Product Review
Edited by Rick Lindquist, N1RL• Senior Assistant Technical Editor
Alinco DX-77T MF/HF Transceiver
Reviewed by Joe Bottiglieri, AA1GW
ARRL Technical Information Service
Coordinator
With improvements in propagation on
the HF bands over the last few months, stories of wide-open bands and easy DX are
rapidly spreading. If you’re a newcomer
looking to join the fun without cleaning out
the bank account, upgrading from “hollow
state,” or are just considering a new or second HF radio for your shack (or at that second QTH in the woods), the Alinco DX-77T
may be just the ticket. Here’s an economical
HF box in the $1000 price category that
won’t take up a lot of space on the operating
desk but still has plenty to offer.
Already known for its VHF and UHF
products, Alinco entered the HF market in
1995 with the release of the DX-70T. This
compact HF-plus-6 meters transceiver
proved to be a popular choice for mobile,
home station, and portable operation. A subsequent model, the DX-70TH, offered 100
W on 6 meters. With the introduction of the
DX-77T, Alinco now adds a somewhat
larger HF-only transceiver to their lineup.
What’s it Got?
The DX-77T is a 100 W output SSB,
CW, FM and 40 W AM transceiver that
covers 160 through 10 meters and includes
0.5 to 30 MHz general-coverage receiving
capability. It features dual VFOs, split operation, 100 memory channels, band stacking registers, a speech processor, IF shift,
multiple scan options, computer controllability, and a front-facing speaker. But wait!
A built-in CW keyer, 500Hz CW filter, and
menu selectable CTCSS encode for 10meter FM repeater operation also are all
standard features (in the US version). In
comparison, setting CTCSS tones in the
DX-70T required setting DIP switches, and
the earlier radio had no CW keyer.
While Alinco has managed to pack in
some very nice capabilities, they’ve also
kept the front panel surprisingly simple and
functional, with just a few large buttons and
knobs and bold, bright labels. Physically
larger than the current crop of subcompact
base/mobile type HF transceivers on the
market the DX-77T is a more convenient
size for desktop or portable operation.
Many users will welcome the generous dimensions. You could almost operate this
radio with oven mitts on!
Although it’s on the small side, the busy
LCD display offers good contrast and easy
readability. Backlighting is adjustable to
52 June 1998
five brightness levels (or off altogether). In
addition to the operating frequency, the window displays icons for mode, noise blanker,
AGC slow or fast (AGC cannot be disabled),
memory number, VFO A and B, split, narrow CW filter, CTCSS tone state, RIT offset
and low power. A four-section readout indicates the state of the two-stage attenuator/
normal/or 10-dB preamplifier RF gain level.
An LCD bargraph-type S meter indicates
relative power output on transmit.
Up Front
The front panel sports 14 buttons and
four knobs, with one concentric control.
The all-mode
trols are huge by today’s standards,
almost
shift knobs are a concentric pair, mounted
in the upper right corner. Center detents in
their travel indicate zero settings, with RIT
adjustable to approximately ±1.0 kHz. The
RIT function is always available—there’s
no way to clear it or turn it off. Some users
might find this a disadvantage.
SQUELCH and AF GAIN con-
5
/8 inch in diameter! The RIT and IF
BOTTOM LINE
A $1000-class desktop radio, the
DX-77T is easy to use and a moderately good performer with some nice
features you wouldn’t typically expect
at this price.
The large main tuning knob spins
smoothly (some users thought a little too
easily, however), is lightly weighted, and
includes a finger dimple. The tuning rate is
fixed at 2 kHz per knob revolution for
SSB/CW and 10 kHz per revolution for FM/
DIAL LOCK button is located to the
AM. A
lower right of the main knob. For large
changes in frequency, the
used in conjunction with the front panel
and DOWN buttons allows stepping through
the band registers and memory channels, or
frequency changes in 1 MHz or 100 kHz
steps. Smaller mode-related step sizes are
selectable in the set mode. A small frontfacing speaker sends the audio in the right
direction, a very nice arrangement. A jack
for an 8-pin microphone connection and
3.5-mm jacks for an external key or
paddles, an external speaker, and headphones are mounted along the bottom of
the speaker grille.
yellow push button located in the top left
corner. Side-by-side green and red LEDs
just to the left of the display window indicate transmit or receive, with the green
LED showing received signal, and the red
showing transmit, with increasing brightness on ALC peaks. Four large, black,
rectangular buttons form a vertical row to
the left of the main tuning knob. Side-byside white and light green legends above
each button indicate their primary and sec-
POWER ON/OFF switch is a large
The
SELECT button
UP
Table 1
Alinco DX-77T, serial number T000528
Manufacturer’s Claimed Specifications Measured in the ARRL Lab
Frequency coverage: Receive, 0.5 to 30 MHz; As specified.
transmit, 1.8-2, 3.5-4, 7-7.3, 10.1-10.15,
14-14.35, 18.068-18.168, 21-21.45,
24.89-24.99; 28-29.7 MHz.
Size (height, width, depth): 3.9×9.7×10.5 inches; weight, 8.4 pounds.
Power requirement: Receive, 1.1 A (max); transmit, 20 A (max). Receive, 0.8 A; transmit, 16 A. Tested at 13.8 V.
Modes of operation: SSB, CW, AM, FM, WBFM. As specified.
Receiver Receiver Dynamic Testing
SSB/CW sensitivity, bandwidth not specified: 0.5-1.8 MHz, –107 dBm; Minimum discernible signal (noise floor), 500 Hz filter:
1.8-30 MHz, –119 dBm.
AM sensitivity, 10 dB S/N: 0.5-1.8 MHz, 10 µV; 1.8-30 MHz, 2 µV. 10 dB (S+N)/N, 1-kHz tone, 30fi modulation:
FM sensitivity, 12 dB SINAD: 0.5 µV. For 12 dB SINAD:
Blocking dynamic range: Not specified. Blocking dynamic range, 500 Hz filter:
Two-tone, third-order IMD dynamic range: Not specified. Two-tone, third-order IMD dynamic range, 500 Hz filter:
Third-order intercept: Not specified.
Second-order intercept: Not specified. Preamp off, +53 dBm; preamp on, +51.5 dBm.
FM adjacent channel rejection: Not specified. 29 MHz: 60 dB, at 20 kHz channel spacing, preamp on.
FM two-tone, third-order IMD dynamic range: Not specified. 29 MHz: 63 dB* at 20 kHz channel spacing, preamp on.
S-meter sensitivity: Not specified. S9 signal at 14.2 MHz: preamp off, 36 µV; preamp on, 16 µV.
Squelch sensitivity: Not specified. At threshold, preamp on: SSB, 14 MHz, 1.0 µV; FM, 29 MHz, 0.1 µV.
Receiver audio output: 2 W at 10% THD into 8 Ω. 2.1 W at 10% THD into 8 Ω.
IF/audio response: Not specified. Range at –6dB points, (bandwidth):
Spurious and image rejection: 70 dB. First IF rejection, 114 dB; image rejection, 104 dB.
Transmitter Transmitter Dynamic Testing
Power output: SSB, CW, FM: 100 W high, ≈10 W low; CW, SSB, FM, typically 106 W high,
AM, 40 W high, ≈4 W low. 11 W low; AM, typically 42 W high, 6 W low.
Spurious-signal and harmonic suppression: 50 dB (45 dB on 30 M). 52 dB. Meets FCC requirements for spectral purity for equipment in its
SSB carrier suppression: 40 dB. As specified.
Undesired sideband suppression: 50 dB. As specified. >60 dB.
Third-order intermodulation distortion (IMD) products: Not specified. See Figure 1.
CW keyer speed range: Not specified. 6 to 49 WPM.
CW keying characteristics: Not specified. See Figure 2.
Transmit-receive turn-around time (PTT release S9 signal, 19 ms.
to 50 % audio output): Not specified.
Receive-transmit turn-around time (tx delay): Not specified. SSB, 20 ms; FM, 8 ms. Unit is suitable for use on AMTOR.
Composite transmitted noise: Not specified. See Figure 3.
Note: Unless otherwise noted, all dynamic range measurements are taken at the ARRL Lab standard spacing of 20 kHz
∗Measurement was noise-limited at the value indicated.
†
Third-order intercept was determined using S5 reference.
1.0 MHz –127 dBm –129 dBm
3.5 MHz –132 dBm –140 dBm
14 MHz –130 dBm –136 dBm
1.0 MHz 3.2 µV 1.9 µV
3.8 MHz 1.4 µV 0.6 µV
29 MHz 0.7 µV 0.2 µV
3.5 MHz 109 dB* 110 dB*
14 MHz 111 dB* 112 dB*
3.5 MHz 92 dB* 93 dB*
14 MHz 94 dB* 95 dB*
3.5 MHz +12.6 dBm +4.5 dBm
14 MHz +17.3 dBm +9.5 dBm
CW-N (500 Hz filter): 525-1027 Hz (500 Hz);
CW-W: 150- 2288 Hz (2138 Hz);
USB-W: 216-2977 Hz (2761 Hz);
LSB-W: 186-2834 Hz (2648 Hz);
AM: 146-2894 Hz (2748 Hz).
power output class and frequency range.
Preamp off Preamp on
Preamp off Preamp on
Preamp off Preamp on
Preamp off Preamp on
Preamp off Preamp on
Preamp off Preamp on
†
ondary functions. The top button in this row
serves as a function button, allowing access to the secondary functions and the set
mode. The lower three buttons control various memory, VFO and scan features.
There’s a second set of six buttons in two
horizontal rows to the right of the main
tuning knob. The top row contains single
function buttons for
TUNE (for use with an external automatic
SELECT, MODE, and
tuner). The second row are dual function
buttons:
CW filter,
RF/FILTER for RF gain level and
NB/AGC for noise blanker and
automatic gain control fast or slow and
H/L/TONE for power output level and
CTCSS tone. All ten buttons also provide
access to set mode controls, including the
speech processor, display brightness, automatic LSB/USB selection, transmit inhibit,
the step size of the
UP/DOWN buttons, and
several additional settings related to CW
keyer and scan operations. A one page
“Controls Quick Reference” table in the
manual gives a description of the functions
performed by each of these ten buttons in
their primary, secondary and set mode applications. New users will definitely want
to photocopy this chart and keep it handy.
The only part about using this radio that
can be confusing—at least at first—is that
June 1998 53
0
Reference Level: 0 dB PEP
–10
–20
–30
–40
–50
–60
–70
–80
–10 –8 –6 –4 –2 0 2 4 6 8 10
Frequency Offset (kHz)
–60
Reference Level: - 60 dBc/Hz
–70
Vertical Scale: dBc/Hz
–80
–90
–100
–110
–120
–130
–140
2 4 6 8 10 12 14 16 18 20 22
Frequency Sweep: 2 to 22 kHz from Carrier
Figure 1—Worst-case spectral display of
the Alinco DX-77T transmitter during twotone intermodulation distortion (IMD)
testing. The worse-case third-order
product is approximately 30 dB below PEP
output, and the worse-case fifth-order
product is approximately 41 dB down. The
transceiver was being operated at 100 W
output at 21.250 MHz.
you won’t find the set mode functions all in
one place. Once you enter set mode, you’ll
have to push different buttons to access
different “menu” items. There’s a certain
logic to it, however, and after a while, you
will remember which settings reside behind
which buttons on the front panel.
To the Rear!
The back panel has jacks for connection
of the required external 13.8 V dc, 20A
power supply, an SO-239 antenna connection, and an attachment point for station
ground. RCA (phono) jacks for amplifier
relay and ALC controls, a five-conductor
connector for control of an external automatic antenna tuner, and a 3.5 mm
REMOTE
jack for the optional Alinco ERW-4 computer-control interface also are included.
REMOTE jack allows memory cloning
This
between two DX-77Ts. Simply connect the
two radios with a length of cable with
stereo 3.5-mm plugs on either end and activate the clone feature.
Alinco says memory programming and
remote control are on the horizon for the
DX-77T. The software has not yet been developed, however. The control is via a serial
port connection directly from the computer’s
COM port to the stereo
REMOTE
jack on the
rear panel (Alinco supplies the ERW-4 cable
as an option). With suitable software, a user
will be able to set and control most of the
radio’s features including transmit and receive frequencies, output power, scanning
start and stop, priority, split, mode, RF gain,
AGC speed, noise blanker, CTCSS encoder,
tune mode, filter, and various menu functions. The transceiver can report out its
S meter reading, PTT status, squelch status,
RIT status, memory channel information,
split mode, and VFO or memory mode.
Attachment of equipment for operating
the digital modes (RTTY, PACTOR,
AMTOR, etc.) is via the front panel microphone connector. Alinco thoughtfully includes fixed-level audio at this connector for
easy hookup. The manual includes a micro-
54 June 1998
Figure 2—The default CW keying waveform
for the Alinco DX-77T showing the first two
dits in full-break-in (QSK) mode using
external keying. The equivalent keying
speed is 60 wpm. The upper trace is the
actual key closure; the lower trace is the
RF envelope. Horizontal divisions are 10
ms. The transceiver was being operated at
100 W output at 14.2 MHz. This is excellent
keying. The waveform was nearly identical
using semi-break-in mode with the “auto”
delay feature.
phone wiring diagram. Two holes for mounting bracket hardware are on each side of the
cabinet, although no mobile mounting
bracket is currently available from Alinco.
On the Air!
Operating the DX-77T is fairly simple.
A few seconds spent looking over the front
panel and a quick glance at the aforementioned “Quick Reference” table should be
enough to get most operators up and running. Once you have a feel for the interaction between the
SELECT
and UP/
DOWN
buttons, moving between frequencies,
bands, or memory channels is easy. Major
controls on this transceiver are very conveniently located, especially for right handers.
Voice operation is a simple matter of
selecting the mode with a few presses of
MODE button (the DX-77T steps
the
through its modes), tuning to the desired
frequency, setting the volume and squelch
levels, and away you go! Power output
level is limited to two levels: high power is
100 W output; low power is 10 W output
(an internal switch allows switching these
to 50 W and 5 W respectively).
The microphone gain level is factory set.
Those needing to make adjustments for
their individual voice characteristics will
find the location of and adjustment procedures for an internal mike gain control in
the manual’s maintenance chapter, but this
probably will not be necessary. Our reviewers reported very good to excellent transmit audio reports with the included mobile
microphone at the factory gain setting.
While this radio has an audio-level speech
processor, it does not have VOX.
Receive audio reports were mixed. The
included speaker is considerably smaller
than the front-panel grille would suggest.
Most reviewers felt that with the internal
speaker, the audio was somewhat tinnysounding. Predictably, using a larger exter-
Figure 3—Worst-case tested spectral
display of the Alinco DX-77T transmitter
output during composite-noise testing.
Power output is 100 W at 3.5 MHz. The
carrier, off the left edge of the plot, is not
shown. This plot shows composite
transmitted noise 2 to 22 kHz from the
carrier.
nal speaker helped quite a bit. Alinco
located the external speaker jack on the front
panel. While this may be convenient in some
situations, for most station arrangements the
rear panel would be a better site for this jack.
Maybe an additional jack on the back would
provide the ultimate solution.
We had complained some about the effectiveness of the noise blanker in the
DX-70T. Apparently, Alinco listened and
made the noise blanker in the DX-77T
pretty aggressive. It works quite well on a
variety of pulse-type interference—such as
ignition noise—but it can impart some distortion to received signals under certain
band or noise conditions. Overall, though,
it will be an acceptable tradeoff for most
users, we believe.
Several features on this transceiver
make the DX-77T a good choice for the CW
operator. For starters, one of the most desirable CW options, a 500-Hz CW filter, already is installed! We peeked inside and
were pleased to find a real crystal filter, too,
not a ceramic job like the one in the
DX-70T. You can opt to receive CW signals on either side of zero beat—CWU or
CWL. This can help fight interference that
might be on one side or the other of the station you’re trying to copy. You can zero
beat a CW signal either by matching its tone
in the CWU and CWL modes, or by a feature that allows matching the received
signal’s pitch to that of the CW sidetone.
Using the set mode, it’s possible to set the
sidetone pitch anywhere between 400 Hz
and 1000 Hz in 50 Hz increments.
The IF shift control allows minor
changes in the position of the IF filter’s
passband—always an excellent feature for
digging out weak signals under crowded
band conditions.
Radios in this price class typically don’t
include built-in CW keyers, so it was a pleasant surprise to find one in the DX-77T. Nice
going, Alinco! The keyer in this radio will
generate code at between 6 and 50 words per
minute, and it can operate fully automatic
(iambic) as well as semi-automatic (bug
style). Operation with a straight key, of
course, is also possible. Whether you are
connecting a straight key or a set of paddles,
you must use a stereo type plug in the key
jack. Pay close attention to the paddle wiring arrangement. The dot-and-dash connections are opposite to those found as the default settings on radios from other
manufacturers (ie, Kenwood, ICOM, and
Yaesu), and you can’t change this via the
menu, as some radios let you do for “lefthand” and “right-hand” paddles.
Transmit-receive switching for CW can
be set to operate full-break-in, semi-breakin (adjustable to seven different delay
times), or auto break-in, which will automatically adjust the delay time for the keying speed being used.
The DX-77T was a pleasure to use on
CW. With its wide range of interferencefighting capabilities, built-in electronic
keyer, and smooth, multi-adjustable QSK,
it earned high marks from our reviewers.
Entry-class radios with built-in CW features like these could potentially put a dent
in the sales of computer-generated CW
practice programs!
Shortwave and AM broadcast performance also was quite decent. You can select an 8 or 2.7-kHz AM filter bandwidth,
and AM tuning step sizes of 1.0, 2.5, 5.0,
9.0 or 10 kHz for the front panel or micro-
UP/DOWN buttons, and scan modes
phone
make cruising for new stations easy. With
the radio’s 100 memory channels, you can
program lots of these and still have plenty
left for your 10-meter FM repeaters and
other favorite ham frequencies.
A few words on our Lab testing results
(see Table 1): The DX-77T stacked up pretty
nicely with other transceivers in the same
general price category. Dynamic range is
always an important consideration. The
higher the numbers, the better the receiver’s
ability to hear a desired signal without being
adversely affected by strong, neighboring
signals (usually exhibited by AGC pumping). In this instance, the DX-77T’s twotone, third-order IMD dynamic range numbers showed up in the low to mid
90s—several dB better than we measured in
the ICOM 706MkII (see “Product Review,”
QST, Jan 1998), the Ten-Tec Scout (see
“Product Review,” QST, Dec 1993), or the
Kenwood TS-50S (see “Product Review,”
QST, Sep 1993). In the IC-706MkII and the
DX-77T, however, the level of measurement
was limited by the transceiver’s phase noise,
although the worst-case phase noise on the
DX-77T was still an improvement over what
we observed on our IC-706MkII.
The DX-77T’s receiver is not quite as
sensitive as the ICOM or the Kenwood,
however, and this results in third-order intercept calculations well into the positive
numbers, preamp off or on.
Just a DX-70T in a New Box?
We had first suspected the DX-77T was
just a DX-70T in a desktop box. The famil-
iar display window and the same integrated
PA-heatsink/rear panel as those on the
DX-70 fueled speculation that Alinco had
just stripped off 6 meters and repackaged
their previous HF offering. Inquiring minds
want to know!
A quick trip across the parking lot to
liberate a DX-70T from one of W1AW’s
guest operating positions, and it was back
to the lab for a closer internal investigation. A few minutes with a screwdriver revealed the truth. While it seems these radios share some of the PA components and
the LCD display, none of the internal
boards was common to both transceivers.
Those who do choose to take a look inside
will be amazed at the amount of unused
space in the DX-77T cabinet!
Modern RF engineering techniques and
miniaturized components have distilled the
amount of actual volume necessary to support the long list of capabilities this transceiver provides to an unbelievably small
level. A telephone answering machine of just
a few years ago would contain twice the
volume of electronics! Lab types gathered
round and proposed various opinions on how
best to occupy the vacant areas of its internal
cavity (battery packs for portable QRP operation, home brew auto antenna tuners,
switching power supplies, transverters, etc).
So, while it was clear that the DX-77T
has borrowed freely from its older sibling,
it’s not really the same radio when you look
under the hood. Also, as we’ve pointed out,
it offers some features the DX-70T does
not. In addition, it provides a rich computer-control interface that was not available on the DX-70T.
Read All About It
The Instruction Manual is excellent—an
improvement from earlier Alinco books, and
generating comments from the reviewers
like “maybe Alinco’s best yet” and “obviously written by hams.” It’s easy to follow
and includes lots of illustrations. A wellorganized table of contents, a “How to Use
this Manual” page with a black page-edge
tab arrangement for quickly locating specific
topics, and a complete index make locating
desired information a snap. Most of the sections on major operating parameters include
a short introduction and explanation of the
particular topic, plus step-by-step examples
to help you along. This is a real boon to
beginners.
In addition to clear, concise instructions
for operating the transceiver, the manual
includes several “tutorials” that give tips to
optimize performance in the radio’s various modes. Newcomers also will find these
a welcome addition to the traditional
manual fare. A maintenance chapter describes the location and adjustment of the
internal controls for microphone gain, the
100 W/50 W maximum output switch, and
CW sidetone and key activation “beep”
volume. The frequency calibration procedure appears as well.
Connection diagrams for Alinco’s optional EDX-1 manual or EDX-2 automatic
antenna tuner also are shown, as well as
wiring instructions for Kenwood’s AT-300
and ICOM’s AH-3 tuner units! A complete—though somewhat difficult to
read—schematic is included. While you
will find some typographical errors in the
manual, they are very minor and don’t distract from the content.
Consensus
The overall impression of those who got
to play with the Alinco DX-77T was that it’s
a terrific “first steps” radio or a fine second
radio. Indeed, some may find it a great
“main” radio. It’s less adaptable to mobile
use than some of the other offerings already
on the market, but it’s not very large nor very
eavy, so it’s good choice for portable use.
h
The inclusion of a CW keyer and a decent narrow CW filter plus speech processing (even though it’s at audio) make this a
slightly better than just the plain-vanilla
starter boxes available just a few years ago.
Some users felt that including a built-in
ac power supply would make the DX-77T a
killer product—sort of the latter-day
equivalent of the Heath HW-16.
With the long list of features already included in the DX-77T, first-time buyers
may be curious as to what additional capabilities they would find in the next step up.
Several other manufacturers offer midlevel radios for an added investment of
$400 to $600. These may include items
such as built-in automatic antenna tuners,
digital signal processing (DSP), SWR metering, CW message memories, voice operated transmit (VOX), remotable faceplates,
and additional IF filtering capabilities. In
addition, manufacturers will usually include a few interesting extended features
that may be unique to their products. While
these certainly may be desirable, none classifies as an absolute necessity for effective
communications.
We also were pleased to report that
everything worked the first time on our
DX-77T, and that we did not encounter any
situations where our unit failed to meet its
published specifications or where it was seriously on the hairy edge of not meeting
them. This increases our confidence in
Alinco’s ability to turn out a radio that you
won’t have to send back to the factory when
it doesn’t work as advertised. Other manufacturers should take notice.
Thanks to Dan Miller, K3UFG, Rick
Lindquist, N1RL, and Mike Tracy,
KC1SX, and Ed Hare, W1RFI of the ARRL
Lab for their contributions to this review.
Manufacturer: Alinco USA, 438
Amapola Ave, Suite 130, Torrance, CA
90501; tel 310-618-8616; fax 310-6188758; http://www.alinco.com. Manufac-
turer’s suggested retail price, DX-77T transceiver, $1059; EMS-14 desk microphone,
$113; ERW-4 computer interface cable, $27;
Alinco DM-340MVT power supply, $199.
June 1998 55
Loading...
