Alpine CDA-7876RB, TDA-7587R, TDA-7588RB Owner Manual

Download

CDA-7876RB CDA-7873R

FM/MW/LW/RDS CD Receiver

TDA-7588RB TDA-7587R

FM/MW/LW/RDS Cassette Receiver

• OWNER'S MANUAL Please read before using this equipment.

• BEDIENUNGSANLEITUNG Lesen Sie diese Bedienungsanleitung bitte vor Gebrauch des Gerätes.

• MODE D'EMPLOI Veuillez lire avant d’utiliser cet appareil.

• MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo.

• ISTRUZIONI PER L’USO Si prega di leggere prima di utilizzare il attrezzatura.

• ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning.

ALPINE ELECTRONICS, INC.

Tokyo office: 1-1-8 Nishi Gotanda,

Shinagawa-ku,

Tokyo 141-8501, Japan

Tel.: (03) 3494-1101

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Tel.: 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF CANADA, INC.

Suite 203, 7300 Warden Ave. Markham,

Ontario L3R 9Z6, Canada

Tel.: 1-800-ALPINE-1 (1-800-257-4631)

Meiyi Printing Factory, Dalian, China No. 28 Chang Qing Street, Xi Gang District, Dalian, China

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

6-8 Fiveways Boulevarde Keysborough,

Victoria 3173, Australia

Tel.: (03) 9769-0000

ALPINE ELECTRONICS GmbH

Kreuzerkamp 7-11 40878 Ratingen, Germany

Via C. Colombo 8, 20090 Trezzano Sul Naviglio

Tel.: 02102-45 50

ALPINE ITALIA S.p.A.

MI, Italy

Tel.: 02-48 47 81

ALPINE ELECTRONICS FRANCE S.A.R.L.

(RCS PONTOISE B 338 101 280)

98, Rue De La Belle Etoile, Z.I. Paris Nord Il

B.P. 50016 F-95945, Roissy, Charles De Gaulle

13 Tanners Drive, Blakelands, Milton Keynes

ALPINE ELECTRONICS DE ESPAÑA, S.A.

01013 Vitoria (Alava)-Apdo. 133, Spain

Cedex, France

Tel.: 01-48 63 89 89

ALPINE ELECTRONICS OF U.K., LTD.

MK14 5BU, U.K.

Tel.: 01908-61 15 56

Portal De Gamarra 36, Pabellón 32

Tel.: 34-45-283588

Printed in China (Y)

68P01434K31-O

CD changer for CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. CD-W echsler für CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. Changeur CD pour CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-

7587R. Cambiador de CD para CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. Cambia CD per CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. CD-växlare för CDA-7876RB/CDA-7873R/TDA-7588R B/TDA-7587R.

CHA-S624

CD changer for CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. CD-Wechsler für CD A-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. Changeur CD pour CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-

7587R. Cambiador de CD para CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. Cambia CD per CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. CD-växlare för CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R.

You cannot connect to CDA-7876RB/CDA-7873R/TD A-7588R B/TD A-7587R. Il est impossible de se raccorder au CDA-7876RB/CDA-7873R/TDA-

7588RB/TDA-7587R. No es posible conectarlo a CDA-7876RB/CD A-7873R/TDA-7588RB/TDA-7587R. Ein Anschluß an CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R

ist nicht möglich. Non è possibile effettuare il collegamento a CDA-7876RB/CDA-7873R/

TDA-7588RB/TDA-7587R. Du kan inte ansluta till CDA-7876RB/CDA-7873R/TD A-7588RB/TD A-7587R.

CHA-1214

CHM-S620

Alpine CD Changers Give You More!

More musical selections, more versatility, more convenience.

An Alpine CD Changer adds more musical choices to your sound system. All models except CHM-S620 can be controlled from Alpine head units and deliver excellent sound quality. The CHA-S624 is a high-performance 6-disc changer with a new M DAC, Ai-NET compatibility, Optical Digital Output, 150 Disc Title Memory and CD TEXT. The CHA-1214 Ai-NET model holds 12 discs, and the CHM-S620 M-Bus model is a super-compact 6-disc changer.

Von Alpine CD-Wechslern haben Sie mehr!

Mehr Musikauswahl, mehr Vielseitigkeit, mehr Komfort.

Mit einem Alpine CD-Wechsler erweitern Sie die Musikauswahl Ihres Systems. Sämtliche Modelle außer dem Modell CHM-M620 lassen sich von einer Alpine-Bedieneinheit aus steuern und liefern hervorragende Klangqualität. Der CHA-S624 ist ein Ai-NETkompatibler Hochleistungs-Wechsler für 6 CDs mit dem neuen M-DAC, Digitalausgang für Glasfaserkabel, CD-Titelspeicher für 150 Titel und CD-TEXT. Das Ai-NET-Modell CHA-1214 nimmt 12 CDs auf, und der M-Bus-kompatible CHM-S620 ist ein superkompakter Wechsler für 6 CDs.

Changeurs de CD Alpine : vous avez le choix!

Plus de sélections musicales, plus de souplesse, plus de confort.

Un changeur de CD Alpine permet d'augmenter la plage des sélections musicales de votre système embarqué. Tous les modèles sauf le modèle CHM-S620 peuvent être contrôlés à partir des autoradios Alpine et offrent une excellente qualité audio. Le modèle CHA-S624 est un changeur 6 disques ultra performant compatible Ai-NET et équipé d'un convertisseur N/A standard, d'une sortie optique numérique, d'une mémoire d'une capacité de 150 titres et de la fonction CD TEXT. Le modèle CHA-1214 Ai-NET peut contenir 12 disques. Le modèle CHM-S620 M-Bus est un changeur 6 disques super compact.

¡Los cambiadores Alpine de CD le ofrecen más!

Más selecciones musicales, más versatilidad y más ventajas.

Un cambiador Alpine de CD añade más opciones musicales a su equipo de sonido. Todos los modelos excepto el modelo CHM-S620 pueden controlarse desde las unidades principales de Alpine y proporcionar un sonido de calidad excepcional. El modelo CHA-S624 es un cambiador de 6 discos de alto rendimiento con el nuevo DAC "M" y compatibilidad con Ai-NET, salida digital óptica, memoria de títulos de 150 discos y TEXTO CD. El modelo CHA-1214 Ai-NET admite 12 discos y el modelo CHM-S620 Bus-M es un cambiador de 6 discos y tamaño reducido.

I caricatori CD Alpine danno di più!

Più scelta, più versatilità, più comodità.

Un caricatore CD Alpine offre maggiore scelta. Tutti i modelli eccètto il modello CHM-S620 possono essere controllati tramite le unità di controllo Alpine e producono un suono di qualità eccellente. CHA-S624 è un caricatore a 6 dischi Ai NET compatibile e dotato di un nuovo M DAC, di un'uscita ottica digitale, memorizzazione dei titoli di 150 dischi e CD TEXT. Il modello CHA-1214 Ai NET può contenere un massimo di 12 dischi, mentre il modello CHM-S620 M-Bus è un caricatore a 6 dischi ultra compatto.

Alpines CD-växlare ger mer!

Fler musikval, mer variation, större bekvämlighet.

Med Alpines CD-växlare i systemet får du större musikalisk valfrihet. Alla modeller utom modell CHM-S620 kan styras från Alpines huvudenheter och ger enastående ljudkvalitet. CHA-S624 är en högpresterande växlare för 6 skivor med en ny M D/A-omvandlare, kompatibel med Ai-NET, optisk digitalutgång, titelminne för 150 skivor och CD-TEXT. Modellen CHA-1214 Ai-NET rymmer 12 skivor och modellen CHM-S620 M-Bus är en superkompakt växlare för 6 skivor.

Contents

ENGLISH

Operating Instructions

WARNING

WARNING.................................................. 2

CAUTION................................................... 2

PRECAUTIONS ......................................... 2

Basic Operation

Detaching the Front Panel..................................5

Attaching the Front Panel ..................................5

Initial System Start-Up ......................................5

Turning Power On and Off ................................6

Display Angle Adjustment .................................6

Adjusting Volume/Balance(Between Left and

Right)/Fader (Between Front and Rear) .........7

Selecting BBE Mode ......................................... 7

Adjusting Source Signal Level ..........................7

Changing Backlighting Colour

(CDA-7873R/TDA-7587R only) ....................7

Dimmer Control .................................................8

Subwoofer On and Off.......................................8

Sound (Beep) Guide Function ...........................9

Turning Mute Mode On/Off...............................9

Setting the AUX Mode (V-Link)......................10

Demonstration..................................................10

Setting the Bass Control ..................................11

Setting the Treble Control................................11

Setting the Bass Forward .................................12

Defeat...............................................................12

Blackout Mode On and Off

(CDA-7876RB/TDA-7588RB only) ............12

Adjusting the built-in Crossover......................13

Switching the Display Modes

(CDA-7876RB/TDA-7588RB only) ............13

Changing the Audio Level Display Pattern

(CDA-7873R/TDA-7587R only) ..................13

Radio Operation

Switching the Tuner Mode...............................14

Manual Tuning................................................. 14

Automatic Seek Tuning ...................................15

Manual Storing of Station Presets ................... 15

Automatic Memory of Station Presets.............16

Tuning to Preset Stations .................................16

RDS Operation

Setting RDS Reception Mode and Receiving

RDS Stations ................................................17

Recalling Preset RDS Stations.........................18

Receiving RDS Regional (Local) Stations ......18

Receiving Traf f ic Information..........................19

PTY (Programme Type) Tuning ......................19

Receiving Traffic Information While Playing

CD or Radio..................................................20

Priority PTY (Programme Type)......................20

Turning Emergency Alarm On or Off..............21

Displaying Radio Text ..................................... 21

CD Player Operation

(CDA-7876RB/CDA-7873R only)

Opening and Closing the Movable display...... 22

Playback...........................................................22

Music Sensor (Skip).........................................23

Fast Forward and Backward ............................23

Repeat Play ......................................................23

M.I.X. (Random Play) .....................................23

Scanning Programmes .....................................23

Displaying the Title/Text..................................24

Titling Discs.....................................................24

Erasing Disc Title.............................................25

CD Text Scroll Setting .....................................25

Cassette Player Operation

(TDA-7588RB/TDA-7587R only)

Inserting/Ejecting Cassette ..............................26

Normal Play and Pause ....................................26

Dolby B NR (Noise Reduction).......................26

Repeat Play ......................................................26

Blank Skip (B.SKIP)........................................26

Fast Forward and Rewind ................................27

Scanning Programmes .....................................27

Manual Reverse ...............................................27

Programme Sensor (P.S.) .................................27

CD Changer Operation

Controlling CD Changer (Optional) ................28

Music Sensor (M.S.) Skip................................28

Fast Forward and Backward ............................29

Repeat Play on Single Track or Entire Disc ....29

M.I.X. (Random) Play .....................................29

Disc Scan .........................................................30

To Display CD Titles .......................................30

Titling Discs.....................................................30

Erasing Disc Title.............................................31

Searching for Titled Discs................................31

Multi-Changer Selection..................................31

Remote Control Operation (CDA-7876RB/

TDA-7588RB/TDA-7587R only)

Controls on Remote Control ............................32

Battery Replacement........................................33

Information

In Case of Difficulty ........................................34

Specifications...................................................36

Installation and Connections

Warning ............................................................37

Caution.............................................................37

Precautions.......................................................38

Installation .......................................................39

Connection .......................................................40

* Dolby noise reduction manufactured under license from

Dolby Laboratories Licensing Corporation. "DOLBY" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

1-EN

WARNING

This symbol means important instructions. Failure to heed them can result in serious injury or death.

DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged attention should only be performed after coming to a complete stop. Al w ays stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident.

KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE NOISE WHILE DRIVING.

Failure to do so may result in an accident.

CAUTION

This symbol means important instructions. Failure to heed them can result in injury or material property damage.

HALT USE IMMEDIATELY IF A PROBLEM APPEARS.

Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing.

DO NOT MIX NEW BATTERIES WITH OLD BATTERIES. INSERT WITH THE CORRECT BATTERY POLARITY.

When inserting the batteries, be sure to observe proper polarity (+ and –) as instructed. Rupture or chemical leakage from the battery may cause fire or personal injury.

PRECAUTIONS

MINIMIZE DISPLAY VIEWING WHILE DRIVING.

Viewing the display may distract the driver from looking ahead of the vehicle and cause an accident.

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire, electric shock or other injury.

KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.

Failure to do so may result in fire or electric shock.

DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

Doing so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

Temperature

Be sure the temperature inside the vehicle is between +60°C (+140°F) and –10°C (+14°F) before turning your unit on.

Moisture Condensation

You may notice the CD playback sound wavering due to condensation. If this happens, remove the disc from the player and wait about an hour for the moisture to evaporate.

Damaged Disc

Do not attempt to play cracked, warped, or damaged discs. Playing a bad disc could severely damage the playback mechanism.

Maintenance

If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing.

Installation Location

Make sure the CDA-7876RB/CDA-7873R/TDA-7588RB/ TDA-7587R will not be installed in a location subjected to:

• Direct sun and heat

• High humidity and water

• Excessive dust

• Excessive vibrations

DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION SLOTS OR GAPS.

Doing so may result in personal injury or damage to the product.

2-EN

Handling the Detachable Front Panel

• Do not expose to rain or water.

• Do not drop or apply shock.

Never Attempt the Following

Do not grip or pull out the disc while it is being pulled back into the player by the automatic reloading mechanism. Do not attempt to insert a disc into the unit when the unit power is off.

Inserting Discs

Your player accepts only one disc at a time for playback. Do not attempt to load more than one disc. Make sure the label side is facing up when you insert the disc. Your player will automatically eject any disc that is inserted incorrectly. If the player continues to eject a correctly inserted disc, push the RESET switch with a pointed object such as a ballpoint pen. Playing a disc while driving on a very bumpy road may result in skips, but this will not scratch the disc or damage the player.

New Discs

As a protective measure to prevent the CD from jamming, the CD player will automatically eject discs with irregular surfaces or inserted incorrectly. When a new disc is inserted into the player and ejected after initial loading, using your finger, feel around the inside of the centre hole and outside edge of the disc. If you feel any small bumps or irregularities, this could inhibit proper loading of the disc. To remove the bumps, rub the inside edge of the hole and outside edge of the disc with a ballpoint pen or other such instrument, then insert the disc again.

Centre Hole

New Disc

Correct Handling

Do not drop the disc while handling. Hold the disc so you will not leave fingerprints on the surface. Do not affix tape, paper, or gummed labels to the disc. Do not write on the disc.

INCORRECT CORRECT

CORRECT

Disc Cleaning

Fingerprints, dust, or soil on the surface of the disc could cause the CD player to skip. For routine cleaning, wipe the playing surface with a clean, soft cloth from the centre of the disc to the outer edge. If the surface is heavily soiled, dampen a clean, soft cloth in a solution of mild neutral detergent before cleaning the disc.

Disc Accessories

There are various accessories available on the market for protecting the disc surface and improving sound quality. However, most of them will influence the thickness and/or diameter of the disc. Using such accessories can cause the disc to be out of standard specifications and may create operational problems. We recommend not using these accessories on discs played in Alpine CD players.

Bumps

Outside (Bumps)

Irregular Shaped Discs

Be sure to use round shape discs only for this unit and never use any special shape discs. Use of special shape discs may cause damage to the mechanism.

Disc StabilizerTransparent Sheet

3-EN

Tape Slack

Check and make sure any slack in the tape is taken up before inserting the tape into the unit. A loose tape can get caught in the mechanism and cause damage to the unit and the tape itself. Tighten the tape by inserting a pencil or a similar instrument into the spindle hole and turn until all the slack has been taken up.

Excessively Thin Tape

C-120 type cassette tapes are not recommended for use in automobile tape players.

Precision Tape Mechanism

Prevent any foreign objects from entering the cassette opening as the precision mechanism and tape head may be damaged. Never play dirty or dusty tapes – they can damage the tape head.

Tape Head Cleaning

Periodic cleaning (approximately every 20 hours of use) of the tape head with a wet type head-cleaning cassette tape (available at audio stores) is necessary for best performance.

Fuse Replacement

When replacing the fuse(s), the replacement must be of the same amperage as shown on the fuse holder. If the fuse blows more than once, carefully check all electrical connections for shorted circuitry. Also have your vehicle's voltage regulator checked.

4-EN

POWER RESET

Basic Operation

Basic

Detaching the Front Panel

1 Press and hold the POWER button at least 3

seconds to turn off the power.

2 Press the (Release) button at left side until

the front panel pops out.

3 Grasp the left side of the front panel and pull it

out.

NOTES

• The front panel may become hot in normal usage

(especially the connector terminals on the back of the front panel), this is not malfunction.

• To protect the front panel, place it in the supplied

carrying case.

Attaching the Front Panel

1 First, insert the right side of the front panel into

the main unit. Align the groove on the front panel with the projections on the main unit.

2 Push the left side of the front panel until it locks

firmly into the main unit.

• Controlable with Remote Control

(CDA-7873R only)

This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control sensor.

Remote control sensor

•

Connectable to Remote Control Interface Box

You can operate this unit from the vehicle's control unit when an Alpine Remote Control Interface Box (optional) is connected. For details, contact your Alpine dealer.

Initial System Start-Up

Immediately after installing or applying power to the unit, it should be initialized. Press the RESET switch with a ballpoint pen or any other pointed object.

NOTE

Before attaching the front panel, make sure that there is no dirt or dust on the connector terminals and no foreign object between the front panel and the main unit.

5-EN

Basic

POWER TUNE MODE/BBE

g DN f UP

SETUP ANGLE 89

Basic Operation

About Demonstration

This unit is equipped a Demonstration function. Soon after resetting the unit or after turning the unit on the first time, the demonstration starts automatically. To cancel the demonstration, refer to “Demonstration” on page 10.

Turning Power On and Off

1 Press the POWER button to turn on the unit.

NOTE

The unit can be turned on by pressing any other button except the eject c button.

The volume level gradually increases to the previous level you were listening to before the unit was turned off. Press and hold the POWER button for at least 3 seconds to turn off the unit.

NOTE

The very first time the power is turned on, the volume will start from level 12, the BBE will be on in the tuner mode.

Display Angle Adjustment

Movable display

The movable display may be adjusted to 3 different angles depending upon user preference.

1 Press the ANGLE 89 button to adjust the angle

of the movable display.

NOTES

• The display will close a half minute after the ignition

key is turned to the OFF position.

• The adjusted angle of the display is stored in memory.

There is no need to re-adjust the angle when the power is turned back on.

CAUTION

Keep hands (or any other object) away from the display while it is opening or closing to avoid damage or injury. The back of the movable display will get very warm under normal operating conditions. This is not a malfunction. Do not touch.

6-EN

Basic

Adjusting V olume/Balance (Between Left and Right)/Fader (Between Front and Rear)

1 Press the MODE (Audio Control) knob

repeatedly to choose the desired mode. Each press changes the modes as follows:

→ BAL → FAD → VOL

NOTES

• If the MODE (Audio Control) knob is not rotated

within 5 seconds after selecting the BALANCE, or FADER mode, the unit automatically returns to the VOLUME mode.

• When the subwoofer or BBE mode is ON, their

respective levels may be adjusted.

2 Rotate the MODE (Audio Control) knob until the

desired sound is obtained in each mode.

NOTE

When the temperature inside the unit rises, the volume may decrease momentarily. This is not a malfunction.

Selecting BBE Mode

The BBE (Barcus Berry Electronics) processor installed in this unit is designed to correct the phase distortion inherent in most loudspeaker designs. Ensuring the phase integrity of the signal driving the speakers improves the accurate reproduction of the sound.

1 Press and hold the BBE button for at least 2

seconds to turn on and off the BBE mode.

2 In BBE mode, press the MODE (Audio Control)

knob to select the BBE adjusting mode. Each press changes the adjusting mode.

3 To change to a desired BBE level, rotate the

MODE (Audio Control) knob. The BBE level can be changed from +1 to +3.

NOTE

The initial mode is +2.

Adjusting Source Signal Level

If the difference in volume level between the CD player and FM radio is too great, adjust the FM signal level as follows.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button repeatedly to select

"FM-LV." Each press of the f UP button scrolls the modes as follows: → FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

When you press the g DN button, the display scrolls in the reverse sequence.

3 Press the TUNE button to select the FM signal

level mode. Each press toggles between "FM-LV HI" (High) and "FM-LV LO" (Low).

4 Press the SETUP button to activate the normal

mode.

Changing Backlighting Colour

CDA-7873R/TDA-7587R only

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button repeatedly to select

"AMBER". Each press of the f UP button changes the modes as shown:

NOTE

If you press the g DN button the display scrolls in reverse sequence.

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

3 Press the TUNE button to toggle the mode

between "AMBER ON" (amber) and "AMBER OFF" (green).

∗

4 Press the SETUP button to set the selected

mode.

7-EN

Basic

TUNE

g DN f UP

SETUP

Basic Operation

Dimmer Control

Set the DIMMER control to AUTO to decrease the illumination brightness of the unit with the head lights of the vehicle ON. This mode is useful if you feel the unit's backlighting is too bright at night.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button repeatedly to select

"DIM." Each press of the f UP button scrolls the modes as shown:

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

If you press the g DN button the display scrolls in reverse sequence.

MODE

Subwoofer On and Off

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button repeatedly to select

"SUB (Subwoofer)." Each press of the f UP button changes the modes as shown:

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

If you press the g DN button the display scrolls in reverse sequence.

∗

3 Press the TUNE b utton to toggle mode betw een

"SUB-W ON" and "SUBW OFF."

4 Press the SETUP button after setting the SUB-W

ON.

∗

3 Press the TUNE b utton to select the Dimmer

mode. Each press toggles between "DIM AUTO" and "DIM MANU."

4 Press the SETUP button to activate the normal

mode.

8-EN

5 Press the MODE (Audio Control) knob

repeatedly to select the SUB-W mode.

→ SUB-W → BAL

VOL ← FAD ←

If an Ai-NET compatible processor with Subwoofer output is connected: The subwoofer output phase is toggled SUBW NOR (0°) or SUBW REV (180°) by pressing the g DN button or the f UP button.

6 Rotate MODE (Audio Control) knob until the

desired sound is obtained in each mode.

Basic

Sound (Beep) Guide Function

This function will give audible f eedback with varying tones depending upon the button pressed.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button repeatedly to select

"BEEP." Each press of the f UP button changes the modes as shown:

NOTE

If you press the g DN button the display scrolls in reverse sequence.

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

3 Press the TUNE b utton to toggle the mode

between "BEEP ON" and "BEEP OFF."

NOTE

The initial setting at the factory is BEEP ON.

4 Press the SETUP button to set the selected

mode.

Turning Mute Mode On/Off

If a device having the interrupt feature is connected, audio will be automatically muted whenever the interrupt signal is received from the device. This function can be turned ON or OFF from the head unit by following procedure below.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button to select the "MUTE"

mode. Each press changes the modes as sho wn:

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

∗

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

If you press the g DN button the display scrolls in reverse sequence.

3 Press the TUNE button to turn on or off the Mute

mode. Each press toggles between the "MUTE ON" and "MUTE OFF" modes.

NOTE

The initial setting at the factory is "MUTE ON."

∗

4 Press the SETUP button again to return to

normal operation.

9-EN

Basic

SOURCE

g DN

f UP

TUNE

CENTER f

MODE/BAND

SETUP

Basic Operation

Setting the AUX Mode (V-Link)

You can input TV/video sound by connecting an optional Ai-NET/RCA Interface cable (KCA-121B) or Versatile Link Terminal (KCA-410C) to this component.

1 Press and hold the SETUP button for at least 3

seconds.

5 To adjust the volume, etc., first press the

SOURCE button and select the AUX mode, then make the necessary adjustment.

NOTE

When using the Versatile Link Terminal (KCA-410C), you can connect two external inputs. To select the mode, press the BAND button on the unit.

Demonstration

2 Press the f UP button repeatedly to select

"AUX." Each press of the f UP button changes the modes as shown:

NOTE

If you press the g DN button the display scrolls in reverse sequence.

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER∗ → DIM → SUB

DEMO ← AUX (AUX Mode Display Setting

∗ CDA-7873R/TDA-7587R Only ∗∗ Displayed after AUX ON is set.

∗∗

) ← SCR ← MUTE ← BEEP ←

3 Press the TUNE button to toggle the mode

between "AUX ON" and "AUX OFF."

NOTES

• The initial setting at the factory is AUX OFF.

• You can set the AUX mode display by pressing the

g DN or f UP button after AUX ON is set, select the AUX mode display setting, and then press the TUNE button.

• When connecting the Versatile Link Terminal (KCA-

410C), you can set two AUX mode displays.

4 Press the SETUP button to return to the normal

mode.

This unit has the Demonstration feature which simulates the display functions on the display panel.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button to select the "DEMO"

mode. Each press changes the modes as shown:

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

If you press the g DN button the display scrolls in reverse sequence.

∗

10-EN

Basic

3 Press the TUNE b utton to turn on or off the

DEMO mode. Each press toggles between "DEMO ON" and "DEMO OFF."

If no buttons are pressed 30 seconds after the DEMO mode is turned ON. The DEMO mode then begins.

NOTE

The initial setting at the factory is "DEMO ON."

4 Press the SETUP button again to return to

normal operation.

Setting the Bass Control

You can change the Bass Frequency emphasis to create your own tonal preference.

1 Press the CENTER f button to select the BASS

(bass Centre frequency) control mode.

→ BASS → TREBLE → OFF

2-1

Setting the bass Centre frequency: Press the g DN or f UP button to select the desired bass centre frequency.

→ 60Hz → 70Hz → 80Hz → 90Hz

180Hz ← 150Hz ← 130Hz ← 100Hz ←

Emphasizes the displayed Bass frequency ranges.

Setting the Treble Control

You can change the Treble Frequency emphasis to create your own tonal preference.

1 Press the CENTER f button select on the

TREBLE (treble Centre frequency) control mode.

→ BASS → TREBLE → OFF

2-1

Setting the treble Centre frequency: Press g DN or f UP button to select the desired treble centre frequency.

→ 10kHz → 12.5kHz → 15kHz → 17.5kHz

Emphasizes the displayed Treble frequency ranges.

2-2

Setting the treble Level: Rotate the MODE (Audio Control) knob to select the desired Treble Level (-7~+7). You can emphasize the treble frequency.

NOTES

• If no buttons are pressed within 5 seconds, the Treble

control setting will be turned off automatically.

• The settings of the Treble will be individually

memorized for each source (FM, MW (LW), Tape and CD) until the setting is changed. Depending on the connected devices, some functions and display indications do not work.

2-2

Setting the bass Band Width (Q-Factor): Press the BAND button to select the desired bass Band Width.

→ B.Width1 → B.Width2→ B .Width3 → B.Width4

(Wide)←→(Narrow)

Changes the bass boost band width to narrow or wide. A wide setting will boost a wide range of frequencies above and below the centre frequency. A narrower setting will boost only frequencies near the centre frequency.

2-3

Setting the bass Level: Rotate the MODE (Audio Control) knob to select the desired bass Level (-7~+7). You can emphasize or weaken the bass frequency.

NOTES

• If no buttons are pressed within 5 seconds, the Bass

control setting will be turned off automatically.

• The settings of the Bass will be individually

memorized for each source (FM, MW (LW), Tape and CD) until the setting is changed. Depending on the connected devices, some functions and display indications do not work.

...........................

11-EN

Basic

Basic Operation

DISP/ B.OUT (CDA-7876RB/TDA-7588RB only)

g DN

f UP

X-OVERB-FWD/DEFEAT

Setting the Bass Forward

The Bass Forward function shifts the low frequency's energy component to the front. This moves the high energy, dynamic bass sound to the front sound stage.

1 Press the B-FWD button to activate the Bass

Forward setting mode.

2 Press the DN g button or f UP button to

select the Bass Forward level.

OFF ←→ 1 ←→ 2 ←→ 3

....

(Less ←

NOTE

If no buttons are pressed within 5 seconds, the setup menu returns to the normal audio display.

Defeat

By setting Defeat ON, all previously adjusted settings will return to the factory defaults.

→ More)

Blackout Mode On and Off

CDA- 7876RB/TDA-7588RB only

When the Blackout mode is turned on, the display will turn off to reduce power consumption. This additional power enhances the sound quality.

1 Press and hold the B.OUT button for at least 3

seconds to start the blackout mode. By doing so the display will be turned off.

NOTE

If any button on the unit is pressed during the blackout mode, the function will be displayed for 5 seconds to show the operation before returning to Blackout mode.

To cancel the blackout mode, press and hold the B.OUT button for at least 3 seconds.

1 Press the DEFEAT button for more than 3

seconds to turn Defeat on. To cancel Defeat, press the DEFEAT button

again for more than 3 seconds.

12-EN

Basic

Adjusting the built-in Crossover

You can change High Pass Filter, Low Pass Filter, Phase on this unit, so that you can create your favourite sound effects.

1 Press the X-OVER button repeatedly to select

the desired parameter.

→ OFF → HPF →LPF

2 Press the DN g or f UP button to select

the disired setting.

1. HPF (Setting the High Pass Filter): → OFF ←→ 80Hz ←→ 120Hz ←→ 160Hz ←

Outputs all frequencies higher than that selected according to your preference.

2. LPF (Setting the Low Pass Filter): → OFF ←→ 80Hz ←→ 120Hz ←→ 160Hz ←

Outputs all frequencies lower than that selected according to your preference. (Only available when using the subwoofer output from this unit.)

NOTES

• If you turn the battery power OFF, all settings return

to factory default.

• If HPF, LPF, Bass Control and Treble Control are all

set to ON, depending on the Bass Control and Treble Control settings, you may not be able to reinforce the sound effect.

• Except when the HPF and LPF is turned OFF, the

subwoofer is in monaural mode.

• When the subwoofer is set to OFF, LPF mode and

change of phase does not work.

• If no buttons are pressed within 5 seconds, the display

for setup menu disappears while an ordinary menu appears on the display.

Switching the Display Modes

CDA-7876RB/TDA-7588RB only

You can select the display pattern mode from three display patterns. You can also deactivate the display.

1 Press the DISP (DISPLAY) button to select the

desired Display pattern mode. Each press changes the display patterns.

→ Pattern1 → Pattern2 → Pattern3 → Display OFF

Changing the Audio Level Display Pattern

You can select the disired display pattern mode from three Audio Level Display Patterns. You can also deactivate the display.

CDA-7873R/TDA-7587R only

1 Press DISP button to switch the display pattern.

→ Pattern 1 → Pattern 2 → Pattern 3 → Display OFF

13-EN

Radio

SOURCE

g DN f UP SETUP

BANDTUNE

Radio Operation

Switching the Tuner Mode

The CDA-7876RB/CDA-7873R/TDA-7588RB/ TDA-7587R incorporates the MAX TUNE Pro for the highest quality tuner audio. Moreover, you can choose between two settings to suit your own personal sound preferences usage.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the g DN or f UP button to select

the "HI-FI or NORMAL or STABLE." Each press of the f UP button changes the modes as shown:

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

3 Press the TUNE button to switch the TUNER

mode.

→ HI-FI → NORMAL → STABLE

Preset buttons

(1 through 6)

Manual T uning

1 Press the SOURCE button until a radio

frequency appears in the display.

2 Press the BAND button repeatedly until the

desired radio band is displayed. Each press changes the band:

→ FM1 → FM2 → FM3 → MW → LW

3 Press the TUNE b utton repeatedly until "DX

SEEK" and "SEEK" disappear from the display.

NOTE

The initial mode is DX SEEK.

4 Press the g DN or f UP button to move

∗

downward or upward one step respectively until the desired station frequency is displayed.

NOTE

The ST indicator appears on the display when a Stereo FM station is tuned in.

NORMAL: Standard setting HI-FI: Sound quality priority setting STABLE: Noiseless priority setting

NOTES

• The initial setting at the factory is "NORMAL."

• If you find the sound is very noisy while listening to

the tuner in the HI-FI mode, we recommend you change to the NORMAL mode.

4 When the setting is completed, press the SETUP

button to return to the normal mode.

14-EN

Radio

Automatic Seek Tuning

1 Press the SOURCE button until a radio

frequency appears in the display.

2 Press the BAND button repeatedly until the

desired radio band is displayed. Each press changes the band:

→ FM1 → FM2 → FM3 → MW → LW

3 Press the TUNE button to illuminate the DX and

SEEK indicators in the display. With the DX (Distance) mode activated, both strong and weak stations will be tuned in the Auto-Seek operation. Press again to return to the local mode. The DX indicator will turn off and the SEEK indicator will remain illuminated. Now, only strong stations will be tuned.

4 Press the g DN or f UP button to

automatically seek for a station downward or upward respectively . The unit will stop at the next station it finds. Press the same button again to seek the next station.

Manual Storing of Station Presets

1 Select the radio band and tune in a desired radio

station you wish to store in the preset memory.

2 Press and hold any one of the Preset buttons (1

through 6) for at least 2 seconds until the station

frequency on the display blinks.

3 Press the Preset button into which you wish to

store the station while the frequency display is blinking (within 5 seconds). The display stops blinking once the station has been memorized. The display shows the band, preset No. with a triangle (9) and station frequency memorized.

4 Repeat the procedure to store up to 5 other

stations onto the same band. To use this procedure for other bands, simply select the band desired and repeat the procedure. A total of 30 stations can be stored in the preset memory (6 stations for each band; FM1, FM2, FM3, MW and LW).

NOTE

If you store a station in a preset memory which already has a station, the current station will be cleared and replaced with the new station.

15-EN

Radio

Radio Operation

SOURCE A.ME BAND

Preset buttons (1 through 6)

Automatic Memory of Station Presets

1 Press the SOURCE button to select the radio

mode.

2 Press the BAND button repeatedly until the

desired radio band is displayed.

3 Press and hold the A. ME button for at least 2

seconds. The frequency on the display continues to change while the automatic memory is in progress. The tuner will automatically seek and store 6 strong stations in the selected band. They will be stored into buttons Preset 1 to 6 in order of signal strength. When the automatic memory has been completed, the tuner goes to the station stored in the preset location No. 1.

NOTE

If no stations are stored, the tuner will return to the original station you were listening to before the auto memory procedure began.

Tuning to Preset Stations

1 Press the SOURCE button to select the radio

mode.

2 Press the BAND button repeatedly until the

desired band is displayed.

3 Press the station Preset button that has your

desired radio station in memory . The display shows the band, preset number with a triangle and frequency of the station selected.

16-EN

SOURCE

RDS

g DN f UP

F AF

RDS Operation

Setting RDS Reception Mode and Receiving RDS Stations

The RDS (Radio Data System) is a radio information system using the 57 kHz subcarrier of regular FM broadcast. The RDS allows you to receive a variety of information such as traffic information, station names, and to automatically re-tune to a stronger transmitter that is broadcasting the same programme.

1 Press the SOURCE button until a radio

frequency appears in the display.

2 Press the "F" button. The indicator will

illuminate.

3 Press the AF button to activate the RDS mode.

Tips

The RDS digital data includes the followings:

PI Programme Identification PS Programme Service Name AF List of Alternative Frequencies TP Traffic Programme T A Traff ic Announcement PTY Programme T ype EON Enhanced Other Networks R.TEXT Radio Text Information

4 Press the g DN or f UP button to tune in

the desired RDS station.

NOTE

When the BAND button is pressed for at least 2 seconds while the PS (Programme Service Name) is being displayed, the display shows the station frequency for 5 seconds, then returns to the previous display. To show the PS (Programme Service Name) in the display, press and hold the BAND button for at least 2 seconds again.

5 Press the AF button to deactivate the RDS

mode.

17-EN

RDS

TUNE T.INFO

g DN f UP

SETUP/F AF

RDS Operation

Recalling Preset RDS Stations

1 Press the "F" button. The indicator will

illuminate.

2 Press the AF button to activate the RDS mode.

The display shows "AF" when the RDS mode is activated.

3 Press the 1 through 6 buttons in which your

desired RDS station is preset. If the preset station's signal is weak, the unit automatically searches and tunes to a stronger station in the AF (Alternative Frequencies) list.

4 If the preset station and the stations in the AF list

cannot be received: The unit searches again for a station in the PI

(Programme Identification) list. If there are still no stations receivable in the area, the unit displays the frequency of the preset station and the preset indicator disappears.

If the signal level of the Regional (Local) station being tuned becomes too weak to receive, press the same preset location button to tune in a Regional station in other district.

NOTE

For presetting the RDS stations, refer to the Radio Operation section. The RDS stations can be preset in the FM1, FM2 and FM3 bands only.

Preset buttons (1 through 6)

PTY

Receiving RDS Regional (Local) Stations

1 Press and hold the SETUP button for at least 3

seconds to activate the setting mode.

2 Press the f UP button repeatedly to select

"REG" Each press of the f UP button scrolls the modes as shown:

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

If you press the g DN button the display scrolls in reverse sequence.

3 Press the TUNE b utton to turn on or off the

"REG" (Regional) mode. In the "REG OFF" mode, the unit automatically keeps receiving the related local RDS station.

4 Press the SETUP button to deactivate the setting

mode.

∗

18-EN

RDS

Receiving T raffic Inf ormation

1 Press the T.INFO button to activate the Traffic

Information mode. To cancel the Traffic information mode, press the T.INFO button again.

2 Press the g DN or f UP button to select

your desired traffic information station. When a traffic information station is tuned in, the TP indicator lights up.

Traffic information is heard only when it is being broadcast. If traffic information is not being broadcast, the unit is set in the standby mode. When a traffic information broadcast begins, the unit automatically receives it and the display shows "TRF-INFO" for 5 seconds, then returns to the previous display.

When traffic information broadcast is over, the unit will automatically set in the standby mode.

NOTES

• If the traffic information broadcast signal falls below a

certain level, the unit remains in the receiving mode for 1 minute. If the signal remains below a certain level for over 1 minute, the "T.INFO" indicator blinks.

• If you do not want to listen to the traffic information

being received, lightly press the T.INFO button to skip that traffic information message. The T.INFO mode will remain in the ON position to receive the next traffic information message.

• If the volume level is changed while receiving traffic

information, the changed volume level will be memorized. When traffic information is received next time, the volume level will be automatically adjusted to the level memorized.

• In the T.INFO mode, the SEEK tuning selects only the

TP stations.

PTY (Programme Type) Tuning

1 Press the "F" button. The indicator will

illuminate.

2 Press the PTY button to activate the PTY mode.

The Programme Type of the station being currently received will be displayed for 5 seconds.

• If there is no receivable PTY broadcast, "NO PTY" will be displayed for 5 seconds.

• If no RDS station can be received, the display shows "NO PTY."

NOTE

If no button is pressed within 5 seconds after pressing the PTY button, the PTY mode will be automatically cancelled.

3 Press the g DN and f UP buttons within 5

seconds after activating the PTY mode to choose the desired programme type while the PTY (programme type) is being displayed. Each press scrolls the programme type by one.

→ LIGHT M → CLASSICS → OTHER M

4 Press the PTY button within 5 seconds after

selecting the programme type to start searching for a station in the selected programme type. The chosen programme type indicator blinks during searching and lights when a station is found.

If no station is found, "NO PTY" will be displayed for 5 seconds.

5 Press the "F" button to activate the normal mode.

The

NOTE

Operate the unit while the indicator is illuminated. If no buttons are pressed within 5 seconds, the indicator will turn off.

indicator will turn off.

19-EN

RDS

TUNE T.INFO

g DN f UP

SETUP/F P.PTY R.TEXT

RDS Operation

Receiving T raffic Information While Playing CD or Radio

1 Press the T.INFO button repeatedly until the

T.INFO indicator appears in the display.

2 Press the g DN and f UP buttons to

select a traffic information station if necessary.

• When a traffic information broadcast starts, the unit automatically mutes the CD player or the regular FM broadcast.

• When the traffic information broadcast finishes, the unit automatically returns to the original source play before the traffic information broadcast began.

• When traffic information stations cannot be received:

In the tuner mode:

When the TP signal can no longer be received for over 1 minute, the "T.INFO" indicator blinks.

In the CD mode:

When the TP signal can no longer be received, the traffic information station of another frequency will be selected automatically.

NOTE

The receiver is equipped with the EON (Enhanced Other Networks) function in order to keep track of additional alternative frequencies to the AF list. The EON indicator appears while an RDS EON station is being received. If the station being received does not broadcast the traffic information, the receiver automatically tunes in the related station that broadcasts the traffic information when it occurs.

Priority PTY (Programme Type)

This function allows presetting of a programme type such as music category, news, etc. You can listen to a programme in the preset programme type as the unit automatically gives priority to the preset programme type when it begins broadcasting, and interrupts the programme you are currently listening. This feature is functional when your unit is set to a mode other than the LW and MW.

1 Press the "F" button. The indicator will

illuminate.

2 Press the P. PTY button to activate the

PRIORITY PTY mode. "PRIO-PTY" is displayed for 2 seconds and then the programme type for 3 seconds. The initial setting is "NEWS."

NOTE

If no button is pressed within 5 seconds after pressing the P. PTY button, the PRIORITY PTY mode is automatically cancelled.

3 Press the g DN or f UP button within 5

seconds while "NEWS" is being displayed to choose a desired programme type. Then press P. PTY button. The PRIORITY PTY function will activate.

3 Press the T.INFO button to deactivate the Traffic

Information mode. The T.INFO indicator disappears.

20-EN

RDS

4 Press the P. PTY button to activate the

PRIORITY PTY mode again.

• To change the programme category, perform the step 3.

• To disable the PRIORITY PTY function, press the P. PTY button.

NOTE

In the PRIORITY PTY function, unlike in the T.INFO function, the volume does not increase during operation.

5 Press the "F" button to activate the normal mode.

The

NOTE

Operate the unit while the indicator is illuminated. If no buttons are pressed within 5 seconds, the indicator will turn off.

Turning Emergency Alarm On or Off

indicator will turn off.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button repeatedly to select

"PTY31" Each press of the f UP button scrolls the modes as shown.

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

If you press the g DN button the display scrolls in reverse sequence.

∗

Displaying Radio Text

Text messages from a radio station can be displayed.

1 Tune in a radio station that transmits text

messages.

2 Press the "F" button. The indicator

illuminates.

3 Press the R.TEXT button to activate the Radio

Text mode. The display shows "WAIT" for a few seconds, then starts scrolling the text message. It continues until other operation is performed.

4 To cancel the Radio Text mode, press the

R.TEXT button.

5 Press the "F" button to return to the normal

operation mode. The from the display.

NOTES

• If there is no receivable text message or the unit

cannot receive a text message properly, the display shows "NO TEXT" for 2 seconds.

• Operate the unit while the

illuminated. If no buttons are pressed within 5 seconds, the indicator will turn off.

indicator disappears

indicator is

3 Press the TUNE b utton repeatedly to select the

"PTY31 ON" or "PTY31 OFF" mode. In the PTY31 ON mode, the unit will show "ALARM" in the display when the unit receives the PTY31 (Emergency Broadcast) signal.

4 Press the SETUP button to activate the selected

mode.

21-EN

SOURCE -/J

g DN f UP

F M.I.X. REPEAT

SCAN c

CD Player Operation (CDA-7876RB/CDA-7873R only)

Opening and Closing the Movable display

1 Press the c button.

The movable display will open.

(Movable display fully opened)

To close the movable display, press the c button again. The movable display will close.

NOTES

• Do not apply shock to the movable display when it is

open as it may result in malfunction of the unit.

• The display may be dim during low temperatures and

immediately after turning on the power. The brightness will return to normal as time elapses.

• The display will stop at the set angle when closing.

CAUTION

Playback

1 Press the c button.

The movable display will open.

Insert a disc with the label side facing up.

2 Insert a disc with the label side facing up.

The disc will be pulled into the unit automatically. The movable display will close and playback will begin. When a disc is already inserted, press the SOURCE button to switch to the CD mode. The mode will change every time the button is pressed.

→ TUNER → CD → CD CHANGER∗ (∗ Only when the CD changer is connected)

3 To pause playback, press the -/J button.

Pressing the -/J button again will resume playback.

4 To eject the disc, press the c button.

NOTES

• If the CD does not eject, press c button again for at

least 3 seconds with the movable display open.

• Only compact discs containing the mark shown can be

used.

22-EN

• We cannot fully guarantee the playback of CD-R (CD-

Recordable). You cannot playback CD-RW (CDReWritable) on this unit.

Music Sensor (Skip)

1 Momentarily press the g DN button once

during CD play to return to the beginning of the current track. If you wish to access the beginning of a track further back, repeatedly press until you reach the desired track.

Press the f UP button once to advance to the beginning of the next track. If you wish to access the beginning of a track further ahead, press repeatedly until the desired track is reached.

NOTE

The music sensor feature is functional in the play or pause mode.

Fast Forward and Backward

1 Press and hold the g DN or f UP button to

quickly move backward or forward until you reach the desired section of the track.

Repeat Play

1 Press the REPEAT(Repeat) button to play back

repeatedly the track being play ed. The RPT indicator appears and the track will be played repeatedly.

Press the REPEAT button again and select OFF to deactivate the repeat play.

NOTES

• If a CD Changer is connected and the RPT ALL mode is selected, the unit repeatedly plays back all tracks on the disc selected.

→ →→

REPEAT REPEAT ALL (off)

• In case a 6-disc CD changer is connected: In CD changer mode, press the "F" button to illuminate the 5 seconds.

• In case a 12-disc CD changer is connected: In changer mode, press the "F" button twice to illuminate the 5 seconds.

indicator and go to step 1 within

M.I.X. (Random Play)

1 Press the M.I.X. b utton in the play or pause

mode. The M.I.X. indicator will illuminate and the tracks on the disc will be played back in a random sequence. After all the tracks on the disc have been played back once, the player will begin a new random sequence play until the M.I.X. mode is cancelled.

To cancel M.I.X. play, press the M.I.X. button again to turn off the M.I.X.

NOTES

• If a CD Changer equipped with the ALL M.I.X.

function is connected, ALL M.I.X. will also be selectable. In this mode, the tracks on all the CDs in the current magazine will be included in the random playback sequence.

→

M.I.X. ALL M.I.X. (off)

• In case a 6-disc CD changer is connected:

In CD changer mode, press the "F" button to illuminate the 5 seconds.

• In case a 12-disc CD changer is connected:

In changer mode, press the "F" button twice to illuminate the 5 seconds.

→→

indicator and go to step 1 within

Scanning Programmes

1 Press the SCAN button to activate the Scan

mode. The first 10 seconds of each track will be played back in succession.

To stop scanning, press the SCAN button and deactivate the Scan mode.

NOTES

• In case a 6-disc CD changer is connected:

In CD changer mode, press the "F" button to illuminate the 5 seconds.

• In case a 12-disc CD changer is connected:

In changer mode, press the "F" button twice to illuminate the 5 seconds.

indicator and go to step 1 within

23-EN

TUNE/

-/J

MODE

TITLE

SETUPg DN f UP

CD Player Operation (CDA-7876RB/CDA-7873R only)

Displaying the Title/Text

It is possible to display the CD title if the title has been previously inputted. For details, see Titling Discs (see this page). Text information, such as the disc name and the track name, will be displayed if playing a CD text compatible disc.

1 Press the TITLE b utton.

The mode will change every time the button is pressed.

About "Title" and "Text" Title: With this device, it is possible to input the CD

name (see this page). This inputted name is referred to as a "title."

Text: Text compatible CDs contain text information

such as the disc name and track name. Such text information is referred to as "text."

CD/Changer mode:

ELAPSED TIME DISPLAY

TEXT DISPLAY (DISC NAME)

TEXT DISPLAY (TRACK NAME)

TITLE DISPLAY

↓ ↓ ↓ ↓

∗1

∗2

Titling Discs

1 Press the TITLE button and select the title

display mode. For details, see Displaying the Title/Text (see this page).

2 Press and hold the TITLE button for at least 3

seconds. The first charactor will blink.

3 Rotate the MODE (Audio Control) knob to select

the desired letter/numeral/symbol available for naming.

4 Press the MODE (Audio Control) knob to store

the first character. The first character will stop blinking and the display will automatically advance to the next character. When that character begins to blink, you may choose the next letter or symbol of your title.

∗1

Displayed during playback of a disc with CD Text. "NO TEXT" will be displayed when the CD contains no text data.

∗2

"--------" will be displayed when the title has not been inputted.

NOTES

• Some characters may not be displayed correctly with this

device, depending on the character type.

• The display may not show all the information of the CD Text

depending on the CD changer .

• When the CD Text Scroll Setting (refer to page 25) is set to

"SCR MANU", press and hold the TITLE button for at least 3 seconds to scroll the Text information only once (TEXT DISPLAY mode only .)

24-EN

5 Repeat the steps 3 and 4 above to complete the

titling. Pressing the MODE (Audio Control) knob after entering the eighth character, automatically stores the title into memory.

When entering a title of less than 8 characters (for example, 3 character title): After entering 3 characters to complete your title, the 4th character space will be blinking. Go to step 6 to complete the title.

6 Press and hold the TITLE button for at least 3

seconds to record the title.

NOTES

• The memory capacity for the disc titles is 18. If you try to store beyond the limit, the display will show "FULL DATA." At this point, no more titles can be stored.

• To input a new title, one of the previously inputted titles must first be deleted.

• When you want to erase a title, enter the " into all spaces.

• The CD Changer title length or memory capacity varies depending upon the model being used.

• Removing power from the unit may delete these titles. Use caution when manipulating the power cord.

" symbol

Erasing Disc Title

1 Press the TITLE button to select the disc titling

mode. Then, press and hold for at least 3 seconds.

CD Text Scroll Setting

This CD player has the ability to scroll the disc and track name recorded on CD-Text discs. The scrolling feature will work with names greater than 8 characters.

1 Press and hold the SETUP button for at least 3

seconds.

2 Press the f UP button repeatedly to select

"SCR". Each press of the f UP button changes the modes as shown:

→ FM-LV → REG → PTY31 → HI-FI/NORMAL/STABLE → AMBER

DEMO ← AUX ← SCR ← MUTE ← BEEP ← SUB ← DIM ←

∗ CDA-7873R/TDA-7587R Only

NOTE

If you press the g DN button the display scrolls in reverse sequence.

3 Press the TUNE button to toggle mode between

SCR AUTO and MANU.

• SCROLL AUTO: the display of CD text is scrolled continuously.

• SCROLL MANUAL: the display is scrolled only when a disc is loaded or when a track is changed.

∗

2 Press and hold the -/J button for at least 2

seconds to activate the title scanning mode. The title in the display will blink.

3 Press the g DN or f UP button repeatedly

until the disc title you want to erase is displayed.

4 Press and hold the -/J button for at least 2

seconds to erase the disc title displayed.

5 Press and hold the TITLE button for at least 3

seconds to cancel the disc title erasing mode.

NOTE

You cannot erase CD-TEXT.

4 When the setting is completed, press the SETUP

button to return to the normal mode.

NOTES

• Initial mode is "SCR MANU."

• The unit scrolls only CD text names. The disc titles

input manually (refer to page 24) cannot be scrolled.

25-EN

Cassette

Cassette Player Operation (TDA-7588RB/TDA-7587R only)

PROG:/J c

g DN f UP

NR B P.S.DN P.S.UP B.SKIP REPEAT SCAN

Inserting/Ejecting Cassette

1 Insert a cassette tape into the slot with the open

side facing right.

When the cassette is loaded, the player automatically starts tape playback and indicates "TAPE" in the display.

2 Press the c button when you want to eject the

cassette tape.

NOTES

• When power is turned off or the front panel is removed,

the full-logic mechanism will automatically switch to the P AUSE mode. This pr otects the tape from being deformed by the pinch-rollers if left for long periods.

• Auto Metal

When a metal cassette tape is inserted, the player automatically adjusts to the equalization for metal or any other high bias tape for optimum sound. The display shows "MTL."

2 Press the :/J button to pause the tape playback.

The display shows "PAUSE." Press again to resume the tape playback.

3 Press the c button to stop the tape play and

eject the cassette. The tape-direction indicator disappears.

Dolby B NR (Noise Reduction)

1 After inserting a Dolby B NR encoded tape,

press the NR B button. The display shows the "B NR" The tape noise is

reduced in the Dolby NR mode when a Dolby B NR encoded tape is played. Press the NR B button to cancel the Dolby NR mode.

Repeat Play

1 Press the REPEAT button to play back

repeatedly the current programme being played. The RPT indicator appears and the programme will be played repeatedly.

Press the REPEAT button to stop the repeat play. The RPT indicator disappears.

Blank Skip (B.SKIP)

Normal Play and Pause

1 Insert a cassette (or press the source button to

switch from the tuner or CD Changer mode if a cassette is already inside the tape player). The player begins playback. The display shows "TAPE" and " show the tape side being played. When the end of the tape is reached, the unit automatically stops and reverses the tape to play the other side of the tape.

or " during tape playback to

26-EN

1 Press the B.SKIP button during tape play to skip

over blank portions of the tape lasting 15 seconds or longer, "B.SKIP" appears on the display. Press the B.SKIP button to cancel the blank skip mode. "B.SKIP" disappears from the display.

Cassette

Fast Forward and Rewind

1 Press the g DN or f UP button during

tape play to fast rewind or forward the tape respectively. The tape side indicator ( or << moves indicating the direction of the tape. When the end of the tape is reached in the rewind mode, the player stops automatically and begins playing from the beginning of the same side. When the end of the tape is reached in the fast forward mode, the player stops automatically and begins playing from the beginning of the opposite side.

or ) blinks and >>

2 Press the f UP button during forwarding to

stop fast forwarding and resume tape play. Press the g DN button during rewinding to stop rewinding and resume tape play. The tape side indicator stops blinking.

Scanning Programmes

1 Press the SCAN button to play the first 10

seconds of each programme on the tape. "SCAN" appears on the display.

Press the SCAN button to cancel the scanning when the desired programme is found.

NOTE

The SCAN operation cannot detect blank sections of less than 4 seconds.

Programme Sensor (P.S.)

1 Press the P.S. DN button once during tape play

to return to the beginning of the current selection being played. If you wish to return to a selection further back, press repeatedly until the number of selections you would like to skip is shown in the display. The display will show PS-1 with the first press and will increase by one with each successive press up to PS-9. The tape indicator will blink showing the direction of your search.

Press the P.S. UP button once during tape play to advance to the beginning of the next selection. If you wish to advance to a selection further ahead, press repeatedly until the number of selections you would like to skip is shown in the display. The display will show PS+1 with the first press and will increase with each successive press up to PS+9. The tape indicator will blink showing the direction of your search during searching operation.

NOTES

• The programme sensor feature is functional in the tape play mode only.

• You can advance to the 9th (max.) programme or return to the 8th (max.) programme.

Manual Reverse

1 Press the PROG button during tape play to

change the tape direction to play the other side of the tape. The tape side indicators ( show which side of the cassette is being played.

and ) change to

27-EN

Changer

SOURCE

g DN f UP

Disc select buttons (1 through 6)

F M.I.X REPEAT

CD Changer Operation

Controlling CD Changer (Optional)

An optional 6-disc or 12-disc CD Changer may be connected to the CDA-7876RB/CDA-7873R/TDA7588RB/TDA-7587R if it is Ai-NET compatible. With a CD Changer connected to the Ai-NET input of the CDA-7876RB/CDA-7873R/TDA-7588RB/TDA7587R, the CD Changer will be controllable from the CDA-7876RB/CDA-7873R/TDA-7588RB/TDA7587R. Using the KCA-400C (the Multi-Changer Switching device) or KCA-410C (Versatile Link Terminal) multiple changers can be controlled by the CD A7876RB/CDA-7873R/TDA-7588RB/TDA-7587R. See the Multi-Changer Selection section on page 31 for selecting the CD Changers.

NOTES

• The controls on the CDA-7876RB/CDA-7873R/

TDA-7588RB/TDA-7587R for CD Changer operation are operative only when a CD Changer is connected.

• The "Changer" indicator illuminates in the CD Changer

mode.

•The DVD changer (optional) is controllable from the

CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R as well as the CD changer.

1 Press the SOURCE button to activate the

CHANGER mode. The display shows the "Changer," disc number and track number.

NOTE

The source indicator varies depending on the connected source.

2 Press the Disc Select buttons (1 through 6)

corresponding to one of the discs loaded in the CD Changer. The selected disc number appears in the display and CD playback starts.

NOTES

• After selecting the desired disc, you can operate in the

same way as for the CD player. For details, please see the CD Operation section.

• If the

buttons become nonfunctional.

When a 12-disc CD Changer is connected:

To select discs numbered from 1 to 6, the procedure is the same as for the 6-disc CD Changer. To select discs numbered from 7 to 12, first press the "F" button. This changes the "D" indicator to "d." Then press the desired Preset button. With the "F" button activated, the Preset buttons 1 to 6 will represent discs 7 to 12 respectively.

Music Sensor (M.S.) Skip

1 Press the g DN button once to return to the

beginning of the current track. If you wish to return to the beginning of a track further back, repeatedly press until you reach the desired track.

Press the f UP button once to advance to the beginning of the next track. If you wish to advance to a track further ahead, press repeatedly until the desired track is reached.

NOTE

The music sensor feature is functional in the play or pause mode.

indicator is illuminated the Disc Select

28-EN

Changer

Fast Forward and Backward

1 Press and hold the g DN or f UP button to

quickly move backward or forward respectively until you reach the desired portion.

NOTE

This feature works only in the CD playback mode.

Repeat Play on Single Track or Entire Disc

1 Press the "F" (Function) button.

The function indicator at the top side of the "F" button will turn off.

2 Press the REPEAT button to display "RPT" or

"RPT ALL" to play back repeatedly the track being currently played or the entire disc selected.

NOTE

Single track cannot be repeated during M.I.X. play.

3 Press the "F" button to activate the normal

mode. The function indicator at the top side of the "F" button will illuminate.

M.I.X. (Random) Play

1 Press "F" button.

The function indicator at the top side of the "F" button will turn off.

2 Press the M.I.X. button while the CD is playing or

in the Pause mode. The M.I.X. indicator will appear in the display . The tracks on the disc will be played back in a random sequence. After all the tracks on the disc have been played back, the player loads the next disc and begins a new random sequence.

Random play continues until the M.I.X. mode is cancelled.

Press the M.I.X. button again to cancel the M.I.X. mode. The M.I.X. indicator will disappear from the display.

3 Press the "F" button to activate the normal

mode. The function indicator at the top side of the "F" button will illuminate.

29-EN

Changer

SOURCE

g DN f UP

TITLE

Preset buttons (1 through 6)T.S.M:/J MODE

CD Changer Operation

Disc Scan

1 Press the "F" button.

The function indicator at the top side of the "F" button will turn off.

2 Press the SCAN button to play the first 10

seconds of each track on the disc. The display shows the disc number, "SCAN", and track number being played during scan play.

Press to the SCAN button to cancel scan play and resume normal play.

3 Press the "F" button to activate the normal

mode. The function indicator at the top side of the "F" button will illuminate.

To Display CD Titles

Titling Discs

1 Press the TITLE button to select the disc title

display mode. (Refer to page 24.)

2 Make sure that the function indicator at the top

side of the "F" button illuminates, then press the Preset buttons to select the desired disc to be titled.

3 Press and hold the TITLE button for at least 3

seconds. The first digit blinks.

4 Press the MODE button to store the first

character. The first character will stop blinking and the display will automatically advance to the next digit. When that digit begins to blink, you may choose the next letter or symbol of your title.

SCAN

Titles can be displayed for the CDs with titles entered. (Refer to page 24 to title discs.)

1 Press the TITLE button in the CD mode.

The display will be switched each time the switch is pressed.

30-EN

5 Repeat the step 4 above to complete the titling.

Entering the eighth character, automatically stores the title into memory.

Changer

6 Press and hold the TITLE button for at least 3

seconds to record the title.

NOTES

• When the memory capacity for the disc titles is used

up, the display shows "FULL DATA" to indicate that no more title can be memorized.

• When you want to erase a title, enter the "

symbol into all spaces.

Erasing Disc Title

1 Press the TITLE button to select the disc titling

mode. Then press and hold it for at least 3 seconds.

2 Press and hold the :/J button for at least 2

seconds to activate the title erasing mode. The disc title in the display will blink.

3 Press the g DN or f UP button repeatedly

until the disc title you want to erase is displayed.

4 Press and hold the :/J button for at least 2

seconds to erase the disc title displayed.

5 Press and hold the TITLE button for at least 3

seconds to cancel the disc title erasing mode.

Multi-Changer Selection

Alpine's Ai-NET system will support up to 6 CD Changers. When operating two or more changers, the KCA-400C (Multi-Changer Switching device) must be used. If you use 1 Switching device, you can connect up to 4 CD Changers. If you use 2 Switching devices, you can connect up to 6 CD Changers. When using KCA-410C (Versatile Link Terminal), you can connect two changers and two external outputs (AUX).

1 Press the SOURCE button to activate the CD

Changer mode. Alternatively, press the SOURCE button on the

Remote Control (RUE-4187) to activate the CD Changer mode. Proceed to Step 3 below to select the desired CD Changer.

SOURCE

BAND

Searching for Titled Discs

If a CD is titled, you can do a search for it. (To title CDs, refer to "Titling Discs" on page 24.)

1 Press and hold the T.S.M. button f or at least 2

seconds. The title blinks in the display.

2 Press the g DN or f UP button to select

the desired disc title.

3 Press the T.S.M. button to play the selected disc.

The unit will automatically search for the disc and begin play.

4 Press the T.S.M. button for at least 2 seconds to

cancel the disc searching mode.

NOTE

This function cannot be performed when using a multichanger switching device.

2 Press the BAND button or the RUE-4187 to

activate the CD Changer Selection mode.

3 The CD Changer Selection mode remains active

for 3 seconds after Step 2 is performed. Press the BAND button until the desired CD Changer indicator appears on the display.

NOTE

If the selected CD Changer is not connected, the display will show "NO CHGRX."

Alternatively press the BAND button on the Remote Control until the desired changer indicator appears on the display.

4 To operate the selected changer, see "CD

Operation" section.

NOTE

For further details about the external input (AUX) when using KCA-410C, see ”Setting the AUX Mode (V-Link)" on page 10.

31-EN

Remote

Remote Control Operation

1 2

5 6

7 8 9 !

" #

Controls on Remote Control

CDA-7876RB/TDA-7588RB/TDA-7587R only

NOTE

Although the remote control is not supplied with the CDA-7873R, you can use it, if purchased separately.

1 Power Button

Press the button to turn the power on/off.

2 Source Button

Press to select the audio source.

3 -/J Button

Press the button to switch between the Play and Pause modes for CD.

4 ANGLE 89 Buttons

Press the button to adjust the angle of the movable display .

5 Band/Program Button

Radio mode: BAND Button Press the button and the band will change as shown below.

→ FM1 → FM2 → FM3 → MW → LW

6 Volume Adjustment Buttons

To increase the volume level: Press the L button To decrease the volume level: Press the K button

7 8 Button

Radio mode: Pressing the button will select, in ascending order, stations programmed into the radio's presets as shown below.

8 g DN Button

Radio mode: SEEK (DN) Button CD mode: Press the button to go back to the beginning of the current track.

9 f UP Button

Radio mode: SEEK (UP) Button CD mode: Press the button to advance to the beginning of the next track.

! 9 Button

Radio mode: Pressing the button will select, in descending order, stations programmed into the radio's presets as shown below.

→ 6 → 5 ... 1

CD Changer mode: DISC Select (DN) Button Press the button to select a disc in descending order.

" Mute Button

Press the button to lower the volume by 20 dB instantly. Press the button again to cancel.

# Audio Processor Button∗∗

Press the button to call the external audio processor mode.∗

∗

For the operation of external audio processor, refer to the Owner's Manual of the external audio processor you purchased.

∗∗ This button is used in conjunction with an optional Ai-

NET processor.

→ 1 → 2 ... 6

CD Changer mode: DISC Select (UP) Button Press the button to select a disc in ascending order.

32-EN

Battery Replacement

CDA-7876RB/TDA-7588RB/TDA-7587R only

Applicable battery: Use two “AAA” sized dry batteries or equivalent.

1 Opening the battery cover

Slide out the battery cover while firmly pressing the direction of arrow.

Remote

2 Replacing the battery

Put the batteries in the case observing the polarities as illustrated.

3 Closing the cover

Push the cover as illustrated until a click is heard.

33-EN

Information

In Case of Difficulty

If you encounter a problem, please review the items in the following checklist. This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is properly connected or consult your authorized Alpine dealer.

Basic

No function or display.

• Vehicle's ignition is off.

- If connected following instructions, the unit will not operate with the vehicle's ignition off.

• Improper power lead connections.

- Check power lead connections.

• Blown fuse.

- Check the fuse on the battery lead of the unit; replace with the proper value if necessary.

• Internal micro-computer malfunctioned due to interference noise etc.

- Press the RESET switch with a ballpoint pen or other

pointed article.

Radio

Unable to receive stations.

• No antenna or open connection in cable.

- Make sure the antenna is properly connected;

replace the antenna or cable if necessary.

Unable to tune stations in the seek mode.

• You are in a weak signal area.

- Make sure the tuner is in the DX mode.

• If the area you are in is a primary signal area, the antenna may not be grounded and connected properly.

- Check your antenna connections; make sure the

antenna is properly grounded at its mounting location.

• The antenna may not be the proper length.

- Make sure the antenna is fully extended; if broken,

replace the antenna with a new one.

Broadcast is noisy.

• The antenna is not the proper length.

- Extend the antenna fully; replace it if it is broken.

• The antenna is poorly grounded.

- Make sure the antenna is grounded properly at its

mounting location.

CD Player/Changer not functioning.

• Out of operating temperature range +50˚C (+120˚F) for CD.

- Allow the vehicle's interior (or trunk) temperature to

cool.

CD playback sound is wavering.

• Moisture condensation in the CD Module.

- Allow enough time for the condensation to evaporate

(about 1 hour).

CD insertion not possible.

• A CD is already in the CD player.

- Eject the CD and remove it.

• The CD is being improperly inserted.

- Make sure the CD is being inserted following

instructions in the CD Player Operation section.

Unable to fast forward or backward the CD.

• The CD has been damaged.

- Eject the CD and discard it; using a damaged CD in

your unit can cause damage to the mechanism.

CD playback sound skips due to vibration.

• Improper mounting of the unit.

- Securely re-mount the unit.

• Disc is very dirty.

- Clean the disc.

• Disc has scratches.

- Change the disc.

CD playback sound skips without vibration.

• Dirty or scratched disc.

- Clean the disc; damaged disc should be replaced.

Error displays (built-in CD player only)

• Mechanical error

- Press the c button. After the error indication

disappears, insert the disc again. If the abovementioned solution does not solve the problem, consult your nearest ALPINE dealer.

Cassette (TDA-7588RB/TDA-7587R only)

Tape playback sounds dull.

• The tape head needs cleaning.

- Clean the tape head.

• Incorrect Dolby NR in use.

- Check Dolby NR switch setting.

34-EN

Indication for CD Player

Indication for CD Changer

HI TEMP

• Protective circuit is activated due to high temperature.

- The indicator will disappear when the temperature returns to within operation range.

T– – – – –

• No CD is inserted.

- Insert a CD.

• Although a disc is inserted, “T and the unit does not start to play or eject the disc.

- Remove the disc by following these steps:

1) Press the c button.

The movable display will open.

2) Press the c button again for at least 3 seconds while

the movable display is open.

-- ---

” is displayed

ERROR

• Mechanism error.

1)Press the c button and eject the CD.

If not ejecting, consult your Alpine dealer.

2)When the error indication remains after ejecting,

press the c button again. If the error indication still does not turn off after pressing the c button for a few times, consult your Alpine dealer.

HI TEMP

• Protective circuit is activated due to high temperature.

- The indicator will disappear when the temperature returns to within operation range.

ERROR - 01

• Malfunction in the CD Changer.

- Consult your Alpine dealer. Press the magazine eject

button and pull out the magazine. Check the indication. Insert the magazine again. If the magazine cannot be pulled out, consult your

Alpine dealer.

• Magazine ejection not possible.

- Press the magagine eject button. If the magazine does

not eject, consult your Alpine dealer.

ERROR - 02

• A disc is left inside the CD Changer.

- Press the Eject button to activate the eject function. When the CD Changer finishes the eject function, insert an empty CD magazine into the CD Changer to receive the disc left inside the CD Changer.

NO MAGZN

NOTE

When the “ERROR” is displayed: In case that the disc connot be ejected by pressing the c button, press the RESET switch (refer to page 5) and press the c button again. If not ejecting, consult your Alpine dealer.

• No magazine is loaded into the CD Changer.

- Insert a magazine.

NO DISC

• No indicated disc.

- Choose another disc.

35-EN

Specifications

FM TUNER SECTION

Tuning Range 87.5 – 108.0 MHz Mono Usable Sensitivity 0.7 µV Alternate Channel Selectivity 90 dB Signal-to-Noise Ratio 65 dB Stereo Separation 35 dB

MW TUNER SECTION

Tuning Range 531 – 1,602 kHz Sensitivity (IEC Standard) 25.1 µV/28 dB

L W TUNER SECTION

Tuning Range 153 – 281 kHz Sensitivity (IEC Standard) 31.6 µV/30 dB

CD SECTION (CDA-7876RB/CDA-7873R only)

Frequency Response 5 – 20,000 Hz (±1 dB) Wow & Flutter (% WRMS) Below measurable limits Total Harmonic Distortion 0.008% (at 1 kHz) Dynamic Range 95 dB (at 1 kHz) Signal-to-Noise Ratio 105 dB Channel Separation 85 dB (at 1 kHz)

TAPE PLAYER SECTION (TDA-7588RB/TDA-7587R only)

Tape Speed 1-7/8 ips (4.8 cm/sec) ±0.7% Wow & Flutter 0.06% WRMS Signal-to-Noise Ratio With Dolby B-TYPE NR 68 dB Without Dolby NR 60 dB Frequency Response With Alpine Test Tape 30–20,000 Hz

REMOTE CONTROL (CDA-7876RB/TDA-7588RB/TDA-7587R only)

Battery Type "AAA" sized dry battery Battery Quantity 2 Dimensions (W × H × D) 42 mm (1-21/32")

× 121 mm (4-3/4") × 23 mm (15/16")

Weight (without battery) 50 g (1.8 oz)

GENERAL

Power Requirement 14.4 V DC

(11–16 V allowable)

Maximum Power Output 60 W × 4 Maximum Subwoofer Output

Voltage 4 V/10 k ohms

Maximum Pre-Output Voltage 2 V/10k ohms

(CDA-7873R/TDA-7587R only) 5 V/10k ohms

(CDA-7876RB/TDA-7588RB only) Bass ±14 dB at 60 Hz Treble ±14 dB at 10 kHz Weight 1.5 kg (3 lbs. 5 oz)

CHASSIS SIZE

Width 178 mm (7") Height 50 mm (2") Depth 155 mm (6-1/8")

NOSEPIECE SIZE

Width 170 mm (6–11/16") Height 46 mm (1-13/16") Depth 24 mm (15/16")

36-EN

Due to continuous product improvement, specifications and design are subject to change without notice.

Installation and Connections

Before installing or connecting the unit, please read the following and pages 2 and 4 of this manual thoroughly for proper use.

Warning

MAKE THE CORRECT CONNECTIONS.

Failure to make the proper connections may result in fire or product damage.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may result in fire, etc.

BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY TERMINAL.

Failure to do so may result in electric shock or injury due to electrical shorts.

DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING OBJECTS.

Arrange wiring and cables in compliance with the manual to prevent obstructions when driving. Cables or wiring that obstruct or hang up on places such as the steering wheel, gear lever, brake pedals, etc. can be extremely hazardous.

DO NOT SPLICE INTO ELECTRICAL CABLES.

Never cut away cable insulation to supply power to other equipment. Doing so will exceed the current carrying capacity of the wire and result in fire or electric shock.

DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING HOLES.

When drilling holes in the chassis for installation, take precautions so as not to contact, damage or obstruct pipes, fuel lines, tanks or electrical wiring. Failure to take such precautions may result in fire.

DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER VEHICLE OPERATION, SUCH AS THE STEERING WHEEL OR GEARSHIFT.

Doing so may obstruct forward vision or hamper movement etc. and results in serious accident.

Caution

HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS.

The wiring and installation of this unit requires special technical skill and experience. To ensure safety, always contact the dealer where you purchased this product to have the work done.

USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM SECURELY.

Be sure to use only the specified accessory parts. Use of other than designated parts may damage this unit internally or may not securely install the unit in place. This may cause parts to become loose resulting in hazards or product failure.

ARRANGE THE WIRING SO IT IS NOT CRIMPED OR PINCHED BY A SHARP METAL EDGE.

Route the cables and wiring away from moving parts (like the seat rails) or sharp or pointed edges. This will prevent crimping and damage to the wiring. If wiring passes through a hole in metal, use a rubber grommet to prevent the wire's insulation from being cut by the metal edge of the hole.

DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST.

Avoid installing the unit in locations with high incidence of moisture or dust. Moisture or dust that penetrates into this unit may result in product failure.

DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO MAKE GROUND CONNECTIONS.

Bolts or nuts used for the brake or steering systems (or any other safety-related system), or tanks should NEVER be used for installations or ground connections. Using such parts could disable control of the vehicle and cause fire etc.

KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

37-EN

Precautions

• Be sure to disconnect the cable from the (–) battery post

before installing your CDA-7876RB/CDA-7873R/ TDA-7588RB/TDA-7587R. This will reduce any chance of damage to the unit in case of a short-circuit.

• Be sure to connect the colour coded leads according to

the diagram. Incorrect connections may cause the unit to malfunction or damage to the vehicle's electrical system.

• When making connections to the vehicle's electrical

system, be aware of the factory installed components (e.g. on-board computer). Do not tap into these leads to provide power for this unit. When connecting the CDA7876RB/CDA-7873R/TDA-7588RB/TDA-7587R to the fuse box, make sure the fuse for the intended circuit of the CDA-7876RB/CDA-7873R/TDA-7588RB/TDA7587R has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle. When in doubt, consult your ALPINE dealer.

• The CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-

7587R uses female RCA-type jacks for connection to other units (e.g. amplifier) having RCA connectors. You may need an adaptor to connect other units. If so, please contact your authorized ALPINE dealer for assistance.

• Be sure to connect the speaker (–) leads to the speaker

(–) terminal. Never connect left and right channel speaker cables to each other or to the vehicle body.

IMPORTANT

Please record the serial number of your unit in the space provided below and keep it as a permanent record. The serial number plate is located on the bottom of the unit.

SERIAL NUMBER: INSTALLATION DATE: INSTALLATION TECHNICIAN: PLACE OF PURCHASE:

38-EN

Installation

Metal plate

Detachable Front panel

Caution

When you install this unit in your car, do not remove the Detachable Front Panel. If the Detachable Front Panel is removed during installation, you might press too hard and warp the metal plate that holds it in place.

3 Slide the CDA-7876RB/CDA-7873R/TDA-

7588RB/TDA-7587R into the dashboard. When the unit is in place, make sure the locking pins are fully seated in the down position. This can be done by pressing firmly in on the unit while pushing the locking pin down with a small screwdriver. This ensures that the unit is properly locked and will not accidentally come out from the dashboard. Install the Detachable Front Panel.

Bracket

Dashboard

Mounting sleeve (Included)

CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R

Slide mounting sleeve from main unit (see "Removal" on this page). Slide the mounting sleeve into the dashboard.

CDA-7876RB/CDA-7873R/TDA-7588RB/TDA-7587R

Metal Mounting Strap

Hex Nut (M5)

Rubber Cap (Included)

Screw

Bolt Stud

∗

Hex Bolt (Included)

Lock pin

Removal

1 Remove the detachable front panel. 2 Use a small screwdriver (or similar tool) to push

the locking pins to the "up" position (see above drawing). As each pin is unlocked, gently pull out on the unit to make sure it does not re-lock before unlocking the second pin.

3 Pull the unit out, keeping it unlocked as y ou do so.

Front frame

Screws (M5 × 8)

CDA-7876RB/CDA-7873R/ TDA-7588RB/TDA-7587R

(Included)

When your vehicle has the Bracket, mount the long hex bolt onto the rear panel of the CDA7876RB/CDA-7873R/TDA-7588RB/TDA-7587R and put the Rubber Cap on the hex bolt. If your vehicle does not have the Mounting Support, reinforce the head unit with the metal mounting strap (not supplied). Connect all the leads of the CDA-7876RB/CDA-7873R/TDA-7588RB/TDA7587R according to details described in the CONNECTION section.

NOTE

For the screw *, provide a proper screw to the chassis installing location.

Mounting Bracket

39-EN

Installation and Connections

Connection

(Pink/Black) AUDIO INTERRUPT IN

(Blue/White) REMOTE TURN-ON

(Orange) DIMMER

(Red) IGNITION

(Blue) POWER ANT

(Black) GND

choke coil

(Yellow) BATTERY

CDA-7876RB /TDA-7588RB only

ISO Antenna Convertor Plug

Antenna

ISO Antenna Plug

To vehicle phone

To amplifier or equalizer To the instrument cluster

illumination lead To power antenna

Ignition Key

Battery

CD Changer (Ai-NET) (Sold Separately)

Speakers

Ai-NET

NORM EQ/DIV

When Subwoofer is set to OFF: Output is from Rear speakers.

(Green)

(Green/Black)

(White)

(White/Black)

(Gray/Black)

(Gray)

(Violet/Black)

(Violet)

;

( )

Amplifier

Speakers

Rear Left

Front Left

Front Right

Rear Right

When Subwoofer is set to ON: Output is from Subwoofer. For details on how to set the Subwoofer to ON/OFF, see "Subwoofer On and Off" on page 8.

Front

Rear

Subwoofers*

40-EN

1 Antenna Receptacle

Connect to the supplied ISO antenna convertor plug.

2 Audio Interrupt In Lead (Pink/Black)

Connect this lead to the Audio Interface output of a cellular phone which provides ground shorting when a call is received.

3 Remote Turn-On Lead (Blue/White)

Connect this lead to the remote turn-on lead of your amplifier or signal processor.

4 Dimmer Lead (Orange)

This lead may be connected to the vehicle’s instrument cluster illumination lead. This will enable the vehicle’s dimmer control to dim the backlighting of the unit.

5 Switched Power Lead (Ignition) (Red)

Connect this lead to an open terminal on the vehicle’s fuse box or another unused power source which provides (+) 12V only when the ignition is turned on or in the accessory position.

6 Power Antenna Lead (Blue)

Connect this lead to the +B terminal of your power antenna, if applicable.

NOTE

This lead should be used only for controlling the vehicle's power antenna. Do not use this lead to turn on an amplifier or a signal processor, etc.

7 Fuse Holder (20A) 8 Battery Lead (Yellow)

Connect this lead to the positive (+) post of the vehicle's battery.

For the battery lead and battery connection

Use an extension battery lead (20A)(sold separately) and connect it directly to the positive (+) side of the vehicle's battery.

9 ISO Power Supply Connector ! Ground Lead (Black)

Connect this lead to a good chassis ground on the vehicle. Make sure the connection is made to bare metal and is securely fastened using the sheet metal screw provided.

" Ai-NET Connector

Connect this to the output or input connector of other product (CD changer, Equalizer, etc.) equipped with Ai-NET.

# System Switch

When connecting a processor using Ai-NET, place this switch in the EQ/DIV position. When no device is connected, leave the switch in the NORM position.

NOTE

Be sure to turn the power off to the unit before changing the switch position.

$ Power Supply Connector % ISO Connector (Speaker Output) & Left Rear (+) Speaker Output Lead (Green) ( Left Rear (–) Speaker Output Lead (Green/

Black)

) Left Front (+) Speaker Output Lead (White) ~ Left Front (–) Speaker Output Lead (White/Black) + Right Front (–) Speaker Output Lead (Grey/

Black)

, Right Front (+) Speaker Output Lead (Grey)

- Right Rear (–) Speaker Output Lead (Violet/

Black)

. Right Rear (+) Speaker Output Lead (Violet) / Remote Control Interface Connector

To remote control interface box.

: Ai-NET Cable (Included with CD Changer) ; Front Output RCA Connectors

RED is right and WHITE is left.

< Rear Output RCA Connectors

RED is right and WHITE is left.

= Subwoofer Output RCA Connectors

RED is right and WHITE is left.

DC/DC Converter (CDA-7876RB/TDA-7588RB

only)

NOTES

• Do not install the converter at a location subjected to

water such as under the floor mat or air conditioner. This may cause a malfunction.

• Do not bundle the DC/DC converter cable with other

audio cables. Doing so may induce noise into your system.

• Keep the DC/DC converter away from the Antenna

cables and the rear side of the unit, otherwise noise may be generated when receiving radio broadcast.

To prevent external noise from entering the audio system.

• Locate the unit and route the leads at least 10 cm away from the car harness.

• Keep the battery power leads as far away from other leads as possible.

• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.

• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries

various noise suppressors, contact them for further information.

• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.

41-EN

42-EN

Alpine CDA-7876RB, TDA-7587R, TDA-7588RB Owner Manual
