Alpine KIT-700LEON Installation Manual [EN]

ABOUT

1 234
DIP ON

The Alpine APF-V1G7 Infodapter for VW MIB platform vehicles allows vehicle information
such as climate control, parking sensors and heated seats and vehicle menus to be dis­played on the Alpine iLX-700 head unit. The APF-V1G7 also allows the use of the steering
wheel controls with the iLX-700 head unit.

DIP SWITCH SETTINGS

See Fig 1.
Up = Off, Down = On

1: Not applicable. (This should be kept in the Up/Off position)
2: Not applicable.
3: Resets the display settings back to default. If the display settings have been

manipulated in a way that it is no longer possible to make adjustments, change the
DIP switch #3 from Off to On and back. This will reset the screen settings to the factory
defaults. During this procedure the screen background will change to red. While the
background is red, no settings can be made.

4: Not applicable. (This should be kept in the Up/Off position)

Interface Connections

Fig 1.

Video/Data output to
head unit AUX/CAMERA
connector

2

Power Harness Steering Wheel

Á

10

Â

À Alpine iLX-700 head unit
Á AUX/CAMERA/CAN

connector

 Steering Wheel Control Input
à Reverse (Purple)
Ä Speed (Pink)

Remote control
connector to
head unit

À

Å

Ã

Ä

Dip Switches

Æ

Ç

Å Park Brake (Green)
Æ Mute (Grey)
Ç ISO Power Connector
È APF-V1G7 Interface

10 To car connector

Not Used

Fig 2.

È

iLX-700 Setup

The iLX-700 must be congured for rst time use with the APF-V1G7 interface:

1. From the home screen, enter Setup menu and select ‘Application’.

2. From the Application menu, select ‘Auxilliary(AUX)’.

3. From the Auxilliary (AUX) menu, go to ‘Aux Name’ and select ‘DVB-T’.
Go to ‘Direct Touch’ and select ‘ON’.

4. The iLX-700 is now setup to work with the APF-V1G7.

Conguration Menu

To access the APF-V1G7 menu, push the iLX-700 ‘HOME’ button on the front of the head
unit. Select the ‘DVB-T’ icon and use the touchscreen to select items within the menu.

Conguration Menu

Vehicle Settings

Infodapter Settings

Language

Version

< Back

• Vehicle Settings

Vehicle settings can be adjusted via
the menu. All vehicle setup options
that were available with the original
head unit, are now available through
the iLX-700 head unit. See the vehicle
handbook for more information
regarding these features.

• Infodapter Settings

o Screen Size/Position -

The APF-V1G7 is setup by
default for the iLX-700,
however the screen size/
position can be adjusted to
suit the user requirements.

ESC System
Tyre
Driver Assistance
Parking and Manoeuvering
Light

Mirrors and Wipers

Vehicle Settings

Screen Size/Position

Horizontal Size

Horizontal Position

Vertical Size

Vertical Position

< Back

3

Conguration Menu...continued

o Picture Settings -

Adjust Brightness, contrast and
colour saturation.

Infodapter Settings

Screen Size/Position

Picture Settings

Preferences

<Back

o Preferences ­Driver Position - Select Left or Right depending

upon vehicle conguration.

Park Brake Source - Set to Speed, Brake or
Always On.

Climate - Select how long the climate display
should be shown on the head unit when ad­justed. Select between the range of 3 seconds
and 30 seconds.

Restore factory settings - Reverts all
Infodapter settings to factory defaults.
(This does not restore vehicle settings)

o Driving Mode -

The driving mode button can be
used as normal. The graphic for the
mode will be shown on the head
unit.

o Park Assist -

The park assist button can be used
as normal to activate/decactivate
park assist. The graphic will be
shown on the head unit.

Preferences

Driver Position Right
Park Brake Source Speed
Climate 5S
Restore factory settings
< Back

Legal Information

Please consult the relevant road trafc laws governing the country in which this product is being operated.

No liability is accepted for material damage, loss or personal injury, directly or indirectly, from installation and

operation of this product. This product should only be operated when safe to do so.
