586IVX
Rev. 2
System Board
User’s Manual
+
- 32970703 -
FCC Statement on Class B
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the
emission limits.
The manufacturer makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability, quality, or
fitness for any particular purpose. The information in this document is
subject to change without notice. The manufacturer reserves the right to
make revisions to this publication and to make changes to any and/or
all parts of its content, at any time, without obligation to notify any person or entity of such changes. Further, the manufacturer assumes no
responsibility for any errors that may appear in this document.
Table of Contents
Chapter 1: Introduction............................................................ 5
Features and Specifications .................................................. 6
Package Checklist .............................................................. 8
Chapter 2: Hardware Installation ............................................... 9
Preparing the Area.............................................................. 9
Handling the System Board .................................................. 9
Installing the System Board .................................................10
Board Layout ....................................................................12
System Memory ................................................................13
SIMM ........................................................................14
Cache Memory .................................................................16
CPU Installation ................................................................17
Jumper Settings for CPUs ..............................................18
Installing Upgrade CPUs................................................21
Installing A Fan/Heatsink for Cyrix CPUs ...........................23
Built-in Ports.....................................................................25
Serial Ports.................................................................26
PS/2 Mouse Port..........................................................26
Parallel Port ................................................................26
Floppy Disk Drive Controller ...........................................27
IDE Hard Disk Interface .................................................27
Installing Expansion Cards...................................................29
Chapter 3: Software Installation ...............................................31
Award BIOS CMOS Setup Utility ...........................................31
Standard CMOS Setup..................................................32
BIOS Features Setup ....................................................36
Chipset Features Setup .................................................41
Power Management Setup .............................................41
PNP/PCI Configuration Setup..........................................43
Load BIOS Defaults ......................................................45
Load Setup Defaults .....................................................46
Integrated Peripherials...................................................46
Supervisor Password ....................................................49
User Password ............................................................49
IDE HDD Auto Detection................................................50
HDD Low Level Format .................................................52
Save & Exit Setup ........................................................53
Exit Without Saving.......................................................54
Desktop Management Interface (DMI) ....................................56
System Error Report ..........................................................54
IDE Device Drivers.............................................................56
Chapter 4: Troubleshooting Checklist ............................................. 57
Appendix A: Types of Modules ......................................................62
Appendix B: Memory and I/O Maps................................................63
Appendix C: Connector Pin Assignments .......................................65
4
Chapter 1
Introduction
The 586IVX is a Pentium processor-class system board supporting
Intel Pentium Processor with MMX Technology and Intel Pentium processors running at 75MHz, 90MHz, 100MHz, 120MHz, 133MHz,
150MHz, 166MHz and 200MHz frequencies. The 586IV X also supports
Cyrix 6x86™ P120+/P133+/P150+/P166+ and AMD-K5 PR75/PR90/
PR100/PR120/PR133/PR166 processors.
The 586IVX system board can support 8MB to 128MB of system
memory. It is equipped with 4 SIMM sockets using EDO or fast page
mode x32 DRAM. This system board also supports 256KB pipeline
burst SRAM.
The 586IVX design is based on the Peripheral Component Interconnect
(PCI) local bus and Industry Standard Architecture (ISA) standards. It is
equipped with 3 dedicated PCI slots, 3 dedicated 16-bit ISA slots and 1
shared PCI/ISA slot.
The 586IVX is equipped with two NS16C550A-compatible serial ports,
an SPP/ECP/EPP parallel port, a shrouded floppy disk header, and two
shrouded PCI IDE headers with bus mastering capabilities that highly
reduce CPU use during disk transfer. This system board is also
equipped with one PS/2 mouse port, one PS/2 keyboard port, two USB
ports and one IrDA connector for wireless connectivity between your
computer and peripheral devices.
The 586IVX system board is designed to fit into an ATX form factor
case. Using an ATX power supply, you can either shut down your computer by pressing the Power button located on the front bezel of your
computer or by executing the Shut Down command under the Windows
95 operating system.
5
Features and Specifications
Processor
• Intel Pentium Processor with MMX Technology - 166/200
• Intel Pentium 75/90/100/120/133/150/166/200MHz
• Future Pentium OverDrive processor
• Cyrix 6x86™ P120+/P133+/P150+/P166+
• AMD-K5 PR75/PR90/PR100/PR120/PR133/PR166
Chipset
• Intel 82430VX PCIset
Cache Memory
• 256KB pipeline burst, direct map write-back cache installed on the
system board
System Memory
• 8MB to 128MB memory
• Four 72-pin SIMM sockets using EDO or fast page mode x32
DRAM, 60/70ns, 5V
BIOS
• Award BIOS, Windows 95 Plug and Play compatible
• Flash EPROM for easy BIOS upgrades
• Supports DMI function
Energy Efficient Design
• System power management supported
• CPU stopped clock control
• Hardware supports SMI green mode
• Microsoft/Intel APM 1.2 compliant
• External power management switch supported
6
• Soft Power supported
PCI IDE Interface
• PIO Mode 3 and Mode 4 Enhanced IDE (data transfer rate up to
16.6MB/sec.)
• DMA Mode 2 Bus Master IDE (data transfer rate up to 22.2MB/sec.)
• Bus mastering reduces CPU utilization during disk transfer
• ATAPI IDE CD-ROM supported
Integrated I/O
• Two NS16C550A-compatible high speed UARTs
• One SPP/ECP/EPP parallel port
• Supports 360KB, 720KB, 1.2MB, 1.44MB, and 2.88MB floppy drives
CPU Socket
• 321-pin ZIF socket (Intel Socket 7)
Connectors
• 2 USB ports
• 1 connector for IrDA interface
• 2 DB-9 serial ports
• 1 DB-25 parallel port
• 2 IDE connectors
• 1 floppy connector
• 1 modem connector
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• One 20-pin ATX power supply connector
Expansion Slots
• 3 dedicated PCI slots
• 3 dedicated 16-bit ISA slots
• 1 shared PCI/ISA slot
PCB
• 4 layers, ATX form factor
• 30.48cm (12") x 23.04cm (9.07")
7
Package Checklist
The 586IVX package contains the following items:
• The 586IVX system board
• The 586IVX user’s manual
• One 40-pin IDE hard disk cable
• One 34-pin floppy disk drive cable
• One IDE driver diskette
• Five spare jumpers
If any of these items are missing or damaged, please contact your
dealer or sales representative for assistance.
8
Chapter 2
Hardware Installation
This chapter summarizes the steps to install the 586IVX system board
into your system unit. It also includes a description of the area in which
you must work and directions for memory installation. Before installing
the system board, obtain the memory you plan to install. Refer to the
System Memory section for the number and type of memory modules
needed for the amount of memory you require.
Preparing the Area
Before unpacking the system board, make sure the location you have
selected is relatively free of dust and static electricity. Excessive exposure to dust, static electricity, direct sunlight, excessive humidity, extreme cold, and water can damage the operational capabilities of your
system board. Avoid placing the unit on surfaces such as carpeted
floors. These areas also attract static electricity which can damage
some circuits on your system board.
Make sure the power source has a properly grounded, three-pronged
socket. It is essential that the power connection be properly grounded
for correct functioning of your system board. For further protection, we
recommend that you use a surge suppressor. This will protect the system board from damage that may result from a power surge on the
electrical line.
Move items that generate magnetic fields away from your system board
since magnetic fields can also damage your system board. Once you
have selected the ideal location, unpack the 586IVX system board carefully.
Handling the System Board
It is quite easy to inadvertently damage your system board even before
installing it in your system unit. Static electrical discharge can damage
computer components without causing any signs of physical damage.
You must take extra care in handling the system board to ensure
against electrostatic build-up.
9
Static Electricity Precautions
1. To prevent electrostatic build-up, leave the board in its anti-static
bag until you are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface with the system
board components facing up.
4. Hold the system board by its edges only. Be careful not to touch
any of the components, contacts or connections, especially gold
contacts, on the board.
5. Avoid touching the pins or contacts on all modules and connectors.
Hold modules and connectors by their ends.
Warning:
Electrostatic discharge (ESD) can damage your processor, disk drives,
add-in boards, and other components. Perform the upgrade instruction
procedures described at an ESD workstation only. If such a station is
not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the system chassis.
If a wrist strap is unavailable, establish and maintain contact with the
system chassis throughout any procedures requiring ESD protection.
Installing the System Board
If you are installing the 586IVX system board, the following outlines the
basic installation steps. Before installing the system board into your system unit, you should prepare the tools you will need.
You will need:
• One medium size, flat-bladed screwdriver
• One medium Phillips screwdriver
• One needle-nosed pliers
• One small nutdriver
1. Unlock your system unit. Turn off the power and disconnect all
power cords and cables.
10
2. Remove the system unit cover. Refer to the manufacturer’s instructions if necessary.
3. Detach all connectors from the old system board and remove expansion cards seated in any expansion slots.
4. Loosen the screws holding the original system board and remove
the board from the system. Save the screws.
5. Remove the 586IVX from its original packing box. Be careful to
avoid touching all connectors and pins on the board. Please refer to
the handling instructions on pages 9-10 for proper handling techniques.
6. Insert the memory modules into the memory banks on the 586IVX. The
quantity and location of the memory modules depends on the
memory configuration and type of modules you intend to use.
7. Insert the cache module, if any, into the cache module slot on the
586IVX. Refer to the Cache Memory section for upgrading your
cache memory.
8. Install the CPU. Be sure pin 1 of the CPU is aligned with pin 1 of
the socket.
9. Set the corresponding jumpers.
10. Install the prepared 586IVX system board into the case and replace
the screws.
11. Reinstall all cards and connectors and replace the system unit
cover. Reconnect all power cords and cables.
If you are using an ATX power supply, install the 20-pin ATX power
cable connector into location PL1 on the system board. The 20-pin
connector can be inserted into PL1 only if pin 1 of the connector is
aligned with pin 1 of PL1.
11
Board Layout
U29
ISA Slot 4
ISA Slot 3
ISA Slot 2
ISA Slot 1
PCI Slot 4
PCI Slot 3
PCI Slot 2
PCI Slot 1
J8
82438VX
J10
JP12
JP11
JP10J9ATX Power Connector
BIOS
82371SB
82438VX
SRAM
JP14
Bank 1
Bank 0
Tag SRAM
82437VX
CN6
CN5J4CN1
Battery
Regulator
Regulator
chip
PL1
I/O
JP1
1 5
1 5
JP4
JP13
JP5
JP2
1 5
SM4
SM3
SM2
SM1
1243
JP3
JP7
Socket 7
Socket 7
1243
62
62
62
Pin 1
Floppy
Secondary IDE
Primary IDE
J13
J11 J12
J3
CN8 J2 CN7
square denotes pin 1
U11 U17
SRAM
12
Jumpers
JP2-JP5, JP7, JP10-JP12
Intel, Cyrix and AMD processors
JP1 - CMOS clear
JP13 - Password clear
Refer to
pages 18-20
page 24
page 25
Sockets
SM1 to SM4 - SIMM sockets
U29 - ZIF socket
Expansion slots
PCI Slots 1, 2, 3, 4 - 32-bit PCI slots
ISA Slots 1, 2, 3, 4 - 16-bit ISA slots
Connectors - refer to pages 69-72
J2 - USB 1 port
J4 - USB 2 port
J8 - IrDA connector
J9 - Fan connector
J10 - FDD connector
J11 - Primary IDE HDD connector
J12 - Secondary IDE HDD connector
J13 - ATX power LED
HD LED
Green LED
ATX power switch
Green switch
Reset switch
Speaker connector
AT power LED/Keylock connector
Refer to
pages 14-15
pages 21-23
Refer to
page 31
page 31
CN1 - PS/2 keyboard port
CN5 - COM 2 serial port
CN6 - COM 1 serial port
CN7 - Parallel printer port
CN8 - PS/2 mouse port
PL1 - ATX power connector
13
System Memory
The 586IVX system board supports One kinds of memory modules:
SIMM. , which uses DRAM. Refer to page 12 for the locations of the nd
SIM sockets.
SIMM
The SIMM (Single In-line Memory Module) sockets are divided into two
banks on the system board, Bank 0 and Bank 1. Each bank consists of
2 SIMM sockets.
You will need either 2 or 4 pieces of SIM modules, depending on the
amount of memory you intend to install. The system board will not work
if you install 1 or 3 pieces. Make sure you insert the same type of
SIMMs in one bank. You can install SIMMs in either of the banks, Bank
0 or Bank 1, but you must populate one bank first before going to the
next bank.
The 586IVX system board can support 8MB to 128MB of memory using
1MBx32, 2MBx32, 4MBx32, or 8MBx32 72-pin SIMMs. The table on the
next page shows the supported SIM modules and their corresponding
memory sizes.
14
SIMMs
1MBx32
2MBx32
4MBx32
8MBx32
Memory Size
4MB
8MB
16MB
32MB
The table below summarizes the bank locations and modules needed
for the corresponding memory sizes.
Memory Size
8MB
8MB
16MB
16MB
16MB
24MB
24MB
32MB
32MB
40MB
40MB
48MB
48MB
64MB
64MB
64MB
72MB
72MB
80MB
80MB
96MB
96MB
128MB
SIMM1
1MBx32
—
2MBx32
—
1MBx32
1MBx32
2MBx32
4MBx32
2MBx32
1MBx32
4MBx32
2MBx32
4MBx32
8MBx32
—
4MBx32
1MBx32
8MBx32
2MBx32
8MBx32
4MBx32
8MBx32
8MBx32
Bank 0
SIMM2
1MBx32
—
2MBx32
—
1MBx32
1MBx32
2MBx32
4MBx32
2MBx32
1MBx32
4MBx32
2MBx32
4MBx32
8MBx32
—
4MBx32
1MBx32
8MBx32
2MBx32
8MBx32
4MBx32
8MBx32
8MBx32
SIMM3
—
1MBx32
—
2MBx32
1MBx32
2MBx32
1MBx32
—
2MBx32
4MBx32
1MBx32
4MBx32
2MBx32
—
8MBx32
4MBx32
8MBx32
1MBx32
8MBx32
2MBx32
8MBx32
4MBx32
8MBx32
Bank 1
SIMM4
—
1MBx32
—
2MBx32
1MBx32
2MBx32
1MBx32
—
2MBx32
4MBx32
1MBx32
4MBx32
2MBx32
—
8MBx32
4MBx32
8MBx32
1MBx32
8MBx32
2MBx32
8MBx32
4MBx32
8MBx32
15
Installing a SIM Module
A SIM module simply snaps into a socket on the system board. Pin 1 of
the SIM module must correspond with Pin 1 of the socket.
notch
key
1. Position the SIMM above the socket with the “notch” in the module
aligned with the “key” on the socket.
2. Seat the module at a 45° angle into the bank. Make sure it is completely seated. Tilt the module upright until it locks in place in the
socket.
Cache Memory
The 586IVX system board can support 256KB pipeline burst, direct map
write-back cache SRAM. Your system board may come with 256KB
cache mounted at locations U11 and U17 of the system board.
16
CPU Installation
The 586IVX allows for easy installation of CPUs. Make sure all jumpers are
set correctly before applying power or you may damage the CPU or system
board. Use a needle-nosed plier to move the jumpers if necessary.
Jumpers JP10, JP11 and JP12 are used to set the external bus clock of
your processor. Refer to the following pages for the external bus clock that
corresponds to your processor and set these jumpers accordingly. The
clock generator will determine the external bus clock that must be sent to
the processor through these settings.
Jumper JP5 is used to set the frequency ratio of your processor. Refer to
the following pages for the frequency ratio that corresponds to your processor and set this jumper accordingly.
After setting these jumpers, an Intel processor will multiply the external bus
clock by the frequency ratio to become the internal clock speed. Internal
clock speed is the commonly used speed of Intel processors in the market
and is the actual operating clock of the processor (external bus clock x
frequency ratio = internal clock speed).
Cyrix and AMD processors use the P-rating system which is the overall
CPU performance rating. Under the system, these processors slightly outperform Intel’s Pentium processors.
Jumpers JP2, JP3, JP4 and JP7 are used to set the voltage of your processor. Make sure these jumpers are set correctly, otherwise your system will
hang.
The table below shows the External System Bus Clock of the CPUs supported by the system board and their corresponding PCI Clock and ISA Bus
Clock.
External System Bus Clock
50MHz
55MHz
60MHz
66MHz
PCI CLK
25MHz
27.5MHz
30MHz
33MHz
ISA Bus CLK
8.333MHz
9.1666MHz
7.5MHz
8.25MHz
17
Jumper Settings for Intel Processors
JP7
JP12
JP11
JP10
JP2
JP3
JP4
JP5
Intel Processors
75MHz
90/120/150MHz
100/133/166/200MHz
Intel Processors
75/90/100MHz
120/133MHz
150/166MHz
200MHz
Voltages
2.7V
2.8V
2.9V
3.3V*
(VR/STD)
3.5V
(VRE)
1-3, 2-4 On
1-3, 2-4 On
1-3, 2-4 On
3-5, 4-6 On
3-5, 4-6 On
JP2
Ext. Bus
CLK
50MHz
60MHz
66MHz
Freq. Ratio
1.5x
2x
2.5x
3x
JP3
1-2 On
3-4 On
5-6 On
3-4 On
3-4 On
JP10
1-2 On
1-2 On
1-2 On
1-3 On, 2-4 On
3-5 On, 2-4 On
3-5 On, 4-6 On
1-3 On, 4-6 On
JP4
3-4 On
3-4 On
3-4 On
3-4 On
1-2 On
JP11
1-2 On
2-3 On
1-2 On
JP5
JP7
1-2, 3-4 Off
1-2, 3-4 Off
1-2, 3-4 Off
1-2, 3-4 On
1-2, 3-4 On
Warning:
The default setting of JP2, JP3, JP4 and JP7 is
3.3V. If the voltage of your CPU is not 3.3V,
make sure you set JP2, JP3, JP4 and JP7
according to the voltage of your CPU, otherwise,
your system will hang.
18
JP12
1-2 On
1-2 On
2-3 On
JP10
214 6
3 5
214 6
3
JP2/JP3
JP11
JP12
JP5
341
5
2
JP4/JP7
Jumper Settings for Cyrix 6x86 Processors
JP7
JP12
JP11
JP10
JP2
JP3
JP4
JP5
JP10
JP11
1-2 On
1-2 On
2-3 On
1-2 On
JP12
1-2 On
1-2 On
1-2 On
2-3 On
JP10
Cyrix CPUs
P120+
P133+
P150+
P166+
Ext. Bus
CLK
50MHz
55MHz
60MHz
66MHz
1-2 On
2-3 On
1-2 On
1-2 On
JP11
JP12
Cyrix CPUs
P120+/P133+/
P150+/P166+
Voltages
2.7V
2.8V
2.9V
3.3V*
(VR/STD)
3.5V
(VRE)
JP2
1-3, 2-4 On
1-3, 2-4 On
1-3, 2-4 On
3-5, 4-6 On
3-5, 4-6 On
Freq. Ratio
2x
JP3
1-2 On
3-4 On
5-6 On
3-4 On
3-4 On
JP5
3-5 On, 2-4 On
JP4
1-2, 3-4 Off
3-4 On
1-2, 3-4 Off
3-4 On
1-2, 3-4 Off
3-4 On
1-2, 3-4 On
3-4 On
1-2, 3-4 On
1-2 On
JP7
Warning:
The default setting of JP2, JP3, JP4 and JP7 is
3.3V. If the voltage of your CPU is not 3.3V,
make sure you set JP2, JP3, JP4 and JP7
according to the voltage of your CPU, otherwise,
your system will hang.
214 6
3
214 6
3
JP2/JP3
JP5
5
341
5
2
JP4/JP7
19
Jumper Settings for AMD-K5 Processors
JP7
JP12
JP11
JP10
JP2
JP3
JP4
JP5
P-Rating
PR75
PR90/PR120
PR100/PR133/PR166
P-Rating
PR75/PR90/PR100/
PR120/PR133
PR166
Voltages
2.7V
2.8V
2.9V
3.3V*
(VR/STD)
3.5V
(VRE)
JP2
1-3, 2-4 On
1-3, 2-4 On
1-3, 2-4 On
3-5, 4-6 On
3-5, 4-6 On
Ext. Bus
CLK
50MHz
60MHz
66MHz
Freq. Ratio
1.5x
1.75x
JP3
1-2 On
3-4 On
5-6 On
3-4 On
3-4 On
JP10
1-2 On
1-2 On
1-2 On
1-3 On, 2-4 On
3-5 On, 4-6 On
JP4
3-4 On
3-4 On
3-4 On
3-4 On
1-2 On
JP11
1-2 On
3-4 On
1-2 On
JP5
JP7
1-2, 3-4 Off
1-2, 3-4 Off
1-2, 3-4 Off
1-2, 3-4 On
1-2, 3-4 On
Warning:
The default setting of JP2, JP3, JP4 and JP7 is
3.3V. If the voltage of your CPU is not 3.3V,
make sure you set JP2, JP3, JP4 and JP7
according to the voltage of your CPU, otherwise,
your system will hang.
20
JP12
1-2 On
1-2 On
3-4 On
JP2/JP3
214 6
3
214 6
3
5
5
JP10
JP5
JP11
JP12
341
2
JP4/JP7
Installing Upgrade CPUs
The 586IVX is equipped with a 321-pin Zero Insertion Force (ZIF)
socket at location U29 of the system board. Refer to page 12 for the
location of the ZIF socket. This socket is designed for easy removal of
an old CPU and easy insertion of an upgrade CPU. The ZIF socket
allows you to carefully place the new CPU into its position. If you need
to apply excessive force to insert the CPU, you are not installing the
CPU correctly.
Warning:
Open the socket only if you are actually installing a CPU. The warranty
on the original CPU will be voided if the S/N seal is broken. Before
proceeding with the upgrade, take note of the following. The microprocessor and heatsink may be hot if the system has been running. To
avoid the possibility of a burn, power the system off and let the processor and heatsink cool for 20 minutes.
The 321-pin ZIF socket consists of five rows of pin holes on each side.
To prevent improper CPU installation, the ZIF socket has a Plug/Keying
mechanism. Several holes in the socket are plugged so that the CPU
will go in only one way. If you cannot easily insert the CPU, verify that
pin 1 of the CPU is aligned with pin 1 of the socket.
Zero Insertion Force (ZIF) Socket
To install an upgrade CPU, do the following:
1. Make sure the handle on the side of the ZIF socket is up. To raise
the handle, push it down, slightly pull it out to the side, then raise it
as far as it will go. It may be necessary to initially apply a small
21
amount of sideways force to free the handle from its retaining “tab”.
Once clear of the “tab”, the handle will open relatively easily. The
top plate will slide back. Do not use screwdrivers or other tools to
open the socket, or you may damage the system or socket.
Handle
Lifting the Handle
2. Once the lever is completely up, remove the old CPU carefully by
lifting it straight out of the socket. You are now ready to insert the
new CPU.
Pin 1
3. Position the CPU above the ZIF socket. Make sure pin 1 of the
CPU is aligned with pin 1 of the socket. Lower the chip until the
pins are inserted properly in their corresponding holes. Remember
that very little force is needed to install the CPU. If the CPU is not
easily inserted, verify whether or not pin 1 of the CPU is aligned
with pin 1 of the socket. Applying too much pressure can damage
the CPU or the socket.
22
Pin 1
Positioning the CPU Above the ZIF Socket
4. Push the handle down until the handle locks into place. The top
plate will slide forward. You will feel some resistance as pressure
starts to secure the CPU in the socket. This is normal and will not
damage the CPU. However, if the handle is not completely closed,
damage to the CPU and/or system board may result.
Installing A Fan/Heatsink
You must choose a fan/heatsink suitable for the processor installed on
your system board. Position the fan/heatsink on the CPU such that the
air from the side of the fan/heatsink will flow across the heat regulators
on the system board. See the figure below.
Clearance Requirements
Your CPU comes with a heatsink mounted on top. To maintain proper
airflow once the upgrade is installed on the system board, the CPU and
heatsink require certain space clearances. The clearance above the
CPU’s fan/heatsink must be at least 0.4 inches. The clearance on at
23
least 3 of 4 sides of the processor and heatsink must be at least 0.2
inches. All cables (for floppy drive, hard drive, CD-ROM, etc.) must be
routed clear of the CPU and its airspace.
Fan Exhaust
The CPU must be kept cool by using a fan with heatsink. The temperature of the air entering the fan/heatsink cannot exceed 45oC (113oF).
The ambient or room temperature must be below 37oC (99oF).
Jumper Settings for CMOS Clear
Jumper JP1
CMOS Clear Select
If, for some reason, the CMOS becomes corrupted, the system can be
reconfigured with the default values stored in the ROM BIOS. To load
the default values, power off your system and set JP1 to On. Power on
your system. After you boot up an operating system, turn your system
off again. Set JP1 back to its default setting, Off.
24
Off: Normal
(default)
On: CMOS Clear
JP1
Jumper Settings for Password Clear
Jumper JP13
Password Clear
If you set a password in the “Password Setting” option and forget your
password, power off your system and set Jumper JP13 to On. Power on
your system. After you boot up an operating system, turn your system
off again. This will clear the password stored in your CMOS. Set JP13
back to its default setting, Off.
Off: Normal
(default)
On: Password Clear
JP13
Built-in Ports
The 586IVX system board is equipped with two serial ports, one parallel
printer port, one shrouded floppy disk header, two shrouded IDE hard
disk headers, and two USB ports. Refer to page 12 for the locations of
the built-in connectors and pin 1 of those connectors.
PS/2
Mouse
USB 1
Parallel Printer
PS/2
K/B
USB 2
COM 2 COM 1
25
Serial Ports
The 586IVX is equipped with two serial ports at locations CN5 (COM 2)
and CN6 (COM 1) of the system board. These built-in serial ports are
RS-232C asynchronous communication ports with 16C550A-compatible
UARTs that can be used with modems, serial printers, remote display
terminals, and other serial devices.
Parallel Port
The 586IVX system board has a standard printer port (CN7) for interfacing your PC to a parallel printer. It supports SPP, ECP and EPP modes.
You can set the port’s mode in the Integrated Peripherals setup of the
Award BIOS (Refer to Chapter 3).
Setting
SPP
(Standard Parallel Port)
ECP
(Extended Capabilities Port)
EPP
(Enhanced Parallel Port)
Function
Allows normal speed operation but in one
direction only.
Allows parallel port to operate in bidirectional
mode and at a speed higher than the maximum data transfer rate.
Allows bidirectional parallel port operation at
maximum speed.
The parallel port on your system board can be set to any of the following system I/O addresses:
I/O Address 3BC-3BE Hex
378-37A Hex (default)
278-27A Hex
26
Floppy Disk Drive Controller
The 586IVX system board is equipped with a shrouded floppy disk
header that supports two standard floppy disk drives. You can install
any 360KB, 720KB, 1.2MB, 1.44MB, or 2.88MB floppy disk drives. To
prevent improper floppy cable installation, the shrouded floppy disk
header has a keying mechanism. The 34-pin connector on the floppy
cable can be placed into the header only if pin 1 of the connector is
aligned with pin 1 of the header.
Connecting the Floppy Disk Cable
1. Install the 34-pin header connector into the shrouded floppy disk
header (J10) on the system board. The colored edge of the ribbon
should be aligned with pin 1 of connector J10.
2. Install the other 34-pin header connector(s) into the disk drive(s).
Align the colored edge of the daisy chained ribbon cable with pin 1
of the drive edge connector(s). The end-most connector should be
attached to the drive you want to designate as Drive A.
IDE Hard Disk Interface
The 586IVX system board is equipped with two shrouded PCI IDE
headers that will interface four Enhanced IDE (Integrated Drive Electronics) hard disk drives.
Note:
Only Enhanced IDE hard drives or ATAPI CD-ROMs can be connected
to the IDE interface.
Connecting the IDE Hard Disk Interface
To prevent improper IDE cable installation, each shrouded PCI IDE
header has a keying mechanism. The 40-pin connector on the IDE
cable can be placed into the header only if pin 1 of the connector is
aligned with pin 1 of the header.
27
Header
Note:
An IDE cable with a standard 40-pin connector (without the keying
mechanism) can be installed in the shrouded PCI IDE header. Be extremely careful to match the colored edge of the ribbon with pin 1 of the
header.
Connecting the Hard Disk Cable
1. If you are connecting two hard drives, install the 40-pin connector of
the IDE cable into the primary shrouded IDE header (connector
J11). If you are adding a third or fourth IDE device, install the 40pin connector of the other IDE cable into the secondary shrouded
IDE header (connector J12).
2. Install the other 40-pin header connector(s) into the device with the
colored edge of the ribbon cable aligned with pin 1 of the drive
edge connector(s).
Note:
Refer to your disk drive user’s manual for information about selecting
proper drive switch settings.
Adding a Second IDE Hard Drive
When using two IDE drives, one must be set as the master and the
other as the slave. Follow the instructions provided by the drive manufacturer for setting the jumpers and/or switches on the drives.
28
We recommend that you use Enhanced IDE hard drives from the same
manufacturer. In a few cases, drives from two different manufacturers
will not function properly when used together. The problem lies in the
hard drives, not the 586IVX system board.
Preparing an IDE Drive for Use
IDE disk drives are already low-level formatted, with any bad-track errors entered, when shipped by the drive manufacturer. Do not attempt
to do a low-level format or you may cause serious damage to the drive.
To use an IDE drive, you need to enter the drive type (this information
is provided by the drive manufacturer) into the system’s CMOS setup
table. Then run FDISK and FORMAT provided with DOS. You may also
use the IDE HDD Auto Detection function which will allow the BIOS to
auto detect your hard drive type. Refer to the IDE HDD Auto Detection
section for details.
Warning:
Do not run FDISK and FORMAT programs on a drive that has already
been formatted or you will lose all programs and data stored on the
drive.
Using 586IVX with CD-ROM Drives
If you encountered problems while using an ATAPI CD-ROM drive that
is set in Master mode, please set the CD-ROM drive to Slave mode.
Some ATAPI CD-ROMs may not be recognized and cannot be used if
incorrectly set in Master mode.
Universal Serial Bus Connectors
The 586IVX system board is equipped with two USB ports on locations
J2 and J4 on the system board. USB allows data exchange between
your computer and a wide range of simultaneously accessible peripherals. Make sure “USB Controller” in the Integrated Peripherals setup of
the Award BIOS is set to Enabled.
29
Installing Expansion Cards
The 586IVX system board is equipped with 3 dedicated PCI slots, 3
dedicated 16-bit ISA slots and 1 shared PCI/ISA slot. All PCI slots are
bus masters. Refer to page 12 for the locations of the expansion slots.
30
Chapter 3
Software Installation
After you power up your system, the BIOS message appears on your
screen and the memory count begins.
After the memory test, the following message will appear on the screen:
Press DEL to enter setup
If the message disappears before you respond, restart your system or
press the “Reset” button located on the front panel of your computer.
You may also restart the system by pressing the <Ctrl> <Alt> and
<Del> keys simultaneously.
If you have set a password and selected “System” in the Security Option of the BIOS Features Setup menu, you will be prompted for the
password every time the system is rebooted or any time you try to enter
Setup. Type in the correct password and press <Enter>.
If you selected “Setup” in the Security Option, you will be prompted for
the password only when you try to enter Setup. Refer to the “BIOS
Features Setup” section for more information.
Award CMOS Setup Utility
While booting up, press <Ctrl> <Alt> <Esc> simultaneously or <Del> to
enter the Setup utility. A screen similar to the one on the next page will
appear.
31
ROM PCI/ISA BIOS
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
STANDARD CMOS SETUP
BIOS FEATURES SETUP
CHIPSET FEATURES SETUP
POWER MANAGEMENT SETUP
PNP/PCI CONFIGURATION
LOAD BIOS DEFAULTS
LOAD SETUP DEFAULTS
:Quit
ESC
:Sve & Exit Setup
F10
Time, Date, Hard Disk Type...
INTEGRATED PERIPHERALS
SUPERVISOR PASSWORD
USER PASSWORD
IDE HDD AUTO DETECTION
HDD LOW LEVEL FORMAT
SAVE & EXIT SETUP
EXIT WITHOUT SAVING
↑↓→←
:Select Item
:Change Color
(Shift) F2
Use the arrow keys to highlight the option you want and press <Enter>.
The following describes each of these options.
Note:
The settings on the BIOS setup screens on the following pages are for
reference only. Some of the settings will vary according to your
system’s configuration and should not be referred to as the standard
default setting.
Standard CMOS Setup
Use the arrow keys to highlight “Standard CMOS Setup” and press
<Enter>. A screen similar to the one below will appear.
32
STANDARD CMOS SETUP
AWARD SOFTWARE, INC.
Date (mm:dd:yy) : Thu, Sep 10 1996
Time (hh:mm:ss) : 9 : 5 : 55
HARD DISKS
Primary Master
Primary Slave
Secondary Master
Secondary Slave
DriveA :1.44M,3.5in.
DriveB :None
Video :EGA/VGA
Halt on :All Errors
ESCF1:Quit
:Help
TYPE
:Auto
:Auto
:Auto
:Auto
SIZE
0
0
0
0
ROM PCI/ISA BIOS
CYLS
HEAD
0
0
0
0
0
0
0
0
:Select Item
↑↓→←
:Change
(Shift)F2
PRECOMP
LANDZ
0
0
0
0
Base Memory : 640K
Extended Memory : 31744K
Other Memory : 384K
MODE
SECTOR
0
0
0
0
0
0
0
0
Total Memory : 32768K
PU/PD/+/- : Modify
Auto
Auto
Auto
Auto
Date
The date format is <day>, <month>, <date>, <year>.
Day
Month
Date
Year
Displays a day, from Sunday to Saturday
Displays the month, from January to December
Displays the date, from 1 to 31
Displays the year, from 1900 to 2099
Time
The time format is <hour>, <minute>, <second>. The time is based on
the 24-hour military-time clock. For example, 1 p.m. is 13:00:00.
Hour
Minute
Second
Displays hours from 00 to 23
Displays minutes from 00 to 59
Displays seconds from 00 to 59
Primary Master, Primary Slave, Secondary Master and Secondary
Slave
These categories allow you to enter the appropriate specifications for
the type of hard disk drive(s) installed in your system. There are 45
predefined types and 4 user definable types for IDE hard drives. Type 1
to Type 45 are predefined. Type “User” is user-definable.
Press <PgUp> or <PgDn> to select a numbered hard disk type or type
the number and press <Enter>. The hard disk will not work properly if
you enter improper information for this category. You can use Type
“User” to define your own drive type manually.
If you select Type “User”, you will need to know the information listed
below. Enter the information and press <Enter>. This information should
be included in the documentation from your hard disk vendor or the
system manufacturer.
33
If the controller of the HDD interface is ESDI, you must select “Type 1”.
If the controller of the HDD interface is SCSI, you must select “None”.
If you select Type “Auto”, the BIOS will auto-detect the HDD & CD-ROM
drive at the POST stage and show the IDE for the HDD & CD-ROM
drive.
Type
Cyls
Heads
Precomp
Landzone
Sectors
Mode
Drive type
Number of cylinders
Number of heads
Write precomp
Landing zone
Number of sectors
Mode type
If a hard disk has not been installed, select “None” and press <Enter>.
Drive A and Drive B
These categories identify the types of floppy disk drives installed. The
following are the options for drives A and B.
None
360K, 5.25 in.
1.2M, 5.25 in.
720K, 3.5 in.
1.44M, 3.5 in.
2.88M, 3.5 in.
No floppy drive is installed
5-1/4 inch PC-type standard drive; 360 kilobyte capacity
5-1/4 inch AT-type high-density drive; 1.2 megabyte capacity
3-1/2 inch double-sided drive; 720 kilobyte capacity
3-1/2 inch double-sided drive; 1.44 megabyte capacity
3-1/2 inch double-sided drive; 2.88 megabyte capacity
Note:
Choosing an incorrect type might cause your system to format the floppy
disk improperly, and you will not be able to access your data.
34
Video
This category selects the type of video adapter used for the primary
system monitor. Although secondary monitors are supported, you do not
have to select the type in Setup. The default setting is EGA/VGA (BIOS
default, Setup default).
EGA/VGA
CGA 40
CGA 80
Mono
Enhanced Graphics Adapter/Video Graphics Array. For EGA,
VGA, SVGA and PGA monitor adapters.
Color Graphics Adapter. Power up in 40-column mode.
Color Graphics Adapter. Power up in 80-column mode.
Monochrome adapter. Includes high resolution monochrome
adapters.
Halt On
This category determines whether the system will stop if an error is detected during power up. The default setting is All Errors (BIOS default,
Setup default).
No Errors
All Errors
All, But
Keyboard
All, But
Diskette
All, But
Disk/Key
The system boot will not stop for any errors detected.
The system boot will stop whenever the BIOS detects a non-
fatal error.
The system boot will not stop for a keyboard error; it will stop
for all other errors.
The system boot will not stop for a disk error; it will stop for
all other errors.
The system boot will not stop for a disk or keyboard error; it
will stop for all other errors.
Memory
The base memory size, extended memory size and the other memory
size cannot be altered; your computer automatically detects and displays them.
35
Base
Memory
Extended
Memory
Other
Memory
This refers to the amount of base or conventional memory
installed on the system board.
This is the amount of memory located above 1MB in the
memory address map of the CPU.
This memory size refers to the memory located in the address space between 640K and 1024K. DOS uses this
area to load device drivers to keep base memory free for
application programs. The most appropriate use of this
area is for Shadow RAM.
BIOS Features Setup
The BIOS Features Setup allows you to configure your system for basic
operation. Some entries are defaults required by the system board,
while others, if enabled, will improve the performance of your system or
let you set some features according to your preference.
ROM PCI/ISA BIOS
BIOS FEATURES SETUP
AWARD SOFTWARE, INC.
Virus Warning
CPU Internal Cache
External Cache
Quick Power On Self Test
Boot Sequence
Swap Floppy Drive
Boot Up Floppy Seek
Boot Up NumLock Status
Gate A20 Option
Typematic Rate Setting
Typematic Rate (Chars/Sec)
Typematic Delay (Msec)
Security Option
PCI/VGA Palette Snoop
OS Select For DRAM > 64MB
: Disabled
: Enabled
: Enabled
: Enabled
: A, C
: Disabled
: Enabled
: On
: Fast
: Disabled
: 6
: 250
: Setup
: Disabled
: Non-OS2
Video BIOS Shadow
C8000-CBFFF Shadow
CC000-CFFFF Shadow
D0000-D3FFF Shadow
D4000-D7FFF Shadow
D8000-DBFFF Shadow
DC000-DFFFF Shadow
ESC
:Quit
F1
:Help
F5
:Old Values
F6
:Load BIOS Defaults
F7
:Load Setup Defaults
↑↓→←
PU/PD/+/(Shift) F2
: Enabled
: Disabled
: Disabled
: Disabled
: Disabled
: Disabled
: Disabled
:Select Item
:Modify
:Color
Virus Warning
This category protects the boot sector and partition table of your hard
disk drive. When this item is enabled, the Award BIOS will monitor the
boot sector and partition table of the hard disk drive. If an attempt is
made to write to the boot sector or partition table of the hard disk drive,
the BIOS will halt the system and the following error message will
appear.
36
! WARNING !
Disk boot sector is to be modified
Type “Y” to accept write or “N” to abort write
Award Software, Inc.
After seeing this message, if necessary, you will be able to run an antivirus program to locate and remove the problem before any damage is
done.
Many disk diagnostic programs which attempt to access the boot sector
table will cause the warning message to appear. If you are running such
a program, we recommend that you first disable this category. Also,
disable this category if you are installing or running certain operating
systems like Windows 95 or the operating system may not install nor work.
Enabled
Disabled
BIOS issues a warning when any program or virus sends a
Disk Format command or attempts to write to the boot sector
of the hard disk drive.
No warning message will appear when the boot sector of the
hard disk drive is accessed.
CPU Internal Cache and External Cache
These categories speed up memory access. The default value is enabled. Enable the External Cache for better performance.
Enabled
Disabled
Enables the internal/external cache.
Disables the internal/external cache.
Quick Power On Self Test
This category speeds up Power On Self Test (POST) after you power
on your system. If it is set to Enabled, the BIOS will shorten or skip
some check items during POST.
Enabled
Disabled
Enables quick POST.
Normal POST.
37
Boot Sequence
This category determines which drive to search first for the disk operating system (i.e. DOS). The default is A, C.
A, C
C, A
CDROM, C, A
C, CDROM, A
The system will first search for a floppy drive and then a
hard disk drive.
The system will first search for a hard disk drive and
then a floppy drive.
The system will first search for a CD-ROM drive, then a
hard disk drive and then a floppy drive.
The system will first search for a hard disk drive, then a
CD-ROM drive, and then a floppy drive.
Swap Floppy Drive
Enabled
Disabled
When this option is enabled and the system is booting from
the floppy drive, the system will boot from drive B instead of
drive A.
When this option is disabled and the system is booting from
the floppy drive, the system will boot from drive A.
Boot Up Floppy Seek
During POST, the BIOS will determine if the floppy disk drive installed is
40 or 80 tracks. 360K type is 40 tracks while 720K, 1.2M, 1.44M and
2.88M are all 80 tracks.
38
Enabled
Disabled
The BIOS will check whether the floppy disk drive installed is
40 or 80 tracks. Note that the BIOS cannot distinguish between 720K, 1.2M, 1.44M or 2.88M drive types as they are all
80 tracks.
The BIOS will not search for the type of floppy disk drive by
track number. Note that there will not be any warning message if the drive installed is 360KB.
Boot Up NumLock Status
This allows you to determine the default state of the numeric keypad.
By default, the system boots up with NumLock on.
On
Off
The function of the numeric keypad is the number keys.
The function of the numeric keypad is the arrow keys.
Security Option
This category allows you to limit access to your system and Setup or
just to Setup.
System
Setup
The system will not boot and access to Setup will be denied if
the correct password is not entered at the prompt.
The system will boot, but access to Setup will be denied if the
correct password is not entered at the prompt.
PCI/VGA Palette Snoop
This is used to select whether to allow MPEG ISA/VESA VGA cards to
work with PCI/VGA or not.
Enabled
Disabled
PCI/VGA working with MPEG ISA/VESA VGA cards.
PCI/VGA not working with MPEG ISA/VESA VGA cards.
OS Select for DRAM > 64MB
This item allows you to access the memory that is over 64MB in OS/2.
The options are: Non-OS2 and OS2.
Video BIOS Shadow
Determines whether video BIOS will be copied to RAM. Video Shadow
will increase the video speed. Note that some graphics boards require
that this option be disabled.
39
Enabled
Disabled
Video shadow is enabled.
Video shadow is disabled.
C8000-CBFFF Shadow to DC000-DFFFF Shadow
These categories determine whether option ROMs will be copied to
RAM.
Enabled
Disabled
Optional shadow is enabled.
Optional shadow is disabled.
Chipset Features Setup
This section gives you instructions on how to configure the system
based on the specific features of the chipset. The chipset manages bus
speeds and access to system memory resources such as DRAM and
external cache. It also coordinates communications between the conventional ISA bus and the PCI bus. These items should not be altered
unless necessary. Depending on your add-in boards, you may not or
should not enable some of these features. The default settings have
been chosen because they provide optimum operating conditions for
your system.
ROM PCI/ISA BIOS
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
Auto Configuration
DRAM Timing
DRAM RAS# Precharge Time
DRAM R/W Leadoff Timing
Fast RAS To CAS Delay
DRAM Read Burst (EDO/FP)
DRAM Write Burst Timing
Fast MA to RAS# Delay CLK
Fast EDO Path Select
Refresh RAS# Assertion
ISA Bus Clock
System BIOS Cacheable
Video BIOS Cacheable
8 Bit I/O Recovery Time
16 Bit I/O Recovery Time
Memory Hole At 15M-16M
Peer Concurrency
Passive Release
: Enabled
: Normal
: 3
: 6
: 2
: x222/x333
: x333
: 1
: Disabled
: 4 Clks
: PCICLK/4
: Enabled
: Enabled
: 1
: 1
: Disabled
: Enabled
: Disabled
Delayed Transaction
ESC
:Quit
F1
:Help
F5
:Old Values
F6
:Load BIOS Defaults
F7
:Load Setup Defaults
↑↓→←
PU/PD/+/(Shift) F2
: Disabled
:Select Item
:Modify
:Color
40
Power Management Setup
Power Management Setup allows you to configure your system to most
effectively save energy. If you like to use the soft power down feature of
Windows 95, you must enable the Power Management below. Select
Min. Power, Max. Power or User Defined. Either one can be used as
long as it is NOT disabled.
ROM PCI/ISA BIOS
POWER MANAGEMENT SETUP
AWARD SOFTWARE, INC.
Power Management
PM Control by APM
Video Off Method
MODEM Use IRQ
Doze Mode
Standby Mode
Suspend Mode
HDD Power Down
** Wake Up Events In Doze & Standby **
IRQ3 (Wake-Up Event)
IRQ4 (Wake-Up Event)
IRQ8 (Wake-Up Event)
IRQ12 (Wake-up Event)
: User Define
: Yes
: V/H SYNC+Blank
: 3
: Disabled
: Disabled
: Disabled
: Disabled
: On
: On
: On
: On
** Power Down & Resume Events **
IRQ3 (COM 2)
IRQ4 (COM 1)
IRQ5 (LPT 2)
IRQ6 (Floppy Disk)
IRQ7 (LPT 1)
IRQ8 (RTC Alarm)
IRQ9 (IRQ2 Redir)
IRQ10 (Reserved)
IRQ11 (Reserved)
IRQ12 (PS/2 Mouse)
IRQ13 (Coprocessor)
IRQ14 (Hard Disk)
IRQ15 (Reserved)
ESC
:Quit
F1
:Help
F5
:Old Values
F6
:Load BIOS Defaults
F7
:Load Setup Defaults
: On
: On
: On
: On
: On
: Off
: On
: On
: On
: On
: On
: On
: Off
↑↓→←
PU/PD/+/(Shift) F2
:Select Item
:Modify
:Color
Power Management
This category allows you to select the type (or degree) of power saving
by changing the length of idle time that elapses before each of the
following modes are activated: Doze Mode, Standby Mode, and Suspend Mode.
Disable
(default)
Min. Power
Saving
Max. Power
Saving
User
Defined
No power management. Disables the Doze, Standby and
Suspend modes.
Minimum power management. Doze Mode = 1 hr., Standby
Mode = 1 hr., and Suspend Mode = 1 hr.
Maximum power management. Doze Mode = 1 min.,
Standby Mode = 1 min., and Suspend Mode = 1 min.
Allows you to set each mode individually. When enabled,
each option ranges from 1 min. to 1 hr.
41
PM Control by APM
Yes
No
An Advanced Power Management device will be activated to
enhance the Max. Power Saving mode and stop the CPU’s
internal clock. Use this option in Windows 95. (default)
The system BIOS will ignore APM when initiating the Power
Management mode.
Video Off Method
This determines the manner in which the monitor is blanked.
V/H
SYNC +
Blank
Blank
Screen
DPMS
MODEM Use IRQ
This category is used to set an IRQ channel (IRQ 3, 4, 5, 7, 9, 10 or
11) for the modem installed in your system.
This selection will cause the system to turn off the vertical and
horizontal synchronization ports and write blanks to the video
buffer.
This option only writes blanks to the video buffer.
Initializes display power management signaling. Use this option
if your video board supports it.
Doze Mode, Standby Mode, Suspend Mode and HDD Power Down
These Green PC power saving categories are user configurable only
when the Power Management category is set to User Defined.
Doze
Mode
Standby
Mode
Suspend
Mode
42
When enabled and after the set time of system inactivity, the
CPU clock will run at a slower speed (1/2 of full speed) while
all other devices still operate at full speed.
When enabled and after the set time of system inactivity, the
CPU clock will run at a speed slower than the speed during
Doze mode (1/3 of full speed) while all other devices still operate at full speed.
When enabled and after the set time of system inactivity, the
CPU and onboard peripherals will be shut off.
HDD
Power
Down
This is used to define the continuous HDD idle time that
elapses before the HDD enters the power saving mode (motor
off). When enabled and after the set time of system inactivity,
the hard disk drive will be powered down while all other devices remain active.
IRQ3-IRQ15 (Wake Up Events in Doze & Standby and Power
Down & Resume Events)
These are I/O events whose occurrence can prevent the system from
entering a power saving mode or can awaken the system from such a
mode. In effect, the system remains alert for anything which occurs to a
device which is configured as enabled, even when the system is in a
power saving mode.
When an I/O device wants to gain the attention of the operating system,
it signals this by causing an IRQ to occur. When the operating system
is ready to respond to the request, it interrupts itself and performs the
service.
PNP/PCI Configuration
This section describes configuring the PCI bus system. It covers some
very technical items, and it is strongly recommended that only experienced users make any changes to the default settings.
Resources Controlled By
Reset Configuration Data
ROM PCI/ISA BIOS
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
: Auto
: Disabled
PCI IRQ Actived By : Level
PCI IDE IRQ Map To : PCI-AUTO
Primary IDE INT# : A
Secondary IDE INT# : B
ESC
:Quit
F1
:Help
F5
:Old Values
F6
:Load BIOS Defaults
F7
:Load Setup Defaults
↑↓→←
PU/PD/+/(Shift) F2
:Select Item
:Modify
:Color
43
Resources Controlled By
The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices.
Auto
Manual
The system will automatically detect the settings for you. The
categories that follow will not be shown on the PNP/PCI Configuration screen.
This allows you to set the IRQ/DMA (you have assigned your
add-in card) to Legacy ISA or PCI/ISA PnP. For non-PnP ISA
cards, select Legacy ISA. For PnP ISA or PCI cards, select
PCI/ISA PnP.
Reset Configuration Data
Enabled
Disabled
The BIOS will reset the configuration data once automatically.
The BIOS will not reset the configuration data.
PCI IRQ Actived By
This category is used to set the method by which the PCI bus recognizes that an IRQ service is being requested by a device. Under all
circumstances, you should retain the default configuration unless a different setting is needed.
PCI IDE IRQ Map To
This category is used to configure your system to the type of IDE disk
controller in use.
ISA
PCI-Auto
44
Designates which ISA slot is installed with an IDE controller
card; that is, if you are using an IDE controller card.
The system will scan and determine the PCI slot that is installed with an IDE controller card.
Primary IDE INT# and Secondary IDE INT#
The Primary and Secondary IDE INT# categories are used to select the
PCI interrupt (A, B, C, or D) that is associated with the connected hard
drives.
Load BIOS Defaults
The “Load BIOS Defaults” option loads the troubleshooting default values permanently stored in the ROM chips. These settings are not optimal and turn off all high performance features. You should use these
values only if you have hardware problems. Highlight this option on the
main menu and press <Enter>. The message below will appear.
Load BIOS Defaults (Y/N)? N
If you want to proceed, type <Y> and press <Enter>. The default settings will be loaded.
Load Setup Defaults
The “Load Setup Defaults” option loads optimized settings from the
BIOS ROM. Use the Setup default values as standard values for your
system.
Highlight this option on the main menu and press <Enter>. The message below will appear.
Load Setup Defaults (Y/N)? N
Type <Y> and press <Enter> to load the Setup default values.
45
Integrated Peripherals
IDE HDD Block Mode
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Secondary Master PIO
IDE Secondary Slave PIO
On-Chip Primary PCI IDE
On-Chip Secondary PCI IDE
PCI Slot IDE 2nd Channel
Onboard FDD Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART 2 Mode
Onboard Parallel Port
Onboard Parallel Mode
IDE HDD Block Mode
ROM PCI/ISA BIOS
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
: Enabled
: Auto
: Auto
: Auto
: Auto
: Enabled
: Enabled
: Disabled
: Enabled
: COM1/3F8
: COM2/2F8
: Standard
: 378/IRQ7
: SPP
USB Controller : Disabled
ESC
:Quit
F1
:Help
F5
:Old Values
F6
:Load BIOS Defaults
F7
:Load Setup Defaults
↑↓→←
PU/PD/+/(Shift) F2
:Select Item
:Modify
:Color
Enabled
The IDE HDD uses the block mode. The system BIOS will
check the hard disk drive for the maximum block size the
system can transfer. The block size will depend on the type
of hard disk drive installed.
Disabled
The IDE HDD uses the standard mode.
IDE Primary Master/Slave PIO and IDE Secondary Master/Slave
PIO
Your system supports five modes, 0 (default) to 4, which primarily differ
in timing. When Auto is selected, the BIOS will select the best available
mode after checking your hard drive or CD-ROM.
Auto
0-4
The BIOS will automatically set the system according to your
hard disk drive’s timing.
You can select a mode that matches your hard disk drive’s
timing. Caution: Do not use the wrong setting or you will
have drive or CD-ROM errors.
On-Chip Primary PCI IDE and On-Chip Secondary PCI IDE
These categories allow you to enable or disable the primary and secondary IDE controller. The default is Enabled. Select Disabled if you
want to add a different hard drive controller.
46
PCI Slot IDE 2nd Channel
This allows you to designate an IDE controller card inserted into one of
the PCI slots as your secondary IDE controller.
Enabled
Disabled
The IDE controller card is designated as the secondary IDE
controller.
No IDE controller card occupying any of the PCI slots.
Onboard FDD Controller
Enabled
Disabled
Enables the onboard floppy disk controller.
Disables the onboard floppy disk controller.
Onboard Serial Port 1 and Onboard Serial Port 2
Auto
COM1 to
COM4
Disabled
The system will automatically select an I/O address for the
onboard serial port 1 and serial port 2.
Allows you to manually select COM1, COM2, COM3, or
COM4 for the onboard serial port 1 and serial port 2.
Disables the onboard serial port 1 and/or serial port 2.
UART 2 Mode
The 586IVX system board supports IrDA function for wireless connectivity between your computer and peripheral devices. To use the IrDA
function, follow the steps below.
1. Connect your IrDA cable to connector J8 of the 586IVX system
board. Refer to page 12 for the location of connector J8.
2. Set “UART 2 Mode” to the type of IrDA standard supported by your
IrDA peripheral/device.
You may not use IrDA (J8) and the COM 2 serial port (CN5) at the
same time. If you are using the COM 2 serial port, set “UART 2 Mode”
to Standard.
47
Standard
HPSIR
ASKIR
Uses the COM 2 serial port.
HP mode IrDA.
SHARP mode IrDA.
Onboard Parallel Port
378H/IRQ7
3BCH/IRQ7
278H/IRQ5
Disabled
Selects the I/O address and IRQ for the onboard parallel port.
Disables the onboard parallel port.
Parallel Port Mode
SPP
EPP/SPP
ECP
ECP/EPP
Selects the parallel port mode according to the type of printer
device connected to your onboard parallel port.
USB Controller
By default, the USB controller is Disabled. To use the USB controller,
set this option to Enabled. Refer to the Universal Serial Bus Connectors
section for instructions on connecting the USB ports.
Supervisor Password
If you want to protect your system and setup from unauthorized entry,
set a supervisor’s password with the “System” option selected in the
BIOS Features Setup.
If you want to protect access to setup only, but not your system, set a
supervisor’s password with the “Setup” option selected in the BIOS Features Setup. You will not be prompted for a password when you cold
boot the system.
Use the arrow keys to highlight the “Supervisor Password” option and
press <Enter>. The message below will appear.
Enter Password:
48
Type in the password. You are limited to eight characters. When done,
the message below will appear:
Confirm Password:
You are being asked to verify the password. Type in exactly the same
password. If you type in a wrong password, you will be prompted to
enter the correct password again.
To delete or disable the password function, highlight “Supervisor Password” and press <Enter>, instead of typing in a new password. Press
the <Esc> key to return to the main menu.
User Password
If you want another user to have access only to your system but not to
setup, set a user’s password with the “System” option selected in the
BIOS Features Setup.
If you want a user to enter a password when trying to access setup, set
a user’s password with the “Setup” option selected in the BIOS Features Setup. Using a user’s password to enter Setup allows a user to
access only the “User Password” option that appears on the main
screen. Access to all other options is denied.
To set, confirm, verify, disable or delete a user’s password, follow the
procedures described in the section “Supervisor Password”. If you forget your password, refer to the procedure described in the same section.
IDE HDD Auto Detection
This option detects the hard disk parameters for the hard disk drives
installed in your system. Highlight this option and press <Enter>. A
screen similar to the one on the next page will appear.
49
ROM PCI/ISA BIOS
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
HARD DISKS TYPE SIZE CYLS HEAD RECOMP LANDZ SECTOR MODE
Primary Master:
Select Primary Master Option (N=Skip): N
OPTIONS SIZE CYLS HEAD RECOMP LANDZ SECTOR MODE
2 (Y) 853 827 32 0 1653 63 LBA
1 853 1654 16 65535 1653 63 Normal
3 853 827 32 65536 1653 63 Large
Note: Some OS (like SCO-UNIX) must be “NORMAL” for installation
ESC: Skip
Enter your choice, and press <Enter> to accept the parameters or press
<Esc> to abort. The parameters of the hard disk will be displayed in the
Standard CMOS Setup.
Hard Drive Mode
The system board supports three HDD modes: Normal, LBA and Large.
If your hard disk drive does not support LBA mode, the “LBA” option will
not be displayed. If your HDD has 1024 or fewer cylinders, the “Large”
option will not be displayed. If your hard drive is larger than 2.1GB, be
sure that your operating system supports it or you may need to create
separate partitions.
Normal Mode
Normal mode is the generic access mode in which neither the BIOS nor
the IDE controller will make any transformations during hard-drive access.
The maximum number of cylinders, heads and sectors for Normal mode
are 1024, 16 and 63, respectively.
no. Cylinders (1024)
x no. Heads ( 16)
x no. Sectors ( 63)
x bytes per sector ( 512)
528 megabytes
50
If you set your HDD to Normal mode, the maximum accessible HDD will
be 528 megabytes even though the physical size of the HDD may be
greater than that.
LBA (Logical Block Addressing) Mode
LBA mode is a HDD accessing method to overcome the 528 megabyte
limitation. The number of cylinders, heads and sectors shown on the
screen may not be the actual number for the HDD.
During HDD accessing, the IDE controller will transform the logical address described by the sector, head and cylinder number into its own
physical address inside the HDD.
The maximum HDD size supported by the LBA mode is 8.4 gigabytes. It
is obtained by the following formula.
no. Cylinders (1024)
x no. Heads ( 255)
x no. Sectors ( 63)
x bytes per sector ( 512)
8.4 gigabytes
Large Mode
Large mode is the extended HDD access mode supported by the system board. Some IDE HDDs have more than 1024 cylinders without
LBA support (in some cases, you may not want the LBA mode). This
system board provides another alternative to support these kinds of
HDDs.
The BIOS tells the operating system that the number of cylinders is half
the actual number and that the number of heads is double the actual
number. During disk access, the reverse conversion is done by the
INT13h routine.
51
Maximum HDD size:
no. Cylinders (1024)
x no. Heads ( 32)
x no. Sectors ( 63)
x bytes per sector ( 512)
1 gigabyte
Note:
To support LBA or Large mode, address translation software is included
in the Award BIOS HDD Service Routine (INT13h). If you are running
an operating system that bypasses the BIOS INT13 Service Routine,
LBA and Large Mode may fail.
HDD Low Level Format
The HDD Low Level Format utility is designed as a tool to save you
time formatting your hard disk. It automatically looks for the necessary
information of the drive you selected. This utility also searches for bad
tracks and lists them for your reference. Highlight this option and press
<Enter>. A screen similar to the one below will appear.
ROM PCI/ISA BIOS
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
Hard Disk Low Level Format Utility
SELECT DRIVE
BAD TRACK LIST
PREFORMED
Current select drive is : C
DRIVE: C CYLINDER: 0 HEAD: 0
CYLS
1654
HEAD
RECOMP
16
0
0
0
0
0
0
Primary Master:
Primary Slave:
Secondary Master:
Secondary Slave:
Up/Down-Select item ENTER-Accept ESC-Exit/Abort
SIZE
853
0
0
0
Copyright (C) Award Software, Inc. 1992-94 All Rights Reserved
65536
LANDZ
1653
0
0
0
0
0
0
No. CYLS HEAD
SECTOR
63
0
0
0
MODE
AUTO
AUTO
AUTO
AUTO
Warning:
Do not use this HDD Low Level Format feature for IDE hard drives.
They already have been low-level formatted at the factory. Do a highlevel format only for these drives. Refer to the manual that comes with
your operating system.
52
Save & Exit Setup
When all the changes have been made, highlight “Save & Exit Setup”
and press <Enter>. The message below will appear:
Save to CMOS and Exit (Y/N)? N
Type “Y” and press <Enter>. The modifications you have made will be
written into the CMOS memory, and the system will reboot. You will
once again see the initial diagnostics on the screen. If you wish to
make additional changes to the setup, press <Ctrl> <Alt> <Esc> simultaneously or <Del> after memory testing is done.
Exit Without Saving
When you do not want to save the changes you have made, highlight “Exit
Without Saving” and press <Enter>. The message below will appear:
Quit Without Saving (Y/N)? N
Type “Y” and press <Enter>. The system will reboot and you will once
again see the initial diagnostics on the screen. If you wish to make any
changes to the setup, press <Ctrl> <Alt> <Esc> simultaneously or
<Del> after memory testing is done.
Desktop Management Interface (DMI)
The 586IVX system board comes with a DMI built into the BIOS. DMI,
along with the appropriately networked software, is designed to make
inventory, maintenance and troubleshooting of computer systems
easier. With DMI, a network administrator or MIS engineer can remotely
access some information about a particular computer system without
physically going to it. Quite often a service call may be unnecessary as
the problem can be solved remotely.
The DMI utility in the BIOS automatically records various information
about your system configuration. Information about the type and speed
of CPU, type and amount of memory for each memory slot, BIOS revision level, types of add-in PCI boards and components, certain revision
numbers of hardware installed, etc. are automatically detected and
stored in the DMI pool, which is a part of the system board's Plug and
53
Play BIOS. Additional information, such as ISA based peripherals,
which may not be automatically detected, can be manually recorded in
the DMI pool by using the Add DMI menu. The DMI pool data is then
verified or updated whenever the system hardware or setup is altered.
Running the DMI Utility
To run the DMI utility, type: DMICFG.EXE. You can download this utility
from http://www.dfi.com.tw - BIOS & DRIVERS section or ftp.dfiusa.com /pub/DMI directory.
The DMI utility must run in real mode with at least 180K of base
memory. Memory managers like HIMEM.SYS (required by Windows)
must not be installed. To do this, boot up from a system diskette without
the AUTOEXEC.BAT and CONFIG.SYS files. “REM” HIMEM.SYS in the
CONFIG.SYS or press <F5> during bootup to bypass your
AUTOEXEC.BAT and CONFIG.SYS files.
Using the DMI Utility
[Edit DMI] [Add DMI] [Load DMI File] [Save DMI File]
s
n
s
↑ ↓
Award DMI Configuration Utility Copyright Award Software Inc, 1996
BIOS
System
Enclosure/Chassis
Processor
Memory Controller
Memory Module
Memory Module
Memory Module
Memory Module
Cache
Cache
Port Connector
Port Connector
Port Connector
Port Connector
Port Connector
Port Connector
Port Connector
System Slots
← →
Move cursor ENTER-Accept DEL-Delete ESC-Abort&Exit
Type : BIOS Information
Handle : 0000
Vendor Name : Award Software International, Inc.
BIOS Version : 4.51PG
BIOS Starting Address Segment : E000
BIOS Build Date :
BIOS Characteristics : Press [ENTER] for details
Size of BIOS ROM : 0128K
*** BIOS Auto Detect ***
The four menus located on top of the DMI Configuration Utility screen
are Edit DMI, Add DMI, Load DMI File and Save DMI File. Use the ←
or → (left or right) arrow keys to select a menu from the Menu bar.
On the left side of the screen is a list of the system configuration items.
Use the ↑ or ↓ (up or down) arrow keys to select an item. The commands at the bottom of the screen will allow you to navigate through
the various setup menus.
54
Edit DMI
1. Use the ← or → arrow keys to select the Edit DMI menu.
2. Highlight the item on the left screen that you would like to edit by
using the ↑ or ↓ arrow keys, then press <Enter>.
3. The cursor will move to the screen you select allowing you to edit
information. The screen will also display the auto-detected information.
4. Press <F10> to update the edited information into the flash ROM.
Add DMI
1. Use the ← or → arrow keys to select the Add DMI menu.
2. Highlight the item on the left screen that you would like to add by
using the ↑ or ↓ arrow keys, then press <Enter>.
3. The cursor will move to the screen you select allowing you to enter
information about the added item.
4. Press <F10> to save information into the flash ROM.
To view information about the added items, go to the Edit DMI menu.
Load DMI File
1. Use the ← or → arrow keys to select the Load DMI File menu.
2. The following message will appear.
Press [Enter] to select DMI file for load
Press <Enter>.
3. The DMI files will appear on the screen. Select the file you would
like to load and press <Enter>.
55
4. The following message will appear.
Do you want to execute? (Y/N)
Type <Y>. All previous DMI structures will be destroyed and the
new file will be saved into the flash ROM.
Save DMI File
1. Use the ← or → arrow keys to select the Save DMI File menu.
2. The following message will appear.
Press [Enter] to select DMI file for save
Press <Enter>.
3. Enter the directory and filename under which you would like the
DMI file saved.
System Error Report
When the BIOS encounters an error that requires the user to correct
something, either a beep code will sound or a message will be displayed in a box in the middle of the screen and the message, PRESS
F1 TO CONTINUE, CTRL-ALT-ESC or DEL TO ENTER SETUP, will be
shown in the information box at the bottom. Enter Setup to correct the
error.
POST Beep
There are two kinds of beep codes in the BIOS. One code indicates
that a video error has occured and the BIOS cannot initialize the video
screen to display any additional information. This beep code consists of
a single long beep followed by three short beeps. The other code indicates that a DRAM error has occured. This beep code consists of a
single long beep.
56
Error Messages
One or more of the following messages may be displayed if the BIOS
detects an error during the POST. This list indicates the error messages
for all Awards BIOSes:
CMOS BATTERY HAS FAILED
The CMOS battery is no longer functional. It should be replaced.
CMOS CHECKSUM ERROR
Checksum of CMOS is incorrect. This can indicate that CMOS has become corrupt. This error may have been caused by a weak battery.
Check the battery and replace if necessary.
DISPLAY SWITCH IS SET INCORRECTLY
The display switch on the motherboard can be set to either monochrome or color. This indicates the switch is set to a different setting
than indicated in Setup. Determine which setting is correct, then either
turn off the system and change the jumper or enter Setup and change
the VIDEO selection.
FLOPPY DISK(S) fail (80)
Unable to reset floppy subsystem.
FLOPPY DISK(S) fail (40)
Floppy type mismatch.
Hard Disk(s) fail (80)
HDD reset failed.
Hard Disk(s) fail (40)
HDD controller diagnostics failed.
Hard Disk(s) fail (20)
HDD initialization error.
Hard Disk(s) fail (10)
Unable to recalibrate fixed disk.
57
Hard Disk(s) fail (08)
Sector Verify failed.
Keyboard is locked out - Unlock the key
The BIOS detects that the keyboard is locked. Keyboard controller is
pulled low.
Keyboard error or no keyboard present
Cannot initialize the keyboard. Make sure the keyboard is attached
correctly and no keys are being pressed during the boot.
Manufacturing POST loop
System will repeat POST procedure infinitely while the keyboard controller is pull low. This is also used for the M/B burn in test at the factory.
BIOS ROM checksum error - System halted
The checksum of ROM address F0000H-FFFFFH is bad.
Memory test fail
The BIOS reports memory test fail if the memory has error(s).
Driver Installation
To install the Intel IDE drivers supported by the 586IVX system board,
please refer to the "Readme" file contained in the provided diskettes.
58
Chapter 4
Troubleshooting Checklist
This chapter of the manual is designed to help you with problems that
you may encounter with your personal computer. To efficiently
troubleshoot your system, treat each problem individually. This is to
ensure an accurate diagnosis of the problem in case a problem has
multiple causes.
Some of the most common things to check when you encounter
problems while using your system are listed below.
1. The power switch of each peripheral device is turned on.
2. All cables and power cords are tightly connected.
3. The electrical outlet to which your peripheral devices are connected
is working. Test the outlet by plugging in a lamp or other electrical
device.
4. The monitor is turned on.
5. The display’s brightness and contrast controls are adjusted properly.
6. All add-in boards in the expansion slots are seated securely.
7. Any add-in board you have installed is designed for your system and
is set up correctly.
Monitor/Display
If the display screen remains dark after the system is turned on:
1. Make sure that the monitor’s power switch is on.
2. Check that one end of the monitor’s power cord is properly attached
to the monitor and the other end is plugged into a working AC outlet.
If necessary, try another outlet.
3. Check that the video input cable is properly attached to the monitor
and the system’s display adapter.
4. Adjust the brightness of the display by turning the monitor’s
brightness control knob.
59
Hard Drive
Hard disk failure.
1. Make sure the correct drive type for the hard disk drive has been
entered in the BIOS.
2. If the system is configured with two hard drives, make sure the
bootable (first) hard drive is configured as Master and the second
hard drive is configured as Slave.
Excessively long formatting period.
1. If your hard drive takes an excessively long period of time to format,
it is likely a cable connection problem.
Parallel Port
The parallel printer doesn’t respond when you try to print.
1. Make sure that your printer is turned on and that the printer is online.
2. Make sure your software is configured for the right type of printer
attached.
3. Verify that the onboard LPT port’s I/O address and IRQ settings are
configured correctly.
4. Verify that the attached device works by attaching it to a parallel port
that is working and configured correctly. If it works, the printer can
be assumed to be in good condition. If the printer remains
inoperative, replace the printer cable and try again.
Serial Port
The serial device (modem, printer) doesn’t output anything or is
outputting garbled characters.
1. Make sure that the serial device’s power is turned on and that the
device is on-line.
2. Verify that the device is plugged into the correct serial port on the
rear of the computer.
60
3. Verify that the attached serial device works by attaching it to a serial
port that is working and configured correctly. If the serial device
does not work, either the cable or the serial device has a problem. If
the serial device works, the problem may be due to the onboard I/O
or the address setting.
4. Make sure the COM port settings and I/O address are configured
correctly.
Keyboard
Nothing happens when a key on the keyboard was pressed.
1. Make sure the keyboard is properly connected.
2. Make sure there are no objects resting on the keyboard and that no
keys are pressed during the booting process.
System Board
1. Make sure the add-in card is seated securely in the expansion slot.
If the add-in card is loose, power off the system, re-install the card
and power up the system.
2. Check the jumper settings to ensure that the jumpers are properly
set.
3. Verify that all SIMMs are seated securely into the SIMM sockets.
4. Make sure the SIMMs are in the correct locations.
5. If the board fails to function, place the board on a flat surface and
seat all socketed components. Gently press each component into
the socket.
6. If you made changes to the BIOS settings, re-enter setup and load
the BIOS defaults.
61
Appendix A
Types of Modules
The following modules have been tested with this board. Most untested
brands will work but a few may fail to do so.
SIMM
1MBx32
2MBx32
4MBx32
8MBx32
Brand
Fujitsu
OKI
OKI
NEC
Micron
TI
Micron
Micron
NEC
Hitachi
Fujitsu
Mitsubishi
Hitachi
NEC
NEC
NEC
Chip Number
81C1000A-70
M51440A-70
M511000B-70
424400-60
40447-60
TMS4400DJ-70
MT4C4007-70 (EDO)
MT4C4007-60 (EDO)
4218165-60 (EDO)
7400AS-70
8117400-70
422A06-70
5117400AS-70
4217400-60
4217405-70 (EDO)
4217405-60 (EDO)
62
Memory Address Map
Address Name Function
0000000 to 640KB System System Board Memory
009FFFF Board RAM
00A0000 to 128KB Video Reserved for Graphics
00BFFFF Display Memory Display Memory
00C0000 to 160KB I/O Reserved for ROM on
00E7FFF Expansion ROM I/O Adapter Card
00E8000 to 96KB ROM on System Board BIOS
00FFFFF the System Board
0100000 to Maximum System Board Memory
7FFFFFF Memory 128MB
Appendix B
Memory and I/O Maps
63
I/O Address Map
I/O Address Function
0000-001F DMA Controller 1, 8237A-5
0020-003F Interrupt Controller 1, 8259A, Master
0040-005F Timer, 8254-2
0060-006F 8742 (Keyboard Controller)
0070-007F Real-time Clock, NMI
0080-009F DMA Page Memory, 74LS612
00A0-00BF Interrupt Controller 2, 8259A
00C0-00DF DMA Controller 2, 8237A-5
00E8 Shadow RAM and Cache Control Bit
00F0 Clear Numeric Processor
00F1 Reset Numeric Processor Extension
00F8-00FF Numeric Processor Extension
01F0-01F8 Fixed Disk
0200-0207 Game I/O
0278-027F Parallel Printer Port 2
02F8-02FF Serial Port 2
0300-031F Prototype Card
0360-036F Reserved
0378-037F Parallel Printer Port 1
0380-038F SDLC, Bisynchronous 2
03A0-03AF Bisynchronous 1
03B0-03BF Monochrome Display and Printer Adapter
03C0-03CF Reserved
03D0-03DF Color/Graphics Monitor Adapter
03F0-03F7 Diskette Controller
03F8-03FF Serial Port 1
(Non-maskable Interrupt) Mask
Extension Busy
64
Note:
The I/O address hex 0000 to 00FF are reserved for the system board
I/O. Hex 0100 to 03FF are available on the I/O channels.
Connectors
Appendix C
Connectors
J2
J4
J8
J9
J10
J11
J12
J13
CN1
CN5
CN6
USB 1 connector
USB 2 connector
IrDA connector
Fan connector
Floppy disk drive connector
Primary IDE hard disk drive connector
Secondary IDE hard disk drive connector
ATX power LED
HD LED
Green LED
ATX power switch
Green switch
Reset switch
AT power LED/Keylock connector
Speaker connector
PS/2 keyboard port
COM 2 serial port
COM 1 serial port
CN7
Parallel printer port
65
CN8
J8
J11
J12
J10J9PL1
J13
CN8J2CN7
PS/2 mouse port
CN9
PL1
Game port
ATX power connector
CN5J4CN1
CN6
66
Pin Assignments
J9 - Fan connector
Pin
1
2
3
Function
Ground
+12V
Ground
J8 - Infrared connector
Pin
1
2
3
4
5
Function
IRTX
GND
IRRX
IRR3
VCC
67
J13
1
+
+
+
SPW-LED
(ATX power LED)
2
HD-LED
1
(Primary/Secondary
2
IDE LED)
1
G-LED
(Green LED)
2
Pin 1
Pin 2
Pin 1
Pin 2
Pin 1
Pin 2
+5V
Ground
+5V
Signal
+5V
Signal
1
SP-SW
(ATX power switch)
2
1
G-SW
(Green switch)
2
1
RESET
(Reset switch)
2
1
2
SPKR
(Speaker connector)
3
4
1
2
KEYLOCK
3
(AT power LED/
Keylock Connector)
4
5
Pin 1
Pin 2
Pin 1
Pin 2
Pin 1
Pin 2
Pin 1
Pin 2
Pin 3
Pin 4
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Signal
Ground
Signal
Ground
Signal
Ground
Signal
N.C.
Ground
+5V
+5V
N.C.
Ground
Keylock Signal
Ground
68
Loading...
