GETTING STARTED USER GUIDE
OX 7102-CII
OX 7104-CII
Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments certifies that this instrument has been calibrated using standards and instruments traceable to international standards.
We guarantee that at the time of shipping your instrument has met its published specifications.
An NIST traceable certificate may be requested at the time of purchase, or obtained by returning the instrument to our repair and calibration facility, for a nominal charge.
The recommended calibration interval for this instrument is 12 months and begins on the date of receipt by the customer. For recalibration, please use our calibration services. Refer to our repair and calibration section at www.aemc.com.
Serial #: _ ________________________________
Catalog #: ______________________________
Model #: OX 7102-CII / OX 7104-CII
Please fill in the appropriate date as indicated:
Date Received: __________________________________
Date Calibration Due: ________________________
Chauvin Arnoux®, Inc. d.b.a AEMC® Instruments
www.aemc.com
Model OX 7102-CII Kit
Cat. #2124.57
PRODUCT PACKAGING
Ships with the following:
(Qty. 1)
Portable Oscilloscope OX7102-CII
Cat. #2124.57
(Qty. 2)
PROBIX PRHX1, 1/10 Probe
Cat. #2124.73
(Qty 2 red, 2 black)
Grip Probes
Cat. #2124.86
(Qty. 1)
Aluminum Carrying Case
Cat. #2124.79
(Qty. 2)
PROBIX Banana Plug Adapter
Cat. #2124.76
(Qty. 1)
Ethernet Cable - Crossed
Cat. 2124.81
(Qty. 1)
Power Adapter 115/230V
Cat. #5000.15
(Qty. 1)
NiMH Battery Pack
Cat. #2140.19
(Qty. 2)
Stylus
Cat. 5000.17 - replacement set of 5
(Qty. 1)
Ethernet Cable - Straight
Cat. 2124.80
|
Also Included: |
|
|
• SX-METRO Software on CD-ROM |
|
|
• User Manual on CD-ROM in Paper Sleeve |
|
(Qty. 2 red, 2 black) |
• Three-Year Warranty Card |
|
• Recorder/Harmonic/Power/50K Memory |
||
Color-coded Leads (1.5m) with Probe Tips |
||
Cat. #2124.85 |
Option (installed) |
|
|
• Quick Reference User Manual |
|
|
|
Model OX 7104-CII Kit
Cat. #2124.65
PRODUCT PACKAGING
Ships with the following:
(Qty. 1)
Portable Oscilloscope OX7104-CII
Cat. #2124.65
(Qty. 4)
PROBIX PRHX1, 1/10 Probe
Cat. #2124.73
(Qty 4 red, 4 black)
Grip Probes
Cat. #2124.86
(Qty. 1)
Aluminum Carrying Case
Cat. #2124.79
(Qty. 4)
PROBIX Banana Plug Adapter
Cat. #2124.76
(Qty. 1)
Ethernet Cable - Crossed
Cat. 2124.81
(Qty. 1)
Power Adapter 115/230V
Cat. #5000.15
(Qty. 1)
NiMH Battery Pack
Cat. #2140.19
(Qty. 2)
Stylus
Cat. 5000.17 - replacement set of 5
(Qty. 1)
Ethernet Cable - Straight
Cat. 2124.80
|
Also Included: |
|
|
• SX-METRO Software on CD-ROM |
|
|
• User Manual on CD-ROM in Paper Sleeve |
|
(Qty. 4 red, 4 black) |
• Three-Year Warranty Card |
|
• Recorder/Harmonic/Power/50K Memory |
||
Set of Color-coded Leads (1.5m) with Probe Tips |
||
Cat. #2124.85 |
Option (installed) |
|
|
• Quick Reference User Manual |
|
|
|
Model OX CII Series Power Kit
Cat. #2124.94
PRODUCT PACKAGING
Ships with the following:
(Qty. 1) |
(Qty. 3) |
PROBIX K Thermocouple Adapter |
Set of Color-coded Leads w/ Alligator Clips |
Cat. #2124.78 |
Cat. #2124.84 |
(Qty. 1) |
(Qty. 3) |
Small Classic Tool Bag |
MiniFlex™ 0.5A to 300A, 3MHz sensors |
Cat. #2133.72 |
Cat. #2124.92 |
