn/strobe combination over a two-wire circuit while leaving strobes active. |
|||||
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
||
CooperWheelock® |
|
|
|
|
This mode is designed to work with the CooperWheelock series of horns, strobes, |
|||||
Sync Mode* |
2, 3, 4 |
|
1 |
|
and horn/strobes to provide a means of synchronizing the Temporal-coded horns, |
|||||
CooperWheelock is a |
|
|
synchronizing the one-second flash timing of the strobe, and silencing the horns of |
|||||||
registered trademark of |
|
|
|
|
the horn/strobe combination over a two-wire circuit while leaving strobes active. |
|||||
Cooper Wheelock. |
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
*Note: The AL802ULADA will only synchronize horns, horn/strobes and strobes that contain synchronization capability. Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs
Note: It is required to control visual notification appliances (strobes) via input 1 (IN1) and audible notification appliances (horns) via input 2 (IN2). This allows audible notification appliances (horns) to be silenced while visual notification appliances (strobes) continue to operate.
- 4 - |
AL802ULADA |
