Alpine TDM-7585R, CDM-7870R User Manual

CDM-7870R

FM/MW/LW/RDS CD Receiver

TDM-7585R

FM/MW/LW/RDS Cassette Receiver

• OWNER'S MANUAL Please read before using this equipment.

• BEDIENUNGSANLEITUNG Lesen Sie diese Bedienungsanleitung bitte vor Gebrauch des Gerätes.

• MODE D'EMPLOI

• MANUAL DE OPERACIÓN

• ISTRUZIONI PER L’USO

• ANVÄNDARHANDLEDNING

ALPINE ELECTRONICS, INC.

Tokyo office: 1-1-8 Nishi Gotanda,

Shinagawa-ku,

Tokyo 141-8501, Japan

Tel.: (03) 3494-1101

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Tel.: 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF CANADA, INC.

Suite 203, 7300 Warden Ave. Markham,

Ontario L3R 9Z6, Canada

Tel.: 1-800-ALPINE-1 (1-800-257-4631)

Veuillez lire avant d’utiliser cet appareil.

Léalo antes de utilizar este equipo.

Si prega di leggere prima di utilizzare il attrezzatura.

Innan du använder utrustningen bör du läsa igenom denna användarhandledning.

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

6-8 Fiveways Boulevarde Keysborough,

Victoria 3173, Australia

Tel.: (03) 9769-0000

ALPINE ELECTRONICS GmbH

Kreuzerkamp 7-11 40878 Ratingen, Germany

Via C. Colombo 8, 20090 Trezzano Sul Naviglio

Tel.: 02102-45 50

ALPINE ITALIA S.p.A.

MI, Italy

Tel.: 02-48 47 81

ALPINE ELECTRONICS FRANCE S.A.R.L.

(RCS PONTOISE B 338 101 280)

98, Rue De La Belle Etoile, Z.I. Paris Nord Il

B.P. 50016 F-95945, Roissy, Charles De Gaulle

13 Tanners Drive, Blakelands, Milton Keynes

ALPINE ELECTRONICS DE ESPAÑA, S.A.

01013 Vitoria (Alava)-Apdo. 133, Spain

Cedex, France

Tel.: 01-48 63 89 89

ALPINE ELECTRONICS OF U.K., LTD.

MK14 5BU, U.K.

Tel.: 01908-61 15 56

Portal De Gamarra 36, Pabellón 32

Tel.: 34-45-283588

Meiyi Printing Factory, Dalian, China No. 28 Chang Qing Street, Xi Gang District, Dalian, China

Printed in China (Y)

68P01434K48-O

CD changer for CDM-7870R/TDM-7585R CD-Wechsler für CDM-7870R/TDM-7585R Changeur CD pour CDM-7870R/

TDM-7585R

Cambiador de CD para CDM-7870R/

TDM-7585R Cambia CD per CDM-7870R/TDM-7585R CD-växlare för CDM-7870R/TDM-7585R

CHA-S624

CHA-1214

CHM-S620

Alpine CD Changers Give You More!

More musical selections, more versatility , more convenience.

An Alpine CD Changer adds more musical choices to your sound system. All models can be controlled from Alpine head units and deliver excellent sound quality. The CHA-S624 is a high-performance 6-disc changer with a new M DAC, Ai-NET compatibility, Optical Digital Output, 150 Disc Title Memory and CD TEXT. The CHA-1214 Ai-NET model holds 12 discs, and the CHM-S620 M-Bus model is a super-compact 6-disc changer.

Von Alpine CD-Wechslern haben Sie mehr!

Mehr Musikauswahl, mehr Vielseitigkeit, mehr Komfort.

Mit einem Alpine CD-Wechsler erweitern Sie die Musikauswahl Ihres Systems. Sämtliche Modelle lassen sich von einer AlpineBedieneinheit aus steuern und liefern hervorragende Klangqualität. Der CHA-S624 ist ein Ai-NET-kompatibler Hochleistungs-Wechsler für 6 CDs mit dem neuen M-DAC, Digitalausgang für Glasfaserkabel, CD-Titelspeicher für 150 Titel und CD-TEXT. Das Ai-NETModell CHA-1214 nimmt 12 CDs auf, und der M-Bus-kompatible CHM-S620 ist ein superkompakter Wechsler für 6 CDs.

Changeurs de CD Alpine : vous avez le choix!

Plus de sélections musicales, plus de souplesse, plus de confort.

Un changeur de CD Alpine permet d'augmenter la plage des sélections musicales de votre système embarqué. Tous les modèles peuvent être contrôlés à partir des autoradios Alpine et offrent une excellente qualité audio. Le modèle CHA-S624 est un changeur 6 disques ultra performant compatible Ai-NET et équipé d'un convertisseur N/A standard, d'une sortie optique numérique, d'une mémoire d'une capacité de 150 titres et de la fonction CD TEXT. Le modèle CHA-1214 Ai-NET peut contenir 12 disques. Le modèle CHM-S620 MBus est un changeur 6 disques super compact.

¡Los cambiadores Alpine de CD le ofrecen más!

Más selecciones musicales, más versatilidad y más ventajas.

Un cambiador Alpine de CD añade más opciones musicales a su equipo de sonido. Todos los modelos pueden controlarse desde las unidades principales de Alpine y proporcionar un sonido de calidad excepcional. El modelo CHA-S624 es un cambiador de 6 discos de alto rendimiento con el nuevo DAC "M" y compatibilidad con Ai-NET, salida digital óptica, memoria de títulos de 150 discos y TEXTO CD. El modelo CHA-1214 Ai-NET admite 12 discos y el modelo CHM-S620 Bus-M es un cambiador de 6 discos y tamaño reducido.

I caricatori CD Alpine danno di più!

Più scelta, più versatilità, più comodità.

Un caricatore CD Alpine offre maggiore scelta. Tutti i modelli possono essere controllati tramite le unità di controllo Alpine e producono un suono di qualità eccellente. CHA-S624 è un caricatore a 6 dischi Ai NET compatibile e dotato di un nuovo M DAC, di un'uscita ottica digitale, memorizzazione dei titoli di 150 dischi e CD TEXT. Il modello CHA-1214 Ai NET può contenere un massimo di 12 dischi, mentre il modello CHM-S620 M-Bus è un caricatore a 6 dischi ultra compatto.

Alpines CD-växlare ger mer!

Fler musikval, mer variation, större bekvämlighet.

Med Alpines CD-växlare i systemet får du större musikalisk valfrihet. Alla modeller kan styras från Alpines huvudenheter och ger enastående ljudkvalitet. CHA-S624 är en högpresterande växlare för 6 skivor med en ny M D/A-omvandlare, kompatibel med Ai-NET, optisk digitalutgång, titelminne för 150 skivor och CD-TEXT. Modellen CHA-1214 Ai-NET rymmer 12 skivor och modellen CHMS620 M-Bus är en superkompakt växlare för 6 skivor.

Contents

ENGLISH

Operating Instructions

WARNING

WARNING..................................................2

CAUTION...................................................2

PRECAUTIONS ......................................... 2

Basic Operation

Detaching the Front Panel................................. 5

Attaching the Front Panel ................................. 5

Initial System Start-Up ..................................... 5

Turning Power On and Off ............................... 6

Display Angle Adjustment ................................ 6

Subwoofer On and Off...................................... 6

Adjusting Source Signal Levels........................ 7

Adjusting Volume/Balance (Between Left and

Right)/Fader (Between Front and Rear) ........ 7

BBE Mode On/Off (CDM-7870R only) ........... 7

Selecting BBE Mode (TDM-7585R only)........ 7

Setting the BASS Control ................................. 8

Setting the Treble Control................................. 8

Changing Audio Level Display Pattern ............ 9

Setting the AUX Mode...................................... 9

Radio Operation

Manual Tuning................................................ 10

Setting Frequency Step ................................... 10

Automatic Seek Tuning .................................. 10

Manual Storing of Station Presets .................. 11

Automatic Memory of Station Presets............ 11

Tuning to Preset Stations ................................ 11

RDS Operation

Setting RDS Reception Mode and Receiving

RDS Stations ............................................... 12

Recalling Preset RDS Stations........................ 13

Receiving RDS Regional (Local) Stations ..... 13

Receiving Traf f ic Information......................... 13

PTY (Programme Type) Tuning ..................... 13

Receiving Traffic Information While Playing

CD/Tape or Radio ........................................ 14

Priority News .................................................. 15

CD Player Operation (CDM-7870R only)

Opening and Closing the Movable display..... 16

Playback.......................................................... 16

Music Sensor (Skip)........................................ 16

Fast Forward and Backward ........................... 17

Repeat Play ..................................................... 17

M.I.X. (Random Play) .................................... 17

Scanning Programmes .................................... 17

Displaying and Scrolling CD Text .................. 17

Cassette Player Operation (TDM-7585R only)

Opening and Closing the Movable display..... 18

Normal Play and Pause ................................... 18

Dolby B NR (Noise Reduction)...................... 19

Repeat Play ..................................................... 19

Blank Skip (B.SKIP)....................................... 19

Fast Forward and Rewind ............................... 19

Scanning Programmes .................................... 19

Manual Reverse .............................................. 19

Programme Sensor (P.S.) ................................ 19

* Dolby noise reduction manufactured under license from

Dolby Laboratories Licensing Corporation. "DOLBY" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

CD Changer Operation

Controlling CD Changer (Optional) ............... 20

Music Sensor (M.S.) Skip............................... 20

Fast Forward and Backward ........................... 20

Repeat Play on Single Track or Entire Disc ... 21

M.I.X. (Random) Play .................................... 21

Scanning Programmes .................................... 21

Information

In Case of Difficulty ....................................... 22

Specifications.................................................. 23

Installation and Connections

Warning ........................................................... 24

Caution............................................................ 24

Precautions...................................................... 24

Installation ...................................................... 25

Connections .................................................... 26

1-EN

WARNING

CAUTION

WARNING

This symbol means important instructions. Failure to heed them can result in serious injury or death.

DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged attention should only be performed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident.

KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE NOISE WHILE DRIVING.

Failure to do so may result in an accident.

MINIMIZE DISPLAY VIEWING WHILE DRIVING.

Viewing the display may distract the driver from looking ahead of the vehicle and cause an accident.

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire, electric shock or other injury.

USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.

Failure to do so may result in fire or electric shock.

DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

Doing so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

KEEP SMALL OBJECTS SUCH AS BATTERY OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

This symbol means important instructions. Failure to heed them can result in injury or material properly damage.

HALT USE IMMEDIATELY IF A PROBLEM APPEARS.

Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing.

DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION SLOTS OR GAPS.

Doing so may result in personal injury or damage to the product.

DO NOT MIX NEW BATTERIES WITH OLD BATTERIES. INSERT WITH THE CORRECT BATTERY POLARITY.

When inserting the batteries, be sure to observe proper polarity (+ and –) as instructed. Rupture or chemical leakage from the battery may cause fire or personal injury.

PRECAUTIONS

Temperature

Be sure the temperature inside the vehicle is between +60°C (+140°F) and –10°C (+14°F) before turning your unit on.

Maintenance

If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing.

Installation Location

Make sure the CDM-7870R/TDM-7585R will not be installed in a location subjected to:

• Direct sun and heat

• High humidity and water

• Excessive dust

• Excessive vibrations

Handling the Detachable Front Panel

• Do not expose to rain or water.

• Do not drop or apply shock.

2-EN

Moisture Condensation

You may notice the CD playback sound wavering due to condensation. If this happens, remove the disc from the player and wait about an hour for the moisture to evaporate.

Damaged Disc

Do not attempt to play cracked, warped, or damaged discs. Playing a bad disc could severely damage the playback mechanism.

Never Attempt the Following

Do not grip or pull out the disc while it is being pulled back into the player by the automatic reloading mechanism. Do not attempt to insert a disc into the unit when the unit power is off.

Irregular Shaped Discs

Be sure to use round shape discs only for this unit and never use any special shape discs. Use of special shape discs may cause damage to the mechanism.

Correct Handling

Do not drop the disc while handling. Hold the disc by its edge so that no fingerprints are left on the surface. Do not affix tape, paper, or gummed labels to the disc. Do not write on the disc.

CORRECT

INCORRECT CORRECT

Inserting Discs

Your player accepts only one disc at a time for playback. Do not attempt to load more than one disc. Make sure the label side is facing up when you insert the disc. Your player will automatically eject any disc that is inserted incorrectly. If the player continues to eject a correctly inserted disc, push the RESET switch with a pointed object such as a ballpoint pen. Playing a disc while driving on a very bumpy road may result in skips, but this will not scratch the disc or damage the player.

New Discs

As a protective measure to prevent the CD from jamming, the CD player will automatically eject discs with irregular surfaces or inserted incorrectly. When a new disc is inserted into the player and ejected after initial loading, using your finger, feel around the inside of the centre hole and outside edge of the disc. If you feel any small bumps or irregularities, this could inhibit proper loading of the disc. To remove the bumps, rub the inside edge of the hole and outside edge of the disc with a ball-point pen or other such instrument, then insert the disc again.

New Disc

Centre Hole

Disc Cleaning

Fingerprints, dust, or soil on the surface of the disc could cause the CD player to skip. For routine cleaning, wipe the playing surface with a clean, soft cloth from the centre of the disc to the outer edge. If the surface is heavily soiled, dampen a clean, soft cloth in a solution of mild neutral detergent before cleaning the disc.

Disc Accessories

There are various accessories available on the market for protecting the disc surface and improving sound quality. However, most of them will influence the thickness and/or diameter of the disc. Using such accessories can cause the disc to be out of standard specifications and may create operational problems. We recommend not using these accessories on discs played in Alpine CD players.

Bumps

Outside (Bumps)

Transparent Sheet Disc Stabilizer

3-EN

Tape Slack

Check and make sure any slack in the tape is taken up before inserting the tape into the unit. A loose tape can get caught in the mechanism and cause damage to the unit and the tape itself. Tighten the tape by inserting a pencil or a similar instrument into the spindle hole and turn until all the slack has been taken up.

Excessively Thin Tape

C-120 type cassette tapes are not recommended for use in automobile tape players.

Precision Tape Mechanism

Prevent any foreign objects from entering the cassette opening as the precision mechanism and tape head may be damaged. Never play dirty or dusty tapes – they can damage the tape head.

Tape Head Cleaning

Periodic cleaning (approximately every 20 hours of use) of the tape head with a wet type head-cleaning cassette tape (available at audio stores) is necessary for best performance.

Fuse Replacement

When replacing the fuse(s), the replacement must be of the same amperage as shown on the fuse holder. If the fuse blows more than once, carefully check all electrical connections for shorted circuitry. Also have your vehicle's voltage regulator checked.

4-EN

POWER RESET

Basic Operation

Detaching the Front Panel

1 Press the POWER button for more than 3

seconds to turn off the power.

2 Press the (Release) button at upper left side

until the front panel pops out.

3 Grasp the left side of the front panel and pull it

out.

• Controlable with Remote Control

This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control sensor.

Remote control sensor

Basic

NOTES

• The front panel may become hot in normal usage

(especially the connector terminals), this is not malfunction.

• To protect the front panel, place it in the supplied

carrying case.

Attaching the Front Panel

1 First, insert the right side of the front panel into

the main unit. Align the groove on the front panel with the projections on the main unit.

2 Push the left side of the front panel until it locks

firmly into the main unit.

NOTE

Before attaching the front panel, make sure that there is no dirt or dust on the connector terminals and no foreign object between the front panel and the main unit.

•

Connectable to Remote Control Interface Box

You can operate this unit from the vehicle's control unit when an Alpine Remote Control Interface Box (optional) is connected. For details, contact your Alpine dealer.

Initial System Start-Up

Immediately after installing or applying power to the unit, it should be initialized. Press the RESET switch with a ballpoint pen or any other pointed object.

5-EN

Basic

POWER

g DN f UP

BAND

MODE / BBE

SETUP

Basic Operation

Turning Power On and Off

1 Press the POWER button to turn on the unit.

NOTE

The unit can be turned on by pressing any other button except the c button.

The volume level gradually increases to the previous level you were listening to before the unit was turned off. Press the POWER button for more than 3 seconds to turn off the unit.

NOTE

The very first time the power is turned on, the volume will start from level 12, the BBE will be on in the tuner mode.

Display Angle Adjustment

Movable display

ANGLE

Subwoofer On and Off

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the g DN or f UP button to select

the SUB mode.

→ FM LV ←→ REG ←→ SUB ←

→ AUX ←→ 100kHz/50kHz ←

3 Press the BAND button to select SUB-W ON or

SUBW OFF .

4 After setting is completed, press the SETUP

button to return to normal mode.

NOTES

• Initial mode is "SUB-W ON."

• Set to "SUBW OFF" unless the subwoofer is used.

• When the subwoofer is turned on, the subwoofer

output level can be adjusted. For more details, refer to the Adjusting Volume/Balance/Fader section on page 7.

The movable display may be adjusted to 3 different angles depending upon user preference.

1 Press the ANGLE button to adjust the angle of

the movable display .

NOTES

• The display will close a half minute after the ignition

key is turned to the OFF position.

• The adjusted angle of the display is stored in memory.

There is no need to re-adjust the angle when the power is turned back on.

CAUTION

Keep hands (or any other object) away from the display while it is opening or closing to avoid damage or injury. The back of the movable display will get very warm under normal operating conditions. This is not a malfunction. Do not touch.

6-EN

Basic

Adjusting Source Signal Levels

If the difference in volume level between the CD player and FM radio is too great, adjust the FM signal level as follows.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the g DN or f UP button to select

the FM signal level mode.

→ FM LV ←→ REG ←→ SUB ←

→ AUX ←→ 100kHz/50kHz ←

3 Press the BAND button to select the FM signal

level HI (High) or LO (Low) to make the signal levels between the FM band and CD player and cassette player closer.

4 After setting is completed, press the SETUP

button to return to normal mode.

Adjusting V olume/Balance (Between Left and Right)/Fader (Between Front and Rear)

1 Press the MODE button repeatedly to choose

the desired mode. Each press changes the modes as follows:

→ VOL → BAL → FAD

NOTES

• If the 5 or 6 button is not pressed in 5 seconds after

selecting the BAL, or FAD mode, the unit automatically sets in the VOL mode.

• When the subwoofer, BBE mode is set to ON, the

level of the subwoofer, BBE can be adjusted.

2 Press the

obtained in each mode.

5 or

6 button until the desired sound is

BBE Mode On/Off (CDM-7870R only)

The BBE (Barcus Berry Electronics) processor installed in this unit is designed to correct the phase distortion inherent in most loudspeaker designs. Ensuring the phase integrity of the signal driving the speakers improves the accurate reproduction of the sound.

1 Press and hold the BBE button for at least 2

seconds to turn on the BBE mode. Each press toggles between the BBE on and off modes.

Selecting BBE Mode (TDM-7585R only)

1 Press and hold the BBE button for at least 2

seconds to turn BBE on. Each press toggles between the BBE on and off modes.

2 In BBE mode, press the BBE button to switch to

the BBE adjusting mode.

NOTE

In BBE adjusting mode, wait 5 seconds without pressing any button. The BBE adjusting mode is turned OFF.

3 To change to a desired BBE level, press the

6 buttons.

The BBE level can be changed from +1 to +3.

5 or

7-EN

+ 21 hidden pages
