Alcatel 9005X, Pixi 8 3G Quick Start Guide

Quick Start Guide

Thank you for buying ALCATEL ONETOUCH 9005X. We hope you will enjoy your high-quality communication experience.

You have purchased a product which uses the open source (http://opensource.org/) programs mtd, msdosfs, netfilter/ iptables and initrd in object code and other open source programs licensed under the GNU General Public License and Apache License.

We will provide you with a complete copy of the corresponding source codes upon request within a period of three years from the distribution of the product by TCL Communication Ltd..

You may download the source codes from http://sourceforge. net/projects/alcatel/files/. The provision of the source code is free of charge from internet.

English - CJB1BA0ALAAA

Table of contents

1 Your device ��3

1.1 Appearance illustration .......................................................3

1.2 Home screen .........................................................................5

1.3 Apps and widgets ..................................................................9

1.4 Basic operation ....................................................................10

2 Settings ��12

2.1 Device ....................................................................................12

2.2 Personal ...............................................................................13

2.3 System ...................................................................................13

3 Phone call �� 14

3.1 Placing a call .........................................................................14

3.2 Answering or rejecting a call ...........................................15

Safety information ��16 General information ��22 Warranty ��24

This device meets applicable national SAR limits of 2.0 W/kg. SAR values can be found on page 20 of this user guide. When carrying the device or using it while worn on your

www.sar-tick.com

body, either use an approved accessory such as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not using it.

To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.

The tablet contains magnets which may interfere with other devices and items (such as credit card, pacemakers, defibrillators, etc.). Please maintain at least 15 cm of separation between your tablet and the devices/items mentioned above.

Your device ��

1�1 Appearance illustration

Number Function

1 Earphone Interface 2 micro-USB connector/Battery charge 3 IR LED 4 SIM Card and microSD Card 5 Front camera 6 Power key 7 Volume Up/Down 8 Rear camera

Inserting the micro SIM card & the microSD card

Take care to insert your SIM and Micro SD card in the correct direction to avoid damage. Please refer to the following instructions.

1 2

Note

Please charge before first use. Normally, press and hold the Power key will power the tablet on and the Home Screen will show up, but a battery icon will show instead of the Home Screen when the tablet is lack of power, that indicates you should charge before use. Use only charger recommended by TCL Communication Ltd. and its affiliates.

This device cannot be charged through USB computer connection. Please plug in your charger before first usage.

3 4

1�2 Home screen

Your device includes three pages of Home screen giving you more space to add your own favorite apps, folders, and widgets for one-touch access. To switch between screens, sliding your finger to left or right.

1�2�1 Lock/Unlock your screen

Once your device is powered on, it shows a locked screen interface, which is set as default.

Press and slide right the locked screen to unlock, slide left to access camera.

1�2�2 Icons on your screen

Status Bar

Google Search

All Apps

Back

Multi-window

Name Description

Google Search Touch it to access the Google search

Voice Actions Use Voice Actions to watch a video, send

All Apps Touch to show all apps list interface. Back Go back to the previous menu or screen. Home Return to the home screen. Menu key Touch to open a list of actions available in

Multi-window key

engine.

email, set alarm, get directions, etc.

the current screen.

Touch and hold to view recent apps. Touch to display the common use apps bar

for entering the Multi-window.

Voice Actions

Home Menu key

Multi-window

• Touch Multi-window key on the Home Screen to enter the common use apps bar.(Figure 1)

• Touch "More" to display all apps.(Figure 2)

• Select an app and hold to drag in/out the common use

apps bar.(Figure 2)

• Touch the apps to enter Multi-window.(Figure 3)

Figure 1

Figure 2

Figure 3

Touch and drag down the Status bar to open the Quick setting panel or Notification panel. Touch and drag up to close it.

Notification panel

When there are notifications, touch and drag down the Status bar to open the Notification panel and read the detailed information.

Touch to switch to the Quick setting panel

Touch to clear all event– based notifications (other ongoing notifications will remain)

Quick setting panel

You can enable or disable functions or change modes by touching the icons on Quick setting panel.

Touch to switch to the Notification panel

Touch to access Settings, where you can set more items

1�3 Apps and widgets

1�3�1 Apps

The Applications (apps) list contains all pre-embedded and newly installed apps. To access the apps list, touch the all apps key from Home screen.

1�3�2 Widgets

Touch and hold an empty area in the Home screen, or press Menu key and select Add widgets in the popup menu list to access widgets interface.

1�3�3 Get more apps

Touch the Google Play Store icon to get more apps.

1�3�4 Create and manage shortcut on desktop

Touch and hold an icon on All Apps or widgets interface, it will jump to home screen automatically, drag it to the right place you want.

1�3�5 Remove apps icon from desktop

Touch and hold the icon you want to delete from the desktop, drag it right over the " ", which is at the middle

top of the screen.

1�3�6 Uninstall apps

Press to enter all Apps, then touch and hold the Apps icon you want to uninstall, drag it over the , which appears top-left in the desktop.

1�4 Basic operation

1�4�1 Power on your device

Press and hold the Powe r key until the tablet powers on. It will take a few seconds to light up the screen.

1�4�2 Power off your device

•Press and h old the Pow er key abo ut 3 seconds until the

optio ns appe ar, selec t "Power off " to power off your device.

•Press and hold the Pow er key about 10 seconds to shut

down your device.

1�4�3 Stand-by mode

Press Powe r key once to shut down the screen and the product enters stand-by mode.

Note: Without operation, the product will enter stand-by mode automatically. Press Pow er key once to wake it up.

1�4�4 Connecting to a computer via USB

When connecting your device to computer by USB, you can transfer files between your device and the computer.

1�4�5 Change your wallpaper

You can change your wallpaper from the Settings > Display > Wallpaper, select an image , then touch Set wallpaper.

1�4�6 Wi-Fi

To turn Wi-Fi on and connect to a wireless network:

•Touch Wi-Fi icon on Quick setting bar to turn on/off Wi-Fi.

•Select Settings, touch the switch beside Wi-Fi to

turn on/off Wi-Fi.

•Touch a Wi-Fi network to connect. If the network you

selected is secured, you are required to enter a password or other credentials (You may need to contact the network operator for details). When finished, touch Connect.

Tip: To extend the batter y life, turn off Wi-Fi when you're not using it.

1�4�7 Zoom in/out

Draw your fingers apart/together to zoom in/out (Web browser, Gallery etc..).

1�4�8 Palm to lock the screen

When this feature is enabled in the Gesture setting, put your palm on any screen will lock the screen.

Settings ��

2�1 Device

2�1�1 Sound

You can set Volumes, Touch sounds and Screen lock sound to your pre ference with t he Volume u p/down key, or touch S ettings > So und.

2�1�2 Display

Touch Settings > Display, you can see the items:

•Wallpaper Set your wallpaper.

•Brightness Adjust your screen in a comfortable brightness.

•Font size Select a suitable font size for your tablet.

•Sleep Set Screensavers time.

•Daydream Select an animation effect shows in standby

2�1�3 Storage

Touch Settings > Storage to view the memory using status.

2�1�4 Battery

Touch Settings > Battery to check the battery power and its service status.

status.

2�1�5 APPs

Touch Setting > APPs to check the APP status.

2�2 Personal

2�2�1 Language & input

Touch Settings > Language & input to view or set system language and input methods.

•Language Set the system language.

•Keyboard & input

methods

Check and select all the input methods installed in the tablet.

2�2�2 Backup & reset

You can back up settings and other data associated with one or more of your Google Accounts. If you need to replace or factory reset your device, you can restore your data for any accounts that were previously backed up.

Touch Settings > Backup & reset Tips: Please make sure that all the important data have been

backed-up before you run factory data reset, for this function will eraser all apps and data that user installed.

2�3 System

2�3�1 Date & time

Touch Settings > Date & time, to set date, time and format.

2�3�2 About tablet

Touch Settings > About tablet to check legal information, tablet status and software version, etc .

Phone call ��

3�1 Placing a call

You can easily launch a call using Phone. Touch all apps key to enter ALL APPS, then select . Touch to display the keyboard. Enter the desired number from the keyboard directly or select a contact from People or Call log by sliding or touching tabs, then touch to place the call. The number you entered can be saved to People by touching Add to Contacts.

To hang up a call, touch .

Touch to show dial pad

Touch to

access your

call memory

Touch to get more options

3�2 Answering or rejecting a call

When you receive a call, drag the icon rightward to

answer the call, leftward to reject the call, upward to reject the call by sending a preset message.

Safety information ��

We recommend that you read this chapter carefully before using your device. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein.

• TRAFFIC SAFETY

Given that studies show that using a device while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their device when the vehicle is not parked.

When driving, do not use your device or headphone to listen to music or to the radio. Using a headphone can be dangerous and forbidden in some areas. When switched on, your device emits electromagnetic waves that can interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:

- do not place your device on top of the dashboard or within an

airbag deployment area,

- check with your car dealer or the car manufacturer to make sure

that the dashboard is adequately shielded from device RF energy.

• CONDITIONS OF USE

You are advised to switch off the device from time to time to optimize its performance.

Switch the device off before boarding an aircraft.

Switch the device off when you are in healthcare facilities, except in designated areas. As with many other types of equipment now in regular use, these devices can interfere with other electrical or electronic devices, or equipment using radio frequencies.

Switch the device off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, petrol station, or chemical plant, or in any potentially explosive atmosphere.

When the device is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc. In particular when using the device, you should hold it against the ear on the opposite side to the device, if any.

To avoid hearing impairment, move the device away from your ear while using the "hands-free" mode because the amplified volume might cause hearing damage.

Do not let children use the device and/or play with the device and accessories without supervision.

Please note that your device is a unibody device, the back cover and battery are not removable. Do not attempt to disassemble your device. If you disassemble your device the warranty will not apply. Also disassembling the device may damage the battery, and may cause leakage of substances that could create an allergic reaction.

Always handle your device with care and keep it in a clean and dust-free place.

Do not allow your device to be exposed to adverse weather or environmental conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc.). The manufacturer's recommended operating temperature range is -0°C to +45°C.

At over 45°C the legibility of the device’s display may be impaired, though this is temporary and not serious.

Do not open, dismantle or attempt to repair your device yourself.

Do not drop, throw or bend your device.

Do not use the device if the glass made screen is damaged, cracked or broken to avoid any injury.

Do not paint it.

Use only battery chargers and accessories which are recommended by TCL Communication Ltd. and its affiliates and are compatible with your device model. TCL Communication Ltd. and its affiliates disclaim any liability for damage caused by the use of other chargers or accessories.

Remember to make back-up copies or keep a written record of all important information stored in your device.

Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your device or enabling a flashing-lights feature on your device.

Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the device. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions:

- Do not play or use a flashing-lights feature if you are tired or

need sleep.

- Take a minimum of a 15-minute break hourly.

- Play in a room in which all lights are on.

- Play at the farthest distance possible from the screen.

- If your hands, wrists, or arms become tired or sore while playing,

stop and rest for several hours before playing again.

- If you continue to have sore hands, wrists, or arms during or after

playing, stop the game and see a doctor.

When you play games on your device, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow the instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders.

• PRIVACY

Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your device regarding taking photographs and recording sounds with your device. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and duplicate or distribute them, as this may be considered to be an invasion of privacy. It is the user's sole responsibility to ensure that prior authorization be obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your device (including the operator) disclaim any liability which may result from the improper use of the device.

• BATTERY

Please note your tablet is a unibody device, the back cover and battery are not removable. Observe the following precautions for battery use:

- Do not attempt to open the back cover and replace the inner

rechargeable Li-polymer battery. Please contact the dealer to replace it.

- Do not attempt to eject, replace and open battery.

- Do not punctuate the back cover of your device.

- Do not burn or dispose of your device in household rubbish or

store it at temperature above 50°C.

- Dispose of used batteries according to the instructions. Risk of

explosion if battery replaced by an incorrect type.

This symbol on your device, the battery and the accessories means that these products must be taken to collection points at the end of their life:

- Municipal waste disposal centers with specific bins for these items of equipment.

- Collection bins at points of sale.

They will then be recycled, preventing substances being disposed of in the environment, so that their components can be reused.

In European Union countries:

These collection points are accessible free of charge.

All products with this sign must be brought to these collection points.

In non-European Union jurisdictions:

Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead they are to be taken to collection points for them to be recycled.

• CHARGERS

Mains powered chargers will operate within the temperature range of: 0°C to 40°C.

The chargers designed for your device meet with the standard for safety of information technology equipment and office equipment use. They are also compliant to the eco design directive 2009/125/ EC. Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction. They should be used for this purpose only.

The charger shall be installed near the equipment and shall be easily accessible.

• RADIO WAVES

THIS D EVIC E MEE TS INTE RNATION AL GUI DELI NES FO R EXP OSUR E TO RADI O WAVES

Your device i s a radio t ransmitte r and receiver. It is de signe d not to exc eed the l imits f or expo sure to r adio wave s (radio frequen cy ele ctrom agnet ic fie lds) reco mmend ed by international guidelines. The guidelines were developed by an independent scientific organization (ICNIRP) and include a subst anti al safe ty margin designed to a ssure t he safe ty of all per sons, r egard less of age and health. T he radi o wave expos ure guid eline s use a uni t of meas ureme nt know n as the Specific Absorpt ion Rat e, or SA R. The S AR limi t for mobile device s is 2 W/kg .

Tests for SA R are con ducte d using s tand ard oper ating positions with the device transmitting at its highest certified power level in all t ested f reque ncy ban ds. The h ighes t SAR value s under t he ICN IRP gu idelin es for th is devic e model a re:

Maximum SAR for this model and conditions under which

it was recorded:

9005X (Body-worn) 0.715 W/kg

Durin g use, th e actual SAR va lues fo r this dev ice are us ually well be low the values stated a bove. Th is is bec ause, f or purposes of system efficiency and to minimize interference on the ne twork , the op erating power o f your dev ice is autom atica lly dec rease d when fu ll power i s not needed. Th e lower th e power ou tput of t he device, th e lower it s SAR value.

Body- worn SA R testi ng has be en car ried out at a separ ation dist ance of 10 mm. To meet RF ex posur e guidel ines du ring body-worn ope ratio n, the device sho uld be po sitio ned at least this di stan ce away fro m the bod y.

If you are n ot usin g an appro ved acces sory e nsure t hat whate ver product is used is free o f any met al and th at it posit ions th e device t he indicated distan ce away fro m the bod y.

Organizations suc h as the Wor ld Heal th Org aniza tion and the US F ood and Drug Admi nistr ation h ave sug geste d that if peopl e are conc erned a nd want t o reduce t heir ex posur e they could use a hands -free a ccesso ry to ke ep the wi reles s device away from t he head o r body du ring us e, or red uce the amount of time s pent on t he devic e.

•LICENCES

microSD Logo is a trademark.

The Bluetooth word mark and logos are owned by the Bluetooth SIG,

Inc. and any use of such m arks by TCL

Communication Ltd. and its affiliates is under

license. Other trademarks and trade names are those of their respective owners.

9005X Bluetooth Declaration ID

D023680

The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance.

Your device uses non-harmonized frequency and is intended for use in all European countries.

The WLAN can be operated in the EU without restriction indoors, but cannot be operated outdoors in France.

Google, the Google logo, Android, the Android logo, Google Search™, Google Maps™, Gmail™, YouTube, Google Play Store, Google Latitude™ and Hangouts™ are trademarks of Google Inc.

The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License (the text will show when you touch and hold Google legal in Settings > About Tablet > Legal information)

(1)

It may not be available according to the countries.

(1)

General information ��

•Internet addres s: www.alcatelonetouch.com

•Hot Line Number : see "TCL Mobile Services" leaflet or go

to our website.

On our we bsite , you will f ind our FAQ (Frequently A sked Questions) se ction . You can also contact us by e- mail t o ask any questions you may have .

An electronic versi on of thi s user guide is avai lable i n Engli sh and oth er lang uages a ccordi ng to avai labil ity on our serve r:

www�alcatelonetouch�com

Your device i s a transceiver that op erate s on Wi- Fi and Bluetooth with 2.4GHz.

This eq uipme nt is in co mplia nce wit h the ess ential requirements and other relevant provisions of Directive 1999/5/EC , 2011/65/EU and 2009/125/ EC. Th e entire copy of th e Decla ratio n of Conformit y for your d evice ca n be obt ained t hrough o ur website: www.alcatelonetouch.com.

Company Address:

Room 1910-12A , Tower 3, Chin a HK Cit y, 33 Canton Road, Tsimshat sui, Kow loon, H ong Kong

Disclaimer

There m ay be cer tain differ ences b etwee n the user manu al description and the device’s operation, depending on the soft ware re lease o f your dev ice or spe cifi c operator ser vices.

TCL Mobile shall not be held legally responsible for such

differences, if any, nor for their potential consequences, which responsibility shall be borne by the operator exclusively.

This dev ice may co ntain m ateri als, in cludin g appli cation s and soft ware in e xecut able or so urce cod e form, which is su bmitt ed by third p arti es for inc lusio n in this de vice (" Third Pa rty Materials").

All thi rd part y mate rials i n this dev ice are pr ovided "a s is", witho ut warr anty o f any kind , whet her exp ress or im plied , inclu ding the i mplie d warra nties o f merch antab ility, f itness for a particular purpose or use/third party application, interoperabili ty with ot her mat erial s or appl icati ons of the p urcha ser and no ninfri ngemen t of copyr ight . The purc haser u ndert akes t hat TCL Mobile has complied with all quality obligations incumbent upon it a s a manuf actur er of mob ile devic es and dev ices in complying with Intellectual Property rights. TCL Mobile w ill at no sta ge be resp onsib le for the i nabil ity or f ailure of t he Third Part y Mate rials t o oper ate on thi s device o r in inter acti on with any othe r device s of the pu rchas er. To the maxim um exte nt permi tted by l aw, TCL M obile di sclai ms all lia bilit y for any claim s, dem ands, su its or ac tions , and mor e specif ical ly – but not limi ted to – t ort law ac tion s, under a ny theo ry of lia bilit y, arisi ng out of th e use, by w hateve r means , or atte mpts t o use, such Th ird Par ty Mat erial s. More over, the pres ent Thi rd Part y Mater ials , which ar e provide d free of ch arge by TC L Mobi le, may be sub ject to p aid upd ates an d upgrad es in the f uture; TCL Mobil e waives a ny respo nsibi lity re garding such add ition al cost s, which s hall be b orne exclusive ly by the pu rchase r. T he availabil ity of the ap plica tions m ay vary d epend ing on the c ountr ies and t he oper ators wh ere the d evice is u sed; in no ev ent sha ll the lis t of possi ble appl icati ons and so ftw are provi ded wit h the devi ces be consid ered as a n under taki ng from TC L Mobile ; it shal l remai n merel y as infor matio n for the pu rchas er. Therefo re, TCL M obile shall n ot be held r espon sible fo r the lac k of avail abili ty of one o r more ap plicat ions wi shed for by t he purc haser, as it s avail abilit y depen ds on the c ountr y and th e opera tor of the p urcha ser. TCL mobil e reser ves the r ight at any t ime to ad d or remove T hird Part y Mate rials f rom its d evices w ithou t prior no tice; in n o event sh all TCL Mo bile be h eld resp onsib le by the pu rchase r for any cons equen ces tha t such rem oval may h ave on the pu rchas er regar ding the u se or att empt to u se such a pplic ations a nd Third Party Materials.

Accessory

◆ Charger, 5.0V/1.0A

◆ USB cable, 5pins micro-USB

Warranty ��

Your device is warranted against any defect or malfunctioning which may occur in conditions of normal use during the warranty period of twelve (12) months (1) from the date of purchase as shown on your original invoice.

Batteries (2) and accessories sold with your device are also warranted against any defect which may occur during the first six (6) months (1) from the date of purchase as shown on your original invoice.

In case of any defect of your device which prevents you from normal use thereof, you must immediately inform your vendor and present your device with your proof of purchase.

(1) The warranty period may vary depending on your country.

(2) The life of a rechargeable mobile device battery in terms

of conversation time standby time, and total service life, will depend on the conditions of use and network configuration. Batteries being considered expendable supplies, the specifications state that you should obtain optimal performance for your device during the first six months after purchase and for approximately 200 more recharges.

If the defect is confirmed, your device or part thereof will be either replaced or repaired, as appropriate. Repaired device and accessories are entitled to a one (1) month warranty for the same defect. Repair or replacement may be carried out using reconditioned components offering equivalent functionality.

This warranty covers the cost of parts and labor but excludes any other costs.

This warranty shall not apply to defects to your device and/or accessory due to (without any limitation):

1) Non-compliance with the instructions for use or

installation, or with technical and safety standards applicable in the geographical area where your device is used;

2) Connection to any equipment not supplied or not

recommended by TCL Communication Ltd.;

3) Modification or repair performed by individuals not

authorised by TCL Communication Ltd. or its affiliates or your vendor;

4) Modification, adjustment or alteration of software or

hardware performed by individuals not authorized by TCL

Communication Ltd.;

5) Inclement weather, lightning, fire, humidity, infiltration of

liquids or foods, chemical products, download of files, crash, high voltage, corrosion, oxidation…

Your device will not be repaired in case labels or serial numbers (IMEI/SN)have been removed or altered.

There are no express warranties, whether written, oral or implied, other than this printed limited warranty or the mandatory warranty provided by your country or jurisdiction.

In no event shall TCL Communication Ltd. or any of its affiliates be liable for indirect, incidental or consequential damages of any nature whatsoever, including but not limited commercial or financial loss or damage, loss of data or loss of image to the full extent those damages can be disclaimed by law.

Some countries/states do not allow the exclusion or limitation of indirect, incidental or consequential damages, or limitation of the duration of implied warranties, so the preceding limitations or exclusions may not apply to you.

Tablet

TCT Mobile Europe SAS / Deputy General Manager, EMEA.

TCT Mobile Europe SAS -Siège social : 55 Avenue des Champs Pierreux, Immeuble Le Capitole 92000 Nanterre France SAS au capital de 23 031 072 euros -RCS Nanterre B 440 038 222 -Siret 440 038 222 000 38 APE 4652Z

TCT Mobile Europe SAS

55 Avenue des Champs Pierreux,

EC declaration of conformity /Déclaration de conformité CE

Product / Produit :

Product identification / Identification du produit :

We / Nous TCT Mobile Europe SAS 55, avenue des Cham ps Pierreux 92000 Nanterre France

____________________________________________________________________________________________________________________

9005X / ALCATEL ONETOUCH PIXI 3(8) type PIXO 8 3G

Declare under our sole responsibility that the product above mentioned is conform to the applicable essential requirements of the directive 1999/5/EC and that all essential radio test suites have been carried out. Conformity assessment procedure : annex IV of the directive. / déclarons sous notre entière

responsabilité que le produit ci-dessus est en conformité avec les exigences essentielles applicables de la directive 1999/5/CE et que toutes les séries d'essais radio essentielles ont été effectuées. Procédure d'évaluation de conformité : annexe IV de la directive.

Applied standards / Normes appliquées :

- Item 3.1.a ( protection of the health and of the safety of the user ) / Article 3.1.a ( protection de la santé

et de la sécurité de l'utilisateur)

- EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011

- EN 50332-1 :2000/EN 50332-2 :2003

- EN 62209-2 :2010/ EN 62311 :2008/ EN 62479 :2010

- EN 50566 :2013/AC :2014

- Item 3.1.b ( protection requirements with respect to electromagnetic compatibility ) / Article 3.1.b ( exigences de protection en ce qui concerne la compatibilité électromagnétique )

- EN 301489-1 V1.9.2 / EN 301489-3 V1.6.1 / EN 301489-7V1.3.1

- EN 301489-17V2.2.1 / EN 301489-24V1.5.1

- EN 55022:2010/AC:2011 / EN 55024:2010

- EN 61000-3-2:2006+A1:2009+A2:2009 / EN 61000-3-3:2008

- Item 3.2 ( effective use of spectrum so as to avoid harmful interferences ) / Article 3.2 ( utilisation efficace du spectre radioélectrique de façon à éviter les interférences dommageables)

- EN 300440-1 V1.6.1 / EN 300440-2 V1.4.1，

- EN 300328 V1.8.1 / EN 301511 V9.0.2

- EN 301908-1 V6.2.1 / EN301908-2 V6.2.1

This product also conforms to the applicable requirements of following directives, / Ce produit est en

conformité avec la directive,

- directive 2011/65/EU (RoHS This product can connect with a Common Mobile Phone Charger which complies with below standards: (Ce produit peut être utilisé avec un chargeur universel pour téléphone portable conforme aux standards suivants :)

- EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 The chargers delivered with this product also conform to the applicable requirements of the directive 2009/125/EC(Energy Related Product) / Les chargeurs livrés avec ce produit sont en conformité avec la directive 2009/125/EC(écoconception des produits)

Conformity of this product has been reviewed by the following Notified body of directive 1999/5/EC / La

conformité de ce produit a été vérifiée par l’organisme de certification (notify body) suivant.

PHOENIX TESTLAB GmbH Königswinkel 10 D-32825 Blomberg, Germany Identification number: 0700

Date :2014-11-06 Signature

TCT Mobile Europe SAS - Siège social : 55 Avenue des Champs Pierreux, Immeuble Le Capitole 92000 Nanterre France

SAS au capital de 23 031 072 euros - RCS Nanterre B 440 038 222 - Siret 440 038 222 000 38 APE 4652Z

restriction of the use of certain hazardous substances)

Christophe Benoit

Immeuble Le Capitole 92000 Nanterre, France

+33 1 46 52 61 00

ALCATEL is a trademark of Alcatel-Lucent and

is used under license by TCL Communication Ltd..

reserved

TCL Communication Ltd. reserves the right to alter

material or technical specification without prior

notice.
