Alpine CDA-9856R, CDA-9857R User Manual

FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/ PARA USO EN AUTOMÓVILES/SOLO PER L’UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK

RDS MP3/WMA CD Receiver

CDA-9857R

CDA-9856R

ALPINE ELECTRONICS MARKETING, INC.

1-1-8 Nishi Gotanda,

Shinagawa-ku,

Tokyo 141-0031, Japan

Phone 03-5496-8231

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF CANADA, INC.

777 Supertest Road, Toronto,

Ontario M3J 2M9, Canada

Phone 1-800-ALPINE-1 (1-800-257-4631)

• OWNER'S MANUAL Please read before using this equipment.

• BEDIENUNGSANLEITUNG Lesen Sie diese Bedienungsanleitung bitte vor Gebrauch des Gerätes.

• MODE D'EMPLOI Veuillez lire avant d’utiliser cet appareil.

• MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo.

• ISTRUZIONI PER L’USO Si prega di leggere prima di utilizzare il attrezzatura.

• ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning.

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

161-165 Princes Highway, Hallam

Victoria 3803, Australia

Phone 03-8787-1200

ALPINE ELECTRONICS GmbH

Frankfurter Ring 117, 80807 München, Germany

Fletchamstead Highway, Coventry CV4 9TW, U.K.

B.P. 50016, 95945 Roissy Charles de Gaulle

Phone 089-32 42 640

ALPINE ELECTRONICS OF U.K. LTD.

Alpine House

Phone 0870-33 33 763

ALPINE ELECTRONICS FRANCE S.A.R.L.

(RCS PONTOISE B 338 101 280)

98, Rue de la Belle Etoile, Z.I. Paris Nord Il,

Cedex, France

Phone 01-48638989

ALPINE ITALIA S.p.A.

Viale C. Colombo 8, 20090 Trezzano

Sul Naviglio (MI), Italy

Phone 02-484781

ALPINE ELECTRONICS DE ESPAÑA, S.A.

Portal de Gamarra 36, Pabellón, 32

01013 Vitoria (Alava)-APDO 133, Spain

Phone 945-283588

ALPINE ELECTRONICS (BENELUX) GmbH

Leuvensesteenweg 510-B6,

1930 Zaventem, Belgium

Phone 02-725-13 15

Dalian Dongtai Colour Printing Technology Co., Ltd. No.24 Liaohexisan Road, Dalian Economic&Technical Development Zone, China

Printed in China (Y)

68-04123Z54-B

ENGLISH

Contents Operating Instructions

WARNING

WARNING ................................................. 3

CAUTION .................................................. 3

PRECAUTIONS ........................................ 3

Getting Started

Turning Power On and Off ............................... 6

Detaching and Attaching the Front Panel ........ 6

Initial System Start-Up ..................................... 6

Adjusting Volume ............................................. 7

Setting the Time and Calendar ......................... 7

Radio

Listening to Radio ............................................ 7

Manual Storing of Station Presets .................... 7

Automatic Memory of Station Presets ............. 8

Tuning to Preset Stations .................................. 8

Frequency Search Function .............................. 8

RDS

Setting RDS Reception Mode and Receiving

RDS Stations ................................................. 8

Recalling Preset RDS Stations ......................... 8

Receiving RDS Regional (Local) Stations ....... 9

PI SEEK Setting ............................................... 9

Setting PTY31 (Emergency Broadcast)

reception ........................................................ 9

Setting the Time to automatically Adjust ......... 9

Receiving Traffic Information ........................ 10

PTY (Programme Type) Tuning ..................... 10

Receiving Traffic Information While Playing

CD or Radio ................................................ 10

Priority News .................................................. 10

Displaying Radio Text .................................... 11

CD/MP3/WMA

Playback ..........................................................11

Repeat Play .....................................................12

M.I.X. (Random Play) ....................................12

Searching from CD Text .................................12

File/Folder Name Search

(concerning MP3/WMA) ............................13

Quick Search ...................................................13

About MP3/WMA ..........................................13

Sound Setting

Adjusting Bass/Treble/Balance (Between Left

and Right)/Fader (Between Front and Rear)/

Defeat ..........................................................15

Setting the Bass Control .................................15

Setting the Treble Control ...............................16

Turning Loudness On/Off ...............................16

Other Functions

Displaying the Text .........................................16

Displaying Time .............................................17

Blackout Mode On and Off

(CDA-9857R only) ......................................17

SETUP

General Setting

Birthday Opening Message Setting

(Birthday Set) ...............................................18

Setting the Clock Display (Clock Mode) .........18

Turning the Clock Display ON/OFF ................18

Changing Lighting Colour ...............................18

Playing MP3/WMA Data (Play Mode) ............18

Sound (Beep) Guide Function ..........................18

Turning Mute Mode On/Off (INT Mute) .........18

Setting the AUX Mode (V-Link) ......................19

Setting the External Digital Input

(Digital AUX) ...............................................19

Connecting to an External Amplifier ...............19

Tuner Setting

Adjusting Source Signal Levels .......................19

Audio Setting

Subwoofer On and Off .....................................20

Setting the Subwoofer System .........................20

1-EN

Display Setting

Dimmer Control ............................................... 20

Scroll Type Setting ........................................... 20

Scroll Setting (Text Scroll) ..............................20

Switching the Character Font (Font Select) .....20

Setting the Russian Font (Language Set) .........20

Switching the Animation Display Type

(BGV Select) ................................................ 20

Opening Message ON/OFF Setting ................. 20

Setting of Calendar Display Pattern Switching

(Calendar)..................................................... 20

Demo Setting

Demonstration ..................................................20

iPod™ (Optional)

Playback ..........................................................21

Searching for a desired Song .......................... 21

Searching by Playlist ...................................21

Searching by artist name .............................21

Searching by album name ...........................22

Random Play Shuffle (M.I.X.) .......................22

Repeat Play .....................................................22

Displaying the Text .........................................23

Changer (Optional)

Controlling CD Changer (Optional) ...............23

Playing MP3 Files with the CD Changer

(Optional) ....................................................24

Multi-Changer Selection (Optional) ...............24

Information

In Case of Difficulty .......................................24

Specifications .................................................. 27

Installation and Connections

Warning .................................................. 28

Caution ................................................... 28

Precautions ............................................ 28

Installation ......................................................29

Connections for CDA-9857R .........................30

Connections for CDA-9856R .........................32

2-EN

Operating Instructions

WARNING

This symbol means important instructions. Failure to heed them can result in serious injury or death.

DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged attention should only be performed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident.

KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE NOISE WHILE DRIVING.

Failure to do so may result in an accident.

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may result in fire, etc.

CAUTION

This symbol means important instructions. Failure to heed them can result in injury or material property damage.

HALT USE IMMEDIATELY IF A PROBLEM APPEARS.

Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing.

PRECAUTIONS

Product Cleaning

Use a soft dry cloth for periodic cleaning of the product. For more severe stains, please dampen the cloth with water only. Anything else has the chance of dissolving the paint or damaging the plastic.

Temperature

Be sure the temperature inside the vehicle is between +60°C (+140°F) and –10°C (+14°F) before turning your unit on.

Moisture Condensation

You may notice the CD playback sound wavering due to condensation. If this happens, remove the disc from the player and wait about an hour for the moisture to evaporate.

KEEP SMALL OBJECTS SUCH AS BATTERIS OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.

Failure to do so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire, electric shock or other injury.

DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION SLOTS OR GAPS.

Doing so may result in personal injury or damage to the product.

Damaged Disc

Do not attempt to play cracked, warped, or damaged discs. Playing a bad disc could severely damage the playback mechanism.

Maintenance

If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing.

3-EN

Never Attempt the Following

Do not grip or pull out the disc while it is being pulled back into the player by the automatic reloading mechanism. Do not attempt to insert a disc into the unit when the unit power is off.

Inserting Discs

Your player accepts only one disc at a time for playback. Do not attempt to load more than one disc. Make sure the label side is facing up when you insert the disc. “Error” will be displayed on your player if you insert a disc incorrectly. If “Error” continues to be displayed even though the disc has been inserted correctly, push the RESET switch with a pointed object such as a ballpoint pen. Playing a disc while driving on a very bumpy road may result in skips, but this will not scratch the disc or damage the player.

New Discs

To prevent the CD from jamming, “Error” is displayed if discs with irregular surfaces are inserted or if discs are inserted incorrectly. When a new disc is ejected immediately after initial loading, use your finger to feel around the inside of the centre hole and outside edge of the disc. If you feel any small bumps or irregularities, this could inhibit proper loading of the disc. To remove the bumps, rub the inside edge of the hole and outside edge of the disc with a ballpoint pen or other such instrument, then insert the disc again.

Centre Hole

New Disc

Correct Handling

Do not drop the disc while handling. Hold the disc so you will not leave fingerprints on the surface. Do not affix tape, paper, or gummed labels to the disc. Do not write on the disc.

CORRECT

INCORRECT CORRECT

Disc Cleaning

Fingerprints, dust, or soil on the surface of the disc could cause the CD player to skip. For routine cleaning, wipe the playing surface with a clean, soft cloth from the centre of the disc to the outer edge. If the surface is heavily soiled, dampen a clean, soft cloth in a solution of mild neutral detergent before cleaning the disc.

Disc Accessories

There are various accessories available on the market for protecting the disc surface and improving sound quality. However, most of them will influence the thickness and/or diameter of the disc. Using such accessories can cause the disc to be out of standard specifications and may create operational problems. We recommend not using these accessories on discs played in Alpine CD players.

Bumps

Outside (Bumps)

Irregular Shaped Discs

Be sure to use round shape discs only for this unit and never use any special shape discs. Use of special shape discs may cause damage to the mechanism.

Installation Location

Make sure the CDA-9857R/CDA-9856R will not be installed in a location subjected to:

• Direct sun and heat

• High humidity and water

• Excessive dust

• Excessive vibrations

4-EN

Transparent Sheet Disc Stabilizer

On handling Compact Discs (CD/CD-R/CD-RW)

• Do not touch the surface.

• Do not expose the disc to direct sunlight.

• Do not affix stickers or labels.

• Clean the disc when it is dusty.

• Make sure that there are no bumps around the disc.

• Do not use commercially available disc accessories.

Do not leave the disc in the car or the unit for a long time. Never expose the disc to direct sunlight. Heat and humidity may damage

the CD and you may not be able to play it again.

To customers using CD-R/CD-RW

• If a CD-R/CD-RW cannot be played back, make sure the last recording session was closed (finalized).

• Finalize the CD-R/CD-RW if necessary, and attempt playback again.

About media that can be played.

Use only compact discs with the label side showing the CD logo marks below.

If you use unspecified compact discs, correct performance cannot be guaranteed. You can play CD-Rs (CD-Recordable)/CD-RWs (CD-ReWritable) which have been recorded only on audio devices. You can also play CD-Rs/CD-RWs containing MP3/WMA formatted audio files.

• Some of the following CDs may not play on this unit: Flawed CDs, CDs with fingerprints, CDs exposed to extreme temperatures or sunlight (e.g., left in the car or this unit), CDs recorded under unstable conditions, CDs on which a recording failed or a re-recording was attempted, copy-protected CDs which do not conform to the audio CD industry standard.

• Use discs with MP3/WMA files written in a format compatible with this unit. For details, see pages 13-14.

• ROM data other than audio files contained in a disc will not produce sound when played back.

• Windows Media and the Windows logo are trademarks, or

registered trademarks of Microsoft Corporation in the United States and /or other countries.

• Apple, the Apple logo and iPod are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.

• “MPEG Layer-3 audio coding technology licensed from Fraunhofer llS and Thomson.”

• “Supply of this product only conveys a license for private, noncommercial use and does not convey a license nor imply any right to use this product in any commercial (i.e. revenuegeneration) real time broadcasting (terrestrial, satellite, cable and/or any other media), broadcasting/streaming via internet, intranets and/or other networks or in other electronic content distribution systems, such as pay-audio or audio-on-demand applications. An independent license for such use is required. For details, please visit http://www. mp3licensing.com.”

5-EN

Getting Started

Rotary encoder

(OPEN)

Turning Power On and Off

Press SOURCE/POWER to turn on the unit.

• The unit can be turned on by pressing any other button except

(OPEN) and Rotary encoder.

Press and hold SOURCE/POWER for at least 2 seconds to turn off the unit.

• The first time power is turned on, the volume will start from level 12.

Detaching and Attaching the Front Panel

Be sure to push the Rotary encoder inside the unit before opening the front panel so that the front panel will open completely, otherwise it may be damaged.

SOURCE/POWER

MODE

Grasp the front panel firmly, slide to the left , then pull to remove.

• The front panel may become hot in normal usage (especially the

connector terminals on the back of the front panel). This is not a malfunction.

• To protect the front panel, place it in the supplied carrying case.

• When detaching the front panel, do not apply excessive force as it

may result in malfunction and damages.

• Do not leave the front panel open, or drive the car with the panel

open as it may result in accident or malfunction.

Attaching

Insert the right side of the front panel into the main unit. Align the groove on the front panel with the projections on the main unit.

Push the left side of the front panel until it locks firmly into the main unit.

Push the Rotary encoder inside

When you push the Rotary encoder again, it pops back out.

The Rotary encoder pops out

Detaching

Turn off the unit power.

Press (OPEN) to open the front panel.

To close the front panel, press the left isde until it locks as shown in the figure below.

• Before attaching the front panel, make sure that there is no dirt or

dust on the connector terminals and no foreign object between the front panel and the main unit.

• Attach the front panel carefully, holding the sides of the front panel to

avoid pushing buttons by mistake.

Initial System Start-Up

Be sure to press the RESET switch when using the unit for the first time, after changing the car battery, etc.

Turn off the unit power.

Press (OPEN) to open the front panel, then remove it.

Press RESET with a ballpoint pen or similar pointed object.

RESET switch

6-EN

Adjusting Volume

Turn the

Rotary encoder

until the desired sound is obtained.

Setting the Time and Calendar

Press MENU to select the SETUP mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the GENERAL mode, then press MODE.

Press or to select the “Clock Adjust”, then press MODE.

Turn the Rotary encoder to set year.

Press MODE.

Repeat steps 4 and 5 above to set month, day, hour and minutes.

Press MENU to select RETURN.

After 2 seconds, the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode.

• To synchronize the clock to another clock/watch or radio time announcement, press and hold MODE for at least 2 seconds after setting the “hour.” Minutes will reset to 00. If the display shows over “30” minutes when you do this, the time will advance one hour.

Radio

Rotary encoder

MODE

Listening to Radio

Press SOURCE/POWER to select the TUNER mode.

Press BAND repeatedly until the desired radio band is displayed.

FM1 FM2 FM3 MW LW FM1

Press TUNE/A.ME to select the tuning mode.

DX (Distance mode) LOCAL (Local mode) MANUAL (Manual mode) DX

• The initial mode is Distance mode.

SOURCE/POWER

BAND

FUNC.

TUNE/A.ME

Preset buttons (1 through 6)

Controllable With Remote Control

The CDA-9857R/CDA-9856R can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control sensor.

Remote control sensor

Connectable to Remote Control Interface Box

This unit may be controlled from the vehicle’s audio controls. An optional Alpine Remote Control Interface Box must be used. For details, contact your Alpine dealer.

Distance mode:

Both strong and weak stations will be automatically tuned in (Automatic Seek Tuning).

Local mode:

Only strong stations will be automatically tuned in (Automatic Seek Tuning).

Manual mode:

The frequency is manually tuned in steps (Manual tuning).

Press or to tune in the desired station.

Holding down or will change the frequency continuously.

Manual Storing of Station Presets

Select the radio band and tune in a desired radio station you wish to store in the preset memory.

Press and hold, for at least 2 seconds, any one of the preset buttons (1 through 6) into which you wish to store the station.

The selected station is stored. The display shows the band, preset number and station frequency memorized.

• A total of 30 stations can be stored in the preset memory (6 stations

for each band; FM1, FM2, FM3, MW and LW).

• If you store a station in a preset memory which already has a station,

the current station will be cleared and replaced with the new station.

• If the audio function mode is activated, press FUNC. to return to

preset mode.

7-EN

Automatic Memory of Station Presets

Press BAND repeatedly until the desired radio band is displayed.

Press and hold TUNE/A.ME for at least 2 seconds.

The frequency on the display continues to change while the automatic memory is in progress. The tuner will automatically seek and store 6 strong stations in the selected band. They will be stored into buttons 1 to 6 in order of signal strength. When the automatic memory has been completed, the tuner goes to the station stored in preset location No. 1.

• If no stations are stored, the tuner will return to the original station you were listening to before the auto memory procedure began.

Tuning to Preset Stations

RDS

Rotary encoder

MODE

Setting RDS Reception Mode and Receiving RDS Stations

FUNC.

1 AF NEWS 2 3 PTY

TITLE

Press BAND repeatedly until the desired band is displayed.

Press any one of the station preset buttons (1 through 6) that has your desired radio station in

memory.

The display shows the band, preset number and frequency of the station selected.

• If the audio function mode is activated, press FUNC. to return to preset mode.

Frequency Search Function

You can search for a radio station by its frequency.

Press and hold for at least 2 seconds in Radio mode to activate Frequency Search mode.

Turn the Rotary encoder to select the desired frequency.

Press MODE to receive the selected frequency.

• Press and hold for at least 2 seconds in the search mode to cancel. Or, the search mode will be cancelled when an operation has not been performed in 10 seconds.

The RDS (Radio Data System) is a radio information system using the 57 kHz subcarrier of regular FM broadcast. The RDS allows you to receive a variety of information such as traffic information, station names, and to automatically re-tune to a stronger transmitter that is broadcasting the same programme.

Press FUNC. to activate the audio function mode.

Press 1 AF to activate the RDS mode.

Press or to tune in the desired RDS station.

Press 1 AF again to deactivate the RDS mode.

Press FUNC. to activate the preset mode.

• When the “Setting PTY31 (Emergency Broadcast) reception” (refer

to page 9) is set to on, if the unit receives the PTY31 (Emergency Broadcast) signal, the unit will show “ALARM” in the display automatically.

The RDS digital data includes the following:

PI Programme Identification PS Programme Service Name AF List of Alternative Frequencies TP Traffic Programme TA Traffic Announcement PTY Programme Type EON Enhanced Other Networks

8-EN

Recalling Preset RDS Stations

Press FUNC. to activate the audio function mode.

Press 1 AF to activate the RDS mode.

Press FUNC. to activate the preset mode.

Make sure that the function mode returns to preset mode, then press the preset button in which your desired RDS station is preset.

If the preset station's signal is weak, the unit automatically searches and tunes to a stronger station in the AF (Alternative Frequencies) list.

If the preset station and the stations in the AF list cannot be received:

When the PI SEEK setting is on (refer to “PI SEEK Setting” on page 9), the unit searches again for a station in the PI (Programme Identification) list. If there are still no stations receivable in the area, the unit displays the frequency of the preset station and the preset no. disappears. If the signal level of the Regional (Local) station being tuned becomes too weak to receive, press the same preset button to tune in a Regional station in other district.

• For presetting the RDS stations, refer to the Radio Operation section. The RDS stations can be preset in the FM1, FM2 and FM3 bands only.

Receiving RDS Regional (Local) Stations

Press MENU to select the SETUP mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the TUNER mode, then press MODE.

Press or to select the “RDS Regional”, then press MODE.

Turn the Rotary encoder to select ON or OFF.

In the OFF mode, the unit automatically keeps receiving the related local RDS station.

Press MENU to select RETURN.

After 2 seconds, the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode.

PI SEEK Setting

Setting PTY31 (Emergency Broadcast) reception

Turn PTY31 (Emergency Broadcast) reception ON/OFF.

Press MENU to select SETUP mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the TUNER mode, then press MODE.

Press or to select the “Alert PTY31”, then press MODE.

Turn the Rotary encoder to select ON or OFF.

If you set to ON, emergency broadcasts are received regardless of source.”ALARM” is displayed during reception.

Press MENU to select RETURN.

After 2 seconds, the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode. When an emergency broadcast is received, the volume level will be automatically changed to the memorized level in the traffic information mode. For details, refer to “Receiving Traffic Information” on page 10.

Setting the Time to automatically Adjust

When you set to ON, the time is automatically adjusted by RDS data.

Press MENU to select the SETUP mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the TUNER mode, then press MODE.

Press or to select the “Auto Clock”, then press MODE.

Turn the Rotary encoder to select ON or OFF.

Press MENU to select the SETUP mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the TUNER mode, then press MODE.

Press or to select the “PI Seek”, then press MODE.

Turn the Rotary encoder to select ON or OFF.

Press MENU to select RETURN.

After 2 seconds, the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode.

Press MENU to select RETURN.

After 2 seconds, the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode.

9-EN

Receiving Traffic Information

Press TA so that the “TA” indicator lights up.

Press or to select your desired traffic information station.

When a traffic information station is tuned in, the “TP” indicator lights up. Traffic information is heard only when it is being broadcast. If traffic information is not being broadcast, the unit is set in the standby mode. When a traffic information broadcast begins, the unit automatically receives it and the display shows “T. INFO”. When the traffic information broadcast is over, the unit will automatically set in the standby mode.

• If the traffic information broadcast signal falls below a certain level, the unit remains in the receiving mode for 1 minute. If the signal remains below a certain level for over 1 minute, the “TA” indicator blinks.

• If you do not want to listen to the traffic information being received, lightly press TA to skip that traffic information message. The TA mode will remain in the ON position to receive the next traffic information message.

• If the volume level is changed while receiving traffic information, the changed volume level will be memorized. When traffic information is received next time, the volume level will be automatically adjusted to the level memorized.

• In the TA mode, the SEEK tuning selects only the TP stations.

PTY (Programme Type) Tuning

Press FUNC. to activate the audio function mode.

Receiving Traffic Information While Playing CD or Radio

Press TA so that the “TA” indicator lights up.

Press or to select a traffic information station if necessary.

When a traffic information broadcast starts, the unit automatically mutes the CD player/changer or the regular FM broadcast. When the traffic information broadcast finishes, the unit automatically returns to the original source play before the traffic information broadcast began.

When traffic information stations cannot be received:

In the tuner mode: When the TP signal can no longer be received for over 1 minute, the “TA” indicator blinks.

In the CD mode: When the TP signal can no longer be received, the traffic information station of another frequency will be selected automatically.

• The receiver is equipped with the EON (Enhanced Other Networks)

function in order to keep track of additional alternate frequencies to the AF list. The “EON” indicator lights up while an RDS EON station is being received. If the station being received does not broadcast the traffic information, the receiver automatically tunes in the related station that broadcasts the traffic information when it occurs.

Press TA to deactivate the Traffic Information mode.

The “TA” indicator goes out.

Press 3 PTY to activate the PTY mode, while the unit is in Radio (FM receiving) mode.

The Programme Type of the station being currently received will be displayed for 10 seconds. If there is no receivable PTY broadcast, “NO PTY” will be displayed for 10 seconds. If no RDS station can be received, the display shows “NO PTY.”

• If no operation is performed within 10 seconds after pressing 3 PTY, the PTY mode will be automatically cancelled.

Press or within 10 seconds after activating the PTY mode to choose the desired programme type while the PTY (programme type) is being displayed.

Each press scrolls the programme type by one.

LIGHT

MUSIC

Press 3 PTY within 10 seconds after selecting the programme type to start searching for a station in the selected programme type.

The chosen programme type display blinks during searching and lights when a station is found.

If no PTY station is found, “NO PTY” will be displayed for 10 seconds.

Press FUNC. to activate the preset mode.

• When the audio function mode is activated, perform the operation.

CLASSIC

MUSIC

OTHERS

MUSIC

Priority News

This function allows you to preset to give priority to the News programme. You will never miss the News programme as the unit automatically gives priority to the News programme whenever it begins broadcasting, and interrupts the programme you are currently listening. This feature is functional when your unit is set to a mode other than the LW and MW modes.

Press FUNC. to activate the audio function mode while the unit is in Radio (FM receiving) mode.

Press NEWS 2 to activate the PRIORITY NEWS mode. The “NEWS” indicator appears in the display.

To disable the PRIORITY NEWS function, press NEWS 2.

• In the PRIORITY NEWS function, unlike in the TA function, the

volume does not increase automatically.

Press FUNC. to activate the preset mode, while the unit is in Radio (FM receiving) mode.

10-EN

Displaying Radio Text

Text messages from a radio station can be displayed.

Press TITLE while receiving FM in the radio mode to select the Radio Text display.

The display will change every time the button is pressed.

If there is PS (Programme Service Name)

CD/MP3/WMA

(OPEN)

Rotary encoder

SOURCE/POWER

PS(Programme Service Name)

(Blank)

PS(Programme Service Name)

CALENDAR/CLOCK

PS(Programme Service Name)

PTY (Programme Type)

Radio Text

PS(Programme Service Name)

(Blank)

* Press and hold TITLE for at least 2 seconds if PS is displayed in the

radio mode, “FREQUENCY” will be displayed for 5 seconds.

If there is no PS (Programme Service Name)

FREQUENCY

(Blank)

FREQUENCY

PTY (Programme Type)

(Blank)

• The “R.TEXT” indicator blinks while receiving Radio Text information. If radio text consists of many characters, the page changes to show further information, regardless of “Scroll Setting (Text Scroll)” (page 20).

• If there is no receivable text information or the unit cannot receive text information properly, nothing will be displayed.

(Blank)

FREQUENCY

CALENDAR/CLOCK

Radio Text

FREQUENCY

(Blank)

MODE

FUNC.

4 5

Playback

Press (OPEN).

The front panel will open.

Insert a disc with the label side facing up.

The disc will be pulled into the unit automatically.

Close the front panel manually. When a disc is already inserted, press SOURCE/POWER to switch to the DISC mode.

The mode will change every time the button is pressed.

TUNER DISC CHANGER* TUNER

* Only when the CD changer is connected

While playing back MP3/WMA, press or to select the desired folder.

Pressing and holding or will change folders continuously.

Press or to select the desired track (file).

Returning to the beginning of the current track (file):

Press .

Fast backward:

Press and hold .

Advancing to the beginning of the next track (file):

Press .

Fast forward:

Press and hold .

TITLE

To pause playback, press / .

Pressing / again will resume playback.

After pressing (OPEN) to open the front panel, press to eject the disc.

• Do not remove a CD during its eject cycle. Do not load more than

one disc at a time. A malfunction may result from doing either.

11-EN

• If the CD does not eject, press and hold for at least 2 seconds.

• The CD-player can play discs containing audio data, MP3 data and WMA data.

• A WMA format file that is protected by DRM (Digital Rights Management) cannot be played back on this unit.

• The track display for MP3/WMA data playback is the file numbers recorded on the disc.

• The playback time may not be correctly displayed when a VBR (Variable Bit Rate) recorded file is played back.

MP3/WMA Play Display

The folder number and file number will be displayed as described below.

File number display

Folder number display

19 20

00:00

Clock display*

* Displayed when “Turning the Clock Display ON/OFF” (page 18) is

set to ON.

• Press TITLE to switch the display. See “Displaying the Text” (page 16) for information about display switching.

M.I.X. (Random Play)

Press 5 in the play or pause mode.

The tracks (files) on the disc will be played back in random sequence.

To cancel M.I.X. play, press 5 again.

CD mode :

: The tracks are played back in random

sequence.

: The tracks on all the CDs in the current

magazine will be played back in the random sequence.

*3When a CD changer equipped with the ALL M.I.X. function is

connected

• If M.I.X. is set to ON during RPT (REPEAT ALL) play in CD

changer mode, M.I.X. will apply to the current disc only.

MP3/WMA mode :

Repeat Play

Press 4 to play back repeatedly the track being played.

The track (file) will be played repeatedly. Press 4 again and select off to deactivate repeat play.

CD mode :

: Only a track is repeatedly played back

: A disc is repeatedly played back

*1When a CD changer is connected

• If REPEAT is set to ON during M.I.X. play in CD changer mode, M.I.X. will apply to the current disc only.

MP3/WMA mode :

: Only a file is repeatedly played back

: Only files in a folder are repeatedly played bac

: A disc is repeatedly played back

*2When an MP3 compatible CD changer is connected

• If a CD changer or an MP3 compatible CD changer is connected: After pressing FUNC. to select the function mode (RPT/M.I.X.), perform the operation within 10 seconds.

: Only files in a folder are played back in

random sequence.

: The files are played back in random

sequence. If an MP3 compatible CD changer is connected, all files in a disc are played back in random sequence, and playback shifts to the next disc.

• If a CD changer or an MP3 compatible CD changer is connected:

After pressing FUNC. to select the function mode (RPT/M.I.X.), perform the operation within 10 seconds.

Searching from CD Text

Tracks can be searched and played by using the CD text on the disc. If a disc is not compatible with text, or a disc is in the changer, searches can be made by track number.

Press during play.

This will set the search mode.

Turn the Rotary encoder to select the desired track, then press MODE.

This will play the selected track.

• Press and hold for at least 2 seconds in the search mode to

cancel. Or, the search mode will be cancelled when an operation has not been performed in 10 seconds.

• CD text search cannot be made during M.I.X. play.

12-EN

File/Folder Name Search (concerning MP3/WMA)

About MP3/WMA

You can display and search the folder and file name while listening to the file currently being played back.

Press to activate Search selection mode during MP3/WMA playback.

Turn the Rotary encoder to select Folder Name Search mode or File Name Search mode, then press

Folder Name Search mode

Turn the Rotary encoder to select the desired folder.

Press / to playback the first file in the selected folder.

• Press and hold for at least 2 seconds in the search mode to cancel. Or, the search mode will be cancelled when an operation has not been performed in 10 seconds.

• While in Folder Name Search mode, press to switch to File Name Search mode.

• “ROOT” is displayed for the root folder which does not have folder name.

• Folder Name search cannot be made during M.I.X. play.

• Press FUNC. in the Search mode to return to the previous step.

• Folder search cannot be performed if the disc only has root folder.

• If there is no file in the folder when selecting the folder search mode,

“NO FILE” will be displayed for 2 seconds.

File Name Search mode

Press or to select another Folder.

Select the desired file by turning the Rotary encoder.

Press MODE to playback the selected file.

• Press and hold for at least 2 seconds in the search mode to cancel. Or, the search mode will be cancelled when an operation has not been performed in 10 seconds.

• File Name search cannot be made during M.I.X. play.

• Press FUNC. in the Search mode to return to the previous step.

CAUTION

Except for private use, duplicating audio data (including MP3/ WMA data) or distributing, transferring, or copying it, whether for free or for a fee, without permission of the copyright holder is strictly prohibited by the Copyright Act and by international treaty.

What is MP3?

MP3, whose official name is “MPEG-1 Audio Layer 3,” is a compression standard prescribed by the ISO, the International Standardization Organization and MPEG which is a joint activity institution of the IEC.

MP3 files contain compressed audio data. MP3 encoding is capable of compressing audio data at extremely high ratios, reducing the size of music files to as much as one-tenth their original size. This is achieved while still maintaining near CD quality. The MP3 format realizes such high compression ratios by eliminating the sounds that are either inaudible to the human ear or masked by other sounds.

What is WMA?

WMA, or “Windows Media™ Audio,” is compressed audio data. WMA is similar to MP3 audio data and can achieve CD quality sound with small file sizes.

Method for creating MP3/WMA files

Audio data is compressed by using MP3/WMA specified software. For details on creating MP3/WMA files, refer to the user’s manual for that software. MP3/WMA files that can be played back by this device have the file extension “mp3” / “wma”. Files with no extension cannot be played back. (WMA ver. 7.1, 8 and 9 are supported)

Supported playback sampling rates and bit rates

MP3

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,

16 kHz, 12 kHz, 11.025 kHz, 8 kHz

Bit rates: 8 - 320 kbps

WMA

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz Bit rates: 48 - 192 kbps

This device may not play back correctly depending on sampling rates.

Quick Search

You can search for tracks (files).

Press and hold for at least 2 seconds in the CD/ Changer/MP3/WMA mode to activate Quick Search mode.

Turn the Rotary encoder to select a desired track (file).

The selected track is played back immediately.

• Press and hold for at least 2 seconds in the search mode to cancel. Or, the search mode will be cancelled when an operation has not been performed in 10 seconds.

ID3 tags/WMA tags

This device supports ID3 tag v1 and v2, and WMA tag. If tag data is in an MP3/WMA file, this device can display the title (track title), artist name, and album name ID3 tag/WMA tag data.

This device can only display single-byte alphanumeric characters (up to 30 for ID3 tags and up to 15 for WMA tags) and the underscore. For non-supported characters, “NO SUPPORT” is displayed. The tag information may not be correctly displayed, depending on the contents.

Producing MP3/WMA discs

MP3/WMA files are prepared, then written to a CD-R or CD-RW using CD-R writing software. A disc can hold up to 510 files/ folders (including Root Folders). However, the maximum number of folders is 255.

13-EN

Media supported

The media that this device can play back are CD-ROMs, CD-Rs, and CD-RWs.

Corresponding File Systems

This device supports discs formatted with ISO9660 Level 1 or Level 2.

Under the ISO9660 standard, there are some restrictions to remember.

The maximum nested folder depth is 8 (including the root directory). The number of characters for a folder/file name is limited.

Valid characters for folder/file names are letters A-Z (all caps), numbers 0-9, and ‘_’ (underscore).

This device also can play back discs in Joliet, Romeo, etc., and other standards that conform to ISO9660. However, sometimes the file names, folder names, etc., are not displayed correctly.

Formats supported

This device supports CD-ROM XA, Mixed Mode CD, Enhanced CD (CD-Extra) and Multi-Session. This device cannot correctly play back discs recorded with Track At Once or packet writing.

Order of files

The unit plays the files in the order that the writing software writes them. Therefore, the playing order may not be the same as the order you input. The playback order of the folders and files is as follows. However, the folder and file playback order differs from the folder and file number indicated on the display.

Terminology

Bit rate

This is the “sound” compression rate specified for encoding. The higher the bit rate, the higher the sound quality, but also the larger the files.

Sampling rate

This value shows how many times per second the data is sampled (recorded). For example, music CDs use a sampling rate of 44.1 kHz, so the sound is sampled (recorded) 44,100 times per second. The higher the sampling rate, the higher the sound quality, but also the larger the volume of data.

Encoding

Converting music CDs, WAVE (AIFF) files, and other sound files into the specified audio compression format.

Tag

Song information such as track titles, artist names, album names, etc., written into MP3/WMA files. MP3: ID3 tag WMA: WMA tag

Root folder

The root folder is found at the top of the file system. The root folder contains all folders and files.

Root folder

Folder MP3/WMA File

14-EN

Sound Setting

SOURCE/POWER MENU

MODE

Adjusting Bass/Treble/Balance (Between Left and Right)/Fader (Between Front and Rear)/Defeat

BANDRotary encoder

Setting the Bass Control

You can change the Bass Frequency emphasis to create your own tonal preference.

Press MENU to select the BASS ENGINE mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the BASS (bass Centre frequency) control mode.

BASS TREBLE

Setting the Bass Centre Frequency

-1 Press SOURCE/POWER to select the desired bass centre frequency.

80Hz 100Hz 120Hz 60Hz 80Hz

Emphasizes the displayed bass frequency ranges.

Press MODE repeatedly to choose the desired mode.

Each press changes the mode as follows:

BASS TREBLE SUBWOOFER* BALANCE FADER

DEFEAT VOLUME BASS

Bass level: –7 ~ +10 Treble level: –7 ~ +7 Subwoofer: 0 ~ +15 Balance: L15 ~ R15 Fader: R15 ~ F15 Defeat: ON/OFF Volum e: 0 ~ 35

• If MODE is not pressed within 5 seconds after selecting the BASS,

TREBLE, BALANCE, FADER, DEFEAT or SUBWOOFER mode, the unit automatically returns to normal mode.

* When the subwoofer mode is set to OFF, its level cannot be adjusted.

Turn the Rotary encoder until the desired sound is obtained in each mode.

By setting Defeat ON, previously adjusted settings of BASS and TREBLE will return to the factory defaults.

• Depending on the connected devices, some functions and display

indications do not work.

Setting the Bass Bandwidth

-2 Press BAND to select the desired bass bandwidth.

Changes the boosted bass bandwidth to wide or narrow. A wide setting will boost a wide range of frequencies above and below the centre frequency. A narrower setting will boost only frequencies near the centre frequency.

Setting the Bass Level

-3*1Turn the Rotary encoder to select the desired bass level (–7~+10).

You can emphasize or weaken the bass level.

Press MENU to select RETURN.

After 2 seconds, the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode.

• If no operation is performed within 60 seconds, the bass control

setting will be turned off automatically.

• The bass level settings will be individually memorized for each

source (FM, MW (LW), CD, etc.) until the setting is changed. The bass frequency and bass bandwidth settings adjusted for one source are effective for all other sources (FM, MW (LW), CD etc.).

• Depending on the connected devices, some functions and display

indications do not work. However, Bass Level is still adjustable if an audio processor with the Bass function is connected.

• This function is inoperable when DEFEAT is set to ON.

• If you press or in the bass control mode, the unit

changes to the treble control mode.

*1The adjustment can also be made by pressing the MODE. Refer to

“Adjusting Bass/Treble/Balance (Between Left and Right)/Fader (Between Front and Rear)/Defeat” (page 15).

15-EN

Setting the Treble Control

You can change the Treble Frequency emphasis to create your own tonal preference.

Press MENU to select the BASS ENGINE mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the TREBLE (treble Centre frequency) control mode.

BASS TREBLE

Setting the Treble Centre Frequency

-1 Press SOURCE/POWER to select the desired treble Centre frequency.

10.0kHz 12.5kHz 15.0kHz 7.5kHz 10.0kHz

Emphasizes the displayed Treble frequency ranges.

Other Functions

TITLEFUNC.

Displaying the Text

Text information, such as the disc name and the track name, will be displayed if playing a CD text compatible disc. It is also possible to display the folder name, the file name, and the tag, etc., while playing MP3/WMA files.

Setting the Treble Level

-2*2Turn the Rotary encoder to select the desired treble level (–7~+7).

You can emphasize the treble level.

Press MENU to select RETURN.

After 2 seconds, the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode.

• If no operation is performed within 60 seconds, the treble control

setting will be turned off automatically.

• The treble level settings will be individually memorized for each

source (FM, MW (LW), CD, etc.) until the setting is changed. The Treble frequency settings adjusted for one source are effective for all other sources (FM, MW (LW), CD, etc.).

• Depending on the connected devices, some functions and display

indications do not work. However, Treble Level is still adjustable if an audio processor with the Treble function is connected.

• This function is inoperable when DEFEAT is set to ON.

• If you press or in the treble control mode, the unit

changes to the bass control mode.

*2The adjustment can also be made by pressing the MODE. Refer to

“Adjusting Bass/Treble/Balance (Between Left and Right)/Fader (Between Front and Rear)/Defeat” (page 15).

Turning Loudness On/Off

Loudness introduces a special low- and high-frequency emphasis at low listening levels. This compensates for the ear's decreased sensitivity to bass and treble sound.

Press and hold MODE for at least 2 seconds to activate or deactivate the loudness mode.

“((LOUD))” indicator lights.

Press TITLE.

The display will change every time the button is pressed.

The display in Radio mode:

If there is PS (Programme Service Name)

PS(Programme Service Name)

(Blank)

PS(Programme Service Name)

CALENDAR/CLOCK

PS(Programme Service Name)

PTY (Programme Type)

Radio Text

PS(Programme Service Name)

(Blank)

If there is no PS (Programme Service Name)

FREQUENCY

(Blank)

FREQUENCY

PTY (Programme Type)

(Blank)

CALENDAR/CLOCK

FREQUENCY

(Blank)

FREQUENCY

Radio Text

16-EN

The display in CD mode:

TEXT (TRACK NAME)

TRACK NO./ELAPSED TIME

TEXT (DISC NAME)

TEXT (TRACK NAME)

CALENDAR/CLOCK

(Blank)

TEXT (TRACK NAME)

TRACK NO./ELAPSED TIME

The display in MP3/WMA mode:

FILE NAME

ALBUM NAME

SONG NAME

(Blank)

FILE NAME

FOLDER NO./FILE NO./ELAPSED TIME

ARTIST NAME

SONG NAME

CALENDAR/CLOCK

FOLDER NO./FILE NO./ELAPSED TIME

SONG NAME

FOLDER NAME

FILE NAME

*5*5

*1Press and hold TITLE for at least 2 seconds if PS is displayed in the

radio mode, “FREQUENCY” will be displayed for 5 seconds. *2Displayed during playback of a disc with CD Text. *3“ROOT” is displayed for the folder name of the root folder which

does not have folder name. *4ID3 tag/WMA tag

If an MP3/WMA file contains ID3 tag/WMA tag information, the ID3

tag/WMA tag information is displayed (song name, artist name, and

album name). All other tag data is ignored.

2~4

If there is no text information, nothing will be displayed.

*5If “Text Scroll Auto” is set in “Scroll Setting (Text Scroll)” (page 20),

the display cannot be switched by pressing TITLE. The display

contents switch alternately.

About the indication display

When displaying Text, the following indicators are lit according to the mode.

Indicator/Mode CD Mode

—

Text (Disc Name) being displayed

Text (Track Name) being displayed

MP3/WMA

Mode

Folder Name being displyed

Song Name being displayed

Artist Name being displayed

Album Name being displayed

File Name being displayed

——

iPod Mode

—

Song Name being displayed

Artist Name being displayed

Album Name being displayed

—

About “Text”

Text:

Text compatible CDs contain text information such as the disc name and track name. Such text information is referred to as “text.”

• Some characters may not be displayed correctly with this device,

depending on the character type.

• The CD changer must also be CD Text compatible for the Text

information to be displayed.

• When the Scroll Setting (page 20) is set to “Text Scroll Manual,”

press and hold TITLE for at least 2 seconds to scroll the Text information only once (TEXT DISPLAY, FOLDER NAME DISPLAY, FILE NAME DISPLAY or TAG DISPLAY mode,etc.).

• “NO SUPPORT” is displayed when the desired text information

cannot be displayed on this unit.

• The text or tag information may not be correctly displayed,

depending on the contents.

Displaying Time

Press TITLE repeatedly until the time is displayed.

Each press changes the display. For details, see “Displaying the Text” (page 16).

•

Selecting any tuner or CD function while in the clock priority mode will interrupt the time display momentarily. The function selected will be displayed for about 5 seconds before the time returns to the display.

Blackout Mode On and Off (CDA-9857R only)

When Blackout mode is turned on, all display indications on this unit will turn off to reduce power consumption. This additional power enhances the sound quality.

Press and hold FUNC. for at least 2 seconds to activate the blackout mode.

All display indications on this unit will turn off.

• If any button on the unit is pressed during the blackout mode, the

function will be displayed for 5 seconds to show the operation before returning to Blackout mode.

To cancel Blackout mode, press and hold FUNC. for at least 2 seconds.

17-EN

SETUP

You can flexibly customize the unit to suit your own preferences and usage. Choose the SETUP menu from GENERAL Setting, TUNER Setting, etc., to select your desired setting.

SOURCE/POWORRotary encoder

BAND

Press MENU to select RETURN.

After 2 seconds the unit returns to normal mode. Pressing and holding MENU for at least 2 seconds will return to normal mode.

General Setting

GENERAL is selected on the setup main menu in step 2.

Birthday Opening Message Setting (Birthday Set)

mm/dd

By inputting your birthday details, a message can be displayed on that day. Turn the

Rotary encoder

the

Rotary encoder

to set “mm” (Month), then press

again to set “dd” (Date), then press

MODE

. Turn

again.

MODE

A typical SETUP procedure is shown in steps 1 to 5 as follows. See below for further information about each SETUP menu.

Press MENU to select the SETUP mode, then press MODE.

BASS ENGINE SETUP RETURN (OFF) BASS ENGINE

Press or to select the desired item, then press MODE.

(e.g. Select AUDIO)

GENERAL TUNER AUDIO DISPLAY DEMO The SETUP menu of the selected item is displayed.

Press or to select the desired SETUP menu, then press MODE.

(e.g. Select Subwoofer)

GENERAL

Birthday Set Clock Mode Clock Clock Adjust* Beep INT Mute AUX IN (AUX Name)* Digital AUX Power IC Birthday Set

Illumination Play Mode

TUNER

FM Level RDS Regional*3 PI Seek*4 Auto Clock*

Alert PTY31*6 FM Level

AUDIO

Subwoofer (SUBW. System)*7 Subwoofer

DISPLAY

Dimmer Scroll Type Text Scroll Font Select Language Set BGV Select Opening MSG Calendar Dimmer

DEMO

*1Refer to “Setting the Time and Calendar” (page 7). *2Displayed only when AUX IN is ON. *3Refer to “Receiving RDS Regional (Local) Stations” (page 9). *4Refer to “PI SEEK Setting” (page 9). *5Refer to “Setting the Time to automatically Adjust” (page 9). *6Refer to “Setting PTY31 (Emergency Broadcast) reception” (page 9). *7Displayed only when Subwoofer is ON.

Turn the Rotary encoder to change the setting.

(e.g. Select Subwoofer ON or Subwoofer OFF.)

Setting the Clock Display (Clock Mode)

AM (Before noon) 12:00 (12HOUR) / 00:00 (24HOUR) (Initial setting)

You can select the clock display type, 12-hour or 24-hour, depending on your preference.

Turning the Clock Display ON/OFF

Clock ON (Initial Setting) / Clock OFF

When ON is set, the time always appears in the lower left of the display.

Changing Lighting Colour

CDA-9857R: Illumination Blue (Initial setting) / Red

CDA-9856R: Illumination Green (Initial setting) / Red

You can change the lighting colour of the buttons.

CDA-9857R:

Blue Red

CDA-9856R:

Green Red

Playing MP3/WMA Data (Play Mode)

CD-DA (Initial setting) / CDDA&MP3/WMA

This product can playback CDs containing both CD and MP3/WMA data. However, in some situations (some enhanced CDs), playback may be difficult. For these special cases, you can select playback of a single session only, containing the CD data. When a disc contains both CD or the MP3/WMA data, playback starts from the CD data portion of the disc.

CD-DA : Only the CD data in Session 1 can be

played back.

CDDA&MP3/WMA :Both CD data and MP3/WMA file tracks on a

mixed mode, multi-session disc can be played back.

• Perform this setting before inserting a disc. If a disc has already been

inserted, perform the setting after you remove the disc. (If you use an MP3 changer, you have to change discs.)

Sound (Beep) Guide Function

BEEP ON (Initial setting) / BEEP OFF

This function will give audible feedback with varying tones depending upon the button pressed.

Turning Mute Mode On/Off (INT Mute)

INT Mute ON (Initial setting) / INT Mute OFF

If a device having the interrupt feature is connected, audio will be automatically muted whenever the interrupt signal is received from the device.

18-EN

Setting the AUX Mode (V-Link)

AUX IN ON / AUX IN OFF (Initial setting)

You can input TV/video sound by connecting an optional Ai-NET/RCA Interface cable (KCA-121B) or Versatile Link Terminal (KCA-410C) to this component. You can change the AUX name display when AUX IN is set to ON. Press MODE when AUX IN is set to ON, and select the AUX Name mode by pressing or , then press MODE. After that, turn the Rotary encoder to select the desired AUX name. If the KCA-410C is connected, it is possible to select two AUX names.

• Via KCA-410C, up to 2 external devices with RCA output can be

connected. In this case, press SOURCE/POWER to select AUX mode

and then press BAND to select your desired device.

Setting the External Digital Input (Digital AUX)

Digtal AUX ON / Digtal AUX OFF (Initial setting)

When an ALPINE Ai-NET compatible digital audio processor (PXA-H701) and a DVD player (DVE-5207) not compatible with Ai-NET are connected, set Digital AUX to ON to enjoy 5.1-channel surround sound.

• Press SOURCE/POWER, and select the D. AUX mode, and adjust

the volume, etc.

• After input selection is completed, turn the ignition off and back on

again. Setting of the optical digital input switch is completed.

• Depending on the connected audio processor, DVD player sound

may continue to be output, even though the source is changed to

another one. If this occurs, set the DVD player’s power to OFF.

Connecting to an External Amplifier

Power IC ON (Initial setting) / Power IC OFF

When an external amplifier is connected, sound quality can be improved by stopping the power supply of the built-in amplifier.

Power IC OFF : Use this mode when the front and rear pre-

amplifier of the unit are used to drive an external amplifier connected to the speakers. In this setting, the head unit’s internal amplifier has no output to drive speakers.

Tuner Sett ing

TUNER is selected on the setup main menu in step 2.

Adjusting Source Signal Levels

FM Level High (Initial setting) / FM Level Low

If the difference in volume level between the CD player and FM radio is too great, adjust the FM signal level.

Front

Amplifier

Power IC ON : The speakers are driven by the built-in amplifier.

left Front

right

Rear left

Rear right

Speakers

SPEAKER RIGHT FRONT

SPEAKER RIGHT REAR

SPEAKER LEFT REAR

SPEAKER LEFT FRONT

Front right

Rear right

Rear left

Front left

• No sound is produced by the system when the power output is set to

OFF.

19-EN

Audio Setting

AUDIO is selected on the setup main menu in step 2.

Subwoofer On and Off

Subwoofer ON (Initial setting) / Subwoofer OFF

When the subwoofer is on, perform the steps below to adjust the subwoofer output level.

1 In the normal mode, press MODE repeatedly to select the

SUBWOOFER mode.

BASS TREBLE SUBWOOFER BALANCE FADER

DEFEAT VOLUME BASS

2 Adjust the level by turning the Rotary encoder.

Setting the Subwoofer System

System1 (Initial setting) / System2

Select either System1 or System2 for the desired subwoofer effect.

System1: Subwoofer level changes according the main

volume setting.

System2: Subwoofer level change is different from the main

volume setting. For example, even at low volume settings, the subwoofer is still audible.

Display Setting

DISPLAY is selected on the setup main menu in step 2.

Dimmer Control

Dimmer Auto (Initial setting) / Dimmer Manual

Set the Dimmer control to Auto to decrease the illumination brightness of the unit with the head lights of the vehicle ON. This mode is useful if you feel the unit’s backlighting is too bright at night.

• If your vehicle should have a dimmer control for the dashboardlights,

never connect the DIMMER cable (orange) of the radio to this

dimmer control.

Scroll Type Setting

Scroll Type 1 / Scroll Type 2 (Initial setting)

Two types of scroll can be selected. You can select the scroll type you like.

Scroll Type 1 : The characters scroll sequentially,

appearing from the right side of the display.

Scroll Type 2 : The characters are displayed one by one,

and disappear one by one from the left side of the display after the screen is filled up with the characters.

Scroll Setting (Text Scroll)

Text Scroll Auto / Text Scroll Manual (Initial setting)

This CD player can scroll the disc and track names recorded on CD-TEXT discs, as well as the text information of MP3/WMA files, folder names, and tags.

Text Scroll Auto: The CD text information, the text information

of folder and file names, and the tags are scrolled automatically. Also, displayed tag information automatically changes to show any further information without pressing TITLE in the tag information display mode.

Text Scroll Manual: The display is scrolled when a disc is loaded

or when a track is changed, etc. Press and hold TITLE for at least 2 seconds to scroll once.

• In parts of the display, scrolling may not occur, or scroll content may

differ.

Switching the Character Font (Font Select)

TYPE1 (Initial setting) / TYPE2

Two types of font can be selected. You can select the font type you like.

Setting the Russian Font (Language Set)

Language1 (Initial setting) / Language2

Two types of font can be selected.

Language1: Normal font Language2: Russian font

Switching the Animation Display Type (BGV Select)

OFF (Initial setting) / TYPE1 / TYPE2 / TYPE3 / TYPE4

You can select from 4 types of animation display for the display background.

Opening Message ON/OFF Setting

Opening MSG ON / Opening MSG OFF (Initial setting)

This unit includes a special message feature with various patterns, which when enabled displays opening messages for certain occasions. For example, when you turn this unit on December 25th (according to the unit’s date setting), a Christmas greeting is displayed if the Opening Message is set to ON.

Setting of Calendar Display Pattern Switching (Calendar)

dd/mm/yyyy (Initial settting) / yyyy/mm/dd / mm/dd/yyyy

You can switch the calendar display pattern to be shown when the time is displayed.

yyyy: shows the year mm: shows the month dd: shows the day

ex. dd/mm/yyyy 25/12/2006

20-EN

Demo Setting

DEMO is selected on the setup main menu in step 2.

Demonstration

Demo ON / Demo OFF (Initial setting)

This unit has a Demonstration feature for the display.

• To quit Demo mode, set to Demo OFF.

iPod™ (Optional)

Rotary encoder

MODE

SOURCE/ POWER

BAND

TITLE

To pause playback, press / .

Pressing / again will resume playback.

• If a song is playing on the iPod when it is connected to the CDA-9857R/CDA-9856R, it will continue playing after the

connection.

• If using the iPod with a changer, the Versatile Link Terminal (KCA-410C) must be used. In this case, press BAND to select the changer mode applicable to the iPod.

Searching for a desired Song

An iPod can contain hundreds of songs. By keeping these songs organized in playlists, the CDA-9857R/CDA-9856R can use these to ease song searches.

An iPod™ can be controlled from the CDA-9857R/CDA-9856R, when connected to an optional ALPINE Interface Adapter for iPod™ (KCA-420i). While connected to the CDA-9857R/CDA-9856R through the KCA-420i, the controls on the iPod™ are disabled.

• For details, refer to the Owner’s Manual of the connected adapter

(KCA-420i).

• For each function, refer to the iPod’s documentation.

About iPods™ usable with this unit

• The unit can be used with third generation and above iPod™, iPod™ photo, iPod™ minis or iPod™ nano. iPod™ Shuffle cannot be used, however.

• Touch wheel or scroll wheel type iPods without the dock connector cannot be connected to the unit.

• The unit can be used with the following iPod versions. Correct function of earlier versions cannot be guranteed.

Third generation iPod:Ver. 2.3 Forth generation iPod:Ver. 3.0.2 iPod photo:Ver. 1.1 iPod mini:Ver. 1.3 iPod nano:Ver. 1.0

• The unit cannot be used with the software versions earlier than “2005-02-22”. For details about “iPod Software Update”, refer to the iPod Instruction Manual.

Playback

Press SOURCE/POWER to switch to the iPod mode.

TUNER DISC iPod TUNER

Press or to select the desired song.

Return to the beginning of the current song:

Press .

Fast backward:

Press and hold .

Advance to the beginning of the next song:

Press .

Fast forward:

Press and hold .

Searching by Playlist

Press to activate the search selection mode.

Turn the Rotary encoder to select the Playlist search mode, then press .

Playlist Artist Album Playlist

Turn the Rotary encoder within 10 seconds, and select a playlist.

Press / to play back a selected playlist.

To search for a song in the selected playlist

1 After selecting the playlist in step 3*1, press to change

to the song search mode of the selected playlist.

2 Turn the Rotary encoder within 10 seconds to select a

song and press MODE. The selected song is played back.

• Press and hold for at least 2 seconds in the search mode to cancel

the search mode.

• All songs in the iPod are played back by selecting the stored “iPod

name” in step 3*1.

• Playlist search cannot be made during M.I.X. play.

Searching by artist name

Press to activate the search selection mode.

Turn the Rotary encoder to select the Artist search mode, then press .

Playlist Artist Album Playlist

Turn the Rotary encoder within 10 seconds, and select an artist.

Press / to play back all songs of the selected artist.

To search for an album of the selected artist

1 After selecting the artist in step 3*2, press to change

to the album search mode of the selected artist.

2*1Turn the Rotary encoder within 10 seconds to select an

album.

3 Press / to play back all songs of the selected

album.

21-EN

To search for a song of the selected album

1 After selecting the album in step 2*1, press to change

to the song search mode of the selected album.

2 Turn the Rotary encoder within 10 seconds to select a

song and press MODE. The selected song is played back.

• Press and hold for at least 2 seconds in the search mode to cancel

the search mode.

• If you choose ALL in step 3*2, and you press /, all songs in

iPod are played back. If you choose ALL, and you press , the Album search mode for all artists is activated.

• If you choose ALL in step 2*1, and you press /, all songs of the

selected artist are played back. If you choose ALL, and you press , the Song search mode for the selected artist is activated.

• Artist name search cannot be made during M.I.X. play.

Searching by album name

Press to activate the search selection mode.

Turn the Rotary encoder to select the Album search mode, then press .

Playlist Artist Album Playlist

Turn the Rotary encoder within 10 seconds, and select an album.

Press / to play back all songs of the selected album.

To search for a song of the selected album

1 After selecting the album in step 3*3, press to change

to the song search mode of the selected album.

2 Turn the Rotary encoder within 10 seconds to select a

song and press MODE. The selected song is played back.

• Press and hold for at least 2 seconds in the search mode to cancel

the search mode.

• If you choose ALL in step 3*3, and you press /, the search mode

is cancelled. If you choose ALL, and you press , the Song search mode for all albums is activated.

• Album name search cannot be made during M.I.X. play.

Random Play Shuffle (M.I.X.)

The Shuffle function of the iPod is displayed as M.I.X. on the CDA-9857R/CDA-9856R.

Shuffle Albums (M.I.X. ALBUM):

Select an album randomly in the iPod, and plays back the songs of the album in sequential order. If a song has been selected in the playlist/ artist search mode before selecting Shuffle Album, only the albums within the playlist/artist are selected randomly. The songs of the album are played back sequentially.

Shuffle Songs (M.I.X. ALL):

All songs in the iPod are played back in random sequence. If a song has been selected in the playlist/artist search mode before selecting Shuffle Song, only the songs of the playlist/artist/album are played back randomly.

Press 5 .

The songs will be played back in random sequence. M.I.X. M.I.X. (off) M.I.X.

(Shuffle Albums) (Shuffle Songs)

To cancel M.I.X. play, select (off) with the above procedure.

• For details of the search mode, refer to “Searching for a desired

Song” (page 21).

• If a song is selected in the album search mode before selecting

Shuffle (M.I.X.), the songs will not play back randomly even when Shuffle album is selected.

Repeat Play

Only Repeat One is available for the iPod. Repeat One: A single song is repeatedly played back.

Press 4.

The file will be played repeatedly. RPT (off) RPT

(Repeat One)

To cancel repeat play, select (off) with the above procedure.

• During repeat playback, no other songs are selectable by pressing

or .

22-EN

Displaying the Text

You can display the tag information of a song in the iPod.

Press TITLE.

Each press changes the display.

SONG NAME

ELAPSED TIME

ALBUM NAME

SONG NAME

ARTIST NAME

SONG NAME

CALENDAR/CLOCK

Changer (Optional)

SOURCE/POWER

BAND

(Blank)

*1TAG information

If there is no tag information, nothing will be displayed.

*2If “Text Scroll Auto” is set in “Scroll Setting (Text Scroll)” (page 20),

the display cannot be switched by pressing TITLE. The display contents switch alternately.

• When the Scroll Setting (page 20) is set to “Text Scroll Manual,”

press and hold TITLE for at least 2 seconds to scroll the tag information only once.

• Only alphanumeric characters (ASCII) can be displayed.

• If the artist, album or song name, created in iTunes, has too many

characters, songs may not be played back when connected to the adapter. Therefore, a maximum of 250 characters is recommended. The maximum number of characters for the head unit is 64 (64 byte).

• Some characters may not be correctly displayed.

• “NO SUPPORT” is displayed when text information is not

compatible with the CDA-9857R/CDA-9856R.

SONG NAME

ELAPSED TIME

FUNC.

Select buttons (1 through 6)

Controlling CD Changer (Optional)

An optional 6-disc or 12-disc CD Changer may be connected to this unit if it is Ai-NET compatible. With a CD Changer connected to the AiNET input of this unit, the CD Changer will be controllable from this unit. Using the KCA-400C (Multi-Changer Switching device) or the KCA410C (Versatile Link Terminal) multiple changers can be controlled by this unit. See “Multi-Changer Selection” on page 24 for selecting the CD Changers.

• The controls on this unit for CD Changer operation are operative

only when a CD Changer is connected.

• The DVD changer (optional) is controllable from this unit as well as

the CD changer.

Press SOURCE/POWER to activate the CHANGER mode.

The display shows the disc number and track number.

• The source indicator varies depending on the connected source.

• Press BAND to switch the Disc mode in the Changer mode.

Press FUNC. to activate the disc selection mode.

Disc Select Mode

(Disc No.1~6)

Disc Select Mode*

(Disc No.7~12)

RPT/M.I.X. Mode

Press the disc select buttons (1 through 6)

Disc Select Mode

(Disc No.1~6)

corresponding to one of the discs loaded in the CD Changer.

The selected disc number appears in the display and CD playback starts.

• After selecting the desired disc, you can operate in the same way as

for the CD player of this unit. For details, please see the CD/MP3/WMA section.

* When a 12-disc CD changer is connected.

23-EN

Playing MP3 Files with the CD Changer (Optional)

Information

If you connect a changer compatible with MP3, you can play CDROMs, CD-Rs, and CD-RWs containing MP3 files on this unit.

Press SOURCE/POWER to switch to the MP3 Changer mode.

Press FUNC. to activate the disc selection mode.

M.I.X./REPEAT operation mode Disc selection mode M.I.X./REPEAT operation mode

Press any one of the disc select buttons(1 through 6) corresponding to one of the discs

loaded in the CD Changer.

To pause playback, press / .

Pressing / again will resume playback.

• The unit can play discs containing both audio data and MP3 data.

• For operating MP3 with an MP3 compatible CD Changer, refer to

“CD/MP3/WMA” pages 11 to 14.

Multi-Changer Selection (Optional)

Alpine’s Ai-NET system will support up to 6 CD Changers. When operating two or more changers, the KCA-400C (Multi-Changer Switching device) must be used. If you use 1 Switching device, you can connect up to 4 CD Changers. If you use 2 Switching devices, you can connect up to 6 CD Changers. When using KCA-410C (Versatile Link Terminal), you can connect two changers and two external outputs (AUX).

Press SOURCE/POWER on this unit to activate the CD Changer mode.

Press BAND to activate the CD Changer Selection mode.

The CD Changer Selection mode remains active for several seconds.

Press BAND until the desired CD Changer indicator appears on the display.

• If the selected CD Changer is not connected, the display will show

“NO CHANGER (No.).”

• To operate the selected changer, see “CD/MP3/WMA”

(pages 11-14).

• For further details about the external input (AUX) when using KCA-

410C, see “Setting the AUX Mode (V-Link)” on page 19.

In Case of Difficulty

If you encounter a problem, please turn the power off, then on again. If the unit is still not functioning normally, please review the items in the following checklist. This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is properly connected or consult your authorized Alpine dealer.

Basic

No function or display.

• Vehicle’s ignition is off.

- If connected following instructions, the unit will not operate with the vehicle's ignition off.

• Improper power lead (Red) and battery lead (Yellow) connections.

- Check power lead and battery lead connections.

•Blown fuse.

- Check the fuse of the unit; replace with the proper value if

necessary.

• Internal micro-computer malfunctioned due to interference noise etc.

- Press the RESET switch with a ballpoint pen or other pointed

article.

Radio

Unable to receive stations.

• No antenna or open connection in cable.

- Make sure the antenna is properly connected;

replace the antenna or cable if necessary.

Unable to tune stations in the seek mode.

• You are in a weak signal area.

- Make sure the tuner is in the DX mode.

• If the area you are in is a primary signal area, the antenna may not be grounded and connected properly.

- Check your antenna connections; make sure the antenna is

properly grounded at its mounting location.

• The antenna may not be the proper length.

- Make sure the antenna is fully extended; if broken, replace the

antenna with a new one.

Broadcast is noisy.

• The antenna is not the proper length.

- Extend the antenna fully; replace it if it is broken.

• The antenna is poorly grounded.

- Make sure the antenna is grounded properly at its mounting

location.

24-EN

CD Player/Changer not functioning.

• Out of operating temperature range +50°C (+120°F) for CD.

- Allow the vehicle’s interior (or trunk) temperature to cool.

CD playback sound is wavering.

• Moisture condensation in the CD Module.

- Allow enough time for the condensation to evaporate (about 1 hour).

CD insertion not possible.

• A CD is already in the CD player.

- Eject the CD and remove it.

• The CD is being improperly inserted.

- Make sure the CD is being inserted following instructions in the CD Player Operation section.

Unable to fast forward or backward the CD.

• The CD has been damaged.

- Eject the CD and discard it; using a damaged CD in your unit can cause damage to the mechanism.

CD playback sound skips due to vibration.

• Improper mounting of the unit.

- Securely re-mount the unit.

• The disc is very dirty.

- Clean the disc.

• The disc has scratches.

- Change the disc.

• The pick-up lens is dirty.

- Do not use a commercial available lens cleaner disc. Consult your nearest Alpine dealer.

CD playback sound skips without vibration.

• The disc is dirty or scratched.

- Clean the disc; damaged disc should be replaced.

Error displays (built-in CD player only)

• Mechanical error

- Press . After the error indication disappears, insert the disc again. If the above-mentioned solution does not solve the problem, consult your nearest Alpine dealer.

CD-R/CD-RW playback not possible

• Close session (finalization) has not been performed.

- Perform finalization and attempt playback again.

MP3/WMA

Indication for CD Player

• Protective circuit is activated due to high temperature.

- The indication will disappear when the temperature returns to normal operating range.

• No CD is inserted.

- Insert a CD.

• Although a disc is inserted, “No Disc” is displayed and the unit does not start to play or eject the disc.

- Remove the disc by following these steps:

Press the button again for at least 2 seconds. If the disc still does not eject, consult your Alpine dealer.

• Mechanism error.

1) Press the button and eject the CD.

If not ejecting, consult your Alpine dealer.

2) When the error indication remains after ejecting, press the

button again. If the error indication still does not turn off after pressing the

button for a few times, consult your Alpine dealer.

• When “Error” is displayed:

If that the disc cannot be ejected by pressing , press the RESET switch (refer to page 6) and press again. If the disc still cannot be ejected, consult your Alpine dealer.

• A copy-protected WMA file was played back.

- You can only play back non-copy-protected files.

• The disc is not written in a MP3/WMA supported format.

- Use a disc written at the MP3/WMA supported format.

MP3 or WMA is not played back.

• Writing error occurred. The CD format is not compatible.

- Make sure the CD has been written in a supported format. Refer to “About MP3/WMA” (pages 13-14), then rewrite in the format supported by this device.

Audio

The sound is not output from the speakers.

• Unit has no output signal of the internal amplifier.

- Power IC is switched to “ON” (page 19).

25-EN

Indication for CD Changer Indication for iPod Mode

• Protective circuit is activated due to high temperature.

- The indication will disappear when the temperature returns to normal operating range.

• Malfunction in the CD Changer.

- Consult your Alpine dealer. Press the magazine eject button and pull out the magazine. Check the indication. Insert the magazine again. If the magazine cannot be pulled out, consult your Alpine dealer.

• Magazine ejection not possible.

- Press the magazine eject button. If the magazine does not eject, consult your Alpine dealer.

• A disc is left inside the CD Changer.

- Press the eject button to activate the eject function. When the CD Changer finishes the eject function, insert an empty CD magazine into the CD Changer to receive the disc left inside the CD Changer.

• No magazine is loaded into the CD Changer.

- Insert a magazine.

• The iPod is not connected.

- Make sure the iPod is correctly connected (refer to “Connections”). Make sure the cable is not bent excessively.

• The iPod’s battery remains low.

- Refer to the iPod’s documentation and charge the battery.

• There are no songs in the iPod.

- Download songs to the iPod and connect to the adapter.

• Communication error

- Turn the ignition key off, and then set to ON again.

- Check the display by reconnecting between the iPod and the adapter, using the iPod cable.

• Caused by the iPod Software Version not being compatible with the optional adapter KCA-420i.

- Refer to the Owner’s Manual of the optional adapter KCA-

420i, and update the iPod Software Version to be compatible with the optional adapter KCA-420i.

• No indicated disc.

- Choose another disc.

26-EN

Specifications

FM TUNER SECTION

Tuning Range 87.5 – 108.0 MHz Mono Usable Sensitivity 0.7 µV Alternate Channel Selectivity 80 dB Signal-to-Noise Ratio 65 dB Stereo Separation 35 dB Capture Ratio 2.0 dB

MW TUNER SECTION

Tuning Range 531 – 1,602 kHz Sensitivity (IEC Standard) 25.1 µV/28 dB

LW TUNER SECTION

Tuning Range 153 – 281 kHz Sensitivity (IEC Standard) 31.6 µV/30 dB

CD SECTION

Frequency Response 5 – 20,000 Hz (±1 dB) Wow & Flutter (% WRMS) Below measurable limits Total Harmonic Distortion 0.008% (at 1 kHz) Dynamic Range 95 dB (at 1 kHz) Signal-to-Noise Ratio 105 dB Channel Separation 85 dB (at 1 kHz)

PICKUP

Wave length 795 nm Laser power CLASS I

GENERAL

Power Requirement 14.4 V DC

(11–16 V allowable)

Maximum Power Output 60 W × 4 (CDA-9857R)

50 W × 4 (CDA-9856R)

Maximum Pre-Output Voltage 4V/10K ohms (CDA-9857R)

2V/10K ohms (CDA-9856R) Bass +20/-14 dB at 60Hz Treble ±14 dB at 10 kHz Weight 1.6 kg (3 lbs. 8 oz)

CHASSIS SIZE

Width 178 mm (7") Height 50 mm (2") Depth 160 mm (6-1/4")

NOSEPIECE SIZE

Width 170 mm (6-11/16") Height 46 mm (1-13/16") Depth 24 mm (15/16")

• Due to continuous product improvement, specifications and design

are subject to change without notice.

CAUTION

CLASS 1

LASER PRODUCT

(Bottom side of player)

27-EN

Installation and Connections

Before installing or connecting the unit, please read the following and pages 3 and 5 of this manual thoroughly for proper use.

Warning

MAKE THE CORRECT CONNECTIONS.

Failure to make the proper connections may result in fire or product damage.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may result in fire, etc.

BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY TERMINAL.

Failure to do so may result in electric shock or injury due to electrical shorts.

DO NOT SPLICE INTO ELECTRICAL CABLES.

Never cut away cable insulation to supply power to other equipment. Doing so will exceed the current carrying capacity of the wire and result in fire or electric shock.

DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING HOLES.

When drilling holes in the chassis for installation, take precautions so as not to contact, damage or obstruct pipes, fuel lines, tanks or electrical wiring. Failure to take such precautions may result in fire.

DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO MAKE GROUND CONNECTIONS.

Bolts or nuts used for the brake or steering systems (or any other safety-related system), or tanks should NEVER be used for installations or ground connections. Using such parts could disable control of the vehicle and cause fire etc.

KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER VEHICLE OPERATION, SUCH AS THE STEERING WHEEL OR SHIFT LEVER.

Doing so may obstruct forward vision or hamper movement etc. and results in serious accident.

Caution

HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS.

The wiring and installation of this unit requires special technical skill and experience. To ensure safety, always contact the dealer where you purchased this product to have the work done.

USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM SECURELY.

Be sure to use only the specified accessory parts. Use of other than designated parts may damage this unit internally or may not securely install the unit in place. This may cause parts to become loose resulting in hazards or product failure.

ARRANGE THE WIRING SO IT IS NOT CRIMPED OR PINCHED BY A SHARP METAL EDGE.

Route the cables and wiring away from moving parts (like the seat rails) or sharp or pointed edges. This will prevent crimping and damage to the wiring. If wiring passes through a hole in metal, use a rubber grommet to prevent the wire’s insulation from being cut by the metal edge of the hole.

DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST.

Avoid installing the unit in locations with high incidence of moisture or dust. Moisture or dust that penetrates into this unit may result in product failure.

Precautions

•

Be sure to disconnect the cable from the (–) battery post before installing your CDA-9857R/CDA-9856R. This will reduce any chance of damage to the unit in case of a short-circuit.

•

Be sure to connect the colour coded leads according to the diagram. Incorrect connections may cause the unit to malfunction or damage

’

to the vehicle

•

When making connections to the vehicle's electrical system, be aware of the factory installed components (e.g. on-board computer). Do not tap into these leads to provide power for this unit. When connecting the CDA-9857R/CDA-9856R to the fuse box, make sure the fuse for the intended circuit of the CDA-9857R/CDA-9856R has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle. When in doubt, consult your Alpine dealer.

•

The CDA-9857R/CDA-9856R uses female RCA-type jacks for connection to other units (e.g. amplifier) having RCA connectors. You may need an adaptor to connect other units. If so, please contact your authorized Alpine dealer for assistance.

•

Be sure to connect the speaker (–) leads to the speaker (–) terminal. Never connect left and right channel speaker cables to each other or to the vehicle body.

s electrical system.

IMPORTANT

Please record the serial number of your unit in the space provided below and keep it as a permanent record. The serial number or the engraved serial number is located on the bottom of the unit.

28-EN

SERIAL NUMBER: INSTALLATION DATE: INSTALLATION TECHNICIAN: PLACE OF PURCHASE:

Installation

Caution

Do not block the unit’s fan or heat sink, thus preventing air circulation. If blocked, heat will accumulate inside the unit and may cause a fire.

Air ventilation hole

(Rear of CDA-9857R/CDA-9856R)

Accessory List

• Head unit .............................................................................1

• Power cable .........................................................................1

• Mounting sleeve...................................................................1

• Carrying case ......................................................................1

• Rubber Cap .........................................................................1

• Hex Bolt ...............................................................................1

• Screw (M5 × 8) ....................................................................4

• Owner’s Manual.............................................................1 set

• The main unit must be mounted within 35 degrees of the horizontal

plane, back to front.

Less than 35°

Bracket

Rubber Cap (Included)

Hex Bolt (Included)

Dashboard

When your vehicle has the Bracket, mount the long hex bolt onto the rear panel of the CDA-9857R/ CDA-9856R and put the Rubber Cap on the hex bolt. If your vehicle does not have the Mounting Support, reinforce the head unit with the metal mounting strap (not supplied). Connect all the leads of the CDA-9857R/CDA-9856R according to details described in the CONNECTION section.

• For the screw *, provide a proper screw to the chassis installing

location.

Slide the CDA-9857R/CDA-9856R into the

dashboard. When the unit is in place, make sure the locking pins are fully seated in the down position. This can be done by pressing firmly in on the unit while pushing the locking pin down with a small screwdriver. This ensures that the unit is properly locked and will not accidentally come out from the dashboard. Install the Detachable Front Panel.

Lock pin

Removal

1. Remove the detachable front panel.

2. Use a small screwdriver (or similar tool) to push the locking pins to the “up” position (see above drawing). As each pin is unlocked, gently pull out on the unit to make sure it does not re-lock before unlocking the second pin.

3. Pull the unit out, keeping it unlocked as you do so.

Mounting sleeve (Included)

Slide mounting sleeve from main unit (see “Removal” on page 29). Slide the mounting sleeve into the dashboard and fix it with the metal shackles.

Metal Mounting Strap

Hex Nut (M5)

∗

this unit

Screw

Bolt Stud

this unit

Front Frame

Screws (M5 × 8) (Included)

this unit

Mounting Bracket

29-EN

Connections for CDA-9857R

To vehicle Display Interface

Antenna

(Pink/Black) AUDIO INTERRUPT IN

(Blue/White) REMOTE TURN-ON

(Orange) DIMMER

(Red) IGNITION

(Black) GND

(Blue) POWER ANT

BATTERY

(Yellow)

(Green)

(Green/Black)

(White)

(White/Black) (Gray/Black)

(Gray)

(Violet/Black)

(Violet)

JASO Antenna Plug

To vehicle phone

To amplifier or equalizer

To the instrument cluster illumination lead

To power antenna

Ignition Key

Speakers

Rear Left

Front Left

Front Right

Rear Right

ISO Antenna Plug

Battery

30-EN

Ai-NET

NORMEQ/DIV

CD Changer

(Sold Separately)

Speakers

Amplifier

Rear Left

Rear Right

Front Left

Amplifier

Front Right

Amplifier

Subwoofers

*1The label is attached or the bottom of the unit.

Vehicle Display Interface Connector

Outputs Vehicle Display Interface control signals. Connect this to the optional Vehicle Display Interface box. For details about connections, consult your nearest Alpine dealer.

Antenna Receptacle Audio Interrupt In Lead (Pink/Black)

Connect this lead to the Audio Interface output of a cellular phone which provides ground shorting when a call is received.

Remote Turn-On Lead (Blue/White)

Connect this lead to the remote turn-on lead of your amplifier or signal processor.

Dimmer Lead (Orange)

This lead may be connected to the vehicle’s instrument cluster illumination lead. This will enable the vehicle’s dimmer control to dim the backlighting of the unit.

Switched Power Lead (Ignition) (Red)

Connect this lead to an open terminal on the vehicle’s fuse box or another unused power source which provides (+) 12V only when the ignition is turned on or in the accessory position.

Ground Lead (Black)

Connect this lead to a good chassis ground on the vehicle. Make sure the connection is made to bare metal and is securely fastened using the sheet metal screw provided.

Power Antenna Lead (Blue)

Connect this lead to the +B terminal of your power antenna, if applicable.

• This lead should be used only for controlling the vehicle’s power

antenna. Do not use this lead to turn on an amplifier or a signal processor, etc.

Choke Coil with Fuse Holder (15A) Battery Lead (Yellow)

Connect this lead to the positive (+) post of the vehicle’s battery.

ISO Power Supply Connector ISO Connector (Speaker Output) Left Rear (+) Speaker Output Lead (Green) Left Rear (–) Speaker Output Lead (Green/Black) Left Front (+) Speaker Output Lead (White) Left Front (–) Speaker Output Lead (White/Black)

Right Front (–) Speaker Output Lead (Gray/Black) Right Front (+) Speaker Output Lead (Gray) Right Rear (–) Speaker Output Lead (Violet/Black) Right Rear (+) Speaker Output Lead (Violet) Ai-NET Connector

Connect this to the output or input connector of other product (CD changer, Equalizer, iPod adapter,*2 etc.) equipped with Ai-NET.

*2If you connect to the iPod, you need the optional adapter

(KCA-420i). For details on connection, refer to the Owner’s Manual of the KCA-420i.

Steering Remote Control Interface Connector

To steering remote control interface box. For details about connections, consult your nearest Alpine dealer.

Rear Output RCA Connectors

RED is right and WHITE is left.

Front Output RCA Connectors

RED is right and WHITE is left.

Subwoofer Ouput RCA Connectors

RED is right and WHITE is left.

System Switch

When connecting a processor using Ai-NET, place this switch in the EQ/DIV position. When no device is connected, leave the switch in the NORM position.

• Be sure to turn the power off to the unit before changing the switch

position.

Power Supply Connector Ai-NET Cable (Included with CD Changer) RCA Extension Cable (Sold Separately) ISO/JASO Antenna Adaptor (Sold Separately)

An ISO/JASO antenna adapter may be required, depending on the vehicle.

DC/DC Converter

• Do not install the converter at a location subjected to water such as

under the floor mat or air conditioner. This may cause a malfunction.

• Do not bundle the DC/DC converter cable with other audio cables.

Doing so may induce noise into your system.

• Keep the DC/DC converter away from the Antenna cables and the

rear side of the unit, otherwise noise may be generated when receiving radio broadcast.

To prevent noise/interference in the audio system.

• Locate the unit and route the leads at least 10 cm away from the car harness.

• Keep the battery power leads as far away from other leads as possible.

• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.

• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.

• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.

31-EN

Connections for CDA-9856R

To vehicle Display Interface

Antenna

(Pink/Black) AUDIO INTERRUPT IN

(Blue/White) REMOTE TURN-ON

(Orange) DIMMER

(Red) IGNITION

(Black) GND

(Blue) POWER ANT

BATTERY

(Yellow)

(Green)

(Green/Black)

(White)

(White/Black) (Gray/Black)

(Gray)

(Violet/Black)

(Violet)

JASO Antenna Plug

To vehicle phone

To amplifier or equalizer

To the instrument cluster illumination lead

To power antenna

Ignition Key

Speakers

Rear Left

Front Left

Front Right

Rear Right

ISO Antenna Plug

Battery

32-EN

Ai-NET

NORMEQ/DIV

CD Changer

(Sold Separately)

Speakers

Amplifier

Rear Left

Rear Right

Front Left

Amplifier

Front Right

Amplifier

Subwoofers

*1The label is attached or the bottom of the unit.

Vehicle Display Interface Connector

Outputs Vehicle Display Interface control signals. Connect this to the optional Vehicle Display Interface box. For details about connections, consult your nearest Alpine dealer.

Antenna Receptacle Audio Interrupt In Lead (Pink/Black)

Connect this lead to the Audio Interface output of a cellular phone which provides ground shorting when a call is received.

Remote Turn-On Lead (Blue/White)

Connect this lead to the remote turn-on lead of your amplifier or signal processor.

Dimmer Lead (Orange)

This lead may be connected to the vehicle’s instrument cluster illumination lead. This will enable the vehicle’s dimmer control to dim the backlighting of the unit.

Switched Power Lead (Ignition) (Red)

Connect this lead to an open terminal on the vehicle’s fuse box or another unused power source which provides (+) 12V only when the ignition is turned on or in the accessory position.

Ground Lead (Black)

Connect this lead to a good chassis ground on the vehicle. Make sure the connection is made to bare metal and is securely fastened using the sheet metal screw provided.

Power Antenna Lead (Blue)

Connect this lead to the +B terminal of your power antenna, if applicable.

• This lead should be used only for controlling the vehicle’s power

antenna. Do not use this lead to turn on an amplifier or a signal processor, etc.

Battery Lead (Yellow)

Connect this lead to the positive (+) post of the vehicle’s battery.

ISO Power Supply Connector ISO Connector (Speaker Output) Left Rear (+) Speaker Output Lead (Green) Left Rear (–) Speaker Output Lead (Green/Black)

Left Front (+) Speaker Output Lead (White) Left Front (–) Speaker Output Lead (White/Black) Right Front (–) Speaker Output Lead (Gray/Black) Right Front (+) Speaker Output Lead (Gray) Right Rear (–) Speaker Output Lead (Violet/Black) Right Rear (+) Speaker Output Lead (Violet) Ai-NET Connector

Connect this to the output or input connector of other product (CD changer, Equalizer, iPod adapter,*2 etc.) equipped with Ai-NET.

*2If you connect to the iPod, you need the optional adapter (KCA-

420i). For details on connection, refer to the Owner’s Manual of the KCA-420i.

Steering Remote Control Interface Connector

To steering remote control interface box. For details about connections, consult your nearest Alpine dealer.

Fuse Holder (10A) Rear Output RCA Connectors

RED is right and WHITE is left.

Front Output RCA Connectors

RED is right and WHITE is left.

Subwoofer Ouput RCA Connectors

RED is right and WHITE is left.

System Switch

When connecting a processor using Ai-NET, place this switch in the EQ/DIV position. When no device is connected, leave the switch in the NORM position.

• Be sure to turn the power off to the unit before changing the switch

position.

Power Supply Connector Ai-NET Cable (Included with CD Changer) RCA Extension Cable (Sold Separately) ISO/JASO Antenna Adaptor (Sold Separately)

An ISO/JASO antenna adapter may be required, depending on the vehicle.

To prevent noise/interference in the audio system.

• Locate the unit and route the leads at least 10 cm away from the car harness.

• Keep the battery power leads as far away from other leads as possible.

• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.

• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.

• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.

33-EN

CHM-S630

CHA-S634

• CD changer for CDA-9854R/CDA-9852RB/ CDA-9852RR

• CD-Wechsler für CDA-9854R/CDA-9852RB/ CDA-9852RR

• Changeur CD pour CDA-9854R/ CDA-9852RB/CDA-9852RR

• Cambiador de CD para CDA-9854R/ CDA-9852RB/CDA-9852RR

• Caricatore CD per CDA-9854R/ CDA-9852RB/CDA-9852RR

• CD-växlare för CDA-9854R/CDA-9852RB/ CDA-9852RR

CHA-1214

• CD changer for CDA-9854R/CDA-9852RB/ CDA-9852RR

• CD-Wechsler für CDA-9854R/CDA-9852RB/ CDA-9852RR

• Changeur CD pour CDA-9854R/ CDA-9852RB/CDA-9852RR

• Cambiador de CD para CDA-9854R/ CDA-9852RB/CDA-9852RR

• Caricatore CD per CDA-9854R/ CDA-9852RB/CDA-9852RR

• CD-växlare för CDA-9854R/CDA-9852RB/ CDA-9852RR

Alpine CD Changers Give You More!

More musical selections, more versatility, more convenience.

The CHA-S634 is a high-performance 6-disc changer with a new M DAC, CD-R/RW PLAY BACK, MP3 PLAY BACK and CD TEXT. The CHA-1214 Ai-NET model holds 12 discs, and the CHM-S630 M-Bus model is a super-compact 6-disc changer with a CD-R/RW PLAY BACK.

Von Alpine CD-Wechslern haben Sie mehr!

Mehr Musikauswahl, mehr Vielseitigkeit, mehr Komfort.

Der CHA-S634 ist ein Hochleistungs-Wechsler für 6 CDs mit dem neuen M-DAC, mit CD-R/RW- und MP3-Wiedergabefunktion und mit CD-TEXT. Der CHA-1214 ist ein Ai-NET-Modell für 12 CDs. Der M-Bus-kompatible CHM-S630 ist ein superkompakter Wechsler für 6 CDs mit CD-R/RW-Wiedergabefunktion.

Changeurs de CD Alpine : vous avez le choix!

Plus de sélections musicales, plus de souplesse, plus de confort.
