Alcatel 1V 2020 Instruction Manual
For more information on how to use the phone, please go to www.alcatelmobile.com and download the
complete user manual. The website will also provide you with answers to frequently asked questions, let
you upgrade the software via Mobile Upgrade, and so much more.
Note:
This is a user manual for Alcatel 1V 5007U.
Help
The following resources will provide you with answers to more FAQs
along with additional software, and service information.
Consulting FAQ
Go to
https://www.alcatelmobile.com/support/
Updating your phone’s software
Update through the System update menu on your device.
To download the software update tool onto your PC, go to
https://www.alcatelmobile.com/support/software-drivers/
Finding your serial number or IMEI
You can find your serial number or International Mobile Equipment
Identity (IMEI) on the packaging materials. Alternatively, go to Settings >
System > About phone > Status on your phone.
Obtaining warranty service
First follow the advice in this guide. Then check hotlines and repair centre
information through
https://www.alcatelmobile.com/contact-us/
Viewing legal information
On the phone, go to Settings > System > About phone > Legal information.
Using ONETOUCH Cloud
Open Support Centre, then touch More info. For an online User Centre
tutorial (may not be available in all areas), go to
https://www.alcatelmobile.com/support/faq/
Using other alcatel apps
Go to
https://www.alcatelmobile.com/support/app-services/
1 2
Table of Contents
Safety and use ..................................................................... 6
Radio waves ....................................................................... 16
Licences ...............................................................................21
General information ......................................................... 23
1 Your mobile ................................................................27
1.1 Keys and connectors ......................................27
1.2 Getting started ................................................31
1.3 Home screen ....................................................34
2 Text input ...................................................................44
2.1 Using the onscreen keyboard ......................44
2.2 Text editing .......................................................46
3 Phone, Call logs and Contacts ...............................47
3.1 Phone ................................................................47
3.2 Call logs .............................................................52
3.3 Contacts ............................................................53
4 Messages .................................................................... 60
4.1 Write a new message ....................................60
4.2 Manage messages...........................................62
5 Multimedia applications .........................................63
5.1 Camera ..............................................................63
5.2 Gallery ...............................................................70
5.3 Music .................................................................78
6 Calendar, Clock, and Calculator ............................79
6.1 Calendar ............................................................79
6.2 Clock ..................................................................81
6.3 Calculator ..........................................................84
7 Others ......................................................................... 85
7.1 Kids Mode ........................................................85
7.2 Support Centre ................................................86
7.3 Other applications ..........................................87
8 Google applications ................................................. 88
8.1 Google ...............................................................88
8.2 Gmail ..................................................................88
8.3 Maps ..................................................................89
8.4 YouTube .............................................................89
8.5 Drive ..................................................................89
8.6 Play Movies & TV ...........................................90
8.7 Play Store ..........................................................90
8.8 Duo ....................................................................90
8.9 Photos ...............................................................90
8.10 Keep notes .......................................................91
8.11 Google Assistant .............................................91
8.12 Files ....................................................................92
9 Settings ....................................................................... 93
9.1 Network & internet ........................................93
9.2 Bluetooth & device connection .................98
9.3 Display ............................................................ 101
9.4 Home screen & wallpapers .......................102
9.5 Sound.............................................................. 103
9.6 Advanced features ....................................... 104
9.7 Smart Manager ............................................. 106
9.8 Security ..........................................................106
9.9 Location .........................................................107
9.10 Privacy ............................................................ 107
9.11 Apps ................................................................ 108
9.12 Storage ...........................................................108
9.13 Accounts ........................................................ 108
9.14 Digital Wellbeing & parental controls .....109
9.15 Google ............................................................ 109
9.16 Accessibility ................................................... 109
9.17 System ............................................................ 109
10 Making the most of your phone ........................ 112
10.1 FOTA Upgrade ..............................................112
11 Accessories ............................................................. 113
12 Warranty .................................................................. 114
13 Troubleshooting ..................................................... 117
14 Specifications ......................................................... 126
3 4
www.sar-ck.com
PROTECT YOUR HEARING
To prevent possible hearing damage, do not
listen at high volume levels for long periods.
Exercise caution when holding your phone near
your ear while the loudspeaker is in use.
This product meets applicable national
SAR limits of 2.0 W/kg. The specific
maximum SAR values can be found in
the Radio waves section.
When carrying the product or using it
while worn on your body, either use an
approved accessory such as a holster or
otherwise maintain a distance of 5 mm
from the body to ensure compliance
with RF exposure requirements. Note
that the product may be transmitting
even if you are not making a phone call.
5 6
Safety and use ...............................
We recommend that you read this chapter carefully
before using your phone. The manufacturer disclaims
any liability for damage, which may result as a
consequence of improper use or use contrary to the
instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a phone while
driving a vehicle constitutes a real risk, even when the
hands-free kit is used (car kit, headset, etc.), drivers are
requested to refrain from using their phone when the
vehicle is not parked.
When driving, do not use your phone and headset to
listen to music or to the radio. Using a headset can be
dangerous and is forbidden in some areas.
When switched on, your phone emits electromagnetic
waves that can interfere with the vehicle’s electronic
systems such as ABS anti-lock brakes or airbags. To
ensure that there is no problem:
- Do not place your phone on top of the dashboard or
within an airbag deployment area;
- Check with your car dealer or the car manufacturer to
make sure that the dashboard is adequately shielded
from phone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the phone from time to
time to optimise its performance.
Switch the phone off before boarding an aircraft.
Switch the phone off when you are in healthcare
facilities, except in designated areas. As with many
other types of equipment now in regular use, phones
can interfere with other electrical or electronic devices,
or equipment using radio frequency.
Switch the phone off when you are near gas or
flammable liquids. Strictly obey all signs and instructions
posted in a fuel depot, petrol station, or chemical plant,
or in any potentially explosive atmosphere.
When the phone is switched on, it should be kept
at least 15 cm from any medical device such as a
pacemaker, a hearing aid, or an insulin pump, etc. If you
have a medical device fitted, you should hold the phone
against the ear that is furthest away from the device.
To avoid hearing impairment, pick up the call before
holding your phone to your ear. Also move the phone away
from your ear while using the "hands-free" mode because
the amplified volume might cause hearing damage.
Do not let children use the phone and/or play with the
phone and accessories without supervision.
If your phone has a removable cover, note that your
phone may contain substances that could create an
allergic reaction.
If your phone is a unibody device, the back cover and
battery are not removable. If you disassemble your
phone the warranty will not apply. Disassembling the
phone may damage the battery, and may cause leakage
of substances that could create an allergic reaction.
Always handle your phone with care and keep it in a clean
and dust-free place.
Do not allow your phone to be exposed to adverse
weather or environmental conditions (moisture,
humidity, rain, infiltration of liquids, dust, sea air,
etc.). The manufacturer’s recommended operating
temperature range is 0°C (32°F) to 40°C (104°F).
At over 40°C (104°F) the legibility of the phone’s
display may be impaired, though this is temporary and
not serious.
Do not open, dismantle, or attempt to repair your phone
yourself.
Do not drop, throw, or bend your phone.
To avoid injury, do not use the phone if the glass screen
is damaged, cracked or broken.
Do not paint it.
7 8
Use only batteries, battery chargers, and accessories
which are recommended by TCL Communication Ltd.
and its affiliates and which are compatible with your
phone model. TCL Communication Ltd. and its affiliates
disclaim any liability for damage caused by the use of
other chargers or batteries.
Remember to make backup copies or keep a written
record of all important information stored on your
phone.
Some people may suffer epileptic seizures or blackouts
when exposed to flashing lights, or when playing video
games. These seizures or blackouts may occur even if a
person has never experienced them before. If you have
experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult your doctor
before playing video games on your phone or enabling a
flashing-lights feature on your phone.
Parents should monitor their children’s use of video
games or other features that incorporate flashing
lights on the phones. All persons should discontinue
use and consult a doctor if any of the following
symptoms occur: convulsion, eye or muscle twitching,
loss of awareness, involuntary movements, or
disorientation. To limit the likelihood of such symptoms,
please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are
tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a room in which all lights are on.
- Play at the farthest distance possible from the screen.
- If your hands, wrists, or arms become tired or sore
while playing, stop and rest for several hours before
playing again.
- If you continue to have sore hands, wrists, or arms
during or after playing, stop the game and see a
doctor.
When you play games on your phone, you may
experience occasional discomfort in your hands, arms,
shoulders, neck, or other parts of your body. Follow the
instructions to avoid problems such as tendinitis, carpal
tunnel syndrome, or other musculoskeletal disorders.
9 10
• PRIVACY:
Please note that you must respect the laws and
regulations in force in your jurisdiction or other
jurisdiction(s) where you will use your phone regarding
taking photographs and recording sounds with your
phone. Pursuant to such laws and regulations, it may
be strictly forbidden to take photographs and/or to
record the voices of other people or any of their
personal attributes, and reproduce or distribute them,
as this may be considered to be an invasion of privacy.
It is the user's sole responsibility to ensure that prior
authorisation has been obtained, if necessary, in order
to record private or confidential conversations or take
a photograph of another person; the manufacturer, the
seller or vendor of your phone (including the operator)
disclaim any liability which may result from improper
use of the phone.
• BATTERY:
In accordance with air regulations, the battery of your
product is not charged. Please charge it first.
For a non-unibody device:
Observe the following precautions:
- Do not attempt to open the battery (due to the risk of
toxic fumes and burns).
- Do not puncture, disassemble, or cause a short circuit
in a battery.
- Do not burn or dispose of a used battery in household
rubbish or store it at temperatures above 60°C
(140°F).
Batteries must be disposed of in accordance with
locally applicable environmental regulations. Only
use the battery for the purpose for which it was
designed. Never use damaged batteries or those not
recommended by TCL Communication Ltd. and/or its
affiliates.
For a non-unibody device with a non-removable
battery:
Observe the following precautions:
- Do not attempt to eject, replace or open the battery.
- Do not puncture, disassemble, or cause a short circuit
in the battery.
- Do not burn or dispose of your phone in household
rubbish or store it at temperature above 60°C (140°F).
Phone and battery must be disposed of in accordance
with locally applicable environmental regulations.
For a unibody device:
Observe the following precautions:
- Do not attempt to open the back cover.
- Do not attempt to eject, replace, or open battery.
- Do not puncture the back cover of your phone.
11 12
- Do not burn or dispose of your phone in household
rubbish or store it at temperature above 60°C (140°F).
Phone and battery as a unibody device must be disposed
of in accordance with locally applicable environmental
regulations.
This symbol on your phone, the battery, and the
accessories means that these products must be
taken to collection points at the end of their life:
- Municipal waste disposal centres with specific bins for
these items of equipment.
- Collection bins at points of sale.
They will then be recycled, preventing substances
being disposed of in the environment, so that their
components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these
collection points.
In non-European Union jurisdictions:
Items of equipment with this symbol are not to be
thrown into ordinary bins if your jurisdiction or your
region has suitable recycling and collection facilities;
instead they are to be taken to collection points for
them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE
OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Disposal of the battery within a fire or a hot oven, or
mechanically crushing or cutting the battery, can result
in an explosion.
Leaving the battery in an extremely high temperature
environment can also result in an explosion or the
leakage of flammable liquid or gas.
Similarly, subjecting the battery to extremely low air
pressure may result in an explosion or the leakage of
flammable liquid or gas.
• CHARGERS:
Mains powered chargers will operate within the
temperature range of: 0°C (32°F) to 40°C (104°F).
The chargers designed for your phone meet the standard
for safety of information technology equipment and
office equipment use. They are also compliant with the
ecodesign directive 2009/125/EC. Due to different
applicable electrical specifications, a charger you
purchased in one jurisdiction may not work in another
jurisdiction. They should be used for the purpose of
charging only.
13 14
This device is compatible with the charger, which
complies with the following standards relating to the
Common Mobile Phone Charger:
- EN301 489-34 V2.1.1 Final Draft (2017-04)
- EN 62684:2018
For the 1A charger:
Model: UC11
Input Voltage: 100~240 V
Input AC Frequency: 50/60 Hz
Output Voltage: 5.0 V
Output Current: 1.0 A
Output Power: 5.0 W
Average active efficiency: 74.68%
No-load power consumption: 0.075W
For the 2A charger:
Model: UC13
Input Voltage: 100~240 V
Input AC Frequency: 50/60 Hz
Output Voltage: 5.0 V
Output Current: 2.0 A
Output Power: 10.0 W
Average active efficiency: 83.52%
No-load power consumption: 0.075W
Radio waves ...................................
Proof of compliance with international standards
(ICNIRP) or with European Directive 2014/53/EU
(RED) is required of all phone models before they can
be put on the market. The protection of the health and
safety of the user and any other person is an essential
requirement of these standards and this directive.
THIS DEVICE MEETS INTERNATIONAL GUIDELINES
FOR EXPOSURE TO RADIO WAVES.
Your phone is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure
to radio waves (radio frequency electromagnetic
fields) recommended by international guidelines. The
guidelines were developed by an independent scientific
organisation (ICNIRP) and include a substantial safety
margin designed to ensure the safety of all persons,
regardless of age and health.
The radio wave exposure guidelines use a unit of
measurement known as the Specific Absorption Rate,
or SAR. The SAR limit for mobile devices is 2 W/kg.
Tests for SAR are conducted using standard operating
positions with the device transmitting at its highest
certified power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for this
device model are:
15 16
Maximum SAR for this model and conditions under
which it was recorded
Head SAR
Body-worn
SAR
During use, the actual SAR values for this phone are
usually well below the values stated above. This is
because, for purposes of system efficiency and to
minimise interference on the network, the operating
power of your phone is automatically decreased when
full power is not needed for the call. The lower the
power output of the phone, the lower its SAR value.
Body-worn SAR testing has been carried out at a
separation distance of 5 mm. To meet RF exposure
guidelines during body-worn operation, the phone
should be positioned at least this distance away from
the body.
If you are not using an approved accessory, ensure that
whatever product is used is free of any metal and that
it positions the phone the indicated distance away from
the body.
GSM 900 + WLAN 2.4G 1.21 W/kg
LTE Band 7 + WLAN 2.4G 1.58 W/kg
Organisations such as the World Health Organisation
and the US Food and Drug Administration have stated
that if people are concerned and want to reduce their
exposure they could use a hands-free device to keep
the phone away from the head and body during phone
calls, or reduce the amount of time spent on the phone.
For more information, you can go to www.alcatelmobile.
com.
Additional information about electromagnetic fields
and public health is available on the following site:
http://www.who.int/peh-emf.
Your phone is equipped with a built-in antenna. For
optimal operation, you should avoid touching it or
degrading it.
As mobile devices offer a range of functions, they can
be used in positions other than against your ear. In such
circumstances the phone will be compliant with the
guidelines when used with a headset or USB data cable.
If you are using another accessory ensure that whatever
product is used is free of any metal and that it positions
the phone at least 5 mm away from the body.
17 18
Please note that when using an accessory some of your
personal data may be shared with the main device. It is
your own responsibility to protect your own personal
data, not to share with it with any unauthorised devices
or third party devices connected to yours. For products
with Wi-Fi features, only connect to trusted Wi-Fi
networks. Also when using your product as a hotspot
(where available), ensure your network security. These
precautions will help prevent unauthorised access
to your phone. Your product can store personal
information in various locations including a SIM card,
memory card, and built-in memory. Be sure to remove
or clear all personal information before you recycle,
return, or give away your product. Choose your apps
and updates carefully, and only install them from
trusted locations. Some apps can impact your product’s
performance and/or have access to private information
including account details, call data, location details and
network resources.
Note that any data shared with TCL Communication Ltd.
is stored in accordance with applicable data protection
legislation. For these purposes TCL Communication Ltd.
implements and maintains appropriate technical and
organisational measures to protect all personal data, for
example, against unauthorised or unlawful processing
and accidental loss, destruction or damage, whereby
the measures shall provide a level of security that is
appropriate with regard to:
- the technical possibilities available;
- the costs for implementing the measures;
- the risks involved with the processing of the personal
data; and
- the sensitivity of the personal data processed.
You can access, review, and edit your personal
information at any time by logging into your user
account, visiting your user profile or by contacting us
directly. Should you require us to edit or delete your
personal data, we may ask you to provide us with
evidence of your identity before we can act on your
request.
19 20
Licences ...........................................
microSD logo is a trademark.
The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by TCL Communication
Ltd. and its affiliates is under licence. Other
trademarks and trade names are those of
their respective owners.
Alcatel 5007U Bluetooth Declaration ID
D048576
The Wi-Fi Logo is a certification mark of the
Wi-Fi Alliance.
This equipment may be operated in all
European countries.
This device may be operated without
restrictions in any EU member state.
Google, the Google logo, Android, the
Android logo, Google SearchTM, Google
MapsTM, GmailTM, YouTube, Google Play Store,
and Hangouts
Inc.
TM
are trademarks of Google
The Android robot is reproduced or modified from
work created and shared by Google and used according
to terms described in the Creative Commons 3.0
Attribution License (the text will appear when you touch
Google legal in Settings > System > About phone >
Legal information)
(1)
.
You have purchased a product which uses the open
source (http://opensource.org/) programmes mtd,
msdosfs, netfilter/iptables and initrd in object code and
other open source programs licensed under the GNU
General Public Licence and Apache Licence.
We will provide you with a complete copy of the
corresponding source codes upon request within a
period of three years from the distribution of the
product by TCL Communication Ltd.
You may download the source codes from http://
sourceforge.net/projects/alcatel/files/. The provision
of the source code is free of charge from the internet.
We hereby point out that the end user warranty for
infringement IPR is solely limited to the EU/EEA/
Switzerland.
(1)
May not be available in all countries.
21 22
If and to the extent that the Product is exported,
taken with, or used by the end customer or end user
outside the EU/EEA/Switzerland any responsibility,
warranty or indemnification of the manufacturer and its
suppliers in regard to the Product expires (including any
indemnification in regard to IPR infringement).
General information .....................
• Internet address: www.alcatelmobile.com
• Hotline: See the "SERVICES" leaflet that came with
your phone or go to our website.
• Manufacturer: TCL Communication Ltd.
• Address: 5/F, Building 22E, 22 Science Park East
Avenue, Hong Kong Science Park, Shatin, NT, Hong
Kong
• Electronic labelling path: Touch Settings > System >
Regulatory & safety or press *#07#, to find more
information about labelling
On our website, you will find our FAQ (Frequently
Asked Questions) section. You can also contact us by
email to ask any questions you may have.
This radio equipment operates with the following
frequency bands and maximum radio-frequency power:
GSM 850/900: 33 dBm
(1)
.
GSM 1800/1900: 31 dBm
UMTS B1/2/5/8 (2100/1900/850/900): 23.5 dBm
LTE 1/3/5/7/8/20/28/38/40/B41 (2100/1800/850/
2600/900/800/700/2600/2300/2500): 24 dBm
Bluetooth 2.4GHz band: 9.97 dBm
Bluetooth LE: -3.20 dBm
802.11 b/g/n 2.4GHz band: 14.67 dBm
• Regulatory information
Hereby, TCL Communication Ltd. declares that the
radio equipment of type Alcatel 5007U is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address: http://www.
alcatelmobile.com/EU_doc.
• Additional information
The description of accessories and components,
including software, which allow the radio equipment
to operate as intended, can be obtained in the full text
of the EU declaration of conformity at the following
internet address: http://www.alcatelmobile.com/EU_
doc.
(1)
Depending on country.
23 24
Protection against theft
(1)
Your phone is identified by an IMEI (phone serial
number) shown on the packaging label and in the
phone’s memory. We recommend that you note the
number the first time you use your phone by entering
*#06# and keep it in a safe place. It may be requested by
the police or your operator if your phone is stolen. This
number allows your phone to be blocked preventing a
third person from using it, even with a different SIM
card.
Disclaimer
There may be certain differences between the user
manual description and the phone’s operation,
depending on the software release of your phone or
specific operator services.
TCL Communication Ltd. shall not be held legally
responsible for such differences, if any, nor for their
potential consequences, which responsibility shall
be borne by the operator exclusively. This phone
may contain materials, including applications and
software in executable or source code form, which
have been submitted by third parties for inclusion in
this phone ("Third Party Materials"). All Third Party
Materials in this phone are provided "as is", without
(1)
Contact your network operator to check service
availability.
25 26
warranty of any kind, whether express or implied. The
purchaser undertakes that TCL Communication Ltd. has
complied with all quality obligations incumbent upon
it as a manufacturer of mobile devices and phones
in complying with Intellectual Property rights. TCL
Communication Ltd. will at no stage be responsible for
the inability or failure of the Third Party Materials to
operate on this phone or in interaction with any other
device. To the maximum extent permitted by law, TCL
Communication Ltd. disclaims all liability for any claims,
demands, suits or actions, and more specifically –
but not limited to – tort law actions, under any theory
of liability, arising out of the use, by whatever means, or
attempts to use, such Third Party Materials. Moreover,
the present Third Party Materials, which are provided
free of charge by TCL Communication Ltd., may be
subject to paid updates and upgrades in the future; TCL
Communication Ltd. waives any responsibility regarding
such additional costs, which shall be borne exclusively
by the purchaser. TCL Communication Ltd. shall not
be held responsible for the lack of availability of any
application, as its availability depends on the country
and the operator of the purchaser. TCL Communication
Ltd. reserves the right at any time to add or remove
Third Party Materials from its phones without prior
notice; in no event shall TCL Communication Ltd. be
held responsible by the purchaser for any consequences
of such removal.
Your mobile .............................
1
1.1 Keys and connectors
Headset
connector
The Google
Assistant
Button
Back
button
Micro -USB
connector
Front
camera
Volume
up/down
Power key
Recent
button
Home
button
Back camera
Back flash
Fingerprint
sensor
Back button
• Touch to go back to the previous screen,
or close a dialog box, options menu, the
Notification panel, etc.
Home button
• From any application or screen, touch to
return to the Home screen.
• Long press to turn on Google Assistant. You
can get help such as getting directions and
restaurant information based on the content
detected on the screen.
Recent Apps button
• Touch to view applications you’ve recently
accessed.
27 28
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the popup menu to
select from Restart/Power off/Aeroplane
mode.
• Press and hold the Power key and Volume
down key to take a screenshot.
• Press and hold the Power key for at least 10
seconds to force reboot.
Volume keys
• Adjust the call volume during a phone call.
• Adjust the media volume while listening to
music or a video, or streaming content.
• Adjust the ringtone volume.
• Mute the ringtone of an incoming call.
• While using the Camera app, press the Volume
up or down key to take a photo or touch and
hold to take several photos.
• Double-press the Volume down key to open
the camera.
• Convenient operations
Touch to switch
between Sound,
vibrate and Mute
Touch to adjust the
volume of media,
calls, ringtones,
alarms or notifications
29 30
1.2 Getting started
1.2.1 Setting up
Insert the pin into the hole and pull out the tray.
1
Insert or remove your SIM card or microSD card.
2
Single-SIM
2
Dual SIM
2
1
1
31 32
Your phone only supports nano-SIM cards. Do
not attempt to insert other SIM types like mini
and micro cards as these may cause damage to
your phone.
Charging the battery
You are advised to fully charge the battery ( ).
Charging status is indicated by a percentage displayed
on screen. The percentage increases as the phone is
charged.
To reduce power consumption and energy waste
when the battery is fully charged, disconnect your
charger from the plug; switch off Wi-Fi, GPS,
Bluetooth or background-running applications
when not in use; reduce the backlight time, etc.
1.2.2 Powering on your phone
Hold down the Power key until the phone powers on,
unlock your phone (Swipe, Pattern, PIN, Password,
Fingerprint or Face) if necessary and confirm. The
Home screen is displayed.
1.2.3 Powering off your phone
Press and hold the Power key until options appear, then
select Power off.
1.3 Home screen
You can bring all the items (applications, shortcuts,
folders and widgets) you love or use most frequently
to your Home screen for quick access. Touch the Home
button to switch to the Home screen.
1
2 3
4
5
33 34
Status bar
1
• Status/Notification indicators
• Swipe down to open the Notification panel
Google Search bar
4
• Touch 2 to enter text search screen
• Touch 3 to enter voice search screen
Favourites tray applications
5
• Enter the application
• Long press to move or remove applications
Auto-rotate screen
From the app list, touch Settings > Display > Autorotate screen to enable the function.
1.3.1 Using the touchscreen
Touch
Drag
Long press an item and drag it to another location.
Slide/Swipe
Slide the screen to scroll up and down the applications,
images, and web pages. You can slide the screen
horizontally too.
Flick
Similar to swiping, flicking is a lighter and quicker stroke.
Pinch/Spread
Place two fingers on the screen surface and draw them
apart or together to scale an element on the screen.
To access an application, touch it with your finger.
Long press
To enter the available options for an item, long press
the item. For example, select a contact in Contacts, long
press this contact, an option list will appear.
35 36
Rotate
Automatically change the screen orientation from
portrait to landscape by turning the phone sideways to
have a better screen view.
1.3.2 Status bar
From the Status bar, you can view both phone status
(on the right side) and notification information (on the
left side).
Swipe down the status bar to view notifications and
swipe down again to enter the Quick settings panel.
Swipe up to close it.
Notification panel
Swipe down the Status bar to open the Notification
panel to read detailed information.
Clear all notifications
(ongoing notifications
will remain)
Quick Settings panel
Swipe down the Status bar twice to access the Quick
Settings panel where you can enable or disable functions
or change modes by tapping the icons.
Open Settings, to view the full list
of settings
37 38
Loading...
